MP3228
User’s Guide
Portable CD Player with
AM/FM Stereo Radio
Before operating this product,
please read these instructions completely.
Dear Customer,
Please read this manual thoroughly before operating the unit to become more familiar with it and obtain the performance that will bring you continued enjoyment for
many years. Keep these instructions handy for future reference.
PLEASE KEEP ALL PACKAGING MATERIAL FOR AT LEAST 90
DAYS IN CASE YOU NEED TO RETURN THIS PRODUCT TO
YOUR PLACE OF PURCHASE OR MEMOREX.
For future reference, record the serial number of the unit printed on the rear of the
cabinet.
Serial Number _______________________________________
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR BACK). NO
USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
DANGEROUS VOLTAGE:
The lightning flash with arrowhead symbol, within an equilateral triangle is intended to alert the
user to the presence of uninsulated dangerous voltage within the product’s enclosure that may
be of sufficient magnitude to constitute a risk of electric shock to persons.
ATTENTION:
The exclamation point within an equilateral triangle is intended to alert the user to the
presence of important operating and maintenance (servicing) instructions in the literature
accompanying the appliance.
DANGER:
Invisible and hazardous laser radiation when open and interlock failed or defeated. Avoid
direct exposure to beam.
FCC WARNING:
This equipment may generate or use radio frequency energy. Changes or
modifications to this equipment may cause harmful interference unless the
modifications are expressly approved in the instruction manual.
The user could
lose the authority to operate this equipment if an unauthorized change or
modification is made.
1
INFORMATION:
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of
the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT
EXPOSE THIS UNIT TO RAIN OR MOISTURE.
LASER SAFETY: This unit employs a laser. Only qualified service personnel
should attempt to service this device due to possible eye injury.
CAUTION: USE OF CONTROLS, ADJUSTMENTS OR PERFORMANCE
PROCEDURE HEREIN MAY RESULT IN HAZARDOUS RADIATION
EXPOSURE.
SURGE PROTECTORS:
It is recommended to use a surge protector for AC connection. Lightning and
power surges ARE NOT covered under warranty for this product.
2
Dear Customer:
A
S
S
O
C
I
A
T
I
O
N
EST. 1924
E
L
E
C
T
R
O
N
I
C
I
N
D
U
S
T
R
I
E
S
EIA
We
LISTENING
For A Lifetime
Want You
Selecting fine audio equipment such as the unit you’ve just purchased is only the start of
your musical enjoyment. Now it’s time to consider how you can maximize the fun and
excitement your equipment offers. This manufacturer and the Electronic Industries
Association’s Consumer Electronics Group want you to get the most out of your equipment by playing it at a safe level. One that lets the sound come through loud and clear
without annoying blaring or distortion and, most importantly, without affecting your sensitive hearing.
Sound can be deceiving. Over time your hearing “comfort level” adapts to higher volumes
of sound. So what sounds “normal” can actually be loud and harmful to your hearing. Guard
against this by setting your equipment at a safe level BEFORE your hearing adapts.
To establish a safe level:
• Start your volume control at a low setting.
• Slowly increase the sound until you can hear it comfortably and clearly, and without distortion.
Once you have established a comfortable sound level:
• Set the dial and leave it there.
Taking a minute to do this now will help to prevent hearing damage or loss in the future.
After all, we want you listening for a lifetime.
We Want You Listening For A Lifetime
Used wisely, your new sound equipment will provide a lifetime of fun and enjoyment. Since
hearing damage from loud noise is often undetectable until it is too late, this manufacturer
and the Electronic Industries Association’s Consumer Electronics Group recommend you
avoid prolonged exposure to excessive noise. This list of sound levels is included for your
protection.
Decibel
Level Example
30 Quiet library, soft whispers
40 Living room, refrigerator, bedroom away from traffic
50 Light traffic, normal conversation, quiet office
60 Air conditioner at 20 feet, sewing machine
70 Vacuum cleaner, hair dryer, noisy restaurant
80 Average city traffic, garbage disposals, alarm clock at two feet
THE FOLLOWING NOISES CAN BE DANGEROUS UNDER CONSTANT EXPOSURE:
90 Subway, motorcycle, truck traffic, lawn mower
100 Garbage truck, chain saw, pneumatic drill
120 Rock band concert in front of speakers, thunderclap
140 Gunshot blast, jet engine
180 Rocket launching pad
Information courtesy of the Deafness Research Foundation.
