Microsoft RM-898 User Manual

Nokia Lumia 510 User Guide

Issue 1

2 Contents

Contents

Safety	4
Get started	6

Divert calls to your voice mailbox or
another phone number	33
Make a conference call	33
Silence an incoming call	34
Use your voice to call a contact	34

Keys and parts	6
Back, start, and search keys	7
Insert the SIM card	8
Charge your phone	10
Antenna locations	12
Switch the phone on or off	12
Create your Windows Live ID	13
Windows Live ID	14
Nokia account	14
Copy contacts from your old phone	15
Lock or unlock the keys and screen	16
Headset	16
Change the volume	17
Access codes	17
Set your phone to sync with your
computer	18
Basics	19
About the start screen and apps
menu	19
Touch screen actions	19
Use your phone when it's locked	23
Switch between open apps	24
Personalize your phone	24
Text input	26
Search your phone and the web	29
Control your phone with your voice	30
Icons on the status bar	30
Use your phone in flight mode	31
Increase battery life	31
Calls	32
Call a contact	32
Call the last dialed number	32
Call your voice mailbox	32

Contacts & social networking
services	35
Contacts	35
Social networks	38
Internet	40
Internet connections	40
Internet	42
Messaging & mail	44
Messages	44
Mail	46
Camera	49
About the camera	49
Take a picture	49
Take a close-up picture	50
Take a picture in the dark	50
Take a picture of a moving object	51
Camera tips	51
Record a video	51
Save location information to your
pictures	51
Send a picture or video	52
Share your pictures and videos	53
Your pictures	53
About the Pictures hub	53
View pictures	53
Mark a picture as a favorite	55
Upload pictures and videos to the
web	55
Change the background in the
Pictures hub	55
Create an album	56

Contents 3

Copy your pictures between your
phone and PC	56
Entertainment	56
Music and videos	56
Marketplace	58
Games	61
Maps & navigation	62
Positioning and location services	62
Nokia Maps	63
Nokia Drive	67
Office	72
Clock	72
Calendar	73
Microsoft Office Mobile	75
Use the calculator	79
Connectivity & phone management	80
Bluetooth	80
Copy a picture or other content
between your phone and PC	81
Keep your phone software and
applications up to date	81
Back up, sync, and restore your
phone	82
Free up phone memory	83
Remove an application from your
phone	83
Security	83
Support	85
Product and safety information	85
Index	92

4 Safety

Safety

Read these simple guidelines. Not following them may be dangerous or illegal. For further info, read the complete user guide.

SWITCH OFF IN RESTRICTED AREAS

Switch the device off when cell phone use is not allowed or when it may cause interference or danger, for example, in aircraft, in hospitals or near medical equipment, fuel, chemicals, or blasting areas. Obey all instructions in restricted areas.

ROAD SAFETY COMES FIRST

Obey all local laws. Always keep your hands free to operate the vehicle while driving. Your first consideration while driving should be road safety.

INTERFERENCE

All wireless devices may be susceptible to interference, which could affect performance.

QUALIFIED SERVICE

Only qualified personnel may install or repair this product.

BATTERIES, CHARGERS, AND OTHER ACCESSORIES

Use only batteries, chargers, and other accessories approved by Nokia for use with this device. Third-party chargers that comply with the IEC/EN 62684 standard, and that can connect to your device micro USB connector, may be compatible. Do not connect incompatible products.

KEEP YOUR DEVICE DRY

Your device is not water-resistant. Keep it dry.

GLASS PARTS

The device screen is made of glass. This glass can break if the device is dropped on a hard surface or receives a substantial impact. If the glass breaks, do not touch the glass parts of the device or attempt to remove the broken glass from the device. Stop using the device until the glass is replaced by qualified service personnel.

Safety 5

PROTECT YOUR HEARING

To prevent possible hearing damage, do not listen at high volume levels for long periods. Exercise caution when holding your device near your ear while the loudspeaker is in use.

6 Get started

Get started

Keys and parts

1Connector for headphones and loudspeakers (3.5 mm)

2Earpiece

3Proximity sensor. Do not cover, for example, with protective film or tape.

