Middleby G-26 Parts List

parts manual

MODEL G-26

INFRARED CONVEYOR OVEN

G-26 (Eng, UL)

CONTENTS page

KEY SPARE PARTS KIT................................................ 2

HEATING ELEMENTS AND THERMOCOUPLES .......... 3

BODY COMPONENTS ................................................ 4-5

ELECTRICAL COMPONENTS .................................... 6-7

P/N 39857

Rev. B  V1  6/99

Key Spare Parts Kit (Kit P/N ACSKG26)

ITEM PART # QUANTITY DESCRIPTION

1 7608516 1 Transformer Ass'y, 32V

2 3002686 1 Cooling Fan

3 3000330 1 Cooling Fan Grille And Filter

4 3004265 1 Thermocouple

5 3002755 2 Motor Brushes

6 34079 1 Gear Motor

7 7610250 1 Control, MenuSelect G26

8 97397 1 Transformer, 12V

9 82905 1 Solid State Relay

10 3003839 1 Rocker Switch, SPST

11 3000227 1 Circuit Breaker

12 97393 1 Bayonet Lock Ass'y

13 3002918 1 Main Relay

Heating Elements and Thermocouples

ITEM PART # QUANTITY DESCRIPTION

1 7610794 2 HEATING ELEMENT - HEARTH PLATE, 208V

7609642 2 HEATING ELEMENT - HEARTH PLATE, 240V

2 33055 4 PORCELAIN TUBE

3 3004265 4 THERMOCOUPLE

NOTE: Always replace bayonet fitting when replacing thermocouple.

4 97393 4 BAYONET FITTING w/COMPRESSION FERRULE