3
SAFETY INSTRUCTIONS
PORTABLE CART WARNING
(symbol provided by RETAC)
Before using the unit, be sure to read all operating instructions carefully. Please note that these are
general precautions and may not pertain to your unit. For example, this unit may not have the capabili
ty to be connected to an outdoor antenna.
1. READ INSTRUCTIONS
All the safety and operating instructions should be read before the product is operated.
2. RETAIN INSTRUCTIONS
The safety and operating instructions should be retained for future reference.
3. HEED WARNINGS
All warnings on the product and in the operating instructions should be adhered to.
4. FOLLOW INSTRUCTIONS
All operating and use instructions should be followed.
5. CLEANING
Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners.
Use a dry cloth for cleaning.
6. ATTACHMENTS
Do not use attachments not recommended by the product's manufacturer as they may cause hazards.
7. WATER AND MOISTURE
Do not use this product near water–for example: near a bathtub, washbowl, kitchen sink or laundry tub; in
a wet basement; or near a swimming pool.
8. ACCESSORIES
Do not place this product on an unstable cart, stand, tripod, bracket or table. The product may fall, causing
serious injury and serious damage to the product. Use only with a cart, stand, tripod, bracket or table recommended by the manufacturer or sold with the product. Any mounting of the product
should follow the manufacturer’s instructions, and should use a mounting accessory recommended by the manufacturer.
8A. An appliance and cart combination should be moved with care. Quick stops, excessive
force and uneven surfaces may cause the appliance and cart combination to overturn.
9. VENTILATION
Slots and openings in the cabinet and in the back or bottom are provided for ventilation,
to ensure reliable operation of the product and to protect it from overheating. These
openings must not be blocked or covered. The openings should never be blocked by
placing the product on a bed, sofa, rug or other similar surface. This product should never be placed near
or over a radiator or heat source. This product should not be placed in a built-in installation such as a
bookcase or rack unless proper ventilation is provided or the manufacturer's instructions have been
adhered to.
10. POWER SOURCES
This product should be operated only from the type of power source indicated on the marking label. If you
are not sure of the type of power supply to your home, consult your appliance dealer or local power company. For products intended to operate from battery power, or other sources, refer to the operating instructions.
11. GROUNDING OR POLARIZATION
This product is equipped with a polarized alternating-current line plug (a plug having one blade wider than
the other). This plug will fit into the power outlet only one way. This is a safety feature. If you are unable to
insert the plug fully into the outlet, try reversing the plug. If the plug should still fail to fit, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug.
12. POWER-CORD PROTECTION Power-supply cords should be
routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying
particular attention to cords at plugs, convenience receptacles, and the point where they exit from the
appliance.
13. LIGHTNING
To protect your product from a lightning storm, or when it is left unattended and unused for long periods of
time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage
to the product due to lightning and power-line surges.
14. POWER LINES
An outside antenna system should not be located in the vicinity of overhead power lines or other electric
light or power circuits, or where it can fall into such power lines or circuits. When installing an outside
antenna system, extreme care should be taken to keep from touching such power lines or circuits as con
tact with them might be fatal.
-
-
4
SAFETY INSTRUCTIONS (CONTINUED)
ANTENNA
LEAD IN
WIRE
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)
NEC - NATIONAL ELECTRICAL CODE
ELECTRIC
SERVICE
EQUIPMENT
GROUND
CLAMP
S2898A
15. OVERLOADING
Do not overload wall outlets and extension cords as this can result in a risk of fire or electric shock.
16. OBJECT AND LIQUID ENTRY
Never push objects of any kind into this product through openings as they may touch dangerous voltage points
or short out parts that could result in fire or electric shock. Never spill or spray any type of liquid on the product.
17. OUTDOOR ANTENNA GROUNDING
If an outside antenna is connect
ed to the product, be sure the
antenna system is grounded so
as to provide some protection
against voltage surges and builtup static charges. Section 810 of
the National Electric Code,
ANSI/NFPA 70, provides information with respect to proper
grounding of the mast and supporting structure, grounding of the
lead-in wire to an antenna discharge product, size of grounding
conductors, location of antenna
discharge product, connection to
grounding electrodes and requirements for grounding electrode.
