Microsoft 1695 User Manual

M

Contents

Microsoft Product Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 Guia do Produto da Microsoft . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11 Guide produit Microsoft . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20 Guía del producto de Microsoft . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29

0508 PartNo.X 2- 6903-05
X121690305mnl.indb 1			5/21/2008 3:15:52 PM

M

Microsoft Product Guide

Read this guide for important safety and health information that applies to the Microsoft® device that you have purchased.

Warning Failure to properly set up, use, and care for this product can increase the risk of serious injury or death, or damage to the device or devices. Read this guide and keep all printed guides for future reference. For replacement guides, go to www.microsoft.com/hardware or refer to the Customer Support Options section for contact information.

This document includes important information about many Microsoft products. Refer to sections that apply to the features of your device:

Important Safety Information AC-Powered Devices Battery-Powered Devices Headset Devices

Webcam Devices

Wireless Devices

Keyboard and Mouse Devices Devices with Laser Pointers All Devices

Laser and LED Specifications

Regulatory Information

Radio Frequency Technical Specifications

Radio and TV Interference Regulations

Disposal of Waste Batteries and Electrical and Electronic Equipment Statement of Compliance with EU Directives

Patent Information Customer Support Options

This symbol identifies safety and health messages in this Product Guide and other product manuals .

Important Safety Information

AC-Powered Devices

These precautions apply to all products that plug into a standard wall power outlet.

Failure to take the following precautions can result in serious injury or death from electric shock or fire or in damage to the device.

2

X121690305mnl.indb 2			5/21/2008 3:15:52 PM

To select an appropriate power source for your device:

●Use only the power supply unit and AC power cord that came with your device or that you received from an authorized repair center.

●Confirm that your electrical outlet provides the type of power indicated on the power supply unit (in terms of voltage [V] and frequency [Hz]). If you are not sure of the type of power supplied to your home, consult a qualified electrician.

●Do not use non-standard power sources, such as generators or inverters, even if the voltage and frequency appear acceptable. Only use AC power provided by a standard wall outlet.

●Do not overload your wall outlet, extension cord, power strip, or other electrical receptacle. Confirm that they are rated to handle the total current (in amps [A]) drawn by the device (indicated on the power supply unit) and any other devices that are on the same circuit.

To avoid damaging the power cords and power supply:

●Protect the power cords from being walked on.

●Protect cords from being pinched or sharply bent, particularly where they connect to the power outlet, the power supply unit, and the device.

●Do not jerk, knot, sharply bend, or otherwise abuse the power cords.

●Do not expose the power cords to sources of heat.

●Keep children and pets away from the power cords. Do not allow them to bite or chew on them.

●When disconnecting the power cords, pull on the plug — do not pull on the cord.

If a power cord or power supply becomes damaged in any way, stop using it immediately. Unplug your device during lightning storms or when unused for long periods of time.

For devices with an AC power cord that connects to the power supply, always connect the power cord according to the following instructions:

1Plug the AC power cord into the power supply until it stops.

2Plug the other end of the AC power cord into the wall outlet.

Battery-Powered Devices

These precautions apply to all products that use rechargeable or disposable batteries.

Improper use of batteries may result in battery fluid leakage, overheating, or explosion. Released battery fluid is corrosive and may be toxic. It can cause skin and eye burns, and is harmful if swallowed.

To reduce the risk of injury:

●Keep batteries out of reach of children.

●Do not heat, open, puncture, mutilate, or dispose of batteries in fire.

●Do not mix new and old batteries or batteries of different types (for example, carbon-zinc and alkaline batteries).

●Do not allow metal objects to touch the battery terminals on the device; they can become hot and cause burns.

3

X121690305mnl.indb 3			5/21/2008 3:15:52 PM

●Remove the batteries if they are worn out or before storing your device for an extended period of time.

●Always remove old, weak, or worn-out batteries promptly and recycle or dispose of them in accordance with Local and National Disposal Regulations.

●If a battery leaks, remove all batteries, taking care to keep the leaked fluid from touching your skin or clothes. If fluid from the battery comes into contact with skin or clothes, flush skin with water immediately. Before inserting new batteries, thoroughly clean the battery compartment with a damp paper towel, or follow the battery manufacturer’s recommendations for cleanup.

Disposable (non-rechargeable) batteries only:

●Caution Risk of explosion if battery is replaced by an incorrect type. Use and replace only with the correct size and type (alkaline, zinc-carbon, or zinc-chloride) of batteries.

Rechargeable batteries only:

●Caution Risk of explosion if battery is replaced by an incorrect type. Use and replace only with the same type and rating as the batteries provided.

