METROLOGIC INSTRUMENTS, INC.

™

MS1690 Focus

Area Imaging Bar Code Scanner

Installation and User’s Guide

Copyright

© 2005 by Metrologic Instruments, Inc. All rights reserved. No part of this work may be reproduced, transmitted, or stored in any form or by any means without prior written consent, except by reviewer, who may quote brief passages in a review, or provided for in the Copyright Act of 1976.

Products and brand names mentioned in this document are trademarks of their respective companies.

The MS1690 Focus is a high performance hand-held area imaging bar code scanner that utilizes high-resolution CMOS imaging sensors for superior image quality. Focus utilized Omniplanar, Inc.’s Swiftdecoder™ software, for reliable decoding of both 1D and 2D bar code symbologies. Sharp images can be captured and transmitted in a variety of outputs including: .jpg, .bmp, and .tiff.

Omnidirectional scanning capabilities and an extended depth of field width provides aggressive scanning of all standard 1D, RSS, PDF417, microPDF, Composite, Matrix and Postal Codes symbology types. Firmware updates are easily loaded via Flash ROM.

Focus provides an extended depth of field width and a built in object detection sensor (IR) that instantly turns on the scanner when an object is presented within the scanner’s field of view. Automatic in-stand detection switches the scanner to a “presentation” mode for convenient in-stand scanning. Focus incorporates Metrologic’s patented CodeGate® technology for accurate menu style scanning and on command data transmission.

Focus™ Interface

MS1690 – 11 IBM 468X/469X, RS232-TXD, RXD, RTS, CTS

MS1690 – 14 RS232 (TX, RX, RTS, CTS, DTR)

MS1690 – 38 Low Speed USB

MS1690 – 40 Full Speed USB

MS1690 – 47

Keyboard Wedge, Stand-Alone Keyboard and RS232 Transmit/Receive

1

INTRODUCTION

Scanner and Accessories

BASIC KIT

Part # Description

MS1690 Focus Area Imaging Bar Code Scanner

00-02544 MetroSelect® Single-Line Configuration Guide*

00-02065 Supplemental Configuration Guide*

00-02098

MS1690 Focus Area Imaging Bar Code Scanner Installation and User’s Guide*

* Available on the Metrologic website - www.metrologic.com

OPTIONAL ACCESSORIES

Part # Description

AC to DC Power Transformer - Regulated 5.2VDC @ 650 mA output.

45-45593 120V United States

45-45591 220V-240V Continental European

45-45592 220V-240V United Kingdom

46-46803 220V-240V Australia

46-46983 220V-240V China

53-53000-3

53-53002-3

RS232 PowerLink Cable with Built in Power Jack

2.7 m (9 ft.) coiled cord, long strain relief, black

Keyboard Wedge PowerLink Cable with Adapter Cable

2.7 m (9 ft.) coiled cord, long strain relief, black

53-53020-3

Other items may be ordered for the specific protocol being used. To order additional items, contact the dealer, distributor or call Metrologic’s Customer Service Department at 1-800-ID-METRO or 1-800-436-3876.

2

Stand Alone Keyboard PowerLink Cable

2.7 m (9 ft.) coiled cord, long strain relief, black

INTRODUCTION

Scanner and Accessories

OPTIONAL ACCESSORIES

Part # Description

53-53213x-N-3

USB Power/Communication Cable,

2.7 m (9 ft.) coiled cord, long strain relief, black

USB Power/Communication Cable,

4.5 m (15 ft.) coiled cord, long strain relief, black

53-53214x-N-3

This cable is for use with full speed USB (-40) interface only.

53-53235x-N-3

MVC-2MPC-IB9

Low Speed USB Non-Locking Communication Cable

2.7 m (9 ft.) coiled cord, long strain relief, black

Metrologic Voltage Converter (MVC) Cable* ±12VDC to +5.2VDC

* Contact a Metrologic customer service representative for additional

information on the MVC cable series and the host connections available.

00-02001 MS1690 Focus Stand (46-00147) Installation Guide

46-00147 Modular Presentation Stand

Other items may be ordered for the specific protocol being used. To order additional items, contact the dealer, distributor or call Metrologic’s Customer Service Department at 1-800-ID-METRO or 1-800-436-3876.

3

INTRODUCTION

Scanner Components

Figure 1. Scanner Components

Item Description

1 Yellow LED See Visual Indicators (on page 17)

2 White LED See Visual Indicators (on page 17)

3 Blue LED See Visual Indicators (on page 17)

4 Speaker See Audible Indicators (on page 16)

5 Trigger

6 Red Window LED Aperture

7 Cable Release See The PowerLink Cable (on page 5)

8 Cable Connection

4

See Scanner Pinout Connections (on page 34)

10-pin RJ45, Female Socket,

INTRODUCTION

THE POWERLINK CABLE

CONNECTING

Important: If the PowerLink cable is not fully ‘latched’ the unit can

power intermittently.

Figure 2. Figure 3.

DISCONNECTING

Before removing the cable from the scanner, Metrologic recommends that the power on the host system is off and the power supply has been disconnected from the PowerLink cable.

Figure 4. Releasing the PowerLink Cable

1. Locate the small ‘pin-hole’ on the handle of the unit near the cable.

2. Bend an ordinary paperclip into the shape shown above.

3. Insert the paperclip (or other small metallic pin) into the small ‘pin-hole’.

4. You will here a faint ‘click’. Pull gently on the strain-relief of the PowerLink cable to remove the cable from the unit.

5

INTRODUCTION

Labels

Each scanner has a label located on the underside of the head. This label provides the unit’s model number, date of manufacture, serial number, CE and caution information. The following figure gives an example of the label and its location.

Figure 5. Label Samples and Location

Maintenance

Smudges and dirt can interfere with the proper scanning of a bar code. Therefore, the output window will need occasional cleaning.

1. Spray glass cleaner onto lint free, non-abrasive cleaning cloth.

2. Gently wipe the scanner window.

6

INSTALLING THE SCANNER TO THE HOST SYSTEM

RS232 MS1690-14

1. Turn off the host device.

2. Plug the male 10-pin RJ45 end of the PowerLink cable into the 10-pin socket on the Focus. You will hear a ‘click’ when the connection is made.

3. Connect the 9-pin D-type connector of the communication cable to the proper COM port of the host device.

4. Plug the power supply into the power jack on the PowerLink cable.

Check the AC input requirements of the power supply to make sure the voltage matches the AC outlet. The outlet must be located near the equipment and be easily accessible.

5. Connect AC power to the transformer.

6. Focus will start to initialize. All LEDs (yellow, white, and blue) will light for approximately 2 seconds then start to alternately flash. When the scanner has finished initializing the LEDs will stop flashing and the unit will beep 3 times indicating that the scanner is ready for use.