18. SERVICING
Do not attempt to service this product yourself as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.
19. REPLACEMENT PARTS
When replacement parts are required, be sure the service technician uses replacement parts specified by
the manufacturer or those that have the same characteristics as the original part. Unauthorized substitutions may result in fire, electric shock or other hazards.
20. SAFETY CHECK
Upon completion of any service or repairs to this product, ask the service technician to perform safety
checks to determine that the product is in proper operating condition.
21. WALL OR CEILING MOUNTING
The product should be mounted to a wall or ceiling only as recommended by the manufacturer.
22. DAMAGE REQUIRING SERVICE
Unplug the product from the wall outlet and refer servicing to qualified service personnel under the following conditions:
a. When the power-supply cord or plug is damaged.
b. If liquid has been spilled or objects have fallen into the product.
c. If the product has been exposed to rain or water.
d. If the product does not operate normally by following the operating
instructions. Adjust only those controls that are covered by the
operating instructions, as an adjustment of other controls may result
in damage and will often require extensive work by a qualified
technician to restore the product to its normal operation.
e. If the product has been dropped or the cabinet has been damaged.
f. When the product exhibits a distinct change in performance–this
indicates a need for service.
23. HEAT
The product should be situated away from heat sources such as radiators, heat registers, stoves or other
products (including amplifiers) that produce heat.
24. NOTE TO CATV SYSTEM INSTALLER
This reminder is provided to call the CA
provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as practical.
-
EXAMPLE OF ANTENNA GROUNDING AS PER
TV system installer's attention to
5
NATIONAL ELECTRICAL CODE
Article 820-40 of the NEC that
LOCATION OF CONTROLS
15 16 2017 18219 21
1 3 4 5 146 7 8 9 10 11 12 13
1. FUNCTION Button
2. POWER Button
3. Tune/Skip/Search
4. Tune/Skip/Search
o Button
n Button
5. AC Power Jack (Rear of Unit)
6. CD Compartment
7. CD Door OPEN/CLOSE Area
8. MODE/M-UP (Memory Up)
Button
9. PLAY/PAUSE (
®p) Button
10. Carrying Handle
14. PHONES (Headphones) Jack
(Side of Unit)
15. Left Speaker
16. BAND Button
17. PROG/MEMORY/CLOCK SET
Button
18. Battery Compartment (Bottom
of Unit)
19. Display
20. STOP (
■) Button
21. Right Speaker
11. FM Antenna
12. BASS Button
13. VOLUME Control
6
POWER SOURCES
AC Plug
AC Outlet
+
+
-
-
+
+
-
-
+
+
-
-
+
+
-
-
This unit is designed to operate on AC household current or DC (batteries).
AC
Use the AC polarized line cord included with the unit
for operation on AC power. Insert one end of the AC
line cord into the AC power jack on the rear of the unit
and the other end (with the 2 blades) into a conveniently located AC outlet having 120V, 60Hz. When
the AC cord is plugged in, the batteries will be disconnected.
NOTE: The AC plug supplied with the unit is polarized to help minimize the possibility of electric shock. If the AC plug does not fit into a nonpolarized AC outlet, do
not file or cut the wide blade. It is the user’s responsibility to have an electrician
replace the obsolete outlet.
BATTERY INSTALLATION
To use this unit with battery power, remove the
battery door on the bottom of the unit by sliding
the battery door off. Insert eight (8) ‘C’ size
batteries following the diagram in the
compartment.
NOTE: The AC power cord must be disconnected from the AC power jack on the rear of the unit
in order for the unit to operate on battery power.
BATTERY PRECAUTIONS
Follow these precautions when using batteries in this device:
1. Use only the size and type of batteries specified.
2. Be sure to follow the correct polarity when installing the batteries as indicated in the battery compartment.
Reversed batteries may cause damage to the device.
3. Do not mix different types of batteries together (e.g. Alkaline, Rechargeable and Carbon-zinc) or old batteries
with fresh ones.
4. If the device is not to be used for a long period of time, remove the batteries to prevent damage or injury from
possible battery leakage.
5. Do not try to recharge batteries not intended to be recharged; they can overheat and rupture. (Follow battery
manufacturer’s directions.)
HEADPHONE JACK (REAR OF UNIT)
For private listening, connect 3.5mm (32 ohm) stereo headphones (not included) to this
jack. The speakers are automatically disconnected when the headphone plug is inserted in
the jack.