●Charge only with the recharger provided with the product.

Lithium button cell batteries only:

●Perchlorate Material — special handling may apply. See: www.dtsc.ca.gov/hazardouswaste/perchlorate

Headset Devices

Extended exposure to high volumes when using a headset may result in temporary or permanent hearing loss.

To prevent damage to your headset, avoid sitting or stepping on the headset, its cable, or the cable connector.

Webcam Devices

Webcam with magnetic and adhesive mounting

After the adhesive attachment disc has been applied to the mounting surface, removing it may damage the cosmetic coating and/or leave an adhesive residue.

Applying the attachment disc next to or directly to a CRT-based display screen may cause permanent visual distortion of the displayed image near the area mounted.

Wireless Devices

Before boarding any aircraft or packing a wireless device in luggage that will be checked, remove the batteries from the wireless device or turn the wireless device off (if it has an on/off switch). Wireless devices can transmit radio frequency (RF) energy, much like a cellular telephone, whenever batteries are installed and the wireless device is turned on (if it has an on/off switch).

X121690305mnl.indb 4			5/21/2008 3:15:52 PM

Keyboard and Mouse Devices

Health Warning

Use of a keyboard or mouse may be linked to serious injuries or disorders.

When using a computer, as with many activities, you may experience occasional discomfort in your hands, arms, shoulders, neck, or other parts of your body. However, if you experience symptoms such as persistent or recurring discomfort, pain, throbbing, aching, tingling, numbness, burning sensation, or stiffness,

DO NOT IGNORE THESE WARNING SIGNS . PROMPTLY SEE A QUALIFIED HEALTH PROFESSIONAL, even if symptoms occur when you are not working at your computer. Symptoms like these can be associated with painful and sometimes permanently disabling injuries or disorders of the nerves, muscles, tendons, or other parts of the body. These musculoskeletal disorders (MSDs) include carpal tunnel syndrome, tendonitis, tenosynovitis, and other conditions.

While researchers are not yet able to answer many questions about MSDs, there is general agreement that many factors may be linked to their occurrence, including: overall health, stress and how one copes with it, medical and physical conditions, and how a person positions and uses his or her body during work and other activities (including use of a keyboard or mouse). The amount of time a person performs an activity may also be a factor.

Some guidelines that may help you work more comfortably with your computer and possibly reduce your risk of experiencing an MSD can be found in the “Healthy Computing Guide” installed with this device’s software. If this device did not come with software, you can access the “Healthy Computing Guide” at www.microsoft.com/hardware or (in the United States only) by calling [phone] to request a CD at no charge.

If you have questions about how your own lifestyle, activities, or medical, or physical condition may be related to MSDs, see a qualified health professional.

Devices with Laser Pointers

Caution Use of controls or adjustments, or performance of procedures other than those specified herein may result in hazardous radiation exposure.

●Do not stare into beam.

●Do not shine a laser pointer at anyone. Laser pointers are designed to illuminate inanimate objects.

●Do not allow minors to use a pointer unsupervised. Laser pointers are not toys.

●Do not point a laser pointer at a mirror-like (reflective) surface. A reflected beam can act like a direct beam on the eye.

●Do not disassemble the device.

●Do not use the device outside of its specified operating temperature range +41ºF (+5ºC) to +95ºF (+35ºC). If the device is exposed to an environment outside of its prescribed operation, turn off the device and allow the temperature to stabilize within the specified operating range before using the device.

5

X121690305mnl.indb 5			5/21/2008 3:15:52 PM

All Devices

Do Not Attempt Repairs

Do not attempt to take apart, open, service, or modify the hardware device or power supply. Doing so could present the risk of electric shock or other hazard. Any evidence of any attempt to open and/or modify the device, including any peeling, puncturing, or removal of any of the labels, will void the Limited Warranty.

Choking Hazard

This device may contain small parts which may be a choking hazard to children under 3. Keep small parts away from children.

Usage and Cleaning

Use in accordance with these instructions:

●Do not use near any heat sources.

●Only use attachments/accessories specified by Microsoft.

●Clean only with dry cloth.

Keeping Cables Out of the Way of People and Pets

Arrange all cables and cords so that people and pets are not likely to trip over or accidentally pull on them as they move around or walk through the area. When the product is not in use, you may need to disconnect all cables and cords from the front and rear of the product to keep them out of the reach of children and pets.

Do not allow children to play with cables and cords.

Laser and LED Specifications

Caution Use of controls or adjustments, or performance of procedures other than those specified herein may result in hazardous radiation exposure.

