COMAND
Supplement
Order no. P000 0057 13 Part no. 117 584 62 03 Edition B-2017
COMAND Operating Instructions
Symbols
In this Operator's Manual you will find the following symbols:
WARNING
G
Warning notes make you aware of dangers
which could pose a threat to your health or
life, or to the health and life of others.
Environmental note
H
Environmental notes provide you with information on environmentally aware actions or
disposal.
Notes on material damage alert you to dan-
!
gers that could lead to damage to your vehicle.
Practical tips or further information that
i
could be helpful to you.
X
X
(Y
page)
Dis‐
play
Parts of the software in the vehicle are protected
by copyright
http://www.freetype.org. All rights reserved.
This symbol indicates an instruction
that must be followed.
Several of these symbols in succession
indicate an instruction with several
steps.
This symbol tells you where you can find
more information about a topic.
This text indicates a message in the
multimedia display.
©
2005 The FreeType Project
Publication details
Internet
Further information about Mercedes-Benz vehicles and about Daimler AG can be found on the
following websites:
http://www.mbusa.com (USA only)
http://www.mercedes-benz.ca (Canada only)
Editorial office
You are welcome to forward any queries or suggestions you may have regarding this Operator's
Manual to the technical documentation team at
the following address:
Daimler AG, HPC: CAC, Customer Service,
70546 Stuttgart, Germany
©
Daimler AG: Not to be reprinted, translated or
otherwise reproduced, in whole or in part, without written permission from Daimler AG.
Vehicle manufacturer
Daimler AG
Mercedesstraße 137
70327 Stuttgart
Germany
As at 10.09.2015
Welcome to the world of Mercedes-Benz
First of all, familiarize yourself with your multimedia system. Read these operating instructions, particularly the safety and warning notes,
before you drive off.
This will help you to obtain the maximum pleasure from your multimedia system and avoid
endangering yourself and others.
The equipment level and functions of your multimedia system may differ depending on:
R
Model
R
Order
R
Country specification
R
Availability
Mercedes-Benz therefore reserves the right to
introduce changes in the following areas:
R
design
R
equipment
R
technical features
The equipment in your vehicle may therefore
differ from that shown in the descriptions and
illustrations.
Consult an authorized Mercedes-Benz Center if
you have further questions.
The Operator's Manual and all supplements are
integral parts of the vehicle. You should always
keep it in the vehicle and pass it on to the new
owner if you sell the vehicle.
The technical documentation team at
Daimler AG wishes you safe and pleasant motoring.
Mercedes-Benz USA, LLC
Mercedes-Benz Canada, Inc.
A Daimler Company
1175846203
É1175846203OËÍ
2
Contents
Index ....................................................... 4
Introduction ......................................... 14
Operating safety .................................... 14
Data stored in the vehicle ...................... 15
Information on copyright .......................17
Your multimedia system equipment ...... 17
Overview and operation ..................... 18
Overview ................................................ 18
Touchpad ...............................................22
Basic functions ...................................... 27
Character entry (telephony) ................... 29
Character entry (navigation) .................. 30
Favorites ................................................ 31
System settings .................................. 34
Your multimedia system equipment ...... 34
Important safety notes .......................... 34
Display settings ..................................... 34
Time settings .........................................35
Text reader settings ...............................37
Voice Control System settings ............... 37
Wi-Fi ...................................................... 37
Bluetooth
Setting the system language .................41
Calling up the favorite functions ............ 41
Importing/exporting data ...................... 42
Reset function .......................................43
Vehicle functions ................................ 45
Your multimedia system equipment ...... 45
Important safety notes .......................... 45
Vehicle settings ..................................... 45
Seats ..................................................... 47
360° camera ......................................... 48
Rear view camera .................................. 49
DYNAMIC SELECT .................................. 50
Driving dynamics ................................... 52
®
settings ............................... 41
Destination entry ................................... 57
Personal POIs and routes ...................... 68
Route guidance ...................................... 71
Real-time traffic reports ......................... 77
Storing destinations ............................... 81
Map functions ........................................ 83
Navigation functions .............................. 89
Problems with the navigation system .... 90
Telephone ............................................ 92
Your multimedia system equipment ...... 92
Important safety notes .......................... 92
General notes ........................................ 92
Telephone menu overview ..................... 93
Connecting/disconnecting a mobile
phone .................................................... 93
Setting the reception and transmis-
sion volume ........................................... 97
Using the telephone .............................. 98
Mobile phone voice recognition ........... 101
Phone book ......................................... 102
Address book ...................................... 105
Importing contacts .............................. 110
Call lists ............................................... 111
Speed dial lists .................................... 113
Messages (text messages and e-
mails) ................................................... 114
Dictation function ................................ 120
Apple CarPlay™ ................................... 121
Android Auto™ .................................... 123
Online and Internet functions .......... 125
Your multimedia system equipment .... 125
Important safety notes ........................ 125
General notes ...................................... 125
Conditions for access .......................... 125
Setting up an Internet connection
(Canada) .............................................. 126
Establishing/ending the connection .... 129
Mercedes-Benz Apps ........................... 129
Web browser ....................................... 130
Navigation ........................................... 53
Your multimedia system equipment ...... 53
Introduction ........................................... 53
Basic settings ........................................ 55
Radio .................................................. 135
Your multimedia system equipment .... 135
Switching on the radio ......................... 135
Overview .............................................. 135
Setting the waveband .......................... 136
Station ................................................. 136
Tagging music tracks ........................... 138
Displaying station information ............. 138
Calling up sound settings .................... 138
Displaying information ......................... 138
Satellite radio ...................................... 138
Media ................................................. 144
Your multimedia system equipment .... 144
Activating media mode ........................ 144
Audio/video mode ............................... 145
Media search ....................................... 152
®
Bluetooth
audio mode ....................... 154
Operation with the Media Interface ..... 158
Video DVD mode ................................. 161
Picture viewer ...................................... 165
Sound ................................................. 167
Your multimedia system equipment .... 167
Sound settings ..................................... 167
®
Harman/kardon
Logic 7®surround
sound system ...................................... 168
Bang & Olufsen BeoSound ................... 170
Contents
3
SIRIUS Weather ................................ 173
Your multimedia system equipment .... 173
Weather forecasts ............................... 173
Rear Seat Entertainment System .... 181
Your multimedia system equipment .... 181
Overview .............................................. 181
Basic functions .................................... 185
System settings ................................... 187
Audio CD/DVD and MP3 mode ........... 187
Video DVD mode ................................. 190
Active COMAND media source mode .. 194
AUX mode ........................................... 196
Index
4
1, 2, 3 ...
360° camera
Displaying images ............................ 48
Opening the camera cover for
cleaning (COMAND) .........................49
Settings ........................................... 49
A
Access data of the mobile phone
network provider
Deleting ......................................... 128
Editing ........................................... 128
Making entries ............................... 127
Selecting ........................................ 127
Activating media mode
General notes ................................ 144
Adding bookmarks ............................ 131
Address book
Adding a new contact .................... 106
Adding information to a contact .... 107
Automatically importing contacts
from the phone .............................. 109
Browsing ........................................ 106
Calling up ....................................... 106
Changing the category of an entry .. 108
Changing the display and sorting
criteria for contacts ....................... 109
Deleting contacts ........................... 110
Deleting imported contacts ........... 111
Displaying contact details .............. 107
Editing a contact ............................ 108
Importing contacts ........................ 110
Introduction ................................... 105
Making a call ................................. 108
Receiving vCards ........................... 111
Saving a contact ............................ 110
Searching for a contact ................. 106
Sending e-mails ............................. 108
Sending text messages .................. 108
Starting route guidance ................. 107
Storing a phone number as a
speed dial number ......................... 108
Voice tags ...................................... 109
Address entry menu ............................ 57
Adjusting the volume
COMAND ......................................... 27
Traffic announcements .................... 27
Alternative Route ................................ 75
Ambient lighting
Setting (COMAND) ........................... 45
Android Auto™
Activating voice control ................. 124
Calling up the sound settings ........ 123
Canceling the connection .............. 124
Establishing a connection .............. 123
Transmitted vehicle data ............... 124
Apple CarPlay™
Activating ....................................... 122
Changing the activation mode ....... 122
Connecting .................................... 121
Ending ............................................ 122
Requirements ................................ 121
Transmitted vehicle data ............... 122
Armrest
COMAND) ....................... 47
sting (
Adju
Audio CD/DVD and MP3 mode
Switching to (Rear Seat Entertain-
ment System) ................................ 188
Audio CD/MP3 mode
Switching to ................................... 144
Audio CDs
Saving ............................................ 151
Automatic time
Switching on/off .............................. 35
AUX jacks
CD/DVD drive ............................... 183
Avoiding an area .................................. 86
B
Back button ......................................... 21
Bang & Olufsen sound system
Balance/Fader ............................... 171
Calling up the sound menu ............ 170
Equalizer ........................................ 170
Features ........................................ 170
Sound profile ................................. 171
VIP selection .................................. 171
Blootooth
®
Connecting a different mobile
phone .............................................. 96
Bluetooth
®
Activating audio mode ................... 157
Activating/deactivating ................... 41
Index
5
Basic display (audio mode) ............ 157
Connecting audio devices .............. 154
De-authorizing (de-registering) a
device ............................................ 157
Device list ...................................... 154
Displaying connection details .......... 97
Entering the passcode ..................... 95
External authorization (audio
device) ........................................... 155
Increasing the volume using
COMAND ....................................... 158
Interface .......................................... 92
Reconnecting an audio device ....... 156
Searching for a mobile phone .......... 94
Selecting a playback option ........... 158
Starting playback if the Blue-
®
audio device has been
tooth
stopped ......................................... 157
Telephony ........................................ 93
Telephony notes .............................. 92
Buttons and controller ........................ 21
C
Call lists
Displaying details ........................... 112
Opening and selecting an entry ..... 112
Saving an entry in the address
book .............................................. 112
Camera
360° camera (COMAND) ................. 48
Rear view camera ............................ 49
Car pool lanes ...................................... 57
Category list (music search) ............ 152
CD
Fast forward/fast rewind ............... 150
Inserting ........................................ 147
Inserting/loading (DVD changer) ... 148
Inserting/loading (Rear Seat
Entertainment System) .................. 188
Notes on discs ............................... 147
Removing/ejecting (Rear Seat
Entertainment System) .................. 188
Selecting a track ............................ 150
CD mode
Playback options ........................... 149
Character entry
Phone book ...................................... 29
Characters
Entering (navigation) ........................ 30
Clear button ......................................... 21
Climate control
Ionization (COMAND) ....................... 46
COMAND
Active multicontour seat .................. 47
Basic functions ................................ 27
Components .................................... 18
Control panel ................................... 20
Controller ......................................... 21
Display ............................................. 19
Functions ......................................... 18
Multicontour seat ............................ 47
Seat functions .................................. 47
Switching on/off .............................. 27
COMAND display
Cleaning instructions ....................... 19
Setting ............................................. 34
Contacts
Deleting ......................................... 110
Importing ....................................... 110
Controller ............................................. 21
Cordless headphones
Changing batteries ........................ 185
Indicator lamp ................................ 184
Rear Seat Entertainment System ... 183
Selecting the screen ...................... 184
D
Date format, setting ............................ 36
Day design, setting ............................. 34
Delayed switch-off
Interior lighting ................................ 46
Delayed switch-off time
Setting (COMAND) ........................... 46
Destination
Saving to an SD card ....................... 81
Storing in the address book ............. 81
Destination (navigation)
Entering a destination using the
map ................................................. 64
Entering a point of interest .............. 62
Entering using geo-coordinates ....... 67
Entering using Mercedes-Benz
Apps ................................................ 67
Keyword search ............................... 60
Index
6
Saving .............................................. 81
Selecting an address book con-
tact as a destination ........................ 62
Selecting from the list of last des-
tinations ........................................... 61
Dialing a number (telephone) ............. 98
Display
Selecting the design ........................ 34
Switching on/off .............................. 35
Displaying energy consumption
and generated electrical energy
(COMAND) ............................................ 46
Driving Dynamics
Displaying ........................................ 52
DVD
Inserting/loading (DVD changer) ... 148
Inserting/loading (Rear Seat
Entertainment System) .................. 188
Notes on discs ............................... 147
Removing/ejecting (DVD
changer) ........................................ 148
Removing/ejecting (Rear Seat
Entertainment System) .................. 188
DVD video
Rear Seat Entertainment System ... 190
DYNAMIC SELECT
Configuration via the DYNAMIC
SELECT controller ............................ 50
Configuring individual drive pro-
gram ................................................ 50
Configuring using the DYNAMIC
SELECT button ................................. 50
Displaying engine data ..................... 50
Setting options ................................ 51
E
E-mail
Answering ...................................... 118
Calling up the settings menu ......... 115
Changing the name of the e-mail
account .......................................... 115
Configuring an e-mail account ....... 115
Configuring the e-mails displayed .. 115
Deactivating the e-mail function .... 115
Deleting ......................................... 120
Displaying details ........................... 117
Downloading e-mails manually ...... 116
Editing text templates .................... 119
Forwarding ..................................... 119
Inbox .............................................. 116
Reading .......................................... 116
Settings ......................................... 115
Storing the sender as a new entry
in the address book ....................... 120
Using a phone number in the text .. 119
Using text templates ...................... 119
Writing ........................................... 118
Entering the address (example) ......... 58
Entering the city .................................. 58
F
Factory setting (reset function) ......... 43
Favorites
Adding ............................................. 32
Deleting ........................................... 32
Displaying and calling up ................. 31
Moving ............................................. 32
Overview .......................................... 31
Renaming ......................................... 32
Favorites (Internet) ........................... 133
Favorites button .................................. 41
Fuel consumption (COMAND) ............ 46
G
GPS reception ...................................... 53
®
Gracenote
Media Database ............ 151
H
Handwriting recognition
Switching text reader function
on/off .............................................. 25
Touchpad ......................................... 24
®
Harman kardon
Logic 7®sur-
round sound system
Balance/Fader ............................... 169
Calling up the sound menu ............ 168
Equalizer ........................................ 169
Features ........................................ 168
Surround sound ............................. 169
Heading up (navigation) ..................... 83
Home address
Entering and saving ......................... 59
Index
7
I
Incident (traffic report) .......................77
Intermediate destinations
Accepting for the route .................... 67
Creating ...........................................65
Editing .............................................. 66
Entering ........................................... 65
Searching for a gas station when
the fuel level is low .......................... 67
Internet
Conditions for access .................... 125
Creating favorites .......................... 133
Entering the URL ............................ 130
Favorites manager ......................... 133
Favorites menu .............................. 133
Menu functions .............................. 131
Options menu ................................ 131
Selecting/setting access data ....... 126
Setting up an Internet connection .. 126
K
Keyword search (navigation)
Entering keywords ........................... 60
Online search ................................... 61
Selecting search options ................. 61
Selecting search results ................... 60
L
Lane recommendations
Explanation ...................................... 72
Presentation .................................... 72
Lights
Activating/deactivating the exte-
rior lighting delayed switch-off ......... 46
Setting the ambient lighting
(COMAND) ....................................... 45
List of access data
New provider ................................. 127
List of mobile phone network providers
With the selected provider ............. 127
Locator lighting
Setting (COMAND) ........................... 46
Lumbar support
Adjusting (COMAND) ....................... 47
M
Making a call
Using speed dial .............................. 99
Using the call lists ............................ 98
Using the number keypad ................ 98
Using the phone book ...................... 98
Map
Selecting map content ..................... 83
Map (navigation)
Adjusting the scale .......................... 83
Building images ................................ 86
Displaying the next intersection ...... 85
Heading ........................................... 83
Map settings .................................... 83
Moving ............................................. 54
North orientation ............................. 83
Notes ............................................... 83
Rotating the 3D map ........................ 85
Selecting POI symbols on the
map ................................................. 84
Selecting text information on the
map ................................................. 84
Showing the map version ................. 85
Switching highway information
on/off .............................................. 85
Traffic Sign Assist ............................ 85
Updating .......................................... 88
Map functions ...................................... 83
Massage
Selecting a program ......................... 48
Media Interface
Mode ............................................. 158
Playback options ........................... 160
Search ........................................... 159
Selecting a music file ..................... 159
Switching to Media Interface ......... 159
Video function ............................... 160
Media mode
Connections for external media
sources .......................................... 144
Media search
By folder ........................................ 153
Category list .................................. 152
Current tracklist ............................ 153
General notes ................................ 152
Keyword search ............................. 153
Music genres ................................. 153
Index
8
Selecting by cover ......................... 153
Starting the media search .............. 152
Menu overview
CD audio and MP3 mode ............... 147
Mercedes-Benz Apps
Calling up ....................................... 129
Voice control ................................. 130
Microphone, switching on/off ......... 100
Mobile phone
Authorizing ....................................... 95
®
Connecting (Bluetooth
inter-
face) ................................................ 93
Connecting another mobile
phone .............................................. 96
De-authorizing ................................. 97
®
Displaying Bluetooth
connection
details .............................................. 97
Enabling for Internet access .......... 126
MP3
Copyright ....................................... 147
Fast forward/fast rewind ............... 150
Notes ............................................. 145
Safety notes .................................. 145
Stop and playback function ........... 150
N
Navigation
Adjusting the volume of the navi-
gation announcements .................... 27
Alternative route .............................. 75
Avoiding an area .............................. 86
Basic settings .................................. 55
Blocking a route section affected
by a traffic jam ................................. 76
Calling up the compass display ........ 89
Calling up the menu ......................... 89
Entering a destination ...................... 57
Entering a destination using the
map ................................................. 64
Entering a point of interest .............. 62
Entering characters (character
bar) .................................................. 30
GPS reception .................................. 53
Important safety notes .................... 53
Info on navigation ............................ 89
Lane recommendation ..................... 72
Off-road/Off-map (off-road desti-
nation) ............................................. 77
Online map display .......................... 89
Reading out traffic reports ............... 80
Repeating announcements .............. 74
Selecting a destination from the
list of last destinations ..................... 61
Setting route options (avoiding:
highways, toll roads, tunnels, fer-
ries) ................................................. 55
Setting the route type (short
route, fast route, dynamic route or
economic route) ............................... 55
Showing/hiding the menu ............... 54
Starting route calculation ................ 59
Switching announcements
on/off .............................................. 74
Switching to ..................................... 54
Navigation announcements
Switching off .................................... 28
North orientation (navigation) ........... 83
O
Off-road ................................................ 77
Online and Internet functions
Calling up the device list ................ 128
Enabling a mobile phone for Inter-
net access ..................................... 126
Ending the connection ................... 129
Establishing a connection .............. 129
Manually setting the access data
of the mobile phone network pro-
vider .............................................. 127
Mercedes-Benz Apps ..................... 129
Selecting the access data of the
mobile phone network provider ..... 127
Setting up an Internet connection .. 126
Web browser .................................. 130
P
Pause function
Video DVD ..................................... 165
Personal POIs and routes
Alert when approaching (personal
POI) .................................................. 68
Editing .............................................. 69
Index
9
Importing via Mercedes-Benz
Apps ................................................ 69
Recording the route .........................70
Saving .............................................. 68
Selecting .......................................... 69
Settings for personal POIs ............... 68
Phone book
Adding a new contact .................... 103
Adding information to a contact .... 104
Automatically importing contacts
from the mobile phone .................. 104
Calling up ....................................... 102
Deleting a contact ......................... 105
Displaying the details of an entry ... 103
Entering characters ......................... 29
Saving a contact ............................ 105
Searching for a contact ................. 102
Symbol overview ............................ 102
Phone call
Dialing .............................................. 98
Picture viewer
Changing view ............................... 165
Displaying pictures ........................ 165
Exiting the picture viewer .............. 166
POI (navigation)
Category .......................................... 63
Defining the position for the POI
search .............................................. 62
Entering ........................................... 62
Selecting .......................................... 64
Previous destinations (navigation) .... 82
Q
Quick access for audio and telephone
Changing the audio source .............. 27
Changing the station/music
track ................................................ 26
Sending DTMF tones ........................ 27
R
Radio
Activating/deactivating the sta-
tion presets display ....................... 136
Deleting a station .......................... 137
Displaying information ................... 138
Displaying station information ....... 138
Displaying the artist and track ....... 138
Overview ........................................ 135
Setting the waveband .................... 136
Sound settings (balance, bass,
treble) ............................................ 138
Storing stations ............................. 137
Switching on .................................. 135
Tagging music tracks (downloading/purchasing tracks from the
iTunes Store
Radio station
Storing ........................................... 137
Read-aloud function
Automatic ........................................ 80
Read-aloud function for e-mails ....... 117
Reading out
Traffic reports on the route .............. 80
Real-time traffic reports ..................... 77
Rear Seat Entertainment System
Active COMAND source ................. 194
Adjusting sound settings ............... 186
Adjusting the brightness ................ 186
Adjusting the color ........................ 186
Adjusting the contrast ................... 186
AUX mode ...................................... 196
CD/DVD audio and MP3 mode ...... 187
Changing the batteries .................. 184
Changing the picture format .......... 187
Control menu ................................. 191
Cordless headphones .................... 183
DVD video mode ............................ 190
Multiple users ................................ 186
Operating with the headphones ..... 185
Picture settings .............................. 186
System settings ............................. 187
Using the main loudspeaker .......... 186
Rear view camera
Displaying the image ........................ 49
Opening the camera cover for
cleaning (COMAND) ......................... 49
Switching on/off (COMAND) ........... 49
Rear-compartment screens .............. 181
Receiving vCards ............................... 111
Redialing (telephone) .......................... 98
Remote control
Button lighting ............................... 182
Changing batteries ........................ 185
®
) ............................... 138
10
Index
Rear Seat Entertainment System ... 182
Reserve fuel level
Switching the function on/off in
COMAND ......................................... 56
Resetting (factory settings) ............... 43
Route (navigation)
Selecting an alternative route .......... 75
Setting route options (avoiding:
highways, toll roads, tunnels, fer-
ries) ................................................. 55
Setting the route type (short
route, fast route, dynamic route or
economic route) ............................... 55
Starting calculation .......................... 59
Route guidance
Continue .......................................... 75
Freeway information ........................ 73
General notes .................................. 71
Lane recommendations ................... 72
Off-road ........................................... 77
Traffic reports .................................. 77
S
Safety notes
Audio CD and MP3 mode ............... 145
Using the telephone ......................... 92
Satellite radio
Displaying information ................... 143
Overview ........................................ 140
Presets menu view ......................... 141
Registering .................................... 139
Switching to ................................... 139
SatRadio
Channel list updates ...................... 143
Memory functions .......................... 141
Music and sports alerts ................. 142
Notes ............................................. 138
Selecting a category ...................... 140
Selecting a channel ....................... 140
Tagging music tracks ..................... 142
Screen
Selecting for the remote control .... 182
SD card
Inserting ........................................ 149
Inserting/removing ........................ 149
Removing ....................................... 149
Seat cushion
Adjusting (COMAND) ....................... 47
Seats
Active multicontour seat
(COMAND) ....................................... 47
Adjusting the lumbar support
(COMAND) ....................................... 47
Balance (seat heating) ..................... 48
Massage function (COMAND) .......... 47
Massage programs (COMAND) ........ 47
Resetting settings ............................ 48
Seat functions (COMAND) ............... 47
Selecting for adjustment
(COMAND) ....................................... 47
Setting the driving dynamics
(COMAND) ....................................... 47
Selecting stations
Radio ............................................. 136
Sending DTMF tones ......................... 100
Setting access data
Online and Internet ........................ 127
Setting the audio format
Rear Seat Entertainment System ... 193
Setting the language
COMAND ......................................... 41
Rear Seat Entertainment System ... 193
Setting the night design ..................... 34
Setting the text reader speed ............ 37
Setting the volume
Telephone calls ................................ 27
Settings
Sound settings ............................... 167
Short message
see Text messages (SMS)
SIRIUS weather display
5-day forecast ................................ 173
Daily forecast ................................. 173
Detail information .......................... 174
Information
lecting a location for the
Se
weather forecast ............................ 174
Switching on/off ........................... 173
Weather map ................................. 176
SIRIUS weather map
Storm Guide .................................. 180
Storm Watch Box ........................... 180
Sound
Switching on/off .............................. 28
chart ........................... 173
Index
11
Sound settings
Balance/fader ...............................167
Calling up the sound menu ............ 167
Equalizer ........................................ 167
Speed dial
Deleting ......................................... 114
Setting up ...................................... 113
State/province
Selecting .......................................... 58
Station presets (radio)
Deleting marked stations ...............137
Stop function
Video DVD ..................................... 164
Storing stations
Radio ............................................. 137
Switching between summer time
and standard time ............................... 35
Switching on media mode
Using the Media button ................. 144
Via the device list .......................... 145
Via the main function bar ............... 144
Via the number keypad .................. 145
System settings
®
Bluetooth
....................................... 41
Date ................................................. 35
Importing/exporting data ................ 42
Language ......................................... 41
Text reader speed ............................ 37
Time ................................................. 35
Time zone ........................................ 35
Voice Control System ...................... 37
T
Telephone
Accepting a call (COMAND) ............. 98
Adding a call .................................... 99
Adjusting the volume for calls .......... 27
®
Apple CarPlay
.............................. 121
Authorizing a mobile phone (con-
necting) ............................................ 95
Call lists ......................................... 111
Call waiting .................................... 101
Calls with several participants ....... 100
Conference calls ............................ 100
Connecting a mobile phone (gen-
eral information) .............................. 93
De-authorizing (disconnecting) a
mobile phone ................................... 97
Deleting a speed dial preset .......... 114
Deleting messages ........................ 120
Dictation function for text mes-
sages and e-mails .......................... 120
®
Displaying Bluetooth
connection
details .............................................. 97
Downloading messages manually .. 116
E-mail ............................................. 114
E-mail requirements ....................... 114
E-mail settings ............................... 115
Ending an active call ...................... 101
Entering a number ........................... 98
Entering phone numbers .................. 98
Establishing the connection from
the mobile phone ............................. 96
Function restrictions ........................ 93
Functions available during a call ...... 99
General notes .................................. 92
Incoming call during an existing
call ................................................. 101
Making a call .................................... 98
Message conditions ....................... 114
Message settings ........................... 115
Operating options ............................ 92
Phone book .................................... 102
Reading messages ......................... 116
Reception and transmission vol-
ume ................................................. 97
Reconnecting a mobile phone
automatically ................................... 96
Rejecting a call (COMAND) .............. 98
Safety notes ..................................... 92
Sending DTMF tones ...................... 100
Setting up a speed dial .................. 113
Switching between calls (call wait-
ing) ................................................ 100
le
Switching between
mobi
phones ............................................. 96
Switching the microphone on/off..100
Telephone menu overview ...............93
Text message conditions ............... 114
Text message settings ...................115
Text messages (SMS) .................... 114
Toggling ......................................... 100
Using the telephone ......................... 98
Voice recognition ........................... 101
12
Index
Writing e-mails ...............................118
Writing text messages ................... 117
Telephone number
Entering ...........................................98
Text messages (SMS)
Calling the sender .......................... 119
Calling up the settings menu ......... 115
Configuring the text messages
displayed ....................................... 115
Deleting ......................................... 120
Displaying details ........................... 117
Downloading manually ................... 116
Editing text templates .................... 119
Inbox .............................................. 116
Reading .......................................... 116
Reading aloud ................................ 117
Settings ......................................... 115
Storing the sender as a new
address book entry ........................ 120
Using a phone number in the text .. 119
Using text templates ...................... 119
Writing ........................................... 117
Time
Setting the format ............................ 36
Setting the time manually ................ 36
Setting the time zone ....................... 35
Setting the time/date format .......... 36
Switching automatic time on/off ..... 35
Touchpad
Calling up quick access for audio
and telephone .................................. 23
Changing the audio source .............. 27
Changing the input language for
handwriting recognition ................... 26
Changing the station/music
track ................................................ 26
Character suggestions ..................... 25
Deleting characters ......................... 25
Entering a space .............................. 25
Entering characters ......................... 25
Gesture control ................................ 22
Handwriting recognition ................... 24
Operating the touchpad ................... 22
Overview .......................................... 22
Quick access for audio and tele-
phone .............................................. 26
Switching ......................................... 22
Switching input line ......................... 25
Track information .............................. 190
Traffic jam function ............................. 76
Traffic reports
Calling up a list ................................ 78
Real-time traffic report .................... 79
U
Updating the digital map .................... 88
USB audio mode
Selecting a track ............................ 150
USB devices
Connecting to the Media Inter-
face ............................................... 149
V
Vehicle
Data acquisition ............................... 15
Vehicle settings
Calling up ......................................... 45
Video
see Video DVD
Video DVD
Control option ................................ 161
DVD functions ............................... 164
DVD menu ..................................... 164
DVD's control menu ...................... 163
Function restrictions ...................... 162
Menu options ................................. 162
Notes on discs ............................... 161
Operation ....................................... 161
Overview ........................................ 162
Pause function ............................... 165
Picture settings .............................. 163
Playing conditions .......................... 161
Safety notes .................................. 161
Selecting a scene/chapter ............ 165
Stop function ................................. 164
Switching to ................................... 162
Video menu ................................... 163
Voice Control System
Settings ........................................... 37
Volume, adjusting
Navigation messages ....................... 27
W
Weather map (SIRIUS)
Activating/deactivating display
levels ............................................. 177
Calling up ....................................... 176
Legend ...........................................179
Moving ...........................................176
Showing/hiding the menu ............. 176
Time stamp ....................................179
Weather memory (SIRIUS)
Selecting an area ........................... 176
Storing an area .............................. 176
Web browser
Entering a web address ................. 130
WiFi
Activating (Canada) .......................... 38
Activating (USA) ............................... 38
Connecting a device via WPS PBC
(CANADA) ........................................ 40
Connecting a device via WPS PBC
(USA) ............................................... 39
Connecting a device via WPS PIN
(CANADA) ........................................ 39
Connecting a device via WPS PIN
(USA) ............................................... 39
Connecting the device ..................... 38
Overview .......................................... 37
Selecting a hotspot .......................... 38
Index
13
Introduction
14
Operating safety
Important safety notes
WARNING
G
If you operate information systems and communication equipment integrated in the vehicle while driving, you will be distracted from
traffic conditions. You could also lose control
of the vehicle. There is a risk of an accident.
