MICROCHIP PIC16F87X Technical data

PIC16F87X

Data Sheet

28/40-Pin 8-Bit CMOS FLASH

Microcontrollers

 2001 Microchip Technology Inc. DS30292C

“All rights reserved. Copyright © 2001, Microchip Technology
Incorporated, USA. Information contained in this publication
regarding device applications and the like is intended through
suggestion only and may be superseded by updates. No rep­resentation or warranty is given and no liability is assumed by
Microchip Technology Incorporated with respect to the accu­racy or use of such information, or infringement of patents or
other intellectual property rights arising from such use or oth­erwise. Use of Microchip’s products as critical components in
life support systems is not authorized except with express
written approval by Microchip. No licenses are conveyed,
implicitly or otherwise, under any intellectual property rights.
The Microchip logo and name are registered trademarks of
Microchip Technology Inc. in the U.S.A. and other countries.
All rights reserved. All other trademarks mentioned herein are
the property of their respective companies. No licenses are
conveyed, implicitly or otherwise, under any intellectual prop­erty rights.”

Trademarks

The Microchip name, logo, PIC, PICmicro, PICMASTER, PIC­START, PRO MATE, K

EELOQ, SEEVAL, MPLAB and The

Embedded Control Solutions Company are registered trade­marks of Microchip Technology Incorporated in the U.S.A. and
other countries.

Total Endurance, ICSP, In-Circuit Serial Programming, Filter­Lab, MXDEV, microID, FlexROM, fuzzyLAB, MPASM,
MPLINK, MPLIB, PICDEM, ICEPIC, Migratable Memory,
FanSense, ECONOMONITOR and SelectMode are trade­marks of Microchip Technology Incorporated in the U.S.A.

Serialized Quick T erm Programming (SQTP) is a service mark
of Microchip Technology Incorporated in the U.S.A.

All other trademarks mentioned herein are property of their
respective companies.

© 2001, Microchip Technology Incorporated, Printed in the
U.S.A., All Rights Reserved.

Microchip received QS-9000 quality system
certification for its worldwide headquarters,
design and wafer fabrication facilities in
Chandler and Tempe, Arizona in July 1999. The
Company’s quality system processes and
procedures are QS-9000 compliant for its
PICmicro

devices, Serial EEPROMs and microperipheral
products. In addition, Microchip’s quality
system for the design and manufacture of
development systems is ISO 9001 certified.

®

8-bit MCUs, KEELOQ

®

code hoppin g

DS30292C - page ii  2001 Microchip Technology Inc.

PIC16F87X

28/40-Pin 8-Bit CMOS FLASH Microcontrollers

Devices Included in this Data Sheet:

• PIC16F873

• PIC16F874

• PIC16F876

• PIC16F877

Microcontroller Core Features:

• High performance RISC CPU

• Only 35 single word instructions to learn

• All single cycle instructions except for program

branches which are two cycle

• Operating speed: DC - 20 MHz clock input
DC - 200 ns instruction cycle

• Up to 8K x 14 words of FLASH Program M em ory,

Up to 368 x 8 bytes of Data Memory (RAM)
Up to 256 x 8 bytes of EEPROM Data Memory

• Pinout compatible to the PIC16C73B/74B/76/77

• Interrupt capability (up to 14 sources)

• Eight level deep hardware stack

• Direct, indirect and relative addressing modes

• Power-on Reset (POR)

• Power-up Timer (PWRT) and

Oscillator Start-up Timer (OST)

• Watchdog Timer (WDT) with its own on-chip RC

oscillator for reliable opera tion

• Programmable code protection

• Power saving SLEEP mode

• Selectable oscillator options

• Low power, high speed CMOS FLASH/EEPROM

technology

• Fully static design

• In-Circuit Serial Programming (ICSP) via two

pins

• Single 5V In-Circuit Seria l Programming capabi lit y

• In-Circuit Debugging via two pins

• Processor read/write access to program memory

• Wide operating voltage range: 2.0V to 5.5V

• High Sink/Source Current: 25 mA

• Commercial, Industria l and Extended temp erature

ranges

• Low-power consumption:

- < 0.6 mA typical @ 3V, 4 MHz

-20 µA typical @ 3V, 32 kHz

-< 1 µA typical standby current

Pin Diagram

PDIP

MCLR/VPP

RA0/AN0
RA1/AN1

RA2/AN2/VREF-

RA3/AN3/VREF+

RA4/T0CKI

RA5/AN4/SS

RE0/RD/AN5

RE1/WR/AN6

RE2/CS/AN7

VDD
VSS

OSC1/CLKIN

OSC2/CLKOUT

RC0/T1OSO/T1CKI

RC1/T1OSI/CCP2

RC2/CCP1

RC3/SCK/SCL

RD0/PSP0
RD1/PSP1

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20

PIC16F877/874

40
39
38
37
36
35
34
33
32
31
30
29
28
27
26
25
24
23
22
21

RB7/PGD
RB6/PGC
RB5
RB4
RB3/PGM
RB2

RB1
RB0/INT
VDD
VSS
RD7/PSP7
RD6/PSP6
RD5/PSP5
RD4/PSP4
RC7/RX/DT
RC6/TX/CK
RC5/SDO
RC4/SDI/SDA
RD3/PSP3
RD2/PSP2

Peripheral Features:

• Timer0: 8-bit timer/counter with 8-bit prescaler

• Timer1: 16-bit timer/counter with prescaler,

can be incremented during SLEEP via external
crystal/clock

• Timer2: 8-bit timer/counter with 8-bit period
register, prescaler and postscaler

• Two Capture, Compare, PWM modules

- Capture is 16-bit, max. resolution is 12.5 ns

- Compare is 16-bit, max. resolution is 200 ns

- PWM max. resolution is 10-bit

• 10-bit multi-channel Analog-to-Digital converter

• Synchronous Serial Port (SSP) with SPI

mode) and I

2C

(Master/Slave)

• Universal Synchronous Asynchronous Receiver
Transmitter (USART/SCI) with 9-bit address
detection

• Parallel Slave Port (PSP) 8-bits wide, with
external RD

, WR and CS controls (40/44-pin only)

• Brown-out detection circuitry for
Brown-out Reset (BOR)



(Master

 2001 Microchip Technology Inc. DS30292C-page 1

PIC16F87X

Pin Diagrams

PDIP, SOIC

MCLR/VPP

RA0/AN0
RA1/AN1

RA2/AN2/V

RA3/AN3/V

OSC2/CLKOUT

RC0/T1OSO/T1CKI

RC1/T1OSI/CCP2

RC3/SCK/SCL

REF-

REF+

RA4/T0CKI

RA5/AN4/SS

VSS

OSC1/CLKIN

RC2/CCP1

1
2
3
4
5
6
7
8
9

10
11

12
13
14

PIC16F876/873

28
27
26
25
24
23
22
21
20
19
18
17
16
15

RB7/PGD
RB6/PGC
RB5
RB4
RB3/PGM
RB2
RB1
RB0/INT
V

DD

VSS
RC7/RX/DT
RC6/TX/CK
RC5/SDO
RC4/SDI/SDA

REF-

/VPP

PLCC

RA4/T0CKI

RA5/AN4/SS

RE0/RD/AN5

RE1/WR

/AN6

RE2/CS

/AN7

V

DD

VSS

OSC1/CLKIN

OSC2/CLKOUT

RC0/T1OSO/T1CK1

NC

RA3/AN3/VREF+

65432

7
8
9
10
11
12
13
14
15
16
17

181920212223242526

NC

RA1/AN1

RA0/AN0

RB7/PGD

MCLR

1

44

RA2/AN2/V

PIC16F877
PIC16F874

RB6/PGC

43

RB5

42

RB4

41

27

NC

40

39
38
37
36
35
34
33
32
31
30
29
28

RB3/PGM
RB2
RB1
RB0/INT
V

DD

VSS
RD7/PSP7
RD6/PSP6
RD5/PSP5
RD4/PSP4
RC7/RX/DT

RC7/RX/DT

RD4/PSP4
RD5/PSP5
RD6/PSP6
RD7/PSP7

V
VDD

RB0/INT

RB1
RB2

RB3/PGM

NC

RC5/SDO

RD3/PSP3

RD2/PSP2

RD1/PSP1

RD0/PSP0

QFP

SS

RC6/TX/CK

4443424140

1
2
3
4
5
6
7
8
9
10
11

121314

NC

RC5/SDO

RC4/SDI/SDA

RD3/PSP3

RD2/PSP2

RD1/PSP1

RD0/PSP0

39

38

PIC16F877
PIC16F874

16

17

1819202122

15

NC

RB5

RB4

RB6/PGC

RB7/PGD

/VPP

MCLR

RC3/SCK/SCL

RC2/CCP1

RC1/T1OSI/CCP2

363435

37

REF-

RA1/AN1

RA0/AN0

RA2/AN2/V

NC

33
32
31
30
29
28
27
26
25
24

23

RA3/AN3/VREF+

NC
RC0/T1OSO/T1CKI
OSC2/CLKOUT
OSC1/CLKIN

SS

V
VDD
RE2/AN7/CS
RE1/AN6/WR
RE0/AN5/RD
RA5/AN4/SS
RA4/T0CKI

RC2/CCP1

RC3/SCK/SCL

RC1/T1OSI/CCP2

RC6/TX/CK

RC4/SDI/SDA

DS30292C-page 2  2001 Microchip Technology Inc.

PIC16F87X

Key Features

PICmicro™ Mid-Range Reference

Manual (DS33023)

Operating Frequency DC - 20 MHz DC - 20 MHz DC - 20 MHz DC - 20 MHz

RESETS (and Delays) POR, BOR

FLASH Program Memory

(14-bit words)

Data Memory (bytes) 192 192 368 368

EEPROM Data Memory 128 128 256 256

Interrupts 13 14 13 14

I/O Ports Ports A,B,C Ports A,B,C,D,E Ports A,B,C Ports A,B,C,D,E

Timers 3333

Capture/Compa re/PW M Modules 2 2 2 2

Serial Communications MSSP, USART MSSP, USART MSSP, USART MSSP, USART

Parallel Communications — PSP — PSP

10-bit Analog-to-Digital Module 5 input channels 8 input channels 5 input channels 8 input channels

Instruction Set 35 instructions 35 instructions 35 instructions 35 instructions

PIC16F873 PIC16F874 PIC16F876 PIC16F877

POR, BOR

(PWRT, OST)

4K 4K 8K 8K

(PWRT, OST)

POR, BOR

(PWRT, OST)

POR, BOR

(PWRT, OST)

 2001 Microchip Technology Inc. DS30292C-page 3

PIC16F87X

Table of Contents

1.0 Device Overview................................................................................................................................................... 5

2.0 Memory Organization.......................................................................................................................................... 11

3.0 I/O Ports.............................................................................................................................................................. 29

4.0 Data EEPROM and FLASH Program Memory.................................................................................................... 41

5.0 Timer0 Module.................................................................................................................................................... 47

6.0 Timer1 Module.................................................................................................................................................... 51

7.0 Timer2 Module.................................................................................................................................................... 55

8.0 Capture/Compare/PWM Modules....................................................................................................................... 57

9.0 Master Synchronous Serial Port (MSSP) Module............................................................................................... 65

10.0 Addressable Universal Synchronous Asynchronous Receiver Transmitter (USART) ........................................ 95

11.0 Analog-to-Digital Converter (A/D) Module......................................................................................................... 111

12.0 Special Features of the CPU............................................................................................................................. 119

13.0 Instruction Set Summary ................................................................................................................................... 135

14.0 Development Support ....................................................... ...... ...... ..... ............................................................... 143

15.0 Electrical Characteristics................................................................................................................................... 149

16.0 DC and AC Characteristics Graphs and Tables................................................................................................ 177

17.0 Packaging Information ...................................................................................................................................... 189

Appendix A: Revision History .................................................................................................................................... 197

Appendix B: Device Differences ................................................................................................................................ 197

Appendix C: Conversion Considerations................................................................................................................... 198

Index .......................................................................................................................................................................... 199

On-Line Support......................................................................................................................................................... 207

Reader Response...................................................................................................................................................... 208

PIC16F87X Product Identification System................................................................................................................. 209

TO OUR VALUED CUSTOMERS

It is our intention to provide our valued customers with the best documentation possible to ensure successful use of your Microchip
products. To this end, we will continue to improve our publications to better suit your needs. Our publications will be refined and
enhanced as new volumes and updates are introduced.

If you have any questions or c omm ents regarding th is publication, p lease c ontact the M a rketing Communications Department via
E-mail at [e-mail] or fax the Reader Response Form in the back of this data sheet to [phone].
We welcome your feedback.

Most Current Data Sheet

To obtain the most up-to-date version of this data sheet, please register at our Worldwide Web site at:

http://www.microchip.com

You can determine the version of a data sheet by examining its literature number found on the bottom outside corner of any page.
The last character of the literature number is the version number, (e.g., DS30000A is version A of document DS30000).

Errata

An errata sheet, describing minor operational differences from the data sheet and recommended workarounds, may exist for current
devices. As device/documentation issues become known to us, we will publish an errata sheet. The errata will specify the revision
of silicon and revision of document to which it applies.

To determine if an errata sheet exists for a particular device, please check with one of the following:

• Microchip’s Worldwide Web site; http://www.microchip.com

• Your local Microchip sales office (see last page)

• The Microchip Corporate Literature Center; U.S. FAX: [phone]

When contacting a sales office or the literature center, please specify which device, revision of silicon and data sheet (include liter­ature number) you are using.

Customer Notification System

Register on our web site at www.microchip.com/cn to receive the most current information on all of our products.

DS30292C-page 4  2001 Microchip Technology Inc.

PIC16F87X

1.0 DEVICE OVERVIEW

There are four devices (PIC16F873, PIC16F874,
PIC16F876 and PIC16F877) covered by this data

This document contains device specific information.
Additional information may be found in the PICmicro™
Mid-Range Reference Manual (DS33023), which may
be obtained from your local Microchip Sales Represen­tative or downloaded from the Microchip website. The
Reference Manual should be considered a complemen­tary document to this data sheet, and is highly recom­mended reading for a better understanding of the device
architecture and operation of the peripheral modules.

sheet. The PIC16F876/873 devices come in 28-pin
packages and the PIC16F877/874 devices come in
40-pin packages. The Parallel Slave Port is not
implemented on the 28-pin devic es .

The following device block diagrams are s orted by pin
number; 28-pin for Figure 1-1 and 40-pin for Figure 1-2.
The 28-pin and 40-pin pin outs are listed in Table 1- 1
and Table 1-2, respectively.

FIGURE 1-1: PIC16F873 AND PIC16F876 BLOCK DIAGRAM

Device

Program

FLASH

Data Memory

PIC16F873 4K 192 Bytes 128 Bytes
PIC16F876 8K 368 Bytes 256 Bytes

13

Program Counter

FLASH

Program

Program

Bus

OSC1/CLKIN
OSC2/CLKOUT

Memory

14

Instruction reg

Instruction

Decode &

Control

Timing

Generation

Direct Addr

8

8 Level Stack

(13-bit)

Power-up

Timer

Oscillator

Start-up Timer

Power-on

Reset

Watchdog

Timer

Brown-out

Reset

In-Circuit

Debugger

Low Voltage

Programming

Data

EEPROM

RAM Addr

7

8

Data Bus

(1)

3

RAM

File

Registers

9

Addr MUX

8

FSR reg

STATUS reg

MUX

ALU

W reg

8

Indirect

Addr

PORTA

PORTB

PORTC

RA0/AN0
RA1/AN1
RA2/AN2/VREF­RA3/AN3/VREF+
RA4/T0CKI
RA5/AN4/SS

RB0/INT
RB1
RB2
RB3/PGM
RB4
RB5
RB6/PGC
RB7/PGD

RC0/T1OSO/T1CKI
RC1/T1OSI/CCP2
RC2/CCP1

RC3/SCK/SCL
RC4/SDI/SDA
RC5/SDO
RC6/TX/CK
RC7/RX/DT

MCLR

Data EEPROM

Note 1: Higher order bits are from the STATUS register.

CCP1,2

VDD, VSS

Synchronous

Serial Port

10-bit A/DTimer0 Timer1 Timer2

USART

 2001 Microchip Technology Inc. DS30292C-page 5

PIC16F87X

FIGURE 1-2: PIC16F874 AND PIC16F877 BLOCK DIAGRAM

Device

Program

FLASH

Data Memory

Data

EEPROM

PIC16F874 4K 192 Bytes 128 Bytes
PIC16F877 8K 368 Bytes 256 Bytes

13

Program Counter

8 Level Stack

Direct Addr

8

Power-up

Oscillator

Start-up Timer

Power-on

Watchdog
Brown-out

In-Circuit

Debugger

Low-Voltage

Programming

MCLR

(13-bit)

RAM Addr

7

Timer

Reset

Timer

Reset

VDD, VSS

Program

Bus

OSC1/CLKIN
OSC2/CLKOUT

FLASH
Program

Memory

14

Instruction reg

Instruction

Decode &

Control

Timing

Generation

Data Bus

RAM

File

Registers

(1)

Addr MUX

3

ALU

8

W reg

Parallel Slave Port

9

Indirect

8

Addr

FSR reg

STATUS reg

MUX

10-bit A/DTimer0 Timer1 Timer2

8

PORTA

PORTB

PORTC

PORTD

PORTE

RA0/AN0
RA1/AN1
RA2/AN2/VREF­RA3/AN3/VREF+
RA4/T0CKI
RA5/AN4/SS

RB0/INT
RB1
RB2
RB3/PGM
RB4
RB5
RB6/PGC
RB7/PGD

RC0/T1OSO/T1CKI
RC1/T1OSI/CCP2
RC2/CCP1
RC3/SCK/SCL
RC4/SDI/SDA
RC5/SDO
RC6/TX/CK
RC7/RX/DT

RD0/PSP0
RD1/PSP1
RD2/PSP2
RD3/PSP3
RD4/PSP4
RD5/PSP5
RD6/PSP6
RD7/PSP7

RE0/AN5/RD
RE1/AN6/WR

RE2/AN7/CS

Data EEPROM

Note 1: Higher order bits are from the STATUS register.

CCP1,2

Synchronous

Serial Port

USART

DS30292C-page 6  2001 Microchip Technology Inc.

TABLE 1-1: PIC16F873 AND PIC16F876 PINOUT DESCRIPTION

PIC16F87X

Pin Name

DIP

Pin#

OSC1/CLKIN 9 9 I ST/CMOS

SOIC

Pin#

I/O/P
Type

Buffer

Type

Description

(3)

Oscillator crystal input/external clock source input.

OSC2/CLKOUT 10 10 O — Oscillator crystal output. Connects to crystal or resonator in

crystal oscillator mode. In RC mode, the OSC2 pin outputs
CLKOUT which has 1/4 the frequency of OSC1, and denotes
the instruction cycle rate.

/VPP 1 1 I/P ST Master Clear (Reset) input or programming voltage input. This

MCLR

pin is an active low RESET to the device.

PORTA is a bi-directional I/O port.
RA0/AN0 2 2 I/O TTL RA0 can also be analog input0.
RA1/AN1 3 3 I/O TTL RA1 can also be analog input1.
RA2/AN2/V

REF- 4 4 I/O TTL RA2 can also be analog input2 or negative analog

reference voltage.

RA3/AN3/V

REF+ 5 5 I/O TTL RA3 can also be analog input3 or positive analog

reference voltage.

RA4/T0CKI 6 6 I/O ST RA4 can also be the clock input to the Timer0

module. Output is open drain type.

/AN4 7 7 I/O TTL RA5 can also be analog input4 or the slave select

RA5/SS

for the synchronous serial port.

PORTB is a bi-directional I/O port. PORTB can be software

programmed for internal weak pull-up on all inputs.
RB0/INT 21 21 I/O TTL/ST

(1)

RB0 can also be the external interrupt pin.
RB1 22 22 I/O TTL
RB2 23 23 I/O TTL
RB3/PGM 24 24 I/O TTL RB3 can also be the low voltage programming input.
RB4 25 25 I/O TTL Interrupt-on-change pin.
RB5 26 26 I/O TTL Interrupt-on-change pin.
RB6/PGC 27 27 I/O TTL/ST

(2)

Interrupt-on-change pin or In-Circuit Debugger pin. Serial

programming clock.
RB7/PGD 28 28 I/O TTL/ST

(2)

Interrupt-on-change pin or In-Circuit Debugger pin. Serial

programming data.

PORTC is a bi-directional I/O port.

RC0/T1OSO/T1CKI 11 11 I/O ST RC0 can also be the Timer1 oscillator output or Timer1

clock input.
RC1/T1OSI/CCP2 12 12 I/O ST RC1 can also be the Timer1 oscillator input or Capture2

input/Compare2 output/PWM2 output.
RC2/CCP1 13 13 I/O ST RC2 can also be the Capture1 input/Compare1 output/

PWM1 output.
RC3/SCK/SCL 14 14 I/O ST RC3 can also be the synchronous serial clock input/output

for both SPI and I
RC4/SDI/SDA 15 15 I/O ST RC4 can also be the SPI Data In (SPI mode) or

data I/O (I

2

C mode).

2

C modes.

RC5/SDO 16 16 I/O ST RC5 can also be the SPI Data Out (SPI mode).
RC6/TX/CK 17 17 I/O ST RC6 can also be the USART Asynchronous Transmit or

Synchronous Clock.
RC7/RX/DT 18 18 I/O ST RC7 can also be the USART Asynchronous Rece ive or

Synchronous Data.

SS 8, 19 8, 19 P — Ground reference for logic and I/O pins.

V

DD 20 20 P — Positive supply for logic and I/O pins.

V
Legend: I = input O = output I/O = input/output P = power

— = Not used TTL = TTL input ST = Schmitt Trigger input

Note 1: This buffer is a Schmitt Trigger input when configured as the external interrupt.

2: This buffer is a Schmitt Trigger input when used in Serial Programming mode.
3: This buffer is a Schmitt Trigger input when configured in RC oscillator mode and a CMOS input otherwise.

 2001 Microchip Technology Inc. DS30292C-page 7

PIC16F87X

TABLE 1-2: PIC16F874 AND PIC16F877 PINOUT DESCRIPTION

DIP

Pin Name

OSC1/CLKIN 13 14 30 I ST/CMOS
OSC2/CLKOUT 14 15 31 O — Oscillator crystal output. Connects to crystal or resonator

/VPP 1 2 18 I/P ST Master Clear (Reset) input or programming voltage input.

MCLR

RA0/AN0 2 3 19 I/O TTL RA0 can also be analog input0.
RA1/AN1 3 4 20 I/O TTL RA1 can also be analog input1.
RA2/AN2/V

RA3/AN3/V

RA4/T0CKI 6 7 23 I/O ST RA4 can also be the clock input to the Timer0 timer/

RA5/SS/

RB0/INT 33 36 8 I/O TTL/ST
RB1 34 37 9 I/O TTL
RB2 35 38 10 I/O TTL
RB3/PGM 36 39 11 I/O TTL RB3 can also be the low voltage programming input.
RB4 37 41 14 I/O TTL Interrupt-on-change pin.
RB5 38 42 15 I/O TTL Interrupt-on-change pin.
RB6/PGC 39 43 16 I/O TTL/ST

RB7/PGD 40 44 17 I/O TTL/ST

Legend: I = input O = output I/O = input/output P = power

Note 1: This buffer is a Schmitt Trigger input when configured as an external interrupt.

REF- 4 5 21 I/O TTL RA2 can also be analog input2 or negative

REF+ 5 6 22 I/O TTL RA3 can also be analog input3 or positive

AN4 7 8 24 I/O TTL RA5 can also be analog input4 or the slave select for

2: This buffer is a Schmitt Trigger input when used in Serial Programming mode.
3: This buffer is a Schmitt Trigger input when configured as general purpose I/O and a TTL input when used in the Parallel

Slave Port mode (for interfacing to a microprocessor bus).

4: This buffer is a Schmitt Trigger input when configured in RC oscillator mode and a CMOS input otherwise.

PLCC

Pin#

— = Not used TTL = TTL input ST = Schmitt Trigger input

Pin#

QFP
Pin#

I/O/P

Type

Buffer

Type

Description

(4)

Oscillator crystal input/external clock source input.

in crystal oscillator mode. In RC mode, OSC2 pin outputs
CLKOUT which has 1/4 the frequency of OSC1, and
denotes the instruction cycle rate.

This pin is an active low RESET to the device.
PORTA is a bi-directional I/O port.

analog reference voltage.

analog reference voltage.

counter. Output is open drain type.

the synchronous serial port.

PORTB is a bi-directional I/O port. PORTB can be soft­ware programmed for internal weak pull-up on all inputs.

(1)

(2)

(2)

RB0 can also be the external interrupt pin.

Interrupt-on-change pin or In-Circuit Debugger pin.
Serial programming clock.

Interrupt-on-change pin or In-Circuit Debugger pin.
Serial programming data.

DS30292C-page 8  2001 Microchip Technology Inc.

PIC16F87X

TABLE 1-2: PIC16F874 AND PIC16F877 PINOUT DESCRIPTION (CONTINUED)

DIP

Pin Name

Pin#

PLCC

Pin#

RC0/T1OSO/T1CKI 15 16 32 I/O ST RC0 can also be the Timer1 oscillator output or a

RC1/T1OSI/CCP2 16 18 35 I/O ST RC1 can also be the Timer1 oscillator input or

RC2/CCP1 17 19 36 I/O ST RC2 can also be the Capture1 input/Compare1

RC3/SCK/SCL 18 20 37 I/O S T RC3 can also be the synchronous serial clock input/

RC4/SDI/SDA 23 25 42 I/O ST RC4 can also be the SPI Data In (SPI mode) or

RC5/SDO 24 26 43 I/O ST RC5 can also be the SPI Data Out (SPI mode).
RC6/TX/CK 25 27 44 I/O ST RC6 can also be the USART Asynchronous Transmit

RC7/RX/DT 26 29 1 I/O S T RC7 can also be the USART Asynchronous Receive

RD0/PSP0 19 21 38 I/O ST/TTL
RD1/PSP1 20 22 39 I/O ST/TTL
RD2/PSP2 21 23 40 I/O ST/TTL
RD3/PSP3 22 24 41 I/O ST/TTL
RD4/PSP4 27 30 2 I/O ST/TTL
RD5/PSP5 28 31 3 I/O ST/TTL
RD6/PSP6 29 32 4 I/O ST/TTL
RD7/PSP7 30 33 5 I/O ST/TTL

/AN5 8 9 25 I/O ST/TTL

RE0/RD

RE1/WR

RE2/CS

V
V

/AN6 9 10 26 I/O ST/TTL

/AN7 10 11 27 I/O ST/TTL

SS 12,31 13,34 6,29 P — Ground reference for logic and I/O pins.
DD 11,32 12,35 7,28 P — Positive supply for logic and I/O pins.

NC — 1,17,28,4012,13,

Legend: I = input O = output I/O = input/output P = power

— = Not used TTL = TTL input ST = Schmitt Trigger input

Note 1: This buffer is a Schmitt Trigger input when configured as an external interrupt.

2: This buffer is a Schmitt Trigger input when used in Serial Programming mode.
3: This buffer is a Schmitt Trigger input when configured as general purpose I/O and a TTL input when used in the Parallel

Slave Port mode (for interfacing to a microprocessor bus).

4: This buffer is a Schmitt Trigger input when configured in RC oscillator mode and a CMOS input otherwise.

QFP
Pin#

33,34

I/O/P
Type

Buffer

Type

Description

PORTC is a bi-directional I/O port.

Timer1 clock input.

Capture2 input/Compare2 output/PWM2 output.

output/PWM1 output.

2

output for both SPI and I

2

data I/O (I

C mode).

C modes.

or Synchronous Clock.

or Synchronous Data.

PORTD is a bi-directional I/O port or parallel slave port
when interfacing to a microprocessor bus.

(3)
(3)
(3)
(3)
(3)
(3)
(3)
(3)

PORTE is a bi-directional I/O port.

(3)

RE0 can also be read control for the parallel slave
port, or analog input5.

(3)

RE1 can also be write control for the parallel slave
port, or analog input6.

(3)

RE2 can also be select control for the parallel slave
port, or analog input7.

— These pins are not internally connected. These pins

should be left unconnected.

 2001 Microchip Technology Inc. DS30292C-page 9

PIC16F87X

NOTES:

DS30292C-page 10  2001 Microchip Technology Inc.

PIC16F87X

2.0 MEMORY ORGANIZATION

There are three memory blocks in each of the
PIC16F87X MCUs. The Program Memory and Data
Memory have separate buses so that concurrent
access can oc cur and is detailed in this section. The
EEPROM data memory block is detailed in Se ction 4.0.

Additional informa tion on devi ce memory may be found
in the PICmicro Mid-Range Reference Manual,
(DS33023).

FIGURE 2-1: PIC16F877/876 PROGRAM

MEMORY MAP AND
STACK

PC<12:0>

CALL, RETURN
RETFIE, RETLW

Stack Level 1

Stack Level 2

13

2.1 Program Memory Organization

The PIC16F87X devic es have a 13-bit p rogram count er
capable of addressing an 8K x 14 program memory
space. The PIC16F877/876 devices have 8K x 14
words of FLASH program memory, and the
PIC16F873/874 devices have 4K x 14. Accessing a
location above the ph ysicall y implem ented addres s will
cause a wraparound.

The RESET vector is at 0000h and the interrupt vector
is at 0004h.

FIGURE 2-2: PIC16F874/873 PROGRAM

MEMORY MAP AND
STACK

PC<12:0>

CALL, RETURN
RETFIE, RETLW

Stack Level 1

Stack Level 2

13

On-Chip
Program

Memory

Stack Level 8

RESET Vector

Interrupt Vector

Page 0

Page 1

Page 2

Page 3

0000h

0004h

0005h

07FFh

0800h

0FFFh

1000h

17FFh

1800h

1FFFh

On-Chip

Program

Memory

Stack Level 8

RESET Vector

Interrupt Vector

Page 0

Page 1

0000h

0004h

0005h

07FFh

0800h

0FFFh

1000h

1FFFh

 2001 Microchip Technology Inc. DS30292C-page 11

PIC16F87X

2.2 Data Memory Organization

The data memory is partitioned into multiple banks
which contain the General Purpose Registers and the
Special Function Registers. Bits RP1 (STATUS<6>)
and RP0 (STATUS<5>) are the bank select bits.