Laser Devices

This device complies with International Standard IEC60825-1:1993+A1+A2 (IEC 60825-1:2001-08) for a Class 1 and Class 2 laser product. This device also complies with 21 CFR 1040.10 and 1040.11 except for deviations pursuant to Laser Notice No. 50, dated June 24, 2007.

Class 1 Laser Devices

Beam description: Collimated (parallel) beam of infrared light	CLASS 1
(invisible to the user)	LASER PRODUCT
Laser power output: < 716 microwatts (at 832 nanometers) to 834 microwatts	IEC 60825- :200 -08
(at 865 nanometers)
Emitted laser wavelength: nominal: 850 nanometers,
range: (832 – 865 nanometers)

A Class laser product is safe under reasonably foreseeable conditions of operation as described by

IEC 60825-1 and 21 CFR 1040.10. However, it is recommended that you not direct the laser beam (which is emitted from the bottom of the device) at anyone’s eyes.

6

X121690305mnl.indb 6			5/21/2008 3:15:52 PM

Class 2 Laser Devices

Beam description: Collimated (parallel) beam of light

Laser power output: < milliwatt

Emitted laser wavelength: 630 – 670 nanometers

This optical device has no serviceable parts. The Class 2 laser beam is emitted from the front of the device.

Optical (LED) Mouse

This product has been evaluated to comply with International Standard
IEC60825-1:1993+A1+A2 (IEC 60825-1:2001-08).	Class 1 LED product
This product uses LEDs that are considered Class 1 (IEC60825-1:1993+A1+A2).
LED output power: < 67.8µW (photochemical limit), < 4.2mW (thermal limit)
LED nominal wavelength: 470nm (blue), 635nm (red)

A Class product is safe under reasonably foreseeable conditions of operation as described by IEC 60825- .

However, it is recommended that you not direct the light (which is emitted from the bottom of the device) at anyone’s eyes.

This optical device has no serviceable parts.

Regulatory Information

Tested to comply with FCC (U.S. Federal Communications Commission) Standards. For home or office use. Not intended for use in machinery, medical, or industrial applications. Any changes or modifications not expressly approved by Microsoft could void the user’s authority to operate this device. This product is for use with NRTL-Listed (UL, CSA, ETL, etc.), and/or IEC/EN 60950 compliant (CE marked) Information Technology equipment. No serviceable parts included.

This device is rated as a commercial product for operation at +41ºF (+5ºC) to +95ºF (+35ºC).

This Class B digital apparatus complies with Part 5 of the U.S. Federal Communications Commission

(FCC) rules, Canadian ICES-003, RSS-Gen, RSS-210, and RSS-310. Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

The term “IC:” before the certification/registration number only signifies that the Industry Canada technical specifications were met.

Complies with IDA Standards DB102868

Complies with IDA Standards DB100398

7

X121690305mnl.indb 7			5/21/2008 3:15:52 PM

Radio Frequency Technical Specifications

27 MHz Devices

Radio frequency (RF) output power: < 54 dBµV/m at 3 m

Keyboard with two channels – RF frequencies: 27.095 MHz (channel 1), 27.195 MHz (channel 2) Keyboard with a single channel – RF frequency: 27.195 MHz or 27.095 MHz

Mouse with two channels – RF frequencies: 27.045 MHz (channel 1), 27.145 MHz (channel 2) Mouse with a single channel – RF frequency: 27.145 MHz or 27.045 MHz

Bluetooth Devices

RF output power: meets Bluetooth® requirements Frequency: 2, 00 MHz to 2 83.5 MHz

2 .4 GHz Devices

Non-specific short range device

RF output power: Meets all SRD requirements

Frequency: within the range of 2, 00 MHz to 2, 83.5 MHz

Radio and TV Interference Regulations

The Microsoft hardware device(s) can radiate RF energy. If not installed and used in strict accordance with the instructions given in the printed documentation and/or on-screen Help files, the device may cause harmful interference with other radio-communications devices (for example AM/FM radios, televisions, baby monitors, cordless phones, etc). There is, however, no guarantee that RF interference will not occur in a particular installation.

To determine if your hardware device is causing interference to other radio-communications devices, disconnect the device from your computer or remove the device’s batteries (for a battery operated device).

If the interference stops, it was probably caused by the device. If the interference continues after you disconnect the hardware device or remove the batteries, turn the computer off and then on again. If the interference stopped when the computer was off, check to see if one of the input/output (I/O) devices or one of the computer’s internal accessory boards is causing the problem. Disconnect the I/O devices one at a time and see if the interference stops.