Only operate the equipment when the traffic
situation permits. If you are not sure that this
is possible, park the vehicle paying attention
to traffic conditions and operate the equipment when the vehicle is stationary.
You must observe the legal requirements for the
country in which you are currently driving when
operating the multimedia system.
The multimedia system calculates the route to
the destination without taking account of the
following, for example:
R
traffic lights
R
stop and yield signs
R
merging lanes
R
parking or stopping in a no parking/no stopping zone
R
other road and traffic rules and regulations
R
narrow bridges
The multimedia system can give incorrect navigation commands if the actual street/traffic situation does not correspond with the digital
map's data. Digital maps do not cover all areas
nor all routes in an area. For example, a route
may have been diverted or the direction of a oneway street may have changed.
For this reason, you must always observe road
and traffic rules and regulations during your
journey. Road and traffic rules and regulations
always have priority over the system's driving
recommendations.
Navigation announcements are intended to
direct you while driving without diverting your
attention from the road and driving.
Please always use this feature instead of consulting the map display for directions. Looking
at the icons or map display can distract you from
traffic conditions and driving, and increase the
risk of an accident.
Bear in mind that at a speed of only 30 mph
(approximately 50 km/h), your vehicle covers a
distance of 44 feet (approximately 14 m) every
second.
This equipment complies with FCC radiation
exposure limits set forth for uncontrolled equipment and meet
s the FCC radio frequency (RF)
Exposure Guidelines in Supplement C to OET65.
This equipment has very low levels of RF energy
that is deemed to comply without maximum
permissive exposure evaluation (MPE). However, it is recommended to install it at a distance
of at least 8 inches (approx. 20 cm) between the
radiation source and a person's body (not
including limbs such as hands, wrists, feet and
legs).
WARNING
G
Modifications to electronic components, their
software as well as wiring can impair their
function and/or the function of other networked components. In particular, systems
relevant to safety could also be affected. As a
result, these may no longer function as intended and/or jeopardize the operating safety of
the vehicle. There is an increased risk of an
accident and injury.
Never tamper with the wiring as well as electronic components or their software. You
should have all work to electrical and electronic equipment carried out at a qualified
specialist workshop.
If you make any changes to the vehicle electronics, the general operating permit is rendered invalid.
Declarations of conformity
Vehicle components which receive
and/or transmit radio waves
USA only: The wireless devices of this vehicle
comply with Part 15 of the FCC Rules. Operation
is subject to the following two conditions:
1) These devices may not cause interference,
and
2) These devices must accept any interference,
including interference that may cause undesired
operation of the device.
Introduction
15
Changes or modifications not expressly
approved by the party responsible for compliance could void the user's authority to operate
the equipment.
Canada only: The wireless devices of this vehicle comply with Industry Canada licenseexempt RSS standard(s). Operation is subject to
the following two conditions:
1) These devices may not cause interference,
and
2) These devices must accept any interference,
including interference that may cause undesired
operation of the device.
Correct use
You need to observe the following information
when using the multimedia system:
R
the safety notes in this manual
R
traffic rules and regulations
R
laws and safety standards pertaining to motor
vehicles
Using roof carriers may impair the correct functioning of a roof antenna (phone, satellite radio,
GPS).
Attaching metalized retrofit film to the windshield may affect radio reception. This can have
a negative impact on all other antennas (e.g.
emergency call antenna) in the vehicle interior.
Protection against theft: this device is equipped with technical provisions to protect it
against theft. Further information on protection
against theft can be obtained from an authorized Mercedes-Benz Center.
Qualified specialist workshop
Read the information on qualified specialist
workshops in the vehicle Operator's Manual.
Function restrictions
For safety reasons, some functions are restricted or unavailable while the vehicle is in motion.
You will notice this, for example, because either
you will not be able to select certain menu items
or a message will appear to this effect.
Data stored in the vehicle
Data recording
A wide range of electronic components in your
vehicle contain data memories.
These data memories temporarily or permanently store technical information about:
R
the vehicle's operating state
R
events
R
malfunctions
In general, this technical information documents the state of a component, a module, a
system or the surroundings.
These include, for example:
R
operating conditions of system components,
e.g. fluid levels
R
the vehicle's status messages and those of its
individual components, e.g. number of wheel
revolutions/speed, deceleration in movement, lateral acceleration, accelerator pedal
position
R
malfunctions and defects in important system
components, e.g. lights, brakes
R
vehicle reactions and operating conditions in
special driving situations, e.g. air bag deployment, intervention of stability control systems
R
ambient conditions, e.g. outside temperature
This data is of an exclusively technical nature
and can be used to:
R
assist in detecting and rectifying faults and
defects
R
analyze vehicle functions, e.g. after an accident
R
optimize vehicle function
The data cannot be used to trace the vehicle's
movements.
When your vehicle is serviced, technical information can be
and fault data memory.
Services include, for example:
R
repair services
R
service processes
R
warranty events
R
quality assurance
The vehicle is read out by employees of the service network (including the manufacturer) using
special diagnostic testers. You can obtain more
information there, if required.
rom the event data memory
read f
Z
Introduction
16
After a malfunction has been rectified, the information is deleted from the malfunction memory
or is continually overwritten.
When operating the vehicle, situations are conceivable in which this technical data, in connection with other information (if necessary, after
consultation with an authorized expert), could
be traced to a person.
Examples include:
R
accident reports
R
damage to the vehicle
R
witness statements
Further additional functions that have been contractually agreed upon with the customer allow
certain vehicle data to be conveyed by the vehicle as well. The additional functions include, for
example, vehicle location in case of an emergency.
COMAND/mbrace
If the vehicle is equipped with COMAND or
mbrace, additional data about the vehicle’s
operation, the use of the vehicle in certain situations, and the location of the vehicle may be
compiled through COMAND or the mbrace system.
For additional information please refer to the
COMAND User Manual and/or the mbrace
Terms and Conditions.
Event data recorders
This vehicle is equipped with an event data
recorder (EDR). The main purpose of an EDR is
to record data that will assist in understanding
how a vehicle’s systems performed in certain
crash or near crash-like situations, such as during air bag deployment or when hitting a road
obstacle. The EDR is designed to record data
related to vehicle dynamics and safety systems
for a short period of time, typically 30 seconds
or less.
The EDR in this vehicle is designed to record
such data as:
R
how various systems in your vehicle are operating
R
whether or not the driver and passenger seat
belts are fastened
R
how far (if at all) the driver is depressing the
accelerator and/or brake pedal and
R
how fast the vehicle is traveling
This data can help provide a better understanding of the circumstances in which crashes and
injuries occur. NOTE: EDR data is recorded by
your vehicle only if a non-trivial crash situation
occurs; no data is recorded by the EDR under
normal driving conditions and no personal data
(e.g., name, gender, age, and crash location) are
recorded. However, other parties, such as law
enforcement, can combine the EDR data wi
the ty
pe of personal identification data routinely
th
acquired during a crash investigation.
To read data recorded by an EDR, special equip-
ment is required, and access to the vehicle or
the EDR is needed. In addition to the vehicle
manufacturer, other parties that have the special equipment, such as law enforcement, can
read the information by accessing the vehicle or
the EDR.
EDR data may be used in civil and criminal matters as a tool in accident reconstruction, accident claims, and vehicle safety. Since the Crash
Data Retrieval CDR tool that is used to extract
data from the EDR is commercially available,
Mercedes-Benz USA, LLC ("MBUSA") expressly
disclaims any and all liability arising from the
extraction of this information by unauthorized
Mercedes-Benz personnel.
MBUSA will not share EDR data with others
without the consent of the vehicle owners or, if
the vehicle is leased, without the consent of the
lessee. Exceptions to this representation
include responses to subpoenas by law enforcement; by federal, state or local government; in
connection with or arising out of litigation involving MBUSA or its subsidiaries and affiliates; or,
as required by law.
Warning: The EDR is a component
of the Su
pplemental Restraint System ("SRS") Module.
Tampering with, altering, modifying or removing
the EDR component may result in a malfunction
of the SRS Module and other systems.
State laws or regulations regarding EDRs that
conflict with federal regulation are pre-empted.
This means that in the event of such conflict, the
federal regulation governs. As of February 2013,
13 states have enacted laws relating to EDRs.
Information on copyright
Information on licenses for free and Open
Source software used in your vehicle and in the
electronic components can be found on this
website: http://www.mercedes-benz.com/
opensource.
Your multimedia system equipment
These operating instructions describe all the
standard and optional equipment of your multimedia system, as available at the time of going
to press. Country-specific differences are possible. Bear in mind that your vehicle may not
feature all functions described here. This also
applies to safety-relevant systems and functions.
Read the information on qualified specialist
workshops in the vehicle Operator's Manual.
Introduction
17
Z
Overview
18
Overview
Components
Overview and operation
:
Display (Y page 19)
;
Control panel (Y page 20)
=
Controller and buttons (Y page 21)
The multimedia system consists of:
R
the display
R
the control panel with a single drive or DVD changer
R
the controller and buttons
R
the touchpad
R
two connection options for USB devices or via Media Interface in the center console
®
An iPod
is connected via a USB cable.
Functions
R
HD FM radio and HD AM radio/satellite
radio
R
Media
-
Media support: audio CD, MP3 CD, DVD
video, two connection options for USB or
via Media Interface, SD card, Bluetooth
audio
®
An iPod
directly to the USB via the integrated Media
Interface.
-
Media search
R
Sound system
, for example, can be connected
You can select from two sound systems:
-
harman/kardon®Logic7®surround sound
system
-
Bang & Olufsen BeoSound AMG sound system
R
Navigation system
-
®
Navigation via the hard drive
-
Destination entry, for example using keyword search
-
Realistic 3D map with textured city models
-
Personal POIs and routes using SD memory
card
-
Navigation functions, e.g. compass display
-
Dynamic route guidance with traffic reports
via SIRIUS satellite radio
R
Communication
-
Messaging functions (text messages, email)
-
Address book
-
Internet browser
-
Mercedes-Benz Apps with Google™ Local
Search, destination and route download,
Facebook, Google Street View™, stock prices, news and much more
-
Mercedes-Benz Mobile Website
-
WiFi interface for the connection of a
smartphone to the multimedia system
-
WiFi hotspot functionality to connect a tablet PC or laptop in order to enable access to
the Internet using the customer's mobile
phone
R
SIRIUS Weather
-
Weather data as an information chart (current forecast, 5-day preview, detailed information)
-
Weather data on the weather map, e.g. rain
radar data, storm characteristics and the
track of tropical cyclones (hurricanes, tornadoes)
R
Vehicle functions
-
Vehicle settings, e.g. fuel consumption
-
Ionization
-
360° camera
-
Rear view camera
-
Seat functions
-
DYNAMIC SELECT (individual drive program)
-
Driving dynamics display in the multimedia
system for vehicles with the Off-Road Engineering package (see the vehicle Operator's Manual)
R
Favorites button
-
Fast access to favorites functions using the
favorites button on the controller
Display
General notes
Do not use the space in front of the display
!
for storage. Objects placed here could damage the display or impair its function. Avoid
any direct contact with the display surface.
Pressure on the display surface may result in
Overview
impairments to the display, which could be
irreversible.
Wearing polarized sunglasses may impair your
ability to read the display.
The display has an automatic temperature-controlled switch-off feature. The brightness is
automatically reduced if the temperature is too
high. The display may then temporarily switch
off completely.
Overview
In the status bar at the top you will see the time
and other displays, depending on the settings.
Below it you will see the main display field.
The climate control status display is briefly dis-
played when you operate the climate control
system.
The example shows media playback in SD memory card mode.
Cleaning instructions
Do not touch the display. The display has a
!
very sensitive high-gloss surface; there is a
risk of scratching. If you have to clean the
screen, however, use a mild cleaning agent
and a soft, lint-free cloth.
The display must be switched off and have
cooled down before you start cleaning. Clean
the display screen, when necessary, with a commercially available microfiber cloth and cleaning
agent for TFT and LCD displays. Do not apply
pressure to the display surface when cleaning it,
as this could cause irreversible damage to the
display. Then, dry the surface with a dry microfiber cloth.
Avoid using alcoholic thinners, gasoline or abrasive cleaning agents. These could damage the
display surface.
19
Overview and operation
Overview
20
Control panel
Overview and operation
Function Page
:
Switches to radio mode 135
Calls up the Radio menu 136
;
Switches to the last selected
media mode
Calls up the Media menu 144
=
Inserts/removes a CD/DVD
into/from the single drive
Inserts a CD/DVD into the
DVD changer
Removes a CD/DVD from
the DVD changer
?
Selects the previous station
from the station list
Skips backwards to a track 150
Rewinds 150
A
Inserts/removes a CD/DVD
8 Single drive
V DVD changer
B
Clear button 21
• Deletes characters
• Deletes an entry
C
Selects the next station from
the station list
Skips forwards to a track 150
Fast forward 150
144
147
148
148
136
147
148
136
Function Page
D
Number pad
• Saves a station 137
• Authorizes (connects) a
mobile phone
• Telephone number entry 98
• Searches for a contact 102
• Character entry 30
z Displays the current
track being played (if the data
medium supports track information)
g Selects stations by
entering the frequency manually
g Selects a track
E
Switches the multimedia system on/off
Adjusts the volume 27
F
Inserts/removes the SD card 149
G
Accepts a call 98
Makes a call 98
Redial 98
Accepts a new call when a
call is being made (call waiting)
H
Rejects a call 98
Ends an active call 101
95
145
136
150
27
101
Overview
21
Function Page
I
Switches the mute function
on/off
28
Switches off navigation
announcements
J
Switches to navigation mode 54
28
Calls up the navigation system menu
89
Buttons and controller
Overview
:
Clear button
;
Switches off the display
=
Favorites button
?
Back button
A
Controller
The controller may be equipped as a 4-button
controller as follows:
R
with the T button instead of button ; for
the seat settings
R
with a further favorites button instead of button ;
The controller may be equipped as a 2-button
controller as follows:
R
with buttons : and ?
R
with the favorites button, button ? plus a
touchpad instead of button :
(
Y page 22)
R
with the favorites button and button ?
instead of button :
For Mercedes-AMG vehicles: the controller is
equipped with buttons : and ?.
Function Page
K
Calls up the telephone menu 93
L
Calls up vehicle settings 45
Controller
The controller in the center console lets you:
R
select menu items on the display
R
enter characters
R
select a destination on the map
R
save entries
The controller can be:
R
turned 3
R
slid left or right 1
R
slid forwards or back 4
R
slid diagonally 2
R
pressed briefly or pressed and held 7
Back button
You can use the % button to exit a menu or to
call up the basic display of the current operating
mode.
X
To exit the menu: briefly press the %
button.
The multimedia system changes to the next
higher menu level in the current operating
mode.
X
To call up the basic display: press the %
button for longer than two seconds.
The multimedia system changes to the basic
display of the current operating mode.
Clear button
The delete button is on the control panel and on
the controller.
X
To delete individual characters: briefly
press the $ button on the control panel.
or
X
Briefly press the j clear button on the
controller.
Overview and operation
22
Touchpad
X
To delete an entire entry: press and hold the
$ button on the control panel.
or
X
Press and hold the j clear button on the
controller.
Favorites button
You can assign predefined functions using the
g favorites button and call them up by pressing the button (
Y page 41).
Display off button
You can switch off the display using the
button.
Overview and operation
Seat button
If the controller is equipped with the T button, you can call up the menu for the seat set-
Y page 47).
tings (
Touchpad
Touchpad overview
Do not use any sharp objects on the touch-
!
pad. This could damage the touchpad.
R
control the active audio source (Y page 26).
R
create, manage and call up favorites
Y page 31).
(
R
enter destinations in navigation
R
save entries
Further information on operating the touchpad
Y page 22).
(
Do not press your fingers too hard on the touch-
pad. This could cause malfunctions.
Switching the touchpad on/off
X
Press the Ø button.
The vehicle menu is displayed.
X
To select System Settings: slide 6, turn
and press the controller.
A menu appears.
X
Select Touchpad if the touchpad is equipped
with handwriting recognition.
X
Select Activate Touchpad.
The touchpad is switched on O or off ª.
Operating the touchpad
Selecting a menu item
:
Touch-sensitive surface
;
Favorites button
=
Calls up quick access for audio and telephone
?
Back button
Using the touchpad, you can:
R
select menu items in the display
Y page 22).
(
R
enter characters (handwriting recognition)
Y page 24).
(
X
Use one finger to touch the touch-sensitive
surface.
X
Swipe your finger up, down, to the left or right.
The selection in the display moves in accordance with the direction of movement.
You can navigate in lists or menus in this way.
Confirming a selection
X
Use one finger to press the touch-sensitive
surface until you reach the pressure point.
A menu, an option or an application is started.
Calling up quick access for audio and
telephone
Touchpad
X
Use two fingers to touch the touch-sensitive
surface.
X
Swipe your fingers down.
Quick access is hidden.
Operating the control for vehicle and
sound settings
X
Touch the touch-sensitive surface with two
fingers, spaced slightly apart.
X
Turn both fingers clockwise.
The control setting is increased.
or
X
Turn both fingers counter-clockwise.
