Microsoft DTE-3 User Guide
User Guide
Issue 2
The PC card described in this guide is approved for use in GSM 850 and GSM 1900 networks.
LEGAL INFORMATION
Issue No. 2
Copyright ©2002-2003 Nokia. All rights reserved.
Nokia, Nokia Connecting People, Nokia D311, and the Nokia original accessories logos are trademarks or registered trademarks of
Nokia Corporation. Other product and company names mentioned herein may be trademarks or tradenames of their respective
owners.
Manufactured or sold under one or more of the following US Patents: 4868846, 4969192, 5101175, 5230091, 5241583, 5331638,
5335362, 5351235, 5384782, 5400949, 5416435, 5442521, 5444816, 5446364, 5479476, 5526366, 5557639, 5581244, 5625274,
5664004, 5664053, 5699482, 5701392, 5706110, 5729534, 5729541, 5754976, 5760568, 5802465, 5805301, 5827082, 5835889,
5839101, 5862178, 5870683, 5884103, 5887266, 5889770, 5896369, 5898925, 5907823, 5914796, 5915440, 5917868, 5920826,
5930233, 5946651, 5949775, 5956331, 5956633, 5960354, 5960389, 5963901, 5966374, 5966378, 5970059, 5987137, 5991716,
5991857, 6005857, 6011853, 6014573, 6026161, 6028567, 6038238, 6043760, 6047196, 6049796, 6069923, 6081534, 6084962,
6094587, 6111545, 6112099, 6115617, 6119180, 6122498, 6138091, 6144243, 6144676, 6154745, 6163609, 6164547, 6170073,
6178535, 6188909, 6195338, 6199035, 6201876, 6212235, 6219560, 6240076, 6240079, 6249584, 6262735, 6266516, 6295286,
6298035, 6308377, 6321257, 6356759, 6370394, 6377803, 6393121, 6437745, D431035. Other patents pending.
Includes RSA BSAFE cryptographic or security protocol software from RSA Security.
The information contained in this user guide was written for the Nokia D311 PC card. Nokia operates a policy of continuous
development. Nokia reserves the right to make changes and improvements to any of the products described in this document without
prior notice.
UNDER NO CIRCUMSTANCES SHALL NOKIA BE RESPONSIBLE FOR ANY LOSS OF DATA OR INCOME OR ANY SPECIAL, INCIDENTAL,
CONSEQUENTIAL, PUNITIVE OR INDIRECT DAMAGES HOWSOEVER CAUSED.
THE CONTENTS OF THIS DOCUMENT ARE PROVIDED “AS IS.” EXCEPT AS REQUIRED BY APPLICABLE LAW, NO WARRANTIES OF ANY
KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE ACCURACY AND RELIABILITY OR CONTENTS OF THIS
DOCUMENT. NOKIA RESERVES THE RIGHT TO REVISE THIS DOCUMENT OR WITHDRAW IT AT ANY TIME WITHOUT PRIOR NOTICE.
EXPORT CONTROLS
This product contains commodities, technology or software exported from the United States in accordance with the Export
Administration regulations. Diversion contrary to U.S. law is prohibited.
FCC/INDUSTRY CANADA NOTICE
Your PC card may cause TV or radio interference (for example, when using a telephone in close proximity to receiving equipment).
The FCC or Industry Canada can require you to stop using your PC card if such interference cannot be eliminated. If you require
assistance, contact your local service facility. This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference and (2) this device must accept any interference received including
interference that may cause undesired operation. Modifications not expressly approved by Nokia could void the user's authority to
operate the equipment.
Table of contents
For your safety. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Network Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Data and fax communication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
About data transmission . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
General Packet Radio Service (GPRS) . . . . . . . . . . . . . . . . . . . . . . . . . 5
Wireless Local Area Network (WLAN) . . . . . . . . . . . . . . . . . . . . . . . . . 6
Antenna. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Install the software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Uninstall the Nokia D311 PC card software . . . . . . . . . . . . . . . . . . . 13
Getting started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Connect to a network. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
End network connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Remove the PC card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Nokia D311 PC card features . . . . . . . . . . . . . . . . . . . . . . . . . . 19
The Manager and Monitor window. . . . . . . . . . . . . . . . . . . . . . . . . . 19
Profiles page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Settings page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Tools page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
Administrator page. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
WEP security. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Nokia Short Messaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Text messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Picture messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44
Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Chat. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Resources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
i
Care and maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Important safety information . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Nokia One-Year Limited Warranty . . . . . . . . . . . . . . . . . . . . . . 63
ii
For your safety
Read these simple guidelines. Breaking the rules may be dangerous or illegal.