7. Turn on the host device.

Plugging the scanner into a port on the host system does not guarantee that scanned information will be communicated properly to the host system. The scanner is shipped from the factory configured with default settings. Please refer to the MetroSelect Single-Line Configuration Guide (MLPN 00-02544) or MetroSet2’s help files for instructions on changing the scanner’s configuration. In addition, please check that the scanner and host system are using the same communication protocol.

Caution:

To maintain compliance with applicable standards, all circuits connected to the scanner must meet the requirements for SELV (Safety Extra Low Voltage) according to EN/IEC 60950.

To maintain compliance with standard CSA-C22.2 No. 60950-00/UL 60950 and norm EN/IEC 60950, the power source should meet applicable performance requirements for a limited power source.

Figure 6.

7

INSTALLING THE SCANNER TO THE HOST SYSTEM

Keyboard Wedge MS1690-47

1. Turn off the host device.

2. Plug the 10-pin RJ45 male end of the PowerLink cable into 10-pin socket on the Focus. You will hear a ‘click’ when the connection is made.

3. Disconnect the keyboard from the host device.

4. Connect the “Y” ends of the communication cable to the keyboard and keyboard port on the host device. If necessary use the male/female adapter cable supplied with the scanner for proper connections.

5. Plug the external power supply (required) into the power jack on the PowerLink cable.

Check the AC input requirements of the power supply to make sure the voltage matches the AC outlet. The outlet must be located near the equipment and be easily accessible.

6. Connect AC power to the transformer.

7. Focus will start to initialize. All LEDs (yellow, white, and blue) will light for approximately 2 seconds then start to alternately flash. When the scanner has finished initializing the LEDs will stop flashing and the unit will beep 3 times indicating that the scanner is ready for use.

8. Turn on the host device.

Plugging the scanner into a port on the host system does not guarantee that scanned information will be communicated properly to the host system. The scanner is shipped from the factory configured with default settings. Please refer to the MetroSelect Single-Line Configuration Guide (MLPN 00-02544) or MetroSet2’s help files for instructions on changing the scanner’s configuration. In addition, please check that the scanner and host system are using the same communication protocol.

Caution: To maintain compliance with applicable standards, all circuits connected to the scanner must meet the requirements for SELV (Safety Extra Low Voltage) according to EN/IEC 60950.

To maintain compliance with standard CSA-C22.2 No. 60950-00/UL 60950 and norm EN/IEC 60950, the power source should meet applicable performance requirements for a limited power source.

Figure 7.

8

INSTALLING THE SCANNER TO THE HOST SYSTEM

Stand Alone Keyboard MS1690-47

1. Turn off the host device.

2. Plug the male 10-pin RJ45 end of the PowerLink cable into the 10-pin socket on the Focus. You will hear a ‘click’ when the connection is made.

3. Plug the other end of the communication cable into the host’s keyboard port.

4. Plug the external power supply into the power jack on the PowerLink cable.

Check the AC input requirements of the power supply to make sure the voltage matches the AC outlet. The outlet must be located near the equipment and be easily accessible.

5. Connect AC power to the transformer.

6. Focus will start to initialize. All LEDs (yellow, white, and blue) will light for approximately 2 seconds then start to alternately flash. When the scanner has finished initializing the LEDs will stop flashing and the unit will beep 3 times indicating that the scanner is ready for use.

7. Turn on the host device.

Plugging the scanner into a port on the host device does not guarantee that scanned information will be communicated properly to the host device. The scanner is shipped from the factory configured with default settings. Please refer to the MetroSelect Single-Line Configuration Guide (MLPN 00-02544) or MetroSet2’s help files for instructions on changing the scanner’s configuration. In addition, please check that the scanner and host system are using the same communication protocol.

Caution: To maintain compliance with applicable standards, all circuits connected to the scanner must meet the requirements for SELV (Safety Extra Low Voltage) according to EN/IEC 60950.

To maintain compliance with standard CSA-C22.2 No. 60950-00/UL 60950 and norm EN/IEC 60950, the power source should meet applicable performance requirements for a limited power source.

Figure 8.

9

INSTALLING THE SCANNER TO THE HOST SYSTEM

IBM MS1690-11

1. Turn off the host device.

2. Plug the male 10-pin RJ45 end of the MVC cable into the 10-pin socket on the Focus. You will hear a ‘click’ when the connection is made.

3. Connect the other end of the MVC cable to the host device.

4. Turn on the host device.

5. Focus will start to initialize. All LEDs (yellow, white, and blue) will light for approximately 2 seconds then start to alternately flash. When the scanner has finished initializing the LEDs will stop flashing and the unit will beep 3 times indicating that the scanner is ready for use.

Plugging the scanner into a port on the host system does not guarantee that scanned information will be communicated properly to the host system. The scanner is shipped from the factory configured with default settings. Please refer to the MetroSelect Single-Line Configuration Guide (MLPN 00-02544) or MetroSet2’s help files for instructions on changing the scanner’s configuration. In addition, please check that the scanner and host system are using the same communication protocol.

Caution: To maintain compliance with applicable standards, all circuits connected to the scanner must meet the requirements for SELV (Safety Extra Low Voltage) according to EN/IEC 60950.

To maintain compliance with standard CSA-C22.2 No. 60950-00/UL 60950 and norm EN/IEC 60950, the power source should meet applicable performance requirements for a limited power source.

Figure 9.

10

INSTALLING THE SCANNER TO THE HOST SYSTEM

Integrated USB:

Full Speed MS1690-40 Low Speed MS1690-38

1. Turn off the host device.

2. Plug the male 10-pin RJ45 end of the USB cable into the 10-pin socket on the Focus. You will hear a ‘click’ when the connection is made.

3. Plug the USB type A end of the USB cable into the host’s USB port.

4. Turn on the host device.

5. Focus will start to initialize. All LEDs (yellow, white, and blue) will light for approximately 2 seconds then start to alternately flash. When the scanner has finished initializing the LEDs will stop flashing and the unit will beep 3 times indicating that the scanner is ready for use.

As a default, the MS1690-38 leaves the factory with USB Keyboard Emulation Mode eabled.

For information on configuring the MS1690-38 for USB Serial Emulation Mode, please refer to the USB section of the MetroSelect Single-Line Configuration Guide (MLPN 00-02544).

Plugging the scanner into a port on the host device does not guarantee that scanned information will be communicated properly to the host device. The scanner is shipped from the factory configured with default settings. Please refer to the MetroSelect Single-Line Configuration Guide (MLPN 00-02544) or MetroSet2’s help files for instructions on changing the scanner’s configuration. In addition, please check that the scanner and host system are using the same communication protocol.

Caution: To maintain compliance with applicable standards, all circuits connected to the scanner must meet the requirements for SELV (Safety Extra Low Voltage) according to EN/IEC 60950.

To maintain compliance with standard CSA-C22.2 No. 60950-00/UL 60950 and norm EN/IEC 60950, the power source should meet applicable performance requirements for a limited power source.

