Metrologic Instruments Laser Scanner User Manual

LOCATIONS

CORPORATE HEADQUARTERS

North America Metrologic Instruments, Inc. Customer Service: 1-800-ID-METRO

EUROPEAN HEADQUARTERS

Germany, Metrologic Instruments GmbH Tel: [phone]
Middle East and Africa Dornierstrasse 2 Fax: [phone]

Spain Metrologic Eria lbérica SL Tel: [phone]

Italy Metrologic Instruments Italia srl Tel: [phone]

France Metrologic Eria France SA Tel: [phone]

United Kingdom Metrologic Instruments UK Limited Tel: [phone]

Russia Metrologic Russia Tel: [phone]

ASIA

SOUTH AMERICA

Copyright

© 2003 by Metrologic Instruments, Inc. All rights reserved. No part of this work may be reproduced, transmitted, or stored
in any form or by any means without prior written consent, except by reviewer, who may quote brief passages in a review,
or provided for in the Copyright Act of 1976.

Products and brand names mentioned in this document are trademarks of their respective companies.

Singapore Metrologic Asia (Pte) Ltd Tel: [phone]

China Metro (Suzhou) Technologies Co., Ltd. Tel: [phone]

Japan Metrologic Japan Co., Ltd. Tel: [phone]

Brazil Metrologic do Brasil Ltda. Tel: [phone]

Outside Brazil Metrologic South America Tel: [phone]

90 Coles Road Tel: [phone]
Blackwood, NJ 08012-4683 Fax: [phone]

82178 Puchheim b. Email: [e-mail]
Munich, Germany Germany Email: [e-mail]

Julián Camarillo 29, D-1 Fax: [phone]
Edificio Diapasón Email: [e-mail]
28037 Madrid

Via Emilia 70 Fax: [phone]
40064 Ozzano dell’Emilia (BO) Email: [e-mail]

69 Rue de la Belle Etoile Fax: [phone]
ZI Paris Nord II, BP 50057 Email: [e-mail]
95947 – ROISSY CDG CEDEX

58 Tempus Business Centre Fax: [phone]
Kingsclere Road, Basingstoke Email: [e-mail]
Hampshire RG21 6XG

Bolshaya Novodmitrovskaya 14
RU-125015 Email: [e-mail]
Moscow Russia

No. 8 Kaki Bukit Place Fax: [phone]
4th Floor Email: [e-mail]
Singapore 416186

221 Xing Hai Street Fax: [phone]
Suzhou Industrial Park Email: [e-mail]
Suzhou, China
215021

Matsunoya Building, 6 Floor Fax: [phone]
3-14-8 Higashiueno Email: [e-mail]
Taitou-Ku, Tokyo 110-0015 Japan

Rua da Paz 2059 Fax: [phone]
CEP 04713-002 Email: [e-mail]
Chácara Santo Antônio
São Paulo, SP, Brasil

Rua da Paz 2059 Fax: [phone]
CEP 04713-002 Email: [e-mail]
Chácara Santo Antônio
São Paulo, SP, Brasil

Email: [e-mail]
Internet: www.metrologic.com

ii

TABLE OF CONTENTS

Introduction .......................................................................................................... 1

Scanner and Accessories .................................................................................... 2

Getting Started ..................................................................................................... 3

Installation

OCIA Interface.................................................................................................. 5

Keyboard Wedge Interface............................................................................... 6

Stand-Alone Keyboard Interface ...................................................................... 7

USB Interface ................................................................................................... 8

RS232 or Light Pen Interfaces ......................................................................... 9

Auxiliary Scanner............................................................................................ 11

Scanner Parts .................................................................................................... 13

Power Save Modes and The Multi-Function Button ........................................... 14

Indicators

Audible............................................................................................................ 16

Failure Modes................................................................................................. 17

Visual.............................................................................................................. 18

Labels................................................................................................................. 19

Scan Volume...................................................................................................... 20

Depth of Field by Minimum Bar Code Element Width........................................ 21

EAS Deactivation Antenna................................................................................. 23

Maintenance....................................................................................................... 23

Troubleshooting Guide....................................................................................... 24

RS232 Demonstration Program ......................................................................... 29

Applications and Protocols................................................................................. 30

Design Specifications......................................................................................... 31

Default Settings.................................................................................................. 33

MS7220 Stands

Vertical Stand Parts [

Optional Flex Stand Parts [

Vertical Stand Installation............................................................................... 40

Optional Flex Stand Installation...................................................................... 41

Scanner and Cable Terminations....................................................................... 42

Limited Warranty ................................................................................................ 46

Laser and Product Safety................................................................................... 47

Patents ............................................................................................................... 49

Index................................................................................................................... 50

MLPN 46-46405 ] ............................................................ 39

MLPN 46-46404 ] ................................................... 39

iii

INTRODUCTION

ArgusScan® is an aggressive, omnidirectional laser barcode scanner ideal for
retail, convenience, liquor, and specialty store applications. Engineered with a
large, easy-to-find optimal scan area, ArgusScan increases the first pass read
rate for maximum productivity.

ArgusScan is equipped with a multitude of standard features including:

• A bright 650 nm laser

• Programmable depth of field

• PowerLink user replaceable cables

®

• MetroSet

• Data editing (parsing) capability using Bits n' Pieces

• A 2 year warranty

SCANNER INTERFACE

MS7220-13 RS232, IBM 46xx, OCIA, Aux

2, MetroSelect® and MetrOPOS® compatible

®

MS7220-37

RS232, Light Pen, Keyboard Wedge,
Stand-Alone Keyboard, USB, Aux

1

SCANNER and Accessories

BASIC KIT

Part # Description

MS7220 ArgusScan Presentation Scanner

00-02407 MetroSelect® Programming Guide**

00-02554 MS7220 User’s and Installation Guide**

46-46406 Standard Horizontal Stand

46-46405 Standard Vertical Stand

**Also available for download at www.metrologic.com

OPTIONAL ACCESSORIES

Part # Description

AC to DC Power Transformer - Regulated 5.2V @ 1 A output

46-46759 120V United States

46-46616 220V – 240V Continental European

46-46615 220V – 240V United Kingdom

46-46984 220V – 240V China

46-46985 220V – 240V Australia

54-54xxx*

53-53xxx*

54-54002 Keyboard Wedge PowerLink Cable w/ Adapter Cable

54-54020 Stand Alone Keyboard Wedge PowerLink Cable

54-54667 RS232 AUX PowerLink Cable

46-46404 Optional Flex Stand

Other items may be ordered for the specific protocol being used. To order additional items,
contact the dealer, distributor or call Metrologic’s Customer Service Department at 1-800-ID­METRO or 1-800-436-3876.

2

Straight PowerLink Cable with built in power jack.

2.1 m (7’) cord with short strain relief

Coiled PowerLink Cable with built in power jack.

2.7 m (9’) cord with long strain relief

* xxx specifies connection to the host

GETTING STARTED

pag

Tools needed:

• Phillips head screwdriver

• ¼”-20 wrench

• Drill with a #39 drill bit (drill for hard-mount installation only)

Slide off the cable cover. Slide off the horizontal stand.

Slide on the cable door and
remove the foam insert.

Mounting the MS7220: Peel off the base plate’s tape backing and affix it to
the countertop or drill four #39 pilot holes and secure the base plate to the
countertop with the four #8 wood screws provided.

Loosen the lock nut, push back
the metal base plate and then
slide the cable through the cable
opening.

Continued on next

e.

3

GETTING STARTED

Return the metal base plate to its
original position then tighten the
lock nut.

Before continuing, determine what communication interface is needed
then follow the installation procedure for that interface on pages 5-12.

It is important to use the correct communication jack on the back of
the scanner (see pages 5-12 for cable the proper connections).
Incorrect cable connections can cause communication problems or
potential damage to the scanner

Return the foam insert to its
original position then slide
the horizontal stand back
into place on the scanner.

After the communication cable has been connected properly, slide the
cable cover down then secure in place with the three M3x .5 x 6 mm pan
head screws provided.

See the “MS7220 Stands” section of this guide for additional information on the vertical
[

MLPN 46-46405 ] and flexible [ MLPN 46-46406 ] stand options.