Further detailed information is given in this manual.
Do not use the PC card when wireless equipment use is prohibited or when
it may cause interference or danger.
Road safety comes first
Don’t use while driving.
Interference
All PC cards may receive interference, which could affect performance.
Switch off in hospitals
Follow any regulations or rules. Switch the PC card off near medical
equipment.
Switch off in aircraft
Wireless devices can cause interference in aircraft.
For your safety
Switch off when refuelling
Don’t use the PC card at a refueling point. Do not use near fuel or chemicals.
Switch off near blasting
Don’t use the PC card where blasting is in progress. Observe restrictions,
and follow any regulations or rules.
Use sensibly
Use only in the normal position. Don’t touch the antenna unnecessarily.
Qualified service
Only qualified personnel may repair PC card equipment.
Water-resistance
Your PC card is not water-resistant. Keep it dry.
Backup copies
Remember to make backup copies of all important data.
Connecting to other devices
When connecting to other devices, read the other device’s user guide for
detailed safety instructions. Do not connect incompatible products.
1
Network Services
The PC card described in this guide is approved for use in GSM 850 and GSM 1900
networks.
A number of features included in this guide are called Network Services. These are
special services that you arrange through your wireless service provider. Before
you can take advantage of any of these Network Services, you must subscribe to
them through your wireless provider and obtain instructions for their use from
your wireless provider.
Note: Some GSM networks may not support all language-dependent
characters and/or services.
For your safety
2
Introduction
The Nokia D311 PC card is a multi-mode PC card that combines General Packet
Radio Service (GPRS), GSM data, and Wireless Local Area Network (WLAN).
With the Nokia D311 PC card you can send and receive e-mail, text messages, data
and fax files, and access the Internet.
Note: You cannot make or receive voice calls with the Nokia D311 PC card.
The Nokia D311 PC card operates on the GSM 850 and 1900 networks and IEEE
802.11b-compliant WLANs. It plugs into compatible portable computers or other
devices with a type II or III PC card slot. The Nokia D311 PC card is equipped with
an integrated smart card reader, Wired Equivalent Privacy (WEP) keys, and
personal network profiles that make moving between networks easy.
Supported operating systems are: Windows 98 Second Edition, Windows Me,
Windows 2000, and Windows XP. For other supported operating systems and
software updates, please check the Nokia Web site at www.club.nokia.com
Introduction
.
Important!
Warning: Do not use the PC card when the use of a wireless device is
prohibited or when it may cause interference or danger.
Warning: Be careful when moving your computer so that you do not cause
damage to the protruding end of the PC card.
Warning: Using the Nokia D311 PC card in some countries or regions may
be illegal. Consult local authorities on the regulations concerning the use of
the Nokia D311 PC card.
Note: Transmitted data is not encrypted by the PC card by default.
Warning: Use only accessories approved by the PC card manufacturer
for use with this particular PC card model. The use of any other types
may invalidate any approval or warranty applying to the PC card, and may
be dangerous.
For availability of approved accessories, please check with your dealer.
3
Data and fax communication
The Nokia D311 PC card provides the functionality of a wireless modem. In order
to connect to a remote computer, send and receive files, e-mail, and faxes, as well
as access the Internet, please take the following into account:
• You will need the appropriate data and fax communications software on your
computer. The Nokia D311 PC card is compatible with a variety of commercially
available Windows 98 Second Edition, Windows Me, Windows 2000, and
Windows XP compatible data and fax communications applications, such as
Dial-Up Networking and HyperTerminal.
