MMP8570A
User’s Guide
Personal FM Stereo
MP3/WMA Player
Before operating this product,
please read these instructions completely.
PRECAUTIONS
COPYRIGHT:
• Distributing copies of MP3, WMA, WMA with DRM tracks without
permission is a violation of international copyright laws.
SAFETY:
• Vibration experienced during walking or exercising will not affect the player.
However, dropping the player or dropping a heavy object on the player may result
in damage or sound distortion.
• Avoid spilling any liquid onto or into the player.
• Do not leave the player in a location near heat sources; in a location subject to direct
sunlight, excessive dust, sand, moisture, rain or mechanical shock; on an unlevel
surface; or in a car with the windows closed during periods of excessive heat.
ROAD SAFETY:
• Do not use headphones while driving, cycling or operating any motorized vehicle. It
may create a traffic hazard and it is illegal in some areas. It can be potentially
dangerous to play your headset at a high volume while walking, especially at
pedestrian crossings. You should exercise extreme caution or discontinue use in
potentially hazardous situations.
FCC WARNING:
• This equipment may generate or use radio frequency energy. Changes or
modifications to this equipment may cause harmful interference unless the
modifications are expressly approved in the instruction manual. The user could
lose the authority to operate this equipment if an unauthorized change or
modification is made.
1
FCC DECLARATION
This device complies with Part 15 of the FCC rules. Operation is subject to the
following two conditions: 1) This device may not cause harmful interference, and 2)
This device must accept any interference received, including interference that may
cause undesired operation.
Warning: Changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Shield cable must be used with this unit to ensure compliance with class B FCC
limits.
2
Dear Customer:
Selecting fine audio equipment such as the unit you’ve just purchased is only the start
of your musical enjoyment. Now it’s time to consider how you can maximize the fun
and excitement your equipment offers. This manufacturer and the Electronic Industries
Association’s Consumer Electronics Group want you to get the most out of your
equipment by playing it at a safe level. One that lets the sound come through loud and
clear without annoying blaring or distortion and, most importantly, without affecting
your sensitive hearing.
Sound can be deceiving. Over time your hearing “comfort level” adapts to higher
volumes of sound. So what sounds “normal” can actually be loud and harmful to your
hearing. Guard against this by setting your equipment at a safe level BEFORE your
hearing adapts.
To establish a safe level:
• Start your volume control at a low setting.
• Slowly increase the sound until you can hear it comfortably and clearly, and without
distortion.
Once you have established a comfortable sound level:
• Set the dial and leave it there.
Taking a minute to do this now will help to prevent hearing damage or loss in the future.
After all, we want you listening for a lifetime.
We Want You Listening For A Lifetime
Used wisely, your new sound equipment will provide a lifetime of fun and enjoyment.
Since hearing damage from loud noise is often undetectable until it is too late, this
manufacturer and the Electronic Industries Association’s Consumer Electronics Group
recommend you avoid prolonged exposure to excessive noise. This list of sound levels
is included for your protection.
3
Decibel
A
S
S
O
C
I
A
T
I
O
N
EST. 1924
E
L
E
C
T
R
O
N
I
C
I
N
D
U
S
T
R
I
E
S
EIA
We
LISTENING
For A Lifetime
Want You
Level Example
30 Quiet library, soft whispers
40 Living room, refrigerator, bedroom away from traffic
50 Light traffic, normal conversation, quiet office
60 Air conditioner at 20 feet, sewing machine
70 Vacuum cleaner, hair dryer, noisy restaurant
80 Average city traffic, garbage disposals, alarm clock at two feet
THE FOLLOWING NOISES CAN BE DANGEROUS UNDER CONSTANT EXPOSURE:
90 Subway, motorcycle, truck traffic, lawn mower
100 Garbage truck, chain saw, pneumatic drill
120 Rock band concert in front of speakers, thunderclap
140 Gunshot blast, jet engine
180 Rocket launching pad
Information courtesy of the Deafness Research Foundation.
