Memorex MMP8570 User Manual

MMP8570

User’s Guide

Personal FM Stereo

MP3/WMA Player

Before operating this product,

please read these instructions completely.

PRECAUTIONS

COPYRIGHT:

• Distributing copies of MP3, WMA, WMA with DRM tracks without
permission is a violation of international copyright laws.

SAFETY:

• Vibration experienced during walking or exercising will not affect the player.
However, dropping the player or dropping a heavy object on the player may result
in damage or sound distortion.

• Avoid spilling any liquid onto or into the player.

• Do not leave the player in a location near heat sources; in a location subject to direct
sunlight, excessive dust, sand, moisture, rain or mechanical shock; on an unlevel
surface; or in a car with the windows closed during periods of excessive heat.

ROAD SAFETY:

• Do not use headphones while driving, cycling or operating any motorized vehicle. It
may create a traffic hazard and it is illegal in some areas. It can be potentially
dangerous to play your headset at a high volume while walking, especially at
pedestrian crossings. You should exercise extreme caution or discontinue use in
potentially hazardous situations.

FCC WARNING:

• This equipment may generate or use radio frequency energy. Changes or
modifications to this equipment may cause harmful interference unless the
modifications are expressly approved in the instruction manual. The user could
lose the authority to operate this equipment if an unauthorized change or
modification is made.

1

FCC DECLARATION

This device complies with Part 15 of the FCC rules. Operation is subject to the
following two conditions: 1) This device may not cause interference, and 2) This
device must accept any interference received, including interference that may cause
undesired operation.

Warning: Changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.

NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Shield cable must be used with this unit to ensure compliance with class B FCC
limits.

2

Dear Customer:

Selecting fine audio equipment such as the unit you’ve just purchased is only the start
of your musical enjoyment. Now it’s time to consider how you can maximize the fun
and excitement your equipment offers. This manufacturer and the Electronic Industries
Association’s Consumer Electronics Group want you to get the most out of your
equipment by playing it at a safe level. One that lets the sound come through loud and
clear without annoying blaring or distortion and, most importantly, without affecting
your sensitive hearing.
Sound can be deceiving. Over time your hearing “comfort level” adapts to higher
volumes of sound. So what sounds “normal” can actually be loud and harmful to your
hearing. Guard against this by setting your equipment at a safe level BEFORE your
hearing adapts.

To establish a safe level:

• Start your volume control at a low setting.

• Slowly increase the sound until you can hear it comfortably and clearly, and without
distortion.

Once you have established a comfortable sound level:

• Set the dial and leave it there.

Taking a minute to do this now will help to prevent hearing damage or loss in the future.
After all, we want you listening for a lifetime.

We Want You Listening For A Lifetime

Used wisely, your new sound equipment will provide a lifetime of fun and enjoyment.
Since hearing damage from loud noise is often undetectable until it is too late, this
manufacturer and the Electronic Industries Association’s Consumer Electronics Group
recommend you avoid prolonged exposure to excessive noise. This list of sound levels
is included for your protection.

3

Decibel

A

S

S

O

C

I

A

T

I

O

N

EST. 1924

E

L

E

C

T

R

O

N

I

C

I

N

D

U

S

T

R

I

E

S

EIA

We

LISTENING

For A Lifetime

Want You

Level Example

30 Quiet library, soft whispers
40 Living room, refrigerator, bedroom away from traffic
50 Light traffic, normal conversation, quiet office
60 Air conditioner at 20 feet, sewing machine
70 Vacuum cleaner, hair dryer, noisy restaurant
80 Average city traffic, garbage disposals, alarm clock at two feet

THE FOLLOWING NOISES CAN BE DANGEROUS UNDER CONSTANT EXPOSURE:

90 Subway, motorcycle, truck traffic, lawn mower
100 Garbage truck, chain saw, pneumatic drill
120 Rock band concert in front of speakers, thunderclap
140 Gunshot blast, jet engine
180 Rocket launching pad

Information courtesy of the Deafness Research Foundation.