• The data and fax applications that reside on your computer must be correctly
configured for use with the Nokia D311 PC card. Follow the instructions given
in the documentation of these applications and remember to select the Nokia
D311 PC card as the modem for each application.
• The data transfer and fax functions depend on the applications you have
chosen, and not only on the computer or the Nokia D311 PC card. For
information on how to use an application, please refer to that application’s
documentation.
Introduction
• You need to subscribe to the corresponding data and fax services from your
wireless provider. Contact your wireless provider for information about the
availability and details of the services in your home network. Internet access
requires that you have subscribed to the data service and obtained an Internet
access point from your wireless provider.
The Nokia D311 PC card can also be controlled with AT commands.
About data transmission
The Nokia D311 PC card employs data transmission capabilities of WLAN and GSM
networks in order to send and receive data, browse the Internet, send short
messages and e-mail, and to establish connections with other computers.
Data connections may be made from most locations where your PC card operates.
However, it is recommended that you move the PC card to a location where the
strongest possible network signal can be obtained. When the signal is strong, data
transmission is more efficient.
Factors that may impair wireless connections:
Interference – Electronic appliances and other equipment can cause radio
interference. Also in areas where PC cards are prevalent, other PC cards can impair
your wireless connection.
4
Introduction
Roaming – As the PC card user moves from one WLAN access point coverage area
or GSM network cell to another, the signal strength may drop. As a consequence,
the network may hand the user over to a coverage area and frequency where the
signal is stronger. Due to varying network traffic loads, roaming may also occur
when the user is stationary. Such roaming may cause slight delays in transmission.
Electrostatic discharge – A discharge of static electricity from a finger or a
conductor may cause erroneous functions in electrical devices. The discharge may
result in unstable software operation. Network connections may become
unreliable, data may become corrupted, and transmission halted. In those cases,
end the existing connection (if any), stop the PC card, and remove it from the PC
card slot. Then re-insert the PC card into the PC card slot and try connecting again.
Dead spots and dropouts – Dead spots are areas where radio signals cannot be
received. Dropouts occur when the PC card user passes through an area where the
radio signal is blocked or reduced by geographical or structural obstructions, such
as concrete walls.
Signal impairment – Distance and obstacles can cause signals to become out-ofphase. They can also cause reflected signals. Both situations result in a loss of
signal strength.
Low signal strength – Due to either distance or obstacles, the radio signal
strength from a WLAN access point or GSM cell site may not be strong or stable
enough to provide a reliable connection for communication. Therefore, to ensure
the best possible communication, remember to consider the following points:
• Data connection works best when the PC card is in a stationary position.
Attempting wireless data communication while in a moving vehicle is not
recommended. Fax transmission is more easily impaired than data or text
message transmission.
• Do not place the PC card on a metal surface.
General Packet Radio Service (GPRS)
Important: GPRS may not be available in all wireless networks. The
establishment and continuation of a GPRS and Internet connection
depends on network availability, wireless provider support, and signal
strength.
GP RS is a p ac ke t d at a t ec hn ology where information is sent in short bursts of data
over the mobile network. The benefit of sending data in packets is that the
network is occupied only when sending or receiving data. GPRS as such is a data
bearer that enables wireless access to data networks like the Internet. The
applications that use GPRS are SMS messaging and GPRS dial-up (for example,
the Internet and e-mail).
5
Before you can use GPRS technology:
• You need to subscribe to GPRS service.
For availability and subscription to GPRS service, contact your wireless
provider.
• You need to save the GPRS settings for the applications used over GPRS.
See “Messages” on page 31 for configuring text message settings.
See also “Create new profiles” on page 21 and “Data and fax communication”
on page 4.
Please refer to the Data Security document found on the Nokia D311 PC card CDROM for information on security issues.
Pricing for GPRS and applications
Confirm the cost of operating your PC card with your wireless provider. You may
be charged for the GPRS connection and any data that is sent and received over
the connection.
Introduction
Wireless Local Area Network (WLAN)
The PC card described in this document is approved for use in a Wireless Local Area
Network (WLAN).
