Metrologic Instruments MLPN 2407 User Manual

MetroSelect™Configuration Guide

MLPN 2407/February 2000

i

MetroSelect

™

Locations

USA Corporate Headquarters

Metrologic Instruments, Inc.
90 Coles Road
Blackwood, NJ 08012-4683
Tel: [phone]
Fax: [phone]
Email: [e-mail]
www.metrologic.com

Europe

Metrologic Instruments GmbH
Dornierstrasse 2
82178 Puchheim b.
Munich, Germany
Tel: [phone]
Fax: [phone]
Email: [e-mail]

Asia

Metrologic Asia (Pte) Ltd
31 Kaki Bukit Road 3
#05-08 Techlink
Singapore 417818
Tel: [phone]
Fax: [phone]
Email: [e-mail]

Brazil

Metrologic do Brasil Ltda.
Rua Flórida, 1821-5˚Andar
São Paulo, SP, Brasil
CEP: 04571-090
Tel: [phone]
Fax: [phone]
Email: [e-mail]

South America

Metrologic South America
Rua Flórida, 1821-5˚ Andar
São Paulo, SP, Brasil
CEP: 04571-090

Tel: [phone]
Fax: [phone]
Email: [e-mail]

China

Metro (Suzhou) Technologies Co., Ltd.
221 Xing Hai Street
Suzhou Industrial Park
Suzhou, China 215021
Tel: [phone]
Fax: [phone]
Email: [e-mail]

Spain

Metrologic Eria Ibérica SL
Julián Carmarillo, 29 D-1
Bajo 28037 Madrid
Tel: [phone]
Fax: [phone]
Email: [e-mail]

Copyright

©2000 by Metrologic ® Instruments, Inc. All rights reserved. No part of this work may be reproduced, transmitted, or stored in any
form or by any means without prior written consent except by the reviewer who may quote brief passages in a review, or provided for
in the Copyright Act of 1976.

Products and brand names mentioned in this document are trademarks of their respective companies.

MetroSelect

™

Table of Contents

Introduction iii
Section A: Code Types & Decode Rules A
Section B: Supplements B
Section C: Communications C
Section D: Scanner Operation D
Section E: Prefixes/Suffixes E
Section F: Code Formatting F
Section G: RS-232 G
Section H: Keyboard H
Section I: OCIA I
Section J: Light Pen Parameters J
Section K: IBM 46xx K
Section L: MS9500 Voyager™ L
Section M:Code Bytes M
Section N: Miscellaneous Features N

ii

iii

MetroSelect

™

Introduction

Your new scanner has been configured at the factory with default settings.

Many host systems have unique formats and protocol requirements. Therefore, Metrologic
provides a wide range of configurable features that may be selected using this bar code based
configuration tool. Once the configuration is completed, the scanner stores the settings in
nonvolatile memory (NOVRAM). NOVRAM saves the settings when the power is turned off.

Note: Every bar code with an “ * ” (asterisk) is a default setting.

Bar codes with a “~” (tilde) require multi-code configuration method.

Directions

The MetroSelect class of scanners can be bar code configured in two ways: Single Code
Method and Multi-Code Method.

Single Code Method: Most features can be enabled or disabled using the single code
method. Scan the bar code next to the feature. The scanner will give a “good scan” beep. A
multi-tone beep will follow to indicate the configuration has been saved to NOVRAM.

Multi-Code Method: All features can be enabled or disabled using the multi-code
method. A feature with a “~” requires the multi-code method. To use the multi-code
method, scan the “Enter/Exit Configuration Mode” code. Next, scan the codes for the
needed feature. Then scan the Enter/Exit Configuration Code to exit and save the configura­tion changes. To abort a configuration change, power off the scanner before scanning the
Enter/Exit code.

MetroSelect

™

Bar Code Configuration Methods

Single Code Method

1. Power up scanner

2. Scan the bar code for the desired feature

3. Observe a “good scan” beep, quickly followed by a multi-toned,
“save setting” beep.

Multi-Code Method

1. Power up scanner

2. Scan Enter/Exit Configuration Mode bar code

(3 beeps)

3. Scan bar code for the desired feature

(1 beep)

4. Scan Enter/Exit Configuration Mode bar code

(3 beeps) and save new configuration.

999999

Enter/Exit

Configuration Mode

iv

999998

v

MetroSelect

™

Need to start over?

Use the Recall Default bar code. This will erase all previous settings and return to the scanner’s default
communications protocol.

-Keyboard Wedge interface scanners will load keyboard wedge defaults.

-All other scanners load RS-232 defaults.

Note: Metrologic manufactures custom OEM scanners which load the OEM’s defaults. Section N will
explain how this affects “Metrologic Defaults.”

Recall Defaults

999998

MetroSelect

™

Section A

Code Types and Decode Rules

UPC-EAN A-1
Code 128 A-3
Code 39 A-4
Interleaved 2 of 5 A-6
Standard 2 of 5 A-8
Other 2 of 5 Codes A-9
Codabar A-10
Code 93 A-11
Code 11 A-11
Telepen A-12
Plessey Codes A-13
Other Decode Features A-15
Configurable Code Lengths A-16

A

A-1

MetroSelect

™

UPC/EAN

*Enable UPC/EAN Disable UPC/EAN

100116

*Enable UPC-A Disable UPC-A

100216

100106

100206

*Enable UPC-E Disable UPC-E

100210

100200

MetroSelect

™

*Enable EAN-13 Disable EAN-13

100211

100201

*Enable EAN-8 Disable EAN-8

100214

100204

A-2

A-3

MetroSelect

™

Code 128

*Enable Code 128 Disable Code 128

100113

Enable UCC/EAN - 128

‘]C1’ Code formatting

100314

100103

*Disable UCC/EAN -128

‘]C1’ Code formatting

100304

For Coupon Code 128,

see Section B.

MetroSelect

Code 39

™

*Enable Code 39

100111

Enable MOD 43

Check on Code 39

100213

When enabled, the scanner will only
scan Code 39 bar codes that have a
valid Modulo 43 check digit.

Disable Code 39

100101

*Disable MOD 43 Check on

Code 39

100203

The scanner will not test Code 39
bar codes for a Modulo 43 check
digit.