4
LOCATION OF CONTROLS
1
9
2
4
3
5
6
7
10
8
11
12
13
14
1. Menu/Lock Button
2. VOLUME +/– Buttons
3. Display
4. PRESS TO OPEN Button
5. PLAY/PAUSE ®p Button
6. Tuning/Skip/Search
m Button
7. Headphone Jack
8. Power/Stop ■ Button
9. Navigation Control
10. Battery Compartment
(Rear of Unit)
11. Preset –/Navigation Up
▲ Button
12. Tuning/Skip/Search
l Button
13. Preset +/Navigation Down
▼ Button
14. USB Port
5
BATTERY INSTALLATION
When the bars in the battery indicator (in the display) become low
(see figure 1), replace the battery as follows.
1. Open the rear cover by pressing the PRESS TO OPEN button,
then lift the rear cover up to remove it as shown in figure 2.
2. Insert one (1) “AAA” battery as shown in figure 3. An alkaline
battery is recommended for the longest playing time.
3. Put the rear cover back on until it snaps in place.
NOTE: Each time after you have replaced the battery, when you turn on the unit again, it
will search the music files to update the index. It will take approx. several seconds to update
the index; this updating time depends on the number of music files in the SD/MMC card and
in the internal memory.
Figure 1
Figure 3Figure 2
Follow these precautions when using a battery in this device:
1. Use only the size and type of battery specified.
2. Be sure to follow the correct polarity when installing the battery as indicated. Reversed
batteries may cause damage to the device.
3. If the device is not to be used for a long period of time, remove the battery to prevent damage
or injury from possible battery leakage.
4. Do not try to recharge batteries not intended to be recharged; they can overheat and rupture.
(Follow battery manufacturer’s directions.)
BATTERY PRECAUTIONS
6
INSTALL “DIGITAL AUDIO PLAYER” SOFTWARE
TO INSTALL THE "DIGITAL AUDIO PLAYER" CD SOFTWARE
For Windows ME, Windows2000 or Windows XP:
Windows will automatically detect the audio player without installing the CD software
when the USB cable is connected.
For Macintosh OSX:
Macintosh OSX will automatically detect the audio player without installing the CD
software (see page 12 for more details). Do not install the software when using a
Macintosh.
For Windows98SE:
The USB mass storage function will not be activated without driver installation. To
activate the USB mass storage function, please use the installation CD-Rom to install
the driver.
For Windows 98SE, if you are connecting your player to your computer for the first
time, please follow these
instructions:
Procedure to Install Player Driver
1. Insert the Installation CD-Rom
into the CD Drive; the auto-run
program will display the Main
Menu window. Click “Software
Drivers”.
NOTE: If the Main Menu window
does not appear, double click the
“Memorex Startup CD” application
file on the Installation CD to open
the Main Menu window.
7
WINDOWS 98 DRIVER INSTALLATION
2. Click “MMP8570” to run the
Windows 98SE driver.
3. Follow the on-screen
instructions to install the
software.
8
WINDOWS 98 DRIVER INSTALLATION (CONTINUED)
4. Install the software under
the directory as prompted.
Warning: DO NOT change the
installation path. Otherwise, the
driver may not run properly.
9
WINDOWS 98 DRIVER INSTALLATION (CONTINUED)
5. After successfully installing the driver software, click "Finish" to finish the
installation and exit the Setup menu.
6. When the installation has completed, the new program, “Memorex Chrono Digital
Audio Player”, will be added to the PROGRAM menu on your computer.
10
DOWNLOADING AND TRANSFERRING FILES
TRANSFERRING FILES
You can download digital music files from the Internet or use encoding software to convert
music that you have on an audio CD into MP3 or WMA format. Once these files are stored on
your computer you can easily copy them to your player.
Connect the computer to your player using the supplied USB cable.