If this hardware device does cause interference, try the following measures to correct it:

●Relocate the antenna of the other radio-communications device (for example AM/FM radios, televisions, baby monitors, cordless phones, etc.) until the interference stops.

●Move the hardware device farther away from the radio or TV, or move it to one side or the other of the radio or TV.

8

X121690305mnl.indb 8			5/21/2008 3:15:52 PM

●Plug the computer into a different power outlet so that the hardware device and radio or TV are on different circuits controlled by different circuit breakers or fuses.

●If necessary, ask your computer dealer or an experienced radio-TV technician for more suggestions.

For more information about interference issues, go to the FCC Web site at: http://www.fcc.gov/cgb/consumerfacts/interference.html.

You can also call the FCC at 888-CALL FCC to request Interference and Telephone Interference fact sheets.

For Bluetooth and 2 .4 GHz devices only: To comply with FCC RF exposure requirements, the following operating configurations must be satisfied: the antenna has been installed by the manufacturer and no changes can be made. The wireless devices must not be co-located or operating in conjunction with any other antenna or transmitter. Except for headset and handheld devices, wireless devices must be at least

20 cm between the antenna of the wireless device and all persons.

For 802 .11 devices only: This product is restricted to indoor use only to reduce any potential for harmful interference with licensed operation in the 5.15 to 5.25 GHz frequency range.

Microsoft Corporation; One Microsoft Way; Redmond, WA 98052-6399; U.S.A. United States: [phone]; Canada: [phone]

Disposal of Waste Batteries and Electrical & Electronic Equipment

This symbol on the product or its batteries or its packaging means that this product and any batteries it contains must not be disposed of with your household waste. Instead, it is your

responsibility to hand this over to an applicable collection point for the recycling of batteries and electrical and electronic equipment. This separate collection and recycling will help to conserve natural resources and prevent potential negative consequences for human health and the environment due to

the possible presence of hazardous substances in batteries and electrical and electronic equipment, which could be caused by inappropriate disposal. For more information about where to drop off your batteries and electrical and electronic waste, please contact your local city/municipality office, your household waste disposal service, or the shop where you purchased this product. Contact [e-mail] for additional information on WEEE and waste batteries.

Statement of Compliance with EU Directives

Hereby, Microsoft Corporation declares that this product is in compliance with the essential requirements and other relevant provisions of Directives, 2006/95/EC, 200 / 08/EC and 999/5/EC.

The technical documentation as required by the Conformity Assessment procedure is kept at the following address:

Company:	Microsoft Ireland Operations Ltd.
Address:	Atrium Building Block B
	Carmenhall Road, Sandyford Industrial Estate, DUBLIN 8
Country:	Ireland
Telephone number:	+353	1 295 3826
Fax number:	+353	1 706 4110
Internet:	http://www.microsoft.com/ireland/
		9
X121690305mnl.indb 9					5/21/2008 3:15:52 PM

Patent Information

United States and/or international patents pending.

Customer Support Options

If you have a question about your Microsoft hardware product, do the following:

●Check the system requirements for your product (located on the packaging) to ensure that your system is compatible.

●For complete product information, see the on-screen Help file installed with the device software.

●For the latest product information and software updates, go to the Microsoft Hardware Web site at www.microsoft.com/hardware.

●For up-to-date help about using or troubleshooting your device, go to the Microsoft Help and Support

Web site at http://support.microsoft.com.

Information in this document, including URL and other Internet Web site references, is subject to change without notice. Unless otherwise noted, the example companies, organizations, products, domain names, e-mail addresses, logos, people, places, and events depicted herein are fictitious, and no association with any real company, organization, product, domain name, e-mail address, logo, person, place, or event is intended or should be inferred. Complying with all applicable copyright laws is the responsibility of the user. Without limiting the rights under copyright, no part of this document may be reproduced, stored in or introduced into a retrieval system, or transmitted in any form or by any means (electronic, mechanical, photocopying, recording, or otherwise), or for any purpose, without the express written permission of Microsoft Corporation.

Microsoft may have patents, patent applications, trademarks, copyrights, or other intellectual property rights covering subject matter in this document. Except as expressly provided in any written license agreement from Microsoft, the furnishing of this document does not give you any license to these patents, trademarks, copyrights, or other intellectual property.

Microsoft Corporation grants the purchaser of this product the right to reproduce one (1) copy of this user manual for each Hardware

Device you purchased in the package.

© 2008 Microsoft Corporation. All rights reserved.

Microsoft, IntelliEye, IntelliMouse, and Windows are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries.

Bluetooth is a registered trademark of Bluetooth SIG, Inc.