The Nokia D311 PC card supports the following WLAN features:
• IEEE 802.11b standard
• Data rates of 1, 2, 5.5, and 11 Mbit/s
• Operation at a frequency of 2.412 - 2.462 GHz using Direct Sequence Spread
Spectrum (DSSS) radio technology
• Wired Equivalent Privacy (WEP) data encryption with keys up to 152 bits.
The Nokia D311 PC card enables you to connect compatible laptop computers,
hand-held devices, desktop PCs, and other devices with a type II or III PC card slot
to a local area network through a WLAN access point. Instead of cables, radio
waves are used to transmit and receive data over the air.
If you move the computer to another location within the WLAN and out of range
of a WLAN access point, the roaming functionality can automatically connect
your computer to another access point that belongs to the same network. As long
as you remain within range of access points that belong to the same network, your
computer can stay connected to the network.
6
Introduction
The Nokia D311 PC card enables different types of communication in a WLAN.
There are two operating modes to choose from: infrastructure and ad hoc.
Infrastructure
The infrastructure operating mode allows two kinds of communication:
• Wireless stations communicate with each other through a WLAN access point.
• Wireless stations communicate with a wired LAN station through a WLAN
access point.
WLAN access point
Figure 1 - Infrastructure network
The advantage of the infrastructure operating mode is that you can have more
control over network connections because they pass through an access point. A
wireless station can access the services that are available in a regular wired LAN:
company database, e-mail, the Internet, and other network resources, for example.
Ad hoc
In the ad hoc operating mode, wireless stations send and receive data directly with
each other; no access point is required. Simply insert the PC cards into the
stations, make the necessary configurations, and start communicating. Ad hoc
networking is easy to set up, but communication is limited to stations that are
within range. As long as the stations are within range, you can, for example, share
and exchange files.
7
SIM services
Introduction
Figure 2 - Ad hoc network
See “Set up and join ad hoc networks” on page 17 for how to set up an ad hoc
network.
SIM services refers to a service which enables you to access the Internet via your
wireless service provider’s own public network. Your wireless provider may, for
example, offer you the possibility to check data from your company intranet, send
and receive e-mail, and save documents. SIM services are usually available in
public places such as hotels, airports, railway stations, business centers, and
corporate buildings.
A SIM card is used as a means for user identification: the data stored on the SIM
card is read, and if valid, you are allowed to connect to the Internet and intranets.
The SIM card is provided by the wireless provider.
Accounting data, such as used access time and/or transferred data, is passed from
the network on to the wireless provider for billing purposes. Accounting begins
when the wireless station is authenticated and ends when the wireless station
logs off.
Security in WLAN
Security issues should always be carefully considered to ensure the secure
transmission of data in both wired and wireless LANs. In current wireless systems,
for example, WLAN access points need to authenticate wireless stations to
Note: Before you can take advantage of the SIM services, you must
subscribe to these services from your wireless provider and obtain
instructions for use.
Note: The actual invoice for services from your wireless provider may vary,
depending upon network features, rounding-off for billing, taxes and so
forth.
8
Introduction
prevent unauthorized access to the network. Authentication is a service that
confirms the identity of an entity, such as a user or a computer, or confirms the
origin of a transmitted message.
The Nokia D311 PC card supports the Wired Equivalent Privacy (WEP) protocol,
which offers basic protection in WLAN. The WEP protocol utilizes the RC4
algorithm with an up to 152-bit secret key, which encrypts data before it is
transmitted over radio waves. When the wireless stations in a WLAN wish to
communicate using WEP, they must have the same WEP key in possession.
The Nokia D311 PC card is also compatible with leading Virtual Private Network
(VPN) clients over GPRS and WLAN. VPN is recommended for more secure network
access.
The Nokia D311 PC card is equipped with an integrated smart card reader. SIM
cards and smart card readers provide a tool for managing secure user
authentication in a WLAN. SIM cards also provide an easy way for users to carry an
authentication device with them. On a SIM card users can store important
information, such as WEP keys and network profiles.
The smart card reader reads the data stored on the computer chip and sends it to
the network for processing. The SIM card is protected by a PIN code; to access the
contents of the SIM card, you need to enter the correct PIN code.