Press the Power/Stop button to turn the unit on.
A "Removable Disk" window will automatically pop-up on your
computer screen.
To add more files and songs to your player simply drag and drop
MP3 or WMA files from anywhere on your computer into the
"Removable Disk" window.
IMPORTANT NOTE: AWMA file with DRM will not play back if you directly drag and drop it
into the “Removable Disk” window. You must use MMJB or Windows Media Player to transfer
copy-protected files.
When you are finished, see the Safely Remove Hardware procedure on page 13 before
disconnecting the player.
11
DOWNLOADING AND TRANSFERRING FILES
TRANSFERRING AUDIO FILES TO YOUR DIGITAL AUDIO
PLAYER USING A MACINTOSH COMPUTER
Make sure to use a Macintosh computer with an operating system of 10.0 or
later to transfer audio files.
1. Turn on your computer.
2. Turn on your digital audio player.
3. Connect the smaller end of the cable to the USB jack on the player and
the larger end of the cable to your USB port on your Macintosh.
4. Your computer will automatically recognize your player and mount a hard
disk icon onto your desktop.
5. Locate the folder where your audio files are stored on your computer’s
hard drive. Simply drag and drop the audio files onto the mounted hard
disk drive icon of your digital audio player located on your desktop.
6. After you have finished your transfer, put away the digital audio player
hard disk icon(s) by dragging it to the Trash icon or Control-click its icon
and choose Eject from the file menu or select Eject from the File drop
down menu located at the top of your screen. You can also use the
keyboard shortcuts by selecting the digital audio player hard disk icon
and pressing the Command-E keys.
7. Your player is ready to play the files you transferred.
12
SAFELY REMOVE HARDWARE (PC)
SAFELY REMOVING YOUR PLAYER FROM THE COMPUTER
NOTE: To avoid damage to your player or data loss, always follow the procedure listed
below before disconnecting the USB cable from your computer or disconnecting the
player from the USB cable.
Using your mouse, double-click the "Safely Remove
Hardware" icon on the task bar.
From the "Safely Remove Hardware" window, select
"USB Mass Storage Device" and click the "Stop"
button. The "Stop a Hardware Device" window will pop-up as shown:
Click "OK". When the "Safe to Remove Hardware" window is displayed, you may
remove the player from the USB cable or remove the USB cable from the computer.
NOTES:
• If the “Safely Remove Hardware” icon is not displayed on the task bar, please double
-click on My Computer. Right-click on “Removable Disk” and left-click on “Eject”.
Then it is safe to remove the player from the computer.
• The “Safely Remove Hardware” procedure is not necessary for Win98 and
Win98SE users.
13
INSTALLING MUSICMATCH JUKEBOX
NOTE: WMA DRM protected files will not play if you use the “drag and drop” procedure.
You must follow the procedure below to play WMA DRM files on your MMP8570.
1. Install the MMJB Software as described above.
2. Turn the unit ON, then connect the USB cable to the unit and the USB port of the
computer. “USB Connect” will be displayed on the LCD when it is properly
connected.
5. The tracks are now properly transferred to the player. Follow the “Safely
Removing Hardware” section on the previous page. Unplug the unit from the
computer and insert the headphones and listen to your music.
14
INSTALLING MUSICMATCH JUKEBOX (CONTINUED)
15
DOWNLOADING AND TRANSFERRING FILES (CONTINUED)
EXTERNAL MEMORY CARD
TO AVOID DAMAGE, make sure the unit is off before
inserting or removing the card.
1. Remove the rear cover by pressing the PRESS TO
OPEN button, then lift the rear cover up to remove it, as
shown in Figure 1.
2. Insert a SD/MMC memory card (not included) up to
512MB, facing up, as shown in Figure 2.
3. Connect the USB cable as described previously.
4. Drag MP3 and WMA files into the SD/MMC memory
card's "Removable Disk" window.