All other trademarks are property of their respective owners.

0

X121690305mnl.indb 10			5/21/2008 3:15:52 PM

M

Guia do Produto da Microsoft

Leia este guia para obter informações importantes sobre saúde e segurança relacionadas ao dispositivo da Microsoft® adquirido por você.

Aviso: se este produto não for instalado, utilizado e manuseado com cuidado, os riscos de lesões graves ou morte, ou ainda de danos ao(s) dispositivo(s), serão maiores. Leia este guia e guarde todos os guias impressos para referência futura. Para obter guias de substituição, vá para www.microsoft.com/hardware ou consulte a seção Opções de atendimento ao cliente para obter informações de contato.

Este documento contém informações importantes sobre diversos produtos da Microsoft. Consulte as seções que se aplicam aos recursos do seu dispositivo:

Informações importantes sobre segurança Dispositivos de corrente alternada Dispositivos que usam pilhas Dispositivos de headset

Dispositivos de webcam

Dispositivos sem fio

Dispositivos de teclado e mouse Dispositivos com apontadores a laser Todos os dispositivos

Especificações de laser e LED

Informações normativas

Especificações técnicas de radiofreqüência

Descarte de resíduos de pilhas e equipamentos elétricos e eletrônicos Declaração de conformidade com as diretivas da UE

Informações sobre patentes Opções de atendimento ao cliente

Este símbolo identifica mensagens de segurança e saúde neste Guia do Produto e em outros manuais .

Informações importantes sobre segurança

Dispositivos de corrente alternada

Estas precauções aplicam-se a todos os produtos que são conectados a uma tomada padrão.

Se as seguintes precauções não forem tomadas, poderão ocorrer lesões graves ou morte devido a choque elétrico ou fogo, ou ainda danos ao dispositivo.

X121690305mnl.indb 11			5/21/2008 3:15:53 PM

Para selecionar uma fonte de alimentação apropriada para seu dispositivo:

●Use apenas a unidade de fonte de alimentação e o fio de corrente alternada fornecidos com o dispositivo ou recebidos de um centro autorizado de assistência técnica.

●Verifique se sua tomada está de acordo com o tipo de alimentação indicado na unidade de fonte de alimentação (quanto à voltagem [V] e à freqüência [Hz]). Se você não tiver certeza quanto ao tipo de alimentação presente em sua casa, consulte um eletricista de sua confiança.

●Não utilize fontes de alimentação não padrão, como geradores ou inversores, mesmo que a voltagem e a freqüência lhe pareçam aceitáveis. Utilize apenas a fonte de corrente alternada fornecida por uma tomada padrão.

●Não sobrecarregue a tomada, a extensão, o filtro de linha ou outro receptáculo elétrico. Verifique a capacidade de suportar a corrente total (em amperes [A]) exigida pelo dispositivo (indicada na unidade de fonte de alimentação) e por quaisquer outros dispositivos que estejam no mesmo circuito.

Para evitar danos aos fios elétricos e à fonte de alimentação:

●Não deixe que os fios elétricos sejam pisados.

●Evite que os fios sejam torcidos ou excessivamente dobrados, principalmente no ponto de conexão com a tomada, a unidade de fonte de alimentação e o dispositivo.

●Não puxe, dê nós, dobre em excesso nem faça algum outro uso não indicado dos fios elétricos.

●Não exponha os fios elétricos a fontes de calor.

●Mantenha crianças e animais longe dos fios elétricos. Não os deixe morder nem mastigar os fios.

●Ao desconectar os fios elétricos, puxe-os pelo conector — e não pelo fio.

Se um fio elétrico ou uma fonte de alimentação for danificado de alguma forma, interrompa imediatamente o uso. Desconecte seu dispositivo durante tempestades com raios ou quando não for utilizá-lo por longos períodos.

Para dispositivos que possuem um fio de corrente alternada conectado à fonte de alimentação, siga sempre as seguintes instruções para conectar o fio elétrico:

1Conecte o fio de corrente alternada à fonte de alimentação até o fim.

2Conecte a outra extremidade do fio de corrente alternada na tomada.

Dispositivos que usam pilhas

Estas precauções aplicam-se a todos os produtos que usam pilhas recarregáveis ou descartáveis.

O uso não apropriado de pilhas pode resultar em vazamentos do fluido das pilhas, superaquecimento ou explosão. O fluido liberado pelas pilhas é corrosivo e pode ser tóxico. Ele pode causar queimaduras na pele e nos olhos e pode ser prejudicial se ingerido.

2

X121690305mnl.indb 12			5/21/2008 3:15:53 PM