Enable Full ASCII Code 39 *Disable Full ASCII Code 39

100217

100207

A-4

A-5

MetroSelect

™

Enable PARAF (Italian
Pharmaceutical Codes)

Support

100215

When enabled, the scanner will

convert Code 39 bar codes to

PARAF format.

Enable TRI-OPTIC Code

100312

*Disable PARAF Support

100205

When disabled, the scanner will not
convert Code 39 bar codes to PARAF
format.

*Disable TRI-OPTIC Code

100302

MetroSelect

™

Interleaved 2 of 5

*Enable Interleaved

2 of 5 (ITF)

100115

Enable MOD 10

Check on ITF

100310

When option enabled, the scanner will
only scan Interleaved 2 of 5 (ITF) bar
codes that have a Modulo 10 check
digit.

Disable Interleaved

2 of 5 (ITF)

100105

*Disable MOD 10

Check on ITF

100300

When option disabled, the scanner will
not test Interleaved 2 of 5 (ITF) bar
codes for a Modulo 10 check digit.

A-6

A-7

MetroSelect

™

~ITF Symbol Length Lock 1

901600

To specify a First ITF symbol length
lock, scan the above bar code and the
a p p ropriate code bytes located in
Section M. Refer to Multi Code Method
on page iii.

~ITF Minimum Symbol

Length

903400

~ITF Symbol Length Lock 2

901700

To specify a second ITF symbol length
lock, scan the above bar code and the
a p p ropriate code bytes located in

Section M. Refer to Multi Code Method

on page iii.

To specify a minimum number of ITF
characters to be decoded, scan the above
bar code and the appropriate code bytes
located in Section M. Refer to Multi Code
Method on page iii.

MetroSelect

™

Standard 2 of 5

Enable Standard

2 of 5

100110

~Standard 2 of 5 Symbol Length

901500

To specify a minimum number of ITF
characters to be decoded, scan the above
bar code and the appropriate code bytes
located in Section M. Refer to Multi Code
Method on page iii.

*Disable Standard

2 of 5

100100

A-8

A-9

MetroSelect

™

Other 2 of 5 Codes

Enable Matrix 2 of 5 *Disable Matrix 2 of 5

100015

Enable 15 Digit

Airline 2 of 5

100014

100005

*Disable 15 Digit

Airline 2 of 5

100004

100313

Enable 13 Digit

Airline 2 of 5

*Disable 13 Digit

Airline 2 of 5

100303

MetroSelect

™

Enable Hong Kong

2 of 5

100316

100306

Codabar

*Enable Codabar Disable Codabar

100114

100104

*Disable Hong Kong

2 of 5

Enable Dual Field Codabar *Disable Dual Field Codabar

100012

100002

A-10

A-11

MetroSelect

™

Code 93

*Enable Code 93

100112

100102

Code 11

Enable Code 11 *Disable Code 11

100013

100003

Disable Code 93

MetroSelect

™

Telepen

Enable Telepen *Disable Telepen

100017

100007

Enable ALPHA Telepen *Disable ALPHA Telepen

100016

100006

A-12

A-13

MetroSelect

™

Plessey Codes

Enable MSI Plessey *Disable MSI Plessey

100212

*No MSI Plessey

Check Digit

200704

This option will not test MSI Plessey bar
codes for a check digit.

100202

Enable MSI Plessey MOD 10/10

Check Digit

200734

Test MSI Plessey bar codes for a double
Modulo 10 check digit.

*Enable MSI Plessey

Mod 10 Check digit

200724

Test MSI Plessey bar codes for a single
Modulo 10 check digit.

MetroSelect

™

Enable UK Plessey *Disable UK Plessey

100117

UK Plessey A

to X Conversion Enabled

100716

Enables UK Plessey A to X
Conversion.

100107

*UK Plessey A

to X Conversion Disabled

100706

Disables UK Plessey A to X
Conversion.

A-14

A-15

MetroSelect

™

Other Decode Features

Enable Double Border

Required/Large Intercharacter

Space

100011

~Minimum Symbol Length

901800

*Disable Double Border

Required/Large Intercharacter

Space

100001

~Symbol Length Lock

901900

Omnidirectional default is 4. Single-line
default is 3. Combine this code with the
proper Code Bytes, to specify the
minimum number of characters in all
non-UPC/EAN bar codes.
Refer to Multi-Code Method on page iii.

This code combined with the proper
Code Bytes, locks the bar c o d e ’slength
into place. Refer to Multi-Code
Method on page iii.

MetroSelect

™

Configurable Code Lengths

There are seven bar code lock lengths available. Specific code types can be assigned to a lock length.

While in programming mode, start with lock length 1, then scan three Code Byte bar codes from

Section M that represent the bar code length. (A table with the code type values can be found in

Section M) Refer to Multi-Code Method on page iii.

This process can be repeated for lock lengths 2 through 7.

~Code Lock #1:

Length

902000

~Code Lock #2: Length

902200

~Code Lock #1:

Code Type

902100

~Code Lock #2: Code Type

902300

A-16

A-17

MetroSelect

™

~Code Lock #3:

Length

902400 902500

~Code Lock #4:

Length

902600 902700

~Code Lock #3:

Code Type

~Code Lock #4:

Code Type

~Code Lock #5:

Length

902800 902900

~Code Lock #5:

Code Type

MetroSelect

™

~Code Lock #6:

Length

903000 903100

~Code Lock #7:

Length

903200 903300

~Code Lock #6:

Code Type

~Code Lock #7:

Code Type

A-18

MetroSelect

™

Section B

Supplements

Two Digit Supplements B-1
Two Digit Redundancy B-1

Five Digit Supplements B-1

Five Digit Redundancy B-2
Supplements Required/Not Required B-2
Remote Supplemental Requirement B-2
Bookland (978) Supplement Requirement B-3
977 (2 digit) Supplement Requirement B-3

378/379 French Supplement Requirement B-3
434/439 German Supplement Requirement B-4
#System 2 Requires Supplements B-4
#System 5 Requires Supplements B-4
Coupon Code 128 B-5
Code 128 ‘]C1’ Extended Code Format B-5
Code 128 Group Separators B-5
400 msec to find Supplemental B-6
200 msec to find Supplemental B-6
100 msec to find Supplemental B-6
Code ID’s with Supplements B-7
Beep Once/Twice on Supplements B-7
ISBN Check Digit Transmission B-8
Bookland to ISBN Conversion B-8
ISBN Re-formatting B-8

B

B-1

MetroSelect

™

Supplements

Enable Two Digit Supplements

101217 101207

*Enable Two Digit Redundancy

101212 101202

*Disable Two Digit Supplements

Disable Two Digit Redundancy

Twice before accepting data, the
scanner will scan the bar code plus
the 2 digit add on.