The control setting is decreased.
23
Overview and operation
X
Use two fingers to touch the lower part of the
touch-sensitive surface.
X
Swipe your fingers up.
Quick access is displayed.
Further information on quick access for audio
and telephone (
Y page 26).
Hiding the quick access for audio and
telephone
Moving the map
X
Use one finger to press the touch-sensitive
surface until you reach the pressure point.
The crosshair is shown.
Touchpad
24
X
Touch the touch-sensitive surface again with
one finger.
X
Swipe your finger in any direction.
The map is moved is the direction of movement.
Overview and operation
Zooming in on the map
X
Touch the touch-sensitive surface with two
fingers, spaced slightly apart.
X
Glide your fingers away from each other.
The map scale is magnified.
Zooming out of the map
X
Touch the touch-sensitive surface with two
fingers, spaced far apart.
X
Glide your fingers towards each other.
The map scale is reduced.
Handwriting recognition
Handwriting recognition overview
This function is only available if the touchpad is
equipped with handwriting recognition.
You can use handwriting recognition for text,
numbers or characters in any input line.
:
Active input line
;
Inserts a space (Y page 25)
=
Illustration of the touch-sensitive surface
?
Deletes characters (Y page 25)
If the character that you have entered can be
interpreted in different ways, these options are
displayed. More information on the character
suggestions (
You can also switch the text reader function of
the handwriting recognition on and off
Y page 25).
(
Y page 25).
:
To exit the menu
;
To return to handwriting recognition
=
To use the phone book or text templates
Touchpad
25
?
To change the input line or the position of
the cursor
A
To change the input language
B
To finish character entry
X
To display the menu: press the touchpad.
Switching the text reader function of
the handwriting recognition on/off
You can switch the text reader function of the
handwriting recognition on or off.
X
Press the Ø button.
The vehicle menu is displayed.
X
To select System Settings: slide 6, turn
and press the controller.
A menu appears.
X
To select Touchpad: turn and press the controller.
X
Select Read Out Handwriting Recogni‐
tion.
The text reader function is switched on O or
off ª.
Entering characters
Prerequisite: an input line for text, numbers or
characters has been selected.
X
Use one finger to draw the desired character
on the touch-sensitive surface.
The character recognized is entered in the
input line. You can draw the next character on
the touch-sensitive surface.
If the character can be interpreted in different
ways, these options are displayed.
More information on the character suggestions
Y page 25).
(
Character suggestions
:
Character recognized
;
Character suggestions
X
To select a character suggestion: turn the
controller.
The selected character is entered instead of
the automatically recognized character. Character entry can be continued.
Inserting a space
Prerequisite: an input line for text, numbers or
characters has been selected.
X
Use your finger to touch the touch-sensitive
surface and swipe to the right.
A space is entered into the input line.
Deleting characters
Prerequisite: an input line for text, numbers or
characters has been selected.
X
Use your finger to touch the touch-sensitive
surface and swipe to the left.
The character last entered is deleted.
Switching input lines
Overview and operation
Touchpad
26
X
Press the touchpad.
A symbol is shown.
X
To select p: glide your finger to the left or
right and press.
X
To select the input line: swipe up or down and
press.
The selected input line is active and character
entry can be continued.
Moving the cursor within the input line
Overview and operation
Further information on handwriting recognition on the touchpad (
X
Draw additional letters on the touchpad sur-
Y page 24).
face one after another.
To complete the search and return to the
X
phone book: press the touchpad.
Selecting the touchpad or controller for
character entry
Prerequisite: an input line for text, numbers or
characters has been selected.
To switch to character entry on the touch-
X
pad: press the touchpad with your finger.
Handwriting recognition on the touchpad is
active.
To switch to character entry with the con-
X
troller: press the controller.
Character entry with the controller is active.
X
Press the touchpad.
A symbol is shown.
X
To select p: glide your finger to the left or
right and press.
X
To move the cursor: glide to the left or right.
Changing the input language for handwriting recognition
Prerequisite: an input line for text, numbers or
characters has been selected.
X
Press the touchpad.
A symbol is shown.
X
To select B: swipe your finger to the left or
right and press.
The list of available input languages appears.
X
To select a language: swipe up or down and
press.
The input language for handwriting recognition has been changed.
Searching in lists
The phone book search is used as an example.
You determine the first letter of the contact you
are looking for with the first character you enter.
X
Draw the letter on the touchpad surface.
The first contact with the selected first character is highlighted in the phone book.
Quick access for audio and telephone
Changing the station/music track
Depending on the audio source that is currently
activated, you can use this function to select the
next station or music track.
X
Call up quick access (Y page 23).
The current audio source is displayed.
X
To select the previous or next station or music
track: swipe to the left or right.
The selected station or music track is played.
Basic functions
27
Changing the audio source
X
Call up quick access (Y page 23).
The current audio source is displayed.
To display the available audio sources:
X
swipe upwards with one finger.
X
To select an audio source: glide your finger
to the left or right and press.
The selected audio source is played.
Sending DTMF tones
The function is not supported by all mobile
phones (see the manufacturer's operating
instructions).
X
Call up quick access during a call (Y page 23).
X
To select characters: glide your finger to the
left or right and press.
Every character selected will be transmitted
immediately.
Basic functions
Switching the multimedia system on/
off
X
Press the q control knob.
When you switch the multimedia system on, a
warning message will appear. The multimedia
system calls up the previously selected menu.
If you switch the multimedia system off, playback of the current media source will also be
switched off.
Adjusting the volume
Adjusting the volume for media sources
X
Turn the q control knob.
or
X
Press the W or X button on the multifunction steering wheel.
The volume of the media source currently
selected changes.
Adjusting the volume for traffic
announcements and navigation
announcements
During traffic or navigation announcements:
X
Turn the q control knob.
or
X
Press the W or X button on the multifunction steering wheel.
You can set the volume for navigation
i
announcements to be different from the volume of the respective media source.
Adjusting the volume for phone calls
You can adjust the volume for hands-free mode
during a telephone call.
X
Turn the q control knob.
or
X
Press the W or X button on the multifunction steering wheel.
Overview and operation
Setting the volume for the Voice Control
i
System voice output; see the separate operating instructions.
Basic functions
28
Switching the sound on or off
Media source sound
X
Press the 8 button on the control panel or
on the multifunction steering wheel.
The sound is switched off. If the audio output
is switched off, the status line will show the
8 symbol. If you switch the media source
or change the volume, the sound is automatically switched on.
Even if the sound is switched off, you will still
i
hear navigation system announcements.
Switching navigation announcements
off and on again
Overview and operation
To switch navigation announcements off:
X
press the 8 button during an announcement.
The Spoken driving recommendations
have been deactivated. message
appears.
To switch navigation announcements on
X
again: switch the multimedia system off and
then on again (
Y page 27).
or
X
Start a new route calculation (Y page 59).
or
X
Select +: while route guidance is active,
show the menu and press the controller
Y page 74).
(
Function menu
X
Press the Õ button or the ß, $,
%, or Ø button.
Navigation: the map displays the current
vehicle position.
Radio: the basic menu of the last radio mode
set appears.
Media: the basic display for the last media
source set appears. In the example, Media
Interface mode is set.
Telephone/Internet: the basic menu of the
last communication function set appears
(telephone, address book, Internet).
Vehicle: the basic display appears.
X
To show the menu: slide 4 the controller.
The menu for the selected functions appears.
Depending on the operation, the marking is
shown:
R
in the main function bar at the top or
R
in the menu bar at the bottom
X
To select a menu item: turn and press the
controller.
If you have selected a menu item from the
main function bar, switch to the last menu set
for the selected function.
The menu bar features options within the currently set function.
Selecting the operating mode for a
main function
For the main functions, e.g. communication or
media, you can choose from the available operating modes.
In the communication menu, you can:
R
switch to telephone mode
R
call up the address book
R
access the Internet
R
call up the digital operating instructions for
®
Tel/
X
Press the % button.
The phone menu appears.
X
To call up the menu: press the % button
again.
or
X
To select Tel/®: slide 5 and press the
controller.
The communication menu appears. Phone
at the front.
X
To select a menu option: turn and press the
controller.
is
Character entry (telephony)
Entering characters using the character bar
In the example, a new entry is added to the
phone book (
three input lines for entering the last name, first
name and phone number. The input line for the
surname is selected automatically.
Entering characters
X
Turn and press the controller.
The character selected in character bar ; is
entered into surname input line :.
X
Enter the complete last name.
Deleting individual characters
X
To switch to the bottom line of the character
bar: slide 6 the controller.
X
To select F: turn and press the controller.
The character last entered is deleted.
Deleting an entire entry
X
To switch to the bottom line of the character
bar: slide 6 the controller.
X
To select F: turn and hold the controller until
the entire entry has been deleted.
Switching input lines
X
To switch to the bottom line of the character
bar: slide 6 the controller.
X
To select 5: turn and press the controller.
The input line for the first name is selected.
You can enter the characters for the first
name.
Y page 103). The new entry has
Character entry (telephony)
When the telephone number input line is selected, the character bar is adapted for entering
digits.
Entering characters
X
Turn and press the controller.
The character selected in character bar ? is
entered into telephone number input line =.
Finishing an entry and saving a contact
X
To switch to the bottom line of the character
bar: slide 6 the controller.
X
To select ¬: turn and press the controller.
Further functions available in the character
bar
Symbol Function
Ä
*
B
4, 5 Selects the input line
2, 3 Moves the cursor within the input
b
%
S
Switches the character bar for
entering characters, digits and
symbols
Switches the character bar to
upper-case or lower-case letters
Changes the country setting for
the character bar
F
Deletes a character or an entry
line
Confirms an entry
Cancels input
Inserts a line break (when writing
text messages)
29
Overview and operation
Character entry (navigation)
30
Entering characters using the number
keypad
If an input line for text or numbers is selected,
the number keypad is used for the character
entry.
X
For example, to enter the letter c: press the
l number key briefly three times in succession.
An additional display area is shown with all
the available characters. Press the key
repeatedly to go through the characters until
is highlighted.
c
X
Wait until the character display goes out.
The letter c
is entered in the input line.
Overview and operation
Character entry (navigation)
Entering characters using the character bar
:
Characters NEW (orange color) entered by
the user
;
Characters automatically added by the multimedia system YORK
=
Characters not currently available
?
Currently selected character
A
Characters currently available
B
Character bar
The example shows the address entry
Y page 58).
(
X
To enter a character: turn, slide 6 or 5
and press the controller.
Selected character : is entered in the upper
line. The multimedia system adds the missing
characters and shows the entry that best
matches the current input.
The characters are available A or not =,
depending on the characters already entered
and the data stored in the digital map.
The G symbol indicates that an entry exists
more than once.
X
To delete a character: slide 6 and turn the
controller, then press it after selecting F.
X
To delete an entire entry: slide 6 and turn
the controller; then after selecting F press
and hold down the controller until the entire
entry is deleted.
X
To confirm an entry: slide 6 and turn the
controller, then press it after selecting¬.
or
X
Slide 5 the controller repeatedly until the
character bar disappears.
The location selection list appears. The selected entry is highlighted.
The example shows the character entry when
you save a destination as a navigable contact in
the address book (
Y page 59). The cursor is
located in the input line.
X
To select an input line: slide 6 and turn
the controller, then press it after selecting 4
or 5.
or
X
Slide 5 the controller repeatedly until the
character bar disappears.
X
To move the cursor: select the input line.
X
Turn and press the controller.
or
X
Slide 6 and turn the controller, then press it
after selecting 2 or 3.
To change the character bar language:
X
slide 6 and turn the controller, then press it
after selecting B.
A menu appears.
X
Turn and press the controller.
The character set for the selected language is
set.
The character bar entry functions are listed in
the table.
Symbol Function
Ä
Switches between digits and symbols
*
Switches the character bar from
uppercase to lowercase letters
B
Changes the character bar language
F
è
Deletes a character or an entry
Switches to keyword search
Y page 60)
(
4, 5 Selects the input line
2, 3 Moves the cursor within the input
line
¬
&
Confirms an entry
Cancels input
Entering characters using the number
keypad
X
Press one of the number keypad buttons, e.g.
l, once or repeatedly in quick succession.
The character appears at the bottom of the
display when the key is pressed. The first
available letter is highlighted.
Favorites
You see which characters you can enter with
that key. Each time the key is pressed, the
next character is selected.
X
Wait until the character display goes out.
The entries matching your input are shown in
the list.
Favorites
Overview of favorites
:
Assigns new favorites (Y page 32)
;
Renames a selected favorite (Y page 32)
=
Moves a selected favorite (Y page 32)
?
Deletes a selected favorite (Y page 32)
X
To display the favorites overview: press
the favorites button on the controller.
The favorites are displayed.
X
To show the menu bar: slide 6 the con-
troller.
You can manage a total of 20 favorites.
Further information on how to select and display
a favorite (
Displaying and selecting favorites
X
Press the favorites button on the controller.
The favorites are displayed.
X
To call up a favorite: turn and press the controller.
Y page 31).
31
Overview and operation
32
Favorites
Adding favorites
Adding predefined favorites
X
Press the favorites button on the controller.
The favorites are displayed.
X
To show the menu bar: slide 6 the con-
troller.
X
To select Reassign: turn and press the controller.
The categories for the available favorites are
displayed.
X
To select a category: turn the controller and
press to confirm.
The corresponding favorites are displayed.
X
To select a favorite: turn and press the con-
Overview and operation
troller.
To add a favorite at the desired position:
X
turn and press the controller.
If there is already a favorite at this position,
then this will be deleted.
Adding your own favorites
You can create your own favorites to help you to
use these functions, for example:
R
Calling up telephone numbers from the telephone book
R
Selecting radio stations
R
Skipping to a specific place in a track or an
audio book
R
Calling up favored media
R
Selecting navigation destinations for route
calculation
The example describes how to add a contact's
telephone number as a favorite.
X
Call up the phone book (Y page 102).
X
Select the contact.
To add a telephone number as a favorite
X
at the desired position: press and hold the
favorites button on the controller until the
favorites are displayed.
X
Turn and press the controller.
If there is already a favorite at this position, it
will be deleted and replaced by a new one.
Renaming favorites
X
Press the favorites button on the controller.
The favorites are displayed.
X
To select a favorite to be renamed: turn the
controller.
X
To show the menu bar: slide 6 the con-
troller.
X
To select Rename: turn and press the controller.
X
Enter characters using the controller.
X
To finish the entry: select OK.
The favorite is renamed.
Moving favorites
X
Press the favorites button on the controller.
The favorites are displayed.
X
To select a favorite to be moved: turn the
controller.
X
To show the menu bar: slide 6 the con-
troller.
X
To select Move: turn and press the controller.
To store a favorite in the desired order:
X
turn and press the controller.
The favorite is moved.
If one favorite is stored over another one, this
is then is deleted.
Deleting favorites
X
Press the favorites button on the controller.
The favorites are displayed.
X
To select a favorite to be deleted: turn the
controller.
X
To show the menu bar: slide 6 the con-
troller.
X
To select Delete: turn and press the controller.
X
To select Yes or No: turn and press the controller.
If you select Yes
cancels the procedure.
the favorite is deleted. No
Favorites
33
Overview and operation
Display settings
34
Your multimedia system equipment
These operating instructions describe all the
standard and optional equipment of your multimedia system, as available at the time of going
to press. Country-specific differences are possible. Bear in mind that your vehicle may not
feature all functions described here. This also
applies to safety-relevant systems and functions.
Read the information on qualified specialist
workshops in the vehicle Operator's Manual.
System settings
Important safety notes
WARNING
G
If you operate mobile communication equipment while driving, you will be distracted from
traffic conditions. You could also lose control
of the vehicle. There is a risk of an accident.
Only operate this equipment when the vehicle
is stationary.
WARNING
G
SD cards are small parts. They can be swallowed and cause choking. This poses an
increased risk of injury or even fatal injury.
Keep the SD card out of the reach of children.
If a SD card is swallowed, seek medical attention immediately.
You must observe the legal requirements for the
country in which you are currently driving when
operating mobile communications equipment in
the vehicle.
Display settings
Setting the brightness
The brightness detected by the display light sensor affects the setting options for this function.
X
Press the Ø button.
or
X
Press Vehicle in the main function bar.
The vehicle menu is displayed.
X
To select System Settings: slide 6, turn
and press the controller.
A menu appears.
X
To select Display: turn and press the controller.
A menu appears.
X
Select Brightness.
A control appears.
X
To select the desired brightness: turn and
press the controller.
Display design
The display features optimized designs for daytime and night-time operation. You can set the
design by manually selecting day or night design
or opt for an automatic setting.
X
Press the Ø button.
or
X
Press Vehicle in the main function bar.
The vehicle menu is displayed.
X
To select System Settings: slide 6, turn
and press the controller.
A menu appears.
X
To select Display: turn and press the controller.
A menu appears.
X
To select Day Mode, Night Mode or Auto:
turn and press the controller.
The # dot indicates the current setting.
Design Explanation
Day Mode
The display is set permanently to day design.
Night Mode
The display is set permanently to night design.
Auto In the Auto setting, the
multimedia system evaluates the readings from the
automatic vehicle light
sensor and automatically
switches the display
design.
Switching the display on/off
X
Press the Ø button.
X
To select Display Off: slide 6, turn and
press the controller.
The display goes out.
X
To switch the display on again: press the
controller.
Time settings
General information
The multimedia system can automatically set
the time and date.
The following navigation system functions
require the time, time zone and summer/standard time to be set correctly in order to work
properly:
R
route guidance on routes with time-dependent traffic guidance
R
calculation of expected time of arrival
Switching automatic time on and off
The Automatic Time Settings function is
used to activate or deactivate the automatic
setting of the time and date. This function is
activated when the vehicle leaves the factory.
X
Press the Ø button.
or
X
Press Vehicle in the main function bar.
The vehicle menu is displayed.
Time settings
X
To select Time: slide 6, turn and press the
controller.
A menu appears.
X
To select Automatic Time Settings: press
the controller.
X
To activate O or deactivate ª the function:
press the controller.
Setting the time zone
To set the time zone, the Automatic Time
Settings function must be activated.
X
Press the Ø button.
or
X
Press Vehicle in the main function bar.
The vehicle menu is displayed.
X
To select Time: slide 6, turn and press the
controller.
A menu appears.
X
To select Time Zone:: turn and press the
controller.
A list of countries appears. The # dot indicates the current setting.
X
Select the country you are currently in by
turning and pressing the controller.
The country is accepted.
A time zone list may also be displayed,
depending on the country selected.
X
To select the desired time zone: turn and
press the controller.
The time zone is accepted.
A list of available options for setting summer
time appears (
Setting summer and standard time
The Daylight Saving Time menu is not available in all countries.
You can use the Daylight
to set automatic summer time changeover or
switch the summer time setting on or off. The
changeover to summer time advances the time
by one hour.
X
Press the Ø button.
or
X
Press Vehicle in the main function bar.
The vehicle menu is displayed.
Y page 35).
Saving Time menu
35
System settings
Z
Time settings
36
X
To select Time: slide 6, turn and press the
controller.
A menu appears.
X
To select Daylight Saving Time: turn and
press the controller.
A list with options appears.
X
To select Automatic, On or Off: turn and
press the controller.
Setting Function
Automatic
The summer and
standard time are
automatically
System settings
On
changed over.
The clock is advanced
one hour ahead of
standard time.
Off
The standard time for
the chosen time zone
is selected.
Manual time setting
Using the manual time settings, you can set
i
the time forwards or backwards by up to several hours.
X
Press the Ø button.
or
X
Press Vehicle in the main function bar.
The vehicle menu is displayed.
X
To select Time: slide 6, turn and press the
controller.
A menu appears.
X
To select Set Time Manually: turn and
press the controller.
A menu with an analog clock appears.
X
To set the hour: turn the controller.
X
To highlight the minutes: slide 9 the
controller.
X
To set the minutes: turn and press the controller.
The time is accepted.
The Automatic Time Settings
function is
deactivated ª.
If Automatic
is set for the summer time
changeover, you will see a prompt asking
whether the automatic changeover should be
maintained between summer and winter
time.
If Automatic Time Settings is reactiva-
i
ted, the previous settings for time zone and
summer time changeover are restored.
Setting the time and date format
Use this function to set the time and date format
for all displays in the vehicle.
X
Press the Ø button.
or
X
Press Vehicle in the main function bar.
The vehicle menu is displayed.
X
To select Time: slide 6, turn and press the
controller.
A menu appears.
X
To select Format: turn and press the controller.
X
To select the desired date format: turn and
press the controller.
The # dot indicates the current setting.
X
To select the desired time format: turn and
press the controller.
The # dot indicates the current setting.
Abbreviation Meaning
DD.MM.YYYY
DD/MM/YYYY
Day.Month.Year
date format,
year (all four digits)
Day/Month/
Year
date format,
year (all four digits)
Wi-Fi
37
Abbreviation Meaning
YYYY/MM/DD
Year/
Month/Day
date format,
year (all four digits)
YYYY-MM-DD
Day - Month Year
date format,
year (all four digits)
YY/MM/DD
Year/
Month/Day
date format,
year (two digits)
MM/DD/YYYY
Month/Day/
Year
date format,
year (all four digits)
HH:MM (24 hrs)
Hours : Minutes
(24 hour time
format)
HH:MM (AM/PM)
Hours : Minutes
(AM/PM time
format)
Voice Control System settings
Opening/closing the help window
If the set system language is not supported
i
by the Voice Control System, English will be
selected.
The help window also shows you information on
audible instructions:
R
during individualization
R
during subsequent operation of the Voice
Control System
X
Press the Ø button.
X
To select System Settings: slide 6, turn
and press the controller.
A menu appears.
X
To select Voice Control: turn and press the
controller.
X
Select Help Window.
You have switched the help window on O or
off ª.
Further information on the Voice Control System (see the separate operating instructions).
Individualization
Using individualization, you can fine-tune the
Voice Control System to your own voice. This
will help improve voice recognition (see the separate operating instructions).
System settings
Text reader settings
X
Press the Ø button on the control panel.
or
X
Press Vehicle in the main function bar.
The vehicle menu is displayed.
X
To select System Settings: slide 6, turn
and press the controller.
A menu appears.
X
To select Text Reader Speed: turn and
press the controller.
A list appears.
X
Select Fast, Medium or Slow.
The # dot indicates the current setting.
Wi-Fi
Overview
USA: requirement for establishing a WiFi con-
nection between the multimedia system and a
WiFi-enabled device, such as a tablet computer
or smartphone:
R
WiFi must be activated on the multimedia system and on the device to be connected.
Z
38
Wi-Fi
If the multimedia system is to be used as a WiFi
hotspot:
R
The multimedia system must be connected to
an Internet-enabled mobile phone via Blue-
®
or USB.
tooth
R
The Internet access data for the mobile phone
network provider must be selected or set in
the multimedia system.
R
An Internet connection must be established
on the multimedia system.
Canada: requirements for establishing a WiFi
connection between the multimedia system and
a WiFi hotspot of a WiFi-enabled device, such as
a smartphone, or another hotspot:
System settings
R
WiFi must be enabled on the multimedia system.
R
Switch on WiFi hotspot on the external device;
see the manufacturer's operating instructions.
Activating WiFi (USA)
Activating WiFi (Canada)
X
Press the Ø button on the control panel.
or
X
Press Vehicle in the main function bar.
The vehicle menu is displayed.
X
To switch to the menu bar: slide 6 the
controller.
X
To select System Settings: press the controller.
X
To select WiFi: turn and press the controller.
The WiFi menu appears.
X
To select the Activate O option: press the
controller.
Available WiFi hotspots are searched for and
displayed.
X
Press the Ø button on the control panel.
or
X
Press Vehicle in the main function bar.