4

INSTALLATION FOR OCIA INTERFACE

1. Follow the “Getting Started” steps on

page 3.

2. Turn off the host system.

3. Connect the MVC cable to the 10-pin

OCIA interface jack. It is the

nd

2

round opening from the left side of the

MS7220 (see figure 1).

4. Connect the other end of the MVC cable

to the host.

Before continuing verify that the MVC
cable is connected to the appropriate
interface jack on the scanner. An
incorrect cable connection can cause
communication problems or potential
damage to the scanner.

Plugging the scanner into the serial port
of the PC does not guarantee that
scanned information will appear at the
PC. A software driver and correct
configuration settings are also required
for proper communication.

5. Slide the cable cover into place on the

back of the scanner then secure it with the

Figure 1: OCIA, Interface

three M3 screws provided.

6. Turn on the host system.

Load OCIA Defaults

7. Scan the Load OCIA Defaults bar code to

configure the MS7220 for OCIA
communication.

³999993

For additional communication options for OCIA interfaces refer to the
MetroSelect Programming Guide (

Caution:

To maintain compliance with applicable standards, all circuits connected to the scanner must meet the requirements
for SELV (Safety Extra Low Voltage) according to EN 60950.

To maintain compliance with standard CSA C22.2 No. 60950-00//UL 60950 and norm EN 60950, the power source
should meet applicable performance requirements for a limited power source.

MLPN 00-02407).

5

INSTALLATION FOR KEYBOARD WEDGE INTERFACE

1. Follow the “Getting Started” steps on

page 3.

2. Turn off the host system.

3. Disconnect the keyboard from the host.

4. Connect the PowerLink cable to the 10-pin

KBW interface jack. It is the 2

nd

round
opening from the left side of the MS7220 (see
figure 2).

5. Connect the “Y” end of the PowerLink cable
to the keyboard and the keyboard port on the
host. If necessary use the male/female
adapter cable supplied with the scanner for
proper connections.

Before continuing verify that the PowerLink
cable is connected to the appropriate
interface jack on the scanner. An incorrect
cable connection can cause communication
problems or potential damage to the scanner.

6. Connect the external power supply to the
power jack on the PowerLink cable.

7. Check the AC input requirements of the
power supply to make sure the voltage
matches the AC outlet.

8. Connect AC power to the transformer. The
outlet should be near the equipment and
easily accessible.

9. Slide the cable cover into place on the back
of the scanner then secure it with the three
M3 screws provided.

10. Turn on the host system.

Figure 2: Keyboard Wedge

Interface

Load Keyboard

Wedge Defaults

11. Scan the bar code below to configure the
MS7220 for Keyboard Wedge

³999994

communication.

Caution:

To maintain compliance with applicable standards, all circuits connected to the scanner must meet the requirements
for SELV (Safety Extra Low Voltage) according to EN 60950.

To maintain compliance with standard CSA C22.2 No. 60950-00/UL 60950 and norm EN 60950, the power source
should meet applicable performance requirements for a limited power source.

6

INSTALLATION FOR STAND-ALONE KEYBOARD INTERFACE

t

1. Follow the “Getting Started” steps on
page 3.

2. Turn off the host system.

3. Disconnect the keyboard from the host.

4. Connect the PowerLink cable to the jack
labeled “Stand-Alone Keyboard” on the
MS7220.

5. Connect the other end of the PowerLink
cable to the keyboard port on the host.

Before continuing verify that the
powerlink cable is connected to the
proper communication jack on the
scanner. Incorrect cable connection
can cause communication problems or
potential damage to the scanner.

6. Connect the external power supply to
the power jack on the PowerLink cable.

7. Check the AC input requirements of the
power supply to make sure the voltage
matches the AC outlet.

8. Connect AC power to the transformer.
The outlet should be near the
equipment and easily accessible.

Scan 1

9. Slide the cable cover into place on the
back of the scanner then secure it with
the three M3 screws provided.

10. Turn on the host system.

Figure 3: Stand-Alone

Keyboard Interface

Load Keyboard Wedge Defaults

S

³999994

Enable Stand-Alone Keyboard Wedge

11. Scan the two bar codes in order to
configure the MS7220 for
Stand-Alone Keyboard communication.

Scan 2

nd

³5155153

Note: When scanning the bar codes, cover the code not being scanned to

ensure the codes are read in the proper sequence.

Caution:

To maintain compliance with applicable standards, all circuits connected to the scanner must meet the requirements
for SELV (Safety Extra Low Voltage) according to EN 60950.

To maintain compliance with standard CSA C22.2 No. 60950-00/UL 60950 and norm EN 60950, the power source
should meet applicable performance requirements for a limited power source.

7

g

INSTALLATION FOR USB INTERFACE

1. Follow the “Getting Started” steps on page 3.

2. Turn off the host system.

3. Determine if your application requires USB
Keyboard communication protocols or USB
Point-of-Sale communication protocols.

4. If you require USB Keyboard
communication protocols, skip to step 5.

If you require USB Point-of Sale
communication protocols set the dip
switches shown in figure 4a to positions
1 and 2.

5. Connect the PowerLink cable to the
10-pin USB interface jack. It is the 2

nd

round opening from the left side of the
MS7220 (see figure 4b).

6. Connect the other end of the USB cable to
the host.

Before continuing verify that the USB cable
is connected to the appropriate interface
jack on the scanner. An incorrect cable
connection can cause communication
problems or potential damage to the
scanner.

Plugging the scanner into the USB port of
the PC does not guarantee that scanned
information will appear at the PC. A
software driver and correct configuration
setting are also required for proper
communication.

7. Slide the cable cover into place on the back
of the scanner then secure it with the three
M3 screws provided.

Figure 4a: POS Dip Switch

ure 4b: USB, Interface

Fi

8. Turn on the host system.

9. Scan the Enable USB Defaults bar
code to configure the MS7220 for
USB communication.

Caution:

To maintain compliance with applicable standards, all circuits connected to the scanner must meet the requirements
for SELV (Safety Extra Low Voltage) according to EN 60950.

To maintain compliance with standard CSA C22.2 No. 60950-00/UL 60950 and norm EN 60950, the power source
should meet applicable performance requirements for a limited power source.

8

Enable USB Defaults

³999978

INSTALLATION FOR RS232 OR LIGHT PEN INTERFACES

1. Follow the “Getting Started” steps on
page 3.

2. Turn off the host system.

3. Connect the PowerLink cable to the
10-pin RS232/Light Pen interface jack. It

st

is the 1
of the MS7220.

4. Connect the other end of the PowerLink
cable to the host.

Before continuing verify that the
powerlink cable is connected to the
appropriate communication jack on the
scanner. An incorrect cable connection
can cause communication problems or
potential damage to the scanner.

5. Connect the external power supply to the
power jack on the PowerLink cable.

round opening from the left side

6. Check the AC input requirements of the
power supply to make sure the voltage

Figure 5: RS232 or

Light Pen Interface

matches the AC outlet.

7. Connect AC power to the transformer.
The outlet should be near the equipment
and easily accessible.

8. Slide the cable cover into place on the
back of the scanner then secure it with
the three M3 screws provided.

9. Turn on the host system.

10. Scan the appropriate bar codes on page 10 to configure
the MS7220 for RS-232 or Light Pen communication.

Caution:

To maintain compliance with applicable standards, all circuits connected to the scanner must meet the requirements
for SELV (Safety Extra Low Voltage) according to EN 60950.

To maintain compliance with standard CSA C22.2 No. 60950-00/UL 60950 and norm EN 60950, the power source
should meet applicable performance requirements for a limited power source.

9

INSTALLATION FOR RS232 OR LIGHT PEN INTERFACES

Step 10, page 9 continued.

For RS232 Communication:

Recall Defaults

Scan 1st

³999998

For Light Pen Communication:

Recall Defaults

Scan 1st

³999998

Scan 2nd

Enable RS-232

³415554

10

Scan 2nd

Enable Light Pen/Wand

³415524

INSTALLATION OF AN AUXILIARY SCANNER

1. Turn off the host system.

2. Connect the round end of the PowerLink RS232 AUX cable

MLPN 54-54667A ] to the RS232 jack of the auxiliary scanner (see figure 6).