Figure 10.

11

STAND KITS

STAND COMPONENTS, MLPN 46-00147

12

Figure 11. Stand Components

Item Description Qty.

a. Stand Base Qty. 1

b. Flexible Shaft Qty. 1

c. Flexible Shaft Cover Qty. 1

d. Scanner Cradle Qty. 1

e. ¼" – 20 x 3/8" Flat Head Phillips, 82° Undercut Qty. 2

f. #8 Round Head Wood Screw Qty. 2

STAND KITS

ARD MOUNTING THE STAND (OPTIONAL)

H

Metrologic provides two #8 wood screws for securing the stand base to the counter top. The following figure provides the pilot hole dimensions for securing the stand base.

Figure 12. Stand Base Hole Pattern (Not to Scale)

13

STAND KITS

ASSEMBLING THE STAND

14

Figure 13. Assembling the Stand

SCANNER OPERATION

TWO DEFAULT MODES OF OPERATION*

CodeGate, Out of Stand

1. The IR detects an object in the IR

activation range and automatically turns on linear illumination.

2. Aim the scanner’s line of light

over the bar code.

3. Pull the trigger to initiate scanning.

The scanner’s light output will start to flash as it attempts to scan the bar code.

If the trigger is released the scanner will stop trying to scan.

4. When scanner successfully reads the

bar code it will beep once, the white LED will flash and the decoded data will be transmitted to the host.

Figure 14. CodeGate, Out-of-Stand

Presentation, In-Stand

1. The IR detects an object in the IR activation range and the scanner’s

light output automatically starts to flash as it attempts to scan the bar code.

2. The scanner continuously attempts to scan the bar code until either it

succeeds or the bar code is removed from the scanner’s field of view.

3. When scanner successfully reads the bar code it will beep once, the

white LED will flash and the decoded data will be transmitted to the host.

* For additional configurable modes of operation, please refer to the MS1690

Focus Supplemental Configuration Guide (

MLPN 00-02065).

15

SCANNER OPERATION

Audible Indicators

When the Focus is in operation, it provides audible feedback. These sounds indicate the status of the scanner. Eight settings are available for the tone of the beep (normal, 6 alternate tones and no tone). To change the tone, refer to the MetroSelect Single-Line Configuration Guide, help files.

One Beep When the scanner successfully reads a bar code it will beep once and the

white LED will turn on indicating data is being transmitted.

If the scanner does not beep once and the white light does not turn on, then the bar code has not been successfully read.

MLPN 00-02544 or MetroSet2’s

Short Razzberry Tone

This tone is a failure indicator (see Failure Modes on page 18).

Long Razzberry Tone

This tone is a failure indicator (see Failure Modes on page 18).

Three Beeps - At Power Up

When Focus first receives power it will start an initialization sequence. All LEDs (yellow, white, and blue) will light for approximately 2 seconds then start to alternately flash. When the scanner has finished initializing the LEDs will stop flashing and the unit will beep 3 times indicating that the scanner is ready for use.

Three Beeps - Configuration Mode

When entering configuration mode, the white LED will flash while the scanner simultaneously beeps three times. The white and blue LEDs will continue to flash while in this mode. Upon exiting configuration mode, the scanner will beep three times, and the LEDs will stop flashing.

When configured, 3 beeps can also indicate a communications timeout during normal scanning mode.

When using single-code-configuring, the scanner will beep three times: a normal tone followed by a short pause, a high tone and then a low tone. This indicates that the single configuration bar code has successfully configured the scanner.

16

SCANNER OPERATION

Visual Indicators

The MS1690 has three LED indicators (yellow, white and blue) located on the top of the scanner. When the scanner is on, the flashing or stationary activity of the LEDs indicates the status of the current scan and the scanner.

No LEDs are Illuminated

The LEDs will not be illuminated if the scanner is not receiving power from the host or transformer.

The scanner is in stand-by mode. Present a bar code to the scanner and the blue LED will turn on when the IR detects the object.

Steady Yellow

The yellow LED is illuminated when the scanner is in the stand.

Steady Blue

The blue LED is illuminated when the scanner is active and linear illumination is on or when the scanner is attempting to decode a barcode.

Steady Blue and Single White Flash

When the scanner successfully reads a bar code it will beep once and the white LED will turn on indicating data is being transmitted.

If the scanner does not beep once and the white light does not turn on, then the bar code has not been successfully read.

Steady White

When the scanner successfully reads a bar code it will beep once and the white LED will turn on indicating data is being transmitted.

After a successful scan, the scanner transmits the data to the host device. Some communication modes require that the host inform the scanner when data is ready to be received. If the host is not ready to accept the information, the scanner’s white LED will remain on until the data can be transmitted.

Alternating Flashing of Blue and White

This indicates the scanner is in configuration mode. A short razzberry tone indicates that an invalid bar code has been scanned while in this mode.

Flashing Blue

The blue LED will flash if the trigger is pressed while the scanner is in the in-stand presentation mode. The blue LED will stop flashing after a brief period of time. .

Figure 15.

17

SCANNER OPERATION

Failure Modes

Long Razzberry Tone – During Power Up

Failed to initialize or configure the scanner. If the scanner does not respond after reprogramming, return the scanner for repair.

Short Razzberry Tone – During Scanning An Invalid bar code has been scanned when in configuration mode or the

trigger has been pulled too fast.

18

SCANNER OPERATION

Depth of Field by Minimum Bar Code Element Width

Figure 16. Depth of Field by Minimum Bar Code Element Width

1D PDF

A B C D E F G

mm

mils

Specifications are subject to change without notice.

.132 .19 .254 .33 .533

5.2 7.5 10.4 13 21

MINIMUM BAR CODE ELEMENT WIDTH

.254 .381

10 15.9

19

SCANNER OPERATION

IR Activation Range

The MS1690 has a built in object detection sensor that instantly turns on the scanner when an object is presented within the scanner’s IR activation Area.

Figure 17. IR Activation Area

Specifications are subject to change without notice.

20

TROUBLESHOOTING GUIDE

The following guide is for reference purposes only. Contact a Metrologic representative at 1-800-ID-Metro or 1-800-436-3876 to preserve the limited warranty terms.

All Interfaces

MS1690 Series Troubleshooting Guide

Symptoms Possible Causes Solution

No LEDs, beep or illumination

Long Razz tone on power up

Long Razz tone when exiting configuration mode

No power is being supplied to the scanner.

No power is being supplied to the scanner from the host.

The wrong communication cable has been used.

There has been a scanner configuration failure.

There has been a RAM or ROM failure.

There was a failure to save the new configuration.

Check transformer, outlet and power strip. Make sure the cable is plugged into the scanner.

Some host systems cannot supply enough current to power Focus. A power supply may be required.

Check that the communication cable matches the unit type and scanner configuration.