4Volume key

5Power/Lock key

6Camera key

7Microphone

8Back key

9Start key

10Search key

11Micro-USB connector. Used also to charge the battery.

Get started

7

12Camera lens

13Loudspeaker

Back, start, and search keys

The back, start, and search keys help you to navigate your phone.

Back key

Return to the previous screen

Press . Your phone remembers all the apps and websites you have visited since the last time your screen was locked.

Switch between open apps

Press and hold , swipe left or right, and select the desired app.

Start key

Go to the start screen

Press .

Control your phone with your voice

Press and hold , and say a voice command.

This feature may not be available in all languages.

8 Get started

Search key

Search the web

Press .

Insert the SIM card

Important: This device is designed to be used with a mini-UICC SIM card, also known as a micro-SIM card only. A micro-SIM card is smaller than the standard SIM card. Use of incompatible SIM cards may damage the card or the device, and may corrupt data stored on the card.

Do not use SIM cards that have been modified to fit the micro-SIM slot. To replace a standard SIM card with a micro-SIM card, contact your service provider.

Do not attach any stickers to the card.

1Place your fingernail in the gap on the lower right edge of the phone, and carefully lift and remove the back cover.

2 If the battery is inserted, lift it out.

3 Make sure the contact area is facing down, and insert the card.

Get started

9

4 Line up the battery contacts, and insert the battery.

5 Replace the back cover.

Remove the SIM card

1Remove the back cover and battery.

2Pull the card out.

10 Get started

Charge your phone

About the battery

Use only Nokia approved chargers designated for this phone. You can also use a compatible USB cable to charge your phone (included).

You can set your phone to automatically save power when the battery charge level is low. Select >Settings and battery saver >Always turn on Battery Saver when battery is low.

When your phone goes into battery saver mode, you may not be able to change the settings of all apps.

Charge the battery

Your battery has been partially charged at the factory, but you may need to recharge it before you can switch on your phone for the first time.

You do not need to charge the battery for a specific length of time, and you can use the phone while it is charging.

If your phone is off when you start to charge the phone, it automatically switches on. Make sure you use a compatible USB charger to charge your phone.

If the phone indicates a low charge, do the following:

Charge from a wall outlet

1First connect the USB cable to the charger, plug the charger into a wall outlet, then connect the micro-USB end of the USB cable to your phone.

2When the battery is full, unplug the charger from the phone, then from the wall outlet.

Get started 11

To avoid breaking the USB cable connector, be careful when connecting or disconnecting the charger cable.

Charge from a computer

You can use USB charging when a wall outlet is not available. Data can be transferred while charging the device. The efficiency of USB charging power varies significantly, and it may take a long time for charging to start and the device to start functioning.

1 First connect the USB cable to the computer, then to your phone.

12 Get started

2When the battery is full, first unplug the USB cable from your phone, then from the computer.

If the battery is completely discharged, it may take several minutes before the charging indicator is displayed or before any calls can be made.

Antenna locations

Avoid touching the antenna area while the antenna is in use. Contact with antennas affects the communication quality and may reduce battery life due to higher power level during operation.

The antenna area is highlighted.

Switch the phone on or off

Switch the phone on

Press and hold the power key, until the phone vibrates.

Get started 13

Switch the phone off

Press and hold the power key, and drag the lock screen down.

Create your Windows Live ID

Your phone guides you through the initial setup when you put your SIM card in your phone and switch your phone on for the first time. To access all Windows Live services, create your Windows Live ID.

14 Get started

To create a Windows Live ID, you need an internet connection. For info about possible data costs, contact your network service provider. If you can't connect to the internet, you can create the account later.

If you already have a Windows Live ID, sign in with your existing username and password.

Tip: Forgotten your password? You can request it to be sent to you in a mail or text message.

To create your Windows Live ID later, go to www.live.com.

To make an emergency call during the initial setup, select emergency call.

Windows Live ID

With a Windows Live ID, you can access Windows Live and Zune services with a single username and password on your computer or phone. You can also use the same username and password to access Xbox Live services on your Xbox.