RP1:RP0 Bank

00 0
01 1
10 2
11 3

Each bank extends up to 7Fh (128 bytes). The lower
locations of each bank are reserved for the Special
Function Registers. Above the Special Function Regis­ters are General Purpose Registers, implemented as
static RAM. All implemented banks contain Special
Function Registers. Some frequently used Special
Function Registers from one bank may be mirrored in
another bank for code reduction and quicker access.

Note: EEPROM Data Memory de scription can b e

found in Section 4.0 of this data sheet.

2.2.1 GENERAL PURPOSE REGISTER FILE

The register file can be acces sed either directly, or indi­rectly through the File Select Register (FSR).

DS30292C-page 12  2001 Microchip Technology Inc.

FIGURE 2-3: PIC16F877/876 REGISTER FILE MAP

PIC16F87X

Indirect addr.

TMR0

PCL

STATUS

FSR
PORTA
PORTB
PORTC

PORTD
PORTE

(1)
(1)

PCLATH
INTCON

PIR1
PIR2

TMR1L
TMR1H
T1CON

TMR2

T2CON

SSPBUF

SSPCON

CCPR1L

CCPR1H

CCP1CON

RCSTA

TXREG
RCREG

CCPR2L
CCPR2H

CCP2CON

ADRESH
ADCON0

File

File

Address

Address

(*)

00h
01h
02h
03h
04h
05h
06h
07h
08h
09h
0Ah
0Bh
0Ch
0Dh
0Eh
0Fh
10h
11h
12h
13h
14h
15h
16h
17h
18h
19h
1Ah
1Bh
1Ch
1Dh
1Eh
1Fh
20h

Indirect addr.
OPTION_REG

PCL

STATUS

FSR
TRISA
TRISB
TRISC

(1)

TRISD

(1)

TRISE
PCLATH
INTCON

PIE1
PIE2

PCON

SSPCON2

PR2

SSPADD

SSPSTAT

TXSTA

SPBRG

ADRESL

ADCON1

Address

(*)

File

80h
81h
82h
83h
84h
85h
86h
87h
88h
89h
8Ah
8Bh
8Ch
8Dh
8Eh
8Fh
90h
91h
92h
93h
94h
95h
96h
97h
98h
99h
9Ah
9Bh
9Ch
9Dh
9Eh
9Fh

A0h

Indirect addr.

TMR0

PCL

STATUS

FSR

PORTB

PCLATH

INTCON
EEDATA

EEADR

EEDATH

EEADRH

General
Purpose
Register

16 Bytes

Address

(*)

File

100h
101h
102h
103h
104h
105h
106h
107h
108h
109h
10Ah
10Bh
10Ch
10Dh
10Eh
10Fh
110h
111h
112h
113h
114h
115h
116h
117h
118h
119h
11Ah
11Bh
11Ch
11Dh
11Eh
11Fh
120h

Indirect addr.

OPTION_REG

PCL

STATUS

FSR

TRISB

PCLATH

INTCON
EECON1
EECON2

Reserved
Reserved

(2)

(2)

General
Purpose
Register

16 Bytes

Address

(*)

File

180h
181h
182h
183h
184h
185h
186h
187h
188h
189h
18Ah
18Bh
18Ch
18Dh
18Eh
18Fh
190h
191h
192h
193h
194h
195h
196h
197h
198h
199h
19Ah
19Bh
19Ch
19Dh
19Eh
19Fh

1A0h

General
Purpose
Register

96 Bytes

Bank 0

7Fh

General
Purpose
Register

80 Bytes 80 Bytes 80 Bytes

EFh

accesses

F0h

70h-7Fh

FFh

Bank 1

General
Purpose
Register

accesses

70h-7Fh

Bank 2

16Fh
170h

17Fh

General
Purpose
Register

accesses
70h - 7Fh

Bank 3

1EFh
1F0h

1FFh

Unimplemented data memory locations, read as ’0’.

* Not a physical register.

Note 1: These registers are not implemented on the PIC16F876.

2: These registers are reserved, maintain these registers clear.

 2001 Microchip Technology Inc. DS30292C-page 13

PIC16F87X

FIGURE 2-4: PIC16F874/873 REGISTER FILE MAP

Indirect addr.

TMR0

PCL

STATUS

FSR
PORTA
PORTB

PORTC
PORTD
PORTE

(1)
(1)

PCLATH
INTCON

PIR1
PIR2

TMR1L
TMR1H
T1CON

TMR2

T2CON

SSPBUF

SSPCON

CCPR1L

CCPR1H

CCP1CON

RCSTA

TXREG
RCREG

CCPR2L

CCPR2H

CCP2CON

ADRESH
ADCON0

File

Address

(*)

00h
01h
02h
03h
04h
05h
06h
07h
08h
09h
0Ah
0Bh
0Ch
0Dh
0Eh
0Fh
10h
11h
12h
13h
14h
15h
16h
17h
18h
19h
1Ah
1Bh
1Ch
1Dh
1Eh
1Fh
20h

Indirect addr.
OPTION_REG

PCL

STATUS

FSR
TRISA
TRISB
TRISC

(1)

TRISD

(1)

TRISE
PCLATH
INTCON

PIE1
PIE2

PCON

SSPCON2

PR2

SSPADD

SSPSTAT

TXSTA

SPBRG

ADRESL

ADCON1

File

Address

(*)

80h
81h
82h
83h
84h
85h
86h
87h
88h
89h
8Ah
8Bh
8Ch
8Dh
8Eh
8Fh
90h
91h
92h
93h
94h
95h
96h
97h
98h
99h
9Ah
9Bh
9Ch
9Dh
9Eh
9Fh

A0h

Indirect addr.

TMR0

PCL

STATUS

FSR

PORTB

PCLATH

INTCON
EEDATA

EEADR

EEDATH
EEADRH

Address

(*)

File

100h
101h
102h
103h
104h
105h
106h
107h
108h
109h
10Ah
10Bh
10Ch
10Dh
10Eh
10Fh
110h

120h

Indirect addr.

OPTION_REG

PCL

STATUS

FSR

TRISB

PCLATH

INTCON
EECON1
EECON2

Reserved

Reserved

(2)
(2)

Address

(*)

File

180h
181h
182h
183h
184h
185h
186h
187h
188h
189h
18Ah
18Bh
18Ch
18Dh
18Eh
18Fh
190h

1A0h

General
Purpose
Register

96 Bytes

7Fh

Bank 0

General
Purpose
Register

96 Bytes

Bank 1

FFh

accesses

20h-7Fh

Bank 2

16Fh
170h

17Fh

accesses

A0h - FFh

1EFh
1F0h

1FFh

Bank 3

Unimplemented data memory locations, read as ’0’.

* Not a physical register.

Note 1: These registers are not implemented on the PIC16F873.

2: These registers are reserved, maintain these registers clear.

DS30292C-page 14  2001 Microchip Technology Inc.

PIC16F87X

2.2.2 SPECIAL FUNCTION REGISTERS

The Special Function Registers are registers used by
the CPU and peripheral modules for controlling the
desired operation of the device. These registers are
implemented as static RAM. A list of these registers is
given in Table 2-1.

The Special Function Registers can be classified into
two sets: core (CPU) and peripheral. Those registers
associated with the core functions are described in
detail in this section. Those related to the operation of
the peripheral features are described in detail in the
peripheral features section.

TABLE 2-1: SPECIAL FUNCTION REGISTER SUMMARY

Address Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

Bank 0

(3)

00h
01h TMR0 Timer 0 Module Register
02h
03h
04h
05h PORTA
06h PORTB PORTB Data Latch when written: PORTB pins when read
07h PORTC PORTC Data Latch when written: PORTC pins when read
08h
09h
0Ah
0Bh
0Ch PIR1 PSPIF
0Dh PIR2
0Eh TMR1L Holding register for the Least Significant Byte of the 16-bit TMR1 Register
0Fh TMR1H Holding register for the Most Significant Byte of the 16-bit TMR1 Register
10h T1CON
11h TMR2 Timer2 Module Regis ter
12h T2CON
13h SSPBUF Synchronous Serial Port Rece i ve Buffer/Transmit Regi ste r
14h SSPCON WCOL SSPOV SSPEN CKP SSPM3 SSPM2 SSPM1 SSPM0
15h CCPR1L Capture/Compare/PWM Register1 (LSB)
16h CCPR1H Capture/Compare/PWM Register1 (MSB)
17h CCP1CON
18h RCSTA SPEN RX9 SREN CREN ADDEN FERR OERR RX9D
19h TXREG USART Transmit Data Register
1Ah RCREG USART Receive Data Register
1Bh CCPR2L Capture/Compare/PWM Register2 (LSB)
1Ch CCPR2H Capture/Compare/PWM Register2 (MSB)
1Dh CCP2CON
1Eh ADRESH A/D Result Register High Byte
1Fh ADCON0 ADCS1 ADCS0 CHS2 CHS1 CHS0 GO/DONE
Legend:

Note 1: The upper byte of the program counter is not directly accessible. PCLATH is a holding register for the PC<12:8> whose

INDF Addressing this location uses contents of FSR to address data memory (not a physical register) 0000 0000 27

(3)

PCL Program Counter (PC) Least Significant Byte 0000 0000 26

(3)

STATUS IRP RP1 RP0 TO PD ZDCC0001 1xxx 18

(3)

FSR Indirect Data Memory Address Pointer xxxx xxxx 27

— — PORTA Data Latch when written: PORTA pins when read --0x 0000 29

(4)

PORTD PORTD Data Latch when written: PORTD pins when read xxxx xxxx 35

(4)

PORTE — — — — — RE2 RE1 RE0 ---- -xxx 36

(1,3)

PCLATH — — — Write Buffer for the upper 5 bits of the Program Counter ---0 0000 26

(3)

INTCON GIE PEIE T0IE INTE RBIE T0IF INTF RBIF 0000 000x 20

x = unknown, u = unchanged, q = value depends on condition, - = unimplemented, read as '0', r = reserved.

Shaded locations are unimplemented, read as ‘0’.

contents are transferred to the upper byte of the program counter.

2: Bits PSPIE and PSPIF are reserved on PIC16F873/876 devices; always maintain these bits clear.
3: These registers can be addressed from any bank.
4: PORTD, PORTE, TRISD, and TRISE are not physically implemented on PIC16F873/876 devices; read as ‘0’.
5: PIR2<6> and PIE2<6> are reserved on these devices; always maintain these bits clear.

(3)

ADIF RCIF TXIF SSPIF CCP1IF TMR2IF TMR1IF 0000 0000 22

— (5) — EEIF BCLIF — — CCP2IF -r-0 0--0 24

— — T1CKPS1 T1CKPS0 T1OSCEN T1SYNC TMR1CS TMR1ON --00 0000 51

— TOUTPS3 TOUTPS2 TOUTPS1 TOUTPS0 TMR2ON T2CKPS1 T2CKPS0 -000 0000 55

— — CCP1X CCP1Y CCP1M3 CCP1M2 CCP1M1 CCP1M0 --00 0000 58

— — CCP2X CCP2Y CCP2M3 CCP2M2 CCP2M1 CCP2M0 --00 0000 58

— ADON 0000 00-0 111

Value on:

POR,

BOR

xxxx xxxx 47

xxxx xxxx 31
xxxx xxxx 33

xxxx xxxx 52
xxxx xxxx 52

0000 0000 55

xxxx xxxx 70, 73
0000 0000 67
xxxx xxxx 57
xxxx xxxx 57

0000 000x 96
0000 0000 99
0000 0000 101
xxxx xxxx 57
xxxx xxxx 57

xxxx xxxx 116

Details

on

page:

 2001 Microchip Technology Inc. DS30292C-page 15

PIC16F87X

TABLE 2-1: SPECIAL FUNCTION REGISTER SUMMARY (CONTINUED)

Address Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

Bank 1

(3)

80h
81h OPTION_REG RBPU
82h
83h
84h
85h TRISA
86h TRISB PORTB Data Direction Register
87h TRISC PORTC Data Direction Register
88h
89h
8Ah
8Bh
8Ch PIE1 PSPIE
8Dh PIE2
8Eh PCON
8Fh — Unimplemented — —
90h — Unimplemented — —
91h S SPCON2 GCEN ACKSTAT ACKDT ACKEN RCEN PEN RSEN SEN
92h PR2 Timer2 Period Register
93h SSPADD Synchronous Serial Port (I
94h SSPSTAT SMP CKE D/A
95h — Unimplemented — —
96h — Unimplemented — —
97h — Unimplemented — —
98h TXSTA CSRC TX9 TXEN SYNC
99h SPBRG Baud Rate Generator Register
9Ah — Unimplemented — —
9Bh — Unimplemented — —
9Ch — Unimplemented — —
9Dh — Unimplemented — —
9Eh ADRESL A/D Result Register Low Byte
9Fh ADCON1 ADFM
Legend: x = unknown, u = unchanged, q = value depends on condition, - = unimplemented, read as '0', r = reserved.

Note 1: The upper byte of the program counter is not directly accessible. PCLATH is a holding register for the PC<12:8> whose

INDF Addressing this location uses contents of FSR to address data memory (not a physical register) 0000 0000 27

(3)

PCL Program Counter (PC) Least Significant Byte 0000 0000 26

(3)

STATUS IRP RP1 RP0 TO PD ZDCC0001 1xxx 18

(3)

FSR Indirect Data Memory Address Pointer xxxx xxxx 27

(4)

TRISD PORTD Data Direction Register 1111 1111 35

(4)

TRISE IBF OBF IBOV PSPMODE — PORTE Data Direction Bits 0000 -111 37

(1,3)

PCLATH — — — Write Buffer for the upper 5 bits of the Program Counter ---0 0000 26

(3)

INTCON GIE PEIE T0IE INTE RBIE T0IF INTF RBIF 0000 000x 20

Shaded locations are unimplemented, read as ‘0’.

contents are transferred to the upper byte of the program counter.

2: Bits PSPIE and PSPIF are reserved on PIC16F873/876 devices; always maintain these bits clear.
3: These registers can be addressed from any bank.
4: PORTD, PORTE, TRISD, and TRISE are not physically implemented on PIC16F873/876 devices; read as ‘0’.
5: PIR2<6> and PIE2<6> are reserved on these devices; always maintain these bits clear.

INTEDG T0CS T0SE PSA PS2 PS1 PS0 1111 1111 19

— — PORTA Data Direction Register --11 1111 29

(2)

ADIE RCIE TXIE SSPIE CCP1IE TMR2IE TMR1IE 0000 0000 21

— (5) — EEIE BCLIE — — CCP2IE -r-0 0--0 23
— — — — — — POR BOR ---- --qq 25

2

C mode) Address Register 0000 0000 73, 74

PSR/WUA BF 0000 0000 66

— BRGH TRMT TX9D 0000 -010 95

— — — PCFG3 PCFG2 PCFG1 PCFG0 0--- 0000 112

Value on:

POR,
BOR

1111 1111 31
1111 1111 33

0000 0000 68
1111 1111 55

0000 0000 97

xxxx xxxx 116

Details

on

page:

DS30292C-page 16  2001 Microchip Technology Inc.

PIC16F87X

TABLE 2-1: SPECIAL FUNCTION REGISTER SUMMARY (CONTINUED)

Address Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

Bank 2

(3)

100h
101h TMR0 Timer0 Module Register
102h
103h
104h
105h — Unimplemented — —
106h PORTB PORTB Data Latch when written: PORTB pins when read
107h — Unimplemented — —
108h — Unimplemented — —
109h — Unimplemented — —
10Ah
10Bh
10Ch EEDATA EEPROM Da ta Register Low By te
10Dh EEADR EEPROM Address Register Low Byte
10Eh EEDATH
10Fh EEADRH
Bank 3
180h
181h OPTION_REG RBPU INTEDG T0CS T0SE PSA PS2 PS1 PS0
182h
183h
184h
185h — Unimplemented — —
186h TRISB PORTB Data Direction Register
187h — Unimplemented — —
188h — Unimplemented — —
189h — Unimplemented — —
18Ah
18Bh
18Ch EECON1 EEPGD
18Dh EECON2 EEPROM Control Register2 (not a physical register)
18Eh — Reserved maintain clear 0000 0000 —
18Fh — Reserved maintain clear 0000 0000 —
Legend:

Note 1: The upper byte of the program counter is not directly accessible. PCLATH is a holding register for the PC<12:8> whose

INDF Addressing this location uses contents of FSR to address data memory (not a physical register) 0000 0000 27

(3)

PCL Program Counter’s (PC) Least Significant Byte 0000 0000 26

(3)

STATUS IRP RP1 RP0 TO PD ZDCC0001 1xxx 18

(3)

FSR Indirect Data Memory Address Pointer xxxx xxxx 27

(1,3)

PCLATH — — — Write Buffer for the upper 5 bits of the Program Counter ---0 0000 26

(3)

INTCON GIE PEIE T0IE INTE RBIE T0IF INTF RBIF 0000 000x 20

— — EEPROM Data Register High Byte xxxx xxxx 41
— — — EEPROM Address Register High Byte xxxx xxxx 41

(3)

INDF Addressing this location uses contents of FSR to address data memory (not a physical register) 0000 0000 27

(3)

PCL Program Counter (PC) Least Significant Byte 0000 0000 26

(3)

STATUS IRP RP1 RP0 TO PD ZDCC0001 1xxx 18

(3)

FSR Indirect Data Memory Address Pointer xxxx xxxx 27

(1,3)

PCLATH — — — Write Buffer for the upper 5 bits of the Program Counter ---0 0000 26

(3)

INTCON GIE PEIE T0IE INTE RBIE T0IF INTF RBIF 0000 000x 20

— — — WRERR WREN WR RD x--- x000 41, 42

x = unknown, u = unchanged, q = value depends on condition, - = unimplemented, read as '0', r = reserved.

Shaded locations are unimplemented, read as ‘0’.

contents are transferred to the upper byte of the program counter.

2: Bits PSPIE and PSPIF are reserved on PIC16F873/876 devices; always maintain these bits clear.
3: These registers can be addressed from any bank.
4: PORTD, PORTE, TRISD, and TRISE are not physically implemented on PIC16F873/876 devices; read as ‘0’.
5: PIR2<6> and PIE2<6> are reserved on these devices; always maintain these bits clear.

Value on:

POR,

BOR

xxxx xxxx 47

xxxx xxxx 31

xxxx xxxx 41
xxxx xxxx 41

1111 1111 19

1111 1111 31

---- ---- 41

Details

on

page:

 2001 Microchip Technology Inc. DS30292C-page 17

PIC16F87X

2.2.2.1 STATUS Register

The STATUS register contains the arithmetic status of
the ALU, the RESET statu s and the b ank sele ct bit s for
data memory.

The STATUS register can be the destination for any
instruction, as with any other register. If the STATUS
register is the destination for an instruction that affects
the Z, DC or C bits, then the write to these three bits is
disabled. These bit s are set or cleared ac cording to the
device logic. Furthermore, the TO
writable, therefore, the result of an instruction with the
STATUS register as dest ination may be di fferent than
intended.

and PD bits are not

For example, CLRF STATUS will clear the upper three
bits and set t he Z bit. T his leaves the STATUS register
as 000u u1uu (where u = unchanged).

It is recommended, therefore, that only BCF, BSF,
SWAPF and MOVWF instructions are used to alter the
STATUS register, because these instructions do not
affect the Z, C or DC bits from the ST ATUS register. For
other instructions not affecting any status bits, see the
“Instruction Set Summary."

Note: The C and DC bits operate as a borrow

and digit borrow bit, respectively, in sub­traction. See the SUBLW and SUBWF
instructions for examples.

REGISTER 2-1: STATUS REGISTER (ADDRESS 03h, 83h, 103h, 183h)

R/W-0 R/W-0 R/W-0 R-1 R-1 R/W-x R/W-x R/W-x

IRP RP1 RP0 TO

bit 7 bit 0

bit 7 IRP: Register Bank Select bit (used for indirect addressing)

1 = Bank 2, 3 (100h - 1FFh)
0 = Bank 0, 1 (00h - FFh)

bit 6-5 RP1:RP0: Register Bank Select bits (used for direct addressing)

11 = Bank 3 (180h - 1FFh)
10 = Bank 2 (100h - 17Fh)
01 = Bank 1 (80h - FFh)
00 = Bank 0 (00h - 7Fh)

Each bank is 128 bytes

bit 4 TO

bit 3 PD

bit 2 Z: Zero bit

bit 1 DC: Digit carry/borrow

bit 0 C: Carry/borrow

: Time-out bit

1 = After power-up, CLRWDT instruction, or SLEEP instruction
0 = A WDT time-out occurred

: Power-down bit

1 = After power-up or by the CLRWDT instruction
0 = By execution of the SLEEP instruction

1 = The result of an arithmetic or logic operation is zero
0 = The result of an arithmetic or logic operation is not zero

bit (ADDWF, ADDLW,SUBLW,SUBWF instructions)

(for borrow, the polarity is reversed)

1 = A carry-out from the 4th low order bit of the result occurred
0 = No carry-out from the 4th low order bit of the result

bit (ADDWF, ADDLW,SUBLW,SUBWF instructions)

1 = A carry-out from the Most Significant bit of the result occurred
0 = No carry-out from the Most Significant bit of the result occurred

Note: For borrow

complement of the second operand. For rotate (RRF, RLF) instructions, this bit is
loaded with either the high, or low order bit of the source register.

, the polarity is reversed. A subtraction is executed by adding the two’s

PD ZDCC

Legend:
R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’

- n = Value at POR ’1’ = Bit is set ’0’ = Bit is cleared x = Bit is unknown

DS30292C-page 18  2001 Microchip Technology Inc.

PIC16F87X

2.2.2.2 OPTION_REG Register

The OPTION_R EG Regis ter i s a readabl e an d writ abl e
register , which cont ains various contr ol bits to conf igure
the TMR0 prescaler/WDT postscaler (single assign­able register k nown als o as th e presca ler), t he Externa l
INT Interrupt, TMR0 and the w eak pull-up s on POR TB.

REGISTER 2-2: OPTION_REG REGISTER (ADDRESS 81h, 181h)

R/W-1 R/W-1 R/W-1 R/W-1 R/W-1 R/W-1 R/W-1 R/W-1
RBPU INTEDG T0CS T0SE PSA PS2 PS1 PS0

bit 7 bit 0

Note: To achieve a 1:1 prescaler assignment for

the TMR0 register, assign the prescaler to
the Watchdog Timer.

bit 7 RBPU

bit 6 INTEDG: Interrupt Edge Select bit

bit 5 T0CS: TMR0 Clock Source Select bit

bit 4 T0SE: TMR0 Source Edge Select bit

bit 3 PSA: Prescaler Assignment bit

bit 2-0 PS2:PS0: Prescaler Rate Select bits

: PORTB Pull-up Enable bit

1 = PORTB pull-ups are disabled
0 = PORTB pull-ups are enabled by individual port latch values

1 = Interrupt on rising edge of RB0/INT pin
0 = Interrupt on falling edge of RB0/INT pin

1 = Transition on RA 4/T0CKI pin
0 = Internal instruction cycle clock (CLKOUT)

1 = Increment on high-to-low transition on RA4/T0CKI pin
0 = Increment on low-to-high transition on RA4/T0CKI pin

1 = Prescaler is assigned to the WDT
0 = Prescaler is assigned to the Timer0 module

Bit Value TMR0 Rate WDT Rate

000
001
010
011
100
101
110
111

1 : 2
1 : 4
1 : 8
1 : 16
1 : 32
1 : 64
1 : 128
1 : 256

1 : 1
1 : 2
1 : 4
1 : 8
1 : 16
1 : 32
1 : 64
1 : 128

Legend:
R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’

- n = Value at POR ’1’ = Bit is set ’0’ = Bit is cleared x = Bit is unknown

Note: When using low volt age ICSP p rogramming (LVP) and the pull-ups on PORTB are enabled , bit 3

in the TRISB register m ust be cleared to disa ble th e pull -up on R B3 and ensu re the p roper op er­ation of th e device

 2001 Microchip Technology Inc. DS30292C-page 19

PIC16F87X

2.2.2.3 INTCON Register

The INTCON Register is a readabl e and writ able regis­ter, which contains various enable and flag bits for the
TMR0 register overflow, RB Port change and External
RB0/INT pin interrupts.

Note: Interrupt flag bits are set when an interru pt

condition occurs, re gardless of the state of
its corresponding enable bit or the global
enable bit, GIE (INTCON<7>). User soft­ware should ensure the appropriate inter­rupt flag bits are clear prior to enabling an
interrupt.

REGISTER 2-3: INTCON REGISTER (ADDRESS 0Bh, 8Bh, 10Bh, 18Bh)

R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-x

GIE PEIE T0IE INTE RBIE T0IF INTF RBIF

bit 7 bit 0

bit 7 GIE: Global Interrupt Enable bit

1 = Enables all unmasked interrupts
0 = Disables all interrupts

bit 6 PEIE: Peripheral Interrupt Enable bit

1 = Enables all unmasked peripheral interrupts
0 = Disables all peripheral interrupts

bit 5 T0IE: TMR0 Overflow Interrupt Enable bit

1 = Enables the TMR0 interrupt
0 = Disables the TMR0 interrupt

bit 4 INTE: RB0/INT External Interrupt Enable bit

1 = Enables the RB0/INT external interrupt
0 = Disables the RB0/INT external interrupt

bit 3 RBIE: RB Port Change Interrupt Enable bit

1 = Enables the RB port change interrupt
0 = Disables the RB port change interrupt

bit 2 T0IF: TMR0 Overflow Interrupt Flag bit

1 = TMR0 register has ov erflowed (must be cleared in software)
0 = TMR0 register did not overflow

bit 1 INTF: RB0/INT External Interrupt Flag bit

1 = The RB0/INT external interrupt occurred (must be cleared in softwar e)
0 = The RB0/INT external interrupt did not occur

bit 0 RBIF: RB Port Change Interrupt Flag bit

1 = At least one of the RB 7:RB4 pins changed state ; a m is m atc h c ond iti on will continue to set

the bit. Reading PORTB will end the mismatch condition and allow the bit to be cleared
(must be cleared in software).

0 = None of the RB7:RB4 pins have changed state

Legend:
R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’

- n = Value at POR ’1’ = Bit is set ’0’ = Bit is cleared x = Bit is unknown

DS30292C-page 20  2001 Microchip Technology Inc.

2.2.2.4 PIE1 Register

The PIE1 register cont ains the ind ividual enab le bits for
the periph eral interrupts.

Note: Bit PEIE (INTCON<6>) must be set to

enable any peripheral interrupt.

REGISTER 2-4: PIE1 REGISTER (ADDRESS 8Ch)

R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0

(1)

PSPIE

bit 7 bit 0

bit 7 PSPIE

bit 6 ADIE: A/D Converter Interrupt Enable bit

bit 5 RCIE: USART Receive Interrupt Enable bit

bit 4 TXIE: USART Transmit Interrupt Enable bit

bit 3 SSPIE: Synchronous Serial Port Interrupt Enable bit

bit 2 CCP1IE: CCP1 Interrupt Enable bit

bit 1 TMR2IE: TMR2 to PR2 Match Interrupt Enable bit

bit 0 TMR1IE: TMR1 Overflow Interrupt Enable bit

(1)

1 = Enables the PSP read/write interrupt
0 = Disables the PSP read/write interrupt

1 = Enables the A/D converter interrupt
0 = Disables the A/D converter interrupt

1 = Enables the USART receive interrupt
0 = Disables the USART receiv e interrupt

1 = Enables the USART transmit interrupt
0 = Disables the USART transmit interrupt

1 = Enables the SSP interrupt
0 = Disables the SSP interrupt

1 = Enables the CCP1 interrupt
0 = Disables the CCP1 interrupt

1 = Enables the TMR2 to PR2 match interrupt
0 = Disables the TMR2 to PR2 match interrupt

1 = Enables the TMR1 overflow interrupt
0 = Disables the TMR1 overflow interrupt

ADIE RCIE TXIE SSPIE CCP1IE TMR2IE TMR1IE

: Parallel Slave Port Read/Write Interrupt Enable bit

PIC16F87X

Note 1: PSPIE is reserved on PIC16F873/876 devices; always maintain this bit clear.

Legend:
R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’

- n = Value at POR ’1’ = Bit is set ’0’ = Bit is cleared x = Bit is unknown

 2001 Microchip Technology Inc. DS30292C-page 21

PIC16F87X

2.2.2.5 PIR1 Register

The PIR1 register contains the individual flag bits for
the periph eral interrupts.

REGISTER 2-5: PIR1 REGISTER (ADDRESS 0Ch)

R/W-0 R/W-0 R-0 R-0 R/W-0 R/W-0 R/W-0 R/W-0

(1)

PSPIF

bit 7 bit 0

bit 7 PSPIF

bit 6 ADIF: A/D Converte r Interrupt Flag bit

bit 5 RCIF: USART Receive Interrupt Flag bit

bit 4 TXIF: USART Transmit Interrupt Flag bit

bit 3 SSPIF: Synchronous Serial Port (SSP) Interrupt Flag

bit 2 CCP1IF: CCP1 Interrupt Flag bit

bit 1 TMR2IF: TMR2 to PR2 Match Interrupt Flag bit

bit 0 TMR1IF: TMR1 Overflow Interrupt Flag bit

(1)

1 = A read or a write operation has taken place (must be cleared in software)
0 = No read or write has occurred

1 = An A/D conversion completed
0 = The A/D conversion is not complete

1 = The USART receive buffer is full
0 = The USART receive buffer is empty

1 = The USART transmit buffer is empty
0 = The USART transmit buffer is full

1 = The SSP interrupt condition has occurred, and must be cleared in software b efore returning

from the Interrupt Service Routine. The conditions that will set this bit are:

• SPI

• I

2

• I

0 = No SSP interrupt condition has occurred.

