Page 1
Principle
Middleby Marshall PS Series conveyor ovens bake
both faster and at a lower temperature than other
ovens. Patented vertical columns of hot air move heat
aerodynamically instead of using high temperatures. The
streams of hot air remove the boundary layers of cool
heavy air which tend to insulate the product. This gives
very rapid baking without burning the product. All PS670
WOW!TM ovens are designed to cook pizza 30% faster than
other conveyor ovens.
PS670
Direct Gas Fired Conveyor Oven
PATENTS PENDING
Standard Features
• Impingement PLUS! low oven prole and dual air
return
• Patented EMS energy Management System
reduces gas consumption and increases cooking
efciency
• 70” (1778mm) long cooking chamber
• 32” (813mm) wide, 106” (2692mm) long conveyor
belt
Speed
• Advanced technology air delivery system bakes up
to 30% faster than standard conveyor ovens
Energy Management System
The PS670 WOW!
Ma nagement System (EMS ) that automatic ally
reduces gas consumption. Touch Screen Control can
be programmed in one energy saving mode.
Automatic “energy eye” saves gas when no pizzas are
in the oven
oven features an Energy
TM
Rev 3 (11/10)
Cleanability
PS670 Ovens are designed for easy cleaning. Removable
parts include: crumb pans, end panels, air ngers, and a
folding conveyor belt assembly.
Easily Services
Control compartment is designed for quick and easy
access. All electrical components are door-mounted.
Warranty
All PS670 models have a one year parts and labor warranty.
Oven start-up and demonstration are included at no
additional charge (USA Only)
Ventilation
For installation under a ventilation hood only.
1401 Toastmaster Drive
Elgin, IL 60120 USA
(847) 741-3300 Fax: (847) 741-0015
www.middleby-marshall.com
Page 2
PS670 Series
Direct Gas Fired Conveyor Oven
TOP VIEW
PS670-1 Single Oven
with 19” (483mm) leg extensions
FRONT VIEW
SIDE VIEW
REAR
VIEWS
PS670-2 Double Oven
with 10” (254mm) leg extensions
FRONT VIEW
PS670-2 Double Oven
with 15” (381mm) leg extensions
FRONT VIEW
REAR
VIEWS
REAR
VIEWS
Rev 3 (11/10)
Page 3
PS670-3 Triple Oven
with 4” (102mm) leg extensions
FRONT VIEW
PS670 Series
Direct Gas Fired Conveyor Oven
REAR
VIEWS
PS670-3 triple Oven
without leg extensions
FRONT VIEW
REAR
VIEWS
Rev 3 (11/10)
Page 4
PS670 Series
Direct Gas Fired Conveyor Oven
RECOMMENDED MINIMUM CLEARANCES
Rear of Oven to Wall Control end of conveyor to wall Non-control end of conveyor to wall
0” (0mm) 0” (0mm) 0” (0mm)
Heating Baking Belt Belt Max. Bake Time Ship Ship
Zone Area Length Width Depth Height Temp Range Wt Cube
PS670-1 with 19” 70” 15.5sq.ft. 106” 32” 61-3/4” 48-1/4” 5500F 3:00 - 30:00 1750lbs. 160ft
(483mm) leg extensions 1778mm 1.44m2 2692mm 813mm 1568mm 1226mm 2880C 795kg 4.5m
PS670-2 with 10” 140” 31sq.ft. 106”” 32” 61-3/4” 57-3/4” 5500F 3:00 - 30:00 3500lbs. 320ft
(254mm) leg extensions 3556mm 2.88m2 2692mm 813mm 1568mm 1467mm 2880C 1589kg 9.0m
PS670-2 with 15” 140” 31sq.ft. 106”” 32” 61-3/4” 62-3/4” 5500F 3:00 - 30:00 3500lbs. 320ft
(381mm) leg extensions 3556mm 2.88m2 2692mm 813mm 1568mm 1594mm 2880C 1589kg 9.0m
PS670-3 with 4” 210” 46.5sq.ft. 106”” 32” 61-3/4” 72-1/4”” 5500F 3:00 - 30:00 5250lbs. 480ft
(102mm) leg extensions 5334mm 4.32m2 2692mm 813mm 1568mm 1835mm 2880C 2384kg 13.5m
PS670-3 without 210” 46.5sq.ft. 106”” 32” 61-3/4” 68” 5500F 3:00 - 30:00 3748lbs. 480ft
leg extensions 5334mm 4.32m2 2692mm 813mm 1568mm 1727mm 2880C 1700kg 13.5m
ELECTRICAL SPECIFICATIONS
Model Version Voltage Phase Freq Amps* Supply Breakers
GENERAL SPECIFICATIONS
3
3
3
3
3
3
3
3
3
3
PS670 208-240v 1 50/60 Hz 20A 2 pole, 3 wire As per
(2 hot, 1 ground) local codes
* The current draw rating shown above are maximum values for normal operation, amperage draw will be less than the listed value.
NOTE: Each oven includes a 6’ cord with NEMA# L6-20P plug. Customer to provide NEMA# L6-20R receptacle
GAS SUPPLY SPECIFICATIONS
Min. Gas Pipe size Supply Gas Pressure Rated Heat Input
Natural Gas 2” (50.8mm) main 6-12” W.C. 175,000 BTU
One 1-1/4” (12.7mm NPT (14.9-29.8 mbar) (44.1 kcal,
branch to lower oven cavity 51.3 kW/hr)
with individual full-ow per cavity
shutoff valve
Propane Gas 2” (50.8mm) main 6-12” W.C.. 175,000 BTU
One 1-1/4” (12.7mm NPT (14.9-29.8 mbar) (44.1 kcal,
branch to lower oven cavity 51.3 kW/hr)
with individual full-ow per cavity
shutoff valve
* The gas supply pressures shown are for ovens installed in North America. The required gas supply
pressures of other locations are dependant on the local gas type and on all applicable codes.
Each oven comes with (1) 1-1/4” NPT x 48” exible vinyl coated gas hose.
ALL SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE.
Middleby Marshall, in accord with its policy to continually improve its products, reserves the right to
change materials or specications without notice. Such revisions do not entitle the buyer to correspond-
ing changes, improvements, additions, or replacements for previously purchased equipment.
© 2010 Middleby Marshall, Inc.
1400 Toastmaster Drive, Elgin, IL 60120-9272, USA • (847) 741-3300 • Fax: (847) 741-0015
Rev 3 (11/10) www.middleby-marshall.com