With your Windows Live ID, you can, for example:

•Download content from Marketplace

•Back up your contacts in Windows Live

•Upload, store, and share pictures and documents on SkyDrive

•Keep track of and lock your lost phone with Find My Phone

•Get your gaming achievements on your phone, and add to them when you play games on your phone

The available services may vary.

To learn more about Windows Live ID and Windows Live services, go to www.live.com.

Nokia account

With your Nokia account, you can access Nokia services with a single username and password, both on your phone and compatible computer. The available services may vary.

You can:

•Download content from Nokia services

•Save details about your phone model and contact information. You can also add your payment card details.

Get started 15

To learn more about the Nokia account and Nokia services, go to www.nokia.com/ support.

To create a Nokia account later, go to account.nokia.com.

Copy contacts from your old phone

Have your nearest and dearest instantly at your fingertips. Use the Contacts Transfer app to easily copy your contacts from your old phone.

Your old phone needs to have Bluetooth, and the contacts need to be stored in the phone memory, not on the SIM. The app does not work with all phone models.

1On your old phone, switch Bluetooth on.

2On the start screen of your new phone, swipe left to the apps menu, then select

Contacts Transfer.

3Select Continue, then switch Bluetooth on.

4Select your old phone from the list of found devices, then follow the instructions shown on both phones.

If your contacts are written in a language that is not supported by your new phone, the contact info may not be shown correctly.

16 Get started

If you have previously backed up your contacts in Windows Live, you can also import them to your phone straight from the service.

Lock or unlock the keys and screen

To avoid accidentally making a call when your phone is in your pocket or bag, lock the keys and screen of your phone.

Lock the keys and screen

Press the power key.

Unlock the keys and screen

Press the power key, and drag the lock screen up.

Set the keys and screen to lock automatically

Select >Settings and lock+wallpaper >Screen times out after, and select the length of time after which the keys and screen are locked automatically.

Headset

You can connect a compatible headset or compatible headphones to your phone.

Get started 17

Do not connect products that create an output signal, as this may damage the device. Do not connect any voltage source to the audio connector. If you connect an external device or headset, other than those approved by Nokia for use with this device, to the audio connector, pay special attention to volume levels.

Change the volume

Press the volume keys up or down.

The volume keys control all sounds, including the volume of alarms and reminders.

Tip: When you change the volume, you can also switch your phone to silent or normal mode. Select , , or .

The built-in loudspeaker allows you to speak and listen from a short distance without having to hold the phone to your ear.

Switch the loudspeaker on or off during a call

Select .

Access codes

	PIN code	This protects your SIM against unauthorized use or is required
	(4-8 digits)	to access some features.
		You can set your phone to ask for the PIN code when you switch
		it on.
		If not supplied with your card or you forget the code, contact
		your service provider.
		If you type in the code incorrectly three times in a row, you
		need to unblock the code with the PUK code.

18 Get started

	PUK code	This is required to unblock a PIN code.
	(8 digits)	If not supplied with your SIM, contact your service provider.
	IMEI number	This is used to identify valid phones in the network. The
	(15 digits)	number can also be used to block, for example, stolen phones.
		You may also need to give the number to Nokia Care services.
		To view your IMEI number, dial *#06#.
	Lock code (security	This helps you protect your phone against unauthorized use.
	code)	You can set your phone to ask for the lock code that you
	(min. 4 digits)
		define.
		Keep the code secret and in a safe place, separate from your
		phone.
		If you forget the code and your phone is locked, your phone
		will require service. Additional charges may apply, and all the
		personal data in your phone may be deleted.
		For more information, contact Nokia Care or your phone
		dealer.

The personal unblocking key (PUK) code and the universal personal unblocking key (UPUK) code (8 digits) are required to change a blocked PIN code and UPIN code, respectively. These codes are not supplied with the SIM card. Contact your local service provider for the codes.

Set your phone to sync with your computer

With the Zune PC app, you can sync music, videos, and pictures between your phone and your compatible computer. You can also back up and update your phone with the latest software, to improve performance and get new features.

Basics 19

1Download and install the latest version of Zune on your PC from www.zune.net.

Tip: If you're using an Apple Mac, download Windows Phone 7 Connector for Mac from the Mac App Store.