4

LOCATION OF CONTROLS

1

9

2

4

3

5
6

7

10

8

11
12
13

14

1. Menu/Lock Button

2. VOLUME +/– Buttons

3. Display

4. PRESS TO OPEN Button

5. PLAY/PAUSE

6. Navigation

m Button

®p Button

√/Skip/Search

7. Headphone Jack

8. Power/Stop Button

9. Navigation Control

10. Battery Compartment (Rear
of Unit)

11. Tuning/Navigation Up
▲ Button

12. Navigation ®/Skip/Search
l Button

13. Tuning/Navigation Down
▼ Button

14. USB Port

5

BATTERY INSTALLATION

When the bars in the battery indicator (in the display) become
low (see figure 1), replace the battery as follows.

1. Open the rear cover by pressing the PRESS TO OPEN
button, then lift the rear cover up to remove it as shown in
figure 2.

2. Insert one (1) “AAA” battery as shown in figure 3. An alkaline battery is
recommended for the longest playing time.

3. Put the rear cover back on until it snaps in place.

Figure 3Figure 2

Batt.
Full
Batt.
Low

Figure 1

Follow these precautions when using a battery in this device:

1. Use only the size and type of battery specified.

2. Be sure to follow the correct polarity when installing the battery as indicated. Reversed
batteries may cause damage to the device.

3. If the device is not to be used for a long period of time, remove the battery to prevent damage
or injury from possible battery leakage.

4. Do not try to recharge batteries not intended to be recharged; they can overheat and rupture.
(Follow battery manufacturer’s directions.)

BATTERY PRECAUTIONS

6

INSTALL “DIGITAL AUDIO PLAYER” SOFTWARE

TO INSTALL THE "DIGITAL AUDIO PLAYER" CD SOFTWARE

For Windows ME, Windows2000 or Windows XP:

Windows will automatically detect the audio player without installing the CD software
when the USB cable is connected.

For Macintosh OSX:

Macintosh OSX will automatically detect the audio player without installing the CD
software. Do not install the software when using a Macintosh.

For Windows98SE:

The USB mass storage function will not be activated without driver installation. To
activate the USB mass storage function, please use the installation CD-Rom to install
the driver.
For Windows 98SE, if you are connecting your player to your computer for the first
time, please follow these instructions:

Procedure to Install Player Driver

1. Insert the Installation CD-Rom
into the CD Drive; the auto-run
program will display the Main
Menu window. Click “Software
Drivers”.

NOTE: If the Main Menu window
does not appear, double click
“Memorex Startup CD” application
file on the Installation CD to open
the Main Menu window.

7

WINDOWS 98 DRIVER INSTALLATION

2. Click “MMP8570” to run the

Windows 98SE driver.

3. Follow the on-screen

instructions to install the
software.

8

WINDOWS 98 DRIVER INSTALLATION (CONTINUED)

4. Install the software under
the directory as prompted.

Warning: DO NOT change the
installation path. Otherwise, the
driver may not run properly.

9

WINDOWS 98 DRIVER INSTALLATION (CONTINUED)

5. After successfully installing the driver software, click "Finish" to finish the
installation and exit the Setup menu.

6. When the installation has completed, the new program, “Memorex Chrono Digital
Audio Player”, will be added to the PROGRAM menu on your computer.

10

DOWNLOADING AND TRANSFERRING FILES

TRANSFERRING FILES

You can download digital music files from the Internet or use encoding software to convert
music that you have on an audio CD into MP3 or WMA format. Once these files are stored on
your computer you can easily copy them to your player.

Connect the computer to your player using the supplied USB cable.

Press the Power/Stop button to turn the unit on.

A "Removable Disk" window will automatically pop up on your
computer screen.
To add more files and songs to your player simply drag and drop
MP3 or WMA files from anywhere on your computer into the

"Removable Disk" window.
IMPORTANT NOTE: A WMA file with DRM will not play back if you directly drag and drop it
into the “Removable Disk” window. You must use MMJB or Windows Media Player to transfer
copy protected files.
When you are finished, see the Safely Remove Hardware procedure on the next page before
disconnecting the player.