[

3. Connect the other end of the PowerLink RS232 AUX cable into the 1
from the left side of the MS7320. The Aux jack has a square opening.

The following Metrologic scanners can be used in the “Aux” input of the
MS7220: the MS9520, MS9540, MS6220, MS7120, MS6520, MS6720,
MS7320 or another MS7220.

Important: The MS7220 aux port requires the signals: transmit, receive,
RTS & CTS from the auxiliary scanner.

4. Connect the MS7220/Host PowerLink* cable to the appropriate interface
jack on the back of the MS7220.

5. Connect the other end of the MS7220/Host PowerLink cable to the Host.

6. Connect the external power supplies for the auxiliary scanner and the
MS7220 to the power jacks on the two PowerLink cables.

Before continuing verify that the powerlink cable is connected to the
appropriate interface jack on the scanner. An incorrect cable connection
can cause communication problems or potential damage to the scanner.

7. Check the AC input requirements of both power supplies to make sure the
voltage matches the AC outlets.

st

jack

8. Slide the cable cover into place on the back of the scanner then secure it
with the three M3 screws provided.

9. Connect AC power to the transformers. The outlets should be near the
equipment and easily accessible.

10. Configure the MS7220 for the appropriate interface configuration settings.*

* The MS7220/host cable connection is interface dependent. Refer to the

installation steps provided for the type of interface required for your
application.

Continued on page 12.

Caution:

To maintain compliance with applicable standards, all circuits connected to the scanner must meet the requirements
for SELV (Safety Extra Low Voltage) according to EN 60950.

To maintain compliance with standard CSA C22.2 No. 60950-00/UL 60950 and norm EN 60950, the power source
should meet applicable performance requirements for a limited power source.

11

INSTALLATION OF AN AUXILIARY SCANNER

11. Configure the auxiliary scanner to send formatted
data to the MS7220. Normal slave mode operation

Reserve Code 32

will only require reserve Code 32 to be set in the
auxiliary scanner. The Reserve Code 32 bar code
applies for all scanners, except the MS6720, to be

³124817

used as an auxiliary scanner. Contact a Metrologic
representative for information on the MS6720.

12. Configure the MS7220 to activate the auxiliary port. Enable the auxiliary
port and configure it to recognize slave formatted data with the following bar
code:

Enable Aux Port

³437330

13. Turn on the host system.

12

Figure 6: Auxiliary Scanner Setup

SCANNER PARTS

n Output Window

o Red LED

p Green LED

q Speaker

r Side Cover

s Cable Door

t Cable Jack Cover

u Horizontal Mount Base

v Multi-Function Button

(see page 15)

Figure 7a: Scanner Parts

Figure 7b: Scanner Parts

w Cable Connection Area

Foam Insert

13

POWER SAVE MODES AND THE MULTI-FUNCTION BUTTON

The MS7220 has five programmable power save modes. Refer to the
MetroSelect Programming Guide for additional information on Power Save
Modes.

1. Blink Power Save Mode (Default):
“Blinks” the laser OFF & ON after a programmed period of non-use.

When the scanner recognizes a bar code it will exit the Blink mode.

2. Laser Off Power Save Mode:
Turns the laser OFF after a programmed period of non-use.

The motor continues to spin allowing for a faster “wake” up time. Pressing
the Multi-Function button will “wake” the scanner from the Laser Off power
save mode (see figure 8d).

3. Laser & Motor Off Power Save Mode:
Turns the laser and motor OFF after a programmed period of non-use.

Pressing the Multi-Function button will “wake” the scanner from the power
save mode (see figure 8d). This mode is the only power save mode that can
be activated by the Multi-Function Button (see figure 8c). This mode’s
“wake up” time is slightly longer due to the motor’s need to restart.

4. Dual Action Power Save Mode #1:
“Blinks” the laser OFF & ON after a programmed period of non-use turns the
laser and motor OFF at thirty-minute intervals.

Example:

If the power save timeout
is set to 15 minutes.

Last

Scan

Laser starts

“Blinking”

Laser & Motor

turn OFF

Pressing the Multi-Function button will “wake” the scanner from the power
save mode (see figure 8d).

5. Dual Action Power Save Mode #2:
Turns the laser OFF after a programmed period of non-use then turns the
motor OFF after thirty-minute intervals.

Example:

If the power save timeout

Last

Scan

Laser turns

OFF

Motor turns

OFF

is set to 15 minutes.

Pressing the Multi-Function button will “wake” the scanner from the power save
mode (see figure 8d).

14

POWER SAVE MODES AND THE MULTI-FUNCTION BUTTON

Figure 8a: Multi-Function Button

CHANGING THE BEEPER TONE

A Short (<3 second) depression and the beeper
tone will change. The new tone will be heard,
followed by a short pause. Then two more of the
new tones will be heard signifying the new
setting has been stored in memory. The silent

Figure 8b: Changing the

Beeper Tone

(no beep) tone is also selectable.

Figure 8c: Laser & Motor

Power Save mode

Figure 8d: Normal Operation

P

LACING THE UNIT IN LASER & MOTOR OFF

POWER SAVE MODE

Long (>3 seconds) depression
The Laser & Motor Off Power Save Mode is the
only power save mode that can be activated with
the multi-function button.

WAKING THE UNIT FROM ALL POWER SAVE MODES

The next button depression will awaken the
scanner for normal operation.

15

AUDIBLE INDICATORS

When the MS7220 scanner is in operation, it provides audible feedback. These
sounds indicate the status of the scanner. Eight settings are available for the
tone of the beep (normal, 6 alternate tones and no tone). To change the tone,
use the Multi-Function Button or refer to the MetroSelect Programming Guide
(

MLPN 00-02407).

One Beep

When the scanner first receives power, the green LED will turn on,
the red LED will flash and the scanner will beep once. The red LED
will remain on for the duration of the beep. The scanner is now
ready to scan.

When the scanner successfully reads a bar code, the red LED will
flash and the scanner beeps once (if programmed to do so). If the
scanner does not beep once and the red light does not flash, then
the bar code has not been successfully read.

Razzberry Tone

This is a failure indicator. Refer to failure modes page 17.

Three Beeps - during operation

When placing the scanner in program mode, the red LED will flash
while the scanner simultaneously beeps three times. The red and
green LEDs will continue to flash until the unit exits program mode.
Upon exiting program mode, the scanner will beep three times and
the red LED will stop flashing.

16

When configured, 3 beeps can also indicate a communications
timeout during normal scanning mode.

When using one-code-programming, the scanner will beep three
times (the current selected tone), followed by a short pause, a high
tone and a low tone. This tells the user that the single
configuration bar code has successfully configured the scanner.

Three beeps will also occur during a manual adjustment of the
beeper tone. With each short depression of the Multi-Function
Button, the new tone will be heard, followed by a short pause then
two more of the new current tones.

Three Beeps - on power up

This is a failure indicator. Refer to failure modes page 17.

FAILURE MODES

Flashing Green and One Razzberry Tone

This indicates the scanner has experienced a laser subsystem
failure. Return the unit for repair at an authorized service
center.

Flashing Red and Green and Two Razzberry Tones

This indicates the scanner has experienced a motor failure.
Return the unit for repair at an authorized service center.

Continuous Razzberry Tone with both LEDs off

If, upon power up, the scanner emits a continuous razzberry
tone, then the scanner has an electronic failure. Return the
unit for repair at an authorized service center.

Three Beeps - on power up

If the scanner beeps 3 times on power up then, the nonvolatile
memory that holds the scanner configuration has failed.
Return the unit for repair at an authorized service center.

17

VISUAL INDICATORS

There is a red LED and a green LED on the front of the MS7220. When the
scanner is on, the flashing or constant illumination of the LEDs indicates the
status of the current scan and the scanner.

No Red or Green LED

The LEDs will not be illuminated if the scanner is not receiving power
from the host or transformer.

Steady Green

When the laser is active, the green LED is illuminated. The green
LED will remain illuminated until the laser is deactivated.

During the power save mode, the laser will turn on and off. During
this period, the green LED remains illuminated.

Steady Green and Single Red Flash

When the scanner successfully reads a bar code, the red LED will
flash and the scanner will beep once. If the red LED does not flash
or the scanner does not beep once, then the bar code has not been
successfully read.