2Make sure your phone is not locked with a security code.

3Connect your phone to your computer with a compatible USB cable, then follow the instructions shown on your computer.

4To change Zune sync settings, on your computer, select SETTINGS.

If you have previously used another app, such as Nokia Suite or Nokia Ovi Suite, to sync your files between your phone and computer, you can set Zune to sync files to the same folders you have used earlier, and have your music and other content easily synced to your new phone.

Basics

About the start screen and apps menu

The two main views in your phone are:

•Start screen

Tap the tiles to open your favorite apps. Animated tiles show missed calls and received messages, the latest news and weather forecasts, your friends' online statuses, and more.

You can rearrange the tiles, and pin contacts, apps, feeds, mailboxes, and other favorites. Pinned contacts' updates are shown on the tile, and you can call them directly from the start screen.

•Apps menu

All your apps are listed here, in alphabetical order. Have a lot of apps? To search for an app, select .

Tip: To switch between the start screen and apps menu, select or , or simply swipe left or right.

Touch screen actions

To use your phone, tap or tap and hold the touch screen.

Important: Avoid scratching the touch screen. Never use an actual pen, pencil, or other sharp object on the touch screen.

Open an app or other screen element

Tap the app or element.

20 Basics

Tap and hold to open a menu with further options

Place your finger on an item, until the menu opens.

Example: To edit or delete a calendar appointment, tap and hold the appointment, and select the appropriate option.

Tap and hold to drag an item

Place your finger on the item for a second or two, and slide your finger across the screen.

Basics 21

Swipe

Place a finger on the screen, and steadily slide your finger in the desired direction.

22 Basics

Example: Swipe left or right between the start screen and the apps menu, or between different views in the hubs. To quickly scroll through a long list or menu, slide your finger quickly in a flicking motion up or down the screen, then lift your finger. To stop the scrolling, tap the screen.

Zoom in or out

Place two fingers on an item, such as a map, picture, or web page, and slide your fingers apart or together.

Basics 23

Use your phone when it's locked

You can use certain features of your phone when it is locked, without having to enter the security code.

You can, for example:

•Change how your phone notifies you about incoming calls

•Answer or reject an incoming call

•Pause or resume playing music, or skip to another song

To wake up your phone, press the power key.

Change how incoming calls are notified

Press a volume key, and select ,, or .

Pause or resume music, or skip to another song

Use the music player controls displayed at the top of the screen.

You can also see:

24 Basics

•The date and time

•Your next calendar event

•Missed calls or messages

Switch between open apps

You can see which apps and tasks are open in the background, and switch between them.

Press and hold , swipe left or right, and select the desired app.

Personalize your phone

Personalize the start screen

Would you like to have only the content you need on the start screen? Move or remove tiles, and pin contacts, apps, and websites to the start screen.

You can also pin music and pictures, your latest mail, favorite contacts, and more. When you pin a contact, their feed updates are shown on the tile, and you can call them directly from the start screen.

Pin a contact

1Select >People.

2Select and hold the contact, then select pin to Start.

Basics 25

Pin an app

1Select to go to the apps menu.

2Select and hold the app, then select pin to Start.

Pin a website

Go to a website, then select >pin to start.

Move a tile

Select and hold the tile, drag and drop it to the new location, then tap the screen.

Remove a tile from the start screen

Select and hold the tile, then select .

Change your theme

You can change the colors, to match your taste and mood. Select >Settings and theme >Background or Accent color.

Tip: You can save battery power if you use a darker background.

Change the background pictures

Want to view your favorite pictures more often? You can change the background picture of the lock screen, or the Pictures hub or live tile.

Change the lock screen wallpaper

1Select >Settings and lock+wallpaper >change wallpaper.

2Select a picture, adjust it to get the best possible fit, and select .

Change the background of the Pictures hub and live tile

1In the Pictures hub, select >choose background.

2Select a picture, adjust it to get the best possible fit, and select .

Tip: If you like variety, select shuffle background, and the phone will shuffle through your pictures.

Personalize your ringtone and other tones

You can personalize your phone tones. Select >Settings and ringtones+sounds.

