User Guide

Nokia XXX

Issue 1 EN

User Guide

Nokia XXX

Safety 4

Get started 5

Keys and parts 5 Insert a SIM card, battery, and memory

card 5 Charge the battery 6 Copy contacts from your old phone 7

Basics 8

Display indicators 8 Touch screen actions 8 Switch between views 10 Check your activity 10 Change settings quickly 11 Prolong battery life 11 Reorganise the apps menu 12 Personalise the lock screen 12 Change your ringtone 12 Add a full keyboard or phone keypad 13 Add a writing language 13 Keys on the keyboard 13 Write using the keyboard 13 Keys on the keypad 14 Write using the keypad 14 Use predictive text 15 Nokia Store 15

People & messaging 16

Make or answer a call 16 Save a name and phone number 16 Add social info to contacts 17 Update your status 17

Send a message 17 Mail for Exchange 18 Set up your mail account 18 Send a mail 19 Chat with your friends 19 Check your voice mail 20

Camera 21

Take a photo 21 Record a video 21 Share your photo or video 21

Maps & navigation 23

Find nearby places 23

Internet 24

Browse the web 24 Add a website to your favourites 24

Entertainment 25

Play a song 25 Listen to the radio 25

Office 26

Change the time and date 26 Set an alarm 26 Add a calendar entry 26

Phone management & connectivity 27

Share your content using Slam 27 Connect to a Wi-Fi network 27 Copy content between your phone and

computer 27 Update your phone software 28 Use your phone in flight mode 28 Access codes 28

Product and safety information 30

Safety

We invite you to read the instructions on this guide before using the device.

SWITCH OFF IN RESTRICTED AREAS

Switch the device off when mobile phone use is not allowed or when it may cause interference or danger, for example, in aircraft, in hospitals or near medical equipment, fuel, chemicals, or

blasting areas. Obey all instructions in restricted areas.

ROAD SAFETY COMES FIRST

Obey all local laws. Always keep your hands free to operate the vehicle while driving. Your first consideration while driving should be road safety.

INTERFERENCE

All wireless devices may be susceptible to interference, which could affect performance.

QUALIFIED SERVICE

Only qualified personnel may install or repair this product.

BATTERIES, CHARGERS, AND OTHER ACCESSORIES

Use only batteries, chargers, and other accessories approved by Nokia for use with th is device. Do not connect incompatible products.

KEEP YOUR DEVICE DRY

Your device is not water-resistant. Keep it dry.

PROTECT YOUR HEARING

To prevent possible hearing damage, do not listen at high volume levels for long periods. Exercise caution when holding your device near your ear while the loudspeaker is in use.

SAR

This device meets RF exposure guidelines when used either in the normal use position against

the ear or when positioned at least 1.5 centimetre (5/8 inch) away from the body. The specific maximum SAR values can be found in the Certification Information (SAR) section of this user guide. For more info, go to www.sar-tick.com.

When a carry case, belt clip or other form of device holder is used for body-worn operation, it should not contain metal and should provide at least the above-stated separation distance from the body. Note that mobile devices may be transmitting even if you are not making a voice call.

Get started

Get to grips with the basics, and have your phone up and running in no time.

Keys and parts

Explore the keys and parts of your new phone. 1 Audio connector (3.5 mm AHJ)

2Earpiece 3Micro-USB connector 4 Volume/Zoom keys 5 Lock/Power key 6Microphone 7 Back key 8 Touch screen 9 Camera flash 10 Camera lens. Before using the camera,

remove the protective tape from the lens. 11 Back cover release button 12 Antenna area

You can set your phone to ask for the lock code that you define.

The antenna area is highlighted. Avoid touching the antenna area while the antenna is in use. Contact with antennas affects the

communication quality and may reduce battery life due to higher power level during operation. Do not connect products that create an output signal, as this may damage the device. Do not connect

any voltage source to the audio connector. If you connect an external device or headset, other than those approved for use with this device, to the audio connector, pay special attention to volume levels.

Some of the accessories mentioned in this user guide may be sold separately.

Insert a SIM card, battery, and memory card

Learn how to insert a battery and SIM and memory cards.

Important: This devi ce is desig ned t o be u sed wi th a mini-UICC SIM card, also known as a microSIM card only. A micro-SIM card is smaller than the standard SIM card. Use of incompatible SIM cards, or use of SIM card adapters, may damage the card or the device, and may corrupt data stored on the card.

Use only compatible memory cards approved for use with this device. Incompatible cards may damage the card and the device and corrupt data stored on the card.

1. Press the release button at the back of the phone, and carefully lift and remove the back cover.

2. If the battery is in the phone, lift it out.

3. Open the SIM holder, and slide the SIM into the holder, contact area face down. Close the holder,

and lock it into place.