Enable Five Digit Supplements

101216 101206

When Scanned, will not implement
the two digit redundancy feature.

*Disable Five Digit Supplements

MetroSelect

™

Enable Five Digit

Redundancy

101211 101201

Twice before accepting data, the
scanner will scan the bar code plus
the five digit add on.

Supplements are Required

101213 101203

When chosen, all UPC/EAN labels
that are scanned must have a sup­plement.

When Scanned, will not implement
the five digit redundancy feature.

*Supplements are not Required

When chosen, all UPC/EAN labels do

not re q u i re a supplement to be

scanned.

*Disable Five Digit

Redundancy

Enable Remote Supplemental

*Disable Remote Supplemental

Requirement

101416 101406

B-2

Requirement

B-3

MetroSelect

™

Enable Bookland

(978) Supplement Requirement

101417 101407

(978) Supplement Requirement

Enable 977 (2 digit)

Supplemental Requirement

101314 101304

When enabled, the scanner will
re q u i re a 2 digit supplement be
scanned whenever an EAN-13 code
begins with 977.

Supplemental Requirement

When enabled, the scanner will not
require a 2 digit supplement be
scanned whenever an EAN-13 code
begins with 977.

*Disable Bookland

*Disable 977 (2 digit)

Enable 378/379 French

Supplemental Requirement

101313 101303

*Disable 378/379 French

Supplemental Requirement

MetroSelect

™

Enable 434/439 German

Supplemental Requirement

101415 101405

Enable #System 2 Requires

*Disable 434/439 German
Supplemental Requirement

*Disable #System 2 Requires

Supplements

101412 101402

Supplements

Enable #System 5 Requires

*Disable #System 5 Requires

Supplements

101215 101205

B-4

Supplements

B-5

MetroSelect

™

Enable Coupon Code 128 *Disable Coupon Code 128

100315 100305

Enable Code 128 ‘]C1’ Extended

Code Format

101411 101401

When enabled, scanner transmits an
‘]C1’ at the beginning of the Code
128 portion of the coupon code.

*Disable Code 128 ‘]C1’

Extended Code Format

When disabled, scanner will not trans­mit on ‘]C1’ at the beginning of the
Code 128 portion of the coupon code.

Enable 128 Group Separators

101414 101404

“GS” (1DH) character will be transmit­ted with coupon Code 128 codes.

*Disable 128 Group Separators

“GS” (1DH) character will not be
transmitted with coupon Code 128 codes.

MetroSelect

™

400 msec to Find Supplemental

301340 301320

With this option, the scanner will allot
400 milliseconds to “find” an add on
after a main UPC/EAN bar code has
been scanned.

200 msec to Find Supplemental

With this option, the scanner will allot
200 milliseconds to “find” an add on
after a main UPC/EAN bar code has
been scanned.

*100 msec to Find Supplemental

301310

With this option, the scanner will allot
100 milliseconds to “find” an add on
after a main UPC/EAN bar code has
been scanned.

B-6

B-7

MetroSelect

™

Enable Code ID’s with

Supplements

101214 101204

*Beep Once on Supplements

118406 118416

Beep Twice on Supplements

*Disable Code ID’s with

Supplements

MetroSelect

™

Enable ISBN Check Digit

Disable ISBN Check Digit

Transmission

101315 101305

Not available with all models.

Enable Bookland to ISBN

*Disable Bookland to ISBN

Conversion

101317 101307

Not available with all models.

Transmission

Conversion

Enable ISBN

Re-Formatting

101316 101306

Not available with all models.

B-8

*Disable ISBN

Re-Formatting

B-9

MetroSelect

™

Section C

Communications

Enable Light Pen/Wand Communication C-1
Enable RS-232 C-1
Load Keyboard Wedge Defaults C-1
Enable Stand-Alone Keyboard Scanner C-1
Enable Keyboard Wedge Emulation C-1
Enable OCIAOutput C-2
Load OCIA Defaults C-2
Enable IBM 46xx Communication C-2
Load IBM 46xx IBM Defaults C-2
Enable No Communication Mode C-3
Reserved C-3
Reserved C-3

C

C-1

MetroSelect

™

Communications

Enable Light Pen/Wand

Communication

415524

Use this option if scanner should be
used in place of a light pen.

*Enable RS-232

415554

When this optionis e n a b l e d, the scanner
will work with RS-232 +/-12V serial
o u t p u t .

Load Keyboard Wedge Defaults

999994

Enable Stand-Alone Keyboard

Scanner

5155153

Allows scanner to be used without an
external keyboard.

Scan this before selecting Normal or
Stand Alone Mode.

Enable Keyboard Wedge Emulation

5155143

Select if the scanner provides keyboard emu­lation by converting the scanned bar code data
to the PC keyboard scan code equivalent.

MetroSelect

™

Enable OCIA Output

415544

Select this option if the communications
re q u i rement is an Optically Co u p l e d
In t e rface Adapter (OCIA). This a clocked
(by the host) serial interf a c e .

Enable IBM 46xx Communication

415504

Load OCIA Defaults

999993

Scan this before selecting Enable

OCIA output

Load IBM 46xx Defaults

999995

Select this option for IBM 46XX
SIOC/RS485 communications. Not all
scanners support this interface. The
correct interface board is required.

Scan this before selecting
IBM 46XX Defaults

C-2

C-3

MetroSelect

™

Enable No Communication Mode

415534

Select this option if the scanner does
not interface with the host device.