The vehicle menu is displayed.
X
To switch to the menu bar: slide 6 the
controller.
X
To select System Settings: press the controller.
X
To select WiFi: turn and press the controller.
The WiFi menu appears.
X
To select the Activate O option: press the
controller.
Connecting the device
General notes
The exact WiFi connection procedure may vary
depending on the device to be connected. Follow the instructions that are shown in the display. Further information; see the manufacturer's operating instructions.
Selecting a hotspot (Canada)
Wi-Fi
39
X
Press the Ø button on the control panel.
or
X
Press Vehicle in the main function bar.
The vehicle menu is displayed.
X
To switch to the menu bar: slide 6 the
controller.
X
To select System Settings: press the controller.
X
To select WiFi: turn and press the controller.
The WiFi menu appears. A search for hotspots
is carried out.
X
To select a hotspot: turn and press the controller.
A menu for making the connection appears.
Connecting a device via WPS PIN (USA)
X
Press the Ø button on the control panel.
or
X
Press Vehicle in the main function bar.
The vehicle menu is displayed.
X
To switch to the menu bar: slide 6 the controller.
X
Select System Settings.
X
To select WiFi: turn and press the controller.
The WiFi menu appears.
X
Select one of the hotspots that has been
found.
A menu for making the connection appears.
X
Select Connect via WPS PIN.
X
Enter the WPS PIN generated by the multimedia system into the device.
X
To confirm the entry: press the controller.
Connecting a device via WPS PBC (USA)
System settings
Requirement: for this type of connection, the
device to be connected must support "Connect
using WPS PIN".
X
Select Connect via WPS PIN.
X
Select the vehicle from the device to be connected and "Connect using WPS PIN". The
vehicle is displayed with the SSID MB Hot‐
spot XXXXX.
The device to be connected generates a PIN.
X
Also enter this PIN into the multimedia system.
X
To confirm the entry: press the controller.
Connecting a device via WPS PIN (Canada)
Requirement: for this type of connection, the
device to be connected must support "Connect
using WPS PIN".
Requirement: for this type of connection, the
device to be connected must support "Connect
via push button".
X
Press the Ø button on the control panel.
or
X
Press Vehicle in the main function bar.
The vehicle menu is displayed.
X
To switch to the menu bar: slide 6 the controller.
X
To select System Settings: press the controller.
X
Select WiFi.
The WiFi menu appears.
X
Select Connect via WPS PBC.
X
Select the vehicle from the device to be connected and Connect
via WPS PBC. The vehi-
cle is displayed with the SSID MB Hotspot
XXXXX.
X
To confirm the entry: press the controller.
Z
Wi-Fi
40
Connecting a device via WPS PBC (Canada)
Requirement: for this type of connection, the
device to be connected must support "Connect
via push button".
X
Press the Ø button on the control panel.
or
X
Press Vehicle in the main function bar.
The vehicle menu is displayed.
X
To switch to the menu bar: slide 6 the controller.
X
To select System Settings: press the controller.
System settings
X
Select WiFi.
The WiFi menu appears.
X
To select one of the hotspots that has been
found: turn and press the controller.
A menu for making the connection appears.
X
Select Connect via WPS PBC.
X
Press the pushbutton on your device.
X
To confirm the entry: press the controller.
Generating a new security key (USA)
X
To select Regenerate: press the controller.
A new security key is generated.
X
To save the security key: turn the controller
and select Save
.
The WiFi menu appears. The new security key
will now be displayed and verified when a
connection is established via the security key.
The connection must be re-established with
the newly created security key.
Device connections established using the
i
previous security key will no longer work after
the security key is changed. You have to
reconnect these devices (
Y page 38).
Changing the name of the SSID (USA)
X
Press the Ø button on the control panel.
or
X
Press Vehicle in the main function bar.
The vehicle menu is displayed.
X
To switch to the menu bar: slide 6 the controller.
X
To select System Settings: press the controller.
X
To select WiFi: turn and press the controller.
The WiFi menu appears.
X
To select Generate Security Key: turn and
press the controller.
X
Press the Ø button on the control panel.
or
X
Press Vehicle in the main function bar.
The vehicle menu is displayed.
X
To switch to the menu bar: slide 6 the controller.
X
To select System Settings: press the controller.
X
To select WiFi: turn and press the controller.
The WiFi menu appears.
X
To select Change SSID: turn and press the
controller.
A dialog for entering the SSID appears.
X
Enter the new SSID.
X
To select ¬: turn and press the controller.
The new SSID is shown on the device to be
connected and in the Connect Using
Security Key menu.
Device connections established using the
i
previous SSID will no longer work after the
SSID is changed. You have to reconnect these
devices (
Y page 38).
Calling up the favorite functions
41
Bluetooth®settings
General information about Blue-
®
tooth
Bluetooth®-capable devices, e. g. mobile
phones, need to comply with a certain profile in
order to be connected to the multimedia system. Every Bluetooth
cific Bluetooth
Bluetooth
®
technology is a standard for short-
®
name.
®
device has its own spe-
range wireless data transmissions up to approximately 10 m.
®
You can use Bluetooth
to connect your mobile
phone to the multimedia system, for example:
R
use the hands-free system
R
establish an Internet connection
R
listen to music using Bluetooth®Audio
R
exchange vCards
Bluetooth
®
is a registered trademark of Blue-
tooth Special Interest Group (SIG) Inc.
Activating/deactivating Bluetooth
X
Press the Ø button.
®
or
X
Press Vehicle in the main function bar.
The vehicle menu is displayed.
X
To select System Settings: slide 6, turn
and press the controller.
A menu appears.
X
To select Activate Bluetooth: turn and
press the controller.
This switches Bluetooth
®
on O or off ª.
Setting the system language
This function allows you to determine the language for the menu displays and the navigation
messages. The selected language affects the
characters available for entry.
The navigation announcements are not
i
available in all languages. If a language is not
available, the navigation announcements will
be in English.
When you set the system language, the lan-
i
guage of the Voice Control System will
change accordingly. If it is not supported by
the Voice Control System, English will be
selected.
X
Press the Ø button.
or
X
Press Vehicle in the main function bar.
The vehicle menu is displayed.
X
To select System Settings: slide 6, turn
and press the controller.
A menu appears.
X
To select Language: turn and press the controller.
The list of languages appears. The # dot indicates the current setting.
X
Select the desired language.
The multimedia system loads the selected
language and sets it.
Calling up the favorite functions
The favorites function can be called up as follows:
R
via the System Settings menu
R
via the Favorites button on the controller
Y page 21)
(
R
via the Favorites button on the touchpad
Y page 22)
(
Calling up the Favorites function via the system menu
X
Press the Ø button.
or
X
Press Vehicle in the main function bar.
The vehicle menu is displayed.
X
To select System Settings: slide 6 and
press the controller.
A menu appears.
X
To select Favorite Functions: press the
controller.
The favorites are displayed.
X
To select the desired function, e.g. Phone‐
book: turn and press the controller.
A menu appears.
Calling up the Favorites function using the
controller
X
Press the favorites button on the controller.
The favorites are displayed.
X
To select the desired function, e.g. Phone‐
book: turn and press the controller.
Z
System settings
Importing/exporting data
42
Calling up the Favorites function via the
touchpad
X
Press the favorites button on the touchpad.
The favorites are displayed.
X
To select the desired function, e.g. Phone‐
book: turn and press the controller.
Exiting the Favorites function
X
Press the Favorites button again.
or
X
Press the % button.
Further information on the Favorites function
Y page 31).
(
System settings
Importing/exporting data
General notes
Never remove the stick or card when writing
!
data to the USB stick or the memory card. You
may otherwise lose data.
Using this function you can do the following with
your personal data:
R
transfer your data from one multimedia system to another multimedia system
The transfer may be limited or not possible,
depending on the vehicle's equipment.
R
make a backup copy of your personal data
(export data) and load it again (import data)
R
protect your data from unwanted export by
activating a PIN prompt (presetting: deactivated ª)
You can either use an SD card or a USB storage
device (e.g. a USB stick) as temporary storage.
Please remember that the NFTS file system is
not supported. The FAT32 file system is recommended.
You can obtain further information on data
import and export from an authorized
Mercedes-Benz Center.
Activating/deactivating PIN protection
X
Press the Ø button.
or
X
Press Vehicle in the main function bar.
The vehicle menu is displayed.
X
To select System Settings: slide 6, turn
and press the controller.
A menu appears.
X
To select Data Import/Export: turn and
press the controller.
X
Select Activate PIN Protection.
Activate O or deactivate ª PIN protection.
When activating PIN protection, you will be
prompted to enter a PIN.
X
To enter the 4-digit PIN and select ¬: turn
and press the controller.
You will be prompted to enter the PIN again.
X
Enter the PIN again and select ¬.
The PIN prompt now protects your personal
data from unwanted export.
If you deactivate your PIN protection, you
i
will first be prompted to enter your PIN. If you
have forgotten your PIN, an authorized
Mercedes-Benz Center can deactivate your
PIN protection for you. Alternatively, you can
deactivate PIN protection by resetting your
personal data (
Y page 43).
Importing/exporting data
X
Insert the SD memory card (Y page 149).
or
X
Connect a USB device (e.g. a USB memory
Y page 149).
stick) (
X
Press the Ø button.
or
X
Press Vehicle in the main function bar.
The vehicle menu is displayed.
X
To select System Settings: slide 6 and
press the controller.
A menu appears.
X
To select Data Import/Export: turn and
press the controller.
X
Select Import Data or Export Data.
If you import data such as address data, the
i
existing data on the multimedia system is
overwritten. You will see a message to this
effect. The multimedia system is restarted
after the data import.
If PIN protection is activated, a PIN prompt
appears when you select Export Data
.
Reset function
X
To enter the 4-digit PIN and select ¬: turn
and press the controller.
PIN protection is deactivated.
X
To select Memory Card, USB 1 or USB 2: turn
and press the controller.
This function exports all the data to the selected disc.
A window appears with the message that the
data has been exported.
You can export address data, bookmarks,
i
system settings that you have made and radio
station lists, for example.
Mercedes-Benz is not liable for any loss of
data.
Reset function
You can reset the multimedia system to the factory settings. This includes the deletion of all of
your personal data on the multimedia system.
These include:
R
Station presets
R
Entries in the destination memory
R
Entries in the list of previous destinations in
the navigation system
R
Entries in the address book
R
Authorized telephone
In addition, an activated PIN protection, which
you have used to protect your data against
unwanted export, will be deactivated. Resetting
is recommended before selling or transferring
ownership of your vehicle, for example.
Mercedes-Benz is not liable for any loss of data.
X
Press the Ø button.
or
X
Press Vehicle in the main function bar.
The vehicle menu is displayed.
X
To select System Settings: slide 6, turn
and press the controller.
A menu appears.
X
To select Reset: turn and press the controller.
A prompt appears asking whether you wish to
reset.
X
Select Yes.
A prompt appears again asking whether you
really wish to reset.
43
System settings
Z
Reset function
44
X
Select Yes.
A message appears. The multimedia system
is reset to the factory settings and restarted.
System settings
Vehicle settings
45
Your multimedia system equipment
These operating instructions describe all the
standard and optional equipment of your multimedia system, as available at the time of going
to press. Country-specific differences are possible. Bear in mind that your vehicle may not
feature all functions described here. This also
applies to safety-relevant systems and functions.
Read the information on qualified specialist
workshops in the vehicle Operator's Manual.
Important safety notes
WARNING
G
If you operate mobile communication equipment while driving, you will be distracted from
traffic conditions. You could also lose control
of the vehicle. There is a risk of an accident.
Only operate this equipment when the vehicle
is stationary.
You must observe the legal requirements for the
country in which you are currently driving when
operating mobile communications equipment in
the vehicle.
Vehicle settings
Exiting the vehicle settings:
X
To select &: slide 6 and press the controller.
Ambient lighting
General notes
You can set the following for the ambient lighting:
R
Brightness
This setting makes an additional change to
the brightness of the ambient lighting.
R
Color
This setting changes the color of the ambient
lighting.
R
Interior welcome light
Ambient lighting is activated for a short time
when the driver's door is opened.
Setting the brightness
X
Call up Vehicle Settings (Y page 45).
X
To select Ambient Light Brightness: turn
and press the controller.
The setting element is active.
X
To change the brightness value: turn and
press the controller.
You can find further information on the interior
lighting in the vehicle Operator's Manual.
Vehicle functions
Calling up vehicle settings
X
Press the Ø button.
or
X
Press Vehicle in the main function bar.
The vehicle menu is displayed.
X
To select Vehicle Settings: turn and press
the controller.
X
To select the desired vehicle setting: turn
and press the controller.
The main area with the setting element is
active.
Selecting a different vehicle setting:
X
To activate the menu for selecting the vehicle
setting: slide 5 the controller.
Setting the color
X
Call up Vehicle Settings (Y page 45).
X
To select Ambient Light Color: turn and
press the controller.
The setting element is active.
X
To select a color: turn and press the controller.
You can find further information on the interior
lighting in the vehicle Operator's Manual.
Setting the interior welcome light
X
Call up Vehicle Settings (Y page 45).
X
To select Interior Welcome Light: turn
and press the controller.
X
Press the controller.
The function is switched on or off, depending
on the previous status.
Z
Vehicle settings
46
You can find further information on the interior
lighting in the vehicle Operator's Manual.
Switching locator lighting on/off
If you switch on the Locator Lighting function, the exterior lighting is switched on for a
short time when it is dark. The light switch must
be set to Ã.
The exterior lighting remains on for 40 seconds
after the vehicle is unlocked. When you start the
engine, the locator lighting is switched off and
the automatic driving lights are activated.
You can find further information on the automatic headlamp mode in the vehicle Operator's
Manual.
X
Call up Vehicle Settings (Y page 45).
Vehicle functions
X
To select Locator Lighting: turn and press
the controller.
X
Press the controller.
The function is switched on or off, depending
on the previous status.
You can find further information on the locking
feature in the vehicle Operator's Manual.
There may be fewer settings or none
i
depending on your vehicle's equipment.
Setting the switch-off delay time
Interior lighting switch-off delay time
The interior lighting is activated for the duration
of the switch-off delay time when the SmartKey
is removed from the ignition lock.
X
Call up Vehicle Settings (Y page 45).
X
To select Interior Lighting Delayed
Switch-off: turn and press the controller.
The setting element is active.
X
To change the delayed switch-off time: turn
and press the controller.
You can find further information on the interior
lighting in the vehicle Operator's Manual.
Exterior lighting switch-off delay time
If you switch on the Exterior Lighting
Delayed Switch-off function, the exterior
lighting is switched on for a short time after the
engine is switched off. The light switch must be
set to Ã.
The exterior lighting remains on for 60 seconds
after the engine is switched off. If you close all
the doors and the tailgate, the exterior lighting
switches off after the set time.
X
Call up Vehicle Settings (Y page 45).
X
To select Exterior Lighting Delayed
Switch-off: turn and press the controller.
The setting element is active.
X
To change the delayed switch-off time: turn
and press the controller.
Displaying energy consumption and
generated electrical energy
A bar graph displays the energy consumption
and the generated electrical energy.
X
Press Vehicle in the main function bar.
The vehicle menu is displayed.
X
To select Consumption: turn and press the
controller.
The energy consumption and the generated
electrical energy for the last 15 minutes of the
journey is shown.
For further information on energy consumption,
see the vehicle Operator's Manual.
Displaying the fuel consumption
A bar graph displays the fuel consumption.
X
Press Vehicle in the main function bar.
The vehicle menu is displayed.
X
To select Consumption: turn and press the
controller.
The fuel consumption for the last 15 minutes
of the journey is shown.
Switching the ionization on/off
The ionization has a cleansing effect on the air in
the vehicle interior. Further information (see the
vehicle Operator's Manual).
X
Call up Vehicle Settings (Y page 45).
X
To select Ionization: turn and press the
controller.
The ionization is switched on or off, depending on the previous status: press and turn the
controller.
X
To exit the menu: press the % button.
Seats
47
Seats
Overview
You can configure the following seat functions in
the menu:
R
Backrest side bolsters
R
Lumbar
R
Seat cushion
R
Massage
R
Dynamics
R
Seat heating balance
There may be fewer settings or none
i
depending on your vehicle's equipment.
Selecting the adjustment function
and seat
X
Press the Ø button.
or
X
To select Vehicle from the main function bar:
turn and press the controller.
The vehicle menu is displayed.
X
To select Seat Settings: turn and press the
controller.
The seat settings menu is shown.
or
X
Press the T button on the controller.
The seat settings menu is shown.
X
To select the required seat function: turn and
press the controller.
X
To switch between Driver and Front
Passenger: slide 1 the controller.
Adjustment functions
Adjusting the backrest side bolsters
X
Call up the seat functions (Y page 47).
X
To select Backrest Sides: turn and press
the controller.
X
To change the setting: turn the controller.
You will see the changes you have made in the
settings display.
X
To exit the menu: press the % button.
Adjusting the seat contour in the lumbar region of the seat backrest
This function allows you to adjust the air cushions in the lumbar region of the backrest (4-way
lumbar support).
X
Call up the seat functions (Y page 47).
X
To select Lumbar: turn and press the controller.
X
To activate the setting element: press the
controller.
X
To change the setting: slide 4 or 1
the controller.
The change will be visible in the setting element.
X
To exit the menu: press the % button.
Adjusting the seat cushion
X
Call up the seat functions (Y page 47).
X
To select Seat Surface: turn and press the
controller.
X
To select a seat: slide 1 the controller.
X
To change the setting: turn the controller.
You will see the changes you have made in the
settings display.
X
To exit the menu: press the % button.
Adjusting the driving dynamics
X
Call up the seat functions (Y page 47).
X
To select Dynamic Multicontour Seat:
turn and press the controller.
X
To select a seat: slide 1 the controller.
You can select:
R
OFF:
R
1: Level 1 (weak)
R
2: Level 2 (strong)
X
To select the setting: turn the controller.
X
To exit the menu: press the % button.
Massage programs
Overview
You can select the following massage programs:
R
Relaxing Massage
Vehicle functions
Z
360° camera
48
Massage the entire back, rising waves, soothing downward movements
R
Activating Massage
Mobilizing massage and rising and descending dynamic waves
R
Classic Massage
Single and twin waves moving upwards
across the entire back
R
Mobilizing Massage
Mobilization via stronger single and twin
waves moving upwards across the entire back
Selecting a massage program
X
Call up the seat functions (Y page 47).
X
To select Massage: turn and press the controller.
Vehicle functions
X
To select a seat: slide 1 the controller.
X
To select massage programs: turn and press
the controller.
The massage program runs for approximately
15 to 25 minutes, depending on the setting.
X
To exit the menu: press the % button.
Seat heating balance
The balance function controls the distribution of
heat for the seat backrest and seat cushion.
The balance function influences the currently
set heating level of the seat heating (see the
vehicle Operator's Manual).
X
Call up the seat functions (Y page 47).
X
To select Seat Heating Balance: turn and
press the controller.
X
To select a seat: slide 1 the controller.
X
To change the setting: turn the controller.
You will see the changes you have made in the
settings display.
The settings represent the following:
R
0 — the backrest and seat cushion are evenly
heated according to the setting selected with
the seat heating button.
R
1 to 3 increasing — the heat output to the seat
cushion is reduced one level at a time.
R
1 to 3 decreasing — the heat output for the
backrest is reduced one level at a time.
X
To exit the menu: press the % button.
Resetting all adjustments
X
Call up the seat functions (Y page 47).
X
Select a seat.
X
To select Reset: turn and press the controller.
X
To select a seat: slide 1 the controller.
X
To reset: press the controller.
A prompt appears.
X
To select Yes or No: turn and press the controller.
If you select No
After selecting Yes
the process is canceled.
all seat adjustments are
reset to the default values (factory setting).
360° camera
General notes
The 360° camera covers the immediate surroundings of the vehicle and assists you, for
instance when parking or at exits with reduced
visibility.
The 360° camera is only an aid. It is not a
replacement for your attention to your immediate surroundings. You are always responsible
for safe maneuvering and parking. Make sure
that no persons or animals are in the maneuvering range.
Further information on the 360°camera can be
found in the vehicle Operator's Manual.
Displaying the 360° camera image
The 360° camera image can be displayed if:
R
your vehicle is equipped with a 360° camera
R
the 360° Camera function is switched on (see
the vehicle Operator's Manual)
X
Press Vehicle in the main function bar.
The vehicle menu is displayed.
X
Select 360° Camera.
The 360° camera image appears in splitscreen mode.
You will see the previous view on the display if,
when the function is switched on:
R
you turn the SmartKey to position 1 in the
ignition lock
R
you select transmission position P
R
when you are driving at moderate speeds
Rear view camera
49
Switching the display off manually
X
To select &: slide 6 and press the controller.
Switching the display on automatically
X
You can switch on the 360 camera display
automatically using the reverse gear
Y page 49).
(
Switching the 360° camera automatic mode on/off
This function activates the 360° camera when
reverse gear is engaged.
X
Press Vehicle in the main function bar.
The vehicle menu is displayed.
X
To switch to the menu bar: slide 6 the
controller.
X
To select System Settings: turn and press
the controller.
X
To select 360° Camera: turn and press the
controller.
The 360° Camera
X
Select Activation by R gear.
menu appears.
The function is switched on O or off ª.
Opening the camera cover for cleaning
X
To select Open Camera Cover in the 360°
camera menu: turn the controller and press to
confirm.
The Please Wait...
message appears for
approximately three seconds.
The camera cover opens.
The camera cover closes automatically if:
R
the ignition is switched off
R
the vehicle exceeds a moderate speed
Depending on the vehicle's equipment, this
i
function is not available.
Rear view camera
General notes
The rear view camera covers the immediate surroundings of the vehicle and assists you when
parking.
The rear view camera is only an aid. It is not a
replacement for your attention to your immediate surroundings. You are always responsible
for safe maneuvering and parking. When maneuvering or parking, make sure that there are no
persons, animals or objects in the area in which
you are maneuvering.
There may be fewer settings depending on your
vehicle's equipment.
You can find further information about the rear
view camera in the vehicle Operator's Manual.
Switching the rear view camera automatic mode on/off
This function activates the rear view camera
when reverse gear is engaged.
X
Press the Ø button.
or
X
Press Vehicle in the main function bar.
The vehicle menu is displayed.
X
Slide 6 the controller.
X
To select System Settings: turn and press
the controller.
X
Select Rear View Camera.
The Rear View Camera
X
Select Activation by R gear.
menu appears.
The function is switched on O or off ª,
depending on the previous status.
When you start the vehicle and engage
reverse gear, the area behind the vehicle is
shown with guide lines in the display. For further information on the rear view camera (see
the vehicle Operator's Manual).
Opening the camera cover for cleaning
X
To select Open Camera Cover in the rear
view camera menu: turn and press the controller.
The Please Wait...
approximately three seconds.
The camera cover opens.
The camera cover closes automatically if:
R
the ignition is switched off
R
the vehicle pulls away
message appears for
Vehicle functions
Z
DYNAMIC SELECT
50
DYNAMIC SELECT
General notes
Press DYNAMIC SELECT to configure the following settings and values for the Individual drive
program:
R
Drive system
R
Suspension
R
Steering
R
Climate control
R
ECO start/stop function
In a few countries, the ECO start/stop func-
i
tion is deactivated at the factory due to the
available fuel grade. In this case, the ECO
start/stop function is not available regardless
of the display in the multimedia system display.
Vehicle functions
For Mercedes-AMG vehicles, you can configure
the following settings and adjustment values for
the Individual drive program:
R
Drive system
R
Suspension
R
Transmission
R
ESP®(Electronic Stability Program)
There may be fewer settings or set values, or
none, depending on your vehicle's equipment.