11

SAFELY REMOVE HARDWARE

SAFELY REMOVING YOUR PLAYER FROM THE COMPUTER
NOTE: To avoid damage to your player or data loss, always follow the procedure listed

below before disconnecting the USB cable from your computer or disconnecting the
player from the USB cable.

Using your mouse, double click the "Safely Remove
Hardware" icon on the task bar.

From the "Safely Remove Hardware" window, select
"USB Mass Storage Device" and click the "Stop"
button. The "Stop a Hardware Device" window will pop up as shown:
Click "OK". When the "Safe to Remove Hardware" window is displayed, you may
remove the player from the USB cable or remove the USB cable from the computer.

NOTES:

• If the “Safely Remove Hardware” icon is not displayed on the task bar, please double

click on My Computer. Right click on “Removable Disk” and left click on “Eject”. Then
it is safe to remove the player from the computer.

• The “Safely Remove Hardware” procedure is not necessary for Win98 and Win98SE

users.

12

INSTALLING MUSICMATCH JUKEBOX

NOTE: WMA DRM protected files will not play if you use the ‘drag and drop’ procedure.

You must follow the procedure below to play WMA DRM files on your MMP8570.

1. Install the MMJB Software as described above.

2. Turn the unit ON, then connect the USB cable to the unit and the USB port of the
computer. “Transfer Mode” will be displayed on the LCD when it is properly
connected.

5. The tracks are now properly transferred to the player. Follow the “Safely

Removing Hardware” section on the previous page. Unplug the unit from the
computer and insert the headphones and listen to your music.

13

INSTALLING MUSICMATCH JUKEBOX (CONTINUED)

14

DOWNLOADING AND TRANSFERRING FILES (CONTINUED)

EXTERNAL MEMORY CARD
TO AVOID DAMAGE, make sure the unit is off before

inserting or removing the card.

1. Remove the rear cover by pressing the PRESS TO
OPEN button, then lift the rear cover up to remove it
as shown in Figure 1.

2. Insert a SD/MMC memory card (not included) up to
512MB, facing up as shown in Figure 2.

3. Connect the USB cable as described previousl

The unit will turn on automatically.

y.

NOTE: If the unit cannot turn on automatically when

connected to the computer using the USB cable.
Remove the inserted SD/MMC memory card then
try again.

4. Drag MP3 and WMA files into the SD/MMC memory
card's "Removable Disk" window.".

NOTE: The WMA file with DRM will not playback if you
directly drag and drop it into the “Removable Disk”
window. See pages 13-14 for downloading WMA files
with DRM from the computer to your player.

Figure 1

Figure 2

5. To remove the SD/MMC memory card,
off, then push the edge of the card as shown in
Figure 3, then the card will spring out. Carefully
remove the card.

6. Replace the rear cover until it snaps in place.

NOTE: If the external memory card is inserted while in
the MUSIC PLAYER mode, the memory card indicator
will appear at the top side of the display.

turn the unit

15

Figure 3

OPERATION

2

1

TURNING THE POWER ON/OFF

LOCK SWITCH

1

Turn the unit on by pressing the Power/Stop
button; the Memorex start screen will appear in
the display temporarily. Then the Music Player
menu will appear and the MP3/WMA track’s
information will appear in the display. To turn the
unit off, press and hold the Power/Stop button;
“Hold Down To Power Off” will appear in the
display. The unit will turn off after it counts up from
one to three. Do not release the Power/Stop
button until the unit turns off.

1

Press and hold the Menu/Lock button until “LOCKED”
and the Lock icon appears in the display, then release.
Then a small Lock icon will appear at the top right side of
the display which indicates that the Lock function is
activated (no buttons will be able to be pressed). This is
useful when you do not want the station/track changed by
accidentally pressing a button. To cancel the Lock
function, press and hold the Menu/Lock button until
“UNLOCKED” appears and the Lock icon flashes in the
display. Then the small Lock icon will disappear from the
display which indicates that the Lock function is cancelled.