4. Line up the battery contacts, and put the battery in.

5. Push the memory card into the memory card slot until it locks into place.

Tip: To remove the memory card, push it in until it's released, then pull it out.

Important: Do not remove the memory card when an app is using it. Doing so may damage the

memory card and the device and corrupt data stored on the card.

6. Replace the back cover.

7. To switch on, press and hold the power key.

Note: Switch the device off and disconnect the charger and any other device before removing

any covers. Avoid touching electronic components while changing any covers. Always store and use the device with any covers attached.

Charge the battery

Your battery has been partially charged at the factory, but you may need to recharge it before you can use your phone.

1. Plug the charger into a wall outlet.

2. Connect the charger to the phone. When done, unplug the charger from the phone, then from the

wall outlet.

If the battery is completely discharged, it may take several minutes before the charging indicator is displayed or before any calls can be made.

Tip: You can use USB charging when a wall outlet is not available. Data can be transferred while charging the device. The efficiency of USB charging power varies significantly, and it may take a long time for charging to start and the device to start functioning.

Copy contacts from your old phone

Get all your contacts to your new phone in one go. Your old phone must have Bluetooth, and the contacts must be stored in the phone memory, not on

the SIM.

1. On both your new and old phone, switch Bluetooth on, and make sure both phones are visible to others.

2. On your new phone, tap

Tip: If you already have contacts on your phone, swipe up from the bottom of the screen, and tap Import contacts > Another device.

3. Move the phones close to each other. When the phones are connected using Bluetooth, the

contacts transfer starts. If your contacts are written in a language that is not supported by your new phone, the contact info

may not show correctly.

> Import contacts > Another device.

Basics

Learn how to get the most out of your new phone.

Display indicators

The display indicators on your phone tell you the current time, battery and signal strength, and much more.

An alarm is set. The silent profile is on.

Battery power level

You have new notifications. Swipe down from the top of the screen to see the details. Wi-Fi is on.

Signal strength Flight mode is on.

Bluetooth is on.

The type of mobile network you're currently connected to may be shown with a single letter, a combination of letters, or a combination of letters and numbers. For example, your network service provider.

The icons may vary depending on your region or network service provider.

Touch screen actions

Explore your phone with a tap or swipe.

1. To open an app or other item, tap the app or item.

, depending on

Important: Avoid scratching the touch screen.

2. To switch a setting on or off, tap the switch.

3. To see more options, tap and hold an item.

4. To swipe, for example, to another home screen, steadily slide your finger left or right.

5. To see more options, swipe up from the bottom of the screen if you can see three lines there.

6. To close an app and go back to the home screen, swipe in from the left or right of the screen.

7. To see notifications and change settings, swipe down from the top of the screen. To close the

menu, swipe up, or tap an empty area outside the menu.

8. To scroll through a long list or menu, slide your finger quickly up or down, and lift your finger.

9. To zoom, slide two fingers apart or together on an item.

Tip: For more info on touch screen actions, tap > Nokia Care > Tutorial.

Switch between views

Your phone has 2 home screens: one for keeping up with your activities, and another one for apps. Swipe left or right to switch between home screens.

Choose your view according to your needs:

• Easily see what you've been doing lately, and check what's happening next in your calendar.

• In the apps menu you can open apps and shortcuts, and rearrange them as you like.

Check your activity

Your phone makes it easy for you to always keep up with what's happening. In the apps menu, swipe left or right to view your activities. Here, you can see the following:

• Apps you've opened recently, grouped by date

• Your upcoming calendar events. Swipe down at the top of the activity list to see what you've got

planned next.

• Your social networking activities, like status updates and comments

• Your latest messages, missed calls, downloads, recent music, alarms, and more

Tip: You can easily pause or resume the currently-playing song directly from the list.

Tip: If you've set up a social networking account, you can post yo ur status update in this screen

when you're signed in.

Clear your activities

Tap and hold an item, and tap

Control your activities

To decide which activities you want to see, tap

. To clear all activity, tap Clear all.

> Fastlane.

Change settings quickly

Need to quickly switch your phone to silent mode? Rather than going into the phone menus, in most views, you can quickly change some settings and check notifications in the menu that opens from the top of the screen.

1. Swipe down from the top of the screen. In this screen, you can:

• See your missed calls or unread messages

• Switch your phone to silent mode

•Check for Wi-Fi networks, and connect to them

• Switch Bluetooth on or off

2. To close the menu, press the back key.

Prolong battery life

Get the most out of your phone while getting the battery life you need. There are steps you can take to save power on your phone.

To save power:

Charge wisely Always charge the battery fully.

Select only the sounds that you need Mute unnecessary sounds, such as key press sounds.