BACKLIGHT
When the unit is on, the backlight in the display will light.
7
2
1
2
1
3
2
1
3
SETTING THE CLOCK
OPERATION
1
With the power off, press the
PROG/MEM/CLOCK SET button; “12
H” will blink.
3
Press the PROG/MEM/CLOCK SET
button and the hours will blink.
2
Press the Tune/Skip/Search o 1 or n
2 button to set the unit to the 24 hour
(24 HOUR) mode (also known as
military time), or 12 hour (12 HOUR)
mode.
4
Press the Tune/Skip/Search o 1 or n 2
button to set the current hour, then press
the PROG/MEM/CLOCK SET button
again; the minute digits will blink. If you
selected 12H time display be sure to
observe the AM or PM indicators to make
sure you have set the hour correctly.
3
5
Press the Tune/Skip/Search o 1 or
n 2 button to set the current minute.
Press the PROG/MEM/CLOCK SET
button ❸ and the time will be set.
8
OPERATION (CONTINUED)
2
1
2
1
2
1
1
2
LISTENING TO THE RADIO
1
Press the POWER button 1 to turn the
unit on. Press the FUNCTION button 2
repeatedly to select the Radio band; AM
or FM will appear in the display.
3
MANUAL TUNING: Repeatedly press
the Tune/Skip/Search o 1 or n 2
button to manually advance the frequency in the display up or down until
the desired frequency appears.
2
Press the BAND button to select AM
or FM.
4
AUTOMATIC TUNING: Press and hold the
Tune/Skip/Search
the frequency in the display starts to scan,
and then release the button; the tuner will
search and then stop on the next strong
station it finds. Repeat this step until the
desired frequency appears in the display.
o 1 or n 2 button until
5
If an FM station is selected, and is
broadcasting in FM stereo, “STEREO”
will light in the display. Adjust the VOLUME control
desired. Press the BASS button
in position to enhance the bass sound.
ANTENNAS
AM–This unit has a built-in ferrite rod antenna, which provides adequate reception in most
areas. If reception is weak, turn the unit to improve reception.
FM–The FM Antenna is for FM reception only. If reception is weak, adjust the length and the
angle of the antenna.
1 and BASS button 2 as
2 to the
6
To turn the radio off, press the
POWER button again.
9
OPERATION (CONTINUED)
2
1
2
1
2
1
SETTING AND RECALLING RADIO PRESETS
This unit can preset 10 AM and 10 FM radio stations for convenient recall.
1
Press the POWER button 1 to turn
the unit on. Press the FUNCTION
button 2 repeatedly to select the
Radio band; AM or FM will appear in
the display.
3
Select a station using the Tune/Skip/
Search o 1 or n 2 button. (See the
previous page for manual or auto
tuning.)
2
Press the BAND button to select AM
or FM.
4
Press the PROG/MEM/CLOCK SET
button 1; “MEM” will blink in the dis-
play. Press the MODE/M-UP button 2
until the desired memory number
appears on the display.
5
Press the PROG/MEM/CLOCK SET
button again to set the station in the
selected memory. Repeat steps 3
through 5 to program up to 10 stations in
each band, if desired.
6
TO RECALL: Follow steps 1 and 2
above. Repeatedly press the
MODE/M-UP button to select a
preset; the station will automatically
be tuned in.
10
2
1
2
1
3
1
2
2
1
TO PLAY A CD
OPERATION (CONTINUED)
1
Press the POWER button 1 to turn the
unit on. Open the CD compartment door
by pressing the OPEN/CLOSE area 2.
Place a CD on the center spindle, with
the printed label side facing up. Close
the CD compartment door.
3
To start from a specific track, locate
the track using the Tune/Skip/Search
o 1 or n 2 button, then press the
PLAY/PAUSE (¨/p) button 3 to start
playback from the specific track.
2
Press the FUNCTION button
repeatedly to select CD, "--" will blink
in the display for a few seconds, then
the total tracks of the CD will appear
in the display. If there is no disc, "--"
will appear in the display.
4
To play a disc from the beginning, press the
PLAY/PAUSE (
PLAY/PAUSE (
playback; the Play indicator will blink. Press
the PLAY/PAUSE (
continue playback; the Play indicator will stop
blinking.
