Metso Lokotrack® LT200HP™
Compact m
obile cone crusher
Lokotrack® LT200HP™ mobile cone crusher is especially suitable for contractors needing versatile aggregate production. Ideal for road
construction, railroad ballast, asphalt, and concrete fractions, it features the proven Nordberg® HP200e™ cone crusher. The latest model
offers at least 15% fuel savings over the previous hydraulic-driven version, thanks to its efficient direct belt drive.
High capacity HP200e cone crush
Proven crusher suitable for hard rock
Excellent end product quality (e.g. concrete aggregates)
Different cavities for secondary or tertiary applications
Max feed size 200 mm (8”)
IC process control for connectivity
Radio remote for feeder control and tracking
Remote IC app for improved safety and productivity
Metso Metrics for remote process monitoring
er
H10-6 lifting conveyor
Adjustable speed for easy material control
Equipped with metal detector
Hopper back wall can be opened for lower feeding height.
Discharge end is hydraulically lowered for transport.
Robust H8-10 or H8-12 main conveyor
Hydraulic driven belt conveyor
Extended conveyor for more discharge height
Lokotrack® LT200HP™ – Mobile cone crusher
38
Fuel-ecient CAT® C9.3B power transmission
Direct drive for crusher with purposely designed
gearbox and hydraulic clutch for high reliability
Optimized hydraulics eciency
Reduced hydraulic oil volume 215 l (57 gal)
Heavy-duty tracks and frame
FEM designed structure for optimized weight and lifetime
Open frame design for easy service access
Agile tracks with 2-speed mode for turnability and speed
Page 2
Technical specifications
© 2024 Metso Corporation. All trademarks and registered trademarks are the property of their respective owners.
Transport dimensions
Weight 32,000 kg 71,000 lbs
Length 16,800 mm 55'
Width 3,000 mm 9' 10"
Height 3,400 mm 11' 2"
Feeder H10-6
Hopper volume 5 m
Loading height 2,700 mm 8' 10"
Loading width 2,440 mm 8' 0"
Crusher
Feed opening
Drive type Direct Direct
Nominal power
Process control IC IC
Main conveyor H8-10 / H8-12
Width 800 mm 31,5"
Length 10,000 / 12,000 mm 32' 10" / 39' 4"
Discharge height 2,900 / 3,630 mm 9' 6" / 11' 11"
Power unit CAT® C9.3B
Power 310 kW 416 hp
Fuel /hydr.oil vol. 630 / 215 l 166 / 57 gal
Options
Additional service platform
Climate kit (hot/cold)
Discharge hood for main conveyor
Dust encapsulation for conveyors
Extended main conveyor
Filter kit
Fuel filling pump
High pressure water spraying
Hydraulic generator
3
Nordberg® HP200e™
200 mm 8"
160 kW
Hydraulic Power Takeo
Interlocking cable
Lifting conveyor feed chute
Metso Metrics
Pre-heater for diesel engine
Remote IC
Remote radio control
Safety package
Special scraper for conveyors
6.5 yd
215 hp
3
See it in 3D at
live.metso.com
Applications
Road construction
Railroad ballast
Asphalt and concrete
fractions
Combine with
• LT96 and LT106 jaw crushers
• LT200HPS and LT220D cone
crushers
• LT7150 VSI crusher
• ST2.3, ST3.8 and ST4.8
mobile screens
Lokotrack® LT200HP™ – Mobile cone crusher