For further information on the Individual drive
program; see the vehicle Operator's Manual.
Configuration using the DYNAMIC
SELECT button
X
Use the DYNAMIC SELECT button to select
the Individual drive program (see the vehicle
Operator's Manual).
A window appears after a short while.
X
To confirm Adjust: press the controller.
The Individual Configuration
setting the drive program appears.
X
To selectDrive, Suspension, Steering,
Climate Control
or Eco Start/Stop
Function: turn and press the controller.
X
Select individual settings.
The menu symbol, text and image show the
selected setting.
menu for
Configuration via the DYNAMIC
SELECT controller
The DYNAMIC SELECT Controller is available for
Mercedes-AMG vehicles.
X
Use the DYNAMIC SELECT controller to select
the Individual drive program; see the vehicle
Operator's Manual.
A window appears after a short while.
X
To confirm Adjust: press the controller.
The Individual Configuration
menu for
setting the drive program appears.
X
To selectDrive, Suspension, Transmis‐
sion or ESP: turn and press the controller.
X
Select individual settings.
The menu symbol, text and image show the
selected setting.
Displaying vehicle data
X
Press Vehicle in the main function bar.
The vehicle menu is displayed.
X
To selectDYNAMIC SELECT: turn and press
the controller.
X
Select Vehicle Data.
Updates of the following data are displayed:
R
Road type analogous to the selected drive
program
R
G-force display of longitudinal and lateral
acceleration
R
Accelerator and brake pedal activity
R
Activity of the suspension struts
R
Wheel angle
R
Vehicle level display (Mercedes-AMG vehicles)
The G-force display is not available in all of the
drive programs.
Daytime or night-time view is shown depending
on the automatic light sensor.
Displaying engine data
There may be fewer displays depending on
i
your vehicle's equipment.
DYNAMIC SELECT
51
X
Press Vehicle in the main function bar.
The vehicle menu is displayed.
X
To select DYNAMIC SELECT: turn and press
the controller.
The Individual Configuration
Engine Data
X
Select Engine Data.
menus appear.
and
The following current data is displayed:
R
Engine output
R
Engine torque
R
Engine oil temperature
R
Transmission oil temperature (MercedesAMG vehicles)
R
On-board electrical system voltage
The values for engine output and engine tor-
i
que may deviate from the nominal values.
Items that can influence this are, for example:
R
Engine speed
R
Sea level
R
Fuel grade
R
Outside temperature
Setting options
You can choose from the following settings for
the drive:
C Comfort
S Sport
S+ Sport Plus
M Manual
E Eco
You can make the following settings for the suspension:
C Comfort
S Sport
S+ Sport Plus
You can make the following settings for the
steering:
C Comfort
S Sport
You can choose from the following settings for
climate control:
E Eco
C Comfort
You can choose from the following settings for
the ECO start/stop function:
On Switches the ECO
start/stop function
on
Off Switches the ECO
start/stop function
off
Setting options (Mercedes-AMG vehicles)
You can choose from the following settings for
the drive:
R Race
C Comfort
S Sport
S+ Sport Plus
You can make the following settings for the suspension:
C Comfort
S Sport
You can choose from the following settings for
the transmission:
D Automatic
M Manual
You can choose from the following settings for
®
the ESP
S Sport
On
(Electronic Stability Program):
Activates ESP®(Electronic Stability Program)
Vehicle functions
Z
Driving dynamics
52
You can choose from the following settings for
the ECO start/stop function:
On Switches the ECO
start/stop function
on
Off Switches the ECO
start/stop function
off
Driving dynamics
General notes
In the Driving Dynamics menu you can call up
current vehicle and engine data. There may be
less or no data and displays depending on your
Vehicle functions
vehicle's equipment.
Displaying engine data
X
Press Vehicle in the main function bar.
The vehicle menu is displayed.
X
To select Driving Dynamics: turn and press
the controller.
X
Select Engine Data.
The following current data is displayed:
R
Engine output
R
Engine torque
R
Engine oil temperature
R
Transmission oil temperature (MercedesAMG vehicles)
R
On-board voltage
The values for engine output and engine tor-
i
que may deviate from the nominal values.
Items that can influence this are, for example:
R
Engine speed
R
Sea level
R
Fuel grade
R
Outside temperature
Displaying vehicle data
X
Press Vehicle in the main function bar.
The vehicle menu is displayed.
X
To select Driving Dynamics: turn and press
the controller.
X
Select Vehicle Data.
Updates of the following data are displayed:
R
Road type analogous to the selected drive
program
R
G-force display of longitudinal and lateral
acceleration
R
Accelerator and brake pedal activity
R
Activity of the spring struts
R
Wheel angle
R
Vehicle level display (Mercedes-AMG vehicles)
The G-force display is not available in all of the
drive programs.
Daytime or night-time view is shown depending
on the automatic light sensor.
Introduction
53
Your multimedia system equipment
These operating instructions describe all the
standard and optional equipment of your multimedia system, as available at the time of going
to press. Country-specific differences are possible. Bear in mind that your vehicle may not
feature all functions described here. This also
applies to safety-relevant systems and functions.
Read the information on qualified specialist
workshops in the vehicle Operator's Manual.
Introduction
Important safety notes
WARNING
G
If you operate information systems and communication equipment integrated in the vehicle while driving, you will be distracted from
traffic conditions. You could also lose control
of the vehicle. There is a risk of an accident.
Only operate the equipment when the traffic
situation permits. If you are not sure that this
is possible, park the vehicle paying attention
to traffic conditions and operate the equipment when the vehicle is stationary.
You must observe the legal requirements for the
country in which you are currently driving when
operating the multimedia system.
The multimedia system calculates the route to
the destination without taking account of the
following, for example:
R
traffic lights
R
stop and yield signs
R
merging lanes
R
parking or stopping in a no parking/no stopping zone
R
other road and traffic rules and regulations
R
narrow bridges
The multimedia system may provide incorrect
navigation recommendations if the actual
street/traffic situation does not correspond
with the digital map's data.
Examples of such deviations incl
R
a diverted route
R
a change in the direction of a one-way street
ude:
Digital maps do not cover all areas nor all routes
in an area.
For this reason, you must always observe road
and traffic rules and regulations during your
journey. Road and traffic rules and regulations
always have priority over the system's driving
recommendations.
Navigation announcements are intended to
direct you while driving without diverting your
attention from the road and driving.
Please always use this feature instead of consulting the map display for directions. Looking
at the icons or map display can distract you from
traffic conditions and driving, and increase the
risk of an accident.
General notes
Operational readiness of the navigation
system
The navigation system must determine the position of the vehicle before first use or whenever
operational status is restored. Therefore, you
may have to drive for a while before precise
route guidance is possible.
GPS reception
Among other things, correct functioning of the
navigation system depends on GPS reception. In
certain situations, GPS reception may be
impaired, there may be interference or there
may be no reception at all, e.g. in tunnels or
parking garages.
Using roof carriers may impair the correct
i
functioning of a roof antenna (phone, satellite
radio, GPS).
Entry restriction
For vehicles in certain countries, there is a data
entry restriction.
Entries can be made when the selector lever is in
position P or the vehicle is stationary.
When the restriction is active, certain entries
cannot be made. This will be indicated by the
fact that certain menu items are grayed out and
cannot be selected.
Z
Navigation
Introduction
54
The following entries are not possible, for example:
R
entering the destination city and street
R
POI entry via a name search
R
editing and saving of entries
Other entries are however possible, such as a
keyword search and entering POIs in the vicinity
of the destination or current position.
Switching to navigation mode
Navigation
X
Press the ß button.
The map shows the vehicle's current position.
or
X
Slide 5 the controller (e.g. in radio mode).
X
To select Navi, turn and press the controller.
The map shows the vehicle's current position.
To call up the map while navigation mode
X
is switched on: press the ß button in any
menu.
The navigation menu appears.
X
Press the controller.
The map shows the vehicle's current position.
Using the menu, you can make a destination
entry or select the navigation settings, for example.
X
To show: slide 6 the controller when the
map appears.
If there has been no route calculated, Des‐
tination is marked.
If a route has been calculated, y is
marked.
X
To hide: press the % button.
or
X
Slide 5 the controller.
Full screen symbol : appears.
X
Press the controller.
Moving the map
Showing/hiding the menu
Requirement: the map is in full screen mode, the
menu is faded out (
X
Press the controller.
Y page 54).
The crosshair is shown.
X
Slide 1, 4 or 2 the controller.
The map moves in the corresponding direction under the crosshair.
X
Press the controller to show the menu.
X
Select Menu.
Basic settings
55
Basic settings
Selecting the route type
X
To switch to navigation mode: press the
Ø button.
X
To show the menu: slide 6 the controller.
X
To select Options: turn and press the controller.
X
To select Route Settings: press the controller.
X
To select the route type: turn and press the
controller.
A filled circle indicates the current selection.
R
With active route guidance, the navigation
system calculates a new route.
Route guidance active: a destination has
been entered and the route has been calculated.
R
If there has been no route calculated, the
navigation system uses the selection as the
new basic setting.
Eco Route
The navigation system calculates an economic route. The
journey may take slightly longer compared to taking the
fast route.
Short
Route
The navigation system calculates a route with a short distance.
The route types Dynamic Traffic Route and
Dynamic TRF. Route After Request
use
real-time traffic reports from SIRIUS satellite
radio.
Further Information on real-time traffic reports
Y page 77).
(
X
To calculate alternative routes: select
Calculate Alternative Routes
.
Switch the function on O or off ª.
Function activated: after each route calcula-
tion, route alternatives are offered that correspond to the local conditions (
Y page 75).
If desired, you can have the navigation system
calculate alternative routes even during route
guidance (
Y page 75).
Setting route options
Navigation
Fast Route
Dynamic
Traffic
Route
Dynamic
TRF. Route
After
Request
The navigation system calculates a route with a short journey time.
Based on the Fast Route
route type and includes traffic reports on the route for the
route guidance.
If there are traffic reports, a
prompt appears asking
whether these reports should
be considered in the route
calculation.
X
To switch to navigation mode: press the
Ø button.
X
To show the menu: slide 6 the controller.
X
To select Options: turn and press the controller.
X
To select Route Settings: press the controller.
Z
Basic settings
56
X
To avoid/use route options: select Avoid
Options.
A menu appears.
X
Select one of the options.
O: using or avoiding route options is enabled
ª: using or avoiding route options is disabled
R
Avoid Area (Y page 86)
You can define areas that you would like to
avoid.
R
Avoid Highways
R
Avoid Ferries
R
Avoid Auto Trains
R
Avoid Tunnels
R
Avoid Unpaved Roads
The function is not available in all countries.
R
Use Toll Roads
Navigation
The route calculation includes roads which
require you to pay a usage fee (toll).
R
Number of Occupants in the Vehicle:
If your vehicle meets the access conditions
for carpool lanes, you can use this function.
Navigation includes carpool lanes if the carpool lanes option is activated.
Depending on local conditions, the navigation
system may not always be able to include all
route options. A route may include a ferry, for
instance, even though Avoid Ferries
bled. The navigation system will notify you of
this visually and through a navigation message.
X
To use toll roads: turn and press the controller.
A menu appears.
X
Select an option.
The options include using roads that require
cash payment or electronic billing, or switching off the function.
X
To exit a menu: slide 1 the controller.
is ena-
Selecting announcements
X
To switch to navigation mode: press the
Ø button.
X
To show the menu: slide 6 the controller.
X
To select Options: turn and press the controller.
X
Select Settings.
X
Select an option.
Switch the option on O or off ª.
Announce
Street
Names
Audio
Fadeout
Audible
Info Dur‐
ing Phone
Call
Gas on
Reserve
Atten‐
tion
Assist
The navigation system announces the names of the roads
onto which the upcoming
change of direction leads.
The volume of an active media
source is automatically
reduced during a navigation
announcement.
The navigation message is also
given during telephone calls.
Function activated: once the
reserve fuel tank level is
reached, a message appears to
help you start a gas station
search.
Function activated: if ATTENTION ASSIST displays a warning in the multifunction display,
a message appears in the multimedia system display when
you drive onto a highway. This
can help you start a rest stop
search.
For further information on
ATTENTION ASSIST, see the
vehicle Operator's Manual.
Destination entry
57
Using car pool lanes
You can include carpool lanes (HOV or car sharing lanes) in the route calculation.
If you use HOV or carpool lanes, please observe
the applicable laws as well as the local and time
limitation conditions.
Carpool lanes may only be used under certain
conditions. They can normally be used when
there are two people in the vehicle. However,
there are also carpool lanes which can only be
used when there are three or more people in the
vehicle. In California, single drivers may also use
the carpool lanes if the vehicle's emission or
consumption values are below the prescribed
levels.
Carpool lanes may be reserved for specific
times (e.g. during the peak period).
Carpool lanes are indicated by a diamond symbol on specific road signs and on the road surface. The road signs may also include the designation CARPOOL. The lanes are arranged as a
separate lane next to the others or are built as a
physically separate lane.
Depending on the setting under Number of
Occupants in the Vehicle:, the navigation
system uses carpool lanes when calculating the
route. During route guidance, visual and audible
driving directions provide guidance into and out
of carpool lanes.
X
To switch to navigation mode: press the
ß button.
X
To show the menu: press the controller.
X
To select Options: turn and press the controller.
X
Select Route Settings.
X
Select Avoid Options.
X
Select Number of Occupants in the
Vehicle:.
A menu appears. The # dot indicates the current setting.
X
To select the number: turn and press the controller.
Destination entry
Important safety notes
WARNING
G
If you operate information systems and communication equipment integrated in the vehicle while driving, you will be distracted from
traffic conditions. You could also lose control
of the vehicle. There is a risk of an accident.
Only operate the equipment when the traffic
situation permits. If you are not sure that this
is possible, park the vehicle paying attention
to traffic conditions and operate the equipment when the vehicle is stationary.
You must observe the legal requirements for the
country in which you are currently driving when
operating the multimedia system.
Destination entry may be blocked while driving,
depending on the country specifications.
Using an address
Calling up the address entry menu
X
To switch to navigation mode: press the
Ø button.
X
To show the menu: slide 6 the controller.
X
To select Destination: turn and press the
controller.
X
Select Address Entry.
Navigation
Address entry options
Examples of how you can enter an address:
R
city or ZIP code, street, house number
R
city or ZIP code, street
Z
Destination entry
58
R
city or ZIP code, center
R
city or ZIP code, street, intersection
R
street, city or ZIP code, house number
R
street, city or ZIP code, intersection
The address can be entered faster by entering
the street before the city if the address has an
unusual street name.
While entering an address in the character bar,
you can call up other destination entry options:
R
keyword search using è (Y page 60)
R
the map via Map (Y page 64)
R
POIs via POIs (Y page 62)
Entering an address
Navigation
The example shows you how to enter a city,
street and house number for an address, e.g. for
your home address.
X
In the address entry menu, select Street:
press the controller (
The city in which the vehicle is currently located is at the top of the list.
X
Enter BROADWAY. Character entry (Y page 30).
X
To call up the list: slide 5 the controller
repeatedly until the character bar disappears.
or
X
To select the ¬ symbol: turn and press the
controller.
Y page 57).
X
To select Town: press the controller.
X
Enter the city, e.g. New York. Then call up the
list and select an entry. Proceed in the same
way as when entering a street.
X
To select No.: press the controller.
X
Enter the house number. Then call up the list
and select an entry. Proceed in the same way
as when entering a street.
The address entry menu shows the address.
The city in which the vehicle is currently located
(current vehicle position) is at the top of the list
of cities. When destinations are entered using
the character bar, the locations for which route
guidance has already been carried out are more
prominently available.
You can enter any of the cities, streets, ZIP
codes, etc. which are stored in the digital map.
However, ZIP codes are not available for some
countries.
State/province and city are sufficient to start
navigating. You can enter either a city or a ZIP
code. The street and house number complete
the destination address.
Entering additional address data
You can enter additional address data:
R
State/province
You can use Last Used
selected state (USA) or province (Canada).
You can also select Mexico and The Bahamas.
R
ZIP code
Entering a ZIP code will delete a previously
entered city.
R
Center
Entering a center will delete a previously
entered street.
R
Intersection
Entering an intersection will delete a previ-
ously entered house number.
to select the last
Destination entry
59
X
Select the address entry menu (Y page 57).
X
To select State/Province, ZIP Code, Cen‐
ter or Intersection: turn, slide 6 and
press the controller.
X
Select an entry (Y page 58).
Saving an address
You can store the address entered as:
R
a home address in the address book
R
a navigable address book contact
For further information on the address book,
Y page 106)
see (
R
a personal destination on the SD card
Y page 81).
(
X
Call up the address entry menu (Y page 57).
X
To select Save: slide 6, turn and press the
controller.
X
As the home address: select As "My
Address".
The home address is stored in the list of contacts under the entry My Address
X
As a contact: select As New Contact.
X
Select Not Classified, Home or Work.
.
X
Enter a surname and first name (Y page 30).
X
To select the¬ symbol: turn and press the
controller.
The destination address is saved in the
address book as a navigable contact.
Starting route calculation
The entered destination appears in the address
entry menu.
X
To confirm Start or Continue: press the
controller.
If you select Start
with the current route settings (
While route calculation is in progress, an
arrow will indicate the direction to your destination. Once the route has been calculated,
route guidance begins. If the vehicle is traveling on a non-digitized road, the system displays the linear distance to the destination,
the direction to the destination and the Road
Not Mapped message.
Selection Continue
native Routes is activated, alternative
routes are calculated (
display these and select them for route guid-
Y page 75).
ance (
If route guidance has already been activated,
a prompt will appear asking whether you wish
to end the current route guidance.
X
To select Cancel Active Route Guidance
or Set as Intermediate Destination:
turn and press the controller.
Cancel Active Route Guidance
the current route guidance and starts route
calculation to the new destination.
Set as Intermediate Destination
the new destination in addition to the existing
destination and opens the intermediate destinations list.
: the route is calculated
Y page 55).
: If Calculate Alter‐
Y page 55). You can
cancels
adds
Navigation
Z
Destination entry
60
The route is calculated using the digital map
i
data. The calculation time depends on the
distance from the destination, for example.
The route may differ from the ideal route, e.g.
due to incomplete map data. Please also refer
to the notes about the digital map
Y page 88).
(
Keyword search
Entering keywords
Navigation
The keyword search is used to help find destinations using fragments of words. If you enable
the appropriate setting in the search options,
the keyword search is tolerant of errors
Y page 61).
(
It can be used for an address or a POI. For exam-
ple, you can search for the Empire State Building
in New York.
The keyword search finds geographically tolerant hits. If, for example, you are searching for a
street located on the edge of a major city, the
search will also cover adjacent smaller cities.
The keyword search supports the character sets
of the system languages available.
X
To switch to navigation mode: press the
Ø button.
X
To show the menu: slide 6 the controller.
X
To select Destination: turn and press the
controller.
X
Select Keyword Search.
X
Enter the first few letters of the city and
street, e.g. NEW
While entering the information, the number of
exact matches and total number of matches
is shown.
---/---
acters have been entered.
and EMP.
is displayed if fewer than three char-
is displayed if there are too many hits.
999+
X
Select the ¬ symbol.
The search results are displayed
Y page 60).
(
Selecting search results
The search results are divided into categories,
such as addresses. The number of exact
matches and total number of matches is shown
in brackets.
Further search results are displayed, if POI
Search and/or Fuzzy Search are activated in
the search options (
X
To select an address: press the controller.
The search results are displayed.
Exact hits are shown at the very top of the list.
Hits are listed alphabetically. The search term
that you entered is highlighted in orange in the
entries.
X
Select an entry: turn and press the controller.
The address entry menu appears, showing the
destination address.
X
To start route calculation: select Start .
Y page 61).
Destination entry
61
X
To select POI: select POIs in the Vicin‐
ity or All POIs by turning and pressing con-
troller.
A list appears. The search results are displayed according to the linear distance, starting with those closest.
X
Select a POI.
The POI is shown.
X
To start route calculation: select Start .
X
To select online search: select Online
Search by turning and pressing the control-
ler.
The search switches to the online functions.
Online search requirement (USA): mbrace
must be activated for Internet access
Y page 125).
(
Requirement for the online map display (Can-
ada): a mobile phone is connected to the multimedia system via Bluetooth
Y page 159).
or USB (
®
(Y page 93)
Selecting search options
X
To switch to navigation mode: press the
Ø button.
X
To show the menu: slide 6 the controller.
X
To select Destination: turn and press the
controller.
X
Select Keyword Search.
X
To select Search Options: slide 5, turn
and press the controller.
X
Select Fuzzy Search or POI Search.
Switch the setting on O or off ª.
The error-tolerant search is useful if parts of
the address are incomplete or the spelling is
unclear.
The POI search takes into account points of
interest in the search.
X
To select State/Province: slide 5, turn
and press the controller.
States/provinces are sorted alphabetically.
X
To select a state/province: turn and press the
controller.
Using online search
Requirement (USA): mbrace must be activated
for Internet access (
Requirement (Canada): a mobile phone is connected to the multimedia system via Bluetooth
(Y page 93) or USB (Y page 159).
X
To switch to navigation mode: press the
Ø button.
X
To show the menu: slide 6 the controller.
X
To select Destination: turn and press the
controller.
X
Select Keyword Search.
X
Enter the first few letters of the city and
street.
X
To select Online Search: slide 5, turn and
press the controller.
The search switches to the online functions.
Y page 125).
Selecting a destination from the list of
last destinations
®
Navigation
Selecting a state/province
X
To switch to navigation mode: press the
Ø button.
X
To show the menu: slide 6 the controller.
X
To select Destination: turn and press the
controller.
X
Select Keyword Search.
The last 50 destinations are stored automatically.
X
To switch to navigation mode: press the
Ø button.
X
To show the menu: slide 6 the controller.
X
To select Destination: turn and press the
controller.
X
Select From Previous Destinations.
Z
Destination entry
62
X
Select the destination.
The address entry menu appears, showing the
destination address.
X
To start route calculation: select Start .
Selecting an address book contact as
a destination
Navigation
You can select navigable address book contacts
as the destination. These are identified by the
L symbol. If you have already entered and
saved your home address, you can select this as
the destination by using My Address
X
To switch to navigation mode: press the
Ø button.
X
To show the menu: slide 6 the controller.
X
To select Destination: turn and press the
controller.
.
X
Select From Contacts.
X
Select the destination.
The address entry menu appears, showing the
contact and associated destination address.
X
To start route calculation: select Start .
Selecting a destination from POIs
Calling up the POI menu
X
To switch to navigation mode: press the
Ø button.
X
To show the menu: slide 6 the controller.
X
To select Destination: turn and press the
controller.
X
Select From POIs.
Defining the position for the POI search
Selection Instructions
X
Near Destination
(when route guidance is
active)
Current Position
Searches in the vicinity of
the current vehicle position.
Call up the POI menu (Y page 62).
X
To select Near Destination: turn and press the controller.
X
Select a POI category (Y page 63).
X
Call up the POI menu (Y page 62).
X
To select Current Position: turn and press the controller.
X
Select a POI category (Y page 63).
Selection Instructions
Other City
After entering a city, the
search is performed
within the city's boundaries
Option 1
X
Call up the POI menu (Y page 62).
X
To select Other City: turn and press the controller.
X
Select the state/province (Y page 58), if desired.
X
Enter the city (Y page 58).
X
Select a POI category (Y page 63).
Option 2
X
Enter a city in the address entry menu (Y page 58).
X
To select POIs: slide 6, turn and press the controller.
X
Select a POI category (Y page 63).
X
Search By Name
Searches for all POIs on
the digital map or around
one of the three previously specified positions
Call up the POI menu (Y page 62).