18

Steady Green and Steady Red

After a successful scan, the scanner transmits the data to the host
device. Some communication modes require that the host inform the
scanner when data is ready to be received. If the host is not ready to
accept the information, the scanner’s red LED will remain on until the
data can be transmitted.

Flashing Green then Flashing Red

This indicates the scanner is in program mode. A razzberry tone
indicates that an invalid bar code has been scanned in this mode.

or

If the unit is in sleep mode, each LED will flash once every 15
seconds.

Steady Red, Green off

This indicates the scanner may be waiting for communication from
the host.

LABELS

Each scanner has a label on the back of the unit. The label contains information
such as the model number, date of manufacture, and the serial number.
Additional CE and caution information has been molded into the back of the
case. The following is an example of the back of the case with the label and
molded text.

Figure 9: Back view of the case. (Top)

Interface Label, Located Under the Cable Jack Cover (Bottom)

19

SCAN VOLUME (DEFAULT)

(BASED ON 100% UPC BAR CODES)

Figure 10: Top View Scan Volume (Default)

Figure 11: Side View Scan Volume (Default)

Specifications subject to change without notice.

20

DEPTH OF FIELD BY MINIMUM BAR CODE ELEMENT WIDTH

(BASED ON 100% UPC BAR CODES)

Figure 12: Top View of Default Depth of Field

Minimum Bar Code Element Width

ABCDEF

mm

mils

Specifications subject to change without notice.

.13 .19 .26 .33 .48 .66

5.2 7.5 10.4 13 19 26

21

DEPTH OF FIELD BY MINIMUM BAR CODE ELEMENT WIDTH

(BASED ON 100% UPC BAR CODES)

Figure 13: Side View of Default Depth of Field

Minimum Bar Code Element Width

ABCDEF

mm

mils

Specifications subject to change without notice.

22

.13 .19 .26 .33 .48 .66

5.2 7.5 10.4 13 19 26

EAS DEACTIVATION ANTENNA

SW1 and SW2 are the switch banks inside the CheckPoint Device that set the
deactivation range. Metrologic recommends end users program the MS7220 to
the Fixed Low-Density depth of field, so that the unit does not scan out beyond
the deactivation range.

Unit #

MS7320

CheckPoint Recommended

Switch Bank Settings

SW1 & SW2
switches 2, 3, 4, 5, and 6 set to ON

*Note: Minimum element width changes to 6.8 mil when in this mode.

Figure 14: EAS Deactivation Antenna

MS7220 Depth of Field

Settings

Default

Contact Checkpoint Systems directly for additional EAS support

.

MAINTENANCE

Smudges and dirt can interfere with the proper scanning of a bar code.
Therefore, the output window will need occasional cleaning.

1. Spray glass cleaner onto lint free, non-abrasive cleaning cloth.

2. Gently wipe the scanner window.

23

TROUBLESHOOTING GUIDE

The following guide is for reference purposes only. Contact a Metrologic
representative at 1-800-ID-METRO or 1-800-436-3876 to preserve the limited
warranty terms.

MS7220 Series Troubleshooting Guide

SYMPTOMS POSSIBLE CAUSE(S) SOLUTION

All Interfaces

No LEDs,
No beep or
No motor spin

No LEDs,
No beep

No power is being
supplied to the
scanner.

No power is being
supplied to the
scanner from host.

Check the transformer,
outlet and power strip.
Make sure the cable is
plugged into the scanner.

Some host systems cannot
supply enough current to
power an ArgusScan. Use
the power supply included
with the scanner.

The unit beeps 3
times on power
up.

The unit razzes
continuously on
power up.

At power up, there
is a Razz tone and
the green LED
flashes.

At power up,
there is a Razz
tone and both
LEDs flash.

There are multiple
scans upon
presentation of a
bar code.

The unit powers
up, but does not
beep.

There has been a
Non-volatile RAM
failure.

There is a RAM or
ROM failure.

There has been a
VLD failure.

There has been a
scanner motor
failure.

The same symbol
timeout is set too
short.

The beeper is
disabled.

No volume is selected.
No tone is selected.

Contact a Metrologic
service representative, if the
unit will not hold the
programmed configuration.

Contact a Metrologic
service representative if the
unit will not function.

Contact a Metrologic
service representative.

Contact a Metrologic
service representative.

Adjust the same symbol
timeout for a longer time.

Enable the beeper.
Select a volume

(programmable).
Select a tone.

24

TROUBLESHOOTING GUIDE (CONTINUED)

SYMPTOMS POSSIBLE CAUSE(S) SOLUTION

UPC/EAN, Code 39,
interleaved 2 of 5, Code 93,
Code 128 and Codabar are
enabled by default. Verify
that the type of bar code
being read has been
enabled.

Verify that the bar code
being scanned falls into the
programmed criteria.
(Typical of Non-UPC/EAN
codes. The scanner

defaults to a minimum of 4
character bar code.)

The unit powers
up, but does not
scan and/or
beep.

The unit is scanning
a particular
symbology that is not
enabled.

The scanner has
been programmed
for a character length
lock, or a minimum
length and the bar
code being scanned
does not satisfy the
programmed criteria.

The unit scans a
bar code, but
locks up after
the first scan
(the red LED
stays on).

The unit scans,
but the data
transmitted to
the host is
incorrect.

The unit beeps
for some bar
codes and NOT
for others of the
same bar code
symbology.

The scanner is
configured to support
some form of host
handshaking but is
not receiving the
signal.

The scanner’s data
format does not
match the host
system requirements.

The print quality of
the bar code is
suspect.

Check the character
length lock.

The aspect ratio of
the bar code is out of
tolerance.

If the scanner is setup to
support ACK/NAK,
RTS/CTS, XON/XOFF or
D/E, verify that the host
cable and host are
supporting the handshaking
properly.

Verify that the scanner’s
data format matches the
host systems requirements.
Make sure that the scanner
is connected to the proper
host port.

Check the print mode. The
type of printer could be the
problem. Change print
settings. For example
change the print mode to
econo or high speed.

25

TROUBLESHOOTING GUIDE (CONTINUED)

SYMPTOMS POSSIBLE CAUSE(S) SOLUTION

The bar code may
have been printed
incorrectly.

The unit beeps
for some bar
codes and NOT
for others of the
same bar code
symbology

Keyboard Wedge Only

The unit scans
the bar code but
there is no data.

The unit scans
but the data is
not correct.

The scanner is not
configured correctly
for the type of bar
code.

The minimum symbol
length setting does
not work with the bar
code.

The configuration is
not correct.

The configuration is
not correct.

Check if it is a check
digit/character/or border
problem.

Check if the check digits are
set properly.

Check if the correct
minimum symbol length is
set.

Make sure the scanner is
configured for the
appropriate mode.

Make sure that the proper
PC type (AT, PS2 or XT) is
selected. Verify the correct
country code and data
formats are selected. Adjust
the intercharacter delay.

The unit is
transmitting
each character

26

The configuration is
not correct.

Increase the interscan code
delay setting. Adjust
whether the F0 break is
transmitted. It may be
necessary to try this in both
settings.

TROUBLESHOOTING GUIDE (CONTINUED)

SYMPTOMS POSSIBLE CAUSE(S) SOLUTION

Alpha
characters
show as lower
case.

Everything
works except
for a couple of
characters.

RS-232 Only

The unit is
transmitting
each character.

Alpha
characters
show as lower
case.

Power-up OK
and scans OK
but does not
communicate
properly to the
host

The computer is in
Caps Lock mode.

The characters may
not be supported by
that country’s key look
up table.

The configuration is
not set correctly.

The computer is in
Caps Lock mode.

Com port at the host is
not working or
configured properly

Com port not
operating properly.

Cable not connected
to the proper com port

Enable Caps Lock Detect
setting of the scanner to
detect whether the PC is
operating in Caps Lock.

Try operating the scanner in
the Alt mode.

Increase the interscan code
delay setting. Adjust if the
F0 break is transmitted. It
may be necessary to try this
in both settings.

Enable the Caps Lock
detect setting of the scanner
to detect whether the PC is
operating in Caps Lock.