Contact a Metrologic service representative, if the unit will not hold the saved configuration.

Contact a Metrologic service representative, if the unit will not function.

Re-try to configure the scanner. Contact a Metrologic Service Representative if the unit will not hold the saved configuration.

Long Razz tone

Short Razz tone in configuration mode

There is a scanning mechanism failure.

An invalid bar code has been scanned.

Contact a Metrologic service representative.

Scan a valid bar code or quit configuration mode.

21

TROUBLESHOOTING GUIDE

Symptoms Possible Causes Solution

The unit powers up, but does not beep when bar code is scanned.

The unit powers up, but does not scan and/or beep.

The unit scans a bar code, but locks up after the first scan and the white LED stays on.

The beeper is disabled and no tone is selected.

The bar code symbology trying to be scanned is not enabled.

The scanner is trying to scan a barcode that does not match the configured criteria.

The scanner is configured to support some form of host handshaking but is not receiving the signal.

Enable the beeper and select a tone.

UPC/EAN, Code 39, interleaved 2 of 5, Code 93, Code 128, Codabar and PDF are enabled by default. Verify that the type of bar code being read has been selected.

Verify that the bar code being scanned falls into the configured criteria (i.e. character length lock or minimum bar code length settings).

If the scanner is setup to support ACK/NAK, RTS/CTS, or XON/XOFF, verify that the host cable and host are supporting the handshaking properly.

The unit scans, but the data transmitted to the host is incorrect.

22

The scanner’s data format does not match the host system requirements.

Verify that the scanner’s data format matches that required by the host. Make sure that the scanner is connected to the proper host port.

TROUBLESHOOTING GUIDE

Symptoms Possible Causes Solution

The unit beeps at some bar codes and NOT for others of the same bar code symbology.

The unit scans the bar code but there is no data.

The print quality of the bar code is suspect.

The aspect ratio of the bar code is out of tolerance.

The bar code may have been printed incorrectly.

The scanner is not configured correctly for this type of bar code.

The minimum symbol length setting does not work with the bar code.

The configuration is not set correctly.

Check print mode. The type of printer could be the problem. Change print settings (i.e. change to econo mode or high speed).

Check if it is a check digit/character/or border problem.

Check if check digits are set properly.

Check if the correct minimum symbol length is set.

Make sure the scanner is configured for the appropriate mode.

The unit scans but the data is not correct.

The configuration is not set correctly.

The scanner and host may not be configured for the same interface parameters.

Make sure that the proper PC type AT, or PS2 is selected. Verify correct country code and data formatting are selected. Adjust inter-character delay symptom.

Check that the scanner and the host are configured for the same interface parameters.

23

TROUBLESHOOTING GUIDE

Symptoms Possible Causes Solution

The unit is transmitting each character twice.

Alpha characters show as lower case.

Everything works except for a couple of characters.

The unit powers up OK and scans OK but does not communicate properly with the host.

The configuration is not set correctly.

The computer is in Caps Lock mode.

These characters may not be supported by that country’s key look up table.

The com port at the host is not working or not configured properly.

The cable is not connected to the correct com port.

Increase interscan code delay setting. Adjust whether the F0 break is transmitted. It may be necessary to try this in both settings.

Enable Caps Lock detect setting of the scanner to detect if the PC is operating in Caps Lock.

Try operating the scanner in Alt mode.

Check to make sure that the baud rate and parity of the scanner and the communication port match and the program is looking for “RS232” data.

Check to make sure that the cable is connected to the correct com port.

Characters are being dropped.

24

Inter-character delay needs to be added to the transmitted output.

Add some inter-character delay to the transmitted output by using the Configuration Guides (

MLPN 00-02544 and 00-02065).

DESIGN SPECIFICATIONS

MS1690 DESIGN SPECIFICATIONS

OPERATIONAL

Light Source: LED 645 nm

Pulse Duration: 1 ms to 8 ms

Maximum Output

of an Osram LED:

Depth of Scan Field:

Field of View:

Minimum Bar Width: 0.127 mm (5.0 mil)

Infrared Activation:

Decode Capability:

Maximum 85 mA emits 3,120 mlm

0 mm – 230 mm (0" – 9") for

0.330 mm (13 mil) Bar Code at Default Setting

49 mm W x 19 mm H (1.9” W x 0.8” H) at 20 mm (0.8”)

264 mm x 106 mm (10.4” W x 4.2” H) at 280 mm (11.0”)

Long Range: 0 mm – 203 mm (0" – 8") from Window

Short Range: 0 mm – 101 mm (0" – 4") from Window

Autodiscriminates All Standard 1-D, RSS, PDF417, microPDF, MaxiCode, Data Matrix, QR Code, UCC, EAN Composites, Postals, Aztec

(Image Transfer) – BMP, TIFF, or JPEG output

System Interfaces:

PC Keyboard Wedge, RS232, IBM 468X/469X, Stand Alone Keyboard, USB (Low Speed and Full Speed)

Print Contrast: 20% Minimum Reflectance Difference

Number Characters Read:

Up to 80 Data Characters on 1D; 1850 Text Characters for PDF417

Beeper Operation: 7 tones or no beep

Blue Unit Powered, Ready to Scan

Indicators (LED)

Default Settings:

White Good Read

Yellow In Stand

MECHANICAL

Height: 183 mm (7.2")

Width:

Handle - 30 mm (1.2")

Head - 79 mm (3.1")

Depth: 111 mm (4.9")

Weight: 225 g (8.0 oz)

Termination: 10 pin modular RJ45

Cable: Standard 2.7 m (9') Coiled; Optional 2.1 m (7’) Straight

Specifications are subject to change without notice.

25

DESIGN SPECIFICATIONS

MS1690 DESIGN SPECIFICATIONS

ELECTRICAL

Input Voltage: 5.0VDC ± 0.25V

Peak = 2 W (Typical)

Power:

Current:

DC Transformer: Class 2; 5.2VDC @ 650 mA

EMC: FCC, ICES-003 & EN55022 Class A

Class 1 LED Product: IEC 60825-1:1993+A1:1997+A2:2001

ENVIRONMENTAL

Temperature:

Humidity: 5% to 95% Relative Humidity, Non-Condensing

Light Levels: Up to 4842 Lux (450 Footcandles)

Shock: Designed to withstand 1.8 m (6’) drops

Contaminants: Sealed to resist airborne particulate contaminants

Operating = 1.65 W (Typical)

Idle / Standby = 800 mW (Typical)

Peak = 400 mA (Typical)

Operation = 330 mA (Typical)

Idle / Standby = 160 mA (Typical)

Operating = 0°C to 40° (32° to 104°F)

Storage = -40°C to 60°C (-40°F to 140°F)

Specifications are subject to change without notice..

Ventilation: None required

26

APPLICATIONS AND PROTOCOLS

The model number on each scanner includes the scanner number and factory default communications protocol.

