Microsoft RM-957 User Guide

User Guide

Nokia 208

Issue draft-2013-09-05 EN

User Guide

Nokia 208

Safety 3

Get started 4

Keys and parts 4 Insert a SIM card and battery 4 Insert a memory card 6 Charge the battery 6 Copy content from your old phone 7

Basics 8

Explore your phone 8 Display indicators 9 Prolong battery life 9 Personalise your home screen 10 Change your ringtone 10 Set a song as your ringtone 10 Nokia Store 11 Write text 11

People & messaging 12

Make or answer a call 12 Save a name and phone number 12 Send a message 13 Check your voice mail 13 Mail for Exchange 14 Set up your mail account 14 Send a mail 15 Get social 15 Chat with your friends 16

Camera 17

Take a photo 17 Take a self-portrait 17 Send a photo or video 18

Maps & navigation 19

Find nearby places 19

Internet 20

Browse the web 20 Add a website to your favourites 20

Office 21

Add a calendar entry 21 Change the time and date 21 Set an alarm 21

Phone management & connectivity 22

Share your content using Slam 22 Back up content to a memory card 22 Restore original settings 23 Update your phone software 23 Access codes 23

Product and safety information 25

Safety

We invite you to read the instructions on this guide before using the device.

SWITCH OFF IN RESTRICTED AREAS

Switch the device off when mobile phone use is not allowed or when it may cause interference or danger, for example, in aircraft, in hospitals or near medical equipment, fuel, chemicals, or

blasting areas. Obey all instructions in restricted areas.

ROAD SAFETY COMES FIRST

Obey all local laws. Always keep your hands free to operate the vehicle while driving. Your first consideration while driving should be road safety.

INTERFERENCE

All wireless devices may be susceptible to interference, which could affect performance.

QUALIFIED SERVICE

Only qualified personnel may install or repair this product.

BATTERIES, CHARGERS, AND OTHER ACCESSORIES

Use only batteries, chargers, and other accessories approved by Nokia for use with thi s device. Do not connect incompatible products.

KEEP YOUR DEVICE DRY

Your device is not water-resistant. Keep it dry.

PROTECT YOUR HEARING

To prevent possible hearing damage, do not listen at high volume levels for long periods. Exercise caution when holding your device near your ear while the loudspeaker is in use.

SAR

This device meets RF exposure guidelines when used either in the normal use position against the ear or when positioned at least 1.5 centimetres (5/8 inch) away from the body. The specific maximum SAR values can be found in the Certification Information (SAR) section

of this user guide. For more info, go to www.sar-tick.com. When a carry case, belt clip or other form of device holder is used for body-worn operation, it should

not contain metal and should provide at least the above-stated separation distance from the body. Note that mobile devices may be transmitting even if you are not making a voice call.

Get started

Get to grips with the basics, and have your phone up and running in no time.

Keys and parts

Explore the keys and parts of your new phone. 1 Audio connector (3.5 mm AHJ)

2Micro-USB connector 3 Scroll key. Also used to change the volume.

Press the key up or down. 4End/Power key 5Microphone 6 Call key 7Selection keys 8Earpiece 9 Camera lens. Before using the camera,

remove the protective tape from the lens. 10 Back cover release button 11 Antenna area

Avoid touching the antenna area while the antenna is in use. Contact with antennas affects the communication quality and may reduce battery life due to higher power level during operation.

Do not connect products that create an output signal, as this may damage the device. Do not connect any voltage source to the audio connector. If you connect an external device or headset, other than those approved for use with this device, to the audio connector, pay special attention to volume levels.

Tip: Lock the keys when not using your phone. Select Menu, and press *. To unlock, select Unlock, and press *.

You can set your phone to ask for the lock code that you define. The default lock code is 12345. Your phone uses S40 software. Some of the accessories mentioned in this user guide may be sold separately. The images in this guide may differ from your device screen.

Insert a SIM card and battery

Learn how to insert a SIM card and the battery. The SIM1 holder under the battery can be used for both 3G and 2G SIMs.