Reserved

917500 415564

Reserved

MetroSelect

™

Section D

Scanner Operation

Configuration Mode Options D-1
Scan Buffers D-2
Redundant Scans D-4
Miscellaneous Decode Features D-6
Depth of Field Adjustments D-7
Same Symbol Time Outs D-8
LED Options D-10
Beeper Options D-11
Data Transmission Delays D-14

Inter-Character D-14

Inter-Record D-15
Communication Timeout Options D-16
Host Scanner Commands D-18
Power Save Modes D-22
Miscellaneous Features D-24
Test Modes D-25

D

D-1

MetroSelect

™

Configuration Mode

Allow Configuration Mode on

Power-Up

118117 118107

Scanner can only enter MetroSet™
mode before any bar codes are
scanned.

Allow Configuration Labels on

Power-up

118116 118106

*Allow Configuration Mode

Allow MetroSet™ configuration at any
t i m e .

*Allow Configuration Labels

Anytime

Anytime

Once a product bar code is scanned
after power-up, the scanner will not
accept configuation bar codes.

Allows scanning of configuration bar

codes any time.

MetroSelect

Scan Buffers

™

*1 Scan Buffer

318000 318010

When enabled, the scanner will scan
one bar code in the scan field and not
scan again until the bar code is
removed from the scan field for the
duration of the same symbol time
out.

When enabled, the scanner will scan
2 bar codes in the scan field one time
each. These 2 bar codes will not be
scanned again until they are removed
from the scan field for the duration of
the same symbol time out.

3 Scan Buffers

318020 318030

Same function as 2 Scan Buffers, but
3 bar codes are in the scan field.

Same function as 2 Scan Buffers, but
4 bar codes are in the scan field.

2 Scan Buffers

5 Scan Buffers

318040 318050

Same function as 2 Scan Buffers, but
5 bar codes are in the scan field.

Same function as 2 Scan Buffers,
but 6 bar codes are in the scan field.

D-2

6 Scan Buffers

D-3

MetroSelect

™

7 Scan Buffers

318060 318070

Same function as 2 Scan Buffers, but
7 bar codes are in the scan field.

Same function as 2 Scan Buffers, but
8 bar codes are in the scan field.

8 Scan Buffers

MetroSelect

™

Redundant Scans

*0 Redundant Scans

301100 301110

Requires 1 good decode for a “good
scan.”

1 Redundant Scans

Requires 2 consecutive decodes of the
same bar code data for a “good
scan” .

2 Redundant Scans 3 Redundant Scans

301120 301130

Requires 3 consecutive...

Requires 4...

4 Redundant Scans

301140 301150

Requires 5...

Requires 6...

D-4

5 Redundant Scans

D-5

MetroSelect

301160 301170

Requires 7... Requires 8...

™

6 Redundant Scans

7 Redundant Scans

MetroSelect

™

Miscellaneous Decode Features

*Enable MAJIC

101113 101103

The Metrologic Algorithm for Joining
Incomplete Codes (MAJIC) aids in
deciphering damaged or incomplete
bar codes. Enable for more aggres­sive decoding.

Optional Same Symbol Check

118113 118103

Disable this feature when bar codes
are in good reading condition. This
will speed up decoding and improve
over all accuracy.

*Normal Same Symbol Check

Disable MAJIC

Require 1 different character between
successive bar codes to consider the bar
code “new”.

Require 3 different characters between

successive bar codes to consider the bar

code “new”.

D-6

D-7

MetroSelect

™

Depth of Field Adjustments

Do not change these settings unless instructed by a Metrologic representative.

*Optimize for Low Density Codes

418790 4187130

For use with omnidirectional
scanners only.

Fixed for High Density Codes Fixed for Medium Density

418700

Optimize for High Density Codes

For use with omnidirectional
scanners only.

418710

For use with omnidirectional
scanners only.

Fixed for Low Density Codes

418720

For use with omnidirectional
scanners only.

For use with omnidirectional
scanners only.

MetroSelect

™

Same Symbol Time outs

These numbers determine the length of time before a bar code can be rescanned after it is removed from the scan field. Single
code fixed settings in msecs of No, 50, 100, 200, 500,1200 (1.2 sec), 2000 (2.0 sec) and infinite are available. Also, user- c o n f i g­urable value can be set in user-configurable increments of 50 for a range of 50 msecs to 6350 (6.35 sec).

If using the MS9500 series, please go to Section L.

No Same Symbol Time Out

818900 818920

Same Symbol Time Out 200

Same Symbol Time Out 100

*Same Symbol Time Out 500 msecs

msecs

818940 8189100

Same Symbol Time Out 1200 msecs

8189240 8189400

Same Symbol Time Out 2000 msecs

msecs

D-8

D-9

MetroSelect

Infinite Same Symbol Time Out

118917 918900

When selected, the scanner will not
repetitively scan the same bar code.

This option overrides the symbol res-

can time-outs.

™

~Variable Same Symbol Time-

In configuration mode, scan this bar
code and a code byte sequence from
Section M to set the same symbol
time out duration. Values range
f rom 001 to 127 (50 to 6350
msecs). Refer to MultiCode Method
on page iii.

out

MetroSelect

LED Options

™

Flash Green LED if Rescan

*Do Not Flash Green LED if

Allowed

118313 118303

This indicates same symbol timeout
has elapsed.

Reverse LED

Functions

118312 118302

Rescan Allowed

*Normal LED

Functions

Red = Laser On
Green = Good Read

Green = Laser On
Red = Good Read

D-10

D-11

MetroSelect

™

Beeper Options

*Normal Tone

318575 318565

Optional Tone 2 Optional Tone 3

318555 318545

Optional Tone 1

Optional Tone 4 Optional Tone 5

318535 318525

MetroSelect

™

Optional Tone 6

318515 318505

*Beep Once on Supplements

118406 118416

Beep Twice on Supplements

No Beep

Enable Fast Beep *Disable Fast Beep

118414 118404

D-12

D-13

MetroSelect

™

Beep on BEL Command

118417 118407

The scanner beeps when it receives
a BEL character from the host. If a
number is sent within 200 msecs
before the BEL character, the
scanner will beep that number of
times.

Enable Light Pen Toggle During

*Disable Light Pen Toggle During

Beep

*Ignore BEL

Command

Beep

116913 116903

When enabled, the scanner beeps and tog­gles the light pen data line on a successful
decode. This drives a good read indicator.

MetroSelect

™

Data Transmission Delays

Use these codes to select the amount of delay between sending data characters and “Bar code” Records from the scan-

ner to the host. This helps prevent the scanner from overflowing host input buffers.