¨/p) button. Press the
¨/p) button again to pause
¨/p) button once again to
5
Adjust the VOLUME control 1 and
BASS button 2 as desired. Press the
BASS button 2 to the in position to
enhance the bass sound.
CONTINUED ON THE NEXT PAGE
6
To search forward or backward through
the playing track, press and hold the
Tune/Skip/Search
chattering noise will be heard. Stop pressing the button to return to normal playback.
11
o 1 or n 2 button, a
OPERATION (CONTINUED)
3
2
1
4
1
2
TO PLAY A CD (CONTINUED)
7
When the disc is through playing, it will
stop rotating. Press the STOP (■) button to stop the disc before it is finished.
NOTES:
• If a disc is inserted incorrectly, dirty or damaged, it will not play.
• As each track is played, the track number is shown in the display.
• To prevent damage to the disc, never open the CD door while the disc is rotating. Wait for the disc to stop before opening the CD door. Never touch the lens
when the CD door is open.
• DO NOT use the carrying handle when playing a CD. The CD should only
be used on a steady surface.
TO REPEATEDLY PLAY BACK ONE TRACK/ALL TRACKS
1
8
To turn the unit off, press the POWER
button again.
2
To repeat a single track, press the
MODE/M-UP button
Stop mode; the Repeat indicator will blink.
Press the Tune/Skip/Search
button to select the specific track that you
wish to repeat. When the desired track
number appears in the display, press the
PLAY/PAUSE (
playback. The specific track you selected
will be repeated continuously.
To stop and cancel Repeat playback, press the STOP (■) button.
1 once while in the
o 2 or n 3
¨/p) button 4 to begin
To repeat all of the tracks on a disc
continuously, press the MODE/M-UP
button
1 twice; the Repeat indicator will
light. Press the PLAY/PAUSE (
2 to begin playback. All tracks will be
repeated continuously.
12
¨/p) button
OPERATION (CONTINUED)
2
1
2
1
2
1
TO PROGRAM THE MEMORY (UP TO 20 TRACKS)
1
Press the POWER button 1 to turn
the unit on. Press the FUNCTION
button
2 repeatedly to select CD.
3
Use the Tune/Skip/Search o 1 or n 2
button to select the first track to be
programmed.
2
Press the PROG/MEM/CLOCK SET
button; “MEM” will blink in the display.
4
Press the PROG/MEM/CLOCK SET
button again; the selected track has
now been programmed and counted
as program 1.
5
Repeat steps 3 and 4 to program the
other desired tracks in sequence.
When the program memory is full, '- -'
will blink in the display.
6
Press the PLAY/PAUSE (¨/p) button
to begin playback; “MEM” will light and
the tracks will play in the order
programmed.
SEE NEXT PAGES FOR NOTES ON PROGRAMMED PLAY
13
OPERATION (CONTINUED)
NOTES ON PROGRAMMED PLAY:
• Programming is the ability to preselect the order in which a series of tracks
will be played.
• Each track may be stored in the program memory as many times as desired.
• As each track is played, its track number will be displayed. You can move forward or backward through the programmed tracks with the
Tune/Skip/Search o or n button.
• The CD player will stop after all programmed tracks have been played or the
STOP (■) button is pressed.
• To stop Program playback, press the STOP (■) button. To play back the program again, press the PROG/MEM/CLOCK SET button followed by the
PLAY/PAUSE (¨/p) button.
• To clear the program memories, while in the Stop mode, press the
PROG/MEM/CLOCK SET button followed by the STOP (■) button.
PROGRAMMED REPEAT
1
It is also possible to use the Program and
Repeat functions together to repeat a
specific program indefinitely. First,
program the tracks you wish to hear in the
order you wish to hear them, as described
on page 13. Then, press the MODE/MUP button twice. Both the “MEM” and
Repeat indicators will light.
NOTE:
Program Repeat operation will continue indefinitely until you press the STOP (■)
button.
2
Press the PLAY/PAUSE (¨/p) button
to begin programmed repeat
playback. The player will play the
tracks you selected in the order in
which you programmed them. When
the last track in the program has been
played, the entire program will begin
again.
14
OPERATION (CONTINUED)
1
2
TO RANDOMLY PLAY A CD
1
Press the MODE/M-UP button 1
three times while in the Stop mode;
“RND” will light. Press the
PLAY/PAUSE (¨/p) button 2 to
begin playback.