NOTE: An illustration of the Lock icon follows:

EQ–MUSIC PLAYER ONLY

1

NOTE: To operate this unit, you can use the Navigation/Skip/Search √/m or ®/l button

and/or the Tuning/Navigation Up

Press the Menu/Lock button 1; the Menu will appear. Rotate the Navigation

2 to select Settings, then press the Navigation control 2; the

control
Settings menu will appear. Rotate the Navigation control
Equalizer, then press the Navigation control
appear. Rotate the Navigation control
Normal, Rock, Jazz, Classical, Pop or Bass. Press the Navigation control
to exit the Equalizer menu. Press the Menu/Lock button 1 to exit the
Settings menu. Rotate the Navigation control
press the Navigation control
bottom left of the display when in Music Player menu.

2. The selected EQ setting will appear at the

2; the Equalizer menu will

2 to select the desired EQ setting:

2 to select Now Playing, then

2 to select

▲ or Down ▼ button in place of the Navigation control.

16

2

OPERATION (CONTINUED)

2

1

1

TO LISTEN TO THE FM RADIO

1

Turn the unit on by pressing the Power/Stop
button; the Memorex start screen will appear
in the display temporarily. Then the Music
Player menu will appear and the MP3/WMA
track’s information will appear in the display.

3

Select a station by rotating the Navigation
control. When a station is broadcasting in
stereo, “STEREO” will appear in the
display, otherwise “MONO” will appear in
the display.
NOTE: See note on Navigation at the
bottom of page 16.

AUTO SCAN: When you select the Radio mode for the first time, the unit will auto­matically scan and set the available stations into presets 1 through 10. Then Channel 1
will appear with the corresponding frequency tuned in. If there are no available stations,
the frequency of the presets will be kept at 87.5MHz.

2

Press the Menu/Lock button 1; the Menu
will appear. Rotate the Navigation control to
select FM Tuner, then press the Navigation
control 2; the FM Tuner will appear.

4

Press the VOLUME +/- buttons to increase
or decrease the volume.

ANTENNA
FM–The headphones act as an antenna for

FM. Extend the headphone wire for best FM
reception.

17

OPERATION (CONTINUED)

2

1

3

2

1

TO MANUALLY SET A STATION INTO MEMORY

1

Follow the steps on the previous page to turn on the
unit and enter the FM Tuner mode. Select the
desired channel number to set using the
Navigation/Skip/Search
Tune a station using the Navigation control
NOTE: See note on Navigation at the bottom of
page 16.

√/m 1 or ®/l 2 button.

3.

TO RECEIVE MEMORY PRESETS

1

Select a desired preset channel by using
the Navigation/Skip/Search

button.

2

√/m 1 or ®/l

2

When a desired station is tuned, press the
PLAY/PAUSE ®p button to store the
preset; “CHANNEL” will blink twice in the
display and the station will be set into
memory.

18

OPERATION (CONTINUED)

2

1

2

1

3

TO LISTEN TO MP3s/WMAs

1

Turn the unit on by pressing the Power/Stop button
❶; the Memorex start screen will appear in the
display temporarily. Then the Music Player menu will
appear and the MP3/WMA track’s information will
appear in the display. Press the PLAY/PAUSE

2

2

button

to start playback; the MP3/WMA information
will scroll across the display and the song number
and timer will appear at the top of the display.

3

Set the Equalizer as shown on page 16.
Press the VOLUME +/- buttons to increase
or decrease the volume.

NOTE: If you are not in the Music Player menu, the Stop function will not be available. Press the
Navigation/Skip/Search

√/m or ®/l button until the unit returns to the Music Player menu.

2

If the unit is in a mode other than the MP3 /WMA player,
press the Menu/Lock button

appear in the display
select “Play Now”
select and enter the Music Player menu and the

®p

MP3/WMA track’s information will appear in the display.
Press the PLAY/PAUSE
NOTE: If the unit is already playing a MP3/WMA track,
“Play Now” will change to “Now Playing”.

. Rotate the Navigation control

, then press the Navigation control

❶; the Main menu will

®p button 3 to start playback.