Intercharacter Delay Options

*1 msec Intercharacter Delay

818810 8188100

25 msec Intercharacter Delay

8188250 918800

10 msec Intercharacter Delay

~Variable msec Intercharacter Delay

Scan this bar code and a sequence of code
bytes in Section M to set the delay
between characters sent to the host
system. (Range from 1 to 255 msecs.)

Refer to the MultiCode Method on page iii.

D-14

D-15

MetroSelect

™

No Intercharacter Delay

818800

Inter-Record Delay

~Variable Inter-Record Delay

919300

Turn Off Laser During Inter-

Record Delay

119317 119307

*Leave Laser On During

Inter-Record Delay

MetroSelect

™

Communication Timeout Options

Enable Communications

Time Outs

118412 118402

*Beep Before

Transmit

118413 118403

Scanner will beep after each label is trans-

m i t t e d .

Scanner will beep after each label is trans­m i t t e d .

*Disable Communications

Beep After

Transmit

~Variable Communications Time Out *Default Communications Time Out

(2 secs)

919100 8191400

D-16

D-17

MetroSelect

Short Communications Time Out

™

Long Communications Time Out

(1 secs)

8191200 8191800

Three Beeps on

Time Out

118410 118400

(4 secs)

*No Beeps on

Time Out

Razzberry Tone on Time Out

118411 118401

*No Razzberry Tone on Time

Out

MetroSelect

™

Host Scanner Commands

Enable “D/E” Disable Command

118115 118105

When this option is chosen, the scan­ner will disable scanning after it
receives an ASCII “D” from the host
device. It will enable scanning when
it receives an ASCII “E.”

Enable Z/R Type D/E Simulation

118211 118201

*Disable “D/E” Disable

Do not monitor D/E commands.

*No “Z/R” Type “D/E”

Simulation

When this option is chosen, the

scanner will disable scanning after it

receives an ASCII “Z” from the host

device. It will enable scanning when it

receives an ASCII “R.”

Do not monitor Z/R commands.

D-18

D-19

MetroSelect

™

Enable “F/L” Laser Command *Disable “F/L” Laser Command

118014 118004

When enabled, the scanner will turn

o ff the laser after the scanner

receives an ASCII “F” character. The

laser will turn on after it receives an

ASCII “L” character.

Motor On/Off Using

M/O Commands

Do not monitor “F/L” commands.

*Disable M/O

Commands

118213 118203

When enabled, the motor will turn on
after the scanner receives an ASCII
“M” character. The scanner will turn
o ff the laser and motor after it
receives an ASCII “O” character.

For use with omnidirectional
scanners only.

Do not monitor M/ O commands.

MetroSelect

™

Use DTRScan Disable

118115 118105

When enabled, the scanner will

monitor the DTR input to determine if

scanning should be allowed. A +12V

“active” level enables decoding.

A -12V “inactive” level disables

decoding.

*Do not use DTRScan Disable

Do not monitor the DTR input.

D-20

D-21

MetroSelect

™

Activate on DC2 Character

118110 118100

Transmit “NO READ” if DC2

Do Not Transmit “NO READ” if

Activated

118111 118101

*Do Not Activate on DC2

Character

DC2 Activated

No Green LED During

*Green LED During “NOREAD”

“NO READ” Xmit

118311 118301

Xmit

MetroSelect

™

Power Save Modes

Always Power Save Mode

118617 818600

Enters power save mode immediately

after power-up and after each bar

code scanned. For use with

Omnidirectional scanners only.

The scanner will never enter power

save mode. For use with

Omnidirectional scanners only.

Power Save Mode in

1 Minute

118610 818620

No Power Save

Mode

Power Save in

2 Minutes

Enters power save mode when the scanner

remains idle for 1 minute. For use with

Omnidirectional scanners only.

Enters power save mode if the scanner
remains idle for 2 minutes. For use

with Omnidirectional scanners

only.

D-22

D-23

MetroSelect

™

Power Save in

5 Minutes

818650

Enters power save mode if the scanner
remains idle for 5 minutes. For use

with Omnidirectional scanners
only.

Power Save in

20 Minutes

Power Save in

10 Minutes

8186100

Enters power save mode if the scanner re m a i n s
idle for 10 minutes. For use with

Omnidirectional scanners only.

Power Save in

30 Minutes

8186200 8186300

Enters power save mode if the scanner
remains idle for 20 minutes. For use

with Omnidirectional scanners
only.

Enters power save mode if the scanner
remains idle for 30 minutes. For use

with Omnidirectional scanners

MetroSelect

™

Miscellaneous Features

Enable Japan Mode *Disable Japan Mode

118112 118102

D-24

118017

118007

D-25

MetroSelect

™

Test Modes

Scanability ON

118017 118007

This option enters scanability test mode. D o

not enable unless instructed by a
M e t rologic re p resentative.

Scan Count Mode ON

*Scanability OFF

*Scan Count Mode OFF

118016 118006

When enabled, the scanner will enter scan

count test mode and the scanner’s

f i rm w a re number will transmit to the host.

Do not enable unless instructed by a

M e t rologic re p resentative.

MetroSelect

™

Section E

Prefixes/Suffixes

User Configurable Prefixes, All Data E-1
User Configurable ID Characters, Code Specific E-3
Standard Prefix Characters E-8
Standard Suffix Characters E-13
Longitudinal Redundancy Check (LRC) E-15
User Configurable Suffixes, All Data E-16
Special Formats E-19

E

E-1

MetroSelect

™

User Configurable Prefixes, All Data

Note: Scan “Enter configuration mode” code before trying to set this feature. Please refer to
MultiCode Method pn page iii.

~Configurable Prefix

Character #1

903500 903600

When this option is chosen, a prefix
ID can be added and assigned for
data transmission. Use this code with
a 3 code byte sequence fro m
Section M that re p resents the
desired character.

~Configurable Prefix

Character #3

903700 903800

~Configurable Prefix

Character #2

Assigns a second configurable prefix
character.

~Configurable Prefix Character

#4

Assigns a third configurable prefix character.

~Configurable Prefix

Character #5

903900

Assigns a fifth configurable prefix character.

Assigns a fourth configurable prefix
character.

~Configurable Prefix

Character #6

904000

Assigns a sixth configurable prefix character.