Check to make sure that the
baud rate and parity of the
scanner and the
communication port match
and the program is looking
for “RS-232" data

The host is
receiving data but
the data does not
look correct.

The scanner and host
may not be configured
for the same interface
font.

Check that the scanner and
the host are configured for
the same interface font.

27

TROUBLESHOOTING GUIDE (CONTINUED)

SYMPTOMS POSSIBLE CAUSE(S) SOLUTION

Add some intercharacter

Characters are
being dropped.

Intercharacter delay
needs to be added to
the transmitted output.

Slave operation with any interface

Trouble with the
Slave Scanner.

delay to the transmitted
output by using the
MetroSelect Programming
Guide (

MLPN 00-02407).

Refer to the user’s guide
provided with the slave
scanner.

Cable [MLPN 54-54667]
may not be connected
to the proper port.

Ensure slave scanner is
connected to the MS7220
com port marked “Aux” port.

Slave Scanner
powers up but
data is not
relayed to the
host.

The “Aux” com port
may not be operating
properly.

* The MS7220 must be

programmed to enable the
“Aux” port.

The slave scanner must be
configured to send “slave”
formatted data (reserve
code 32).

* Use MetroSet®. For the Auxiliary interface, choose “HoloTrak Decode”. All

remaining parameters will be automatically chosen.

USB Only

Check that the scanner is
The unit powers
and scans but
does not
communicate.

The USB Port is not
operating correctly.

programmed for USB

operation.

Check that the host’s USB

port is enabled.

The unit emits a
razz tone and the
LEDs flash three
times when
configured for
USB.

The USB port is not
operating correctly.

Disconnect then reconnect

the USB cable at the host

end. Contact a Metrologic

service representative if

symptoms persist.

28

RS232 DEMONSTRATION PROGRAM

If an RS232 scanner is not communicating with your IBM compatible PC,
key in the following BASIC program to test that the communication port
and scanner are working. This program is for demonstration purposes
only. It is only intended to prove that cabling is correct, the com port is
working, and the scanner is working. If the bar code data displays on the
screen while using this program, it only demonstrates that the hardware
interface and scanner are working. At this point, investigate whether the
application software and the scanner configuration match. If the
application does not support RS-232 scanners, a software wedge
program that will take RS-232 data and place it into a keyboard buffer
may be needed. This program tells the PC to ignore RTS-CTS, Data Set
Ready (DSR) and Data Carrier Detect (DCD) signals. If the
demonstration program works and yours still does not, jumper RTS to
CTS and Data Terminal Reading (DTR) to DCD and DSR on the back of
your PC.

110 CLS
110 ON ERROR GOTO 100
110 OPEN “COM1:9600,S,7,1,CS0,DS0,CD0,LF” AS #1
110 PRINT “SCAN A FEW BAR CODES”
110 LINE INPUT #1, BARCODE$
110 PRINT BARCODE$
110 K$ = INKEY$: IF K$ = CHR$(27) THEN GOTO 32766
110 GOTO 40
110 PRINT “ERROR NO.”; ERR; “ PRESS ANY KEY TO TERMINATE.”
110 K$ = INKEY$: IF K$ = “” THEN GOTO 110
32766 CLOSE: SYSTEM
32767 END

29

APPLICATIONS AND PROTOCOLS

The model number on each scanner includes the scanner number and factory
default communications protocol.

Scanner

7220

7220

Version

Identifier

13

37

Communication Protocol(s)

RS232, IBM 46xx, OCIA, Aux

RS232, Light Pen, Keyboard Wedge, Stand­Alone Keyboard, USB, Aux

The MS7220 with Built-in PC Keyboard Wedge Interface is designed to be used
for keyboard emulation only. Many RS-232 programmable functions available in
other Metrologic scanners are also available as keyboard wedge functions.

The following are the most important selectable options specific to the keyboard
wedge.

Keyboard Type

• ** AT (includes IBM® PS2 models 50, 55, 60, 80)

•XT

• IBM PS2 (includes models 30, 70, 8556)

Keyboard Country Type

• ** USA • United Kingdom

• French • German

• Italian • Spanish

• Belgium • Swiss

• Japanese

** Refer to pages 33-38 for complete information on the factory default

settings. Refer to the MetroSelect

MLPN 00-02407) or MetroSet

(

®

Programming Guide

®

2’s help files for information on how to

change the default settings.

30

DESIGN SPECIFICATIONS

OPERATIONAL

Light Source: VLD 650 ± 10 nm

Laser Power: 0.678 mW maximum

Depth of Field: 0 mm to 215 mm 8.5" at default (programmable)

Scan Speed: 2000 scans/second

Scan Pattern: 5 fields of 4 parallel lines (omnidirectional)

Scan Lines: 20

Min Bar Width: 0.13 mm (5.2 mil)

MS7220 DESIGN SPECIFICATIONS

Decode Capability:

System Interfaces:

Print Contrast: 35% minimum reflectance difference

No. Characters

Read:

Roll, Pitch, Yaw: 360°, 60°, 60°

Beeper Operation: 7 tones or no beep

Indicators (LED):

Autodiscriminates all standard bar codes; for
other symbologies call Metrologic

PC Keyboard Wedge, RS-232, OCIA, Light Pen,
Stand Alone PC Keyboard

up to 80 data characters(Maximum number will
vary based on symbology and density)

green = laser on, ready to scan
red = good read, decoding

MECHANICAL

Height: 123 mm (4.8")

Depth: 65mm (2.6")

Width: 168 mm (6.6")

Weight: 0.91 Kg (2 lbs)

Termination: Four 10-pin modular RJ45 Jacks

Cable:

Specifications subject to change without notice

Standard 2.1m (7’) straight; optional 2.7m (9')
coiled; for other cables call Metrologic

31

DESIGN SPECIFICATIONS

MS7220 DESIGN SPECIFICATIONS

ELECTRICAL

Input Voltage: 5.2VDC ± 0.25V

Power: 1.9 W

Operating Current: 360 mA

DC Transformers: Class II; 5.2 V @ 1A

CDRH: Class IIa;

Laser Class 1:

EMC: FCC, ICES-003 & EN 55022 Class B

ENVIRONMENTAL

Operating Temperature: 0°C to 40°C (32°F to 104°F)

Storage Temperature: -40°C to 60°C (-40°F to 140°F)

EN 60825-1: 1994/A11:1996
IEC 60825-1:1993+A1:1997+A2:2001

Humidity: 5% to 95% relative humidity, non-condensing

Light Levels: 4842 LUX (450 foot candles)

Contaminants:

Ventilation: None required

Specifications subject to change without notice.

32

Sealed to resist airborne particulate
contaminants

DEFAULT SETTINGS

Many functions of the scanner can be "programmed" - that is, enabled or
disabled. The scanner is shipped from the factory programmed to a set of
default conditions. The default parameter of the scanner has an asterisk
( * ) in the charts on the following pages. If an asterisk is not in the default
column then the default setting is Off or Disabled. Every communication does
not support every parameter. If the communication supports a parameter listed
in the charts on the following pages, a check mark will appear.

IGHT

a

IBM

46XX

KBW USB

PARAMET ER DEFAULT OCIA RS-232

UPC/EAN

Code 128

Code 93

Codabar

Interleaved 2 of 5 (ITF)

MOD 10 Check on ITF

Code 11

Code 39

Full ASCII Code 39

MOD 43 Check on
Code 39

MSI-Plessey

Airline (15 Digit) 2 of 5

Airline (13 Digit) 2 of 5

Matrix 2 of 5

Telepen

UK Plessey

STD 2 of 5

MSI-Plessey 10/10 Check Digit

MSI-Plessey MOD 10 Check
Digit

Paraf Support

ITF Symbol Lengths Variable

Mini mum Symbol Leng th 4

Symbol Length Lock None

Bars High as Code 39

*

aaaaaa

*

aaaaaa

*

aaaaaa

*

aaaaaa

*

aaaaaa

aaaaaa

aaaaaa

*

aaaaaa

aaaaaa

aaaaaa

aaaaaa

aaaaaa

aaaaaa

aaaaaa

aaaaaa

aaaaaa

aaaaaa

aaaaaa

*

aaaaaa

aaaaaa

aaaaaa

aaaaaa

aaaaaa

*

L

PEN

33

DEFAULT SETTINGS (CONTINUED)

Parameter Default OCIA RS-232

Spaces High as Code 39

Bars High as Scanned

Spaces High as Scanned

DTS/SIEMENS

DTS/NIXDORF

NCR F

NCR S

Poll Light Pen Source

Beeper Tone Normal

Beep/Transmit Sequence

Beeper Volume Loudest

Communication Timeout None

Razzberry Tone on Timeout

Three Beeps on Timeout

No Beeps on Timeout

Enter Power Save Mode 10 mins.