4

Press the Power/Stop button to stop playback.
To turn the unit off, press and hold the Power/Stop
button; “Hold Down To Power Off” will appear in the
display. The unit will turn off after it counts up from one
to three. Do not release the Power/Stop button until
the unit turns off.

NOTE:

• See pages 7 through 15 for information on
uploading MP3 and WMA files to this unit.

19

2 to
2 to

OPERATION (CONTINUED)

2

1

1

TO PAUSE PLAYBACK

1

During playback, if you wish to pause the
file momentarily, press the PLAY/PAUSE
®p button; playback will pause, the Pause
indicator will appear and the timer will stop
counting.

2

Press the PLAY/PAUSE ®p button again to resume
playback; the sound will return, the Play indicator
will appear and the timer will start counting again.
NOTE: If you are not in the Music Player menu, the
Pause function will not be available. Press the
Navigation
returns to the Music Player menu.

√/Skip/Search m button until the unit

TO SELECT/BROWSE THROUGH THE FILES

1

Press the Menu/Lock button 1; the Main menu will
appear. Rotate the Navigation control
Browse, then press the Navigation control
Root folder contents will appear.

NOTE: If you select a track/file inside a particular folder, the total tracks/files in that folder will appear at the
top of the display and the unit will only play the tracks/files in that folder. To play all the tracks on the unit (in
both the Internal and External memories), press the Menu/Lock button to enter the Main menu, then select
Browse and press the Navigation control to enter the Browse menu. Then select All Music using the
Navigation control. Press the Navigation control and the total tracks/files (of both the Internal and External
memories) will be shown at the top of the display.

2 to select

2; the

2

Rotate the Navigation control to select Internal or
External (card), then press the Navigation control; the
contents of the folder will appear. Rotate the
Navigation control to browse through the files, then
press the Navigation control to select a file to play; the
file will automatically start playing.

20

OPERATION (CONTINUED)

2

1

FORWARD/REVERSE SKIP

1

During playback, press the
Navigation/Skip/Search ® /l button to
advance the player to the beginning of the
next file. Press the Navigation/Skip/Search
®/l button repeatedly to advance the
player to higher-numbered files.

2

During playback, press the
Navigation/Skip/Search
the player back to the beginning of the currently
playing file. Press the Navigation/Skip/Search
√/m button repeatedly to move the player back
to lower-numbered files.

√/m button to move

HIGH-SPEED MUSIC SEARCH

1

NOTE: If you are not in the Music Player menu, the Forward/Reverse Skip and High-Speed Music

Search functions will not be available. Press the Navigation/Skip/Search
unit returns to the Music Player menu.

During playback, press and hold the press
the Navigation/Skip/Search √/m 1 or ®/l
2 button to move the player forward or
backward within a file to locate a specific
musical passage. The player will move
forward or backward at high speed as long
as the button is held. When you release the
button, normal playback will resume.

√/m or ®/l button until the

21

OPERATION (CONTINUED)

2

1

1

1

2

1

TO SELECT A PLAY MODE

1

Press the Menu/Lock button 1. Rotate the
Navigation control
press the Navigation control
menu will appear.

2 to select Settings, then

2; the Settings

3

Rotate the Navigation control to select a
desired Play mode (Normal, Repeat Track,
Repeat All, Shuffle or Shuffle Repeat) , then
press the Navigation control; the respective
indicator will appear at the top of the display
and the Settings menu will appear.

2

Rotate the Navigation control to select Play
mode, then press the Navigation control; the
Play Mode menu will appear.

4

Press the Menu/Lock button 1 once to return
to the Main Menu. Rotate the Navigation
control 2 to select Now Playing, then press
the Navigation control
will be activated.

22

2; the selected mode

OPERATION (CONTINUED)

2

1

1

2

1

1

TO SET THE CONTRAST

1

Press the Menu/Lock button 1. Rotate the
Navigation control
press the Navigation control
menu will appear. Rotate the Navigation control
2 to select Contrast, then press the Navigation
control; the Contrast setting will appear.