MetroSelect

™

~Configurable Prefix

~Configurable Prefix

Character #7

904100 904200

Assigns a seventh configurable prefix

character.

Assigns an eighth configurable prefix
character.

~Configurable Prefix

Character #9

904300 904400

Assigns a ninth configurable prefix
c h a r a c t e r.

Assigns a tenth configurable prefix
c h a r a c t e r.

Character #8

~Configurable Prefix

Character #10

*Clear All User Configurable

Prefixes

999985

E-2

E-3

MetroSelect

™

User Configurable ID Characters, Code Specific

*Use Configurable Code ID Bytes

as Prefixes

105507 105517

User configured, code specific ID bytes

a re transmitted before the data. I f

using prefixes, user configure d
s u ffixes can not be used.

Identifiers Characters

Configurable

UPC-A ID

Use Configurable Code ID Bytes

User configured, code specific ID bytes
a re transmitted after the data. I f

using suffixes, user configure d
p refixes can not be used.

as Suffixes

Configurable

UPC-E ID

905600 905700

While using the MultiCode Method, scan

this bar code followed by the 3 code byte

bar codes in Section M that re p resent a

unique ID character to be associated with

this bar code type. Please refer to

MultiCode Method on page iii.

While using the MultiCode Method, scan
this bar code followed by the 3 code byte
bar codes in Section Mthat re p resent a
unique ID character to be associated with
this bar code type. Please refer to
MultiCode Method on page iii.

MetroSelect

™

Configurable

EAN-8 ID

905800 905900

While in using the MultiCode Method, scan

this bar code followed by the 3 code byte

bar codes in Section M that re p resent a

unique ID character to be associated with

this bar code type. Please refer to

MultiCode Method on page iii.

While in using the MultiCode Method, scan

this bar code followed by the 3 code byte

bar codes in Section Mthat re p resent a
unique ID character to be associated with
this bar code type. Please refer to
MultiCode Method on page iii.

Configurable

Code 39 ID

906000 906100

Configurable

EAN-13 ID

Configurable
Code 128 ID

While in using the MultiCode Method, scan

this bar code followed by the 3 code byte

bar codes in Section Mthat re p resent a

unique ID character to be associated with

this bar code type. Please refer to

MultiCode Method on page iii.

While in using the MultiCode Method, scan
this bar code followed by the 3 code byte
bar codes in Section Mthat re p resent a
unique ID character to be associated with
this bar code type. Please refer to
MultiCode Method on page iii.

E-4

E-5

MetroSelect

™

Configurable

Code 93 ID

906300 906400

While in using the MultiCode Method, scan

this bar code followed by the 3 code byte

bar codes in Section Mthat re p resent a

unique ID character to be associated with

this bar code type. Please refer to

MultiCode Method on page iii.

While in using the MultiCode Method, scan
this bar code followed by the 3 code byte
bar codes in Section M that re p resent a
unique ID character to be associated with
this bar code type. Please refer to
MultiCode Method on page iii.

Configurable

Telepen ID

Configurable

Code 11 ID

Configurable
TRI-OPTIC ID

906200 907200

While in using the MultiCode Method, scan
this bar code followed by the 3 code byte
bar codes in Section Mthat re p resent a
unique ID character to be associated with
this bar code type. Please refer to
MultiCode Method on page iii.

While in using the MultiCode Method, scan
this bar code followed by the 3 code byte
bar codes in Section Mthat re p resent a
unique ID character to be associated with

this bar code type. Please refer to

MultiCode Method on page iii.

MetroSelect

™

Configurable

Standard 2 of 5 ID

907100 906700

While in using the MultiCode Method, scan

this bar code followed by the 3 code byte

bar codes in Section Mthat re p resent a

unique ID character to be associated with

this bar code type. Please refer to

MultiCode Method on page iii.

While in using the MultiCode Method, scan
this bar code followed by the 3 code byte
bar codes in Section Mthat re p resent a
unique ID character to be associated with
this bar code type. Please refer to
MultiCode Method on page iii.

Configurable

Matrix 2 of 5 ID

906800 906900

Configurable

Interleaved 2 of 5 ID

Configurable

Airline 2 of 5 ID

While in using the MultiCode Method, scan

this bar code followed by the 3 code byte

bar codes in Section Mthat re p resent a

unique ID character to be associated with

this bar code type. Please refer to

MultiCode Method on page iii.

While in using the MultiCode Method, scan
this bar code followed by the 3 code byte
bar codes in Section Mthat re p resent a
unique ID character to be associated with
this bar code type. Please refer to
MultiCode Method on page iii.

E-6

E-7

MetroSelect

™

Configurable

MSI Plessey ID

906500 907000

While in using the MultiCode Method, scan

this bar code followed by the 3 code byte

bar codes in Section Mthat re p resent a

unique ID character to be associated with

this bar code type. Please refer to

MultiCode Method on page iii.

Configurable

While in using the MultiCode Method, scan
this bar code followed by the 3 code byte
bar codes in Section Mthat re p resent a
unique ID character to be associated with
this bar code type. Please refer to
MultiCode Method on page iii.

*Clear all Configurable Code

Codabar ID

Configurable

UK Plessey ID

Specific ID’s

906600 999983

While in using the MultiCode Method, scan
this bar code followed by the 3 code byte
bar codes in Section Mthat re p resent a
unique ID character to be associated with
this bar code type. Please refer to
MultiCode Method on page iii.

While in using the MultiCode Method, scan
this bar code followed by the 3 code byte
bar codes in Section Mthat re p resent a
unique ID character to be associated with
this bar code type. Please refer to
MultiCode Method on page iii.

MetroSelect

™

Standard Prefix Characters

Enable STX Prefix *Disable STX Prefix

116615 116605

When enabled, the scanner will trans-

mit a St a rt of TeXt (ASCII 02H)

before each bar code.

Will not transmit a Start of TeXt
(ASCII 02H) before each bar code.

Enable Rochford-Thomson Mode *Disable Rochford-Thomson Mode

105513 105503

Enable AIM ID Characters

107915 107905

The scanner will transmit AIM

symbology identifiers. Some scan-

ners may not support this feature

*Disable AIM ID Characters

The scanner will not transmit AIM
symbology identifiers.