NOTE: A WMA file with DRM will not playback if you directly
drag and drop it into the “Removable Disk” window. See
page 14 for downloading WMA files with DRM from the
computer to your player.
5. To remove the SD/MMC memory card,
then push the edge of the card as shown in Figure 3, and
the card will spring out. Carefully remove the card.
6. Replace the rear cover until it snaps in place.
NOTE:
• If the external card is inserted, removed or replaced, the
unit will search the music files to update the index when
the unit is turned on again.
• If the external card is inserted, the memory card
indicator will appear at the top side of the display while
in the Music Player mode.
turn the unit off,
16
Figure 1
Figure 2
Figure 3
OPERATION
2
1
TURNING THE POWER ON/OFF
LOCK SWITCH
1
Turn the unit on by pressing the Power/Stop
button; the Memorex start screen will appear
in the display temporarily. Then the Music
Player menu will appear and the MP3/WMA
track's information will appear in the display.
To turn the unit off, press and hold the
Power/Stop button; “Continue Holding To
Power Off” will appear in the display. Do not
release the Power/Stop button until the unit
turns off.
1
While in the Music Player menu or the FM Tuner menu,
press and hold the Menu/Lock button; "Holding" will
appear in the display. When “Locked” appears in the
display, release the button. Then a small Lock icon will
appear at the bottom right side of the display which
indicates that the Lock function is activated (no buttons will
be able to be pressed). This is useful when you do not
want the station/track changed by accidentally pressing a
button. To cancel the Lock function, press and hold the
Menu/Lock button, "Locked" will appear in the display.
When "Unlocked" appears in the display, release the
button. Then the small Lock icon will disappear from the
display which indicates that the Lock function is cancelled.
EQ–MUSIC PLAYER ONLY
1
NOTE: To navigate up/down through the menu, you can use the Preset –/Navigation Up
▲ or Preset +/Navigation Down ▼ button in place of rotating the Navigation control.
While in the Music Player menu, press the Menu/Lock button 1; the Main
menu will appear. Rotate the Navigation control
press the Navigation control
Navigation control
2; the Equalizer menu will appear. Rotate the Navigation control 2 to
select the desired EQ setting: Normal, XBass, Rock, Classical, Jazz or
Pop. Press the Navigation control
Press the Menu/Lock button
setting will appear at the top of the display when in Music Player mode.
17
2; the Settings menu will appear. Rotate the
2 to select Equalizer, then press the Navigation control
2 to select and exit the Equalizer menu.
1 twice to exit the menus. The selected EQ
2 to select Settings, then
OPERATION (CONTINUED)
2
1
1
2
1
3
TO LISTEN TO THE FM RADIO
1
Turn the unit on by pressing the Power/Stop
button; the Memorex start screen will appear
in the display temporarily. Then the Music
Player menu will appear and the MP3/WMA
track's information will appear in the display.
3
Select a station by rotating the Navigation
control. When a station is broadcasting in
stereo, “STEREO” will appear in the
display, otherwise “MONO” will appear in
the display.
2
Press the Menu/Lock button 1; the Main menu will
appear. Rotate the Navigation control
then press the Navigation control 2; the FM Tuner will
appear.
NOTE: When you select the Radio mode for the first
time, the unit will automatically scan and set the available
stations into Presets 1 through 20. Then Preset 1 will
appear with the corresponding frequency tuned in.
2 to select FM,
4
AUTOMATIC TUNING: You can also press
and hold the Tuning/Skip/Search √/m 1 or
®/l 2 button and the unit will automatically
search for the next strong station. Press the
VOLUME +/- buttons 3 to increase or
decrease the volume.
ANTENNA
FM–The headphones act as an antenna for
FM. Extend the headphone wire for best FM
reception.
18
2
1
TO ADD PRESETS
1
2
2
1
1
OPERATION (CONTINUED)
1
While in FM Playback mode, and with a desired
station selected, press the Menu/Lock button
the FM Menu will appear. Rotate the Navigation
control
2 to select Add Preset, then press the
Navigation control
2.