TO SET THE BACKLIGHT

2 to select Settings, then

2; the Settings

1

Press the Menu/Lock button 1. Rotate the
Navigation control
press the Navigation control
menu will appear. Rotate the Navigation control
2 to select Backlight, then press the Navigation
control; the Backlight menu will appear.

2 to select Settings, then

2; the Settings

2

Rotate the Navigation control to set the
contrast, then press the Navigation control; the
Settings menu will appear.

2

Rotate the Navigation control to select Always
Off, 3 seconds, 5 seconds, 10 seconds or
Always On. This is the time the backlight will
be lit before turning off when no buttons are
pressed. Select Always Off and the backlight
will not light. Press the Navigation control to
set; the Settings menu will appear.

23

OPERATION (CONTINUED)

2

1

1

TO SET THE POWER SAVINGS

1

Press the Menu/Lock button 1. Rotate the
Navigation control
the Navigation control
appear. Rotate the Navigation control
Power Savings, then press the Navigation control

2; the Power Savings menu will appear.

2 to select Settings, then press

2; the Settings menu will

2 to select

2

Rotate the Navigation control to select Disable,
1 minute, 3 minutes, 5 minutes or 10 minutes.
This is the time the unit will stay on if it is not in
Play mode and no buttons have been pressed
for the set time. Press the Navigation control to
set; the Settings menu will appear.

24

OPERATION (CONTINUED)

2

1

1

2

1

1

TO SET THE LANGUAGE

1

Press the Menu/Lock button 1. Rotate the
Navigation control 2 to select Settings, then
press the Navigation control
menu will appear. Rotate the Navigation control
2 to select Language, then press the Navigation
control 2; the Language menu will appear.

TO VIEW THE SYSTEM INFO

2; the Settings

1

Press the Menu/Lock button 1. Rotate the
Navigation control
press the Navigation control
menu will appear.

NOTE: Press the Menu/Lock button to exit the Settings Menu and return to the Main menu.

2 to select Settings, then

2; the Settings

2

Rotate the Navigation control to select English,

Traditional Chinese, French, Spanish, Dutch
or Italian. Press the Navigation control to set;

the Settings menu will appear.

2

Rotate the Navigation control to select System
Info, then press the Navigation control; the
System Information will appear. Press the
Navigation control to exit System Info; the
Settings menu will appear.

25

2

1

2

1

1

2

DELETING A FILE

SPECIFICATIONS

1

While in the Music Player Menu, press the
Navigation/Skip/Search
to select the file that you wish to delete.
NOTE: You can also use the Browse function
(see page 20) to browse and select a file to
delete.

√/m 1 or ®/l 2 button

3

Rotate the Navigation control 1 to highlight
"Yes" or "No". If you highlight "Yes", then press
the Navigation control, the selected file will be
deleted. If you highlight "No" , then press the
Navigation control
next MP3/WMA file. Press the Menu/Lock

2 once to cancel the Delete File

button
function and return to the main menu.

1, the unit will skip to the

2

When the selected MP3/WMA file's information
appears in the display, press the Menu/Lock
button

1; the Main Menu will appear. Rotate
the Navigation control to select Delete File
then press the Navigation control
file menu will appear in the display.

26

2; the delete

2,

TROUBLESHOOTING GUIDE

If you experience a problem with this unit, check the chart below before calling for service.

SYMPTOM CAUSE SOLUTION

Unit will not Dead battery, or not Replace battery and install
turn on. installed properly. properly.

No sound. Headphones are not Insert headphones.

inserted.
Volume is set too low. Raise the volume.
DRM files copied & pasted. See pages 13-14.
The MP3 or WMA files Download uncorrupted
are corrupted. files.

FM distorted. Station not tuned. Retune station and extend

Download Failure. Damaged USB cable. Replace cable.
The computer is not The USB cable is Make sure USB cable is
recognizing the not securely connected. securely connected.
player.

Win98 driver is not Install Win98 driver and/or
installed or computer is see pages 7 through 10 for
not compatible. compatibility.

headphone wire.