X
To select Search By Name: turn and press the controller.
X
Select All POIs or one of the three previously selected positions.
The POI list with character bar appears.
X
Enter a name.
or
X
To select Mercedes-Benz Service: turn and press the controller.
X
Search By Phone Num‐
ber
All POIs with a telephone
number can be selected.
Call up the POI menu (Y page 62).
X
To select Search By Phone Number: turn and press the controller.
You will see a list of phone numbers.
X
Enter the telephone number.
The telephone number consists of:
R
the country code (international dialing code)
R
the area code
When entering the area code, omit the leading "0"
R
the telephone number of the participating caller
Destination entry
63
Navigation
Selecting a POI category
POI categories appear after choosing the menu
items Near Destination
and after entering another city.
, Current Position
Z
Destination entry
64
X
Turn and press the controller.
The G symbol after an entry shows that further categories are available.
X
Select a sub-category.
The POI search covers a 240 mi (400 km)
radius around the selected position.
Once the search is completed, the POI list is
displayed.
The search results display the following information:
R
an arrow that shows the linear direction to
the POI (search around vehicle position)
R
the linear distance to the POI
R
the name of the POI
X
Select a POI.
The complete address of the POI is shown.
Navigation
Selecting a POI
Requirement for "Calling up a POI": a mobile
phone must be connected to the multimedia
system (
Requirements for "Viewing the vicinity of the
destination" and "Loading data from the Internet" (USA): mbrace must be activated for Internet access (
Requirements for "Viewing the vicinity of the
destination" and "Loading data from the Internet" (Canada): a mobile phone must be connected to the multimedia system via Bluetooth
(Y page 93) or USB (Y page 159).
Y page 93).
Y page 125).
®
X
To call up a POI: select Call.
If a phone number is available, the multimedia
system switches to the telephone function.
X
To load data from the Internet: select www.
If an Internet address is available, data is loaded from the Internet.
X
To store a POI: select Save.
The POI can be saved as:
R
Home address
R
a navigable address book contact
Y page 106)
(
R
A personal destination on the SD card
Y page 81).
(
X
To start route calculation: to select Start
or Continue: turn and press the controller.
If Calculate Alternative Routes
is ena-
bled in the basic settings, the menu item
Continue
Start
is displayed instead of
(Y page 55).
Using the map
The complete address of the POI is shown.
To view the vicinity of the destination:
X
select : by turning and pressing the controller.
If street images are available, the street in the
vicinity of the destination address is shown.
X
To call up the map: select Map.
X
Move the map, change the map scale and
select the POI (
Y page 64).
:
Crosshair
;
Distance of crosshair position from current
vehicle position
X
To switch to navigation mode: press the
ß button.
X
To show the menu: slide 6 the controller.
X
To select Destination: turn and press the
controller.
X
Select Using Map.
The map with crosshair is shown.
X
To move the map: slide 1, 4 or 2
the controller.
X
To change the map scale: turn the controller
until the desired map scale is selected.
The scale is displayed at the bottom of the
display.
Destination entry
65
To enlarge the map: turn the controller counter-clockwise.
To zoom the map out: turn the controller
clockwise.
X
To select a destination: press the controller.
If several destinations are available in the
area around the crosshair, these are displayed. The list may show the Menu
menu
item.
X
Press the controller to show the menu.
X
To select a destination from the selection list:
turn and press the controller.
If the digital map provides navigable address
data, you will see the destination address in
the address entry menu.
X
To start route calculation: select Start .
Entering intermediate destinations
Introduction
You can also map the route to the destination
yourself by entering up to four intermediate destinations. The sequence of the intermediate destinations can be changed at any time.
The multimedia system provides a selection of
eight predefined POI categories, e.g. Restau‐
rants for a quick selection. You can also use the
destination entry options to enter intermediate
destinations.
Creating intermediate destinations
X
To switch to navigation mode: press the
Ø button.
X
To show the menu: slide 6 the controller.
X
To select Destination: turn and press the
controller.
X
Select Intermediate Destinations.
X
To select a POI category or Other : turn and
press the controller.
After selecting one of the eight POI categories, available POIs are displayed:
R
along the route
R
in the vicinity
The multimedia system first searches for destinations on the route. The search for destinations is then initiated in the area around the
current vehicle position.
X
After selecting Other, select one of the destination entry options.
Selection Step
X
Address Entry
Keyword
Search
From Previ‐
ous Destina‐
tions
From Contacts
Enter a destination by
address (
X
Select a destination
Y page 58).
using a keyword search
Y page 60).
(
X
Select a destination
from the list of last destinations (
X
Select a contact from
Y page 61).
the address book as the
Y page 62).
Y page 64).
From POIs
Using Map
From Memory
Card
From
MercedesBenz Apps
Using GeoCoordinates
destination (
X
Select a point of interest
Y page 62).
(
X
Enter a destination using
the map (
X
Select a personal POI
Y page 69).
(
X
Enter a destination from
Mercedes-Benz Apps
Y page 67).
(
X
Enter a destination using
the geo-coordinates
Y page 67).
(
Navigation
Z
Destination entry
66
X
To select a POI: turn the controller and press
to confirm.
After selecting a POI or entering a destination,
the address of the intermediate destination is
displayed.
After entering a destination using the map,
Navigation
the address entry menu is displayed. Start
highlighted.
To enter another intermediate destina-
X
tion: slide 5 the controller and highlight
Add New:
X
Press the controller.
X
Proceed as described above.
.
Editing intermediate destinations
The following editing options are available:
R
You can change intermediate destinations.
R
You can switch the sequence of the intermediate destinations in the intermediate destinations menu.
R
You can delete intermediate destinations.
is
X
To call up a map: select Map by turning and
pressing the controller.
You can move the map and select the destination.
X
To make a call: select Call.
If the intermediate destination has a telephone number and a mobile phone is connected to the multimedia system
Y page 93), the call is connected.
(
X
To load data from the Internet: select www.
If an Internet address is available, data is loaded from the Internet.
To store an intermediate destination in
X
the destination memory: select Save
(Y page 81).
To accept an intermediate destination:
X
select OK
by pressing the controller.
The destination is entered in the intermediate
destinations menu. Start Route Guidance
is highlighted.
X
To select an intermediate destination in the
intermediate destinations menu: turn and
press the controller.
A menu appears.
To change an intermediate destination:
X
select Edit
X
Select a new intermediate destination from a
category or via Other
X
To select OK: turn and press the controller.
in the menu.
.
The intermediate destinations menu appears
and displays the changed intermediate destination.
You can change the order of the intermediate
destinations entered and the destination. To
change the order, at least one intermediate destination and the destination must have been
entered.
X
To change the order: in the menu, select
.
Move
X
Turn the controller and move the intermediate
destination or destination to the desired position.
X
Press the controller.
To delete an intermediate destination:
X
select Delete
in the menu.
Destination entry
67
Accepting intermediate destinations
for the route
X
To select Start Route Guidance in the
intermediate destinations menu: press the
controller.
The route is calculated with the entered intermediate destinations.
If Calculate Alternative Routes
bled in the basic settings, the Continue
item is displayed (
Y page 55).
is ena-
menu
If an intermediate destination was passed
during route guidance, a green tick mark will
be entered in the intermediate destinations
menu. Once the route has been recalculated,
the intermediate destination is deleted from
the intermediate destinations menu.
Saving as a personal route
X
Insert the SD memory card (Y page 149).
X
To select Save As Personal Route in the
intermediate destinations menu: turn and
press the controller.
The route is saved on the SD card under Per‐
sonal Routes.
Searching for a gas station when the
fuel level is low
Requirement: the setting Gas on Reservemust
be enabled (
If the fuel tank reserve level is displayed, you will
see the Reserve Fuel Would you like to
start a search for surrounding gas
stations? message.
X
To select Yes or No: turn and press the controller.
If you select Yes
starts. When the search is complete, a list of
the gas stations available along the route or in
the vicinity is displayed.
If you select No
X
Select the gas station.
The address of the gas station is displayed.
X
To select Start: press the controller.
The gas station selected is set in the intermediate destinations menu as the next intermediate destination not yet reached. Route
guidance begins.
Y page 56).
: the gas station search
: the search is canceled.
Entering a destination from
Mercedes-Benz Apps
Requirement (USA): mbrace is activated for the
Mercedes-Benz Apps (
Requirement (Canada): a mobile phone is connected to the multimedia system via Bluetooth
(Y page 93) or USB (Y page 159).
X
To switch to navigation mode: press the
Ø button.
X
To show the menu: slide 6 the controller.
X
To select Destination: turn and press the
controller.
X
Select From Mercedes-Benz Apps.
The list of Mercedes-Benz Apps appears.
Y page 125).
Using geo-coordinates
X
To switch to navigation mode: press the
ß button.
X
To show the menu: slide 6 the controller.
X
To select Destination: turn and press the
controller.
X
Select Using Geo-Coordinates.
Geo-coordinates are entered in degrees,
minutes and seconds.
To enter the latitude and longitude coor-
X
dinates: turn the controller to change the
value.
X
To move the selection within the line: slide
1 the controller.
X
To move the selection between lines: slide
4 the controller.
X
To confirm the value: press the controller.
X
To save a destination: to select Save: turn
and press the controller.
The destination can be stored as:
R
a home address in the address book
R
a navigable address book contact
For further information on the address
book, see (
R
a personal destination on the SD card
Y page 81).
(
Starting route calculation
X
To select Start Route Guidance: turn and
press the controller.
Y page 106)
®
Navigation
Z
Personal POIs and routes
68
Personal POIs and routes
General notes
The use of personal POIs for displaying traffic
surveillance equipment is not permitted in every
country. Please observe the country-specific
regulations and always drive at a suitable speed.
Personal POIs are filed in categories:
R
Not Classified
Standard entry for personal POIs
R
Mercedes-Benz Apps
Personal POIs (destinations, routes) that you
have imported via the online functions
R
Categories which you have created yourself,
e.g. on your PC
Personal routes are not categorized.
Navigation
Settings for personal POIs
Displaying on the map
Requirements: an SD card with personal POIs is
inserted (
All personal POIs of the selected category are
displayed on the map with a corresponding symbol.
If the "Alert when approaching" function
Y page 68) is activated, the symbols are dis-
(
played up to a map scale of 2 km (2 mi).
X
X
X
X
X
X
Y page 149).
To switch to navigation mode: press the
ß button.
To show the menu: slide 6 the controller.
To select Options: turn and press the con-
troller.
Select Personal POIs.
Select Display on the Map.
The menu displays the categories available on
the SD card.
To select a category: turn the controller and
press to confirm.
All personal POIs in the selected category are
displayed O or not displayed ª, depending
on the previous status.
Alert when approaching
Requirements: an SD card with personal POIs is
inserted (
Y page 149).
If the vehicle is approaching a personal POI and
the functions are enabled, the personal POI is
highlighted on the map and an audible signal
sounds.
For this purpose, both the corresponding function Approaching POI Cue
and the category
containing the personal POI must be activated.
X
To switch to navigation mode: press the
ß button.
X
To show the menu: slide 6 the controller.
X
To select Options: turn and press the controller.
X
Select Personal POIs.
X
Select Approaching POI Cue.
The menu displays the categories available on
the SD card.
X
Select Audible or Optical.
The function is switched on O or off ª,
depending on the previous status.
X
To select a category: turn the controller and
press to confirm.
The function is switched on O or off ª, for
all personal POIs of this category, depending
on the previous setting.
Saving personal POIs and routes
General notes
Personal POIs and routes are geodata which are
saved in open GPX format (GPS Exchange format) on the SD card.
Personal POI from current vehicle position or crosshair position
X
Insert the SD memory card (Y page 149).
X
To switch to navigation mode: press the
ß button.
X
When the map is displayed, press the controller until a message appears.
The current vehicle position is saved to the
Not Classified
and also stored in the "Last destinations"
memory (
Y page 82).
If the "Move map" function is selected
Y page 54), the crosshair position is saved.
(
If no SD card is inserted, the personal POI
i
will only be stored in the "Last destinations"
memory.
category on the SD card
Personal POIs and routes
69
Personal POI from destination address
X
Insert the SD memory card (Y page 149).
X
To switch to navigation mode: press the
ß button.
X
Call up the address entry menu and enter the
destination address (
X
To select Save: slide 6 the controller.
X
Turn and press the controller.
X
To select To Memory Card: turn and press
Y page 57).
the controller.
X
Enter the name.
The current address is saved in the Not
Classified category on the SD card.
You can select a destination from the From
i
Previous Destinations or From Contacts
memories and save it on the SD card.
R
From Previous Destinations
(Y page 61)
R
From Contacts (Y page 62)
Personal route from a tour including
intermediate destinations
X
Insert the SD memory card (Y page 149).
X
To switch to navigation mode: press the
ß button.
X
Enter a destination, e.g. by address
Y page 57).
(
X
Start route calculation (Y page 59).
X
Create intermediate destinations (Y page 65).
X
To select Save As Personal Route in the
intermediate destinations menu: turn and
press the controller.
The route is saved in the Personal Routes
folder on the SD card.
used by the multimedia system. Points on the
route may therefore be situated off the digital
roads.
R
The Mercedes-Benz Apps minimize the number of route points offered.
For this reason an imported route commenced in the multimedia system may deviate from the original route from the
Mercedes-Benz Apps.
Selecting and editing personal POIs
and routes
Selecting
X
Insert the SD memory card (Y page 149).
X
To switch to navigation mode: press the
ß button.
X
To show the menu: slide 6 the controller.
X
To select Destination: turn and press the
controller.
X
Select From Memory Card.
X
To select a category or Personal Routes:
turn and press the controller.
The available personal POIs or route entries
are displayed.
X
Select personal POI or personal route.
The address of the personal POI appears or
the personal route is displayed in the map.
If a large number of entries are stored, a register
for quick selection appears. Personal POIs and
routes can be stored with different character
sets (e.g. Latin, Cyrillic, Arabic).
X
To select a register: slide 9 the control-
ler.
X
Select a character by turning the controller.
Navigation
Importing personal POIs and routes
via Mercedes-Benz Apps
You can use Mercedes-Benz Apps (e.g. Download POI) to import destinations to the navigation system. These have their own symbol and
are filed in the Mercedes-Benz Apps
You can save the imported destinations and
routes as personal POIs and routes (
When importing routes, please note:
R
The Mercedes-Benz Apps may generate a
route based on a different map from the one
category.
Y page 68).
Editing
Z
Personal POIs and routes
70
The example shows a personal route.
X
Select personal POI or personal route
Y page 69).
(
X
To explore a personal POI or route: slide
5 and press the controller to select Map
The map with the crosshair appears and
shows the destination.
X
Scroll the map (Y page 54).
X
Set the map scale (Y page 83).
X
To return to the menu: press the % button.
X
To call the personal POI: turn and press the
controller to select Call
.
If a mobile phone is connected to the multimedia system and the telephone number is
available, the call is connected (
X
To change the name: turn and press the
Navigation
controller to select Edit
X
Select Change Name or Edit Icon.
X
To change name: enter character (Y page 30).
X
To delete a personal POI or route: turn and
Y page 99).
.
press the controller to select Delete
A prompt will appear.
X
Select Yes or No.
If you select Yes
, the personal destination or
personal route is deleted.
To select the outward and return routes:
X
select Swap
by turning and pressing the controller.
The starting and destination positions of your
personal route, and thus the direction for
route guidance, are switched round. One-way
streets or restricted intersections are taken
into consideration. Therefore, the outward
and return routes may differ from each other.
X
To save a personal POI: turn and press the
controller to select Save
X
Continue saving (Y page 81).
X
To start route guidance: select Start by
.
turning and pressing the controller.
Recording the route
General notes
When recording the route, bear in mind the fol-
.
lowing:
R
If the SD card is inserted, it must not be
removed during recording.
R
If route recording is started manually, it must
be finished manually before the multimedia
system is switched off.
R
The multimedia system minimizes the number of route points recorded. Therefore when
the recorded route is subsequently commenced, it may differ from the route that was
originally recorded.
Starting/finishing route recording
X
Insert the SD memory card (Y page 149).
X
To switch to navigation mode: press the
.
ß button.
X
To show the menu: slide 6 the controller.
X
To select Destination: turn and press the
controller.
X
Select From Memory Card.
X
Select Start Route Recording.
The route is recorded and REC
appears at the
bottom edge of the screen.
X
To stop recording, select End Route
Recording from the menu.
The route is stored under Personal Routes
.
Displaying/editing the recorded route
X
Insert the SD memory card (Y page 149).
X
To switch to navigation mode: press the
ß button.
X
To show the menu: slide 6 the controller.
Route guidance
71
X
To select Destination: turn and press the
controller.
X
Select From Memory Card.
X
Select Personal Routes.
Previously recorded routes are displayed.
X
To select a route: turn and press the controller.
The map appears with a menu. The recorded
route is shown on the map in blue.
X
To start route calculation: select Start .
X
To change the name and symbol: select
.
Edit
X
Select Change Name or Edit Icon.
X
To change name: enter character (Y page 30).
X
To change symbol: select a symbol.
The symbol is saved.
Route guidance
General notes
Always observe the traffic regulations when
driving. Road and traffic rules and regulations
always have priority over system driving recommendations.
The multimedia system calculates the route to
the destination without taking account of the
following, for example:
R
traffic lights
R
stop and yield signs
R
parking or stopping restrictions
R
road narrowing
R
temporary traffic rules and regulations
The multimedia system may give differing navigation commands if the actual street/traffic situation does not correspond with the digital
map's data. For example, if the road layout or
the direction of a one-way street has been
changed.
Route guidance begins once a route has been
calculated (
The multimedia system guides you to your destination by means of navigation announcements
in the form of audible navigation announcements and route guidance displays.
Navigation messages guide you during the journey without distracting you from traffic conditions or driving. Please always use this feature
instead of consulting the map display for direc-
Y page 59).
tions. The symbols or the map display could distract you from traffic conditions and driving.
The route guidance displays can be seen if navigation mode is switched on.
If you do not follow the navigation announcements or if you leave the calculated route, the
multimedia system automatically calculates a
new route to the destination.
If the digital map contains the corresponding
information, the following applies:
R
During route guidance, the multimedia system tries to avoid roads with restricted
access. These include, for example, roads
which are closed to through-traffic.
R
Roads that have time restrictions (e.g. closed
on Sundays and public holidays) are considered for route guidance on days when they are
open. For this purpose, the relevant times
must be correctly stored in the database.
Change of direction
Overview
Changes of direction have three phases:
R
Preparation phase
R
Announcement phase
R
Change-of-direction phase
Changes in direction are also shown in the multifunction display of the instrument cluster (see
the vehicle Operator's Manual).
Preparation phase
The multimedia system prepares you for the
upcoming driving maneuver, e.g. with the
announcement "Prepare to turn right". You see
the full-screen map.
Navigation
Z
Route guidance
72
Announcement phase
:
Point at which the change of direction takes
place (white dot)
;
Change of direction (turn right here)
=
Distance to the next change of direction
Navigation
The multimedia system announces the imminent change of direction. The change of direction is announced ahead of time, with the
announcement "Turn right in 300 meters", for
example.
The display is now split into two sectors. The
map is shown on the left side of the display, and
a detailed image of the intersection or a 3D
image of the imminent change of direction is
shown on the right side of the display.
Change-of-direction phase
When the change of direction is completed, the
map will appear in full screen mode again.
Display on highways
The image shows an example of route guidance
at a highway intersection when driving on a
highway.
Lane recommendations
Display on multi-lane roads
The multimedia system announces the immediate change of direction. The change of direction
is announced ahead of time, e.g. with the
announcement "Now turn right".
The display is split in two like in the announcement phase.
The change of direction is performed when the
light-colored bar on the right drops down to 0 ft
and the current vehicle position symbol has
reached the white change-of-direction point.
:
Lanes not recommended (dark gray)
;
Possible lane (light gray)
=
Recommended lanes (white)
If the digital map contains the relevant data, the
multimedia system can display lane recommendations on multi-lane roads for the next change
of direction.
Lane not recommended :: you will not be able
to complete the next change of direction if you
stay in this lane.
Possible lane ;: you will be able to complete
the next change of direction in this lane.
Recommended lane =: in this lane you will be
able to complete the next change of direction
and the one after that.
Route guidance
73
Lane recommendations are also shown in the
multifunction display of the instrument cluster
(see the vehicle Operator's Manual).
Approaching new lanes
:
Approaching new lane
During the change of direction, new lanes may
be added. These will be shown in the display of
lane recommendations with a lower boundary
line.
Highway information
Display mode
Calling up the selection mode
X
When highway information is displayed, slide
9 the controller.
The marker is on the highway information. The
associated position is highlighted on the map.
X
To select the desired rest stop/freeway exit:
turn and press the controller.
The available POIs are displayed.
Starting route guidance to a POI
Navigation
Requirement: the Highway Information map
content must be enabled (
Y page 85).
While driving on the highway, gas stations, rest
stops, rest areas and highway exits are displayed along with their immediate distances
from the current vehicle position.
Highway information enables route guidance to
a POI and other functions.
X
To select a POI: turn the controller and press
to confirm.
The POI details are displayed.
You can perform the following functions:
R
Storing in the address book (Y page 81)
R
Save to the SD card (Y page 81)
R
Viewing on the map (Y page 86)
R
Calling if a mobile phone is connected and
a phone number is available (
R
USA: viewing the vicinity of the destination
Y page 99)
if street images are available and mbrace is
activated for Internet access
Y page 125)
(
R
Canada: view the vicinity of the destination
if street images are available and a mobile
Z
Route guidance
74
phone is connected to the multimedia system via Bluetooth
Y page 159)
(
R
USA: download data from the Internet if an
®
(Y page 93) or USB
Internet address is available and mbrace is
activated for Internet access
Y page 93)
(
R
Canada: download data from the Internet if
an Internet address is available and a
mobile phone is connected to the multimedia system via Bluetooth
Y page 159)
USB (
R
Select for route guidance and calculate a
route to it (
Y page 59)
®
(Y page 93) or
Using the traffic jam function
Navigation
Highway information enables the use of the traffic jam function. The remaining route on the
highway in this case is blocked in the direction of
travel from the selected exit.
X
To select Detour: turn and press the controller.
The traffic jam function appears
Y page 76).
(
Destination reached
Once the destination is reached, you will see the
checkered flag. Route guidance is finished.
Navigation announcements
Repeating navigation announcements
If you missed the current navigation announcement, you can call it up again.
X
To switch to navigation mode: press the
Ø button.
X
To show the menu: slide 6 the controller.
X
To select +: turn and press the controller.
If you previously assigned the Repeat Spo‐
i
ken Driving Recommendations function to
the Favorites button, you can select the function using the Favorites button instead
Y page 41).
(
Setting the volume manually
X
During a navigation announcement, turn the
q control knob.
When you start the engine, the volume will
i
be at its lowest setting.
Switching navigation announcements
on/off
To deactivate navigation announcements:
X
during a navigation announcement, press the
8 button on the control panel.
or
X
During a navigation announcement, press the
8 button on the multifunction steering
wheel.
The Spoken driving recommendations
have been deactivated. message
appears.
To switch navigation announcements
X
back on: slide 6 the controller.
X
To select +: turn and press the controller.
The multimedia system automatically switches
the navigation announcements back on when:
R
a new route is calculated
R
the multimedia system is switched back on
R
you start the vehicle
A navigation message is given if the route is
recalculated during dynamic route guidance due
to new traffic reports (
Y page 77).
Canceling/continuing route guidance
Canceling route guidance
X
Slide 6 the controller.
The menu is shown.
X
To select Destination, turn and press the
controller.
X
Select Cancel Route Guidance.
The blue route line is no longer shown on the
map.