SCANNER

VERSION

IDENTIFIER

COMMUNICATION PROTOCOL(S)

11 IBM 468X/469X, RS232-TXD, RXD, RTS, CTS

14 RS232 (TX, RX, RTS, CTS, DTR)

MS1690 -

38 Low Speed USB

40 Full-speed USB

47

Keyboard Wedge, Stand-Alone Keyboard and RS232 Transmit/Receive

The MS1690-47 with a built-in PC Keyboard Wedge Interface is designed for Keyboard emulation use only. Many RS232 configurable functions available in other Metrologic scanners are also available as keyboard wedge functions.

The following are the most important selectable options specific to the keyboard wedge.

Keyboard Type

• **AT (includes IBM® PS2 models 50, 55, 60, 80)

• IBM PS2 (includes models 30, 70, 8556)

Keyboard Country Type

• **USA • German • Spanish

• Belgium • Italian • Swiss

• French • Japanese • United Kingdom

** For additional information on the MS 1690’s default settings refer to

pages 28-31. For information on how to change the default settings, refer to help files in MetroSet2 or the MetoSelect Single-Line Configuration Guide (

MLPN 00-02544).

27

DEFAULT SETTINGS – COMMUNICATION PARAMETERS

Many functions of the scanner can be “configured” – that is, enabled or disabled. The scanner is shipped from the factory programmed to a set of default conditions. The default parameter of the scanner has an asterisk (*) in the charts on the following pages. If an asterisk is not in the default column then the default setting is OFF or DISABLED. Every interface does not support every parameter. If the interface supports a parameter listed in the charts on the following pages, a check mark (9) will appear.

PARAMETER DEFAULT RS232 IBM 46XX KBW USB

Multi-Try Trigger Out-of-Stand *

Presentation Mode In-Stand *

Continuous Trigger

Single Trigger

Aiming in Trigger and Continuous Modes

Aiming in Presentation Mode

Long-Range In-Stand *

Short-Range In-Stand

Long-Range Out-of-Stand *

Short-Range Out-of-Stand

UPC/EAN *

Code 128 *

Code 93 *

Codabar *

Interleaved 2 of 5 (ITF) *

MOD 10 check on ITF

Code 11

Code 39 *

Full ASCII Code 39

PDF *

Data Matrix

QR Code

9

*

9

9 9 9

28

DEFAULT SETTINGS – COMMUNICATION PARAMETERS

PARAMETER DEFAULT RS232 IBM 46XX KBW USB

Maxicode

Aztec

Postals

Mod 43 Check on Code 39

MSI-Plessy 10/10 Check Digit

MSI-Plessy Mod 10 Check Digit *

Paraf Support ITF

ITF Symbol Lengths Variable

Symbol Length Lock None

Beeper tone Normal

Beep/transmit sequence

Communication timeout None

Razzberry tone on timeout

Three beeps on timeout

Same symbol rescan timeout: 1000 msecs

Same symbol rescan timeout configurable in 50 msec steps (maximum of 6.35 sec.)

No Same symbol timeout

Before

transmit

*

9

9 9 9

Infinite Same symbol timeout

Inter-character delay configurable in 1 msec steps (maximum of 255 msecs)

Number of scan buffers (maximum)

Transmit UPC-A check digit *

Transmit UPC-E check digit

Expand UPC-E

Convert UPC-A to EAN-13

1 msecs

10 msecs

in KBW

8

9

9 9 9

29

DEFAULT SETTINGS – COMMUNICATION PARAMETERS

PARAMETER DEFAULT RS232 IBM 46XX KBW USB

Transmit lead zero on UPC-E

Transmit UPC-A number system *

Transmit UPC-A Manufacturer ID# *

Transmit UPC-A Item ID# *

Transmit Codabar Start/Stop Characters

CLSI Editing (Enable)

Transmit Mod 43 Check digit on Code 39

Transmit Mod 10/ITF

Transmit MSI-Plessy

Parity No

Baud Rate 9600

8 Data Bits *

7 Data Bits

Stop Bits 1

Transmit Sanyo ID Characters

Nixdorf ID

LRC Enabled

UPC Prefix

UPC Suffix

Carriage Return *

Line Feed-Disabled by default in KBW

Tab Prefix

Tab Suffix

“DE” Disable Command

Enable Command

DTR Handshaking support

RTS/CTS Handshaking

Character RTS/CTS *

Message RTS/CTS

30

9

*

9

9 9 9

9

DEFAULT SETTINGS – COMMUNICATION PARAMETERS

PARAMETER DEFAULT RS232 IBM 46XX KBW USB

XON/XOFF Handshaking

ACK/NAK

Two Digit Supplements

Five Digit Supplements

Bookland

977 (2 digit) Supplemental Requirement

Supplements are not Required *

Two Digit Redundancy *

Five digit Redundancy

Coupon Code 128

† Configurable Code Lengths 7 avail

† Code Selects with configurable

Code Length Locks

Configurable Prefix characters 10 avail

Suffix characters 10 avail

3 avail

9

9 9 9 9

9

Prefixes for Individual Code types

Editing

Function/Control Key Support *

Omnidirectional Scanning *

Linear Only Scanning

Linear 1D / Omni 2D

9

9 9 9 9

9

† These options are mutually exclusive. One can not be used in conjunction with the

other.

31

CONFIGURATION MODES

The MS1690 Focus Series has three modes of configuration.

• Bar Codes The MS1690 can be configured by scanning the bar codes included in the Metrologic Single-Line Configuration Guide ( can be downloaded for FREE from Metrologic’s website (www.metrologic.com).

• MetroSet2 This user-friendly Windows-based configuration program allows you to simply ‘point-and-click’ at the desired scanner options. This program can be downloaded for FREE from Metrologic’ website (www.metrologic.com) or set-up disks can be ordered by calling 1-800-ID-METRO.

• Serial Programming This mode of configuration is ideal for OEM applications. This mode gives the end-user the ability to send a series of commands using the serial port of the host system. The commands are equivalent to the numerical values of the bar codes located in the MetroSelect Single-Line Configuration Guide (

MLPN 00-02544).

MLPN 00-02544). This manual

32

UPGRADING THE FLASH ROM FIRMWARE

The MetroSet2 program is a functional component of Metrologic’s new line of Flash- based scanners. This program allows the user of a Metrologic scanner to quickly upgrade to a new or custom version of firmware. It requires the use of a personal computer running Windows 95 or greater and the use of a serial port. The user merely connects the scanner to a serial port on the PC, launches the MetroSet2 program, and blasts off to new software upgrades.

Each MS1690, regardless of the version number or communication protocol, can be upgraded. In other words, all RS232 (-14), keyboard wedge (-47), IBM 468X/469X (-11), low speed USB (-38), and full speed USB (-40) units can be upgraded. To upgrade all units, a power supply and PowerLink cable (

MLPN 54-54014) are required.