Blink Power Save Mode

Laser OFF Power Save Mode

Laser & Motor OFF Power
Save Mode

Dual Action Power Save
Mode #1

Dual Action Power Save
Mode #2

Same Symbol Rescan
Timeout: 200 msecs

Same Symbol Rescan
Timeout: 500 msecs
Programmable in 50 msec
steps (MAX 6.35 seconds)

Same Symbol Rescan
Timeout: 1250 msecs

Before

Transmit

a

*

a

a

a

aaaaa a

aaaaa a

aaaaa a

aaaaa a

aaaaa a

aaaaa a

*

aaaaa a

aaaaa a

*

aaaaa a

aaaaa a

aaaaa a

aaaaa a

aaaaa a

aaaaa a

*

aaaaa a

aaaaa a

Light

Pen

a

a

a

a

IBM

46XX

KBW USB

34

DEFAULT SETTINGS (CONTINUED)

Parameter Default OCIA RS-232

Same Symbol Rescan
Timeout: 2000 msecs

Intercharacter Delay
Programmable in 1 msec
steps (MAX 255 msecs)

Number of Scan Buffers 1

Transmit EAN-8 Check Digit

Transmit EAN-13 Check Digit

Transmit UPC-A Check Digit

Transmit UPC-E Check Digit

Expand UPC-E

Convert UPC-A to
EAN-13

UPC GTIN-14 Format

Transmit Lead Zero on
UPC-E

Convert EAN-8 to
EAN-13

Transmit UPC-A Number
System

Transmit UPC-A
Manufacturer ID#

Transmit UPC-A Item ID#

Transmit Codabar
Start/Stop Characters

CLSI Editing (Enable)

Transmit Mod 43 Check Digit
on Code 39

Transmit Code 39
Stop/Start Characters

Transmit Mod 10/ITF

Transmit MSI-Plessey Check
Characters

Parity Space

Baud Rate 9600

1 msecs

10 msecs in

KBW

*

*

*

*

*

*

aaaaaa

aa aa

aaaaaa

aa aa a

aa aa a

aa aa a

aaaa

aa aa a

aa aa a

aa aa a

aaaaaa

aa a a a

aa a a a a

aa a a a a

aa a a a a

aa a a a

aa a a a

aa a a a

aa a a a

aa a a a

aa a a a

a

a

Light

Pen

IBM

46XX

KBW USB

35

DEFAULT SETTINGS (CONTINUED)

Parameter Default OCIA RS-232

8 Data Bits

7 Data Bits

Transmit Sanyo ID
Characters

Nixdorf ID

LRC Enabled

UPC Prefix

UPC Suffix

Transmit AIM ID Characters

STX Prefix

ETX Suffix

Carriage Return

Line Feed - disabled by
default in KBW

Tab Prefix

Tab Suffix

"DE" Disable Command

"FL" Laser Enable Command

DTR Handshaking Support

RTS/CTS Handshaking

Character RTS/CTS

Message RTS/CTS

XON/XOFF Handshaking

ACK/NAK

Two Digit Supplements

Five Digit Supplements

Bookland 978

*

*

*

*

aa

aa

aa

a

a

aaa

aaa

aaa

aaa

aaa

aaa

aaa

aaa

aaa

aaa

aaa

aaa

aa

aa

a

a

a

a

a

a

Light

Pen

as code

39

as code

39

as code

39

IBM

46XX

KBW USB

aaa

aaa

aaa

36

DEFAULT SETTINGS (CONTINUED)

Parameter Default OCIA RS-232

Bookland 977 (2 digit)
Supplemental Requirement

Supplements are not
Required

Two Digit Redundancy

Five Digit Redundancy

100 msec to Find
Supplement Programmable
in 100 msec steps
(MAX 800 msec)

Coupon Code 128

Programmable Code Lengths 7 avail.

Programmable Prefix
Characters

Suffix Characters

Prefixes for individual Code
Types

Editing

Inter Scan-Code Delay
Programmable
(100 µsec steps)

Function/Control Key
Support

Minimum Element Width
Programmable in 5.6 µsec
steps

*

*

*

10 avail.

800 µsec

1 msec

aaaaa a

aaaaa a

aaaaa a

aaaaa a

aaaaa a

aa

aaaaaa

aaa

aaa

aaa

aaaaaa

Light

Pen

as code

39

a

IBM

46XX

KBW USB

aaa

aa

aa

Depth of Field

Variable Depth of Field

Normal Depth of Field

Extended Depth of Field

Long Depth of Field

Ultra Close Depth of Field

*

*

aaaaaa

aaaaaa

aaaaaa

*

aaaaaa

aaaaaa

37

DEFAULT SETTINGS (CONTINUED)

Default settings for “Aux” interface

The secondary scanner and the MS7320 always communicate via RS232. Data
is relayed to the host via various primary interfaces.

Parameter Default OCIA RS-232

Aux Baud Rate 38400

Aux parity space

Aux data bits 7

Aux stop bits 2

Aux character RTS

Aux message RTS

Aux Ack/Nak

Aux Xon/Xoff

Aux D/E commands

Aux M/O commands

Aux F/L commands

Aux Intercharacter Delay 1 msec

*

*

*

aaaa a a

aaaa a a

aaaa a a

aaaa a a

aaaa a a

aaaa a a

aaaa a a

aaaa a a

aaaa a a

aaaa a a

aaaa a a

aaaa a a

Light

Pen

IBM

46XX

KBW USB

Aux Port Data Format

38

None

(Disabled)

aaaa a a

MS7220 STANDS

Vertical Stand Kit [ MLPN 46-46405 ]

See page 40 for installation instructions.

Kit Includes:

a. #8 x 1 round head wood screw [
b. M3 x .5 x 6mm pan head screw [
c. Vertical base cover [
d. Cable door [

Tools required for installation:

• Flat head screw driver

• Phillips head screw driver

• ¼”-20 wrench

• Drill with #39 drill bit (Needed for hard mount installation only)

Optional Flex Stand Kit [ MLPN 46-46404 ]

See 41 for installation instructions.

Kit Includes:

a. Long coupler [
b. Bearing plate [
c. Bellows [
d. Flex pole [
e. ¼ -20 x 3/8 pan head screw [

MLPN 18-18057 ] Qty. 4
MLPN 18-18670 ] Qty. 3
MLPN 36-00363 ] Qty. 1
MLPN 18-18057 ] Qty. 2

MLPN 36-00324 ] Qty. 1
MLPN 36-00501 ] Qty. 1
MLPN 36-36615 ] Qty. 1
MLPN 36-00351 ] Qty. 1
MLPN 18-18602 ] Qty. 1

Tools required for installation:

• Flat head screw driver

• Phillips head screw driver

• ¼”-20 wrench

• Drill with #39 drill bit (Needed for hard mount installation only)

39

MS7220 STANDS

p

Vertical Stand Installation [ MLPN 46-46405 ]

Remove the three screws
securing the cable cover to the
unit and slide it up and off the
scanner. Disconnect the cable
and slide the horizontal stand
up and off the unit.

Mounting the MS7220: Peel off the base plate’s tape backing and affix it to the
countertop or drill four #39 pilot holes and secure the base plate to the counterto
with the four #8 wood screws provided.

Replace the horizontal base
cover with the vertical base cover
[ 36-00363 ] then reassemble.

Disassemble the horizontal stand and
remove the horizontal cover plate.

Move the side cover from the vertical
to the horizontal position on the unit.

Slide the vertical stand onto the
unit.

40

Reattach the cable and secure the cable
cover with the three M3 screws.