1. Press the release button, and lift and remove the back cover.

Note: Switch the device off and disconnect the charger and any other device before removing

any covers. Avoid touching electronic components while changing any covers. Always store and

use the device with any covers attached.

2. If the battery is in the phone, lift it out.

3. Lift the cover of the SIM1 holder, and put the SIM in, contact area face down.

Important: This devi ce is desig ned t o be u sed wi th a mini-UICC SIM card, also known as a micro-

SIM card only. A micro-SIM card is smaller than the standard SIM card. Use of incompatible SIM

cards, or use of SIM card adapters, may damage the card or the device, and may corrupt data

stored on the card.

4. Line up the battery contacts, and put the battery in.

5. Press the back cover down until it locks into place. To switch the phone on, press and hold the

power key

until the phone vibrates.

Insert a memory card

Read on to learn how to insert a memory card into your phone.

Use only compatible memory cards approved for use with this device. Incompatible cards may damage the card and the device and corrupt data stored on the card.

1. Press the release button, and lift and remove the back cover.

Note: Switch the device off and disconnect the charger and any other device before removing

any covers. Avoid touching electronic components while changing any covers. Always store and

use the device with any covers attached.

2. Push the card in with the contact area face down until it locks into place.

3. To remove, push the card in, until it is released.

Important: Do not remove the memory card when an app is using it. Doing so may damage the

memory card and the device and corrupt data stored on the card.

Charge the battery

Your battery has been partially charged at the factory, but you may need to recharge it before you can use your phone.

1. Plug the charger into a wall outlet.

2. Connect the charger to the phone. When done, unplug the charger from the phone, then from the

wall outlet.

If the battery is completely discharged, it may take several minutes before the charging indicator is displayed or before any calls can be made.

Tip: You can use USB charging when a wall outlet is not available. Data can be transferred while

charging the device. The efficiency of USB charging power varies significantly, and it may take

a long time for charging to start and the device to start functioning.

Copy content from your old phone

Easily get your contacts, calendar entries, and other stuff to your new phone.

1. Switch Bluetooth on in both phones. To switch Bluetooth on on your new phone, select Menu > Settings > Connectivity > Bluetooth.

2. On your new phone, select Menu > Settings > Sync & backup > Copy from dev..

3. Select what you want to copy, then select Done.

4. Choose your old phone from the list of found devices.

5. If asked, create a one-time passcode (such as 123), and select OK.

6. Check that the codes match on both phones.

7. Follow the instructions shown on both phones.

Basics

Learn how to get the most out of your new phone.

Explore your phone

Explore your phone with a simple key press.

1. To see the apps and features of your phone, press Menu.

2. To go to an app or feature, press the scroll key up, down, left, or right.

3. To open the app or select the feature, press Select.

Select

4. To go back to the previous view, press Back.

5. To go back to the home screen, press .

Back

Display indicators

The display indicators on your phone tell you the current time, battery and signal strength, and much more.

You have unread messages.

You have unsent or failed messages.

The keys are locked.

An alarm is set. Bluetooth is on.

The phone is connected to a GSM network.

All incoming calls are forwarded to another number.

The phone is connected to a headset.

The phone is connected to a device, such as a PC, with a USB cable.

The type of mobile network you're currently connected to may be shown with a single letter, a combination of letters, or a combination of letters and numbers. For example, your network service provider.

The icons may vary depending on your region or network service provider.

, depending on

Prolong battery life

Get the most out of your phone while getting the battery life you need. There are steps you can take to save power on your phone.

• Always charge the battery fully.

• Mute unnecessary sounds, such as key press sounds.

• Use wired headphones, rather than the loudspeaker. To save power, you can:

Lower the backlight brightness Select Menu > Settings > Display > Backlight, and change

Set the backlight to switch off after a short time

the setting for Backlight intensity.

Select Menu > Settings > Display > Backlight, and change the setting for Backlight time-out.