RS232 units can be upgraded using the standard PowerLink cable (

MLPN 53-53xxx-3).

The program guides the user with its simplistic one click approach. The user must first select the file. Once the file is selected and verified, the scanner is ready to be upgraded. Press the “Flash Scanner” button to upgrade the scanner. The unit will go into a “flash mode” – the blue and white LEDs will be flashing alternately. The user can follow the progress of the upgrade by watching the screen for details. When the upgrade is complete, the scanner will reset itself. If a razz/beep occurs, the scanner did not upgrade properly. Contact a Metrologic service representative for additional assistance.

MetroSet2 incorporates all functions that were previously in Meteor.

33

SCANNER AND CABLE TERMINATIONS

Scanner Pinout Connections

The MS1690 scanner interfaces terminate to a 10-pin, RJ45 Female Socket. The serial # label indicates the interface enabled when the scanner is shipped from the factory.

Pin Function

1 Ground 2 RS232 Transmit Output 3 RS232 Receive Input 4 RTS Output 5 CTS Input 6 DTR Input 7 Reserved 8 Reserved 9 +5VDC

10 Shield Ground

MS1690-47, Keyboard Wedge &

Pin Function

1 Ground 2 RS232 Transmit Output 3 RS232 Receive Input 4 PC Data 5 PC Clock 6 KB Clock 7 PC +5V 8 KB Data 9 +5VDC

10 Shield Ground

MS1690-11, IBM 468X/469X

MS1690-14, RS232

Stand-Alone Keyboard

34

Figure 18.

Pin Function

1 Ground 2 RS232 Transmit Output 3 RS232 Receive Input 4 RTS Output 5 CTS Input 6 Reserved 7 IBM B-Transmit 8 IBM A+ Receive 9 +5VDC

10 Shield Ground

SCANNER AND CABLE TERMINATIONS

MS1690-38, Low Speed USB

Pin Function

1 GND/USB2 Transmit 3 Receive 4 RTS Output 5 CTS Input 6 D+ 7 USB + V 8 D9 +5VDC

10 Shield Ground

MS1690-40, Full Speed USB

Pin Function

1 GND/USB2 Transmit 3 Receive 4 RTS Output 5 CTS Input 6 D+ 7 USB + V 8 D9 +5VDC

10 Shield Ground

Figure 19.

35

r

SCANNER AND CABLE TERMINATIONS

Cable Connector Configurations (Host End)

“Standard” PowerLink Cable

53-53000-3 Coiled

Pin Function

1 Shield Ground 2 RS232 Transmit Output 3 RS232 Receive Input 4 DTR Input/Light Pen Source 5 Power/Signal Ground 6 Reserved

CTS Input

7

8 RTS Output 9 +5VDC

Stand Alone Keyboard PowerLink

53-53020-3

Cable

Pin Function

1 PC Data 2 NC 3 Power Ground 4 +5VDC PC Power to KB 5 PC Clock 6 NC

USB Power/Communication Cable

53-53213-N-3, 53-53214-N-3 or

53-53235-N-3

Pin Function

1 PC +5V/V_USB 2 D3 D+ 4 Ground

Shield Shield

Locking with Power

-Pin D-T

6-Pin Male Mini-DIN Connecto

USB Type A

95

61

nn

1

2

4

3

5

6

USB

Non-Locking

36

SCANNER AND CABLE TERMINATIONS

Cable Connector Configuration (Host End)

Keyboard Wedge PowerLink Cable

Pin Function

1 Keyboard Clock 2 Keyboard Data 3 No Connect 4 Power Ground 5 +5 VDC

Pin Function

1 PC Data 2 No Connect 3 Power Ground 4 +5 VDC

5 PC Clock 6 No Connect

Metrologic will supply an adapter cable with a 5-pin DIN male connector on one end and a 6-pin mini DIN female connector on the other. According to the termination required, connect the appropriate end of the adapter cable to the PowerLink cable, leaving the necessary termination exposed for connecting to the keyboard and the keyboard port on the PC.

Keyboard Wedge Adapter Cable

Pin Function

1 PC Clock 2 PC Data 3 No Connect 4 Power Ground 5 +5 VDC

Pin Function

1 Keyboard Data 2 No Connect 3 Power Ground 4 +5 VDC 5 Keyboard Clock 6 No Connect

53-53002-3 Coiled

2

5

4

1

3

5-Pin DIN, Female

1

2

4

3

5

6

6-Pin DIN, Male

2

4

5

3

1

5-Pin DIN, Male

2

1

3

4

5 6

6-pin Mini DIN, Female

37

LIMITED WARRANTY

The MS1690 Focus™ scanners are manufactured by Metrologic at its Blackwood, New Jersey, U.S.A. facility. The MS1690 Focus scanners have a five (5) year limited warranty from the date of manufacture. Metrologic warrants and represents that all MS1690 Focus scanners are free of all defects in material, workmanship and design, and have been produced and labeled in compliance with all applicable U.S. Federal, state and local laws, regulations and ordinances pertaining to their production and labeling.

This warranty is limited to repair, replacement of product or refund of product price at the sole discretion of Metrologic. Faulty equipment must be returned to one of the following Metrologic repair facilities: Blackwood, New Jersey, USA; Madrid, Spain; or Suzhou, China. To do this, contact the appropriate Metrologic Customer Service/Repair Department to obtain a Returned Material Authorization (RMA) number.

In the event that it is determined the equipment failure is covered under this warranty, Metrologic shall, at its sole option, repair the Product or replace the Product with a functionally equivalent unit and return such repaired or replaced Product without charge for service or return freight, whether distributor, dealer/reseller, or retail consumer, or refund an amount equal to the original purchase price.

This limited warranty does not extend to any Product which, in the sole judgment of Metrologic, has been subjected to abuse, misuse, neglect, improper installation, or accident, nor any damage due to use or misuse produced from integration of the Product into any mechanical, electrical or computer system. The warranty is void if the case of Product is opened by anyone other than Metrologic’s repair department or authorized repair centers.

THIS LIMITED WARRANTY, EXCEPT AS TO TITLE, IS IN LIEU OF ALL OTHER WARRANTIES OR GUARANTEES, EITHER EXPRESS OR IMPLIED, AND SPECIFICALLY EXCLUDES, WITHOUT LIMITATION, WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE UNDER THE UNIFORM COMMERCIAL CODE, OR ARISING OUT OF CUSTOM OR CONDUCT. THE RIGHTS AND REMEDIES PROVIDED HEREIN ARE EXCLUSIVE AND IN LIEU OF ANY OTHER RIGHTS OR REMEDIES. IN NO EVENT SHALL METROLOGIC BE LIABLE FOR ANY INDIRECT OR CONSEQUENTIAL DAMAGES, INCIDENTAL DAMAGES, DAMAGES TO PERSON OR PROPERTY, OR EFFECT ON BUSINESS OR PROPERTY, OR OTHER DAMAGES OR EXPENSES DUE DIRECTLY OR INDIRECTLY TO THE PRODUCT, EXCEPT AS STATED IN THIS WARRANTY. IN NO EVENT SHALL ANY LIABILITY OF METROLOGIC EXCEED THE ACTUAL AMOUNT PAID TO METROLOGIC FOR THE PRODUCT. METROLOGIC RESERVES THE RIGHT TO MAKE ANY CHANGES TO THE PRODUCT DESCRIBED HEREIN.