MS7220 STANDS

Optional Flexible Stand Installation [ MLPN 46-46404 ]

Remove the three screws
securing the cable cover to the
unit and slide it up and off the
scanner. Disconnect the cable
and slide the horizontal stand
up and off the unit.

Mounting the MS7220: Peel off the base plate’s tape backing and affix it to the
countertop or drill four #39 pilot holes and secure the base plate to the
countertop with the four #8 wood screws provided.

Disassemble the horizontal stand. Remove
the lock nut and the short coupler. They will
not be used on the flex stand.

Slide the bearing plate over the
stud on the base plate then
attach the flex pole.

Slide the flex stand on the unit. Reconnect the cable and secure the cable

Slide the bellows over the flex pole and
cable. Position the long coupler over the
top of the bellows. Secure the long coupler
in place with the ¼-20 pan head screw
provided then position the foam insert over
the screw head.

cover with the three M3 screws.

41

SCANNER AND CABLE TERMINATIONS

Scanner Pinout Connections

The MS7220 scanner interfaces terminate to 10-pin modular jacks located on
the back of the unit. The serial # label indicates the interface enabled when the
scanner is shipped from the factory.

Figure 15: EAS Scanner Interface Ports

MS7220-13

OCIA

Pin Function Pin Function

1 Ground 1 Ground
2 NC 2 RS232 Transmit Output
3 NC 3 RS232 Receive Input
4 RDATA 4 RTS Output
5 RDATA Return 5 CTS Input
6 Clock in 6 DTR
7 Clock out 7 IBM B- (D-)

Clock in Return/

8

Clock out Rtrn

9 +5VDC 9 +5V IN

10 Shield Ground 10 NC

Continued next page

42

8 IBM A+ (D+)

MS7220-13

IBM 46xx

SCANNER AND CABLE TERMINATIONS (CONTINUED)

Figure 16: Scanner Interface Ports

MS7220-37
Keyboard Wedge, Stand
Alone Keyboard or USB

Pin Function Pin Function

1 Ground 1 Ground
2 USB D- 2 RS-232 Transmit Output
3 USB D+ 3 RS-232 Receive Input
4 PC Data 4 RTS Output
5 PC Clock 5 CTS Input
6 KB Clock 6 DTR Input/LTPN Source
7 PC +5V, V-USB 7 Reserved
8 KB Data 8 LTPN Data
9+5VDC 9+5VDC

10 Shield Ground 10 Shield Ground

MS7220-13/-37

Auxilary Port RS232 IN Only

Pin Function

1 Ground
2 RS-232 Receive Input
3 RS-232 Transmit Output
4RTS in
5 CTS out

6-10 NC

MS7220-37

RS-232 or Light Pen

43

SCANNER AND CABLE TERMINATIONS (CONTINUED)

Cable Connector Configurations (Host End)

PowerLink Cable MLPN 54-54xxx*

Pin Function

1 Shield Ground
2 RS-232 Transmit Output
3 RS-232 Receive Input
4 DTR Input
5 Power/Signal Ground
6 Reserved
7 CTS Input
8 RTS Output
9+5VDC

xxx* specifies connection to the host

USB PowerLink Cable

MLPN 54-54165, Type A)

(

Pin Function

1N/C
2D­3D+
4 Ground

PowerLink, RS232 AUX Cable

MLPN 54-54667

Pin Function

1 Ground
2 RS-232 Transmit Output
3 RS-232 Receive Input
4 RTS Output
5 CTS Input

6-10 N/C

95

61

9-Pin D-Type Conn.

4

1

USB Type A (Top)

Locking Type A (Bottom)

4

1

110

10-pin Modular Plug

Stand Alone Keyboard Cable

MLPN 54-54020

Pin Function

1 PC Data
2NC
3 Power Ground
4 +5VDC PC Power to KB
5 PC Clock
6NC

44

1

2

4

3

5

6

6-Pin Male Mini-DIN Conn.

SCANNER AND CABLE TERMINATIONS (CONTINUED)

Cable Connector Configuration

The PowerLink cable is terminated with a 5-pin DIN female connector on
one end, and a 6-pin mini DIN male on the other.

2

5

4

1

PowerLink Cable

5-Pin DIN, Female

3

Metrologic will supply an adapter cable with a 5-pin DIN male connector
on one end and a 6-pin mini DIN female connector on the other.

2

4

5

3

5-Pin Din, Male

1

Adapter Cable

According to the termination required, connect the appropriate end of the
adapter cable to the PowerLink cable, leaving the necessary termination
exposed for connecting to the keyboard and the keyboard port on the PC.
The pin assignments are as follows:

21

4

3

65

6-Pin DIN, Male

12

3

4

56

6-pin Mini Din, Female

PowerLink Cable Adapter Cable

5-pin Female DIN 5-pin Male DIN

Pin Function Pin Function

1 Keyboard Clock 1 PC Clock
2 Keyboard Data 2 PC Data
3 No Connect 3 No Connect
4 Power Ground 4 Power Ground
5 +5 Volts DC 5 +5 Volts DC

6-pin Male Mini-DIN 6-pin Female Mini-DIN

Pin Function Pin Function

1 Keyboard Data 1 Keyboard Data
2 No Connect 2 No Connect
3 Power Ground 3 Power Ground
4 +5 Volts DC 4 +5 Volts DC
5 PC Clock 5 Keyboard Clock
6 No Connect 6 No Connect

45

LIMITED WARRANTY

The MS7220 scanners are manufactured by Metrologic at its Blackwood, New Jersey,
U.S.A. facility. The MS7220 scanners have a two (2) year limited warranty from the date of
manufacture. Metrologic warrants and represents that all MS7220 scanners are free of all
defects in material, workmanship and design, and have been produced and labeled in
compliance with all applicable U.S. Federal, state and local laws, regulations and
ordinances pertaining to their production and labeling.

This warranty is limited to repair, replacement of Product or refund of Product price at the
sole discretion of Metrologic. Faulty equipment must be returned to the Metrologic facility in
Blackwood, New Jersey, U.S.A. or Puchheim, Germany. To do this, contact Metrologic’s
Customer Service/Repair Department to obtain a Returned Material Authorization (RMA)
number.

In the event that it is determined the equipment failure is covered under this warranty,
Metrologic shall, at its sole option, repair the Product or replace the Product with a
functionally equivalent unit and return such repaired or replaced Product without charge
for service or return freight, whether distributor, dealer/reseller, or retail consumer, or
refund an amount equal to the original purchase price.

This limited warranty does not extend to any Product which, in the sole judgement of
Metrologic, has been subjected to abuse, misuse, neglect, improper installation, or
accident, nor any damage due to use or misuse produced from integration of the Product
into any mechanical, electrical or computer system. The warranty is void if the case of
Product is opened by anyone other than Metrologic’s repair department or authorized
repair centers.

THIS LIMITED WARRANTY, EXCEPT AS TO TITLE, IS IN LIEU OF ALL OTHER
WARRANTIES OR GUARANTEES, EITHER EXPRESS OR IMPLIED, AND
SPECIFICALLY EXCLUDES, WITHOUT LIMITATION, W ARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE UNDER THE
UNIFORM COMMERCIAL CODE, OR ARISING OUT OF CUSTOM OR CONDUCT.
THE RIGHTS AND REMEDIES PROVIDED HEREIN ARE EXCLUSIVE AND IN LIEU OF
ANY OTHER RIGHTS OR REMEDIES. IN NO EVENT SHALL METROLOGIC BE
LIABLE FOR ANY INDIRECT OR CONSEQUENTIAL DAMAGES, INCIDENTAL
DAMAGES, DAMAGES TO PERSON OR PROPERTY, OR EFFECT ON BUSINESS OR
PROPERTY, OR OTHER DAMAGES OR EXPENSES DUE DIRECTLY OR INDIRECTLY
TO THE PRODUCT, EXCEPT AS STATED IN THIS WARRANTY. IN NO EVENT SHALL
ANY LIABILITY OF METROLOGIC EXCEED THE ACTUAL AMOUNT PAID TO
METROLOGIC FOR THE PRODUCT. METROLOGIC RESERVES THE RIGHT TO
MAKE ANY CHANGES TO THE PRODUCT DESCRIBED HEREIN.