Capture mode:

1 = A TMR1 register capture occurred (must be cleared in software)
0 = No TMR1 register capture occurred

Compare mode:

1 = A TMR1 register compar e match occurred (must be cleared in software)
0 = No TMR1 register compare match occurred

PWM mode:
Unused in this mode

1 = TMR2 to PR2 match occurred (must be cleared in software)
0 = No TMR2 to PR2 match occurred

1 = TMR1 register overflowed (must be cleared in software)
0 = TMR1 register did not overflow

Note 1: PSPIF is reserved on PIC16F873/876 devices; always maintain this bit clear.

ADIF RCIF TXIF SSPIF CCP1IF TMR2IF TMR1IF

: Parallel Slave Port Read/Write Interrupt Flag bit

- A transmission/reception has taken place.

2

C Slave

- A transmission/reception has taken place.

C Master

- A transmission/reception has taken place.

- The initiated START condition was completed by the SSP module.

- The initiated STOP condition was completed by the SSP module.

- The initiated Restart condition was completed by the SSP module.

- The initiated Acknowledge condition was completed by the SSP module.

- A START con dition occurre d while the SSP module was idle (Multi-Master system).

- A STOP condition o ccurre d w h ile th e S SP m odu le w as i dle (M ulti-Master system).

Note: Interrupt flag bits are set when an interrupt

condition occurs, regardless of the state of
its corresponding enable bit or the global
enable bit, GIE (INTCON<7>). User soft­ware should en sure the approp riate interrup t
bits are cle ar pri or to en ab li ng an i nte rru pt.

Legend:
R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’

- n = Value at POR ’1’ = Bit is set ’0’ = Bit is cleared x = Bit is unknown

DS30292C-page 22  2001 Microchip Technology Inc.

2.2.2.6 PIE2 Register

The PIE2 register cont ains the ind ividual enab le bits for
the CCP2 peripheral interrupt, the SSP bus collision
interrupt, and the EEPROM write operation interrupt.

REGISTER 2-6: PIE2 REGISTER (ADDRESS 8Dh)

U-0 R/W-0 U-0 R/W-0 R/W-0 U-0 U-0 R/W-0

— Reserved — EEIE BCLIE — — CCP2IE

bit 7 bit 0

bit 7 Unimplemented: Read as '0'
bit 6 Reserved: Always maintain this bit clear
bit 5 Unimplemented: Read as '0'
bit 4 EEIE: EEPROM Write Operation Interrupt Enable

1 = Enable EE Write Interrupt
0 = Disable EE Write Interrupt

bit 3 BCLIE: Bus Collision Interrupt Enable

1 = Enable Bus Collision Interrupt
0 = Disable Bus Collision Interrupt

bit 2-1 Unimplemented: Read as '0'
bit 0 CCP2IE: CCP2 Interrupt Enable bit

1 = Enables the CCP2 interrupt
0 = Disables the CCP2 interrupt

PIC16F87X

Legend:
R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’

- n = Value at POR ’1’ = Bit is set ’0’ = Bit is cleared x = Bit is unknown

 2001 Microchip Technology Inc. DS30292C-page 23

PIC16F87X

2.2.2.7 PIR2 Register

The PIR2 register contains the flag bits for the CCP2
interrupt, the SSP bus collision interrupt and the
EEPROM write operation interrupt.

.

Note: Interrupt flag bits are set when an interru pt

condition occurs, re gardless of the state of
its corresponding enable bit or the global
enable bit, GIE (INTCON<7>). User soft­ware should ensure the appropriate inter­rupt flag bits are clear prior to enabling an
interrupt.

REGISTER 2-7: PIR2 REGISTER (ADDRESS 0Dh)

U-0 R/W-0 U-0 R/W-0 R/W-0 U-0 U-0 R/W-0

— Reserved — EEIF BCLIF — — CCP2IF

bit 7 bit 0

bit 7 Unimplemented: Read as '0'
bit 6 Reserved: Always maintain this bit clear
bit 5 Unimplemented: Read as '0'
bit 4 EEIF: EEPROM Write Operation Interrupt Flag bit

1 = The write operation completed (must be cleared in software)
0 = The write operation is not complete or has not been started

bit 3 BCLIF: Bus Collision Interrupt Flag bit

1 = A bus collision has occurred in the SSP, when configured for I2C Master mode
0 = No bus collision has occurred

bit 2-1 Unimplemented: Read as '0'
bit 0 CCP2IF: CCP2 Interrupt Flag bit

Capture mode:

1 = A TMR1 regist er capture occurred (must be cleared in software)
0 = No TMR1 regi ster capture occurred

Compare mode:

1 = A TMR1 register compare match occurred (must be cleared in software)
0 = No TMR1 register compare match occurred

PWM mode:
Unused

Legend:
R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’

- n = Value at POR ’1’ = Bit is set ’0’ = Bit is cleared x = Bit is unknown

DS30292C-page 24  2001 Microchip Technology Inc.

PIC16F87X

2.2.2.8 PCON Register

The Power Control (PCON) Register contains flag bits
to allow differentiation between a Power-on Reset
(POR), a Brown-out Reset (BOR), a Watchdog Reset
(WDT), and an external MCLR

Reset.

Note: BOR is unknown on P OR. It mus t be set by

the user and checked on subsequent
RESETS to see if BOR is clear, indicating
a brown-out has occurre d. The BOR st atus
bit is a “don’t care” and is n ot pre dictable if
the brown-out circuit is disabled (by clear­ing the BODEN bit in the configuration
word).

REGISTER 2-8: PCON REGISTER (ADDRESS 8Eh)

U-0 U-0 U-0 U-0 U-0 U-0 R/W-0 R/W-1

— — — — — —PORBOR

bit 7 bit 0

bit 7-2 Unimplemented: Read as '0'
bit 1 POR

bit 0 BOR

: Power-on Reset Status bit

1 = No Power-on Reset occurred
0 = A Power-on Reset occurred (must be set in software after a Power-on Reset occurs)

: Brown-out Reset Status bit

1 = No Brown-out Reset occurred
0 = A Brown-out Reset occurred (must be set in software after a Brown-out Reset occurs)

Legend:
R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’

- n = Value at POR ’1’ = Bit is set ’ 0’ = Bit is cleared x = Bit is unknown

 2001 Microchip Technology Inc. DS30292C-page 25

PIC16F87X

2.3 PCL and PCLATH

The program counter (PC) is 13-bits wid e. The low byte
comes from the PCL register, which is a readable and
writable register. The upper bits (PC<12:8>) are not
readable, but are indirectly writable through the
PCLA TH reg is ter. On any RESET, the upper bits of the
PC will be cleared. Fig ure2-5 shows the two situations
for the loading of the PC. The up per ex ample in th e fig­ure shows how the PC is loaded on a write to PCL
(PCLATH<4:0> → PCH). The lower exampl e i n th e fi g­ure shows how the PC is loaded during a CALL or GOTO
instruction (PCLATH<4:3> → PCH).

FIGURE 2-5: LOADING OF PC IN

DIFFERENT SITUATIONS

PCH PCL

12 8 7 0

PC

PCLATH<4:0>

5

PCLATH

PCH PCL

12 11 10 0

PC

2

87

PCLATH<4:3>

PCLATH

11

2.3.1 COMPUTED GOTO

A computed GOTO is accomplish ed by adding an offset
to the progr am counter (ADDWF PCL). When doing a
table read using a computed GOTO method, care
should be exercise d i f the t able loca tio n cros ses a PCL
memory boundary (each 256 byte block). Refer to the
application note, “Implementing a Table Read"
(AN556).

2.3.2 STACK

The PIC16F87X family has an 8-level deep x 13-bit wide
hardware stack. The stack sp ace is not part of either pro­gram or data space and the stack pointer is not readable
or writable. The PC is PUSHed onto the stack when a
CALL instruction is executed, or an interrupt causes a
branch. The stack is POPed in the event of a
RETURN,RETLW or a RETFIE instruction execution.
PCLA TH is not affected by a PUSH or POP operation.

The stack opera tes as a circular buf fer . This means that
after the st ack h as be en PUSHed ei ght ti mes, th e nin th
push overwrites the v alue tha t was stored fro m the first
push. The tenth pus h ov erwri t es the se co nd p us h (an d
so on).

8

Instruction with
PCL as
Destination

ALU

GOTO,CALL

Opcode <10:0>

Note 1: There are no status bits to indicate stack

overflow or stack underflow conditions.

2: There are no instructions/mnemonics

called PUSH or POP. These are actions
that occur from the execution of the
CALL, RETURN, RETLW and RETFIE
instructions, or the vectoring to an inter­rupt address.

2.4 Program Memory Paging

All PIC16F87X devices are capable of addressing a
continuous 8K word block of program memory. The
CALL and GOTO instructions provide only 11 bits of
address to allow branching within any 2K program
memory page. When doing a CALL or GOTO instruction,
the upper 2 bits of the address are provided by
PCLATH<4:3>. When doing a CALL or GOTO instruc­tion, the user must ensu re tha t the p age select bits are
programmed so that the desired program memory
page is addressed. If a return from a CALL instruction
(or interrupt) is execute d, the entire 13-bit PC is popped
off the stack. Therefore, manipulation of the
PCLA TH<4:3> bits is not required for the return instruc­tions (which POPs the address from the stack).

Note: The contents of the PCLATH register are

unchanged after a RETURN or RETFIE
instruction is executed. The user must
rewrite the contents of the PCLATH regis­ter for any subsequent subroutine calls or
GOTO instructions.

Example 2-1 shows the calling of a subroutine in
page 1 of the program memory . Thi s example as sumes
that PCLATH is saved and restored by the Interrupt
Service Routine

EXAMPLE 2-1: CALL OF A SUBROUTINE

SUB1_P1

(if interrupts are used).

IN PAGE 1 FROM PAGE 0

ORG 0x500
BCF PCLATH,4
BSF PCLATH,3 ;Select page 1

;(800h-FFFh)

CALL SUB1_P1 ;Call subroutine in

: ;page 1 (800h-FFFh)
:
ORG 0x900 ;page 1 (800h-FFFh)

: ;called subroutine

;page 1 (800h-FFFh)
:
RETURN ;return to

;Call subroutine

;in page 0

;(000h-7FFh)

DS30292C-page 26  2001 Microchip Technology Inc.

PIC16F87X

2.5 Indirect Addressing, INDF and FSR Registers

The INDF register is not a physi cal register. Addressin g
the INDF register will cause indirect addressing.

Indirect addressing is possible by using the INDF reg­ister. Any instruc tion using the INDF register actual ly
accesses the register pointed to by the File Sele ct Reg­ister, FSR. Reading the INDF register itself, indirectly
(FSR = ’0’) will read 00h. Writing to the INDF register
indirectly result s in a no op era tion ( alth oug h status bits
may be affected ). An ef fective 9- bit add ress is obt ained
by concatenating the 8 -bit FSR regi ster and the IRP b it
(STATUS<7>), as shown in Figure 2-6.

FIGURE 2-6: DIRECT/INDI RECT ADDRE SSING

RP1:RP 0 6

Bank Select Location Select

From Opcode

0

00 01 10 11

00h

80h

100h

A simple program to clear RAM locations 20h-2Fh
using indirect addressing is shown in Example 2-2.

EXAMPLE 2-2: INDIRECT ADDRESSING

MOVLW 0x20 ;initialize pointer

NEXT CLRF INDF ;clear INDF register

CONTINUE

MOVWF FSR ;to RAM

INCF FSR,F ;inc pointer
BTFSS FSR,4 ;all done?
GOTO NEXT ;no clear next

: ;yes continue

Indirect AddressingDirect Addressing

IRP F SR regist er

Bank Select

180h

7

0

Location Select

Data

(1)

Memory

7Fh

Bank 0 Bank 1 Bank 2 Bank 3

Note 1: For register file map detail, see Figure 2-3.

FFh

17Fh

1FFh

 2001 Microchip Technology Inc. DS30292C-page 27

PIC16F87X

NOTES:

DS30292C-page 28  2001 Microchip Technology Inc.

PIC16F87X

3.0 I/O PORTS

Some pins for th ese I/O ports are multiplexed with an
alternate function for the peripheral features on the
device. In general, when a peripheral is enabled, that
pin may not be used as a general purpose I/O pin.

Additional inform atio n o n I/O ports may b e f oun d i n th e
PICmicro™ Mid-Range Reference Manual, (DS33023).

3.1 PORTA and the TRISA Register

PORTA is a 6-bit wide, bi-directional port. The corre­sponding data direction register is TRISA. Setting a
TRISA bit (= 1) wi ll make the correspondin g PORTA pin
an input (i.e., put the corresponding output driver in a
Hi-Impedance mode). Clearing a TRISA bit (= 0) will
make the correspondin g POR TA pin an output (i.e., put
the contents of the output latch on the selected pin).

Reading the PORTA register reads the status of the
pins, whereas writing to i t will wri te to th e po rt latch. All
write operations are read-modify-write operations.
Therefore, a write to a port implies that the port pins are
read, the value is modified and then written to the port
data latch.

Pin RA4 is multiplexed with the Timer0 module clock
input to become the RA4/T0CKI pin. The RA4/T0CKI
pin is a Schmitt Trigger input and an open d rain o utput .
All other PORTA pins have TTL input levels and full
CMOS output drivers.

Other PORTA pins are multiplexed with analog inputs
and analog V
selected by clearing/setting the control bits in the
ADCON1 register (A/D Control Register1).

Note: On a Power-on Reset, these pins are con-

The TRISA register controls the direction of the RA
pins, even when they are be ing us ed as ana lo g inputs.
The user must ensure the bits in the TRISA regi ster are
maintained set when using them as analog inputs.

EXAMPLE 3-1: INITIALIZING PORTA

BCF STATUS, RP0 ;
BCF STATUS, RP1 ; Bank0
CLRF PORTA ; Initialize PORTA by

BSF STATUS, RP0 ; Select Bank 1
MOVLW 0x06 ; Configure all pins
MOVWF ADCON1 ; as digital inputs
MOVLW 0xCF ; Value used to

MOVWF TRISA ; Set RA<3:0> as inputs

REF input. The operation of each pin is

figured as analog inputs and read as '0'.

; clearing output
; data latches

; initialize data
; direction

; RA<5:4> as outputs
; TRISA<7:6>are always
; read as ’0’.

FIGURE 3-1: BLOCK DIAGRAM OF

RA3:RA0 AND RA5 PINS

Data
Bus

WR
Port

WR
TRIS

RD
TRIS

RD Port

To A/D Converter

Note 1: I/O pins have protection diodes to VDD and VSS.

Data Latch

CK

TRIS Latch

CK

QD

VDD

Q

QD

Q

QD

Analog
Input
Mode

EN

P

I/O pin

N

V

SS

TTL
Input
Buffer

FIGURE 3-2: BLOCK DIAGRAM OF

RA4/T0CKI PIN

Data
Bus

WR
Port

WR
TRIS

RD
TRIS

RD Port

TMR0 Clock Input

Note 1: I/O pin has protection diodes to VSS only.

Data Latch

QD

Q

CK

TRIS Latch

QD

Q

CK

N

SS

V

Schmitt
Trigger
Input
Buffer

QD

EN

EN

I/O pin

(1)

(1)

 2001 Microchip Technology Inc. DS30292C-page 29

PIC16F87X

TABLE 3-1: PORTA FUNCTIONS

Name Bit# Buffer Function

RA0/AN0 bit0 TTL Input/output or analog input.
RA1/AN1 bit1 TTL Input/output or analog input.
RA2/AN2 bit2 TTL Input/output or analog input.
RA3/AN3/V
RA4/T0CKI bit4 ST Input/output or external clock input for Timer0. Output is open drain type.
RA5/SS
Legend: TTL = TTL input, ST = Schmitt Trigger input

TABLE 3-2: SUMMARY OF REGISTERS ASSOCIATED WITH PORTA

REF bit3 TTL Input/output or analog input or VREF.

/AN4 bit5 TTL Input/output or slave select input for synchronous serial port or analog input.

Value on:

Address Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

05h PORTA
85h TRISA — — PORT A Data Direction Register
9Fh ADCON1 ADFM — — — PCFG3 PCFG2 PCFG1 PCFG0

Legend: x = unknown, u = unchanged, - = unimplemented locations read as '0'.

Shaded cells are not used by PORTA.

Note: When using the SSP module in SPI Slave mode and SS enabled, the A/D converter must be set to one of

the following modes, where PCFG3:PCFG0 = 0100,0101, 011x, 1101, 1110, 1111.

— — RA5 RA4 RA3 RA2 RA1 RA0

POR,

BOR

--0x 0000 --0u 0000

--11 1111 --11 1111

--0- 0000 --0- 0000

Value on al l

other

RESETS

DS30292C-page 30  2001 Microchip Technology Inc.

PIC16F87X

3.2 PORTB and the TRISB Register

PORTB is an 8-bit wide, bi-directional port. The corre­sponding data direction register is TRISB. Setting a
TRISB bit (= 1) will mak e the corresponding PORTB pin
an input (i.e., put the corresponding output driver in a
Hi-Impedance mode). Clearing a TRISB bit (= 0) will
make the corresponding POR TB pin an output (i.e. , put
the contents of the output latch on the selected pin).

Three pins of PORTB are multiplexed with the Low
Voltage Programming function: RB3/PGM, RB6/PGC
and RB7/PGD. The alternate functions of these pins
are described in the S p ec ial Feat ure s Sect ion .

Each of the PORTB pi ns has a w eak i nternal pul l-up. A
single control bit can turn on all the pull-ups. This is per­formed by clearing bit RBPU
weak pull-up is automatically turned off when the port
pin is configured as an output. The pull-ups are dis­abled on a Power-on Reset.

FIGURE 3-3: BLOCK DIAGRAM OF

(2)

RBPU

Data Bus

WR Port

WR TRIS

RD TRIS

RD Port

RB0/INT
RB3/PGM

Note 1: I/O pins have diode protection to V

2: To enable weak pull-ups, set the appropriate TRIS

bit(s) and clear the RBPU

Data Latch

CK

TRIS Latch

CK

(OPTION_REG<7>). The

RB3:RB0 PINS

QD

QD

Schmitt Trigger
Buffer

TTL
Input
Buffer

QD

EN

DD and VSS.

bit (OPTION_REG<7>).

V

DD

Weak

P

Pull-up

RD Port

I/O
pin

(1)

This interrupt can wake the device from SLEEP. The
user, in the Interrupt Service Routine, can clear the
interrupt in the following manner:

a) Any read or write of PORTB. This will end the

mismatch condition.

b) Clear flag bit RBIF.
A mismatch c ond it i on wi ll cont i n ue to s et f lag bi t RB IF.

Reading PORTB will end the mismatch condition and
allow flag bit RBIF to be cleared.

The interrupt-on-change feature is recommended for
wake-up on key depression operation and operations
where PORTB is only used for the interrupt-on-change
feature. Polling of PORTB is not recommended while
using the interrupt-on-change feature.

This interrupt-on-mismatch feature, together with soft­ware configureable pull-ups on these four pins, allow
easy interface to a keypad and make it possible for
wake-up on key depression. Refer to the Embedded
Control Handbook, “Implementing Wake-up on Key
Strokes” (AN552).

RB0/INT is an ext ernal i nterrupt input pin a nd is confi g­ured using the INTEDG bit (OPTION_REG<6>).

RB0/INT is discussed in detail in Section 12.10.1.

FIGURE 3-4: BLOCK DIAGRAM OF

RB7:RB4 PINS

DD

EN

TTL
Input
Buffer

V

P

Weak
Pull-up

I/O
pin

Buffer

Q1

(1)

ST

(2)

RBPU

Data Bus

WR Port

WR TRIS

RD TRIS

RD Port
Set RBIF

Data Latch

QD

CK

TRIS Latch

QD

CK

Latch

QD

Four of the PORTB pins, RB7:RB4, have an interrupt­on-change feature. Only pins configured as inputs can
cause this interrupt to occur (i.e., any RB7:RB4 pin
configured as an output is excluded from the interrupt­on-change comparison). The input pins (of RB7:RB4)
are compared with the old value latched on the last
read of PORTB. The “mismatch” outputs of RB7:RB4
are OR’ed together to generate the RB Port Change

From other
RB7:RB4 pins

RB7:RB6

In Serial Programming Mode

Note 1: I/O pins have diode protec tion to V

2: To enable weak pull-u ps, set the appropriate TRIS

bit(s) and clear the RBPU

QD

RD Port

EN

DD and VSS.

bit (OPTION_REG<7>).

Q3

Interrupt with flag bit RBIF (INTCON<0>).

 2001 Microchip Technology Inc. DS30292C-page 31

PIC16F87X

TABLE 3-3: PORTB FUNCTIONS

Name Bit# Buffer Function

RB0/INT b it0 TTL/ST

RB1 bit1 TTL Input/output pin. Internal software programmable weak pull-up.
RB2 bit2 TTL Input/output pin. Internal software programmable weak pull-up.

(3)

RB3/PGM

RB4 bit4 TTL Input/output pin (wi th interru pt-on-change) . Inter nal sof tware pro grammabl e

RB5 bit5 TTL Input/output pin (wi th interru pt-on-change) . Inter nal sof tware pro grammabl e

RB6/PGC bit6 TTL/ST

RB7/PGD bit7 TTL/ST

Legend: TTL = TTL input, ST = Schmitt Trigger input

Note 1: This buffer is a Schmitt Trigger input when configured as the external interrupt.

2: This buffer is a Schmitt Trigger input when used in Serial Programming mode.
3: Low Voltage ICSP Programming (LVP) is enabled by default, which disables the RB3 I/O function. LVP

bit3 TTL Input/output pin or programming pin in LVP mode. Internal software

must be disabled to enable RB3 as an I/O pin and allow maximum compatibility to the other 28-pin and
40-pin mid-range devices.

(1)

Input/output pin or external interrupt input. Internal software
programmable weak pull-up.

programmable weak pull-up.

weak pull-up.

weak pull-up.

(2)

Input/output pin (with interrupt-on-change) or In-Circuit Debugger pin.
Internal software programmable weak pull-up. Serial programming clock.

(2)

Input/output pin (with interrupt-on-change) or In-Circuit Debugger pin.
Internal software programmable weak pull-up. Serial programming data.

TABLE 3-4: SUMMARY OF REGISTERS ASSOCIATED WITH PORTB

Address Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

06h, 106h PORTB RB7 RB6 RB5 RB4 RB3 RB2 RB1 RB0
86h, 186h T RISB PORTB Data Direction Register
81h, 181h OPTION_REG RBPU INTEDG T0CS T0SE PSA PS2 PS1 PS0
Legend: x = unknown, u = unchanged. Sh aded cells are not used by PORTB.

Value on:

POR,

BOR

xxxx xxxx uuuu uuuu

1111 1111 1111 1111

1111 1111 1111 1111

Value on

all other

RESETS

DS30292C-page 32  2001 Microchip Technology Inc.

PIC16F87X

3.3 PORTC and the TRISC Register

PORTC is an 8-bit wide, bi-directional port. The corre­sponding data direction register is TRISC. Setting a
TRISC bit (= 1) will make the corresponding PORTC
pin an input (i.e., put the corresponding output driver in
a Hi-Impedance mode). Clearing a TRISC bit (= 0) will
make the correspondi ng PORTC pin an output (i.e., p ut
the contents of the output latch on the selected pin).

PORTC is mul tiplexed with s everal peri pheral function s
(Table 3-5). PORTC pins have Schmitt Trigger input
buffers.

2

When the I
pins can be configured with normal I
SMBus levels by using the CKE bit (SSPSTAT<6>).

When enabling peripheral functions, care should be
taken in defining TRIS bit s fo r each POR TC pin. Some
peripherals override the TRIS bit to make a pin an out­put, while other peripherals override the TRIS bit to
make a pin an input. Since the TRIS bit override is in
effect while the peripheral is enabled, read-modify­write instructions (BSF, BCF, XORWF) with TRISC as
destination, should be avoided. The user should refer
to the corresponding peripheral section for the correct
TRIS bit settings.

FIGURE 3-5: PORTC BLOCK DIAGRAM

Port/Peripheral Select

C module is enabled, the PORTC<4:3>

2

C levels, or with

(PERIPHERAL OUTPUT
OVERRIDE) RC<2:0>,
RC<7:5>

(2)

FIGURE 3-6: PORTC BLOCK DIAGRAM

(PERIPHERAL OUTPUT
OVERRIDE) RC<4:3>

Port/Peripheral Select

Peripheral Data Out

Data Bus
WR

Port

WR
TRIS

RD
TRIS

Peripheral

(3)

OE

RD
Port

SSPl Input

Note 1: I/O pins have diode protection to VDD and VSS.

2: Port/Peripheral select signal selects between port data

and peripheral output.

3: Peripheral OE (output enable) is only activated if

peripheral select is active.

(2)

QD

Q

CK

Data Latch

QD
Q

CK

TRIS Latch

0

1

QD

Schmitt
Trigger

EN

CKE

SSPSTAT<6>

V
P

N

Vss

0

1

DD

I/O
pin

Schmitt
Trigger
with
SMBus
levels

(1)

Peripheral Data Out
Data Bus

WR
Port

WR
TRIS

RD

TRIS

Peripheral

(3)

OE

RD
Port

Peripheral Input

Note 1: I/O pins have diode protection to VDD and VSS.

CK

Data Latch

CK

TRIS Latch

2: Port/Peripheral select signal selects between port

data and peripheral output.

3: Peripheral OE (output enable) is only activated if

peripheral select is active.

0

QD

1

Q

QD
Q

QD

EN

Schmitt
Trigger

V

P

N

VSS

DD

I/O
pin

(1)

 2001 Microchip Technology Inc. DS30292C-page 33

PIC16F87X

TABLE 3-5: PORTC FUNCTIONS

Name Bit# Buffer Type Function

RC0/T1OSO/T1CKI bit0 ST Input/output port pin or Timer1 oscillator output/Timer1 clock input.
RC1/T1OSI/CCP2 bit1 ST Input/output port pin or Timer1 oscillator input or Capture2 input/

Compare2 output/PWM2 output.

RC2/CCP1 bit2 ST Input/output port pin or Capture1 input/Compare1 output/

PWM1 output.

RC3/SCK/SCL bit3 ST RC3 can also be the synchronous serial clock for both SPI

RC4/SDI/SDA bit4 ST RC4 can also be the SPI Data In (SPI mode) or data I/O (I
RC5/SDO bit5 ST Input/output port pin or Synchronous Serial Port data output.
RC6/TX/CK bit6 ST Input/output port pin or USART Asynchronous Transmit or

RC7/RX/DT bit7 ST Input/output port pin or USART Asynchronous Receive or

Legend: ST = Schmitt Trigger input

TABLE 3-6: SUMMARY OF REGISTERS ASSOCIATED WITH PORTC

2

C modes.

and I

Synchronous Clock.

Synchronous Data.

2

C mode).

Address Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

07h PORTC RC7 RC6 RC5 RC4 RC3 RC2 RC1 RC0
87h TRISC PORTC Data Direction Register
Legend: x = unknown, u = unchanged

Value on:

POR,
BOR

xxxx xxxx uuuu uuuu

1111 1111 1111 1111

Value on all

other

RESETS

DS30292C-page 34  2001 Microchip Technology Inc.

PIC16F87X

3.4 PORTD and TRISD Registers

PORTD and TRISD are not implemented on the
PIC16F873 or PIC16F876.

PORTD is an 8-bit port with Schmitt Trigger input buff­ers. Each pin is in dividually co nfigureable as a n input or
output.

PORTD can be configured as an 8-bit wide micropro­cessor port (parallel slave p ort) by setting c ontrol bit
PSPMODE (TRISE<4>). In this mode, the input buffers
are TTL.

FIGURE 3-7: PORTD BLOCK DIAGRAM

(IN I/O PORT MODE)

(1)

Data
Bus

WR
Port

WR
TRIS

RD

TRIS

RD Port

Note 1: I/O pins have protection diodes to VDD and VSS.

Data Latch

CK

TRIS Latch

QD

CK

QD

Schmitt
Trigger
Input
Buffer

QD

EN

EN

I/O pin

TABLE 3-7: PORTD FUNCTIONS

Name Bit# Buffer Type Function

RD0/PSP0 bit0 ST/TTL
RD1/PSP1 bit1 ST/TTL
RD2/PSP2 bit2 ST/TTL
RD3/PSP3 bit3 ST/TTL
RD4/PSP4 bit4 ST/TTL
RD5/PSP5 bit5 ST/TTL
RD6/PSP6 bit6 ST/TTL
RD7/PSP7 bit7 ST/TTL

(1)
(1)
(1)
(1)
(1)
(1)
(1)
(1)

Input/output port pin or parallel slave port bit0.
Input/output port pin or parallel slave port bit1.
Input/output port pin or parallel slave port bit2.
Input/output port pin or parallel slave port bit3.
Input/output port pin or parallel slave port bit4.
Input/output port pin or parallel slave port bit5.
Input/output port pin or parallel slave port bit6.
Input/output port pin or parallel slave port bit7.

Legend: ST = Schmitt Trigger input, TTL = TTL input

Note 1: Input buffers are Schmitt Triggers when in I/O mode and TTL buffers when in Parallel Slave Port mode.

TABLE 3-8: SUMMARY OF REGISTERS ASSOCIATED WITH PORTD

Value on:

Address Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

POR,
BOR

08h PORTD RD7 RD6 RD5 RD4 RD3 RD2 RD1 RD0
88h TRISD PORTD Data Direction Register
89h TRISE IBF OBF IBOV PSPMODE — PORTE Data Direct ion Bits

xxxx xxxx uuuu uuuu

1111 1111 1111 1111

0000 -111 0000 -111

Legend: x = unknown, u = unchanged, - = unimplemented, read as '0'. Shaded cells are not used by PORTD.

Value on

all other

RESETS

 2001 Microchip Technology Inc. DS30292C-page 35

PIC16F87X

3.5 PORTE and TRISE Register

PORTE and TRISE are not implemented on the
PIC16F873 or PIC16F876.