2
Select a desired Preset by rotating the Navigation
control
1;
1, then press the Navigation control 1.
Select Yes (confirm adding the station to the
Preset) or No (cancel adding the station to the
Preset) by rotating the Navigation control 1, then
press the Navigation control
menu, press the Menu/Lock button 2.
1. To exit the FM
TO LOAD PRESETS
1
While in FM Playback mode, press the
Menu/Lock button
Rotate the Navigation control
Preset, then press the Navigation control
AUTO SCAN:
While in FM Playback mode, press the Menu/Lock button; the FM menu will appear. Rotate the
Navigation control to select Auto Scan then press the Navigation control. The unit will automatically scan
and set the available stations into Presets 1 through 20. Then Preset 1 will appear with the
corresponding frequency tuned in.
NOTE: During Auto Scan, " " will appear in the display.
1; the FM Menu will appear.
2 to select Load
2
Select a desired Preset by rotating the Navigation
control, then press the Navigation control.
NOTE: You can also load a Preset while in FM
Playback mode by pressing the Preset/
2.
Navigation Up
19
▲ or Down ▼ button.
OPERATION (CONTINUED)
2
1
1
2
2
1
1
2
TO DELETE A PRESET
1
While in FM Playback mode, press the
Menu/Lock button
Rotate the Navigation control
One, then press the Navigation control
TO DELETE ALL PRESETS
1; the FM Menu will appear.
2 to select Delete
2.
1
While in FM Playback mode, press the
Menu/Lock button
Rotate the Navigation control
All, then press the Navigation control
1; the FM Menu will appear.
2 to select Delete
2.
2
Select a desired Preset to delete by rotating the
Navigation control
control 1. Select Yes (to delete the selected preset)
or No (to cancel deleting the selected preset) by
rotating the Navigation control
Navigation control 1. To exit the menus, press the
Menu/Lock button
1, then press the Navigation
1, then press the
2 twice.
2
Press the Navigation control 1. Select Yes (to delete
all the preset stations) or No (to cancel deleting all the
preset stations) by rotating the Navigation control
then press the Navigation control 1. To exit the
menu, press the Menu/Lock button
20
2.
1,
OPERATION (CONTINUED)
2
1
2
1
3
TO LISTEN TO MP3s/WMAs
1
Turn the unit on by pressing the Power/Stop button
❶; the Memorex start screen will appear in the
display temporarily. Then the MP3/WMA track's
information will scroll across the display and the
song number and timer will appear at the bottom of
the display, press the PLAY/PAUSE
start playback.
®p button 2 to
3
Set the Equalizer as shown on page 17. Press the
VOLUME +/- buttons to increase or decrease the
volume.
RESUME:
If you turn the unit off while playing a music file, when you turn on the unit again, the last file played will appear
in the display. Press the PLAY/PAUSE
NOTE: There will be no Resume after replacing the battery; inserting, removing or changing the SD/MMC
card;or adding/deleting music files in the internal/external memory.
®p button to resume playback of the music file.
2
If the unit is in FM mode, press the Menu/Lock button ❶;
the FM menu will appear in the display. Rotate the
Navigation control
Navigation control
Player menu and the MP3/WMA track’s information will
appear in the display. Press the PLAY/PAUSE
button 3 to start playback.
2 to select “Exit FM”, then press the
2 to select and enter the Music
4
Press the Power/Stop button to stop playback. To
turn the unit off, press and hold the Power/Stop
button; “Continue Holding To Power Off” will appear
in the display. Do not release the Power/Stop button
until the unit turns off.
NOTE:
• See pages 7 through 16 for information on
uploading MP3 and WMA files to this unit.
21
®p
OPERATION (CONTINUED)
2
1
1
TO PAUSE PLAYBACK
1
During playback, if you wish to pause the file
momentarily, press the PLAY/PAUSE
playback will pause, the Pause indicator will
appear and the timer will stop counting.