Select the type of ringtone or alert you want to change, and select the sound.

26 Basics

Tip: You can use the Zune PC app to create ringtones from your favorite songs.

Make your own ringtone

You can use your own sound files as ringtones.

1Connect your phone to your computer with a compatible USB cable.

2On your computer, open Zune.

3Select the sound file you want to use as a ringtone. The file must be in MP3 or WMA format, and should be less than 40 seconds long and less than 1 MB in size.

4Right-click the file, then select Edit.

5Write ringtone in the genre field, or select it from the list.

6Drag and drop the new ringtone to your phone.

7On your phone, select >Settings and ringtones+sounds, then select your ringtone.

Silence your phone

When you switch silent mode on, all ringtones and alert tones are muted. Use this when you are, for example, at the cinema or in a meeting.

Press a volume key to see the volume status bar, then select ring . Silent mode is switched on. If you have set your phone to vibrate, vibrate mode is switched on instead of silent mode.

Set your phone to vibrate

Select >Settings and ringtones+sounds, and switch Vibrate to On .

Text input

Use the on-screen keyboard

To open the on-screen keyboard, select a text box. You can use the on-screen keyboard when holding your phone in portrait or landscape mode.

Basics 27

1Character keys

2Shift key

3Numbers and symbols key

4Smiley key

5Space key

6Language key. Shown when more than one writing language is used.

7Enter key

8Backspace key

The keyboard layout can vary in different apps.

Switch between upper and lower case characters

Select the shift key. To switch caps lock mode on, select the key twice. To return to normal mode, select the shift key again.

Type in a number or special character

Select the numbers and symbols key. Some of the special character keys can bring up more symbols. To see more related symbols, select and hold a symbol or special character.

Tip: To quickly type in a number or commonly used special character, put a finger on the numbers and symbols key, slide your finger to the character, then lift your finger.

Tip: To quickly type in a period and a space when you get to the end of a sentence, select the space key twice.

Add an accent to a character

Select and hold the character, then select the accented character.

Delete a character

Select the backspace key.

Switch between the writing languages

Select the language key.

Move the cursor

Tap and hold the screen near the text until a cursor is shown. Without lifting your finger, drag the cursor to the place you want.

To move the cursor to the next row or text box, select the enter key. The function of the enter key can change in different apps. For example, in the web address box of the web browser, it acts as the Go icon.

28 Basics

Use keyboard word suggestions

Your phone suggests words as you write, to help you write quickly and more accurately.

Word suggestions are not available in all languages. Select >Settings and keyboard >typing settings.

1Select a keyboard and Suggest text and highlight misspelled words.

2In a text input field, start writing a word. Your phone suggests possible words as you write. When the correct word is displayed, select the word.

3To add a new word to the dictionary, write the word, select it, and then select the plus sign (+) next to the word in the suggestion bar.

Switch word suggestions off

Select a keyboard, then clear the Suggest text and highlight misspelled words check box.

Remove all words manually added to suggestion list

Select reset suggestions.

Add more writing languages

You can add several writing languages for your keyboard and switch between the languages when writing.

Select >Settings and keyboard, then select the languages you want to write in. The language key is shown on the keyboard.

Switch between the languages when writing

Select the language key. The keyboard layout and word suggestions change according to the language selected.

Basics 29

Search your phone and the web

Explore your phone, the web, and the outside world. With Bing search, you can use the on-screen keyboard or your voice to write your search words. You can also use your phone camera to scan things, such as barcodes and book and DVD covers, and get further info on what your phone recognizes.

Some services may not be available in all countries, and may be provided only in selected languages.

Search the web

1Press .

2Write your search word in the search box, then select . You can also select from the proposed matches.

Tip: To see related search results, swipe to local or images.

Use voice search

1Press .

2Select in the search box.

3Say Find or Search for and your search word.

Voice search is currently available in the following countries: Canada, France, Germany, Italy, Spain, the United Kingdom, and the United States.

Search inside an app

1In an app, such as Marketplace, select .

2Write your search word in the search box, then select . You can also select from the proposed matches.

Use vision search

1Press .

2Select , then scan text, QR codes, or barcodes.