PORTE has three pins (RE0/RD
and RE2/CS

/AN7) which are ind iv idu all y co nfi gure abl e
as inputs or outputs. These pins have Schmitt Trigger
input buffers.

The PORTE pins become the I/O control inputs for the
microprocessor port when bit PSPMODE (TRISE<4>) is
set. In this mode, the user must make certain that the
TRISE<2:0> bits are set, and that the pins are configured
as digital input s. Also ensure that ADCON1 is co nfigured
for digital I/O. In this mo de, th e in put bu f f ers are TTL.

Register 3-1 shows the TRISE register, which also con­trols the parallel slave port operation.

PORTE pins are multiplexed with analog inputs. When
selected for analog input, these pins will read as ’0’s.

TRISE controls the direction of the RE pins, even when
they are being used as analog inputs. The user must
make sure to keep the pins configured as inputs when
using them as analog inputs.

Note: On a Power-on Reset, these pins are con-

figured as analog inputs, and read as ‘0’.

/AN5, RE1/WR/AN6,

FIGURE 3-8: PORTE BLOCK DIAGRAM

(IN I/O PORT MODE)

(1)

Data
Bus

WR
Port

WR
TRIS

RD
TRIS

RD Port

Note 1: I/O pins have protection diodes to VDD and VSS.

Data Latch

QD

CK

TRIS Latch

QD

CK

Schmitt
Trigger
Input
Buffer

QD

EN

EN

I/O pin

TABLE 3-9: PORTE FUNCTIONS

Name Bit# Buffer Ty pe Function

I/O port pin or read control input in Parallel Slave Port mode or analog input:
RD

RE0/RD

/AN5 bit0 ST/TTL

(1)

1 =Idle
0 = Read operation. Contents of PORTD register are output to PORTD

I/O pins (if chip selected)

I/O port pin or write control input in Paralle l Slave Port mode or anal og input:
WR

RE1/WR

/AN6 bit1 ST/TTL

(1)

1 =Idle
0 = Write operation. Value of PORTD I/O pins is latched into PORTD

register (if chip selected)

I/O port pin or ch ip sele ct co ntrol in put in Para llel Sl ave Port m ode or an alog in put:
CS

RE2/CS

/AN7 bit2 ST/TTL

(1)

1 = Device is not selected
0 = Device is selected

Legend: ST = Schmitt Trigger input, TTL = TTL input

Note 1: Input buffers are Schmitt Triggers when in I/O mode and TTL buffers when in Parallel Slave Port mode.

TABLE 3-10: SUMMARY OF REGISTERS ASSOCIATED WITH PORTE

Address Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

09h PORTE
89h TRISE IBF OBF IBOV PSPMODE — PORTE Data Direction Bits 0000 -111 0000 -111
9Fh ADCON1 ADFM — — — PCFG3 PCFG2 PCFG1 PCFG0 --0- 0000 --0- 0000

— — — — — RE2 RE1 RE0 ---- -xxx ---- -uuu

Val ue on:

POR, BOR

Legend: x = unknown, u = unchanged, - = unimplemented, read as ’0’. Shaded cells are not used by PORTE.

Value o n
all other
RESETS

DS30292C-page 36  2001 Microchip Technology Inc.

REGISTER 3-1: TRISE REGISTER (ADDRESS 89h)

R-0 R-0 R/W-0 R/W-0 U-0 R/W-1 R/W-1 R/W-1
IBF OBF IBOV PSPMODE

bit 7 bit 0

Parallel Slave Port Status/Control Bits:

bit 7 IBF: Input Buffer Full Status bit

1 = A word has been received and is waiting to be read by the CPU
0 = No word has been received

bit 6 OBF: Output Buffer Full Status bit

1 = The output buffer still holds a previously written word
0 = The output buffer has been read

bit 5 IBOV: Input Buffer Overflow Detect bit (in Microprocessor mode)

1 = A write occurred when a previously input word has not been read (must be cleared in

software)

0 = No overflow occurred

bit 4 PSPMODE: Parallel Slave Port Mode Select bit

1 = PORTD functions in Parallel Slave Port mode
0 = PORTD functions in general purpose I/O mode

bit 3 Unimplemented: Read as '0'

PORTE Data Direction Bits:

bit 2 Bit2: Direction Control bit for pin RE2/CS/AN7

1 = Input
0 = Output

bit 1 Bit1: Direction Control bit for pin RE1/WR

1 = Input
0 = Output

bit 0 Bit0: Direction Control bit for pin RE0/RD

1 = Input
0 = Output

/AN6

/AN5

PIC16F87X

— Bit2 Bit1 Bit0

Legend:
R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’

- n = Value at POR ’1’ = Bit is set ’0’ = Bit is cleared x = Bit is unknown

 2001 Microchip Technology Inc. DS30292C-page 37

PIC16F87X

3.6 Parallel Slave Port

The Parallel Slave Port (PSP) is not implemented on
the PIC16F873 or PIC16F876.

PORTD operates as an 8-bit wide Parallel Slav e Port or
microprocessor port, when control bit PSPMODE
(TRISE<4>) is set. I n Sl av e mo de, it is asynchronousl y
readable and writa ble by the ex ternal world throu gh RD
control input pin RE0/RD and WR control input pin
RE1/WR

The PSP can directly interfac e to an 8-bit micr oproce s­sor data bus. The external microprocessor can read or
write the PORTD latch as an 8-bit latch. Setting bit
PSPMODE enables port pin RE0/RD
input, RE1/WR to be the WR input and RE2/CS to be
the CS
responding data direction bits of the TRISE register
(TRISE<2:0>) must be configured as inputs (set). The
A/D port configuration bits PCFG3:PCFG0
(ADCON1<3:0>) must be set to configure pins
RE2:RE0 as digital I/O.

There are actually two 8-bit latches: one for data out­put, and one for data input. The user writes 8-bit data
to the PORTD data latch and reads data from the port
pin latch (note that they have the same address). In thi s
mode, the TRISD registe r is ignore d, since the externa l
device is controlling the direction of data flow.

A write to the PSP occurs when both the CS
lines are first detected low. When either the CS or WR
lines become high (l evel triggered) , the Input Buffe r Full
(IBF) status flag bit (TRISE<7>) is set on the Q4 clock
cycle, following the next Q2 cycle, to signal the write is
complete (Figure 3-10). The interrupt flag bit PSPIF
(PIR1<7>) is also set on the same Q4 clock cycle. IBF
can only be cle are d b y re adi ng the PO R TD i npu t l atc h.
The Input Buffer Overflow (IBOV) status flag bit
(TRISE<5>) is set if a second write to the PSP is
attempted w hen the pre vious byte has not bee n read
out of the buffer.

A read from the PSP occurs when both the CS
lines are first detected low. The Output Buffer Full
(OBF) status flag bit (TRISE<6>) is cleared immedi­ately (Figure 3-11), indicating that the PORTD latch is
waiting to be read by the ext ernal bus . When ei ther the
CS
rupt flag bit PSPIF is set on the Q4 clock cycle, follow­ing the next Q2 cycle, indicating that the read is
complete. OBF remains low until data is written to
PORTD by the user firmware.

.

to be the RD

(chip select) input. Fo r this function ality , th e cor-

and WR

and RD

or RD pin becomes high ( lev el trigg ere d), the inter-

When not in PSP mode, the IBF and OBF bits are held
clear. However, if flag bit IBOV was previously set, it
must be cleared in firmware.

An interrupt is generated and latched into flag bit
PSPIF when a read or write operation is completed.
PSPIF must be cleared by the user in fi rmware an d the
interrupt can be disabled by clearing the interrupt
enable bit PSPIE (PIE1<7>).

FIGURE 3-9: PORTD AND PORTE

BLOCK DIAGRAM
(PARALLEL SLAVE
PORT)

Data Bus

WR
Port

RD
Port

One bit of PORTD

Set Interrupt Flag
PSPIF(PIR1<7>)

Note 1: I/O pins have protection diodes to V

QD

CK

QD

EN

EN

Read

Chip Select

Write

TTL

TTL

TTL

TTL

DD and VSS.

RDx
pin

RD

CS

WR

DS30292C-page 38  2001 Microchip Technology Inc.

FIGURE 3-10: PARALLEL SLAVE PORT WRITE WAVEFORMS

Q1 Q2 Q3 Q4CSQ1 Q2 Q3 Q4 Q1 Q2 Q3 Q4

WR
RD

PORTD<7:0>

IBF

OBF

PSPIF

FIGURE 3-11: PARALLEL SLAVE PORT READ WAVEFORMS

PIC16F87X

Q1 Q2 Q3 Q4

CS

WR
RD

PORTD<7:0>

IBF

OBF

PSPIF

Q1 Q2 Q3 Q4 Q1 Q2 Q3 Q4

TABLE 3-11: REGISTERS ASSOCIATED WITH PARALLEL SLAVE PORT

Address Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

08h PORTD Port Data Latch when written: Port pins when read
09h PORTE — — — — — RE2 RE1 RE0 ---- -xxx ---- -uuu
89h TRISE IBF OBF IBOV PSPMODE — PORTE Data Direction Bits 0000 -111 0000 -111
0Ch PIR1 PSP IF
8Ch PIE1 PSPIE
9Fh ADCON 1 ADFM — — — PCFG3 PCFG2 PCFG1 PCFG0 --0- 0000 --0- 0000
Legend: x = unknown, u = unchanged, - = unimplemented, read as '0'. Shaded cells are not used by the Parallel Slave Port.

Note 1: Bits PSPIE and PSPIF are reserved on the PIC16F873/876; always maintain these bits clear.

(1)

ADIF RCIF TXIF SSPIF CCP1IF TMR2IF TMR1IF 0000 0000 0000 0000

(1)

ADIE RCIE TXIE SSPIE CCP1IE TMR2IE TMR1IE 0000 0000 0000 0000

Value o n:

POR, BOR

xxxx xxxx uuuu uuuu

Value on

all other

RESETS

 2001 Microchip Technology Inc. DS30292C-page 39

PIC16F87X

NOTES:

DS30292C-page 40  2001 Microchip Technology Inc.

PIC16F87X

4.0 DATA EEPROM AND FLASH PROGRAM MEMORY

The Data EEPROM and FLASH Program Memory are
readable and writab le during no rmal operati on over the
entire V
gle byte for Data EEPROM memory and a single word
for Program memory. A write operation causes an
erase-then-write operation to take place on the speci­fied byte or word. A bulk erase operation may not be
issued from user code (which includes removing code
protection).

Access to program memory all ows for che cksum calc u­lation. The values written to program memory do not
need to be valid instructions. Therefore, up to 14-bit
numbers can be stored in memory for use as calibra­tion parameters, serial numbers, packed 7-bit ASCII,
etc. Executing a program memory location containing
data that form an invalid instruction, results in the exe­cution of a NOP instruction.

The EEPROM Data memory is rated for high erase/
write cycles (specif ica tio n D 120 ). The FLAS H pro gra m
memory is rated much lower (specification D130),
because EEPROM data memory can be used to store
frequently updated values. An on-chip timer controls
the write time and it w ill v ary with v olt age and tempe ra­ture, as well as from chip to chip. Please refer to the
specifications for exact limits (specifications D122 and
D133).

A byte or word write automatically erases the location
and writes the new value (erase before write). Writing
to EEPROM data memory does not impact the opera­tion of the device. Writing to program memory will
cease the execution of instructions until the write is
complete. The program memory cannot be accessed
during the write. During the write operation, the oscilla­tor continues to run, the peripherals continue to func­tion and interrupt events will be detected and
essentially “queued” until the write is complete. When
the write completes, the next instruction in the pipeline
is executed and the branch to the interrupt vector will
take place, i f the i nte rrupt is enabled and oc cu rred dur­ing the write.

Read and write access to both memories take place
indirectly through a set of Special Function Registers
(SFR). The six SFRs used are:

• EEDATA

• EEDATH

• EEADR

• EEADRH

• EECON1

• EECON2

DD range. These opera tions take place on a si n-

The EEPROM data memory allows byte read and write
operations without interfering with the normal operation
of the microcontroller. When interfacing to EEPROM
data memory, the EEADR register holds the address to
be accessed. Depending on the operation, the EEDATA
register holds the data to be written, or the data read, at
the address in EEADR. The PIC16F873/874 devices
have 128 bytes of EEPROM data memory and there­fore, require that the MSb of EEADR remain clear. The
EEPROM data memory on these devices do not wrap
around to 0, i.e., 0x80 in the EEADR does not map to
0x00. The PIC16F876/877 devices have 256 bytes of
EEPROM data memory and therefore, uses all 8-bits of
the EEADR.

The FLASH program memory allows non-intrusive
read access, but write operations cause the device to
stop executing instructions, until the write completes.
When interfacing to the program memory, the
EEADRH:EEADR registers form a two-byte word,
which holds the 13-bit address of the memory location
being accessed. The register combination of
EEDATH:EEDATA holds the 14-bit data for writes, or
reflects the val ue of program m emory after a read oper­ation. Just as in EEPROM data memory accesses, the
value of the EEADRH:EEADR registers must be within
the valid range of program memory, depending on the
device: 0000h to 1FFFh for the PIC16F873/874, or
0000h to 3FFFh for the PIC16F876/877. Addresses
outside of this ran ge do no t wrap around t o 0000h (i.e.,
4000h does not map to 0000h on the PIC16F877).

4.1 EECON1 and EECON2 Registers

The EECON1 register is the control register for config­uring and initiatin g the access. The EECON2 reg ister is
not a physically implemented register, but is used
exclusively in the memory write sequence to prevent
inadvertent writes.

There are many bits used to control the read and write
operations to EEPROM data and FLASH program
memory. The EEPGD bit determines if the access will
be a program or data memory access. When clear, any
subsequent operations will work on the EEPROM data
memory. When set, all subsequent operations will
operate in the program memory.

Read operations only us e one additio nal bit, RD, whic h
initiates the read operation from the desired memory
location. Once this bit is set, the value of the desired
memory location will be available in the data registers.
This bit cannot be cleared by firmware. It is automati­cally cleared at the end of the read operation. For
EEPROM data memory reads, the data will be avail­able in the EEDATA register in the very next i nstruc tion
cycle after the RD bit is set. For program memory
reads, the data will be loaded into the
EEDATH:EEDATA registers, following the second
instruction after the RD bit is set.

 2001 Microchip Technology Inc. DS30292C-page 41

PIC16F87X

Write operations have two control bit s, WR and WREN,
and two status bits, WRERR and EEIF. The WREN bit
is used to enable or disable the write operation. When
WREN is clear, the write operation will be disabled.
Therefore, the WREN bit must be set befo re ex ec utin g
a write operation. Th e WR bit is used to initi ate the write
operation. It also is automatically cleared at the end of
the write operation. The interrupt flag EEIF is used to
determine when the mem ory write comp letes. This fla g
must be cleared in software before setting the WR bit.
For EEPROM data memory, once the WREN bit and
the WR bit have been set, the desired memory addres s
in EEADR will be erased, followed by a wri te of the data
in EEDATA. This operation takes place in parallel with
the microcontroller continuing to execute normally.
When the write is c omplete, the EEIF flag bit will be set.
For program memory, once the WREN bit and the WR
bit have been set, the m icrocontr oller will cease to ex e-

cute instructions. T he de sired mem ory l ocatio n poi nted
to by EEADRH:EEADR will be erased. Then, the data
value in EEDATH:EEDATA will be programmed. When
complete, the EEIF flag bi t will be set and the microcon­troller will continue to execute code.

The WRERR bit is used to indicate when the
PIC16F87X device has be en re se t during a write oper­ation. WRERR should be cleared after Power-on
Reset. Thereafter, it should be checked on any other
RESET. The WRERR bit is set when a write operation
is interrupted by a MCLR
Reset, during normal o peration. In these situati ons, fol­lowing a RESET , the user should check the WRERR bit
and rewrite the memory locati on, if set. The c ontents of
the data registers, address registers and EEPGD bit
are not affected by either MCLR
out Reset, during normal operation.

REGISTER 4-1: EECON1 REGISTER (ADDRESS 18Ch)

R/W-x U-0 U-0 U-0 R/W-x R/W-0 R/S-0 R/S-0

EEPGD — — — WRERR WREN WR RD

bit 7 bit 0

Reset, or a WDT Time-out

Reset, or WDT Time-

bit 7 EEPGD: Program/Data EEPROM Select bit

1 = Accesses program memory
0 = Accesses data memory

(This bit cannot be changed while a read or write operati on is in progress)
bit 6-4 Unimplemented: Read as '0'
bit 3 WRERR: EEPROM Error Flag bit

1 = A write operation is prematurely termina ted

(any MCLR

0 = The write operation completed
bit 2 WREN: EEPROM Write Enable bit

1 = Allows write cycles

0 = Inhibits write to the EEPROM

bit 1 WR: Write Control bit

1 = Initiates a write cycle. (The bit is cleared by hardware once write is complete. The WR bit

can only be set (not cleared) in software.)

0 = Write cycle to the EEPROM is complete
bit 0 RD: Read Control bit

1 = Initiates an EEPROM read. (RD is cleared in hardware. The RD bit can only be set (not

cleared) in software.)

0 = Does not initiate an EEPROM read

Legend:
R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’

- n = Value at POR ’1’ = Bit is set ’0’ = Bit is cleared x = Bit is unknown

Reset or any WDT Reset during normal operation)

DS30292C-page 42  2001 Microchip Technology Inc.

PIC16F87X

4.2 Reading the EEPROM Data Memory

Reading EEPROM data memory only requires that the
desired address to access be written to the EEADR
register and clear the EEPGD bit. After the RD bit is set,
data will be av ailable in the EEDATA register on the
very next instruction cycle. EEDAT A will hold this value
until another read ope rati on is in iti ated or unt il it is writ­ten by firmware.

The steps to reading the EEPROM data memory are:

1. Write the address to EEDATA. Make sure that

the address is not larger than the memory size
of the PIC16F87X device.

2. Clear the EEPGD bit to point to EEPROM data

memory.

3. Set the RD bit to start the read operation.

4. Read the data from the EEDATA register.

EXAMPLE 4-1: EEPROM DATA READ

BSF STATUS, RP1 ;
BCF STATUS, RP0 ;Bank 2
MOVF ADDR, W ;Write address
MOVWF EEADR ;to read from
BSF STATUS, RP0 ;Bank 3
BCF EECON1, EEPGD ;Point to Data memory
BSF EECON1, RD ;Start read operation
BCF STATUS, RP0 ;Bank 2

MOVF EEDATA, W ;W = EEDATA

4.3 Writing to the EEPROM Data Memory

There are many steps in writing to the EEPROM data
memory . Both address and dat a valu es must be writte n
to the SFRs. The EEPGD bit must be cleared, and the
WREN bit must be set, t o enab le w rites. The WREN b it
should be kept clear at all times, ex cept when writi ng to
the EEPROM data. The WR bit can only be set if the
WREN bit wa s set in a previous operation, i.e., they
both cannot be set in the same operation. The WREN
bit should then be cleared by firmware after the write.
Clearing the WREN bit before the write actually com­pletes will not terminate the wri te in progress.

Writes to EEPROM data memory must also be pref­aced with a special sequence of instructions, that pre­vent inadvertent wri te operatio ns. This is a s equence of
five instructions that m ust be executed without in terrup­tions. The firmware should verify that a write is not in
progress, before starting another cycle.

The steps to write to EEPROM data memory are:

1. If step 10 is not implemented, check the WR bit
to see if a write is in progress.

2. Write the address to EEADR. Make sure that the
address is not larger than the memory size of
the PIC16F87X device.

3. Write the 8-bit data value to be programmed in
the EEDATA register.

4. Clear the EEPGD bit to point to EEPROM data
memory.

5. Set the WREN bit to enable program operati ons.

6. Disable interrupts (if enabled).

7. Execute the special five instruction sequence:

• Write 55h to EECON2 in two st eps (first to W ,

then to EECON2)

• Write AAh to EECON2 in two steps (first to

W, then to EECON2)

• Set the WR bit

8. Enable interrupts (if using interrupts).

9. Clear the WREN bit to disable program opera­tions.

10. At the completion of the write cycle, the WR bit
is cleared and the EEIF interrupt flag bit is set.
(EEIF must be cleared by firmware.) If step 1 is
not implemented, then firmware should check
for EEIF to be set, or WR to clear , to indica te the
end of the program cycle.

EXAMPLE 4-2: EEPROM DATA WRITE

BSF STATUS, RP1 ;
BSF STATUS, RP0 ;Bank 3
BTFSC EECON1, WR ;Wait for
GOTO $-1 ;write to finish
BCF STATUS, RP0 ;Bank 2
MOVF ADDR, W ;Address to
MOVWF EEADR ;write to
MOVF VALUE, W ;Data to
MOVWF EEDATA ;write
BSF STATUS, RP0 ;Bank 3
BCF EECON1, EEPGD ;Point to Data memory
BSF EECON1, WREN ;Enable writes
;Only disable interrupts
BCF INTCON, GIE ;if already enabled,
;otherwise discard
MOVLW 0x55 ;Write 55h to
MOVWF EECON2 ;EECON2
MOVLW 0xAA ;Write AAh to
MOVWF EECON2 ;EECON2
BSF EECON1, WR ;Start write operation
;Only enable interrupts
BSF INTCON, GIE ;if using interrupts,
;otherwise discard
BCF EECON1, WREN ;Disable writes

 2001 Microchip Technology Inc. DS30292C-page 43

PIC16F87X

y

4.4 Reading the FLASH Program Memory

Reading FLASH program memory is much like that of
EEPROM data memory , only two NOP instructions must
be inserted afte r the RD bit is set. These two i nstruction
cycles that t he NOP instructions execute, will be used
by the micr ocontr olle r to r ead th e data out o f prog ram
memory and insert the value into the
EEDATH:EEDATA registers. Data will be available fol­lowing the second NOP instruction. EEDATH and
EEDATA will hold their value until another read opera­tion is initiated, or until they are written by firmware.

The steps to rea din g t he FLASH program memory are:

1. Write the address to EEADRH:EEADR. Make

sure that the address is not larger than the mem­ory size of the PIC16F87X device.

2. Set the EEPGD bit to point to FLASH program

memory.

3. Set the RD bit to start the read operation.

4. Execute two NOP instructions to allow the micro-

controller to read out of program memory.

5. Read the data from the EEDATH:EEDATA

registers.

EXAMPLE 4-3: FLASH PROGRAM READ

BSF STATUS, RP1 ;
BCF STATUS, RP0 ;Bank 2
MOVF ADDRL, W ;Write the
MOVWF EEADR ;address bytes
MOVF ADDRH,W ;for the desired
MOVWF EEADRH ;address to read
BSF STATUS, RP0 ;Bank 3
BSF EECON1, EEPGD ;Point to Program memor
BSF EECON1, RD ;Start read operation
NOP ;Required two NOPs
NOP ;
BCF STATUS, RP0 ;Bank 2
MOVF EEDATA, W ;DATAL = EEDATA
MOVWF DATAL ;
MOVF EEDATH,W ;DATAH = EEDATH
MOVWF DATAH ;

4.5 Writing to the FLASH Program Memory

Writing to FLASH program memory is unique, in that
the microcontroller does not execute instructions while
programming is taking place. The oscillator continues
to run and all peripherals continue to operate and
queue interrupts, if enabled. Once the write operation
completes (specification D133), the processor begins
executing code from where it left off. The other impor­tant difference when writing to FLASH program mem­ory, is that the WRT configuration bit, when clear,
prevents any writes to program memory (see Table 4-1).

Just like EEPROM data memory, there are many s teps
in writing to the FLASH program mem ory . Bot h address
and data values must be written to the SFRs. The
EEPGD bit must be set, and the WREN bit must be set
to enable writes. The WREN bit s hould b e kept clear at
all times, except when writing to the FLASH Program
memory. The WR bit can only be set if the WREN bit
was set in a previous operation, i.e., they both cannot
be set in the same operation. The WREN bit should
then be cleared by firmwa re after the writ e. Clearing the
WREN bit before the write actually completes will not
terminate the write in progress.

Writes to program memory must also be prefaced with
a special sequence of instructions that prevent inad­vertent write operations. This is a sequence of five
instructio ns t h at mu st b e e xe cu t ed w it hou t i n ter r upt i on
for each byt e writ ten. Th ese ins tructi ons must then be
followed by two NOP instructions to allow the microcon­troller to setup for th e writ e opera tion. Onc e the wr ite i s
complete, the execution of instructions starts with the
instruction after the second NOP.

The steps to write to program memory are:

1. Write the address to EEADRH:EEADR. Make

sure that the address i s not larger than the m em­ory size of the PIC16F87X device.

2. Write the 14-bit da t a va lue to be programmed in

the EEDATH:EEDATA registers.

3. Set the EEPGD bit to point to FLASH program

memory.

4. Set the WREN bit to enable program operati ons.

5. Disable interrupts (if enabled).

6. Execute the special five instruction sequence:

• Write 55h to EECON2 in two st eps (fi rst to W ,
then to EECON2)

• Write AAh to EECON2 in two step s (first to W ,

then to EECON2)

• Set the WR bit

7. Execute two NOP instruction s to allow the mic ro­controller to setup for write operation.

8. Enable interrupts (if using interrupts).

9. Clear the WREN bit to disable program
operations.

DS30292C-page 44  2001 Microchip Technology Inc.

PIC16F87X

At the completion of the write cycle, the WR bit is
cleared and the EEIF interrupt flag bit is set. (EEIF
must be cleared by firmware. ) Since the microcont roller
does not execute in structions duri ng the write cy cle, the
firmware does not necessarily have to check either
EEIF, or WR, to determine if the write had finished.

EXAMPLE 4-4: FLASH PROGRAM WRI TE

BSF STATUS, RP1 ;
BCF STATUS, RP0 ;Bank 2
MOVF ADDRL, W ;Write address
MOVWF EEADR ;of desired
MOVF ADDRH, W ;program memory
MOVWF EEADRH ;location
MOVF VALUEL, W ;Write value to
MOVWF EEDATA ;program at
MOVF VALUEH, W ;desired memory
MOVWF EEDATH ;location
BSF STATUS, RP0 ;Bank 3
BSF EECON1, EEPGD ;Point to Program memory
BSF EECON1, WREN ;Enable writes
;Only disable interrupts
BCF INTCON, GIE ;if already enabled,
;otherwise discard
MOVLW 0x55 ;Write 55h to
MOVWF EECON2 ;EECON2
MOVLW 0xAA ;Write AAh to
MOVWF EECON2 ;EECON2
BSF EECON1, WR ;Start write operation
NOP ;Two NOPs to allow micro
NOP ;to setup for write
;Only enable interrupts
BSF INTCON, GIE ;if using interrupts,
;otherwise discard

BCF EECON1, WREN ;Disable writes

4.6 Write Verify

The PIC16F87X device s do not automatic ally verify the
value written during a write operation. Depending on
the application, good programming practice may dic­tate that the value written to memory b e verified against
the original value. This should be used in applications
where excessive writes can stress bits near the speci­fied endurance limit s.

4.7 Protection Against Spurious

Writes

There are conditions when the device may not want to
write to the EEPROM data memory or FL ASH program
memory. To protect against these spurious write condi­tions, various mechanisms have been built into the
PIC16F87X devices. On power-up, the WREN bit is
cleared and the Power-up Timer (if enabled) prevents
writes.

The write initiate sequence, and the WREN bit
together, help prevent any accidental writes during
brown-out, power glitches, or firmware malfunction.

4.8 Operation While Code Protected

The PIC16F87 X devi ce s ha ve tw o c ode pr o tec t mec ha ­nisms, one bit for EEPROM dat a memory and two bi ts for
FLASH program memory. Data can be read and written
to the EEPROM data memory, regardless of the state of
the code protection bit, CPD. When code protection is
enabled and CPD cleared, external access via ICSP is
disabled, regardles s of the sta te of the prog ram memory
code protect bits. This prevents the contents of EEPROM
data memory fro m bei ng rea d o ut of the device.

The state of the program memory code protect bits,
CP0 and CP1, do not affect the execution of instruc­tions out of program mem ory. The PIC16F87X devices
can always read the values in program memory,
regardless of the state of the code protect bits. How­ever , the st a te of th e c ode protect bits and the WRT bit
will have diffe rent effects on wr iting to prog ram mem­ory. Table 4-1 shows the effect of the code protect bits
and the WRT bit on program memory.

Once code protection has been enabled for either
EEPROM data memory or FLASH program memory,
only a full erase of the entire device will disable code
protection.

 2001 Microchip Technology Inc. DS30292C-page 45

PIC16F87X

4.9 FLASH Program Memory Write Protection

The configuration word contains a bit that write protects
the FLASH program memory, called WRT. This bit can
only be accessed when programming the PIC16F87X
device via ICSP. Once write protec tion i s e na ble d, onl y
an erase of the entire device will disable it. When
enabled, write protec tion prevent s any writes to FLASH
program memory. Write protection does not affect pro­gram memory reads.

TABLE 4-1: READ/WRITE STATE OF INTERNAL FLASH PROGRAM MEMORY

Configuration Bits

CP1 CP0 WRT

00x All program memory Yes No No No
010 Unprotected areas Yes No Yes No
010 Protected areas Yes No No No
011 Unprotected areas Yes Yes Yes No
011 Protected areas Yes No N o No
100 Unprotected areas Yes No Yes No
100 Protected areas Yes No N o No
101 Unprotected areas Yes Yes Yes No
101 Protected areas Yes No N o No
110 Al l program mem ory Yes No Yes Yes
111 Al l program mem ory Yes Yes Yes Yes

Memory Location

TABLE 4-2: REGISTERS ASSOCIATED WITH DATA EEPROM/PROGRAM FLASH

Address Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

0Bh, 8Bh,
10Bh, 18Bh

10Dh EEADR EEPROM Addr ess Regist er, Low Byte
10Fh EEADRH — — — EEPROM Address, High Byte
10Ch EEDATA EEPROM Data Register, Low Byte
10Eh EED ATH — — EEPROM Data Register, High Byte
18Ch EECON1 EEPGD — — — WRERR WREN WR RD
18Dh EECON2 EEPROM Control Register2 (not a physical register)
8Dh PIE2
0Dh PIR2 — (1) — EEIF BCLIF — — CCP2IF
Legend: x = unknown, u = unchanged, r = reserved, - = unimplemented, read as '0'.

