Page 1

Item # ______________________________________________

Job ________________________________________________

Utility Carts – Three-Shelf MW200, MW400 and MW700 Series

SUPER ERECTA SHELF

MW UTILITY CARTS —

Three-Shelf Models

• Attractive and thoroughly practical, these carts are offered as complete units, shipped knocked down, with all components packaged in a compact carton.

• Super Erecta Shelf® Construction makes units easy to assemble with absolute rigidity, and makes relocation of shelves quick and simple.

• Choice of 20 Three-Shelf Models:

MW200 Series — Three stainless steel ﬂat shelves.

Five sizes. Stainless steel handles.

MW400 Series — Two chrome wire shelves and one

stainless steel ﬂat shelf. Five sizes. Chrome handles. Solid shelf can be positioned top, middle or bottom.

MW700 Series — Three wire shelves, choice of chrome

or stainless steel. Five sizes; ten models. Handle material matches shelves.

• Wire Shelves: Bright, modern, sanitary appearance. Open construction minimizes dust accumulation, maximizes visibility and air circulation.

• Solid Shelves: Ideal for transporting materials that require an expanse of ﬂat surface. Raised ship’s edge permits fast clean-up in case of liquid spills. Double thickness of 18-gauge steel at edges also gives rigidity and high strength.

• Casters: Standard-duty. 4LD 4" (102mm) diameter casters on carts 18" (457mm) wide; 5LD 5" (127mm) diameter casters on carts 21" (533mm) and 24" (610mm) wide. See sheet #11.20 for additional information on casters.

• Donut Bumpers

• One-Piece Handle

• Height: 38" (965mm) ﬂoor to handle with 4" (102mm) casters;

39" (991mm) ﬂoor to handle with 5" (127mm) casters.

• Replaceable Parts: If any part of any cart is damaged by use, replacement parts are readily available and easily installed.

• Accessories: A wide variety are available to increase usefulness. See Catalog Sheets 10.04 and 10.05 for wire shelf accessories, 10.25 for solid shelf accessories.

MW700 Series

MW200 Series

InterMetro Industries Corporation

North Washington Street Wilkes-Barre, PA 18705 www.metro.com

MW400 Series

12.05

Page 2

Job ________________________________________________Job ________________________________________________

12.05

SUPER ERECTA SHELF

MW UTILITY CARTS — Three-Shelf Models

MW Carts (Three-Shelf Models)

MW200 Series

Dimensions

Approx. Width Length Pkd. Wt. Casters Cat. No. (in.) (mm) (in.) (mm) (lbs.) (kg) Shelves Shelf Material Handles (in.) (mm)

MW203 18 457 24 610 48 21.8 3-Solid Stainless Steel Stainless Steel 4 102 MW204 18 457 30 760 53 24.0 3-Solid Stainless Steel Stainless Steel 4 102 MW205 18 457 36 914 59 26.8 3-Solid Stainless Steel Stainless Steel 4 102 MW206 21 533 36 914 66 29.9 3-Solid Stainless Steel Stainless Steel 5 127 MW208 24 610 36 914 74* 33.6 3-Solid Stainless Steel Stainless Steel 5 127 MW401 18 455 24 610 43 19.5 1-Solid Stainless Steel Chrome 4 102 2-Wire Chrome MW402 18 457 30 760 47 21.3 1-Solid Stainless Steel Chrome 4 102 2-Wire Chrome MW403 18 457 36 914 52 23.6 1-Solid Stainless Steel Chrome 4 102 2-Wire Chrome MW404 21 533 36 914 59 26.8 1-Solid Stainless Steel Chrome 5 127 2-Wire Chrome MW406 24 610 36 914 65 29.5 1-Solid Stainless Steel Chrome 5 127 MW701 18 457 24 610 39 17.6 3-Wire Chrome Chrome 4 102 MW702 18 457 24 610 38 17.2 3-Wire Stainless Steel Stainless Steel 4 102 MW703 18 457 30 760 43 19.5 3-Wire Chrome Chrome 4 102 MW704 18 457 30 760 42 19.1 3-Wire Stainless Steel Stainless Steel 4 102 MW705 18 457 36 914 47 21.3 3-Wire Chrome Chrome 4 102 MW706 18 457 36 914 45 20.4 3-Wire Stainless Steel Stainless Steel 4 102 MW707 21 533 36 914 50 22.7 3-Wire Chrome Chrome 5 127 MW708 21 533 36 914 50 22.7 3-Wire Stainless Steel Stainless Steel 5 127 MW711 24 610 36 914 60 27.2 3-Wire Chrome Chrome 5 127 MW712 24 610 36 914 57 25.9 3-Wire Stainless Steel Stainless Steel 5 127

* Cannot be shipped UPS.

MW700 SeriesMW400 Series

All Metro Catalog Sheets are available on our Web Site: www.metro.com

SUPER ERECTA SHELF

Utility Carts – Three-Shelf MW200, MW400 and MW700 Series

For Product Information: U.S. and Canada: 1.800.433.2232

InterMetro Industries Corporation

North Washington Street, Wilkes-Barre, PA 18705 Phone: 570-825-2741 Fax: 570-825-2852

Latin America: 1.561.333.3824 Europe: +31.76.587.7550

Printed in U.S.A. Rev. 11

Information and speciﬁcations are subject to change

without notice. Please conﬁrm at time of order.

Asia/Paciﬁc: +65.6567.8003 Middle East/Africa: +971.4.811.8286

L02-055