E-8

E-9

MetroSelect

™

Enable UPC Prefix ID *Disable UPCPrefix ID

116617 116607

When enabled, the scanner will

transmit a prefix before any UPC/EAN

bar code. The prefixes are A (UPC-A),

E0 (UPC-E), F (EAN-13), and

FF (EAN-8).

Enable NCR Prefix ID

107911 107901

Do not send prefix ID Characters with
UPC/EAN codes.

*Disable NCR Prefix ID

When enabled, the scanner will transmit a
prefix before the following code types.
The prefixes are as follows:
A (UPC-A)
E0 (UPC-E)
FF (EAN-8)
F (EAN 13)

B1 (Code 39)
B2 (ITF)
B3 (Code 128 and other codes)

MetroSelect

™

Enable Nixdorf ID Characters

107917

When enabled, this option transmits
code identifiers before each bar code
for many Siemens/Nixdorf re g i s t e r s .

Enable SANYO ID Characters

107916

Transmit Sanyo ID Characters.

*Disable Nixdorf ID Characters

107907

This bar code will not transmit
S i e m e n s / N i x d o rf code identifiers.

*Disable SANYO ID Characters

107906

Do not transmit Sanyo ID Characters.

E-10

E-11

MetroSelect

™

Enable Manufacturer ID Prefix

105512

Transmits “METROLOGIC” before all bar

code data to identify the scanner as a

M e t rologic scanner.

Enable “C” Prefix

105511

*Disable Manufacturer ID Prefix

105502

Will not transmit the identification
string.

*Disable “C” Prefix

105501

Enable “$” Prefix ID for

UPC/EAN

105510

*Disable “$” Prefix ID for

UPC/EAN

105500

MetroSelect

™

Enable Tab Prefix

116611

The Scanner will transmit a TAB

(ASCII 09H) before each bar code.

Enable SNI Beetle Mode

116111 116101

116601

Will not transmit a TAB.

*Disable SNI Beetle Mode

*Disable Tab Prefix

Enable Cipher 1021 IDs *Disable Cipher 1021 IDs

116113 116103

E-12

E-13

MetroSelect

™

Standard Suffix Characters

*Enable CR Suffix

116613 116603

When enabled, the scanner transmits a

Carriage Return after each bar code.

*Enable LF Suffix

116612 116602

The scanner will not transmit a

Ca rriage Re t u rn after each bar
code.

Disable CR Suffix

Disable LF Suffix

When enabled, the scanner transmits

a Line Feed after each bar code.

Note: Disabled when keyboard

wedge defaults are loaded.

The scanner will not transmit a Line
Feed after each bar code.

Enable Tab Suffix *Disable Tab Suffix

116610 116600

When enabled, the scanner will

transmit a TAB (ASCII 09H) after

each bar code.

Will not transmit TAB (ASCII 09H)

after each bar code.

MetroSelect

™

Enable ETX Suffix

116614 116604

When enabled, the scanner will
transmit End of TeXt (ASCII 03H)
after the bar code data.

When disabled, the scanner will not
transmit End of TeXt (ASCII 03H).

Enable UPC Suffix ID

116616 116606

When enabled, the scanner will

transmit a suffix after any UPC/EAN

bar code. The suffixes are A (UPC-

A), E (UPC-E), F (EAN-13) and
F (EAN-8).

Will not transmit a suffix after
UPC/EAN bar codes.

*Disable ETX Suffix

*Disable UPC Suffix ID

E-14

E-15

MetroSelect

Longitudinal Redundancy Check (LRC)

™

Enable Transmit of LRC

Calculation

107811 107801

With this option, the scanner outputs
an LRC check character after the bar
code.

Will not output an LRC (check
character) after the bar code.

Start LRC on

Second Byte

*Disable Transmit of LRC

Calculation

*Start LRC on

First Byte

107810 107800

The scanner will calculate the LRC check

digit starting with the second character.

The scanner will calculate the LRC check
digit starting with the first character

MetroSelect

™

User Configurable Suffixes, All Data

Note: Scan “Enter configuration mode” code before trying to set this feature. Refer to
MultiCode Method on page iii.

~Configurable Suffix

Character #1

904500 904600

When chosen, a suffix ID can be added

and assigned for data transmission.

Use this code with a 3 code byte

sequence from Section M that

represents the desired character.

Assigns a second configurable suffix
c h a r a c t e r.

~Configurable Suffix

Character #3

904700 904800

~Configurable Suffix

Character #2

~Configurable Suffix

Character #4

Assigns a third configurable suffix
c h a r a c t e r.

Assigns a fourth configurable suffix
c h a r a c t e r.

E-16

E-17

MetroSelect

™

~Configurable Suffix

Character #5

904900 905000

Assigns a fifth configurable suffix character.

Assigns a sixth configurable suffix character.

~Configurable Suffix

Character #7

905100 905200

Assigns a seventh configurable suffix
c h a r a c t e r.

Assigns an eighth configurable suffix
c h a r a c t e r.

~Configurable Suffix

Character #6

~Configurable Suffix

Character #8

~Configurable Suffix

Character #9

905300 905400

Assigns a ninth configurable suffix character.

Assigns a tenth configurable suffix character.

~Configurable Suffix

Character #10

MetroSelect

™

*Clear All User Configurable

Suffixes

999984

E-18

E-19

MetroSelect

™

Special Formats

Enable SINEKO

Mode

107914 107904

Enable Newcode Formatting

Mode A

116711 116701

*Disable Newcode Formatting

*Disable SINEKO Mode

Mode A

Enable Newcode Formatting

*Disable Newcode Formatting

Mode B

116710 116700

Mode B

MetroSelect

™

Section F

Code Formatting

UPC-EAN Formatting F-1
Codabar Formatting F-5
Code 39 Formatting F-6
Code 11 F-7
Telepen F-7
Plessey F-8

2 of 5 Code Formatting F-9

F

F-1

MetroSelect

™

UPC/EAN Formatting

*Transmit UPC-A

Check Digit

116617 116607

Transmit UPC-E

Check Digit

107516 107506

*Do Not Transmit UPC-E

Do Not Transmit UPC-A

Check Digit

Check Digit

Expand UPC-E to

*Do Not Expand UPC-E to

12 Digits

107515 107505

Expand UPC-E bar codes to the 12 digit

equivalent, UPC-A bar codes.