Note 1: These bits are reserved; always maintain these bits clear.

INTCON GIE PEIE

— (1) — EEIE BCLIE — — CCP2IE

Shaded cells are not used during FLASH/EEPROM access.

T0IE INTE RBIE T0IF INTF RBIF

Internal

Read

Internal

Write

ICSP Read ICSP Write

Value on:

POR,
BOR

0000 000x 0000 000u

xxxx xxxx uuuu uuuu

xxxx xxxx uuuu uuuu

xxxx xxxx uuuu uuuu

xxxx xxxx uuuu uuuu

x--- x000 x--- u000

——

-r-0 0--0 -r-0 0--0

-r-0 0--0 -r-0 0--0

Val ue on
all other

RESETS

DS30292C-page 46  2001 Microchip Technology Inc.

PIC16F87X

5.0 TIMER0 MODULE

Counter mode is selected by setting bit T0CS
(OPTION_REG<5>). In Counter mode, Timer0 will

The Timer0 module timer/co unter has the follow ing fea­tures:

• 8-bit timer/counter

• Readable and writable

• 8-bit software programmable prescaler

• Internal or external clock select

• Interrupt on overflow from FFh to 00h

• Edge select for external clock

Figure 5-1 is a block diagram of the T imer0 m odule and

increment either on every rising, or falling edge of pin
RA4/T0CKI. The incrementing edge is determined by
the Timer0 Source Edge Select bit, T0SE
(OPTION_REG<4>). Clearing bit T0SE selects the ris­ing edge. Restrictions on the external clock input are
discussed in detail in Section 5.2.

The prescaler is mutually exclusively shared between
the Timer0 modu le and t he W a tchdo g Timer . The pres­caler is not readabl e or w rit able. Sectio n 5.3 details the
operation of the prescaler.

the prescaler shared with the WDT.
Additional information on the Timer0 module is avail-

able in the PICmicro™ Mid-Range MCU Family Refer­ence Manual (DS33023).

Timer mode is selected by clearing bit T0CS
(OPTION_REG<5>). In Timer mode, the Timer0 mod­ule will incremen t every ins tru ction cycle (without pres­caler). If the TMR0 register is written, the increment is
inhibited for the following two instruction cycles. The
user can work around this by writing an adjusted value

5.1 Timer0 Interrupt

The TMR0 interrupt is generated when the TMR0 reg­ister overflows from FFh to 00h. This overflow sets bit
T0IF (INTCON<2>). The interrupt can be masked by
clearing bit T0IE (INTCON<5>). Bit T0IF must be
cleared in soft ware by the T imer0 mo dule Interrupt Ser­vice Routine before re-enabling this interrupt. The
TMR0 interrupt cannot awaken the processor from
SLEEP, since the timer is shut-off during SLEEP.

to the TMR0 register.

FIGURE 5-1: BLOCK DIAGRAM OF THE TIMER0/WDT PRESCALER

CLKOUT (= F

RA4/T0CKI

pin

Watchdog

Timer

WDT Enable bit

OSC/4)

T0SE

Data Bus

M

0

U
X

1

T0CS

0

M
U

1

X

PSA

8-bit Prescaler

8 - to - 1MUX

0

Time-out

PRESCALER

8

M U X

WDT

1

M
U

0

X

PSA

1

SYNC

2

Cycles

PS2:PS0

PSA

8

TMR0 Reg

Set Flag Bit T0IF

on Overflow

Note: T0CS, T0SE, PSA, PS2:PS0 are (OPTION_REG<5:0>).

 2001 Microchip Technology Inc. DS30292C-page 47

PIC16F87X

5.2 Using Timer0 with an External Clock

When no pr escal er is us ed, t he ex ternal clock inpu t is
the same as the prescaler outp ut. Th e synchronization
of T0CKI with the internal phase clocks is accom­plished by sampli ng the prescale r output on the Q2 and
Q4 cycles of the internal phase clocks. Therefore, it is
necessary f or T 0 C KI t o be hi g h f or at le as t 2Tosc (and
a small RC delay of 20 ns) and low for at least 2Tosc
(and a small RC delay of 20 ns). Refer to the electrical
specification of the desired device.

Timer0 m odule means that there is no presc aler fo r the
Watchdog Timer, and vice-versa. This prescaler is not
readable or writable (see Figure 5-1).

The PSA and PS2:PS0 bits (OPTION_REG<3:0>)
determine the prescaler assignment and pre scale ratio.

When assigned to the Timer0 module, all instructions
writing to the TMR0 register ( e.g. CLRF

BSF

to WDT, a CLRWDT instruction will clea r the prescaler
along with the Watchdog Timer. The prescaler is not
readable or writable.

5.3 Prescaler

There is only one presca ler a vailable, which i s mutuall y
exclusively sha red between the T imer0 mod ule and the
Watchdog Timer. A prescaler assignment for the

REGISTER 5-1: OPTION_REG REGISTER

R/W-1 R/W-1 R/W-1 R/W-1 R/W-1 R/W-1 R/W-1 R/W-1
RBPU

bit 7 bit 0

bit 7 RBPU
bit 6 INTEDG
bit 5 T0CS: TMR0 Clock Source Select bit

1 = Transition on T0CKI pin
0 = Internal instruction cycle clock (CLKOUT)

bit 4 T0SE: TMR0 Source Edge Select bit

1 = Increment on high-to-low transition on T0CKI pin
0 = Increment on low-to-high transition on T0CKI pin

bit 3 PSA: Prescaler Assignment bit

1 = Prescaler is assigned to the WDT
0 = Prescaler is assigned to the Timer0 module

bit 2-0 PS2:PS0: Prescaler Rate Select bits

Bit Value TMR0 Rate WDT Rate

000
001
010
011
100
101
110
111

INTEDG T0CS T0SE PSA PS2 PS1 PS0

1 : 2
1 : 4
1 : 8
1 : 16
1 : 32
1 : 64
1 : 128
1 : 256

1 : 1
1 : 2
1 : 4
1 : 8
1 : 16
1 : 32
1 : 64
1 : 128

1, MOVWF 1,

1,x.. ..etc.) will clear the pre scaler . When assi gned

Note: Writing to TMR0, when the prescaler is

assigned to T imer0, will clear the pre scaler
count, but will not change the prescaler
assignment.

Legend:
R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’

- n = Value at POR ’1’ = Bit is set ’0’ = Bit is cleared x = Bit is unknown

Note: To avoid an unintended device RESET, the instruc tion sequence s hown in the PICmicro™ M id-Range MCU

Family Reference Manual (DS33023) must be executed when changing the prescaler assignment from
Timer0 to the WDT. This sequence must be followed even if the WDT is disabled.

DS30292C-page 48  2001 Microchip Technology Inc.

TABLE 5-1: REGISTERS ASSOCIATED WITH TIMER0

PIC16F87X

Address Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

01h,101h TMR0 Timer0 Module’s Register
0Bh,8Bh,

10Bh,18Bh
81h,181h OPTION_REG RBPU INTEDG T0CS T0SE PSA PS2 PS1 PS0
Legend: x = unknown, u = unchanged, - = unimplemented locations read as '0'.

INTCON GIE PEIE T0IE INTE RBIE T0IF INTF RBIF

Shaded cells are not used by T ime r0.

Value on:

POR,

BOR

xxxx xxxx uuuu uuuu

0000 000x 0000 000u

1111 1111 1111 1111

Value on

all other

RESETS

 2001 Microchip Technology Inc. DS30292C-page 49

PIC16F87X

NOTES:

DS30292C-page 50  2001 Microchip Technology Inc.

PIC16F87X

6.0 TIMER1 MODULE

The Timer1 mod ule is a 16-bi t timer/c ou nter c ons isting
of two 8-bit registers (TMR1H and TMR1L), which are
readable and writable. The TMR1 Register pair
(TMR1H:TMR1L) increments from 0000h to FFFFh
and rolls over to 0000 h. The TMR1 Inte rrupt, if enabled,
is generated on overflow, which is latched in interrupt
flag bit TMR1IF (PIR1<0>). This interrupt can be
enabled/disabled by setting/clearing TMR1 interrupt
enable bit TMR1IE (PIE1<0>).

Timer1 can operate in one of two modes:

• As a timer

• As a counter

The operating mode is determined by the clock select
bit, TMR1CS (T1CON<1>).

In Timer mode, Timer1 increments every instruction
cycle. In Counter mode, it increments on every rising
edge of the external clock input.

Timer1 can be enabled/disabled by setting/clearing
control bit TMR1ON (T1CON<0> ) .

Timer1 also has an internal “RESET input”. This
RESET can be generated by either of the two CCP
modules (Section 8.0). Register 6-1 shows the Timer1
control register.

When the Timer1 oscillator is enabled (T1OSCEN is
set), the RC1/T1OSI/CCP2 and RC0/T1OSO/T1CKI
pins become inputs. That is, the TRISC<1:0> value is
ignored, and these pins read as ‘0’.

Additional information on timer modules is available in
the PICmicro™ Mid-Range MCU Family Reference
Manual (DS33023).

REGISTER 6-1: T1CON: TIMER1 CONTROL REGISTER (ADDRESS 10h)

U-0 U-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0

— — T1CKPS1 T1CKPS0 T1OSCEN T1SYNC TMR1CS TMR1ON

bit 7 bit 0

bit 7-6 Unimplemented: Read as '0'
bit 5-4 T1CKPS1:T1CKPS0: Timer1 Input Clock Prescale Select bits

11 = 1:8 Prescale value
10 = 1:4 Prescale value
01 = 1:2 Prescale value
00 = 1:1 Prescale value

bit 3 T1OSCEN: Timer1 Oscillator Enable Control bit

1 = Oscillator is enabled
0 = Oscillator is shut-off (t he oscillator inverter is turned off to eliminate power drain)

bit 2 T1SYNC

When TMR1CS = 1:

1 = Do not synchronize external clock input
0 = Synchronize external clock input

When TMR1CS = 0
This bit is ignored. Timer1 uses the internal clock when TMR1CS = 0.

bit 1 TMR1CS: Timer1 Clock Source Select bit

1 = External clock from pin RC0/T1OSO/T1CKI (on the rising edge)
0 = Internal clock (FOSC/4)

bit 0 TMR1ON: Timer1 On bit

1 = Enables Timer1
0 = Stops Timer1

: Timer1 External Clock Input Synchronization Control bit

:

Legend:
R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’

- n = Value at POR ’1’ = Bit is set ’0’ = Bit is cleared x = Bit is unknown

 2001 Microchip Technology Inc. DS30292C-page 51

PIC16F87X

6.1 Timer1 Operation in Timer Mode

Timer mode is selected by clearing the TMR1CS
(T1CON<1>) bit. In this mode, the input clock to the
timer is F
(T1CON<2>) has no effect, since the internal clock is
always in sync.

FIGURE 6-1: TIMER1 INCREMENTING EDGE

OSC/4. The synchronize control bit T1SYNC

T1CKI
(Default High)

T1CKI
(Default Low)

Note: Arrows indicate counter increments.

6.2 Timer1 Counter Operation

Timer1 may operate in either a Synchronous, or an
Asynchronous mode, depending on the setting of the
TMR1CS bit.

When Timer1 is being incremented via an external
source, increment s occur on a rising edg e. After T imer1
is enabled in Coun ter mode, the module mus t first have
a falling edge before the counter begins to increment.

6.3 Timer1 Operation in Synchronized Counter Mode

Counter mode is selected by setting bit TMR1CS. In
this mode, the timer increm ents on every risin g edge of
clock input on pin RC1/T1OSI/CCP2, when bit
T1OSCEN is set, or on pi n RC0/T1 OSO/T 1CKI , when
bit T1OSCEN is cleared.

FIGURE 6-2: TIMER1 BLOCK DIAGRAM

Set Flag bit
TMR1IF on
Overflow

RC0/T1OSO/T1CKI

RC1/T1OSI/CCP2

(2)

TMR1H

T1OSC

TMR1

TMR1L

T1OSCEN
Enable

Oscillator

(1)

If T1SYNC is cleared, the n the externa l clock input is
synchronized with internal phase clocks. The synchro­nization is done after the prescaler stage. The
prescaler stage is an asynchronous ripple-counter.

In this configuration, during SLEEP mode, Timer1 will
not increment even if the external clock is present,
since the synchronization circuit is shut-off. The
prescaler, however, will continue to increment.

Synchronized

Clock Input

Synchronize

det

Q Clock

FOSC/4
Internal

Clock

TMR1ON

On/Off

1

0

TMR1CS

0

1

T1SYNC

Prescaler

1, 2, 4, 8

2

T1CKPS1:T1CKPS0

Note 1: When the T1OSCEN bit is cleared, the inverter is turned off. This eliminates power drain.

DS30292C-page 52  2001 Microchip Technology Inc.

PIC16F87X

6.4 Timer1 Operation in Asynchronous Counter Mode

If control bit T1SYNC (T1CON<2>) is set, the external
clock input is not synchronized. The timer continues to
increment asynchronous to the internal phase clocks.
The timer will continue to run during SLEEP and can
generate an interrupt-on-overflow, which will wake-up
the processor. However, special precautions in soft­ware are needed to read/write the time r (Section 6.4.1).

In Asynchronous Counter mode, Timer1 cannot be
used as a time-base for capture or compare opera­tions.

6.4.1 READING AND WRITING TIMER1 IN

ASYNCHRONOUS COUNTER
MODE

Reading TMR1H or TMR1L while the timer is running
from an external asynchronous clock, will guarantee a
valid read (taken care of in hardware). However, the
user shoul d keep i n mind that r eadin g the 16-bit time r
in two 8-bit values it self, poses certain probl em s, s inc e
the timer may overflow between the reads.

For writes, it is recomm ended that the us er simply stop
the timer and write the desired values. A write conten­tion may occur by writing to the timer registers, while
the register is incrementing. This may produce an
unpredictable value in the timer register.

Reading the 16-bit value requires some care. Exam­ples 12-2 and 12-3 in the PICmicro™ M id - Range MCU
Family Reference Manual (DS33023) show how to
read and write Timer1 when it is running in Asynchro­nous mode.

6.5 Timer1 Oscillator

A crystal oscillator ci rcuit is built-in betwee n pins T1OSI
(input) and T1OSO (amplifier output). It is enabled by
setting control bit T1OSCEN (T 1CON<3>). The oscill a­tor is a low power oscillator, rated up to 200 kHz. It will
continue to run during SLEEP. It is primarily intended
for use with a 32 kHz crystal. Table 6-1 shows the
capacitor selection for the Timer1 oscillator.

The Timer1 oscillator is identical to the LP oscillator.
The user must provide a so f t ware time delay to ensure
proper oscillator start-up.

T ABLE 6-1: CAPACITOR SELECTION FOR

THE TIMER1 OSCILLATOR

Osc T y pe Freq. C1 C2

LP 32 kHz 33 pF 33 pF

100 kHz 15 pF 15 pF
200 kHz 15 pF 15 pF

These values are for design guidance only.

Crystals Tested:

32.768 kHz Epson C-001R32.768K-A ± 20 PPM
100 kHz Epson C-2 100.00 KC-P ± 20 PPM
200 kHz STD XTL 200.000 kHz ± 20 PPM

Note 1: Higher capacitance increases the stability

of oscillator , b ut also inc rease s the st art-up
time.

2: Since each resonator/crystal has its own

characteristics, the u ser shoul d consult th e
resonator/crystal manufacturer for appro­priate values of external components.

6.6 Resetting Timer1 using a CCP Trigger Output

If the CCP1 or CCP2 module is config ured in C omp are
mode to generate a “special event trigger”
(CCP1M3:CCP1M0 = 1011), this signal will reset
Timer1.

Note: The special event triggers from the CCP1

and CCP2 modules will not set interrupt
flag bit TMR1IF (PIR1<0>).

Timer1 mu st be confi gured fo r either T ime r or Synchr o­nized Counter mode to take advantage of this feature.
If Timer1 is running in Asynchronous Counter mode,
this RESET operation may not work.

In the event that a write t o T imer1 coinc ides with a sp e­cial event trigger from CCP1 or CCP2, the write will
take precedence.

In this mode of ope rati on, the CCPRxH :CCPRx L regis ­ter pair effectively becomes the period register for
Timer1.

 2001 Microchip Technology Inc. DS30292C-page 53

PIC16F87X

6.7 Resetting of Timer1 Register Pair (TMR1H, TMR1L)

TMR1H and TMR1L registers are not rese t to 00h on a

6.8 Timer1 Prescaler

The prescaler counter is cleared on writes to the
TMR1H or TMR1L registers.

POR, or any other RESET, except by the CCP1 and
CCP2 special event triggers.

T1CON register is reset to 00h on a Power-on Reset,
or a Brown-out Reset, which shuts off the timer and
leaves a 1:1 prescale. In all other RESETS, the register
is unaffected.

TABLE 6-2: REGISTERS ASSOCIATED WITH TIMER1 AS A TIMER/COUNTER

Address Na me Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

0Bh,8Bh,
10Bh, 18Bh

0Ch PIR1 PSPIF
8Ch PIE1 PSPIE
0Eh TMR1L Holding Register for the Least Significant Byte of the 16-bit TMR1 Register
0Fh TMR1H Holding Register for the Most Significant Byte of the 16-bit TMR1 Register
10h T1CON — — T1CKPS1 T1CKPS0 T1OSCEN T1SYNC TMR1CS TMR1ON
Legend: x = unknown, u = unchanged, - = unimplemented, read as '0'. Shaded cells are not used by the Timer1 module.

Note 1: Bits PSPIE and PSPIF are reserved on the PIC16F873/876; always maintain these bits clear.

INTCON GIE PEIE

(1)

ADIF RCIF TXIF SSPIF CCP1IF TMR2IF TMR1IF

(1)

ADIE RCIE TXIE SSPIE CCP1IE TMR2IE TMR1IE

T0IE INTE RBIE T0IF INTF RBIF

Value on:

0000 000x 0000 000u

0000 0000 0000 0000

0000 0000 0000 0000

xxxx xxxx uuuu uuuu

xxxx xxxx uuuu uuuu

--00 0000 --uu uuuu

POR,

BOR

Value on
all other
RESETS

DS30292C-page 54  2001 Microchip Technology Inc.

PIC16F87X

7.0 TIMER2 MODULE

Timer2 is an 8-bit timer with a prescaler and a
postscaler. It can be used as the PW M time-base fo r
the PWM mode of the CCP mod ule (s). The T MR2 re g­ister is readable and writable, and is cleared on any
device RESET.

The input clock (F
1:4, or 1:16, selected by control bits

OSC/4) has a prescale option of 1:1,

Register 7-1 shows the Timer2 control register.
Additional information on timer modules is available in

the PICmicro™ Mid-Range MCU Family Reference
Manual (DS33023).

FIGURE 7-1: TIMER2 BLOCK DIAGRAM

Sets Flag
bit TMR2IF

TMR2

Output

(1)

T2CKPS1:T2CKPS0 (T2CON<1:0>).

RESET

EQ

TMR2 Reg

Comparator

PR2 Reg

The Timer2 module has an 8-bit period register, PR2.
Timer2 increments from 00h until it matches PR2 and
then resets to 00h on the next increment cycle. PR2 is
a readable and writable register. The PR2 register is
initialized to FFh upon RESET.

The match output of TMR2 goes through a 4-bit
postscaler (which gives a 1:1 to 1:16 scaling inclusive)
to generate a TMR2 interrupt (latched in flag bit
TMR2IF, (PIR1<1>)).

Postscaler
1:1 1:16

to

4

T2OUTPS3:

T2OUTPS0

Note 1: TMR2 register output can be software selected by the

SSP module as a baud clock.

Timer2 c an b e s hu t-off by clearing c ont rol bit TMR2ON
(T2CON<2>) , to minimize power consumption.

REGISTER 7-1: T2CON: TIMER2 CONTROL REGISTER (ADDRESS 12h)

U-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0

— TOUTPS3 TOUTPS2 TOUTPS1 TOUTPS0 TMR2ON T2CKPS1 T2CKPS0

bit 7 bit 0

Prescaler

1:1, 1:4, 1:16

2

T2CKPS1:

T2CKPS0

OSC/4

F

bit 7 Unimplemented: Read as '0'
bit 6-3 TOUTPS3:TOUTPS0: Timer2 Output Postscale Select bits

0000 = 1:1 Postscale
0001 = 1:2 Postscale
0010 = 1:3 Postscale

•

•

•

1111 = 1:16 Postscale

bit 2 TMR2ON: Timer2 On bit

1 = Timer2 is on
0 = Timer2 is off

bit 1-0 T2CKPS1:T2CKPS0: Timer2 Clock Prescale Select bits

00 = Prescaler is 1
01 = Prescaler is 4
1x = Prescaler is 16

Legend:
R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’

- n = Value at POR ’1’ = Bit is set ’0’ = Bit is cleared x = Bit is unknown

 2001 Microchip Technology Inc. DS30292C-page 55

PIC16F87X

7.1 Timer2 Prescaler and Postscaler

The prescaler and postscaler counters are cleared
when any of the following occurs:

• a write to th e TMR2 register

7.2 Output of TMR2

The output of TMR2 (before the post scaler) is fed to the
SSP module, which optionally uses it to generate shift
clock.

• a write to the T2CON register

• any device RESET (POR, MCLR

Reset, WDT

Reset, or BOR)

TMR2 is not cleared when T2CON is written.

TABLE 7-1: REGISTERS ASSOCIATED WITH TIMER2 AS A TIMER/COUNTER

Address Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

0Bh,8Bh,
10Bh,18Bh

0Ch PIR1 PSPIF
8Ch PIE1 PSPIE
11h TMR2 Timer2 Module’s Register 0000 0000 0000 0000
12h T2CON — TOUTPS3 TOUTPS2 TOUTPS1 TOUTPS0 TMR2ON T2CKPS1 T2CKPS0 -000 0000 -000 0000
92h PR2 Timer2 Period Register 1111 1111 1111 1111
Legend: x = unknown, u = unchanged, - = unimplemented, read as '0'. Shaded cells are not used by the Timer2 module.

Note 1: Bits PSPIE and PSPIF are reserved on the PIC16F873/876; always maintain these bits clear.

INTCON GIE PEIE

(1)

ADIF RCIF TXIF SSPIF CCP1IF TMR2IF TMR1IF 0000 0000 0000 0000

(1)

ADIE RCIE TXIE SSPIE CCP1IE TMR2IE TMR1IE 0000 0000 0000 0000

T0IE INTE RBIE T0IF INTF RBIF 0000 000x 0000 000u

Value on:

POR,
BOR

Value on
all other
RESETS

DS30292C-page 56  2001 Microchip Technology Inc.

PIC16F87X

8.0 CAPTURE/COMPARE/PWM MODULES

Each Capture/Compare/PWM (CCP) module contains
a 16-bit register which can operate as a:

• 16-bit Capt ure register

• 16-bit Compare register

• PWM Master/Slave Duty Cycle register

Both the CCP1 and CCP2 modules are identical in
operation, with the e xception being the operation of the
special event trigg er. Table 8-1 and Ta ble 8-2 show the
resources and interactions of the CCP module(s). In
the following sections, the operation of a CCP module
is described with respect to CCP1. CCP2 operates the
same as CCP1, except where noted.

CCP1 Module:
Capture/Compare/PWM Register1 (CCPR1) is com-

prised of two 8-bit registers: CCPR1L (low byte) and
CCPR1H (high byte). The CCP1CON register controls
the operation of CCP1. The special event trigger is
generated by a compare match and will reset Timer1.

TABLE 8-2: INTERACTION OF TWO CCP MODULES

CCP2 Module:
Capture/Compare/PWM Register2 (CCPR2) is com-

prised of tw o 8-bit registers: CCPR2L (low byte) and
CCPR2H (high byte). The CCP2CON register controls
the operation of CCP2. The special event trigger is
generated by a compare match and will reset Timer1
and start an A/D conversion (if the A/D module is
enabled).

Additional information on CCP modules is available in
the PICmicro™ Mid-Range MCU Family Reference
Manual (DS33023) and in application note AN594,
“Using the CCP Modules” (DS00594).

TABLE 8-1: CCP MODE - TIMER

RESOURCES REQUIRED

CCP Mode Timer Resource

Capture

Compare

PWM

Timer1
Timer1
Timer2

CCPx Mode CCPy Mode Interaction

Capture Capture Same TMR1 time-base
Capture Compare The compare should be configured for the special event trigger, which clears TMR1

Compare Compare The compare(s) should be configured for the special event trigger, which clears TMR1

PWM PWM The PWMs will have the same frequency and update rate (TMR2 interrupt)
PWM Capture None
PWM Compare None

 2001 Microchip Technology Inc. DS30292C-page 57

PIC16F87X

REGISTER 8-1: CCP1CON REGISTER/CCP2CON REGISTER (ADDRESS: 17h/1Dh)

U-0 U-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0

— — CCPxX CCPxY CCPxM3 CCPxM2 CCPxM1 CCPxM0

bit 7 bit 0

bit 7-6 Unimplemented: Read as '0'
bit 5-4 CCPxX:CCPxY: PWM Least Significant bits

Capture mode
Unused

Compare mode:
Unused

PWM mode:
These bits are the two LSbs of the PWM duty cycle. The eight MSbs are found in CCPRxL.

bit 3-0 CCPxM3:CCPxM0: CCPx Mode Select bits

0000 =Capture/Compare/PWM disabled (resets CCPx module)
0100 =Capture mode, every falling edge
0101 =Capture mode, every rising edge
0110 =Capture mode, every 4th rising edge
0111 =Capture mode, every 16th rising edge
1000 =Compare mode, set output on match (CCPxIF bit is set)
1001 =Compare mode, clear output on match (CCPxIF bit is set)
1010 =Compare mode, generate software interrupt on match (CCPxIF bit is set, CCPx pin is

1011 = Compare mode, trigger spe cial event (CCPxIF bit i s set, CCPx pin is unaf fected); CCP1

11xx =PWM mode

:

unaffected)
resets TMR1; CCP2 resets TMR1 and starts an A/D conversion (if A/D module is

enabled)

Legend:
R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’

- n = Value at POR ’1’ = Bit is set ’0’ = Bit is cleared x = Bit is unknown

DS30292C-page 58  2001 Microchip Technology Inc.

PIC16F87X

8.1 Capture Mode

In Capture mode, CCPR1H:CCPR1L captures the
16-bit value of the TMR1 r egister wh en an eve nt occurs
on pin RC2/CCP1. An ev ent is defined as on e of the fol­lowing:

• Every falling edge

• Every rising edge

• Every 4th rising edge

• Every 16th rising edge

The type of event is configured by control bits
CCP1M3:CCP1M0 (CCPxCON<3:0>). When a cap­ture is made, the interrupt request flag bit CCP1IF
(PIR1<2>) is set. The interrupt flag must be cleared in
software. If another capture occurs before the value in
register CCPR1 is read, th e old ca ptured v alue is over­written by the new value.

8.1.1 CCP PIN CONFIGURATION

In Capture mode, the R C2/ CCP 1 pin sh oul d b e config­ured as an input by setting the TRISC<2> bit.

Note: If the RC2/CCP1 pin is configured as an

output, a write t o the port c an cau se a cap­ture condition.

8.1.2 TIMER1 MODE SELECTION

Timer1 must be running in Timer mode, or Synchro­nized Counter mode, for the CCP module to use the
capture feature. In Asynchronous Counter mode, the
capture operation may not work.

8.1.3 SOFTWARE INTERRUPT

When the Capture mode is changed, a false capture
interrupt may be generated. The user should keep bit
CCP1IE (PIE1<2>) clear to avoid false interrupts and
should clear the flag bit CCP1IF, following any such
change in operating mode.

8.1.4 CCP PRESCALER

There are four prescaler settings, specified by bits
CCP1M3:CCP1M0. Whenever the CCP module is
turned off, or the CCP module is not in Capture mode,
the prescaler counter is cleared. Any RESET will clear
the prescaler counter.

Switching from one capture prescaler to another may
generate an interrupt. Also, the prescaler counter will
not be cleared, therefore, the first cap ture may be from
a non-zero prescaler. Example8-1 shows the recom­mended method for switching between capture pres­calers. This example also clears the prescaler counter
and will not generate the “false” interrupt.

FIGURE 8-1: CAPTURE MODE

OPERATION BLOCK
DIAGRAM

RC2/CCP1

pin

Prescaler
÷ 1, 4, 16

edge detect

Qs

Set Flag bit CCP1IF

and

CCP1CON<3:0>

(PIR1<2>)

CCPR1H CCPR1L

Capture
Enable

TMR1H TMR1L

EXAMPLE 8-1: CHANGING BETWEEN

CAPTURE PRESCALERS

CLRF CCP1CON ; Turn CCP module off
MOVLW NEW_CAPT_PS ; Load the W reg with

; the new prescaler
; move value and CCP ON

MOVWF CCP1CON ; Load CCP1CON with this

; value

 2001 Microchip Technology Inc. DS30292C-page 59

PIC16F87X

8.2 Compare Mode

In Compare mo de, th e 16- bit CCP R1 re gist er valu e is
constantly compared against the TMR1 register pair
value. When a match occurs, the RC2/C CP 1 pin is:

• Driven high

• Driven low

• Remains unchanged

The action on the pin is based on the value of control
bits CCP1M3:CCP1M0 (CCP1CON<3:0>). At the
same time, interrupt flag bit CCP1IF is set.

FIGURE 8-2: COMPARE MODE

OPERATION BLOCK
DIAGRAM

Special event trigger will:

reset Timer1, but not set interrupt flag bit TMR1IF (PIR1<0>),
and set bit GO/DONE (ADCON0<2>).

Special Event Trigger

Set Flag bit CCP1IF

RC2/CCP1

pin

TRISC<2>

Output Enable

QS

R

(PIR1<2>)

Output

Logic

CCP1CON<3:0>
Mode Select

CCPR1H CCPR1L

Match

Comparator

TMR1H TMR1L

8.2.2 TIMER1 MODE SELECTION

Timer1 must be running in Timer mode, or Synchro­nized Counter mode, if the CCP module is using the
compare feature. In Asynchronous Counter mode, the
compare operation may not work.