Antenna
Warning: Keep all SIM cards out of reach of small children. Please refer to
the Data Security document found on the product CD-ROM for more
information on security issues.
Tip: T IPS ON EF FI CI EN T O PE RA TI ON : Y our PC ca rd ha s a bu il t- in an te nn a. As
with any other radio transmitting device, do not touch the antenna
unnecessarily when the PC card is on. Contact with the antenna affects
connection quality and may cause the PC card to operate at a higher power
level than otherwise needed. Not touching the antenna area during a
connection optimizes the antenna performance.
The Nokia D311 PC card antenna is inside an
extension box. In this document antenna
refers to the extension box and the antennas
inside it.
Do not cover the antenna. Unauthorized
antennas, modifications, or attachments
could damage the PC card and may violate regulations governing radio devices.
See page 54 for more information on antennas and on using a laptop computer on
your lap.
9
Installation
There are some differences in the installation process between Windows
operating systems. If the installation differs from the steps described below,
follow the instructions on the screen.
Software for the Nokia D311 PC card requires 20 MB of free disk space.
Install the software
Note: Do not insert the PC card into your computer until the installation
program instructs you to do so.
1 Exit all Windows applications and insert the CD-ROM containing the
installation software into the CD-ROM drive of your computer.
2 If the CD-ROM does not launch automatically, open Windows Explorer and
locate the icon for your CD-ROM drive. Click on the icon to view the contents
of the CD-ROM drive.
3 Double-click on Start.exe.
4 Select the language for the CD-ROM and installation program and read
through and accept the Nokia license agreement. If you do not accept the
license agreement, you cannot use the CD-ROM.
5 The main screen of the CD-ROM opens. Click Install to start the installation.
6 The Welcome page of the installation wizard opens. Click Next to continue.
7 Read through and accept the Nokia license agreement. If you do not accept the
license agreement, you cannot use the software and the installation procedure
stops. Click I Accept to accept the license agreement.
8 Select the destination folder for the software. The default folder is C:\Program
Files\Nokia\Nokia D311 PC card. If you want to install the software in another
drive or folder, click Browse. When you have selected the correct destination
folder, click Next.
Note: You cannot install the Nokia D311 PC card software on a
network drive.
Installation
9 Select the type of installation you want. The Administrator option is for system
administrators only. Custom allows you to choose the individual software
components to be installed, and is recommended for advanced users. Typical
installs the most common software components. This option is recommended
10
Installation
for most users. When you have selected the desired type of installation,
click Next.
10 Check the installation settings. To accept them, click Next. To change the
settings, click Back, make the changes, and then click Next. The installation
program starts copying the files.
11 When the installation program prompts you to insert the PC card, insert it
firmly into the PC card slot of your computer as shown in Figure 3. Note that
there is a gap between the protruding extension box and the computer. Do not
use excess force when inserting the card.
Figure 3 - Inserting the PC card
In the Windows 2000 operating system you are informed that no digital
signature was found. Click Yes in each dialog box to continue with the
installation.
In Windows XP, the operating system opens Found New Hardware wizards. For
each of these wizards, first select the option Install the software
automatically, and then select Continue Anyway to continue with the
installation.
12 The Completion page informs you when the installation is completed. Remove
the CD-ROM from the CD-ROM drive and click Finish. You may need to restart
your computer.
13 A dialog box asks if you want to create a network profile now. Remember that
you can create and edit your own network profiles at any time. If you do not
want to create a profile, click No and the installation procedure is completed.
If you want to create a profile, click Yes and the Welcome window of the
profile wizard opens. See “Create new profiles” on page 21 for more
information.
11
Note: If you want other applications to be able to use the smart card reader
of the Nokia D311 PC card, you need to install separately a PC/SC (Personal
Computer Smart Card) compliant smart card driver on your computer.
Install the smart card driver only if you want to use other applications or
special types of smart cards with the smart card reader of the Nokia D311
PC card. To install the driver, select Custom as the installation type (see step
7 above) and select the PC/SC smart card driver component. In the Windows
98 SE and Me operating systems you must have the Microsoft Smart Card
Base Components 1.0 or later installed.