Do not expand UPC-E to the 12 digit
equivalent, UPC-A bar code.

12 Digits

MetroSelect

™

Convert UPC-A to EAN-13

107514 107504

With this option, the scanner convert s

UPC-A to EAN-13 by transmitting a lead-

ing zero before the bar code.

Transmit Lead Zero on UPC-E

107513 107503

When chosen, this option will transmit

a zero before each UPC-E bar code

*Do Not Convert UPC-A to EAN-13

With this option, the scanner will not
convert UPC-A to EAN-13.

Do Not Transmit Lead Zero on

This option will not transmit a zero
b e f o re each UPC-E bar code.

UPC-E

Convert EAN-8 to

EAN-13

107512 107502

When chosen, the scanner will trans-

mit five zeros before the bar code to

convert EAN-8 to Ean-13.

When chosen, the scanner will not
convert EAN-8 to Ean-13.

*Do Not Convert

EAN-8 to EAN-13

F-2

F-3

MetroSelect

™

*Transmit UPC-A

Number System

107511 107501

Metrologic strongly discourages using
this feature. Duplicate numbers may
result in the database.

*Transmit UPC-A MFR#

107611 107601

Do Not Transmit UPC-A

Number System

Do Not Transmit

UPC-A MFR#

*Transmit UPC-A ITEM# Do Not Transmit

UPC-A ITEM#

107610 107600

MetroSelect

™

*Transmit EAN-8

Check Digit

107910 107900

*Transmit EAN-13 Check Digit

107912 107902

Scanner will transmit EAN-13
Check Digit.

Scanner will not transmit EAN-13
Check Digit.

Do Not Transmit EAN-8

Check Digit

Do Not Transmit

EAN-13 Check Digit

F-4

F-5

MetroSelect

™

Codabar Formatting

Transmit Codabar Start/Stop

Characters

107717 107707

Transmits Codabar’s start/stop

characters before and after each

bar code.

Enable CLSI Editing

107716 107706

*Do Not Transmit Codabar

Will not transmit Codabar’s start / s t o p
characters before and after each bar
c o d e .

Start/Stop

*Do Not Enable

CLSI Editing

Works only with 14 digit Codabar type

lengths. This option will perform CLSI

type editing before the information is

transmitted to the host.

This option will not perf o rm CLSI
type editing before the information is
transmitted to the host.

MetroSelect

™

Code 39 Formatting

Transmit Mod 43 Check

*Do Not Transmit Mod 43 Check

Digit On Code 39

107715 107705

This feature works in conjunction with
Mod 43 Check on Code 39 option in
section A. Both must be enabled for this
f e a t u re to work.

Transmit Code 39

This option will not transmit Code 39’s Mod
43 check character.

*Do Not Transmit Code 39

Stop/Start Characters

107710 107700

Digit On Code 39

When chosen, the scanner transmits
Code 39’s start and stop characters
before and after each bar code.

When chosen, the scanner will not
transmit Code 39’s start and stop

characters before and after each bar

code.

F-6

F-7

MetroSelect

™

Code 11

Transmit Code 11 Check Digit

107713 107703

This bar code will transmit Code 11
check characters when used with
Enabled Code 11 in section A.

*Do Not Transmit Code 11

This bar code will not transmit Code
11 check characters.

Telepen

Check Digit

Enable Convert

Telepen ^L to E

107814 107804

*Disable Convert

Telepen ^L to E

MetroSelect

Plessey

™

Transmit UK Plessey Check Digit

107816 107806

The scanner will transmit UK

Plessey Check Digit characters and

must be used with the UK Plessey option.

*Do Not Transmit UK Plessey

Will not transmit UK Plessey Check
Digit characters.

Enable UK Plessey

Special Format

107815 107805

Transmit MSI Plessey

* Do Not Transmit MSI Plessey

Check Digit

107711 107701

Check Digit

Disable UK Plessey

Special Format

Check Digit

This option works in conjunction with
one or both of the Enabled MSI Plessey
Mod options in Section A.

The scanner will not transit MSI

Plessey’s check digit characters.

F-8

F-9

MetroSelect

™

2 of 5 Code Formatting

Transmit Mod 10 Check Digit

on ITF

107714 107704

With this option, the scanner transmits
Interleaved 2 of 5 (ITF) Mod 10 check
c h a r a c t e r.

*Do not Transmit Mod 10 Check

The scanner will not transmit Interleaved
2 of 5 (ITF) Mod 10 check character.
Works in conjunction with Mod 10 check
on ITF. Both must be enable for this fea­t u re to work.

Digit on ITF

Transmit Matrix 2 of 5

*Do Not Transmit Matrix 2 of

Check Digit

107812 107802

5 Check Digit

MetroSelect

™

Section G

RS-232

Enable RS-232 G-1
Parity Features G-2
BAUD Rate Features G-3
Data/Stop Bit Features G-5
Hardware Handshaking G-6
Software Handshaking G-9
Miscellaneous G-11

G

G-1

MetroSelect

™

*Enable RS-232 Mode

415554

When enabled the scanner will
work with RS-232 +/-12V serial
output.

MetroSelect

™

Parity Features

A parity bit is an extra data bit used to help catch data transmission errors.

The scanner’s parity must match the host’s parity.

No Parity

316045

Odd Parity

316005 316015

Select Odd Parity to set the

parity bit to either a 1 or a 0 to

ensure an odd number of bits are

1’s.

Select Space Parity to set the
parity bit always 0.

Even Parity

316025 316035

Select Even Parity to set the parity bit to

either a 1 or 0 to ensure an even num­ber of bits are 1’s .

Select Mark Parity to set the parity bit
always 1.

*Space Parity

Mark Parity

G-2

G-3

MetroSelect

™

BAUD Rate

A “BAUD” or “BAUD Rate” is the speed at which data is transmitted. Select a BAUD for the scanner that matches

the host device.

115200 BAUD Rate

4158100 415890

Not supported on the

MS9500 Vo y a g e r.

™

38400 BAUD Rate

415880 415870

57600 BAUD Rate

Not supported on the

MS9500 Vo y a g e r.

19200 BAUD Rate

™

14400 BAUD Rate *9600 BAUD Rate

415860 415850