8.2.3 SOFTWARE INTERRUPT MODE

When Generate Sof tware Interrupt mod e is chosen, the
CCP1 pin is not affecte d. The CCPIF b it is set, c ausing
a CCP interrupt (if enabled).

8.2.4 SPECIAL EVENT TRIGGER

In this mode, an internal hardware trigger is gene rated,
which may be used to initiate an action.

The special event trigger output of CCP1 resets the
TMR1 regist er pai r. This al lows the CCPR 1 re gis ter to
effectively b e a 16-bit progra mmable period registe r for
Timer1.

The special event trigger output of CCP2 resets the
TMR1 register pai r and starts an A/D conv ersi on (if th e
A/D module i s enabled).

Note: The special event trigger from the

CCP1and CCP2 modul es w ill not set int er­rupt flag bit TMR1IF (PIR1<0>).

8.2.1 CCP PIN CONFIGURATION

The user must configure the RC2/CCP1 pin as an out­put by clearing the TRISC<2> bit.

Note: Clearing the CCP1CON register will force

the RC2/CCP1 compare output latch to the
default low level. This is not the PORT C I/O
data latch.

DS30292C-page 60  2001 Microchip Technology Inc.

PIC16F87X

8.3 PWM Mode (PWM)

In Pulse Width Modulation mode, the CCPx pin pro­duces up to a 10-bit resolution PWM output. Since the
CCP1 pin is multiplexed with the PORTC data latch,
the TRISC<2> bit must be cleared to make the CCP1
pin an output.

Note: Clearing the CCP1CON register will force

the CCP1 PWM output latch to the default
low level. This is not the PORTC I/O data
latch.

Figure 8-3 shows a simplified block diagram of the
CCP module in PWM mode.

For a step-by-step procedure on how to set up the C CP
module for PWM operation, see Section 8.3.3.

FIGURE 8-3: SIMPLIFIED PWM BLOCK

DIAGRAM

Duty Cycle Registers

CCPR1L

CCPR1H (Slave)

Comparator

TMR2

Comparator

PR2

Note 1: The 8-bit timer is concatenated with 2-bit internal Q

(Note 1)

Clear Timer,
CCP1 pin and
latch D.C.

clock, or 2 bits of the prescaler, to create 10-bit time­base.

A PWM output (Figure 8-4) has a time-base (period)
and a time that the output stays high (duty cycle). The
frequency of the PWM is the inverse of the period
(1/period).

FIGURE 8-4: PWM OUTPUT

Period

CCP1CON<5:4>

Q

R

S

TRISC<2>

RC2/CCP1

8.3.1 PWM PERIO D

The PWM period is specifi ed by writin g to the PR2 reg­ister. The PWM period can be calculated using the fol­lowing formula:

PWM period = [(PR2) + 1] • 4 • T

OSC •

(TMR2 prescal e va lu e)

PWM frequency is defined as 1 / [PWM period].
When TMR2 is eq ual to PR2, t he following three event s

occur on the ne xt increment cycle:

• TMR2 is cleared

• The CCP1 pin is set (exception: if PWM duty

cycle = 0%, the CCP1 pin will not be set)

• The PWM duty cycle is latc hed from CC PR1L into
CCPR1H

Note: The Tim er2 pos t sc al er (s ee Sec ti on 7.1) is

not used in the determination of the PWM
frequency. The pos tscaler c ould be used
to have a servo update rate at a different
frequency than the PWM output.

8.3.2 PWM DUTY CYCLE

The PWM duty cycle is specified by writing to the
CCPR1L register and to the CCP1CON<5:4> bits. Up
to 10-bit re so l uti on is av ai l ab le. T he CC PR 1L c on tai ns
the eight MSbs and the CCP1CON<5:4> contains the
two LSbs. This 10-bit value is represented by
CCPR1L:CCP1CON<5:4>. The following equation is
used to calculate the PWM duty cycle in time:

PWM duty cycle =(CCPR1L:CCP1CON<5:4>) •

OSC • (TMR2 prescale value)

T

CCPR1L and CCP1CON<5:4> can be written to at any
time, but the duty cycle value is not latched into
CCPR1H until after a match between PR2 and TMR2
occurs (i.e., the period is complete). In PWM mode,
CCPR1H is a read-only register.

The CCPR1H register and a 2-bit internal latch are
used to double buf fer the PWM duty cycle. Thi s doubl e
buffering is essential for glitch-free PWM operation.

When the CCPR 1H and 2 -bit latch match T MR2, con ­catenated with an internal 2-b it Q clo ck, or 2 bits of the
TMR2 prescaler, the CCP1 pin is cleared.

The maximum PWM resolution (bits) for a given PWM
frequency is given by the formula:

F

OSC

FPWM

log(2)

)

bits

log(

Duty Cycle

TMR2 = PR2

TMR2 = Duty Cycle

TMR2 = PR2

 2001 Microchip Technology Inc. DS30292C-page 61

Resolution

Note: If the PWM duty cycle value is longer than

the PWM period, the CCP1 pin will not be
cleared.

=

PIC16F87X

8.3.3 SETUP FOR PWM OPERATION

The following steps should be taken when configuring
the CCP module for PWM operation:

1. Set the PWM period by writing to the PR2
register.

3. Make the CCP1 pin an output by clearing the
TRISC<2> bit.

4. Set the TMR2 prescale value a nd enable T imer2
by writing to T2CON.

5. Configure the CCP1 module for PWM o peration.

2. Set the PWM duty cycle by writing to the
CCPR1L register and CCP1CON<5:4> bits.

TABLE 8-3: EXAMPLE PWM FREQUENCIES AND RESOLUTIONS AT 20 MHz

PWM Frequency 1.22 kHz 4.88 kHz 19.53 kHz 78.12kHz 156.3 kHz 208.3 kHz

Timer Prescaler (1, 4, 16) 16 4 1 1 1 1
PR2 Value 0xFFh 0xFFh 0xFFh 0x3Fh 0x1Fh 0x17h
Maximum Resolution (bits) 10 10 10 8 7 5.5

TABLE 8-4: REGISTERS ASSOCIATED WITH CAPTURE, COMPARE, AND TIMER1

Address Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

0Bh,8Bh,
10Bh, 18Bh

0Ch PIR1 PSPIF
0Dh PIR2 — — — — — — — CCP2IF ---- ---0 ---- ---0
8Ch PIE1 PSPIE
8Dh PIE2 — — — — — — — CCP2IE ---- ---0 ---- ---0
87h TRISC PORTC Data Direction Register 1111 1111 1111 1111
0Eh TMR1L Holding Register for the Least Significant Byte of the 16-bit TMR1 Register xxxx xxxx uuuu uuuu
0Fh TMR1H Holding Register for the Most Significant Byte of the 16-bit TMR1 Register xxxx xxxx uuuu uuuu
10h T1CON — — T1CKPS1 T1CKPS0 T1OSCEN T1SYNC TMR1CS TMR1ON --00 0000 --uu uuuu
15h CCPR1L Capture/Compare/PWM Register1 (LSB) xxxx xxxx uuuu uuuu
16h CCPR1H Capture/Compare/PWM Register1 (MSB) xxxx xxxx uuuu uuuu
17h CCP1CON — — CCP1X CCP1Y CCP1M3 CCP1M2 CCP1M1 CCP1M0 --00 0000 --00 0000
1Bh CCPR2L Capture/Compare/PWM Register2 (LSB) xxxx xxxx uuuu uuuu
1Ch CCPR2H Capture/Compare/PWM Register2 (MSB) xxxx xxxx uuuu uuuu
1Dh CCP2CON — — CCP2X CCP2Y CCP2M3 CCP2M2 CCP2M1 CCP2M0 --00 0000 --00 0000
Legend: x = unknown, u = unchanged, - = unimplemented, read as '0'. Shaded cells are not used by Capture and Timer1.

Note 1: The PSP is not implemented on the PIC16F873/876; always maintain these bits clear.

INTCON GIE PEIE

(1)

ADIF RCIF TXIF SSPIF CCP1IF TMR2IF TMR1IF 0000 0000 0000 0000

(1)

ADIE RCIE TXIE SSPIE CCP1IE TMR2IE TMR1IE 0000 0000 0000 0000

T0IE INTE RBIE T0IF INTF RBIF 0000 000x 0000 000u

Value o n:

POR,

BOR

Value o n

all other

RESETS

DS30292C-page 62  2001 Microchip Technology Inc.

TABLE 8-5: REGISTERS ASSOCIATED WITH PWM AND TIMER2

PIC16F87X

Address Name Bit 7 Bit 6 Bit 5 Bit 4 B it 3 Bit 2 Bit 1 Bit 0

0Bh,8Bh,
10Bh, 18Bh

0Ch PIR1 PSPIF
0Dh PIR2 — — — — — — — CCP2IF ---- ---0 ---- ---0
8Ch PIE1 PSPIE
8Dh PIE2 — — — — — — — CCP2IE ---- ---0 ---- ---0
87h TRISC PORTC Data Direc ti o n Re gi s ter 1111 1111 1111 1111
11h TMR2 Timer2 Module’s Registe r 0000 0000 0000 0000
92h PR2 Timer2 Mod ule ’s Period Register 1111 1111 1111 1111
12h T2CON — TOUTPS3 TOUTPS2 TOUTPS1 TOUTPS0 TMR2ON T2CKPS1 T2CKPS0 -000 0000 -000 0000
15h CCPR1L Captur e /Co mp ar e/ P WM Re gis t er1 (L SB) xxxx xxxx uuuu uuuu
16h CCPR1H Capt ur e/ Co mp ar e/P WM Reg is ter 1 (MS B) xxxx xxxx uuuu uuuu
17h CCP1CON — — CCP1X CCP1Y CCP1M3 CCP1M2 CCP1M1 CCP1M0 --00 0000 --00 0000
1Bh CCPR2L Capture/Co mpare/PWM Regis t er2 (L SB) xxxx xxxx uuuu uuuu
1Ch CCPR2H Capture/Compare/PWM Re gis ter 2 (MS B) xxxx xxxx uuuu uuuu
1Dh CCP2CON — — CCP2X CCP2Y CCP2M3 CCP2M2 CCP2M1 CCP2M0 --00 0000 --00 0000
Legend: x = unknown, u = unchanged, - = unimplemented, read as '0'. Shaded cells are not used by PWM and Timer2.

Note 1: Bits PSPIE and PSPIF are reserv ed on the PIC16F873/876; always maintain these bits clear.

INTCON GIE PEIE

(1)

ADIF RCIF TXIF SSPIF CCP1IF TMR2IF TMR1IF 0000 0000 0000 0000

(1)

ADIE RCIE TXIE SSPIE CCP1IE TMR2IE TMR1IE 0000 0000 0000 0000

T0IE INTE RBIE T0IF INTF RBIF 0000 000x 0000 000u

Value on:

POR,

BOR

Value on

all other

RESETS

 2001 Microchip Technology Inc. DS30292C-page 63

PIC16F87X

NOTES:

DS30292C-page 64  2001 Microchip Technology Inc.

9.0 MASTER SYNCHRONOUS

SERIAL PORT (MSSP)
MODULE

The Master Synchronous Serial Port (MSSP) module is
a serial interface, useful for communicating with other
peripheral or microc ontroll er dev ices. Th ese p eriphera l
devices may be serial EEPROMs, shift registers, dis­play drivers, A/D converters, etc. The MSSP module
can operate in one of two modes:

• Serial Peripheral Interface (SPI)

• Inter-Integrated Circuit (I

Figure 9-1 shows a block diagram for the SPI mode,
while Figure 9-5 and Figure 9-9 show the block dia­grams for the two different I

The Application Note AN734, “Using the PICmicro
SSP for Slave I2CTM Communication” describes the
slave operation of the MSSP module on the
PIC16F87X devices. AN735, “Using the PICmicro
MSSP Module for I2CTM Communications” describes
the master operation of the MSSP module on the
PIC16F87X devices.

2

C)

2

C modes of operation.

PIC16F87X

®

®

 2001 Microchip Technology Inc. DS30292C-page 65

PIC16F87X

REGISTER 9-1: SSPSTAT: SYNC SERIAL PORT STATUS REGISTER (ADDRESS: 94h)

R/W-0 R/W-0 R-0 R-0 R-0 R-0 R-0 R-0

SMP CKE D/A

bit 7 bit 0

PSR/WUA BF

bit 7 SMP

: Sample bi t

SPI Master mode:

1 = Input data sampled at end of data output time
0 = Input data sampled at middle of data output time

SPI Slave mode:
SMP must be cleared when SPI is used in slave mode

2

C Master or Slave mode:

In I

1 = Slew rate control disabled for standard speed mode (100 kHz and 1 MHz)
0 = Slew rate control enabled for high speed mode (400 kHz)

bit 6 CKE: SPI Clock Edge Select (Figure 9-2, Figure 9-3 and Figure 9-4)

SPI mode:
For CKP = 0

1 = Data transmitted on rising edge of SCK
0 = Data transmitted on falling edge of SCK

For CKP = 1

1 = Data transmitted on falling edge of SCK
0 = Data transmitted on rising edge of SCK

2

C Master or Slave mode:

In I

1 = Input levels conform to SMBus spec
0 = Input levels conform to I

bit 5 D/A: Data/Address

bit (I2C mode only)

2

C specs

1 = Indicates that the last byte received or transmitted was data
0 = Indicates that the last byte received or transmitted was address

bit 4 P: STOP bit

2

(I

C mode only. This bit is cleared when the MSSP module is disabled, SSPEN is cleared.)

1 = Indicates that a STOP bit has been detected last (this bit is ’0’ on RESET)
0 = STOP bit was not detected last

bit 3 S: START bit

2

(I

C mode only. This bit is cleared when the MSSP module is disabled, SSPEN is cleared.)

1 = Indicates that a START bit has been detected last (this bit is ’0’ on RESET)
0 = START bit was not detected last

2

bit 2 R/W: Read/Write bit Information (I

C mode only)

This bit holds the R/W bit information following the last address match. This bit is only valid from the
address match to the next START bit, STOP bit or not ACK

2

C Slave mode:

In I

bit.

1 = Read
0 = Write

2

C Master mode:

In I

1 = Transmit is in progress
0 = Transmit is not in progress

Logical OR of this bit with SEN, RSEN, PEN, RCEN, or ACKEN will indicate if t he MSSP is in IDLE mode.

2

bit 1 UA: Update Address (10-bit I

C mode only)

1 = Indicates that the user needs to update the address in the SSPADD register
0 = Address does not need to be updated

bit BF: Buffer Full Status bit

Receive (SPI and I

2

C modes):

1 = Receive complete, SSPBUF is full
0 = Receive not complete, SSPBUF is empty

Transmit (I

2

C mode only):

1 = Data transmit in progress (does not include the ACK and STOP bits), SSPBUF is full
0 = Data transmit complete (does not include the ACK and STOP bits), SSPBUF is empty

Legend:
R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’

- n = Value at POR ’1’ = Bit is set ’0’ = Bit is cleared x = Bit is unknown

DS30292C-page 66  2001 Microchip Technology Inc.

PIC16F87X

REGISTER 9-2: SSPCON: SYNC SERIAL PORT CONTROL REGISTER (ADDRESS 14h)

R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0

WCOL SSPOV SSPEN CKP SSPM3 SSPM2 SSPM1 SSPM0

bit 7 bit 0

bit 7 WCOL: Write Collision Detect bit

Master mode:

1 = A write to SSPBUF was attempted while the I2C conditions were not valid
0 = No collision

Slave mode:

1 = SSPBUF register is written while still transmitting the previous word (must be cleared in

software)

0 = No collision

bit 6 SSPOV: Receive Overflow Indicator bit

In SPI mode:

1 = A new byte is received while SSPBUF holds previous data. Data in SSPSR is lost on overflow. In Slave

0 = No overflow

2

In I

1 = A byte is received while the SSPBUF is holding the previous byte. SSPOV is a "don’t care" in Transmit
0 = No overflow

bit 5 SSPEN: Synchronous Serial Port Enable bit

In SPI mode
When enabled, these pins must be properly configured as input or output

1 = Enables serial port and configures SCK, SDO, SDI, and SS as the source of the serial port pins
0 = Disables serial port and configures these pins as I/O port pins

2

In I
When enabled, these pins must be properly configured as input or output

1 = Enables the serial port and configures the SDA and SCL pins as the source of the serial port pins
0 = Disables serial port and configures these pins as I/O port pins

bit 4 CKP: Clock Polarity Select bit

In SPI mode:

1 = Idle state for clock is a high level
0 = Idle state for clock is a low level

2

In I
SCK release control

1 = Enable clock
0 = Holds clock low (clock stretch). (Used to ensure data setup time.)

2

In I
Unused in this mode

bit 3-0

SSPM3:SSPM0: Synchronous Serial Port Mode Select bits

0000 = SPI Master mode, clock = FOSC/4
0001 = SPI Master mode, clock = FOSC/16
0010 = SPI Master mode, clock = FOSC/64
0011 = SPI Master mode, clock = TMR2 output/2
0100 = SPI Slave mode, clock = SCK pin. SS pin control enabled.
0101 = SPI Slave mode, clock = SCK pin. SS pin control disabled. SS can be used as I/O pin.
0110 = I
0111 = I
1000 = I
1011 = I
1110 = I
1111 = I
1001, 1010, 1100, 1101 = Reserved

mode, the user must read the SSPBUF, even if only transmitting data, to avoid overflows. In Master
mode, the overflow bit is not set, since each operation is initiated by writing to the SSPBUF register.
(Must be cleared in software.)

C mode:

mode. (Must be cleared in software.)

,

C mode,

C Slave mode:

C Master mode:

2

C Slave mode, 7-bit address

2

C Slave mode, 10-bit address

2

C Master mode, clock = FOSC / (4 * (SSPADD+1))

2

C Firmware Controlled Master mode (slave idle)

2

C Firmware Controlled Master mode, 7-bit address with START and STOP bit interrupts enabled

2

C Firmware Controlled Master mode, 10-bit address with START and STOP bit interrupts enabled

Legend:
R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’

- n = Value at POR ’1’ = Bit is set ’0’ = Bit is cleared x = Bit is unknown

 2001 Microchip Technology Inc. DS30292C-page 67

PIC16F87X

REGISTER 9-3: SSPCON2: SYNC SERIAL PORT CONTROL REGISTER2 (ADDRESS 91h)

R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0

GCEN ACKSTAT ACKDT ACKEN RCEN PEN RSEN SEN

bit 7 bit 0

2

bit 7 GCEN: General Call Enable bit (In I

1 = Enable interrupt when a general call address (0000h) is received in the SSPSR
0 = General call address disabled

bit 6 ACKSTAT: Acknowledge Status bit (In I

In Master Transmit mode:

1 = Acknowledge was not received from slave
0 = Acknowledge was received from slave

bit 5 ACKDT: Acknowledge Data bit (In I

In Master Receive mode:
Value that will be transmitted when the user initiates an Acknowledge sequenc e at the
end of a receive.

1 = Not Acknowledge
0 = Acknowledge

bit 4 ACKEN: Acknowledge Sequence Enable bit (In I

In Master Receive mode:
1 = Initiate Acknowledge sequence on SDA and SCL pins and transmit ACKDT data bit.

Automatically cleared by hardware.

0 = Acknowledge sequence idle

bit 3 RCEN: Receive Enable bit (In I

1 = Enables Receive mode for I
0 = Receive idle

bit 2 PEN: STOP Condition Enable bit (In I

SCK Release Control:

1 = Initiate STOP condition on SDA and SCL pins. Automatically cleared by hardware.
0 = STOP condition idle

bit 1 RSEN: Repeated START Condition Enable bit (In I

1 = Initiate Repeated START cond ition on SDA and SCL pins. Automatically cleared by hardware.
0 = Repeated START condition idle

bit 0 SEN: START Conditi on Enab le bit (In I2C Master mode only)

1 = Initiate START condition on SDA and SCL pins. Automatically cleared by hardware.
0 = START condition idle

C Slave mode only)

2

C Master mode only)

2

C Master mode only)

2

2

C Master mode only)

2

C

2

C Master mode only)

C Master mode only)

2

C Master mode only)

Note: For bits ACKEN, RCEN, PEN, RSEN, SEN: If the I

2

C module is not in the IDLE
mode, this bit may no t be set (no spooling), an d t he SSPBUF m ay n ot be writte n (or
writes to the SSPBUF are disabled).

Legend:
R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’

- n = Value at POR ’1’ = Bit is set ’0’ = Bit is cleared x = Bit is unknown

DS30292C-page 68  2001 Microchip Technology Inc.

PIC16F87X

9.1 SPI Mode

The SPI mode allo ws 8 bits of data to be sync hronously
transmitted and received simultaneously. All four
modes of SPI are supported. To accomplish communi­cation, typically three pins are used:

• Serial Data Out (SDO)

• Serial Data In (SDI)

• Serial Clock (SCK)

Additionally, a fourth pin may be used when in a Slave
mode of operation:

• Slave Select (SS
When initializing the SPI, several options need to be

specified. This is done by pro gramming th e appropriate
control bits (SSPCON<5:0> and SSPSTAT<7:6>).
These control bits allow the following to be specified:

• Master mode (SCK is the clock output)

• Slave mode (SCK is the clock input)

• Clock Polarity (Idle state of SCK)

• Data input sample phase

(middle or end of data output time)

• Clock edge
(output data on rising/falling edge of SCK)

• Clock Rate (Master mode only)

• Slave Select mode (Slave mode only)

Figure 9-4 shows the block diagram of th e MSSP mod­ule when in SPI mode.

To enable the serial port, MSSP Enable bit, SSPEN
(SSPCON<5>) must be set. T o reset or rec onfigure SPI
mode, clear bit SSPEN, re-initialize the SSPCON reg­isters, and then set bit SSPEN. This configures the
SDI, SDO, SCK and SS
pins to behave as the serial port function, some must
have their data direction bits (in the TRIS register)
appropriately programmed. That is:

• SDI is automaticall y controlled by the SPI module

• SDO must have TRISC<5> cleared

• SCK (Master mode) must have TRISC<3>

cleared

• SCK (Slave mode) must have TRISC<3> set

must have TRISA<5> set and register

• SS
ADCON1 (see Section11.0: A/D Mo dule) must be
set in a way that pin RA5 is confi gured a s a dig it al
I/O

)

pins as serial port pins. Fo r the

Any serial port function that is not desired may be
overridden by programming the corresponding data
direction (TRIS) register to the opposite value.

FIGURE 9-1: MSSP BLOCK DIAGRAM

(SPI MODE)

Internal

Data Bus

Read Write

SSPBUF Reg

SSPSR Reg

SDI

SDO

SS

SCK

SS

Edge

Select

SMP:CKE

bit0

Control
Enable

Select

Clock Select

SSPM3:SSPM0

4

2

Edge

Data to TX/RX in SSPSR

Data Direction bit

Shift

Clock

2

TMR2 Output

2

T

Prescaler

4, 16, 64

OSC

 2001 Microchip Technology Inc. DS30292C-page 69

PIC16F87X

9.1.1 MASTER MODE

The master can initiate the data transfer at any time
because it controls the SCK. The master determines
when the slave (Processor 2, Figure 9-5) is to broad­cast data by the software protoc ol.

In Master mode, the data is transmitted/received as
soon as the SSPBUF register is written to. If the SPI
module is only going to receive, the SDO output could
be disabled (programmed as an input). The SSPSR
register will conti nue to shif t in the signa l present o n the
SDI pin at the programmed clock rate. As each byte is
received, it will be loaded into the SSPBUF register as
if a normal received byte (interrupts and status bits
appropriately set). This could be useful in receiver
applications as a “line activity monitor”.

The clock polarity is selected by appropriately program­ming bit CKP (SSPCON<4>). This then, would give
waveforms for SPI communication as shown in

FIGURE 9-2: SPI MODE TIMING, MASTER MODE

SCK (CKP = 0,

CKE = 0)

SCK (CKP = 0,

CKE = 1)

SCK (CKP = 1,

CKE = 0)

SCK (CKP = 1,

CKE = 1)

Figure 9-6, Figure 9-8 and Figure 9-9, where the MSb is
transmitted first. In Master mode, the SPI clock rate (bit
rate) is user programmable to be one of the following:

OSC/4 (or TCY)

• F

• F

OSC/16 (or 4 • TCY)

• FOSC/64 (or 16 • TCY)

• Timer2 output/2

This allows a maximu m bit clock freq uency (at 20 MHz)
of 5.0 MHz.

Figure 9-6 shows the waveforms for Master mode.
When CKE = 1, the SDO data is valid before there is a
clock edge on SCK. The change of the input sample is
shown based on the state of the SMP bit. The time
when the SSPBUF is loaded with the received data is
shown.

SDO

SDI (SMP = 0)

SDI (SMP = 1)

SSPIF

bit7 bit6 bit5

bit7

bit7 bit0

bit4

bit3

bit2

bit1 bit0

bit0

DS30292C-page 70  2001 Microchip Technology Inc.

PIC16F87X

9.1.2 SLAVE MODE

In Slave mode, the data is tra nsmitted and r eceived as
the external clock pulses ap pea r on SCK . Wh en the last
bit is latched, the interrupt flag bit SSPIF (PIR1<3>) is set.

While in Slave mode, the external clock is supplied by
the external clock source on the SCK pin. This external
clock must meet the minimum high and low times as
specified in the electrical specifications.

While in SLEEP mode, the slave can transmit/receive
data. When a byte is received, the device will wake-up
from SLEEP.

Note 1: When the SPI module is in Slave

mode with SS
(SSPCON<3:0> = 0100), the SPI module
will reset if the SS pin is set to VDD.

2: If the SPI is used in Slave mode with

CKE = ’1’, then SS
enabled.

FIGURE 9-3: SPI MODE TIMING (SLAVE MODE WITH CKE = 0)

SS (optional)

SCK (CKP = 0)
SCK (CKP = 1)

SDO

bit7

bit6 bit5

bit4

bit3

bit2

pin control enabled

pin control must be

bit1 bit0

SDI (SMP = 0)

bit7 bit0

SSPIF

FIGURE 9-4: SPI MODE TIMING (SLAVE MODE WITH CKE = 1)

SS

SCK (CKP = 0)
SCK (CKP = 1)

SDO

SDI (SMP = 0)

SSPIF

bit7

bit7 bit0

bit6 bit5

bit4

bit3

bit2

bit1 bit0

 2001 Microchip Technology Inc. DS30292C-page 71

PIC16F87X

TABLE 9-1: REGISTERS ASSOCIATED WITH SPI OPERATION

Address Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

0Bh, 8Bh,
10Bh,18Bh

0Ch PIR1 PSPIF
8Ch PIE1 PSPIE
13h SSPBUF Synchronous Serial Port Receive Buffer/Transmit Register xxxx xxxx uuuu uuuu
14h SSPCON WCOL SSPOV SSPEN CKP SSPM3 SSPM2 SSPM1 SSPM0 0000 0000 0000 0000

94h SSPSTA T SMP CKE D/A P S R/W UA BF 0000 0000 0000 0000
Legend: x = unknown, u = unchanged, - = unimplemented, read as ’0’. Shaded cells are not used by the SSP in SPI mode.

Note 1: These bits are reserved on PCI16F873/876 devices; always maintain these bits clear.

INTCON GIE PEIE

(1)

ADIF RCIF TXIF SSPIF CCP1IF TMR2IF TMR1IF 0000 0000 0000 0000

(1)

ADIE RCIE TXIE SSPIE CCP1IE TMR2IE TMR1IE 0000 0000 0000 0000

T0IE INTE RBIE T0IF INTF RBIF 0000 000x 0000 000u

Value on:

POR, BOR

Value on:

MCLR

, WDT

DS30292C-page 72  2001 Microchip Technology Inc.

PIC16F87X

9.2 MSSP I2C Operation

The MSSP module in I2C mode, fully implements all
master and slav e functions (incl uding general call sup­port) and provides interrupts on ST AR T and STO P bits in
hardware, to determine a free bus (multi-master func­tion). The MSSP modul e im plemen ts the s ta ndard m ode
specification s, as wel l as 7-bit and 10-bi t addre ssin g.

Refer to Application Note AN578, "Use of the SSP

Module in the I

A "glitch" filter is on the SCL and SDA pins when the pi n
is an input. This fil ter operates in both the 100 kHz and
400 kHz modes. In the 10 0 kHz mode, whe n these pin s
are an output, there is a sle w rate control of the pin that
is independent of device frequency.

FIGURE 9-5: I2C SLAVE MODE BLOCK

SCL

SDA

Two p ins a re use d for dat a tra nsfer. These a re the SCL
pin, which is the clock, and the SDA pin, which is the
data. The SDA and SCL pins are automatically config­ured when the I
functions are enabled by setting SSP Enable bit
SSPEN (SSPCON<5>).

The MSSP module has six registers for I
They are the:

• SSP Control Register (SSPCON)

• SSP Control Register2 (SSPCON2)

• SSP Status Register (SSPSTAT)

• Serial Receive/Transmit Buffer (SSPBUF)

• SSP Shift Register (SSPSR) - Not directly

accessible

• SSP Address Register (SSPADD)

2

C Multi-Master Environment."

DIAGRAM

Internal

Data Bus

Read Write

SSPBUF Reg

Shift

Clock

SSPSR Reg

MSb

Match Detect

SSPADD Reg

START and

STOP bit Detect

2

C mode is enabled. The SSP module

LSb

(SSPSTAT Reg)

2

Addr Match

Set, Reset
S, P bits

C operation.