CORPORATE HEADQUARTERS, NORTH AMERICA

Metrologic Instruments, Inc. Metrologic Eria Ibérica, SL

90 Coles Rd. C/Alfonso Gomez, 38-40, 1D Blackwood, NJ 08012-4683 28037 Madrid Customer Service Department Tel: +34 913 751 249 Tel: 1-800-ID-METRO Fax: +34 913 270 437 Fax: 856-228-6673 Email: info@metrologic.com

AUTO ID INSTRUMENTS (SHANGHAI) CO., LTD

MTLG Suzhou Sales Office

BLK A, Room# 03/03-04 No.5 Xinghan Street, Xinsu Industrial Square China-Singapore Suahou Industrial Park, Suzhou, PRC Tel: 86-512-67622550 Fax: 86-512-67622560 Email: info@cn.metrologic.com

METROLOGIC EUROPEAN REPAIR CENTER (MERC)

38

PRODUCT SAFETY

Notices

This equipment has been tested and found to comply with limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference, in which case the user will be required to correct the interference at his own expense. Any unauthorized changes or modifications to this equipment could void the users’ authority to operate this device.

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Notice This Class A digital apparatus complies with Canadian ICES-003.

Remarque Cet appareil numérique de la classe A, conformé a la norme NMB-003 du Canada.

39

PRODUCT SAFETY

Caution

Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure. Under no circumstances should the customer attempt to service the LED scanner. Never attempt to look at the LED beam, even if the scanner appears to be nonfunctional. Never open the scanner in an attempt to look into the device. Doing so could result in hazardous radiation exposure. The use of optical instruments with the LED equipment will increase eye hazard.

Atención

La modificación de los procedimientos, o la utilización de controles o ajustes distintos de los especificados aquí, pueden provocar una exposición de luz brillante peligrosa. Bajo ninguna circunstancia el usuario deberá realizar el mantenimiento del LED (Diodo Emisor de Luz) del lector. Ni intentar mirar al haz del LED incluso cuando este no esté operativo. Tampoco deberá abrir el lector para examinar el aparato. El hacerlo puede conllevar una exposición peligrosa a la luz del LED. El uso de instrumentos ópticos con el equipo LED puede incrementar el riesgo para la vista.

Attention

L'emploi de commandes, réglages ou procédés autres que ceux décrits ici peut entraîner de graves irradiations. Le client ne doit en aucun cas essayer d'entretenir lui-même le scanner ou la LED. Ne regardez jamais directement le rayon LED, même si vous croyez que le scanner est inactif. N'ouvrez jamais le scanner pour regarder dans l'appareil. Ce faisant, vous vous exposez à un risque d’irradiation. L'emploi d'appareils optiques avec cet équipement à LED augmente le risque d'endommagement de la vision.

Achtung

Die Verwendung anderer als der hier beschriebenen Steuerungen, Einstellungen oder Verfahren kann eine gefährliche Licht emittierender Dioden strahlung hervorrufen. Der Kunde sollte unter keinen Umständen versuchen, den Licht emittierender Dioden-Scanner selbst zu warten. Sehen Sie niemals in den Licht emittierender Diodenstrahl, selbst wenn Sie glauben, daß der Scanner nicht aktiv ist. Öffnen Sie niemals den Scanner, um in das Gerät hineinzusehen. Wenn Sie dies tun, können Sie sich einer gefährlichen Licht emittierender Diodenstrahlung aussetzen. Der Einsatz optischer Geräte mit dieser Laserausrüstung erhöht das Risiko einer Sehschädigung.

Attenzione L'utilizzo di sistemi di controllo, di regolazioni o di procedimenti diversi da quelli descritti nel presente Manuale può provocare delle rischiose esposizioni radiattive. Il cliente non deve assolutamente tentare di riparare egli stesso lo scanner LED (o diodo emettitore di luce). Non guardate mai il raggio LED (d. emettitore di luce), anche se credete che lo scanner non sia attivo. Non aprite mai lo scanner per guardare dentro l'apparecchio. Facendolo potete esporVi ad una radiazione rischiosa. L'uso di apparecchi ottici, equipaggiati con raggi LED (d. emettitori di luce), aumenta il rischio di danni alla vista.