Modify the installation
You can alter the installation of the Nokia D311 PC card by adding or removing
components, for example.
1 Exit all Windows applications and insert the CD-ROM containing the
installation software into the CD-ROM drive of your computer.
2 If the CD-ROM does not launch automatically, open Windows Explorer and
locate the icon for your CD-ROM drive. Click on the icon to view the contents
of the CD-ROM drive.
3 Double-click on Start.exe.
4 Select the language for the CD-ROM and installation program and read
through and accept the Nokia license agreement. If you do not accept the
license agreement, you cannot use the CD-ROM.
5 The main screen of the CD-ROM opens. Click Install to start the installation.
6 When the Welcome page of the installation maintenance program opens,
choose from the following options:
Modify – You can install new components or remove existing ones.
Installation
Update – You can update the installed components and network profiles.
Uninstall – You can remove the Nokia D311 PC card program files and drivers
from your computer.
When you have selected the option, click Next.
7 The selected wizard opens. Make the changes and click Next to continue.
8 Check the settings. To accept them, click Next. To change the settings, click
Back, make the changes, and then click Next.
9 The modification starts. The Completion page informs you when the
modification is completed. Click Finish.
12
Uninstall the Nokia D311 PC card software
Important: Before you uninstall the Nokia D311 PC card software, you
must first stop the PC card and then remove it from the PC card slot of the
computer. See “Remove the PC card” on page 18 for more information.
Close all dialog boxes in the user interface before you uninstall the Nokia D311 PC
card.
To uninstall the Nokia D311 PC card software:
1 From the Start menu, select Settings and then click Control Panel. Click Add/
Remove Programs.
2 From the list of programs, select Nokia D311 PC card and click Add/Remove.
3 The Welcome page of the uninstall wizard opens. If you do not want profiles
and settings configured on the Settings page removed, select the Keep all
profiles and other settings check box. If you want to save all data relat ing to
the SMS application, for example text and picture messages you have sent or
received, select the Keep all data from the SMS application check box.
Click Next to continue.
4 Check the uninstall settings. To accept them, click Next. To change the
settings, click Back, make the changes, and then click Next.
5 The uninstall program begins. The Completion page informs you when the
uninstallation is completed. Click Finish.
Installation
13
Getting started
With the Nokia D311 PC card you can:
• establish a General Packet Radio Service (GPRS) connection where
information is sent in short bursts of data over the cellular network. The
benefit of sending data in packets is that the network is occupied only when
sending or receiving data. GPRS is ideal for applications which transmit data in
short bursts, such as Web browsers. The data ra te can be u p t o 4 0.2 Kb it/ s. Yo u
need to subscribe to the GPRS service.
• connect to a GSM network where you can send and receive text and picture
messages. You can also connect to the Internet or your e-mail by making a
data call, which enables data transmission rates of up to 14.4 Kbit/s. You can
make GSM data calls if your network supports data calls and you have
subscribed to this service.
• connect to a Wireless Local Area Network (WLAN) and send and receive data
like in a regular wired LAN. The data rate in WLAN can be up to 11 Mbit/s.
Getting started
Connect to a network
To be able to connect to a network you need a network profile. Easy connection
profile with predefined settings is automatically created during software
installation. This profile enables network access without your needing to
configure any settings.
If you want to create a profile yourself, see “Create new profiles” on page 21 for
more information.
You need a SIM card to be able to establish a GSM or GPRS connection.
To create a network connection:
1 Slide the SIM card into the smart card slot of the Nokia
D311 PC card. Make sure that the metal contacts of
the SIM card are facing down and that the bevelled
corner is on the right.
Note: Insert the SIM card into the slot until the edge
with the bevelled corner can no longer be seen, but no
further than that.
Note that the PC card does not support 5 Volt SIM
cards.
14
Getting started
2 If you are using the laptop computer on your lap,
slide the snap-on spacer on the PC card in the
direction of arrow 1.
Note: To use the laptop computer when it is on your
lap, see page 54 for more information.
3 Insert the PC card firmly into the PC card slot of the
computer.