The SSPCON register allows control of the I
tion. Four mode selection bits (SSPCON<3:0>) allow
one of the following I

2

C Slave mode (7-bit address)

• I

2

• I

C Slave mode (10-bit address)

2

C modes to be selected:

2

C opera-

• I2C Master mode, cl ock = OSC/4 (SSPADD +1)

2

• I

C firmware modes (provided for compatibility to

other mid-range product s)

2

Before selecting any I
must be programmed to inputs by setting the appropri­ate TRIS bits. Selecting an I
SSPEN bit, enables the SCL and SDA pins to be used
as the clock and data lines in I

C mode, the SCL and SDA pins

2

C mode by setting the

2

C mode. Pu ll -u p res i s­tors must be provided externally to the SCL and SDA
pins for the proper operation of the I2C module.

The CKE bit (SSPSTAT<6:7>) sets the levels of the
SDA and SCL pins in either Master or Slave mode.
When CKE = 1, the levels will conform to the SMBus
specification. W hen C KE = 0 , th e le vels will conform to

2

C specification.

the I
The SSPSTAT register gives the status of the data

transfer. This information includes detection of a
START (S) or STOP (P) bit, specifies if the received
byte was data or address, if the next byte is the com­pletion of 10-bit address, and if this will be a read or
write data transfer.

SSPBUF is the register to which the transfer data is
written to, or read from. The SSPSR register shifts the
data in or out of the device. In re ceive oper atio ns, the
SSPBUF and SSPSR create a doubled buffered
receiver . This allo ws reception of the next by te to begin
before reading the last by te of receiv ed data. Wh en the
complete byte is received, it is transferred to the
SSPBUF register and flag bit SSPIF is set. If another
complete byte is received before the SSPBUF register
is read, a receiver overflow has occurred and bit
SSPOV (SSPCON<6>) is set and the byte in the
SSPSR is lost.

The SSPADD register holds the slave address. In
10-bit mode, the use r needs to write th e high byte of the
address (1111 0 A9 A8 0). Following the high byte
address match, the l ow byte of the address needs to be
loaded (A7:A0).

 2001 Microchip Technology Inc. DS30292C-page 73

PIC16F87X

9.2.1 SLAVE MODE

In Slave mode, the SCL and SDA pins must be confi g­ured as inputs. The MSSP module will override the
input state with the output data, when required (slave­transmitter).

When an address is matched, or the data transfer af ter
an address m atch i s re ceiv ed, the ha rd ware autom ati ­cally will generate the Acknowledge (ACK
then load the SSPBUF register with th e re ce ive d valu e
currently in the SSPSR register.

There are certain conditions that will cause the MSSP
module not to give thi s ACK
(or both):

a) The buffer full bit BF (SSPSTAT<0>) was set

before the transfer was received.

b) The overflow bit SS POV (SSPCON<6>) was set

before the transfer was received.

If the BF bit is set, the SSPSR register value is not
loaded into the SSPBUF, but bit SSPIF and SSPOV are
set. Table 9-2 shows what happens when a data trans­fer byte is received, given the status of bits BF and
SSPOV. The shaded cells show the condition where
user software d id no t prope rly c lear th e ove rflow cond i­tion. Flag bit BF is cleared by read ing the SSPBUF reg­ister, while bit SSPOV is cleared through software.

The SCL clock input must have a minimum high and
low time for proper operation. The high and low times

2

of the I
the MSSP module, is shown in timing parameter #100
and parameter #101 of the electrical specifications.

C specification, as well as the requirement of

pulse. These are if either

) pulse, and

9.2.1.1 Addressing

Once the MSSP module has been enabled, it waits for
a ST AR T co ndition to o ccur. Following the START co n­dition, the 8-bits are shif ted into the SSPSR register. All
incoming bits are sampled with the rising edge of the
clock (SCL) line. The value of register SSPSR<7:1> is
compared to the value of the SSPADD register. The
address is compared on the falling edge of the eighth
clock (SCL) pulse. If the addresses match, and the BF
and SSPOV bits are clear, the following events occur:

a) The SSPSR register value is loaded into the

SSPBUF register on the falling edge of the 8th
SCL pulse.

b) The buffer full bit, BF, is set on the falling edge

of the 8th SCL pulse.
c) An ACK pulse is generated.
d) SSP interrupt flag bit, SSPIF (PIR1<3>), is set

(interrupt is generated if enabled) on the falling

edge of the 9th SCL pulse.
In 10-bit address mode, two address bytes need to be

received by the slave. The five Most Significant bits
(MSbs) of the first address byte specify if this is a 10-bit
address. Bit R/W
the slave device will receive the second address byte.

(SSPSTA T<2>) must specify a write so

For a 10-bit address, the first byte would equal
‘1111 0 A9 A8 0’, where A9 and A8 are the two MSbs
of the address. The sequence of events for a 10-bit
address is as follows, with steps 7-9 for slave-transmitter:

1. Receive first (high) byte of Address (bits SSPIF,
BF and UA (SSPSTAT<1>) are set).

2. Update the SSPADD register with the second
(low) byte of Address (clears bit UA and
releases the SCL line).

3. Read the SSPBUF register (clears bit BF) and
clear flag bit SSPIF.

4. Receive second (low) byte of Address (bits
SSPIF, BF and UA are set).

5. Update the SSPADD register wi th the firs t (hig h)
byte of Address. This will clear bit UA and
release the SCL line.

6. Read the SSPBUF register (clears bit BF) and
clear flag bit SSPIF.

7. Receive Repeated Start condition.

8. Receive first (high) byte of Address (bits SSPIF
and BF are set).

9. Read the SSPBUF register (clears bit BF) and
clear flag bit SSPIF.

Note: Following the Repeated START condition

(step 7) in 10-bit mode, the user only
needs to match the fi rst 7-bit ad dress. The
user does not update the SSPADD for the
second half of the address.

9.2.1.2 Slave Reception

When the R/W bit of the address byte is clear and an
address match occurs, the R/W
register is cleared. Th e receive d addre ss is loa ded in to
the SSPBUF register.

When the address byte overflow condition exists, then
no Acknowledge (ACK
condition is defined as either bit BF (SSPSTAT<0>) is
set, or bit SSPOV (SSPCON<6>) is set. Thi s is an error
condition due to user firmware.

An SSP interrupt is generated for each data transfer
byte. Flag bit SSPIF (PIR1<3>) must be cleared in sof t­ware. The SSPSTAT register is used to determine the
status of the received byte.

Note: The SSPBUF will be loaded if the SSPOV

bit is set and the BF flag is cleared. If a
read of the SSPBUF was performed, but
the user did not clear the state of the
SSPOV bit before the next receive
occurred, the ACK
SSPBUF is updated.

) pulse is given. An overflow

bit of the SSPSTAT

is not sent and the

DS30292C-page 74  2001 Microchip Technology Inc.

TABLE 9-2: DATA TRANSFER RECEIVED BYTE ACTIONS

PIC16F87X

Status Bits as Data

Transfer is Received

BF SSPOV

SSPSR

→ SSPBUF

Generate ACK

Pulse

Set bit SSPIF

(SSP Interrupt occurs

if enabled)

0 0 Yes Yes Yes
1 0 No No Yes
1 1 No No Yes
0 1 Yes No Yes

Note: Shaded cells show the conditions where the user software did not properly clear the overflow condition.

9.2.1.3 Slave Transmission

When the R/W bit of the incoming address byte is set
and an address match occurs, the R/W
SSPSTAT register is set. The received address is
loaded into the SSPBUF register. The ACK
be sent on the ninth bit, and the SCL pin is held low.
The transmit data must be loaded into the SSPBUF
register, which also loads the SSPSR register. Then,
the SCL pin should be enabled by setting bit CKP
(SSPCON<4>). The master must monitor the SCL pin
prior to asserting another clock pulse. The slave
devices may be holding off the master by stretching the
clock. The eight data bits are shifted out on the falling
edge of the SCL input. This ensures that the SDA sig­nal is vali d during the SCL high ti me (Figur e 9-7).

bit of the

pulse will

An SSP interrupt is generated for each data transfer
byte. The SSPIF flag bit must be cleared in software
and the SSPST AT register is used to determine the sta­tus of the byte tran sf er. The SSPIF fl ag bi t is set on the
falling edge of the ninth clock pulse.

As a slave-transmitter, the ACK

pulse from the master
receiver is latched on the rising edge of the ninth SCL
input pulse. If the SDA line is high (not ACK), then the
data transfer is comple te. Whe n the n ot ACK

is latched
by the slave, the slave logic is reset and the slave then
monitors for another occurrence of the START bit. If the
SDA line was low (ACK

), the transmit data must be
loaded into the SSPBUF register, which also loads the
SSPSR register. Then the SCL pin should be enabled
by setting the CKP bit.

FIGURE 9-6: I2C WAVEFORMS FOR RECEPTION (7-BIT ADDRESS)

Receiving Address

A7 A6 A5 A4

1234

S

SCL

SSPIF

BF (SSPSTAT<0>)

SSPOV (SSPCON<6>)

A3 A2 A1SDA

5

R/W=0

ACK

7

6

9

8

Receiving Data

D5

D6D7

1234

Cleared in software

SSPBUF register is read

Bit SSPOV is set because the SSPBUF register is still full.

D2

D3D4

56

D1

7

ACK

D0

89

Receiving Data

D5

D6D7

123

4

ACK is not sent.

Not

ACK

D0

D2

D3D4

D1

9

5

8

7

6

P

Bus Master
Terminates
Transfer

 2001 Microchip Technology Inc. DS30292C-page 75

PIC16F87X

FIGURE 9-7: I2C WAVEFORMS FOR TRANSMISSION (7-BIT ADDRESS)

= 1

R/W

ACK

Transmitting Data

D7 D6 D5 D4 D3 D2 D1 D0

SDA

Receiving Address

A7 A6 A5 A4 A3 A2 A1

= 0

R/W

Not ACK

SCL

SSPIF
BF (SSPSTAT<0>)

CKP (SSPCON<4>)

123456789 123456789

S

Data in
sampled

9.2.2 GENERAL CALL ADDRESS SUPPORT

The addressing procedure for the I2C bus is such that
the first byte after the START condition usually deter­mines which device will be the slave addressed by the
master. The exception is the gene ral call address , which
can address all devices. When this address is used, all
devices should, in theory , respond with an acknowledge.

The general call address is one of eight addresses
reserved for specific purposes by the I
consists of all 0’s with R/W

= 0.

The general call address is recognized when the Gen­eral Call Enable bit (GCEN) is enabled (SSPCON2<7>
is set). Following a START bit detect, 8 bits are shifted
into SSPSR and the address is compared against
SSPADD. It is also compared to the general call
address and fixed in hardware.

2

C protocol. It

SCL held low
while CPU

responds t o SSPIF

If the general call address matches, the SSPSR is
transferred to the SSPBUF, the BF flag is set (eighth
bit), and on the falling edge of the ninth bit (ACK
the SSPIF flag is set.

When the interrupt is serv ic ed, the s ou r ce f or the int er­rupt can be checked by reading the contents of the
SSPBUF to determine if the address was device spe­cific, or a general call address.

In 10-bit mode, the SSPADD is required to be updated
for the second half of the address to match , and the UA
bit is set (SSPSTAT<1>). If the general call address is
sampled when GCEN is set, while the slave is config­ured in 10-bit address mode, then the second half of
the address is not ne cessary , the UA bit will n ot be set,
and the slave will begin receiving data after the
Acknowledge (Figure9-8).

Cleared in software

SSPBUF is written in software

Set bit after writing to SSPBUF
(the SSPBUF must be written to,
before the CKP bit can be set)

From SSP Interrupt

Service Routine

P

bit),

FIGURE 9-8: SLAVE MODE GENERAL CALL ADDRESS SEQUENCE (7 OR 10-BIT MODE)

Address is compared to General Call Address
after ACK, set interrupt flag

= 0

SDA

SCL

S

SSPIF

BF
(SSPSTAT<0>)

SSPOV
(SSPCON<6>)

GCEN
(SSPCON2<7>)

DS30292C-page 76  2001 Microchip Technology Inc.

General Call Address

123456789123456789

R/W

ACK

D7 D6 D5 D4 D3 D2 D1 D0

Receiving data

Cleared in software
SSPBUF is read

ACK

’0’

’1’

PIC16F87X

9.2.3 SLEEP OPERATION

While in SLEEP mode, the I2C module can receive
addresses or data. When an address match or com-

9.2.4 EFFECTS OF A RESET

A RESET disables the SSP module and terminates the

current tran sfer.
plete byte transfer occurs, wake the processor from
SLEEP (if the SSP interrupt is enabled).

TABLE 9-3: REGISTERS ASSOCIATED WITH I2C OPERATION

Address Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

0Bh, 8Bh,
10Bh,18Bh

0Ch PIR1 PSPIF
8Ch PIE1 PSPIE

0Dh PIR2 — (2) — EEIF BCLIF — — CCP2IF -r-0 0--0 -r-0 0--0
8Dh PIE2 — (2) — EEIE BCLIE — — CCP2IE -r-0 0--0 -r-0 0--0
13h SSPBUF Synchronous Serial Port Receive Buffer/Transmit Register xxxx xxxx uuuu uuuu
14h SSPCON WCOL SSPOV SSPEN CKP SSPM3 SSPM2 SSPM1 SSPM0 0000 0000 0000 0000
91h SSPCON2 GCEN ACKSTAT ACKDT ACKEN RCEN PEN RSEN SEN 0000 0000 0000 0000

93h SSPADD I2C Slave Address/Master Baud Rate Register 0000 0000 0000 0000
94h SSPSTAT SMP CKE D/A PSR/WUA BF 0000 0000 0000 0000

Legend: x = unknown, u = unchanged, - = unimplemented, read as '0'. Shaded cells are not used by the SSP in I2C mode.
Note 1: These bits are reserved on PIC16F873/876 devices; always maintain these bits clear.

INTCON GIE PEIE

(1)

ADIF RCIF TXIF SSPIF CCP1IF TMR2IF TMR1IF 0000 0000 0000 0000

(1)

ADIE RCIE TXIE SSPIE CCP1IE TMR2IE TMR1IE 0000 0000 0000 0000

2: These bits are reserved on these devices; always maintain these bits clear.

T0IE INTE RBIE T0IF INTF RBIF 0000 000x 0000 000u

Value on:

POR, BOR

Value on:

MCLR,

WDT

 2001 Microchip Technology Inc. DS30292C-page 77

PIC16F87X

9.2.5 MASTER MODE

Master mode of operation is supported by interrupt
generation on the detection of the START and STOP
conditions. The STOP (P) and START (S) bits are
cleared from a RESET, or when the MSSP module is
disabled. Control of the I
P bit is set, or the bus is idle, with bo th the S and P bit s
clear.

2

C bus may be t aken when th e

The following events will cause the SSP Interrupt Flag
bit, SSPIF, to be set (an SSP interrupt will occur if
enabled):

• START condition

• STOP condition

• Data transfer byte transmitted/received

• Acknowledge transmit

• Repeated START

In Master mode, the SCL and SDA lines are manipu­lated by the MSSP hardware.

FIGURE 9-9: SSP BLOCK DIAGRAM (I2C MASTER MODE)

Internal

Data Bus

Read Write

SSPBUF

LSb

Shift

Clock

SDA

SCL

SDA in

SSPSR

MSb

START bit, STOP bit,

Acknowledge

Generate

Receive Enable

Clock Cntl

SSPM3:SSPM0,

SSPADD<6:0>

Baud
Rate
Generator

(hold off clock source)

Clock Arbitrate/WCOL Detect

START bit Detect,

SCL in
Bus Collision

STOP bit Detect

Write Collision Detect

Clock Arbitration

State Counter for

end of XMIT/RCV

9.2.6 MULTI-MASTER MODE

In Multi-Master mode, the interrupt generation on the
detection o f the START and STOP conditions al lows
the determination of when the bus is free. The STOP
(P) and START (S) bits are cleared from a RESET or
when the MSSP module is disabled . Control of the I
bus may be taken when bit P (SSPSTAT<4>) is set, or
the bus is idle with both the S and P bits clear. When
the bus is busy, enabling the SSP Interrupt will gener­ate the interrupt when the STOP condition occurs.

2

Set/Reset, S, P, WCOL (SSPSTAT)
Set SSPIF, BCLIF

Reset ACKSTAT, PEN (SSPCON2)

In Multi-Master operation, the SDA line must be moni­tored for arbitration to see if the signal level is the
expected output leve l. This chec k is performe d in hard­ware, with the result placed in the BCLIF bit.

The states where arbitration can be lost are:

C

• Address Trans fer

• Data Transfer

• A START Condition

• A Repeated START Condition

• An Acknowledge Condition

DS30292C-page 78  2001 Microchip Technology Inc.

PIC16F87X

9.2.7 I2C MASTER MODE SUPPORT

Master mode is enabled by setting and clearing the
appropriate SSPM bits in SSPCON and by setting the
SSPEN bit. Once Master mode is enabled, the user
has six options:

• Assert a START condition on SDA and SCL.

• Assert a Repeated START condition on SDA and

SCL.

• Write to the SSPBUF register initiating transmis-

sion of data/address.

• Generate a STOP condition on SDA and SCL.

2

• Configure the I

C port to receive data.

• Generate an Acknowled ge cond ition at the end of

a received byte of data.
Note: The MSSP Module, when confi gured in I2C

Master mode, does not allow queueing of
events. For instance, the user is not
allowed to initiate a START condition and
immediately write the SSPBUF register to
initiate transmission before the START
condition is complete. In this case, the
SSPBUF will not be written to and the
WCOL bit will be set, indicating that a write
to the SSPBUF did not occur.

9.2.7.1 I2C Master Mode Operation

The master device generates all of the serial clock
pulses and the START and STOP conditions. A trans­fer is ended with a STOP condition or with a Repeated
START condition. Since the Re peated START condi­tion is also the beginning of the next s eri al transfer, th e

2

C bus will not be released.

I
In Master Transmitter mode, serial data is output through

SDA, while SCL outputs the serial cl ock. The first by te
transmitted con tains the slave addres s of the receiving
device (7 bit s) and t he Re ad/W rite (R/W
the R/W

bit will be logic '0'. Serial data is transmitted 8 bits
at a time. After each byte is transmitted, an Acknowledge
bit is received. START and STOP conditions are output
to indicate the beginning and the end of a serial transfer.

In Master Receive mode, the firs t byte transmitt ed con­tains the slave address of the transmitting device
(7 bits) and the R/W

bit. In this case, the R/W bit will be
logic '1'. Thus, the first byte transmitted is a 7-bit slave
address foll owed by a '1' to indicat e recei ve bit. Serial
data is receiv ed vi a SDA , whi le SC L outp uts th e ser ial
clock. Serial dat a is rec eived 8 bits at a tim e. Aft er each
byte is received, an Acknowledge bit is transmitted.
START and STOP conditions indicate the beginning
and end of transmission.

The baud rate generator used for SPI mode operation
is now used to set the SCL clock frequency for either
100 kHz, 400 kHz, or 1 MHz I
rate generator reload value is contained in the lower 7
bits of the SSPADD register. The baud rate generator
will automatically begin counting on a write to the

) bit. In this case ,

2

C operation. The baud

SSPBUF. Once the given operation is complete (i.e.,
transmission of the last d ata bit is followed b y ACK), the
internal clock will automatically stop counting and the
SCL pin will remain in its last state.

A typical transmit sequence would go as follows:
a) User generates a START condition by setting

the START enable bit (SEN) in SSPCON2.

b) SSPIF is set. The module will wait the required

start time before any other operation takes place.
c) User loads SSPBUF with address to transmit.
d) Address is s hi f ted o ut the SDA pin until all 8 bits

are transmitted.
e) MSSP module shifts in the ACK bit from the

slave device and writes its value into the

SSPCON2 register (SSPCON2<6>).
f) MSSP module generates an interrupt at the end

of the ninth clock cycle by setting SSPIF.
g) User loads SSPBUF with eight bits of data.
h) DA T A is shifted out the SDA pin unti l all 8 bit s are

transmitted.
i) MSSP module shifts in the ACK bit from the

slave device, and writes its value into the

SSPCON2 register (SSPCON2<6>).
j) MSSP module generat es an interru pt at t he end

of the ninth clock cycle by setting the SSPIF bit.
k) User generates a STOP conditi on by setting the

STOP enable bit, PEN, in SSPCON2.
l) Interrupt is generated once the STOP condition

is complete.

9.2.8 BAUD RATE GENERATOR

In I2C Master mode, the reload value for the BRG is
located in the lower 7 bits of the SSPADD register
(Figure 9-10). When the BRG is loaded with this value,
the BRG counts down to 0 and stops until another reload
has taken place. The BRG count is decremented twice
per instruction cycle (T

2

C Master mode, the BRG is reloaded automatically. If

In I

CY), on the Q2 and Q4 clock.

clock arbitration is taking place, the BRG will be reloaded
when the SCL pin is sampled high (Figure 9-11).

Note: Baud Rate = FOSC / (4 * (SSPADD + 1) )

FIGURE 9-10: BAUD RATE GENERATOR

BLOCK DIAGRAM

SSPM3:SSPM0

SSPM3:SSPM0

SCL

CLKOUT

SSPADD<6:0>

Reload
Control

Reload

BRG Down Counter

F

OSC/4

 2001 Microchip Technology Inc. DS30292C-page 79

PIC16F87X

FIGURE 9-11: BAUD RATE GENERATOR TIMING WITH CLOCK ARBITRATION

SDA

SCL de-asserted but slave holds
SCL low (clock arbitration)

SCL

9.2.9 I

BRG
Value

BRG
Reload

2

C MASTER MODE START

03h 02h 01h 00h (hold off) 03h 02h

SCL is sampled high, reload takes
place, and BRG starts its count

CONDITION TIMING

To initiate a START condi tion, the user sets the START
condition enable bit, SEN (SSPCON2<0>). If the SDA
and SCL pins are samp led hig h, th e ba ud ra te g enera­tor is reloaded with the contents of SSPADD<6:0> and
starts it s coun t. If SCL and SDA are bot h sam pl ed hig h
when the baud rate generator times out (T
SDA pin is driven low. The action of the SDA being
driven low while SCL is high is the START condition,
and causes the S bit (SSPSTAT<3>) to be set. Follow­ing this, the baud rate generator is reloaded with the
contents of SSPADD<6:0> and resumes its count.
When the baud rate generator times out (T
SEN bit (SSPCON2<0>) will be automatically cleared
by hardware. The baud rate generator is suspended,
leaving the SDA li ne held low, and th e ST ART conditio n
is complete .

BRG), the

BRG), the

DX-1DX

SCL allowed to transition high

BRG decrements
(on Q2 and Q4 cycles)

Note: If, at the beginning of START condition, the

SDA and SCL pins are already sampled
low, or if during t he START condition the
SCL line is sampled low before the SDA
line is driven low, a bus collision occurs,
the Bus Collision Interrupt Flag (BCLIF) is
set, the START condition is aborted, and

2

C module is reset into its IDLE state.

the I

9.2.9.1 WCOL Status Flag

If the user writes the SSPBUF when a START
sequence is in progress, then WCOL is set and the
contents of the bu ff er are un chang ed (th e write doe sn ’t
occur).

Note: Because queueing of events is not

allowed, writing to the lower 5 bits of
SSPCON2 is disabled until the START
condition is complete .

FIGURE 9-12: FIRST START BIT TIMING

Write to SEN bit occurs here

SDA

SCL

DS30292C-page 80  2001 Microchip Technology Inc.

SDA = 1,
SCL = 1

TBRG

Set S bit (SSPSTAT<3>)

At completion of START bit,
Hardware clears SEN bit
and sets SSPIF bit

TBRG

S

Write to SSPBUF occurs here

1st Bit

TBRG

2nd Bit

TBRG

PIC16F87X

9.2.10 I2C MASTER MODE REPEATED START CONDITION TIMING

A Repeated START condition occurs when the RSEN
bit (SSPCON2<1>) is programmed high and the I
module is in the IDLE state. When the RSEN bit is set,
the SCL pin is asserted low. When the SCL pin is sam­pled low, the baud rate generator is loaded with the
contents of SSPADD<6:0> and begins counting. The
SDA pin is released (brought high) for one baud rate
generator count (T

BRG). When the baud rate generator

times out, if SD A is sampl ed hi gh, th e SCL pin w ill be
de-asserted (brought high). When SCL is sampled high
the baud rate genera tor is reloaded w ith the content s of
SSPADD<6:0> and begins counting. SDA and SCL
must be sampled high for one T

BRG. This action is then

followed by assertion of the SDA pin (SDA is low) for
one T

BRG, while SCL is high. Following thi s, t he RSEN

bit in the SSPCON2 register will be automatically
cleared and the baud rate generator will not be
reloaded, leaving the SDA pin held low. As soon as a
ST ART cond ition is det ected on the SDA and SCL p ins,
the S bit (SSPSTAT<3>) will be set. The SSPIF bit will
not be set until the ba ud rate generator has timed out.

Note 1: If RSEN is programmed while any other

event is in progress, it will not take effect.

2: A bus collision during the Repeated

START condition occurs if:

• SDA is sampled low when SCL
goes from low to high.

• SCL goes low before SDA is
asserted low . This may indicate that
another master is attempting to
transmit a data "1".

2

Immediately following the SSPIF bit getting set, the
user may write the SSPBUF with the 7-bit address in
7-bit mode, or the default first address in 10-bit mode.
After the first eight bits are transmitted and an ACK is

C

received, the use r may then transmi t an additional e ight
bits of address (1 0-bit mod e), or ei ght bi t s of dat a (7-b it
mode).

9.2.10.1 WCOL Status Fl ag

If the user writes the SSPBUF when a Repeated
ST ART sequence is i n progress , then WCOL is s et and
the contents of the buffer are unchanged (the write
doesn’t occur).

Note: Because queueing of events is not

allowed, writing of the lower 5 bits of
SSPCON2 is disabled until the Repeated
START condition is complete.

FIGURE 9-13: REPEAT START CONDITION WAVEFORM

Write to SSPCON2
occurs here
SDA = 1,
SCL (no change)

SDA

Falling edge of ninth clock

 2001 Microchip Technology Inc. DS30292C-page 81

End of Xmit

SCL

SDA = 1,
SCL = 1

TBRG TBRG

Set S (SSPSTAT<3>)

At completion of START bit,
hardware clears RSEN bit
and sets SSPIF

TBRG

1st bit

Write to SSPBUF occurs here

T

BRG

Sr = Repeated START

T

BRG

PIC16F87X

9.2.11 I2C MASTER MODE TRANSMISSION

Transmission of a data byte, a 7-bit address, or either
half of a 10-bit address, is accomplished by simply writ­ing a value to SSPBUF register. This action will set th e
Buffer Full flag (BF) and allow the baud rate generator
to begin counting and s tar t the next trans mission. Eac h
bit of address/data will be shifted out onto the SDA pin
after the falling edg e of SCL is ass erte d (se e data hold
time spec). SCL i s held low for o ne baud rate gen erator
rollover count (T
is released high (see data setup time spec). When the
SCL pin is r eleased high, i t is hel d that w ay for T
The data on the SDA pin must remain stable for that
duration and some hold ti me after the next falling edge
of SCL. After the eighth bit is shifted out (the falling
edge of the eighth c lock), the BF f lag is cl eared and th e
master releases SDA allowing the slave device being
addressed t o res p on d wi th an ACK
bit time, if an address match occurs or if data was
received properly. The status of ACK is read into the
ACKDT on the falling edge of the ninth clock. If the
master receives an Acknowledge, the Acknowledge
Status bit (ACKSTAT) is cleared. If not, the bit is set.
After the ninth clock, the SSPIF is set and the master
clock (baud rate gene rator ) is sus pe nde d u ntil the nex t
data byte is loaded into the SSPBUF, leaving SCL low
and SDA unchanged (Figure 9-14).

After the write to the SSPBUF, each bit of address will
be shifted out on the fal ling edge of SC L, until all seve n
address bits and the R/W
ing edge of the eighth clock, the master will de-assert
the SDA pin, allowing the slave to respond with an
Acknowledge. On th e falling edge o f the ninth clock , the
master will sample the SDA pin to see if the address
was recognized by a slave. The status of the ACK bit is
loaded into the ACKSTAT status bit (SSPCON2<6>).
Following t he falli ng edge o f the ni nth clock transmis ­sion of the address, the SSPIF is set, the BF flag is
cleared, and the baud rate generator is turned off until
another write to the SSPBUF takes place, holding SCL
low and allowing SDA to float.

BRG). Data should be valid before SCL

BRG.

bit during the ninth

bit are complet ed. On the fall-

9.2.11.1 BF Status Flag

In Transmit mode, the BF bit (SSPSTAT<0>) is set
when the CPU writes to SSPBUF and is cleared when
all 8 bits are shifted out.

9.2.11.2 WCOL Status Flag

If the user writes the SSPBUF when a transmit is
already in progress (i.e., SSPSR is still shifting out a
data byte), then WCOL is set and the contents of the
buffer are unchanged (the write doesn’t occur).

WCOL must be cleared in software.

9.2.11.3 ACKSTAT Status Flag

In Transmit mod e, the ACKSTAT bit (SSPCON2<6>) is
cleared when the slave has sent an Acknowledge
(ACK

= 0), and is set when th e slave does not Ackno wl­edge (ACK
it has recognized its address (including a general call),
or when the slave has properly received its data.

= 1). A slave sends an Acknowledge when

DS30292C-page 82  2001 Microchip Technology Inc.

PIC16F87X

FIGURE 9-14: I2C MASTER MODE TIMING (TRANSMISSION, 7 OR 10-BIT ADDRESS)

P

ACKSTAT in

SSPCON2 = 1

ACK

Cleared in software

From slave clear ACKSTAT bit SSPCON2<6>

Write SSPCON2<0> SEN = 1

START condition begins

Transmitting Data or Second Half

of 10-bit address

= 0Transmit Address to Slave
R/W

SEN = 0

A7 A6 A5 A4 A3 A2 A1 ACK = 0 D7D6D5D4D3D2D1D0

Cleared in software service routine

From SSP interrupt

SCL held low

while CPU

responds to SSPIF

Cleared in software

123456789 123456789

start transmit

SSPBUF written with 7-bit address and R/W

S

SSPBUF is written in software

SSPBUF written

After START condition SEN, cleared by hardware.