2
The unit will randomly play the tracks
on the CD and then stop. Press the
STOP (■ ) button to stop Random
playback before it is finished.
15
CARE AND MAINTENANCE
B
E
N
Z
E
N
E
C
L
E
A
N
E
R
Caring for Compact Discs
• Treat the compact disc carefully. Handle the compact disc only by its edges. Never allow your
fingers to come in contact with the shiny, unprinted side of the compact disc.
• Do not attach adhesive tape, stickers, etc. to
the disc label.
• Clean the compact disc periodically with a soft, lint-free, dry cloth. Never use detergents or abrasive cleaners to clean the compact disc. If necessary, use a CD cleaning kit.
• If a disc skips or gets stuck on a section of the compact disc, it is probably
dirty or damaged (scratched).
• When cleaning the compact disc,
wipe in straight lines from the center
of the compact disc to the outer edge
of the compact disc. Never wipe in
circular motions.
• This unit is designed to play only compact discs bearing the identification logo as shown here. Other discs may not conform to the CD standard and may not play properly.
• Compact discs should be stored in their cases after each use to avoid damage.
• Do not expose compact discs to direct sunlight, high humidity, high temperatures or
dust, etc. Prolonged exposure or extreme temperatures can warp the compact disc.
• Do not stick or write anything on either side of the compact disc. Sharp writing
instruments, or the ink, may damage the surface.
Cleaning the Unit
• To prevent fire or shock hazard, disconnect your unit from the AC power source
when cleaning.
• The finish on your unit may be cleaned with a dust cloth and cared for as other furniture. Use caution when cleaning and wiping the plastic parts.
• Mild soap and a damp cloth may be used on the front panel.
16
TROUBLESHOOTING GUIDE
If you experience a problem with this unit, check the chart below before calling for
service.
SYMPTOM CAUSE SOLUTION
Unit will not AC cord not Check AC cord
turn on. connected. connection.
Disc will not play. CD compartment Close CD compartment
door not closed. door.
Disc inserted Reinsert disc correctly.
incorrectly.
Dirty or defective CD. Try another disc.
Moisture Wipe disc with soft cloth.
condensation on disc.
No sound. VOLUME control Increase volume.
set to minimum.
Defective disc. Try another disc.
Erratic playback. Dirty or defective Clean or replace disc.
disc.
AM or FM, no sound. Power is not on. Press the POWER button.
VOLUME control Increase volume.
set to minimum.
AM/FM, poor sound. Station is not tuned Retune the AM or FM
properly. broadcast station.
FM: Telescopic ant- Reorient FM telescopic
antenna is not antenna.
properly adjusted
AM: Unit is not pos- Rotate unit until best
itioned correctly. reception is obtained.
17
SPECIFICATIONS
GENERAL:
Power Source ..............................................................................120V, 60Hz AC
Battery .........................................................12V DC (8 x 1.5V ‘C’ size batteries)
Alkaline is recommended for longer life
Speaker......................................................................................2 x 5W 8 Ohms
Output Power....................................................................2 x 1.8W @ 10% THD
RADIO SECTION:
Frequency Range (FM) ...............................................................87.5 - 108 MHz
Frequency Range (AM) ...............................................................520 -1710 KHz
CD SECTION:
Disc Diameter ...............................................................................4.72" (120mm)
3.15" (80mm) Single
CD
Optical Source....................................................................Semiconductor Laser
Specifications are subject to change without notice.
FOR ADDITIONAL SET-UP OR OPERATING ASSISTANCE, PLEASE VISIT
OUR WEBSITE AT WWW.MEMOREXELECTRONICS.COM OR CONTACT
CUSTOMER SERVICE AT
1-800-919-3647.
PLEASE KEEP ALL PACKAGING MATERIAL FOR AT LEAST 90 DAYS IN
YOUR PLACE OF PUR-
CASE YOU NEED TO RETURN THIS PRODUCT T
CHASE OR MEMOREX.
FOR PARTS AND ACCESSORIES, CONT
1-800-321-6993.
ACT FOX INTERNA
18
O
TIONAL AT
Memcorp, Inc.
Weston, FL
Printed in Hong Kong
Visit our website at www.memorexelectronics.com
Loading...