Note that there is a gap between the protruding extension box and the
computer. Do not use excess force when inserting the card.
4 Switch on your computer.
5 If you are using a SIM card, enter the PIN code and click OK. You can enter the
PIN code before logging on to a network.
6 During the log on a dialog box opens in the top left-hand corner of the screen.
To select the profile and connection type at this stage, click Select.
7 The Select Connection dialog box opens. See Figure 4. From the list of profiles
open the profile and select the connection type you want to use.
1
Figure 4 - Select Connection dialog box
WLAN – Connects you to a wireless local area network where you can send
and receive data.
GSM – Allows you to make data calls if your network supports data calls and
you have subscribed to this service.
GPRS – You can establish a GPRS connection and send packet data. You need
to subscribe to the GPRS service.
15
OFF – Disconnects the PC card from the network and turns off all radios.
8 Click OK to establish a network connection.
Tip: You can access the Select Connection dialog box also by right-clicking
the Nokia D311 PC card icon on the taskbar, or by opening the Profiles page
of the Manager window and clicking Select. If the taskbar icon is not visible,
see page 28 for more information.
Tip: You can manage network connections also by using the Nokia D311 PC
card icon on the taskbar. Right-click the icon and click Connect to connect
to SIM services. To make a data call, click Dial, and to send packet data, click
Activate. See “Connection status indicators” below for more information. If
the taskbar icon is not visible, see page 28 for more information.
Warning: Do not use the PC card when wireless equipment use is prohibited
or when it may cause interference or danger.
Connection status indicators
Taskbar icons and icons on the Profiles page indicate the status of the network
connection.
Getting started
Ready for data call – You have established a connection to a GSM network
and can send and receive text messages. To access the Internet or your e-mail
by using GSM data services, you need to make a data call. Click Dial to make
a data call.
The use of GSM data services requires that your network supports data calls
and that you have subscribed to this service. For more information, contact
your wireless provider.
Data call to [phone number] – GSM data call is active. To finish the call, click
End Call.
Ready to activate GPRS – You have established a connection to a GSM
network that supports packet data sending (GPRS). You can send and receive
text messages. To access the Internet or your e-mail by using GPRS, you need
to establish a GPRS connection. Click Activate to establish a GPRS
connection.
You need to subscribe to the GPRS service. For availability and subscription to
packet data services, please contact your wireless provider.
GPRS active – GPRS connection is now active. To end the connection, click
Deactivate.
Linked to (access point name) – You have established a connection to a
WLAN access point.
16
To connect to the SIM services, click Connect. The Connect button is
activated only when the wireless station has detected a service in the
network, otherwise the button remains inactive.
Connected to SIM services – You have established a connection to SIM
services. To end the connection, click Disconnect.
Before you can take advantage of the SIM services, you must subscribe to
these services from your wireless provider and obtain instructions for use.
Ad hoc network – You have either established or joined an ad hoc network.
No network – You have selected Off as a connection type and are not
connected to any network.
Set up and join ad hoc networks
Ad h oc n et wor ks all ow w ir ele ss sta ti ons to c om mun ica te dir ec tly wi th e ac h ot her
without any WLAN access points. The stations can, for instance, share folders. One
user creates the ad hoc network and other users then join the network.
See “Wireless Local Area Network (WLAN)” on page 6 for more information on ad
hoc networks.
Getting started
To connect to an ad hoc network:
1 On the Profiles page, select the General tab and click Select.
2 The Select Connection dialog box opens. Open the Easy connection profile
and select the WLAN (ad hoc) connection type. Click OK.
3 If you are starting an ad hoc network, type the network name. If you are joining
a network, select the network name from the list box. Click OK.
Tip: Create your own profile for ad hoc networking with the profile wizard if
you use the ad hoc operating mode frequently. This saves you from having to
select a network each time and allows for quicker access. See “Create new
profiles” on page 21 for more information.
End network connections
Closing the Monitor or Manager window does not quit the program or end an
existing network connection. To end a connection, select the connection type Off
for a profile. See Figure 4 on page 15.
You can end the network connection also by stopping and removing the PC card.
To power off the PC card, you have to remove it from the PC card slot.