®p button;
2
Press the PLAY/PAUSE ®p button again to resume
playback; the sound will return, the Play indicator
will appear and the timer will start counting again.
NOTE: If you are not in the Music Player menu, the
Pause function will not be available.
TO SELECT/BROWSE THROUGH THE FILES
1
Press the Menu/Lock button 1; the Main menu will
appear. Rotate the Navigation control
Browse, then press the Navigation control
Browse Menu will appear.
All Songs–the unit will start playback automatically; all the music files in the player and in the SD/MMC card will be played.
Albums/Genres–the Albums/Genres will be shown in the display. Select the desired Album/Genre by rotating the Navigation
control and pressing the Navigation control to confirm. To playback all music files of the Album/Genre, rotate the Navigation
control to select All Songs and press the Navigation control to start playback. OR rotate the Navigation control to select the
desired music file inside the Album/Genres; press the Navigation control to playback the music file selected.
Artists–the Artists will be shown in the display. Select the desired Artist by rotating the Navigation control and press the
Navigation control to confirm the selection. Rotate the Navigation control to select All Songs and press the Navigation control
to start playback all the music files of the selected artist. OR select the desired Album by rotating the Navigation control and
press the Navigation control to confirm. To playback all music files in the album, rotate the Navigation control to select All Songs
and press the Navigation control to start playback of the music files in the selected album. OR rotate the Navigation control to
select the desired music file inside the album. Press the Navigation control to playback the music file selected.
Songs–the Songs/music files will be shown in the display, select the desired music file by rotating the Navigation control; then
press the Navigation control to playback the music file selected.
NOTE: To return to the previous menu, press the Menu/Lock button once.
2 to select
2; the
2
Rotate the Navigation control to select the desired
songs to browse (All Songs, Albums, Artists, Genres,
Songs), then press the Navigation control. (See below
for how to navigate within the category.)
22
OPERATION (CONTINUED)
2
1
FORWARD/REVERSE SKIP
1
During playback, press the Navigation/
Skip/Search ®/l button to advance the
player to the beginning of the next file.
Press the Navigation/Skip/Search ®/l
button repeatedly to advance the player to
higher-numbered files.
HIGH-SPEED MUSIC SEARCH
1
NOTE: If you are not in the Music Player menu, the Forward/Reverse Skip and High-
Speed Music Search functions will not be available.
2
During playback, press the Navigation/Skip/
Search √/m button to move the player back
to the beginning of the currently-playing file.
Press the Navigation/Skip/Search √/m
button repeatedly to move the player back to
lower-numbered files.
During playback, press and hold the
Navigation/Skip/Search √/m 1 or ®/l 2
button to move the player forward or
backward within a file to locate a specific
musical passage. The player will move
forward or backward at high speed as long
as the button is held. When you release the
button, normal playback will resume.
23
OPERATION (CONTINUED)
2
1
1
1
TO SELECT A PLAY MODE
1
Press the Menu/Lock button 1. Rotate the
Navigation control
press the Navigation control
menu will appear.
2 to select Settings, then
2; the Settings
3
Rotate the Navigation control to select a desired Play
mode (Normal, Repeat One, Repeat All, Random or
Random All), then press the Navigation control.
Normal–normal playback mode
Repeat One–repeatedly playback a music file
Repeat All–repeatedly playback all the selected music
files
Random–randomly playback all the selected music
files once
Random All–randomly playback all the selected music
files repeatedly
NOTE: see page 22 for Selecting/Browsing the files.
2
Rotate the Navigation control to select Play Mode,
then press the Navigation control; the Play Mode
menu will appear.
4
Press the Menu/Lock button twice to exit the
menus; the selected mode will be activated.