SDA

SCL

SSPIF

BF (SSPST AT<0>)

SEN

PEN

R/W

 2001 Microchip Technology Inc. DS30292C-page 83

PIC16F87X

9.2.12 I2C MASTER MODE RECEPTION

Master mode recepti on is enab led by pr ogrammin g the
Receive Enable bit, RCEN (SSPCON2<3>).

Note: The SSP module must be in a n IDL E st a te

before the RCEN bit is set, or the RCEN bit
will be disregarded.

The baud rate genera tor b egi ns cou nti ng, and on each
rollover, the state of the SCL pin changes (high to low/
low to high), and data is shifted into the SSPSR. After
the falling edge of the eighth clock, the receive enable
flag is automatically cleared, the contents of the
SSPSR are loaded into the SSPBUF, the BF flag is set,
the SSPIF is set, and the baud rate generator is sus­pended from counting, holding SCL low. The SSP is
now in IDLE state, awaiting the next command. When
the buffer is read by the CPU, the BF flag is automati­cally cleared. The us er can then s end an Acknowl edge
bit at the end of reception, by setting the Acknowledge
Sequence Enable bit, ACKEN (SSPCON2<4>).

9.2.12.1 BF Status Flag

In receive operation, BF is set when an address or data
byte is loaded into SSPBUF from SSPSR. It is cleared
when SSPBUF is read.

9.2.12.2 SSPOV Status Flag

In receive operation, SSPOV is set when 8 bits are
received into the SSPSR, and the BF flag i s already set
from a previous reception.

9.2.12.3 WCOL Status Fl ag

If the user writes the SSPBUF when a receive is
already in progress (i.e., SSPSR is s till shifting in a dat a
byte), then WCOL is set and the contents of the buffer
are unchanged (the write doesn’t occur).

DS30292C-page 84  2001 Microchip Technology Inc.

PIC16F87X

FIGURE 9-15: I2C MASTER MODE TIMING (RECEPTION, 7-BIT ADDRESS)

Bus Master

terminates

transfer

Set SSPIF interrupt

at end of Acknow-

ledge sequence

Set P bit

(SSPSTA T<4>)

sequence

and SSPIF

Cleared in

software

SSPOV is set because

SSPBUF is still full

Cleared in software

Last bit is shifted into SSPSR and

contents are unloaded into SSPBUF

P

PEN bit = 1

written here

ACK is not sent

9

87

6
5

1234

of receive

Set SSPIF at end

Set SSPIF interrupt

at end of acknowledge

Data shifted in on falling edge of CLK

ACK

RCEN cleared

RCEN = 1 start

automatically

next receive

D0

D1

D2

D3D4

D5

D6D7

Receiving Data from Slave

ACK

D0

SDA = ACKDT = 1

Set ACKEN to start Acknowledge sequence

ACK from Master

SDA = ACKDT = 0

Write to SSPCON2<4>

to start Acknowledge sequence

SDA = ACKDT (SSPCON2<5>) = 0

D1

RCEN cleared

automatically

D2

D3D4

D5

D6D7

Receiving Data from Slave

Master configured as a receiver

by programming SSPCON2<3>, (RCEN = 1)

SEN = 0

Write to SSPCON2<0> (SEN = 1)

Begin START Condition

ACK

R/W = 1

ACK from Slave

A3 A2 A1

Transmit Address to Slave

Start XMIT

Write to SSPBUF occurs here

A7 A6 A5 A4

678 9

5

4

3

12

9

8

7

6

5
4

3

12

S

Set SSPIF interrupt

Cleared in software

at end of receive

Cleared in software

Cleared in software

while CPU

responds to SSPIF

SDA

SCL

SDA = 0, SCL = 1

SSPIF

BF

(SSPSTAT<0>)

SSPOV

ACKEN

 2001 Microchip Technology Inc. DS30292C-page 85

PIC16F87X

9.2.13 ACKNOWLEDGE SEQUENC E TIMING

rate generator cou nts for T
pulled low. Following this, t he AC KEN b it is au to mat i­cally cleared, the baud rate generator is turned off,

An Acknowledge sequence is enabled by setting the
Acknowledge Sequence Enable bit, ACKEN
(SSPCON2<4>). When this bit is set, the SCL pin is
pulled low and the content s of the Acknowledge dat a bit
is presented on the SD A pin . If t he user wishes to gen­erate an Acknowledge, the ACKDT bit should be
cleared. If not, the user should set the ACKDT bit
before starting an Acknowledge sequence. The baud
rate generator then counts for one rollover period

BRG), and the SCL pin is de-asserted high. When the

(T

and the SSP module then goes into IDLE mode
(Figure 9-16).

9.2.13.1 WCOL Status Fl ag

If the user writes the SSPBUF when an Acknowledge
sequence is in progress , the WCOL is set and the con­tents of the buffer are unchanged (the write doesn’t
occur).

SCL pin is sampled high (clock arbitration), the baud

FIGURE 9-16: ACKNOWLEDGE SEQUENCE WAVEFORM

Acknowledge sequence starts here,

SDA

SCL

Write to SSPCON2

ACKEN = 1, ACKDT = 0

D0

8

TBRG

ACKEN automatically cleared

TBRG

ACK

9

BRG. The SCL pin is t hen

SSPIF

Set SSPIF at the end
of receive

Note: TBRG = one baud rate generator period.

Cleared in
software

Cleared in
software

Set SSPIF at the end
of Acknowledge sequence

DS30292C-page 86  2001 Microchip Technology Inc.

PIC16F87X

9.2.14 STOP CONDITION TIMING

A STOP bit is asserted on the SDA pin at the end of a
receive/t ransmi t by s etti ng the Stop Sequen ce E nable
bit, PEN (SSPCON2<2>). At the end of a receive/
transmit, the SCL line is held low after the falling edge
of the ninth clock. When the PEN bit is set, the master
will assert the SDA line lo w . Whe n the SDA line is sam­pled low, the baud rate generator is reloaded and
counts down to 0. Wh en th e ba ud rat e ge nera tor times
out, the SCL pin will be brought high, and one T
(baud rate generator rollover count) later, the SDA pin
will be de-asserted. Wh en the SDA pin is sam pled high

BRG

while SCL is high, the P bit (SSPSTAT<4>) is set. A

BRG later, the PEN bit is cleared and the SSPIF bit is

T
set (Figure 9-17).

Whenever the firmware decides to take control of the
bus, it will firs t dete rm ine if the bus is busy b y checking
the S and P bits in the SSPSTAT register. If the bus is
busy, then the CPU can be interrupted (notified) when
a STOP bit is detected (i.e., bus is free).

9.2.14.1 WCOL Status Fl ag

If the user writes the SS PBUF when a ST OP se quence
is in progress, then WCOL is set an d the content s of the
buffer are unchanged (the write doesn’t occur).

FIGURE 9-17: STOP CONDITION RECEIVE OR TRANSMIT MODE

Write to SSPCON2

Falling edge of
9th clock

SCL

Set PEN

T

SCL = 1 for T
after SDA sampled high. P bit (SSPSTAT<4>) is set.

BRG

BRG, followed by SDA = 1 for TBRG

PEN bit (SSPCON2<2>) is cleared by
hardware and the SSPIF bit is set

SDA

Note: TBRG = one baud rate generator period.

ACK

BRG

T

SDA asserted low before rising edge of clock
to setup STOP condition

BRG

T

SCL brought high after T

P

TBRG

BRG

 2001 Microchip Technology Inc. DS30292C-page 87

PIC16F87X

9.2.15 CLOCK ARBITRATION

Clock arbitration occurs when the master, during any
receive, transmit, or Repeated START/STOP condi­tion, de-asserts th e SCL pin (SCL allowed to float high).
When the SCL pin is allowed to floa t high, the baud rate

9.2.16 SLEEP OPERATIO N

While in SLEEP mode, the I2C module can receive
addresses or data, and when an address match or
complete byte transfer occurs, wake the processor

from SLEEP (if the SSP interrupt is enabled).
generator (BRG) is suspended from counting until the
SCL pin is actually sam ple d hi gh. W hen the SC L p in i s
sampled high, the baud rate gen erator is reloaded with
the contents of SSPADD<6:0> and begins counting.
This ensures that the SCL high time will always be at

9.2.17 EFFECTS OF A RESET

A RESET disables the SSP module and terminates the

current tran sfer.
least one BRG rollover c ount in the e vent that the clock

is held low by an external device (Figure 9-18).

FIGURE 9-18: CLOCK ARBITRATION TIMING IN MASTER TRANSMIT MODE

BRG overflow,
Release SCL,

If SCL = 1, Load BRG with
SSPADD<6:0>, and start count

to measure high time interval

SCL

BRG overflow occurs,
Release SCL, Slave device holds SCL low

SCL line sampled once every machine cycle (T
Hold off BRG until SCL is sampled high.

SCL = 1, BRG starts counting
clock high interval

OSC • 4).

SDA

TBRG

TBRG

TBRG

DS30292C-page 88  2001 Microchip Technology Inc.

PIC16F87X

9.2.18 MULTI -MASTER COMMUNICATION, BUS COLLISION, AND BUS ARBITRATION

Multi-Master mode support is achieved by bus arbitra­tion. When the master outputs address/data bits onto
the SDA pin, arbitration takes place when the master
outputs a ’1’ on SDA, by letting SDA float high and
another master asserts a ’0’. When the SC L pi n fl oats
high, data should be stable. If the expected data on
SDA is a ’1’ a nd the da ta s ampl ed on th e SDA pin = ’0’,
a bus collision has t ak en place. The master will set the
Bus Collision Interrupt Flag, BCLIF and reset the I
port to its IDLE state (Figure 9-19).

If a transmit was in progress when the bus collision
occurred, the transmission is halted, the BF flag is
cleared, the SDA and SCL lines are de-asserted, and
the SSPBUF can be w ritten t o. When the u ser se rvice s
the bus collision Interrupt Service Routine, and if the

2

C bus is free, the user can res ume commu nication b y

I

2

C

If a START, Repeated START, STOP, or Acknowledge
condition was in progress when the bus collision
occurred, the condition is aborted, the SDA and SCL
lines are de-assert ed, and t he respe ctiv e contro l bit s in
the SSPCON2 register are cleared. When the user ser­vices the bus collision Interrupt Service Routine, and if

2

C bus is free, the use r can resume communicatio n

the I
by asserting a START condition.

The master will continue to monitor the SDA and SCL
pins and if a STOP condition occurs, the SSPIF bit will
be set.

A write to the SSPBUF will start the transmission of
data at the first data bit, regardless of where the trans­mitter left off when the bus collision occurred.

In Multi-Master mode, the interrupt generation on the
detection of START and STOP conditions allows the
determination of whe n the bus is free. Con trol of the I
bus can be taken when the P bit is set in the SSPSTAT
register, or the bus is idle and the S and P bits are
cleared.

asserting a START condition.

FIGURE 9-19: BUS COLLISION TIMING FOR TRANSMIT AND ACKNOWLEDGE

2

C

SDA

SCL

BCLIF

Data changes
while SCL = 0

SDA line pulled low
by another source

SDA released

by master

Sample SDA. While SCL is high,
data doesn’t match what is driven
by the master.
Bus collision has occurred.

Set bus collision
interrupt

 2001 Microchip Technology Inc. DS30292C-page 89

PIC16F87X

9.2.18.1 Bus Collision During a START Condition

During a START condition, a bus collision occurs if:
a) SDA or SCL are s ampled low a t the beginni ng of

the START condition (Figure 9-20).

b) SCL is sampl ed l ow be fore SD A is as se rted low

(Figure 9-21).

During a START condition, both the SDA and the SCL
pins are monitored. If e ither the SDA pi n or
is already low, then these events all occur:

• the START condition is aborted,

• and

the BCLIF flag is set,

• and the SSP module is reset to its IDLE state

(Figure 9-20).

The START condition begins with the SDA and SCL
pins de-asserted. When the SDA pin is sampled high,
the baud rate generator is loaded from SSPADD<6:0>
and counts down to 0. If the SCL pin is sampled low
while SDA is high, a bus collision occurs, because it is
assumed that another master is attempting to drive a

the SCL pin

If the SDA pin is sampled low during this count, the
BRG is reset and the SDA line is asserted early
(Figure 9 -22). If, however, a '1' is sampled on the SDA
pin, the SDA pin is asserted low at the end of the BRG
count. The baud rate generator is then reloaded and
counts down to 0. During this time, if the SCL pins are
sampled as '0', a bus collision does not occur. At the
end of the BRG count, the SCL pin is asserted low.

Note: The reason that bus coll ision is no t a fact or

during a START condition is that no two
bus masters can assert a START co ndition
at the exact same time. Therefore, one
master will always assert SDA before the
other . T his condition does not cause a bus
collision, becau se the two master s must be
allowed to arbitrate t he first add ress follow­ing the START condition. If the address is
the same, arbitration must be allowed to
continue into the data portion, Repeated
START, or STOP conditions.

data '1' during the START condition.

FIGURE 9-20: BUS COLLISION DURING START CONDITION (SDA ONLY)

SDA

SCL

SEN

BCLIF

S

SSPIF

SDA goes low before the SEN bit is set.
Set BCLIF,

S bit and SSPIF set because
SDA = 0, SCL = 1.

Set SEN, enable START

condition if SDA = 1, SCL = 1

SDA sampled low before
START condition.

S bit and SSPIF set because
SDA = 0, SCL = 1.

Set BCLIF.

SEN cleared automatically because of bus collision.
SSP module reset into IDLE state.

SSPIF and BCLIF are
cleared in software

SSPIF and BCLIF are
cleared in software

DS30292C-page 90  2001 Microchip Technology Inc.

PIC16F87X

FIGURE 9-21: BUS COLLISION DURING START CONDITION (SCL = 0)

SDA = 0, SCL = 1

TBRG

SCL = 0 before SDA = 0,
Bus collision occurs, Set BCLIF

Interrupts cleared
in software

’0’

’0’

SDA

SCL

SEN

BCLIF

S

SSPIF

Set SEN, enable START
sequence if SDA = 1, SCL = 1

SCL = 0 before BRG time-out,
Bus collision occurs, Set BCLIF

’0’

’0’

TBRG

FIGURE 9-22: BRG RESET DUE TO SDA COLLISION DURING START CONDITION

SDA = 0, SCL = 1

Set SSPIF

Less than T

SDA pulled low by other master.

SDA

Reset BRG and assert SDA.

BRG

Set S

TBRG

SCL

SEN

BCLIF

S

SSPIF

s

SCL pulled low after BRG
Time-out

Set SEN, enable START

’0’

sequence if SDA = 1, SCL = 1

SDA = 0, SCL = 1
Set SSPIF

Interrupts cleared
in software

 2001 Microchip Technology Inc. DS30292C-page 91

PIC16F87X

9.2.18.2 Bus Collision During a Repeated ST ART Condition

During a Repeated START condition, a bus collision
occurs if:

a) A low level is sampled on SDA when SCL goes

from low level to high level.

b) SCL goes low before SDA is asserted low, indi-

cating that another m aster is attem pting to trans­mit a data ’1’.

When the user de-asserts SDA and the pin is allowed
to float high, the BRG is loaded with SSPADD<6:0>
and counts down to 0. The SCL pin is then de-asserted,
and when sampled high, the SDA pin is sampled. If
SDA is low, a bus collision has occurred (i.e., another

SDA is sampled high, the BRG is reloaded and begins
counting. If SDA goes from high to low befo re the BRG
times out, no bus collision occurs, because no two
masters can assert SDA at exactly the same time.

If, however , SCL goes from hig h to low before the BRG
times out and SDA has not already been asserted, a
bus collision occurs. In this case, another master is
attempting to transmit a data’1’ during the Repeated
START condition.

If at the end of the BRG time-out, both SCL and SDA
are still high, the SDA pin is driven low, the BRG is
reloaded and begins counting. At the end of the count,
regardless of the status of the SCL pin, the SCL pin is
driven low and the Repeated START condition is
complete (Figure 9-23).

master is attempting to transmit a data’0’). If, however,

FIGURE 9-23: BUS COLLISION DURING A REPEATED START CONDITION (CASE 1)

SDA

SCL

Sample SDA when SCL goes high.
If SDA = 0, set BCLIF and release SDA and SCL.

RSEN

BCLIF

Cleared in software

’0’
’0’

S

SSPIF

’0’
’0’

FIGURE 9-24: BUS COLLISION DURING REPEATED START CONDITION (CASE 2)

TBRG TBRG

SDA

SCL

SCL goes low before SDA,

BCLIF

RSEN

Set BCLIF. Release SDA and SCL.

Interrupt cleared
in software

S

SSPIF

DS30292C-page 92  2001 Microchip Technology Inc.

’0’
’0’

’0’
’0’

PIC16F87X

9.2.18.3 Bus Collision During a STOP Condition

Bus collision occurs during a STOP condition if:
a) After the SDA pin has been de-asserted and

allowed to float high, SDA is sampled low after
the BRG has timed out.

b) After the SCL pin is de-asserted, SCL is sam-

pled low before SDA goes high.

The STOP condition begins with SDA asserted low.
When SDA is sampled low, the SCL pin is allowed to
float. When th e pin i s sa mple d hi gh (c loc k ar bit rati on) ,
the baud rate generator is loaded with SSPADD<6:0>
and counts down to 0. After the BRG times out, SDA i s
sampled. If SDA is sampled low, a bus collision has
occurred. This is due to another master attempting to
drive a data ’0’. If the SCL pin is s ampled low before
SDA is allowed to float hi gh, a bus collis ion occurs. Thi s
is a case of another master attempting to drive a data
’0’ (Figure 9-25).

FIGURE 9-25: BUS COLLISION DURING A STOP CONDITION (CASE 1)

TBRG TBRG TBRG

SDA

SCL

PEN

BCLIF

P

’0’

SDA asserted low

SDA sampled
low after T
Set BCLIF

’0’

BRG,

SSPIF

’0’

FIGURE 9-26: BUS COLLISION DURING A STOP CONDITION (CASE 2)

TBRG TBRG TBRG

SDA

SCL goes low before SDA goes high,
Set BCLIF

SCL

PEN

BCLIF

P

SSPIF

Assert SDA

’0’

’0’

’0’

 2001 Microchip Technology Inc. DS30292C-page 93

PIC16F87X

9.3 Connection Considerations for

2

I

C Bus

For standard-mode I2C bus devices, the values of
resistors R
lowing parameters:

• Supply voltage

• Bus capacitance

• Number of connected devices

(input current + leakage current)

The supply voltage limits the minimum value of resistor

due to the specified minimum sink current of 3 mA at

R

p,

OL max = 0.4V, for the specified output stages.

V

and Rs in Figure 9-27 depend on the fol-

p

For

example, with a supply voltage of V

OL max = 0.4V at 3 mA, R

V
V

DD as a function of R

desired noise margin of 0.1V
the maximum value of R
and used to improve ESD susceptibility.

The bus capacitance is the total capacitance of wire,
connections, an d pins. This capacit ance lim its the m ax­imum value of R

due to the specified rise time

p

(Figure 9-27).
The SMP bit is the slew rate control enabled bit. This bit

is in the SSPSTAT register, and controls the slew rate
of the I/O pins when in I

FIGURE 9-27: SAMPLE DEVICE CONFIGURATION FOR I2C BUS

VDD + 10%

R

p

R

p

DEVICE

DD = 5V±10% and

min = (5.5-0.4)/0.003 = 1.7 kΩ.

p

is shown i n Figure 9-27 . The

p

DD for the low level limits

. Series resistors are optional

s

2

C mode (master or slave).

R

R

SDA
SCL

Note: I2C devices with input levels related to VDD must have one com mon supply line to which the pull-up resistor is also

connected.

s

s

Cb=10 - 400 pF

DS30292C-page 94  2001 Microchip Technology Inc.

PIC16F87X

10.0 ADDRESSABLE UNIVERSAL

SYNCHRONOUS
ASYNCHRONOUS RECEIVER
T RANSMITTER (USART)

The Universal Synchronous Asynchronous Receiver
Transmitter (USART) module is one of the two serial
I/O modules . (USA RT is als o know n as a S erial Com­munications Interface or SCI.) The USART can be con­figured as a full duplex asynchronous system that can
communicate with pe ripheral devi ces s uch as CR T ter­minals and perso nal comp uters, or it can be configure d
as a half duplex s yn chronous system that can commu­nicate with periphera l de vi ces su ch as A/D or D /A in te­grated circuits, serial EEPROMs etc.

The USART can be configured in the following modes:

• Asynchronous (full duplex)

• Synchronous - Master (half duplex)

• Synchronous - Slave (half duplex)

Bit SPEN (RCSTA<7>) and bits TRISC<7:6> have to
be set in order to configure pins RC6/TX/CK and
RC7/RX/DT as the Universal Synchronous Asynchro­nous Receiver Transmitter.

The USART module also has a multi-processor com­munication capability using 9-bit address detection.

REGISTER 10-1: TXST A: TRANSMIT ST ATUS AND CONTROL REGISTER (ADDRESS 98h)

R/W-0 R/W-0 R/W-0 R/W-0 U-0 R/W-0 R-1 R/W-0
CSRC TX9 TXEN SYNC — BRGH TRMT TX9D

bit 7 bit 0

bit 7 CSRC: Clock Source Select bit

Asynchronous mode:
Don’t care

Synchronous mode:

1 = Master mode (clock generated internally from BRG)
0 = Slave mode (clock from external source)

bit 6 TX9: 9-bit Transmit Enable bit

1 = Selects 9-bit transmission
0 = Selects 8-bit transmission

bit 5 TXEN: Transmit Enable bit

1 = Transmit enabled
0 = Transmit disabled

Note: SREN/CREN overrides TXEN in SYNC mode.

bit 4 SYNC: USART Mode Select bit

1 = Synchronous mode
0 = Asynchronous mode

bit 3 Unimplemented: Read as '0'
bit 2 BRGH: High Baud Rate Select bit

Asynchronous mode:

1 = High speed
0 = Low speed

Synchronous mode:
Unused in this mode

bit 1 TRMT: Transmit Shift Register Status bit

1 = TSR empty
0 = TSR full

bit 0 TX9D: 9th bit of Transmit Data, can be parity bit

Legend:
R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’

- n = Value at POR ’1’ = Bit is set ’0’ = Bit is cleared x = Bit is unknown

 2001 Microchip Technology Inc. DS30292C-page 95

PIC16F87X

REGISTER 10-2: RCST A: RECEIVE ST ATUS AND CONTROL REGISTER (ADDRESS 18h)

R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R-0 R-0 R-x

SPEN RX9 SREN CREN ADDEN FERR OERR RX9D

bit 7 bit 0

bit 7 SPEN: Serial Port Enable bit

1 = Serial port enabled (configures RC7/RX/DT and RC6/TX/CK pins as serial port pins)
0 = Serial port disabled

bit 6 RX9: 9-bit Receive Enable bit

1 = Selects 9-bit reception
0 = Selects 8-bit reception

bit 5 SREN: Single Receive Enable bit

Asynchronous mode:
Don’t care

Synchronous mode - master:

1 = Enables single receive
0 = Disables single receive

This bit is cleared after reception is complete.
Synchronous mode - slave:

Don’t care

bit 4 CREN: Continuous Receive Enable bit

Asynchronous mode:

1 = Enables continuous receive
0 = Disables co ntinuous r eceive

Synchronous mode:

1 = Enables continuous receive until enable bit CREN is cleared (CREN overrides SREN)
0 = Disables co ntinuous r eceive

bit 3 ADDEN: Address Detect Enable bit

Asynchronous mode 9-bit (RX9 = 1):
1 = Enables address detection, enables interrupt and load of the receive buffer when

RSR<8> is set

0 = Disables address detection, all bytes are received, and ninth bit can be used as parity bit

bit 2 FERR: Framing Error bit

1 = Framing error (can be updated by reading RCREG register and receive next valid byte)
0 = No framing error

bit 1 OERR: Overrun Error bit

1 = Overrun error (can be cleared by clearing bit CREN)
0 = No overrun error

bit 0 RX9D: 9th bit of Received Data (can be parity bit, but must be calculated by user firmware)

Legend:
R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’

- n = Value at POR ’1’ = Bit is set ’0’ = Bit is cleared x = Bit is unknown

DS30292C-page 96  2001 Microchip Technology Inc.

PIC16F87X

10.1 USART Baud Rate Generator

(BRG)

The BRG supports both the Asynchronous and Syn­chronous modes of the USART. It is a dedicated 8-bit
baud rate generator. The SPBRG register controls the
period of a free running 8-bit timer. In Asynchronous
mode, bit BRGH (TXSTA<2>) also controls the baud
rate. In Synchronous mode, bit BRGH is ignored.
Table 10-1 shows the formula for computation of the
baud rate for differen t US ART modes which only apply
in Master mode (internal clock).

Given the desired baud rate and F
integer value for the SPBRG register can be calculated

OSC, the nearest

It may be advantageous to use the high baud rate
(BRGH = 1), even for slower baud clocks. This is
because the F

OSC/(16(X + 1)) equat ion c an red uce th e

baud rate error in some cases.
Writing a new value to the SPBRG register causes the

BRG timer to be reset (or cleared). This ensures the
BRG does not wait for a timer overflow before output­ting the new baud rate.

10.1.1 SAMPLING

The data on the RC7/RX/D T pin is sampled three times
by a majority detect circuit to determine if a high or a
low level is present at the RX pin.

using the formula in Table 10-1. From this, the error in
baud rate can be determined.

TABLE 10-1: BAUD RATE FORMULA

SYNC BRGH = 0 (Low Speed) BRGH = 1 (High Speed)

0
1

X = value in SPBRG (0 to 255)

(Asynchronous) Baud Rate = F

(Synchronous) Baud Rate = F

OSC/(64(X+1))
OSC/(4(X+1))

Baud Rate = F

N/A

OSC/(16(X+1))

TABLE 10-2: REGISTERS ASSOCIATED WITH BAUD RATE GENERATOR

Value o n:

Address Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

98h TXSTA
18h RCSTA SPEN RX9 SREN CREN ADDEN FERR OERR RX9D 0000 000x 0000 000x
99h SPBRG Baud Rate Generator Register 0000 0000 0000 0000
Legend: x = unknown, - = unimplemented, read as '0'. Shaded cells are not used by the BRG.

CSRC TX9 TXEN SYNC — BRGH TRMT TX9D 0000 -010 0000 -010

POR,

BOR

Val ue on

all other

RESETS

 2001 Microchip Technology Inc. DS30292C-page 97

PIC16F87X

TABLE 10-3: BAUD RATES FOR ASYNCHRONOUS MODE (BRGH = 0)

F

BAUD

RATE

(K)

KBAUD%ERROR

0.3------- --

1.2 1.221 1.75 255 1.202 0.17 207 1.202 0.17 129

2.4 2.404 0.17 129 2.404 0.17 103 2.404 0.17 64

9.6 9.766 1.73 31 9.615 0.16 25 9.766 1.73 15

19.2 19.531 1.72 15 19.231 0.16 12 19.531 1.72 7

28.8 31.250 8.51 9 27.778 3.55 8 31.250 8.51 4

33.6 34.722 3.34 8 35.714 6.29 6 31.250 6.99 4

57.6 62.500 8.51 4 62.500 8.51 3 52.083 9.58 2

HIGH 1.221 - 255 0.977 - 255 0.610 - 255

LOW 312.500 - 0 250.000 - 0 156.250 - 0

BAUD

RATE

(K)

KBAUD

0.3 0.300 0 207 0.3 0 191

1.2 1.202 0.17 51 1.2 0 47

2.4 2.404 0.17 25 2.4 0 23

9.6 8.929 6.99 6 9.6 0 5

19.2 20.833 8.51 2 19.2 0 2

28.8 31.250 8.51 1 28.8 0 1

33.6 - - - - - -

57.6 62.500 8.51 0 57.6 0 0

HIGH 0.244 - 255 0.225 - 255

LOW 62.500 - 0 57.6 - 0

OSC = 20 MHz FOSC = 16 MHz FOSC = 10 MHz

SPBRG

value

(decimal)

OSC = 4 MHz FOSC = 3.6864 MHz

F

%

ERROR

SPBRG

value

(decimal) KBAUD

KBAUD%ERROR

ERROR

SPBRG

value

(decimal)

SPBRG

%

value

(decimal)

KBAUD%ERROR

SPBRG

value

(decimal)

TABLE 10-4: BAUD RATES FOR ASYNCHRONOUS MODE (BRGH = 1)

OSC = 20 MHz FOSC = 16 MHz FOSC = 10 MHz

BAUD

RATE

(K)

0.3---------

1.2---------

2.4 - - - - - - 2.441 1.71 255

9.6 9.615 0.16 129 9.615 0.16 103 9.615 0.16 64

19.2 19.231 0.16 64 19.231 0.16 51 19.531 1.72 31

28.8 29.070 0.94 42 29.412 2.13 33 28.409 1.36 21

33.6 33.784 0.55 36 33.333 0.79 29 32.895 2.10 18

57.6 59.524 3.34 20 58.824 2.13 16 56.818 1.36 10

HIGH 4.883 - 255 3.906 - 255 2.441 - 255

LOW 1250.000 - 0 1000.000 0 625.000 - 0

BAUD

RATE

(K)

0.3------

1.2 1.202 0.17 207 1.2 0 191

2.4 2.404 0.17 103 2.4 0 95

9.6 9.615 0.16 25 9.6 0 23

19.2 19.231 0.16 12 19.2 0 11

28.8 27.798 3.55 8 28.8 0 7

33.6 35.714 6.29 6 32.9 2.04 6

57.6 62.500 8.51 3 57.6 0 3

HIGH 0.977 - 255 0.9 - 255

LOW 250.000 - 0 230.4 - 0

F

KBAUD%ERROR

OSC = 4 MHz FOSC = 3.6864 MHz

F

%

KBAUD

ERROR

SPBRG

value

(decimal)

SPBRG

value

(decimal) KBAUD

KBAUD%ERROR

%

ERROR

SPBRG

value

(decimal)

SPBRG

value

(decimal)

KBAUD%ERROR

SPBRG

value

(decimal)

DS30292C-page 98  2001 Microchip Technology Inc.