40

PATENTS

Worldwide Patents Pending

41

INDEX

A

AC ..................................2, 7–11, 26

Accessories....................................2

Adapter ....................................2, 37

Aperture .........................................4

Audible Indicator ..............17–18, 33

B

Bar Code................... 21–24, 25, 32

Bar Code Element........................19

Beep.............. 17–18, 21–24, 25, 33

Blue LED........... 4, 7–11, 17–18, 33

Depth of Field ..............................19

E

EMC............................................. 26

F

Firmware...................................... 33

Flash ROM ..................................33

H

Host .....................................5, 7–11

C

Cable..............................................3

IBM ...........................................10

Keyboard Wedge ...........8, 36–37

MVC ...........................................3

PowerLink....... 2, 5, 7–11, 21–24,

33, 36–37

RS232 ............................7, 36–37

Stand Alone Keyboard ...9, 36–37

USB ..............................11, 36–37

Caution........................ 7–11, 39–40

CE ..................................6, 7–11, 40

Class ............................................39

CodeGate.............................1, 4, 15

Communication Parameters ..28–31

Compliance........... 7–11, 38, 39–40

Configuration... 2, 21–24, 27, 32, 33

Connector Pinouts .................34–35

Converter .....................................11

Current.........................................26

Customer Service ................2, 3, 38

D

DC................... 2, 26, 34–35, 36–37

Decode.........................................25

Default Parameters..........27, 28–31

IBM .....................................28–31

Keyboard Wedge ...............28–31

RS232 ................................28–31

Stand Alone Keyboard .......28–31

USB ....................................28–31

I

Indicator

Audible ...............4, 17–18, 25, 33

Failure ............................ 4, 17–18

Visual .................4, 17–18, 25, 33

Interface...........................21–24, 25

Cable........................7–11, 36–37

IBM.....1, 3, 10, 27, 28–31, 34–35

Keyboard Wedge ........1, 2, 8, 27,

28–31, 34–35

RS232 .............1, 2, 7, 27, 28–31,

34–35

Stand Alone Keyboard......1, 2, 9,

27, 28–31, 34–35

USB...............1, 3, 11, 27, 28–31,

34–35

IR .......................................1, 15, 20

K

Keyboard Country Type...............27

Keyboard Type ............................27

Keyboard Wedge...........................2

L

Labels ............................................ 6

LED............7–11, 21–24, 25, 39–40

Blue..........................7–11, 17–18

White........................7–11, 17–18

Yellow ......................7–11, 17–18

Light Levels .................................26

Light Source ................................25

42

INDEX

M

Maintenance ..................................6

Meteor..........................................33

MetroSelect......................16, 27, 32

MetroSet2 ....................................33

Mode of Operation .......................15

N

Notices .........................................39

Stand ...........................3, 12–14, 15

Stand Alone Keyboard...................2

Swiftdecoder

T

Tone.......................................17–18

Alternate................................... 16

Transformer ................... 2, 7–11, 26

Trigger ...........................................4

Troubleshooting.....................21–24

™

...............................1

P

Patent...........................................41

PDF..............................................19

Pinouts ...................... 34–35, 36–37

Power.......................... 7–11, 26, 33

Power Supply.......................5, 7–11

PowerLink ......................................4

Presentation.................................15

Product Safety .......................39–40

Protocols......................................27

R

Razz.......................... 17–18, 21–24

Repair ..........................................38

RMA .............................................38

RS232 ............................................2

S

SELV........................................7–11

Service .........................................38

Specifications

Electrical...................................26

Environmental ..........................26

Mechanical ...............................25

Operational...............................25

U

UL ........................................6, 7–11

Upgrade.......................................33

USB

Full Speed.....1, 3, 11, 27, 28–31,

34–35

Low Speed ....1, 3, 11, 27, 28–31,

34–35

V

Ventilation....................................26

Visual Indicator ................17–18, 33

Voltage ........................................26

W

Warranty ...................................... 38

White LED .........4, 7–11, 17–18, 33

Window......................................4, 6

Y

Yellow LED ..............4, 7–11, 17–18

43

NOTES

44

CONTACT INFORMATION AND OFFICE LOCATIONS

CORPORATE HEADQUARTERS NORTH AMERICA

USA, New Jersey

Metrologic Instruments, Inc. Metrologic Instruments GmbH Tel: 1-800-ID-METRO Fax: 856-228-6673 Tel: 49-89-89019-0 Fax: 49-89-89019-200 Email: info@metrologic.com Email: info@europe.metrologic.com

SOUTH AMERICA AND CENTRAL AMERICA

Brazil São Paulo

Metrologic do Brasil Ltda. Email: info@de.metrologic.com Tel: 55-11-5182-8226 Fax: 55-11-5182-8315 Email: info@br.metrologic.com

Tel: 49-89-89019-222 Fax: 49-89-89019-173

Outside Brazil São Paulo

Metrologic South America Tel: 55-11-5182-7273 Fax: 55-11-5182-7198 Metrologic Instruments Italia srl Email: info@sa.metrologic.com Tel: +39 0 51 6511978 Fax: +39 0 51 6521337

Email: info@it.metrologic.com

ASIAN HEADQUARTERS

Asia, Singapore

Metrologic Asia (Pte) Ltd Tel: (65) 6842-7155 Fax: (65) 6842-7166 Tel: +33 (0) 1 48.63.78.78 Email: info@sg.metrologic.com Fax: +33 (0) 1 48.63.24.94 Email: info@fr.metrologic.com

China

MTLG Auto ID Instruments (Shanghai) Co., Ltd Tel: 86-2158692780 Fax: 86-21-58692782 Metrologic Eria Ibérica, SL Email: info@cn.metrologic.com Tel: +34 913 272 400 Fax: +34 913 273 829 Email: info@es.metrologic.com Metro (Suzhou) Sales Office Tel: 86-512-67622550 Fax: 86-512-67622560 Metrologic European Repair Center (MERC) Email: info@cn.metrologic.com Metrologic Eria Ibérica, SL Tel: +34 913 751 249 Fax: +34 913 270 437 Guangzhou Sales Office Tel/: 86-20-38823476 Fax: 86-20-38823477 Email: info@cn.metrologic.com Metrologic Instruments UK Limited Tel: +44 (0) 1256 365900 Beijing Sales Office Fax: +44 (0) 1256 365955 Tel/Fax: 86 10 82253472 Email: info@uk.metrologic.com Email: info@cn.metrologic.com

Japan, Tokyo

Metrologic Japan Co., Ltd. Tel: 81-03-3839-8511 Fax: 81-03-3839-8519 Email: info@ru.metrologic.com Email: info@jp.metrologic.com

India, Bangalore

Metrologic India Tel: +48 (22) 545 04 30 Tel: +91 80 51256718 Fax: +91 80 51256719 Fax: +48 (22) 545 04 31 Email: info@in.metrologic.com Email: info@pl.metrologic.com

EUROPEAN, MIDDLE EAST & AFRICAN HEADQUARTERS

Germany, Munich

Germany, Austria and Switzerland

Tel: 49-89-89019-0 Fax: 49-89-89019-200

Eastern Europe and Middle East

Italy, Bologna

France, Paris

Metrologic Eria France SA

Spain, Madrid

United Kingdom, Basingstoke

Russia, Moscow

Metrologic Russia

Tel: +7 095 730 7424 Fax: +7 095 730 7425

Poland, Warsaw

Metrologic Instruments Poland Sp.z o.o

45

April 2005

Printed in the USA

00-02098B

Metrologic Instruments MS1690 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

MS1690 Focus

TABLE OF CONTENTS

INTRODUCTION

Scanner and Accessories

Scanner Components

THE POWERLINK CABLE

CONNECTING

DISCONNECTING

Labels

Maintenance

INSTALLING THE SCANNER TO THE HOST SYSTEM

RS232 MS1690-14

Keyboard Wedge MS1690-47

Stand Alone Keyboard MS1690-47

IBM MS1690-11

STAND KITS

STAND COMPONENTS, MLPN 46-00147

ASSEMBLING THE STAND

SCANNER OPERATION

CodeGate, Out of Stand

Presentation, In-Stand

Failure Modes

Depth of Field by Minimum Bar Code Element Width

IR Activation Range

TROUBLESHOOTING GUIDE

DESIGN SPECIFICATIONS

OPERATIONAL

MECHANICAL

ELECTRICAL

ENVIRONMENTAL

APPLICATIONS AND PROTOCOLS

CONFIGURATION MODES

UPGRADING THE FLASH ROM FIRMWARE

SCANNER AND CABLE TERMINATIONS

Scanner Pinout Connections

Cable Connector Configurations (Host End)

LIMITED WARRANTY

PRODUCT SAFETY

Notices

PATENTS

INDEX

CONTACT INFORMATION AND OFFICE LOCATIONS