Resuming route guidance
X
Slide 6 the controller.
The menu is shown.
X
To select Destination: turn and press the
controller.
X
Select Continue Route Guidance.
The multimedia system calculates the route.
Route guidance
X
Select Destination Information.
The destination and existing intermediate
destinations are displayed with distances,
travel time and arrival time.
To select destination or intermediate des-
X
tination: turn and press the controller.
The address appears.
You can use these functions for the destination or intermediate destination:
R
Storing in the address book (Y page 81)
R
Saving to the SD card (Y page 81)
R
Viewing on the map (Y page 86)
R
Calling if a mobile phone is connected and
a phone number is available (
R
USA: viewing the vicinity of the destination
if street images are available and mbrace is
activated for Internet access
Y page 125)
(
R
Canada: viewing the vicinity of the destination if street images are available and a
mobile phone is connected to the multimedia system via Bluetooth
Y page 159)
USB (
R
USA: download data from the Internet if an
Internet address is available and mbrace is
activated for Internet access (
R
Canada: download data from the Internet if
an Internet address is available and a
mobile phone is connected to the multimedia system via Bluetooth
Y page 159)
USB (
Y page 99)
®
(Y page 93) or
Y page 93).
®
(Y page 93) or
75
Navigation
Route information
Destination information
X
To switch to navigation mode: press the
Ø button.
X
To show the menu: slide 6 the controller.
X
To select Route: turn and press the controller.
Taking an alternative route
If the Calculate Alternative Routes setting
is activated O, different routes will be offered
each time a route is calculated (
You can call up alternative routes to the current
route.
Y page 55).
Z
Route guidance
76
Route 1 is calculated with the current settings
for the route type and route options and shown
with a dark blue line.
Routes 2 and 3 are alternatives to route 1 and
also displayed with a dark blue line.
Route 4 is the most economic route and is displayed with a green line.
X
To switch to navigation mode: press the
Ø button.
X
To show the menu: slide 6 the controller.
X
To select Route, turn and press the controller.
X
Select Alternative Route.
Route 1 is shown.
X
To display additional routes: select Next or
Previous
X
To start a new route guidance: select
Navigation
Start
.
.
Route list
Where am I?
X
To switch to navigation mode: press the
Ø button.
X
To show the menu: slide 6 the controller.
X
To select Position: turn and press the controller.
X
Select Where am I?.
The street you are currently on and the previous and next intersections are displayed.
Traffic jam function
X
To switch to navigation mode: press the
Ø button.
X
To show the menu: slide 6 the controller.
X
To select Route, turn and press the controller.
X
Select Route List.
The route list shows the next change of direction and the immediate distances from the
current vehicle position.
X
To display additional route sections: turn
the controller.
The position of the change of direction that
belongs to the respective route section is
indicated on the map with a cross.
X
To switch to navigation mode: press the
Ø button.
X
To show the menu: slide 6 the controller.
X
To select Route, turn and press the controller.
X
Select Detour.
To specify the start of the traffic jam sec-
X
tion: select Beginning
.
The next possible traffic jam section starting
point is marked.
X
Turn the controller.
The marking moves along the route to the
next starting position.
X
Press the controller.
The start of the traffic jam is set.
To specify the end of a traffic jam section:
X
select End
The next possible traffic jam section end point
is marked.
X
Turn the controller.
The marking moves along the route to the
next end position.
X
Press the controller.
The end of the traffic jam is determined.
X
To calculate the detour: select Start.
.
Off-road
General notes
The multimedia system may guide you to offroad routes that your vehicle cannot drive on
without causing damage to the tires and wheels,
or the vehicle itself. It is the driver’s sole responsibility to determine the suitability of the route.
The state and navigability of off-road routes may
be influenced, for example, by factors such as
time of day, time of year and current weather
conditions. The multimedia system cannot
judge these factors or take them into account
for route guidance.
Real-time traffic reports
system is able to guide you to a destination even
from an off-road location.
At the start of route guidance, you will see the
Road Not Mapped
distance to the destination. The arrow shows
the compass heading to the actual destination.
As soon as the vehicle is back on a road known
to the system, route guidance continues in the
usual way.
Off-road during route guidance
Due to road construction, for example, there
may be differences between the data on the
digital map and the actual course of the road.
In such cases, the system will temporarily be
unable to locate the vehicle position on the digital map. The vehicle is therefore in an off-road
position.
In the display, you will then see the Road Not
Mapped message, an arrow and the distance to
the destination. The direction arrow shows the
compass heading to the destination.
As soon as the system can assign the vehicle
position to the map again, route guidance continues in the usual way.
message, an arrow and the
77
Navigation
Route guidance to an off-road destination
The multimedia system can guide you to destinations which are within the area of the digital
map, but which are not themselves on the map.
These destinations are known as off-road destinations, which you can enter using the map, for
example. In these cases, the multimedia system
guides you for as long as possible with navigation announcements and displays on roads
known to the system.
If the vehicle reaches an area which is not part of
the digital map, the display appears as a splitscreen view. On the right, an arrow appears that
points to the off-road destination. You hear the
announcement: "Please follow the arrow on the
display". As the vehicle approaches the destination, you will see a display to this effect.
Route guidance from an off-road location to a destination
Off-road location: the vehicle's position is on the
digital map, but the map does not contain any
information about that location. The multimedia
Real-time traffic reports
Requirements
In order to receive real-time traffic reports via
satellite radio, you need to subscribe to SIRIUS
XM Satellite Radio Traffic Message Service.
Further information on satellite radio
Y page 138).
(
The multimedia system can receive traffic
reports via satellite radio and take account of
these for route guidance in the navigation system. Received traffic reports are displayed on
the map either as text or as symbols.
Z
Real-time traffic reports
78
Real-time traffic reports on the map
Traffic reports are shown on the map with symbols and colored lines. The symbols indicate the
type of traffic report and the colored lines show
the extent of the area affected by the traffic
Navigation
incident. The symbols are shown in map scales
from 1/32 miles (20 m) to 10 miles (10 km).
When : is displayed, traffic reports can be
received or traffic reports are available. If it is
not displayed, no reception is possible.
X
To hide the menu: slide 5 and press the
controller.
The map can be seen in the full-screen display.
X
To set the map scale: turn the controller until
the desired map scale is selected.
The legend shows the symbolic traffic messages on the map.
D
Slow-moving traffic (orange line along the
affected route)
E
Traffic jam (red line along the affected route)
Displaying real-time traffic reports
Starting a search for traffic reports
X
To switch to navigation mode: press the Ø
button.
X
To show the menu: slide 6 the controller.
X
To select Traffic: turn and press the controller.
X
To close the report: press the controller.
Traffic symbol information
:
Traffic jam on the route
;
Slow-moving traffic on the route
=
Road blocked
?
Traffic jam
A
Traffic warning
B
Dashed red and white line delimiting the
traffic warning
C
Road block (red crosses along the affected
road)
:
Affected roads with indication of direction
;
Symbol for report type, e.g. traffic flow message
X
To switch to navigation mode: press the Ø
button.
X
To show the menu: slide 6 the controller.
X
To select Traffic: turn and press the controller.
Real-time traffic reports
79
X
To select Traffic Symbol Information:
turn and press the controller.
The map appears and shows the available
traffic information as icons. The first traffic
information is highlighted.
X
To highlight additional traffic symbols, select
or Previous.
Next
X
To move the map: select Map.
You can move the map to enable further traffic information to be displayed.
You can have the traffic report relevant to a traffic icon shown.
X
To select Details: turn and press the controller.
The report shows the following information:
R
State/province, road and display of the affected direction
R
Section of the road to which the traffic report
applies
R
Traffic icon and traffic report
X
To close the detailed display: press the %
button.
If there are no reports for the route or the function is not supported in the selected language:
the Messages
On Route menu item is gray and
cannot be selected.
X
To switch to navigation mode: press the Ø
button.
X
To show the menu: slide 6 the controller.
X
To select Traffic: turn and press the controller.
X
To select Messages On Route: turn and
press the controller.
The traffic report window appears. Several
traffic reports may be available for the calculated route, marked for example by 1/4.
The report shows the following information:
R
State/province, road and display of the
affected direction
R
Section of the road to which the traffic
report applies
R
Traffic icon and traffic report
To display the next/previous traffic
X
report: turn the controller.
X
To close the display: press the % button.
Displaying all traffic reports
Navigation
Displaying reports on the route
The function is only available while route guidance is active. It shows the available traffic
reports affecting the current route.
X
To switch to navigation mode: press the Ø
button.
X
To show the menu: slide 6 the controller.
X
To select Traffic: turn and press the controller.
X
To select All Messages: turn and press the
controller.
A list is shown containing all roads, areas or
regions affected by traffic reports. Roads,
areas or regions not on the route also appear
in the list.
Z
Real-time traffic reports
80
X
To select the road, area or region: turn the
controller and press to confirm.
The traffic report is displayed (
Y page 79).
There may be several traffic reports for the
affected road.
X
To close the display: press the % button.
Activating/deactivating traffic information on the map
You can switch the following traffic information
on the map on/off:
R
Incidents
R
Speed & Flow
R
Free Flow
X
To switch to navigation mode: press the Ø
Navigation
button.
X
To show the menu: slide 6 the controller.
X
To select Traffic: turn and press the controller.
X
To select Traffic Information On Map:
turn and press the controller.
X
Select Incidents, Speed & Flow or Free
Flow.
The display is on O or off ª.
Reading out traffic reports on the
route
Introduction
The text reader function is only available while
route guidance is active. It reads out traffic
reports affecting the current route.
You can select from the following text reader
properties:
R
Language (Y page 41)
R
Text reader speed (Y page 37)
You can start the text reader function manually
or set it to automatic.
Starting the text reader function manually
X
To switch to navigation mode: press the Ø
button.
X
To show the menu: slide 6 the controller.
X
To select Traffic: turn and press the controller.
X
Select Read Out All Messages on Route.
The multimedia system reads out the reports
in sequential order.
If there are no reports for the route, the Read
Out All Messages on Route menu item is
gray and cannot be selected.
X
To cancel the read-aloud function: select
Cancel Read-Aloud Function
.
The multimedia system reads the current
report aloud and then exits the read-aloud
function.
Automatic text reader function
X
To switch to navigation mode: press the Ø
button.
X
To show the menu: slide 6 the controller.
X
To select Traffic: turn and press the controller.
X
Select Read Traffic Announcements
Automatically.
Depending on the previous state, switch the
option on O or off ª.
Recalculating the route dynamically
Route types Dynamic Traffic Route and
Dynamic TRF. Route After Request
into account all of the traffic reports they receive
for the current route when calculating the route
Y page 55).
(
If you have selected Dynamic Traffic Route
as the route type, the multimedia system guides
you to your destination along the updated route.
If you have selected the route type Dynamic
TRF. Route After Request, a prompt will first
appear.
You can now decide whether to:
R
accept the detour proposed by the multimedia system or
R
continue your original route
X
To accept the proposed detour: press the
controller.
X
To reject the proposed detour and continue
with the original route: turn the controller and
press to confirm.
The original route is continued.
take
Storing destinations
81
Storing destinations
General notes
In the "Last destinations" memory, the following
are stored:
R
destinations and intermediate destinations
according to the route calculation
R
the current vehicle position or the crosshair
position, if these are saved
R
personal routes
If the memory is full, the oldest destination is
overwritten.
You can save destinations permanently in the
address book (
Y page 81). For instance, this is possible
(
Y page 81) and on an SD card
immediately after entering an address.
For further information on the address book, see
Y page 105)
(
Storing the destination in the address
book
Storing as a new contact
The example shows a POI.
X
To select Save: turn and press the controller.
A menu appears.
X
Select As New Contact.
X
Select Not Classified, Home or Work.
An input menu shows the destination
address.
X
Enter a surname and first name. Character
Y page 29).
entry (
X
To select OK: turn and press the controller.
The Saving Successful
The destination address is saved in the
address book as a navigable contact.
message appears.
Adding to a contact
The example shows a POI.
Requirement: the address book contains con-
tacts.
X
To select Save: turn and press the controller.
A menu appears.
X
Select Add to Contact.
The address book appears.
X
Search for a contact (Y page 106).
X
Press the controller.
The Saving Successful
message appears.
The destination address is allocated to a contact in the address book.
Telephone numbers are not transferred to the
telephone number fields of the address book.
After selecting the destination address from
the address book for navigation, the associated telephone number will be displayed.
If the contact already has two destination
addresses, a prompt will appear asking if a
destination address should be overwritten.
X
Select Yes or No.
If you select Yes
, a list showing both destina-
tion addresses appears.
X
To select the destination address: turn and
press the controller.
The destination address is overwritten.
Saving a destination to an SD card
X
Insert the SD memory card (Y page 149).
X
Display a POI, for example.
X
To select Save: turn and press the controller.
A menu appears.
X
Select To Memory Card.
X
Select Not Classifiedor, if available, select
a category that you have created yourself.
An input menu appears.
Navigation
Z
Storing destinations
82
X
Enter a surname and first name. Character
Y page 30).
entry (
X
Select OK.
The Saving Successful
message appears.
The destination is saved to the SD card.
Saving the current vehicle position
Using the map
X
To switch to navigation mode: press the
ß button.
X
When the map is shown, press and hold the
COMAND controller until you hear a tone.
The current vehicle position is saved to the
"Last destinations" memory.
Navigation
If an SD card is inserted, the current vehicle
position will also be saved in the Not Clas‐
sified category.
Using the menu
X
To switch to navigation mode: press the
ß button.
X
To show the menu: slide 6 the controller.
X
To select Position: turn and press the controller.
X
Select Save.
X
Store the destination in the address book
Y page 81).
(
X
Save the destination to the SD card
Y page 81).
(
Saving the crosshair position
X
To switch to navigation mode: press the
ß button.
X
To display the crosshair: press the controller.
X
Move the map to the desired position
Y page 54).
(
X
To show the menu: press the controller.
X
To select Position: turn and press the controller.
X
Select Save.
The current crosshair position is saved to the
"Last destinations" memory.
If an SD card is inserted, the current crosshair
position will also be saved in the Not Clas‐
sified category.
Editing the last destinations
X
To switch to navigation mode: press the
ß button.
X
To show the menu: slide 6 the controller.
X
To select Destination: turn and press the
controller.
X
Select From Previous Destinations.
The "Last destinations" memory appears.
X
To save the destination: select the destination.
The destination address appears.
X
Store the destination in the address book
Y page 81).
(
X
Save the destination to the SD card
Y page 81).
(
X
To view the details: while in the "Last destinations" memory, turn the controller and
highlight the entry.
X
Slide 9 the controller.
A menu appears.
X
To select Details: press the controller.
The destination address can be changed if
i
desired.
X
To delete one or all destinations: while in
the "Last destinations" memory, turn the controller and highlight the entry.
X
Slide 9 the controller.
A menu appears.
Map functions
83
X
To select Delete or Delete All: turn and
press the controller.
A prompt appears.
X
Select Yes or No.
Selecting Yes
deletes the selected destina-
tion or all destinations.
Map functions
General notes
Company logos displayed on the map are trademarks of the respective companies and used
solely for the purpose of indicating the locations
of these companies. The use of such logos on
the map does not indicate approval of, support
of or advertising by these companies for the
navigation system itself.
Map settings
Setting the map scale
X
To set the map scale: as soon as you turn the
controller, the scale bar appears on the bottom of the display.
X
Turn the controller until the needle points to
the desired map scale.
Once you are finished selecting a map scale,
the new map scale will be shown.
Selecting map orientation
X
To switch to navigation mode: press the
ß button.
X
To show the menu: slide 6 the controller.
X
To select Options: turn and press the controller.
X
Select Map Orientation.
The # dot indicates the current setting.
X
Turn and press the controller.
The map orientation is set.
Navigation
Requirement: the map is in full screen mode, the
menu is faded out (
Y page 54).
The lower left-hand section of the map shows
the currently set map scale and compass needle.
Right-hand-drive vehicles: the currently set map
scale and compass needle are displayed in the
lower right-hand section of the map.
X
To show the map in full screen mode: to
hide the menu, push the % button.
or
X
Slide the controller to the center of the map
and press to confirm.
The image is an example of the 3D map display
with crosshair.
Z
Map functions
84
Change
Explanation
map direction
North Up
0 The map view is displayed
so that north is always up.
Heading Up
¤ The map view is aligned to
the direction of travel. The
direction of travel is always at
the top; the red tip of the sym-
bol points north.
3-D Map
¤ The map view is aligned to
the direction of travel. The
map displays a 3D oblique
view with elevation; the red tip
of the symbol points north.
Navigation
Selecting POI symbols on the map
POIs can be displayed as symbols in the map
display. POIs include, for example, gas stations,
hotels and restaurants.
X
To switch to navigation mode: press the
ß button.
X
To show the menu: slide 6 the controller.
X
To select Options: turn and press the controller.
X
Select Map Content.
X
Select POI Symbols On Map.
The # dot indicates the current setting.
X
Turn and press the controller.
Default Symbols
fined categories in the map.
Custom
Symbols allows symbols to be selec-
ted from other/all available categories.
X
Turn and press the controller.
You have the option of selecting symbols to
be displayed O or not displayed ª on the
map.
shows symbols of prede-
The list shows all symbols that are contained on
the digital map across all countries. However,
not all points of interest are available in all countries. As a result, certain point of interest symbols may not be displayed on the map, even if
the symbol display is switched on.
Selecting text information on the map
At the bottom of the display, you can specify
whether to display geo-coordinates or not to
display text information for the street you are
currently on.
X
To switch to navigation mode: press the
ß button.
X
To show the menu: slide 6 the controller.
X
To select Options: turn and press the controller.
X
Select Map Content.
X
Select Text Information On Map.
The # dot indicates the current setting.
X
Turn and press the controller.
Current
Street shows the current street at
the bottom of the display.
Geo-coordinates
shows the longitude and
latitude, elevation and number of satellites
received.
The elevation shown may deviate from the
actual elevation.
X
Turn and press the controller.
Displaying the range on the map
The range can be displayed on the map for electric vehicles. A circle appears around the current
vehicle position.
For further information on range, see the vehicle
Operator's Manual.
X
To switch to navigation mode: press the
ß button.
X
To show the menu: slide 6 the controller.
X
To select Options: turn and press the controller.
X
Select Map Content.
X
Select Range on Map.
Switch the display in the map on O or off ª.
Switching highway information on/off
While driving on the highway, gas stations, rest
stops, rest areas and highway exits are displayed along with their immediate distances
from the current vehicle position (
X
To switch to navigation mode: press the
ß button.
X
To show the menu: slide 6 the controller.
X
To select Options: turn and press the controller.
X
Select Map Content.
X
Select Highway Information.
Switch the display in the map on O or off ª.
Y page 73).
Map functions
X
To select Options: turn and press the controller.
X
Select Map Content.
X
Select Map Version.
Information on the current map version is
shown. Information about new versions of the
digital map can be obtained from an authorized Mercedes-Benz Center.
Rotating the 3D map
85
Traffic Sign Assist
The function is available depending on the
equipment installed in the vehicle.
The map shows traffic signs detected by Traffic
Sign Assist (see the vehicle Operator's Manual).
X
To switch to navigation mode: press the
ß button.
X
To show the menu: slide 6 the controller.
X
To select Options: turn and press the controller.
X
Select Map Content.
X
Select Traffic Sign Assist.
Switch the display in the map on O or off ª.
Displaying the next crossroads
If route guidance is not active, the next crossroads can be displayed at the upper edge of the
display.
X
To switch to navigation mode: press the
ß button.
X
To show the menu: slide 6 the controller.
X
To select Options: turn and press the controller.
X
Select Map Content.
X
Select Next Intersecting Street.
Switch the display in the map on O or off ª.
You can use this function to explore the vicinity
of the destination in a 3D view. The function is
available in all map scales.
X
To switch to navigation mode: press the
Ø button.
X
To show the menu: slide 6 the controller.
X
To select Position: turn and press the controller.
X
Select 3D Map Rotation.
X
Turn the controller to change to the 3D map
perspective.
Additional functions:
R
Moving the map (Y page 54)
Navigation
Showing the map version
X
To switch to navigation mode: press the
ß button.
X
To show the menu: slide 6 the controller.
Z
Map functions
86
Map display
Displaying the navigation map
The multimedia system shows the navigation
map in globe projection. This allows for a real-
Navigation
istic map display free from distortion in all map
scales.
Satellite maps are shown in map scales from
2 miles to 1000 miles.
Other functions:
R
Moving the map (Y page 54)
R
Changing the map scale (Y page 83)
Building images
In small map scales (1/32 mile, 1/16 mile),
important buildings are depicted realistically on
the map. Other buildings are shown as models.
deactivate a route block while route guidance is
inactive, the multimedia system will use the new
setting for the next route guidance.
The calculated route may include an area to be
avoided if:
R
your destination is located in such an area
R
there is no alternative route available
Highways within blocked areas are always taken
into consideration in the route calculation.
Avoiding a new area
X
To switch to navigation mode: press the
Ø button.
X
To show the menu: slide 6 the controller.
X
To select Options: turn and press the controller.
X
Select Route Settings.
X
Select Avoid Options.
X
Select Avoid Area.
X
Select Avoid New Area.
A menu appears.
X
Select Using Map or Address Entry.
If you select Using Map
hair appears.
If you select Address Entry
entry menu appears where you can enter the
address (
Y page 57). The map appears with
the crosshair after the address is entered.
, the map with cross-
, the address
Avoiding an area
General notes
The multimedia system enables you to avoid
areas you do not wish to drive through.
If you activate or deactivate a route block while
route guidance is active, the multimedia system
will calculate a new route. If you activate or
X
To select an area: when the map with crosshair appears, press the controller.
A red square appears on the map, symbolizing
the area to be blocked.
X
To change the size of the area, turn the controller.
The map scale is shown at the bottom of the
display. The needle points to the map scale
currently selected.
X
When the desired size is set, press the controller.
The area is entered into the list.
Turning an area on/off and displaying/
changing the area
X
To switch to navigation mode: press the
ß button.
X
To show the menu: slide 6 the controller.
X
To select Options: turn and press the controller.
X
Select Route Settings.
X
Select Avoid Options.
X
Select Avoid Area.
A list appears.
X
To switch an area to avoid on/off: select an
area to mark by turning and pressing the controller.
The area will be avoided O or not ª.
Map functions
X
To display/change an area: mark an area by
turning the controller.
X
Slide 9 the controller.
X
To select Display/Change: press the controller.
The map with the crosshair appears.
The area currently blocked is displayed as a
red square.
X
To move the area to a new location: slide
1, 4, 2 the controller.
X
To change the size of the area, press the controller.
X
Turn the controller.
X
To apply the changes, press the controller.
A message appears stating that the area has
been set.
Deleting one/all areas
X
To switch to navigation mode: press the
ß button.
X
To show the menu: slide 6 the controller.
X
To select Options: turn and press the controller.
X
Select Route Settings.
X
Select Avoid Options.
X
Select Avoid Area.
A list appears.
X
To delete an area: mark an area by turning
the controller.
X
Slide 9 the controller.
X
Select Delete or Delete All.
A prompt appears asking whether you wish to
delete the area.
X
Select Yes or No.
After selecting Yes
X
To delete all areas: when the list appears,
slide 9 the controller.
X
Select Delete All.
A prompt appears asking whether you wish to
delete all areas.
X
Select Yes or No.
After selecting Yes
, the area is deleted.
, all areas are deleted.
87
Navigation
Z
Map functions
88
SIRIUS XM service
Displaying SIRIUS XM service information
You can display the SIRIUS XM service information.
X
To switch to navigation mode: press the
Ø button.
X
To show the menu: slide 6 the controller.