24
OPERATION (CONTINUED)
2
1
1
2
2
1
1
2
TO SET THE CONTRAST
1
Press the Menu/Lock button 1. Rotate the
Navigation control
press the Navigation control
menu will appear. Rotate the Navigation control
2 to select Contrast, then press the Navigation
2; the Contrast setting will appear.
control
TO SET THE BACKLIGHT
2 to select Settings, then
2; the Settings
1
Press the Menu/Lock button 1. Rotate the
Navigation control
press the Navigation control
menu will appear. Rotate the Navigation control
2 to select Backlight, then press the Navigation
2; the Backlight menu will appear.
control
2 to select Settings, then
2; the Settings
2
Rotate the Navigation control 1 to set the
contrast, then press the Navigation control 1;
the Settings menu will appear. Press the
Menu/Lock button
2 twice to exit the menus.
2
Rotate the Navigation control 1 to select Off, 3
seconds, 5 seconds, 10 seconds or Always On. This
is the time the backlight will be lit before turning off
when no buttons are pressed. Select Off and the
backlight will not light. Press the Navigation control
1 to set; the Settings menu will appear. Press the
Menu/Lock button
25
2 twice to exit the menus.
OPERATION (CONTINUED)
2
1
1
2
TO SET THE POWER SAVINGS
1
Press the Menu/Lock button 1. Rotate the
Navigation control
the Navigation control
appear. Rotate the Navigation control
Power Saving, then press the Navigation control
2; the Power Saving menu will appear.
2 to select Settings, then press
2; the Settings menu will
2 to select
2
Rotate the Navigation control 1 to select Off, 1
minute, 2 minutes, 5 minutes or 15 minutes. This
is the time the unit will stay on if it is in the Stop
mode and no buttons have been pressed for the
set time. Press the Navigation control
the Settings menu will appear. Press the
Menu/Lock button
26
2 twice to exit the menus.
1 to set;
OPERATION (CONTINUED)
2
1
1
2
2
1
1
TO SET THE LANGUAGE
1
Press the Menu/Lock button 1. Rotate the
Navigation control
press the Navigation control
menu will appear. Rotate the Navigation control
2 to select Language, then press the Navigation
2; the Language menu will appear.
control
TO VIEW THE SYSTEM INFO
2 to select Settings, then
2; the Settings
1
Press the Menu/Lock button 1. Rotate the
Navigation control 2 to select Settings,
then press the Navigation control
Settings menu will appear.
2; the
2
Rotate the Navigation control 1 to select
English, Traditional Chinese, Spanish,
French, Dutch or Italian. Press the Navigation
control 1 to set; the Settings menu will
appear. Press the Menu/Lock button
to exit the menus.
2 twice
2
Rotate the Navigation control 1 to select
About, then press the Navigation control 1;
the System Information will appear. Press or
rotate the Navigation control
additional System Info. Press the Menu/Lock
button 2 three times to exit the menus.
27
1 to view
TROUBLESHOOTING GUIDE
If you experience a problem with this unit, check the chart below before calling for service.
SYMPTOM CAUSE SOLUTION
Unit will not Dead battery, or not Replace battery and install
turn on. installed properly. properly.
No sound. Headphones are not Insert headphones.
inserted.
Volume is set too low. Raise the volume.
DRM files copied & pasted. See page 14.
The MP3 or WMA files Download uncorrupted
are corrupted. files.
FM distorted. Station not tuned. Retune station and extend
Download Failure. Damaged USB cable. Replace cable.
The computer is not The USB cable is Make sure USB cable is
recognizing the not securely connected. securely connected.
player.
Win98 driver is not Install Win98 driver and/or
installed or computer is see pages 7 through 10 for
not compatible. compatibility.
headphone wire.
28
TROUBLESHOOTING GUIDE (CONTINUED)
SYMPTOM CAUSE SOLUTION
No buttons work.
Unit acting erratically. Unit needs to be reset Reset unit and/or
WMA files with DRM Incorrect downloading See page 14 to download
cannot playback. methods. WMA files with DRM.
