Page 1
®
®
Item # ______________________________________________
Job ________________________________________________
Super Erecta Shelf® SOLID SHELVING ACCESSORIES
• 4" Shelf Ledges for Solid
Shelves: To prevent items from
protruding or falling off shelves,
ledges can be installed on the
shelf edges. Spring-clip tabs
(supplied with ledge) are used
to attach ledges to solid
shelves.
• Rods & Tabs for Solid
Shelving: Can be used in place
of ledges to enclose sides and
back of entire unit. Rods hook
over outer edge of top shelf
and attach to each shelf with
spring-clip tab. Required: one
tab per shelf per rod.
Dimensions
Length Cat. No. Cat. No.
(in.) (mm) Chrome Stainless
14 355 L14WC L14WS
18 455 L18WC L18WS
21 530 L21WC L21WS
24 610 L24WC L24WS
30 760 L30WC L30WS
36 910 L36WC L36WS
42 1065 L42WC L42WS
48 1220 L48WC L48WS
60 1525 L60WC L60WS
• Rods
Dimensions
Post
Number Rod Length Cat. No.
(minimum) (in.) (mm) Chrome
54 52 1320 R52FC
63 60 1525 R60FC
74 72 1830 R72FC
86 84 2135 R84FC
NSF
®
Solid Shelving Accessories
• 8" Shelf Dividers: Shelf
dividers enable you to
compartmentalize shelves, help
keep shelf contents orderly.
They attach to solid shelf with
spring clip at each end of the
divider. All models 8" high.
• Adjustable Undershelf Slides:
An undershelf drawer can be
created by combining a tote
box with these slides. Two slides
are required and can be spaced
to fit any width container,
including TB22 or BSD1350.
LOAD RATING: 25 lbs. (11.3 kg.)
• Tabs
Tabs for 4-shelf unit supplied
with rods. For additional tabs,
order: Solid Shelf Tab —
Cat. No. 9184Z
Dimensions
Shelf
Width Cat. No. Cat. No.
(in.) (mm) Chrome Stainless
14 355 DD14FC
18 455 DD18FC DD18FS
21 530 DD21FC
24 610 DD24FC DD24FS
Item Cat. No.
One Slide US18FA
for 18" wide shelf
One Slide US21FA
for 21" wide shelf
One Slide US24FA
for 24" wide shelf
DD24FS
NSF
®
10.25
InterMetro Industries Corporation
®
North Washington Street
Wilkes-Barre, PA 18705
www.metro.com
Copyright © 2000 InterMetro Industries Corp.
Page 2
Job ________________________________________________
®
®
Super Erecta Shelf
10.25
SOLID SHELVING ACCESSORIES
• Solid Shelf Joining Clamp:
Used to “add on” solid shelving
units with only two posts required.
Units can be joined end-to-end,
back-to-back or at right angles.
Two clamps required for each shelf.
Clamp adds 1/4"(6mm) clearance
between shelves.
Cat. No. 9998Z
• Hole Plug: Used to fill corner
openings where posts have
been eliminated by joining
clamp.
Cat. No. 9997C
®
• Post Clamp: For maximum
strength in adjacent shelving
units, the post clamp is
recommended. With it each unit
is supported by four posts and
buttressed by the adjacent unit.
Cat. No. 9994Z
• Foot Plate: Replaces the
leveling bolt. Used when units
are to be bolted to the floor or,
without bolts, when a broader
foot is desired.
Zinc
Cat. No. 9993Z
Stainless Steel
Cat. No. 9993S
• Glides: Fit over leveling bolt to
protect tile floors.
Cat. No. 9991P
Solid Shelving Accessories
Manufactured by:
®
InterMetro Industries Corporation
North Washington Street, Wilkes-Barre, PA 18705
Phone: 570-825-2741 • Fax: 570-825-2852
For Product Information Call: 1-800-433-2232
Visit Our Web Site: www.metro.com
L02-015
Rev. 9/00
Printed in U.S.A.
Information and specifications are subject to change
without notice. Please confirm at time of order.