X
To select Traffic: turn and press the controller.
X
Select SIRIUS Service.
The provider's phone number (SIRIUS XM)
and the serial number of your service module
are displayed.
Navigation
Registering the SIRIUS XM service
X
Call the provider telephone number shown on
the multimedia system display.
You can also have the satellite service acti-
i
vated online. To do so, visit the SIRIUS XM
Radio website at http://www.sirius.com
(USA).
Once the connection has been established:
X
Follow the service employee's instructions.
The activation process may take up to ten
minutes.
If registration is not included when purchasing
the system, your credit card details will be
required to activate your account.
Updating the digital map
Introduction
The digital maps generated by the map software
become outdated in the same way as conventional road maps. Optimal route guidance can
only be provided by the navigation system in
conjunction with the most up-to-date map software.
Information about new versions of the digital
map can be obtained from an authorized
Mercedes-Benz Center. You can have the digital
map updated there using a data medium, or you
can update it yourself.
For USA and Mexico, it is possible to update the
map data for the multimedia system free of
charge for a period of three years. Information
on the availability of this service for your vehicle
can be obtained from an authorized MercedesBenz Center.
Entitlement to the free update
For the first three years after your vehicle is registered, you are entitled to all available updates
to the map software for the multimedia system.
They are usually installed during a regular vehicle service. After this period, you can purchase
further updates from an authorized MercedesBenz Center.
The free updates relate to the vehicle and not to
an individual. If there is a change of ownership
within the three years after first registration, the
new owner is entitled to the map software
updates.
Updating at an authorized MercedesBenz Center
If an update for your map software is available,
you will receive it free of charge at an authorized
Mercedes-Benz Center during your vehicle's
annual service. You can arrange a separate
appointment for this at an authorized MercedesBenz Center on request.
The update can only be performed:
R
at an authorized Mercedes-Benz Center
R
for navigation data for North America
The map software is not provided on DVD.
Carrying out a manual update
After the free update of the map data has
expired or when buying map data, you can
update the data yourself.
The update process may take some time (up to
45 minutes), depending on the size of the digital
map. The update will be completed more quickly
if the vehicle is stationary. If you begin the
update while the vehicle is stationary and the
starter battery has insufficient power, the multimedia system may switch off automatically.
This protects the battery. In order to prevent
this, a suitable power supply to the vehicle must
be maintained.
Navigation functions
89
Navigation functions
Calling up the navigation system
menu
X
To switch to navigation mode: press the
ß button.
X
To show the menu: slide 5 the controller.
is highlighted in the main function bar.
Navi
X
Press the controller.
The navigation menu appears.
X
Turn the controller to display the navigation
functions one after another.
X
To switch to the map, turn the controller until
Navigation
ler.
appears and press the control-
Calling up the compass display
X
Call up the navigation menu (Y page 89).
X
Turn the controller until Compass is brought to
the front.
X
Press the controller.
The compass display provides the following
information:
R
The current direction of travel with bearing
(360 degree format) and compass direction
R
Longitude and latitude coordinates in
degrees, minutes and seconds
R
Height (rounded off) above sea level
R
Number of GPS satellites from which a signal can be received
X
To select Compass On Map: turn and press
the controller.
X
To exit the compass display: press the %
button.
Info on navigation
Navigation
Calling up the online map display
Online search requirement (USA): mbrace must
be activated for Internet access (
X
Call up the navigation menu (Y page 89).
X
Turn the controller until Online Map Dis‐
play is brought to the front.
X
Press the controller.
The online connection is established. Once
the connection is established, the Google
Maps™ map shows the vicinity of the current
vehicle position.
X
To exit the online map display: press the %
button.
Y page 125).
X
Call up the navigation menu (Y page 89).
X
Turn the controller until Info on Naviga‐
tion is brought to the front.
X
Press the controller.
The Digital Operator's Manual is opened at
the section on navigation.
Z
Problems with the navigation system
90
Problems with the navigation system
Problem
The multimedia system
does not resume route
guidance after the journey has been interrupted.
Problem
The multimedia system
is unable to determine
the vehicle's position.
Navigation
Problem
The digital map is not
compatible with the
vehicle software.
Possible causes/consequences and M Solutions
Route guidance is canceled if you interrupt the journey for more than
two hours.
"Interrupting the journey" refers to stopping the vehicle.
"Continuing route guidance" refers to switching the multimedia sys-
tem back on and driving on.
X
Continue route guidance manually (Y page 75).
Possible causes/consequences and M Solutions
The multimedia system must identify the vehicle’s position again after
it has been transported.
Example:
R
After transporting the vehicle by ferry
R
After transporting the vehicle by motorail
X
Start the vehicle and pull away.
The multimedia system calculates the vehicle's position. Depending
on the driving situation, this may take some time.
Route guidance may be restricted during the determination of the
vehicle's position.
When positioning is complete, route guidance is resumed with navigation announcements and route guidance displays.
Possible causes/consequences and M Solutions
The data medium containing the digital map cannot be used for the
update.
X
To confirm the message: press the controller.
X
Remove the data medium.
X
Have the data medium checked at an authorized Mercedes-Benz
Center.
Problem
The multimedia system
asks for an activation
code during the map
update.
Possible causes/consequences and M Solutions
The digital map is secured with an activation code.
X
Consult an authorized Mercedes-Benz Center.
Problems with the navigation system
91
Problem
The map software
update has failed.
Possible causes/consequences and M Solutions
The digital map can be installed with a DVD, SD card or USB stick.
X
Check the readability of the data medium, e.g. in a PC.
X
To restart the update: insert the DVD.
or
X
Insert an SD card or USB stick.
The multimedia system asks for an activation code during the map
update. The code must be validated in the vehicle.
X
Start the vehicle.
X
To restart the update: insert the DVD, SD card or connect a USB
device.
The multimedia system's integral hard disk has been physically damaged.
X
Consult an authorized Mercedes-Benz Center.
Navigation
Z
General notes
92
Your multimedia system equipment
These operating instructions describe all the
standard and optional equipment of your multimedia system, as available at the time of going
to press. Country-specific differences are possible. Bear in mind that your vehicle may not
feature all functions described here. This also
applies to safety-relevant systems and functions.
Read the information on qualified specialist
workshops in the vehicle Operator's Manual.
Important safety notes
WARNING
G
If you operate mobile communication equipment while driving, you will be distracted from
Telephone
traffic conditions. You could also lose control
of the vehicle. There is a risk of an accident.
Only operate this equipment when the vehicle
is stationary.
If you make a call on your mobile phone while
driving, always use hands-free mode. Only use
the mobile phone when road, weather and traffic
conditions permit. Some jurisdictions prohibit
the driver from using a mobile phone while driving a vehicle.
Bear in mind that at a speed of 30 mph (approximately 50 km/h), the vehicle covers a distance
of 44 ft (approximately 14 m) per second.
Excessive levels of electromagnetic radiation
may cause damage to your health and the health
of others.
There is scientific discussion surrounding the
possible health risks posed by electromagnetic
fields. You can reduce this risk by using an exterior antenna.
Therefore, connect your mobile communications equipment to the vehicle's exterior
antenna wherever possible.
General notes
If your mobile phone supports the Bluetooth
®
profile PBAP (Phone Book Access Profile), the
contacts are automatically displayed in the multimedia system.
You can use the text message and e-mail functions if your mobile phone supports the MAP
Bluetooth
®
profile (Message Access Profile).
Observe the other requirements for the e-mail
and text message functions (
Y page 114).
With a suitable mobile phone, you can use the
hands-free system and receive vCards via the
Bluetooth
®
interface.
You can obtain more information about suitable
mobile phones on the Internet at
http://www.mercedes-benz.com/connect.
You can also obtain more information by calling.
In the USA, you can get in touch with the
Mercedes-Benz Customer Assistance Center on
1-800-FOR-MERCedes (1-800-367-6372).
In Canada, you can get in touch with the Customer Relations Center on 1-800-387-0100.
Call disconnection while the vehicle is
in motion
A call may be disconnected if:
R
there is insufficient network coverage in certain areas.
R
you move from one transmitter/receiver area
(cell) into another and no channels are free.
R
you use a SIM card that is not compatible with
the network available.
Operating options
You can operate the telephone by:
R
using the controller:
turning
sliding 1 or 4
pressing
R
using the 6 or ~ button on the multifunction steering wheel
R
using the Voice Control System (see the separate operating instructions)
Telephony
The Bluetooth®interface on the multimedia system is available for telephony.
Connecting/disconnecting a mobile phone
93
Function restrictions
You may have to wait to use telephony via the
multimedia system in the following situations:
R
the mobile phone is switched off
R
Bluetooth®is switched off on the mobile
phone
R
the mobile phone has not logged on to a
mobile phone network
R
the Bluetooth®function is switched off in the
multimedia system
The telephone automatically tries to log on to a
network. If no network is available, you may not
be able to make a "911" emergency call. If you
attempt to make an outgoing call, the No Ser‐
vice message will appear for a short while.
Telephone menu overview
:
Mobile phone network provider
;
Signal strength of the mobile phone network
=
Receiver icon ¢ or ¡
?
Telephone menu character bar
A
Bluetooth®device name of the currently
connected mobile phone
B
Displays the phone book
Symbols : to = and A are not shown until
after a mobile phone has been connected to the
multimedia system. The symbols depend on
your mobile phone and your mobile phone network provider. Further information on connecting a mobile phone (
Symbol ; shows the current signal strength of
the mobile phone network. If all bars are filled,
you have optimum reception.
If no bars are shown, reception is either very
poor or there is none at all.
Receiver icon shows whether a call is active/
being connected ¡ or not ¢.
Y page 93).
Calling up the telephone menu
X
Press %.
Showing the menu bar
X
Slide 6 the controller.
If the mobile phone connected supports the
MAP Bluetooth
®
profile (Message Access
Profile), the 1 menu item is available. Further
information on text messages and e-mail
(
Y page 114).
If you have an unread text message or e-mail,
the 0 mail symbol is displayed in the status
bar. The symbol disappears once you have read
the text message or e-mail. The ú symb
ol i
displayed as soon as the message memory on
the connected mobile phone is full. The symbol
disappears once you delete at least one message.
Connecting/disconnecting a mobile
phone
Requirements
For telephony via the Bluetooth®interface, you
require a Bluetooth
mobile phone must support Hands-Free Profile
1.0 or above.
On the multimedia system
X
Activate Bluetooth®(Y page 41).
On the mobile phone
X
Switch on the mobile phone and enter the PIN
when prompted to do so (see the manufacturer's operating instructions).
X
Activate Bluetooth®and, if necessary, Blue-
®
visibility for other devices (see the
tooth
manufacturer's operating instructions).
This visibility is for restricted periods of time
on some mobile phones (see the manufacturer's operating instructions).
X
Set the Bluetooth®device name for the
mobile phone if necessary.
The device names for all of one manufacturer's
products might be identical. To make it possible
to clearly identify your mobile phone, change
the device name (see the manufacturer's operating instructions). The name can be freely
selected.
®
-capable mobile phone. The
Z
s
Telephone
Connecting/disconnecting a mobile phone
94
If the mobile phone supports the PBAP (Phone
Book Access Profile) and MAP (Message
Access Profile) Bluetooth
®
profiles, the following information will be transmitted after you
connect:
R
Phone book
R
Call lists
R
Text messages and e-mail
Further information on allowing or suppressing
the automatic download of the phone book
Y page 109).
(
The battery of the mobile phone should always
be kept sufficiently charged in order to prevent
malfunctions.
Not all mobile phones available on the mar-
i
ket are equally suitable. You can obtain further information about suitable mobile
phones and about the connection between
the mobile phone and the multimedia system
Telephone
on the Internet at http://www.mercedesbenz.com/connect.
You can also obtain more information by calling.
In the USA, you can get in touch with the
Mercedes-Benz Customer Assistance Center
on 1-800-FOR-MERCedes (1-800-367-6372).
In Canada, you can get in touch with the Customer Relations Center on 1-800-387-0100.
Some displays (e.g. the signal strength)
i
depend on the supported version of the
Hands-Free Profile.
tem. The mobile phone is connected automatically after authorization. Further information
about automatically reconnecting authorized
mobile phones (
Y page 96).
If the multimedia system does not detect your
mobile phone, this may be due to particular
security settings on your mobile phone. You can
also start the search procedure and authorization on the mobile phone (
Device-specific information on authorizing and
connecting Bluetooth
Y page 96).
®
-capable mobile phones
can be obtained from an authorized MercedesBenz Center or via the Internet at http://
www.mercedes-benz.com/connect.
You can authorize up to 15 mobile phones. After
authorization, the connection of the last two telephones used always functions automatically.
For telephony, only one mobile phone can be
connected to the multimedia system at any one
time.
De-authorizing (disconnecting) a mobile
phone
The connection is terminated automatically if
you leave the receiver range of the multimedia
system or deactivate Bluetooth
phone.
If you no longer want the Bluetooth
to be established automatically, the mobile
phone must be de-authorized (disconnected)
Y page 97).
(
®
on your mobile
®
connection
Procedure and general information
Authorizing a mobile phone (connecting)
Before using your mobile phone with the multimedia system for the first time, you will need to
search for the phone (
authorize it (
Y page 95). Depending on the
mobile phone, authorization either takes place
by means of Secure Simple Pairing or by entering a passkey. The multimedia system automatically makes the procedure that is relevant for
your mobile phone available. You can recognize
Secure Simple Pairing by the fact that a code is
displayed on the mobile phone and on the multimedia system. You can recognize the passkey
system by the fact that you have to enter a code
on the mobile phone and on the multimedia sys-
Y page 94) and then
Searching for a mobile phone
X
To call up the telephone menu: press the
% button.
X
To switch to the menu bar: slide 6 the controller.
Connecting/disconnecting a mobile phone
95
X
To select Conn. Device: turn and press the
controller.
The device list is displayed.
X
To select Search for Phones: turn and
press the controller.
A message is displayed that Bluetooth
®
must
be activated on the mobile phone and must be
made visible to other devices.
X
To select Start Search: press the controller.
The available mobile phones are displayed in
the device list.
The duration of the search depends on the number of Bluetooth
®
telephones within range and
their characteristics.
If a new phone is found, it appears in the device
list with the Ï symbol. You can now authorize (connect) the mobile phone found
Y page 95).
(
If the maximum number of authorized devices in
the device list is reached, you will be requested
to de-authorize a mobile phone (
Y page 97).
When you call up the device list again, deauthorized devices will be removed from the list.
To update the device list, start the search again.
Symbols in the device list
Sym-
Explanation
bol
Ï
New mobile phone found, not yet
authorized.
Ñ
Mobile phone is authorized, but is
not connected.
#
Mobile phone is authorized and
connected.
Authorizing a mobile phone (connecting)
Authorization via Secure Simple Pairing
If the multimedia system has found your mobile
phone, you can authorize (connect) it.
X
To select a mobile phone from the device list:
turn the controller and press to confirm.
A code is displayed in the multimedia system
and on the mobile phone.
The code is the same
X
Multimedia system:select Yes.
X
Mobile phone: confirm the code. Depending
on the mobile phone used, you may have to
confirm the connection to the multimedia system and for the PBAP and MAP Bluetooth
®
profiles separately. You may also save the
confirmation on the mobile phone (see the
manufacturer's operating instructions).
The mobile phone is now authorized and connected to the multimedia system. You can
now speak using the hands-free system.
To ensure an optimum language quality, you can
set the mobile phone's transmission and reception volume (
Y page 97).
The code is different
X
Multimedia system:select No.
The process is canceled. Repeat the authorization.
Authorization via passkey entry (access
code)
If the multimedia system has found your mobile
phone, you can authorize (connect) it.
X
To select a mobile phone from the device list:
turn the controller and press to confirm.
The input menu for the passkey is displayed.
The passkey is a one- to sixteen-digit number
combination which you can choose yourself.
Depending on the mobile phone used, you
may have to enter a number sequence of four
digits or more.
X
Multimedia system: enter the passkey using
the character bar.
X
Select ¬ once all the numbers have been
entered.
X
Mobile phone: enter the same passkey and
confirm your entry. Depending on the mobile
phone used, you may have to confirm the
connection to the multimedia system and for
the PBAP and MAP Bluetooth
rately. You may also save the confirmation on
the mobile phone (see the manufacturer's
operating instructions).
The mobile phone is now authorized and connected to the multimedia system. You can
now speak using the hands-free system.
To ensure an optimum language quality, you can
set the mobile phone's transmission and reception volume (
Y page 97).
®
profiles sepa-
Telephone
Z
Connecting/disconnecting a mobile phone
96
If the Authorization Failed message
appears, you may have entered a different passkey or exceeded the prescribed time limit.
Repeat the procedure.
If you wish to re-authorize the mobile phone
i
after de-authorizing it, you can choose
another passkey for it.
Mercedes-Benz recommends de-authoriza-
i
tion in the multimedia system as well as on
the mobile phone (
Y page 97). Subsequent
authorization may otherwise fail.
Establishing the connection from the
mobile phone
The Bluetooth®device name of the multimedia
system is MB Bluetooth
X
Multimedia system: call up the telephone
Telephone
menu.
X
To switch to the menu bar: slide 6 the controller.
X
To select Conn. Device: turn and press the
controller.
The device list is displayed.
X
To select Connect via Phone: turn and
press the controller.
A message is displayed, stating that you can
start the search on your mobile phone.
X
Mobile phone: start the search for a Blue-
®
device (see manufacturer's operating
tooth
instructions).
The multimedia system is displayed with the
name MB Bluetooth
device list.
X
Select MB Bluetooth.
A prompt appears in the multimedia system's
display asking if the mobile phone should be
authorized.
X
Multimedia system:select Yes.
is selected, the procedure is canceled.
If No
If your mobile phone supports Secure Simple
Pairing, a code is now displayed on both devices.
The code is the same
X
Multimedia system:select Yes.
X
Mobile phone: confirm the code. Depending
on the mobile phone used, you may have to
confirm the connection to the multimedia system and for the PBAP and MAP Bluetooth
.
in the mobile phone's
profiles separately. You may also save the
confirmation on the mobile phone (see the
manufacturer's operating instructions).
The mobile phone is now authorized and connected to the multimedia system. You can
now speak using the hands-free system.
To ensure an optimum language quality, you
can set the mobile phone's transmission and
reception volume (
Y page 97).
The code is different
X
Multimedia system:select No.
The process is canceled. Repeat the procedure.
If your mobile phone does not support Secure
Simple Pairing, an input menu is displayed for
the passkey. The passkey is a one- to sixteendigit number combination which you can choose
yourself. Enter the same passkey in both the
multimedia system and on the mobile phone and
confirm. Depending on the mobile phone used,
you may have to confirm the connection to the
multimedia system and for the PBAP and MAP
Bluetooth
®
profiles.
Reconnecting automatically
The multimedia system always searches for the
last connected mobile phone.
If no connection can be made to the most
recently connected mobile phone, the system
searches for the mobile phone that was connected before that one.
Switching between mobile phones
If you have authorized more than one mobile
phone, you can switch between the individual
phones.
X
To call up the telephone menu: press the
% button.
X
To switch to the menu bar: slide 6 the controller.
X
To select Conn. Device: turn and press the
controller.
The device list is displayed.
X
To select the desired mobile phone: turn and
press the controller.
The selected mobile phone is connected if it is
®
within Bluetooth
activated.
®
range and if Bluetooth®is
Setting the reception and transmission volume
97
Only one mobile phone can be connected at any
one time for telephony. The currently connected
mobile phone is indicated by the # dot in the
device list.
You can only switch to another authorized
i
mobile phone if you are not currently making
a call.
De-authorizing (disconnecting) a
mobile phone
Mercedes-Benz USA, LLC recommends deauthorization in the multimedia system as well
as on the mobile phone. Subsequent authorization may otherwise fail.
X
To call up the telephone menu: press the
% button.
X
To switch to the menu bar: slide 6 the controller.
X
To select Conn. Device: turn and press the
controller.
The device list is displayed.
X
To highlight the desired mobile phone in the
device list: turn the controller.
X
To select G: slide 9 the controller.
X
To select Deauthorize: turn and press the
controller.
A prompt appears, asking whether you really
wish to de-authorize this device.
X
To select Yes: turn and press the controller.
The mobile phone is de-authorized.
Displaying connection details
X
To call up the telephone menu: press the
% button.
X
To switch to the menu bar: slide 6 the controller.
X
To select Conn. Device: turn and press the
controller.
The device list is displayed.
X
To highlight the desired mobile phone: turn
the controller.
X
To select G: slide 9 the controller.
X
To select Details: turn and press the controller.
The following information concerning the
selected mobile phone is shown:
R
Bluetooth®device name
R
Bluetooth®address
R
Authorization status
Setting the reception and transmission volume
Once the mobile phone has been authorized,
you can optimize the transmission and reception volume settings. To find out about the best
possible settings for your mobile phone, visit
http://www.mercedes-benz.com/connect.
You can also obtain more information by calling.
In the USA, you can get in touch with the
Mercedes-Benz Customer Assistance Center on
1-800-FOR-MERCedes (1-800-367-6372).
In Canada, you can get in touch with the Customer Relations Center on 1-800-387-0100.
X
To call up the telephone menu: press the
% button.
X
To switch to the menu bar: slide 6 the controller.
X
To select Conn. Device: turn and press the
controller.
The device list appears.
X
To highlight the desired mobile phone in the
device list: turn the controller.
X
To select G: slide 9 the controller.
X
To select Reception Volume or Transmis‐
sion Volume: turn and press the controller.
X
To select a volume setting: turn the controller.
X
To accept changes: press the controller.
Incorrect settings may have an impact on
i
the quality of calls.
Telephone
Z
Using the telephone
98
Using the telephone
Accepting a call
X
To select w Accept: press the controller.
or
X
Press 6 on the multifunction steering
wheel.
The call is accepted.
Additional functions available during a call
Y page 99).
(
Adjusting the call volume (
Y page 97).
Further information about ending a call
Y page 101).
(
If the phone number of the caller is trans-
i
ferred, it appears in the display. If the phone
number is saved in the phone book, the contact's name and picture are also displayed. If
the phone number is not transferred,
Telephone
Unknown
is shown in the display.
Rejecting a call
X
To select = Reject: turn and press the
controller.
or
X
Press ~ on the multifunction steering
wheel.
Making a call
Using the telephone menu
X
To call up the telephone menu: press the
% button.
X
To select the sequence of numbers: turn and
press the controller for each number.
X
To select w in the telephone menu: turn
and press the controller.
The call is made.
Further information about ending a call
Y page 101).
(
Using the number keypad
X
To call up the telephone menu: press the
% button.
X
Enter the number sequence using the number
keypad.
X
To select w in the telephone menu: turn
and press the controller.
The call is made.
Redial
X
To call up the telephone menu: press the
% button.
X
To select w in the telephone menu: turn
and press the controller.
The list of outgoing calls is displayed. The
most recently dialed number is at the top.
X
To select an entry and make a call: turn and
press the controller.
For redialing using the multifunction steering
wheel (see the vehicle Operator's Manual).
Further information about ending a call
Y page 101).
(
Using call lists
X
To call up the telephone menu: press the
% button.
X
To switch to the menu bar: slide 6 the controller.
X
To select Call Lists: turn and press the
controller.
X
To select Calls Receivedor Calls Dialed:
turn and press the controller.
The relevant list is displayed.
X
To select an entry and make a call: turn and
press the controller.
Selecting and placing a call using the multifunction steering wheel (see vehicle Operator's Manual)
Further information about ending a call
Y page 101).
(
Using the phone book
X
To call up the telephone menu: press the
% button.
X
To select Name in the telephone menu: turn
and press the controller.
X
Search for and call a contact (Y page 102).
Loading...