Corporate Headquarters

Metrologic Instruments, Inc. Customer Service: 1-800-ID-METRO
90 Coles Road Tel: [phone]
Blackwood, NJ 08012-4683 Fax: [phone]

Germany

Metrologic Instruments GmbH Tel: [phone]
Dornierstrasse 2 Fax: [phone]
82178 Puchheim b. Email: [e-mail]
Munich, Germany

Email: [e-mail]
Website: www.metrologic.com

46

LASER AND PRODUCT SAFETY

Notice

This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including interference
that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:

• Reorient or relocate the receiving antenna

• Increase the separation between the equipment and receiver

• Connect the equipment into an outlet on a circuit different from that to which

the receiver is connected

• Consult the dealer or an experienced radio/TV technician for help

Notice

This Class B digital apparatus complies with Canadian ICES-003.

Avertissement

Cet appareil numérique de la class B est conforme à la norme NMB-003.

47

LASER AND PRODUCT SAFETY

Caution

Use of controls or adjustments or performance of procedures other than those
specified herein may result in hazardous laser light exposure. Under no
circumstances should the customer attempt to service the laser scanner. Never
attempt to look at the laser beam, even if the scanner appears to be
nonfunctional. Never open the scanner in an attempt to look into the device.
Doing so could result in hazardous laser light exposure. The use of optical
instruments with the laser equipment will increase eye hazard.

Atención

La modificación de los procedimientos, o la utilización de controles o ajustes
distintos de los especificados aquí, pueden provocar una luz de láser peligrosa.
Bajo ninguna circunstancia el usuario deberá realizar el mantenimiento del láser
del escáner. Ni intentar mirar al haz del láser incluso cuando este no esté
operativo. Tampoco deberá abrir el escáner para examinar el aparato. El
hacerlo puede conllevar una exposición peligrosa a la luz de láser. El uso de
instrumentos ópticos con el equipo láser puede incrementar el riesgo para la
vista.

Attention

L'emploi de commandes, réglages ou procédés autres que ceux décrits ici peut
entraîner de graves irradiations. Le client ne doit en aucun cas essayer
d'entretenir lui-même le scanner ou le laser. Ne regardez jamais directement le
rayon laser, même si vous croyez que le scanner est inactif. N'ouvrez jamais le
scanner pour regarder dans l'appareil. Ce faisant, vous vous exposez à une
rayonnement laser qú êst hazardous. L'emploi d'appareils optiques avec cet
équipement laser augmente le risque d'endommagement de la vision.

Achtung

Die Verwendung anderer als der hier beschriebenen Steuerungen, Einstellungen
oder Verfahren kann eine gefährliche Laserstrahlung hervorrufen. Der Kunde
sollte unter keinen Umständen versuchen, den Laser-Scanner selbst zu warten.
Sehen Sie niemals in den Laserstrahl, selbst wenn Sie glauben, daß der
Scanner nicht aktiv ist. Öffnen Sie niemals den Scanner, um in das Gerät
hineinzusehen. Wenn Sie dies tun, können Sie sich einer gefährlichen
Laserstrahlung aussetzen. Der Einsatz optischer Geräte mit dieser
Laserausrüstung erhöht das Risiko einer Sehschädigung.

Attenzione

L’utilizzo di sistemi di controllo, di regolazioni o di procedimenti diversi da
quelli descritti nel presente Manuale può provocare delle esposizioni a raggi
laser rischiose. Il cliente non deve assolutamente tentare di riparare egli
stesso lo scanner laser. Non guardate mai il raggio laser, anche se credete
che lo scanner non sia attivo. Non aprite mai lo scanner per guardare dentro
l’apparecchio. Facendolo potete esporVi ad una esposizione laser rischiosa.
L’uso di apparecchi ottici, equipaggiati con raggi laser, aumenta il rischio di
danni alla vista.

48

PATENTS

“Patent Information

This METROLOGIC product may be covered by one or more of the following
U.S. Patents:

U.S. Patent No.;
4,960,985; 5,081,342; 5,216,232; 5,260,553; 5,340,971; 5,343,027;
5,557,093; 5,627,359; 5,637,852; 5,661,292; 5,686,717; 5,777,315;
5,789,731; 5,828,049; 6,029,894; 6,098,885; 6,209,789;

4,360,798; 4,369,361; 4,387,297; 4,460,120; 4,496,831; 4,593,186;
4,607,156; 4,673,805; 4,736,095; 4,758,717; 4,816,660; 4,845,350;
4,896,026; 4,923,281; 4,933,538; 4,992,717; 5,081,342; 5,015,833;
5,017,765; 5,059,779; 5,117,098; 5,124,539; 5,130,520; 5,132,525;
5,140,144; 5,149,950; 5,180,904; 5,200,599; 5,229,591; 5,247,162;
5,250,790; 5,250,791; 5,250,792; 5,260,553; 5,262,628; 5,280,162;
5,280,164; 5,304,788; 5,321,246; 5,324,924; 5,340,973; 5,396,053;
5,396,055; 5,408,081; 5,410,139; 5,424,525; 5,436,440; 5,449,891;
5,468,949; 5,468,951; 5,479,000; 5,484,992; 5,525,789; 5,528,024;
5,532,469; 5,545,889; 5,591,953; 5,616,908; 5,627,359

No license right or sublicense is granted, either expressly or by implication,
estoppel, or otherwise, under any METROLOGIC or third party intellectual
property rights (whether or not such third party rights are licensed to
METROLOGIC), including any third party patent listed above, except for an
implied license only for the normal intended use of the specific equipment,
circuits, and devices represented by or contained in the METROLOGIC products
that are physically transferred to the user, and only to the extent of
METROLOGIC’S license rights and subject to any conditions, covenants and
restrictions therein.”

Other worldwide patents pending.

49

INDEX

A

Accessories...................................2

Adapter....................................2, 45

Audible ........................................16

Autodiscriminates........................31

B

Bar Code .........................20, 21, 22

Beep......................................16, 34

C

Cable......2, 5, 9, 13, 27, 28, 31, 39,

42-45

Caution....................5, 6, 7, 8, 9, 11

CE ...............................................48

Communication .....................30, 34

Connector..............................44, 45

Customer Service....................2, 46

D

Decode Capability .......................31

Default Settings......................33-38

Design Specifications............31, 32

E

EAS ............................................. 23

Electrical......................................32

Extended Depth of Field..............37

F

Failure Modes..............................17

Function ...........................37, 42-45

G

Ground ...................................42-45

H

Host.............................................11

I

Indicators.........................16, 18, 31

Input Voltage ...............................32

Installation ..2, 5, 6, 9-12, 39, 40, 41

Interfaces .......................5, 7-10, 24

K

Keyboard Type............................30

Keyboard Wedge 1, 2, 6, 30, 31, 43

L

Labels..........................................19

LED ...............13, 16, 18, 24, 25, 31

Light Levels .................................32

Light Pen 1, 2, 10, 30-31, 33-38, 43

Light Source ................................31

M

Maintenance ............................... 23

Mechanical.................................. 31

Min Bar Width .............................31

Modes ......................................... 14

N

Normal Depth of Field................. 37

Notices........................................ 48

O

OCIA ........ 1, 2, 5, 30, 31, 33-38, 42

Operating Current ....................... 32

Operation .................................... 31

Operational ................................. 31

Output Window ........................... 13

P

Parts ........................................... 13

Patents........................................ 48

Port ....................................... 38, 43

Power Save................................. 14

Programming Guide.... 2, 16, 28, 30

Protocols..................................... 30

R

Razzberry Tone ..............16, 17, 34

RDATA........................................ 42

Repair ......................................... 46

S

Scan Lines .................................. 31

Scan Pattern ............................... 31

Scan Speed ................................ 31

Specifications............. 20-22, 31, 32

Stand .................... 2, 31, 39, 40, 41

Storage ....................................... 32

System Interfaces ....................... 31

T

Termination................................. 31

Transformers .............................. 32

Troubleshooting..................... 24-28

V

Ventilation ................................... 32

Visual .......................................... 18

Voltage................................. 5-9, 11

W

Warranty .....................................46

Weight ........................................ 31

50

July 2003

Printed in USA

00- 02554B