The Lock feature is Deactivate Lock feature as
activated. described on page 17.
Unit needs to be reset Reset unit and/or
or firmware needs to be update firmware, see
updated. page 31.
or firmware needs to be update firmware, see
updated. page 31.
29
FORMATTING THE PLAYER
WARNING! Do not format this player unless it stops working and you are
instructed to do so by technical support personnel.
Formatting the Player
1. Use the USB cable to connect the player and
the computer.
2. Double click on My Computer, right-click the
"Removable Disk" and left-click on "Format".
3. At the "Format" window, select "FAT32" from
the file system pull-down menu, then click start
to format the unit (see figure to the right).
NOTE: Make sure you have selected "FAT32" at
the file system pull-down menu, otherwise after
formatting, the player will not work properly.
4. Click OK to confirm and the player will start to
format.
5. When finished, click "Close" to close the Format window.
495 MB
30
UPDATING THE FIRMWARE
WARNING! Do not update the firmware unless you are experiencing problems with
your digital audio device. Incorrect or faulty firmware installation will cause the player
to stop functioning.
1. Download the updated firmware at www.memorexelectronics.com.
2. Unzip the file, then double-click setup.exe in the Desktop folder to install the
software to your computer.
3. Connect the player to the computer using the supplied USB cable and the
installation screen will appear. (If the installation screen does not appear, unplug
the USB cable and turn off the unit. Connect to the computer again and press and
hold the Power/Stop button until the installation screen appears.)
4. Follow the on-screen instructions to install the driver.
5. When finished, click START and locate the newly-installed software “Memorex
Chrono Digital Audio Player” and select “Firmware Download”.
RESETTING THE UNIT
If the player is not operating properly, try resetting it by removing the battery for a few
seconds.
31
SPECIFICATIONS
Audio Frequency Range 20Hz–20KHz
File Support MP3 MPEG 1/2/2.5 Layer 3
FM Tuner FM Frequency Range 87.5MHz–108MHz
General Dimension 75 x 68 x 25 mm
Headphones Output 10mW, 16ohm (Max. Vol)
S/N Ratio 90dB (MP3)
WMA Windows Media Audio (WMA file with DRM)
Bit Rate 8kbps–320kbps
Tag Info ID3 Tag (Unicode OS)
Antenna Headphones/Earphones Cord
Antenna
Weight 50g (without battery)
Battery 1 x AAA battery
LCD Full Graphic with Backlight
Language 6 Languages (English, Traditional
Chinese, French, Spanish, Dutch,
Italian)
USB USB 2.0
Built-in Memory 512MB
Max. Playtime Approx. 18 hours (128kbps, MP3 files)
Supported OS Win ME, 2000, XP and Mac OSX
Win 98SE (Driver is required)
Operating Temperature 23° F to 104° F (-5° C to 40° C)
Specifications are subject to change without notice.
32
FOR FIRMWARE UPGRADE, PLEASE VISIT OUR WEBSITE AT
WWW.MEMOREXELECTRONICS.COM
TO CHECK IF THERE IS NEW FIRMWARE AVAILABLE.
FOR ADDITIONAL SET-UP OR OPERATING ASSISTANCE,
PLEASE VISIT OUR WEBSITE AT
WWW.MEMOREXELECTRONICS.COM
OR CONTACT CUSTOMER SERVICE AT (954) 660-7100.
PLEASE KEEP ALL PACKAGING MATERIAL FOR AT LEAST 90
DAYS IN CASE YOU NEED TO RETURN THIS PRODUCT TO YOUR
PLACE OF PURCHASE OR TO MEMOREX.
FOR PARTS AND ACCESSORIES, CONTACT FOX INTERNATIONAL
AT 1-800-321-6993.
33
Memcorp, Inc.
Weston, FL
Printed in China
Visit our website at www.memorexelectronics.com
MMP8570-A
Loading...