27

TROUBLESHOOTING GUIDE (CONTINUED)

SYMPTOM CAUSE SOLUTION

No buttons work.

Unit acting erratically. Unit needs to be reset Reset unit and/or

WMA files with DRM Incorrect downloading See pages 13-14 to

cannot playback. methods. download WMA files with DRM.

The Lock feature is Deactivate Lock feature as
activated. described on page 16.
Unit needs to be reset Reset unit and/or
or firmware needs to be update firmware, see
updated. pages 29-30.

or firmware needs to be update firmware, see
updated. pages 29-30.

28

FORMATTING THE PLAYER

WARNING! Do not format this player unless it stops working and you are

instructed to do so by technical support personnel.

Formatting the Player

1. Use the USB cable to connect the player and
the computer.

2. Double click on My Computer, right click the
"Removable Disk" and left click on "Format".

3. At the "Format" window, select "FAT32" from
the file system pull down menu, then click start
to format the unit (see figure to the right).

NOTE: Make sure you have selected the "FAT32"
at the file system pull down menu, otherwise after
formatting, the player will not work properly.

4. Click OK to confirm and the player will start to
format.

5. When finished, click "Close" to close the Format window.

29

UPDATING THE FIRMWARE

WARNING! Do not update the firmware unless you are experiencing problems with

your digital audio device. Incorrect or faulty firmware installation will cause the player
to stop functioning.

1. Download the updated firmware at www.memorexelectronics.com.

2. Unzip the file, then double click setup.exe in the Desktop folder to install the
software to your computer.

3. Connect the player to the computer using the supplied USB cable and the
installation screen will appear. (If the installation screen does not appear, unplug
the USB cable and turn off the unit. Connect to the computer again and press &
hold for the Power/Stop button until the installation screen appears.

4. Follow the on-screen instructions to install the driver.

5. When finished, click START and locate the newly installed software “Memorex
Chrono Digital Audio Player” and select “Firmware Download”.

RESETTING THE UNIT

If the player is not operating properly, try resetting it by removing the battery for a few
seconds.

30

SPECIFICATIONS

Audio Frequency Range 20Hz – 20KHz

File Support MP3 MPEG 1/2/2.5 Layer 3

FM Tuner FM Frequency Range 87.5MHz – 107.9 MHz

General Dimension 75 x 68 x 25 mm

Headphones Output 10mW, 16ohm (Max. Vol)
S/N Ratio 90dB (MP3)

WMA Windows Media Audio (WMA file with DRM)
Bit Rate 8kbps – 320kbps
Tag Info ID3 Tag (Unicode OS)

Antenna Headphones/Earphones Cord

Antenna

Weight 50g (without battery)
Battery 1 x AAA battery
LCD Full Graphic with Backlight
Language 6 Languages (English, Traditional

Chinese, French, Spanish, Dutch,

Italian)
USB USB 2.0
Built-in Memory 512MB
Max. Playtime Approx. 18 hours (128kps, MP3)
Supported OS Win ME, 2000, XP and Mac OSX

Win 98SE (Driver is required)
Operating Temperature 23° F to 104° F (-5° C to 40° C)

Specifications are subject to change without notice.

31

FOR FIRMWARE UPGRADE, PLEASE VISIT OUR WEBSITE AT

WWW.MEMOREXELECTRONICS.COM

TO CHECK IF THERE IS NEW FIRMWARE AVAILABLE.

FOR ADDITIONAL SET-UP OR OPERATING ASSISTANCE,
PLEASE VISIT OUR WEBSITE AT

WWW.MEMOREXELECTRONICS.COM

OR CONTACT CUSTOMER SERVICE AT [phone].

PLEASE KEEP ALL PACKAGING MATERIAL FOR AT LEAST 90
DAYS IN CASE YOU NEED TO RETURN THIS PRODUCT TO YOUR
PLACE OF PURCHASE OR TO MEMOREX.

FOR PARTS AND ACCESSORIES, CONTACT FOX INTERNATIONAL
AT 1-800-321-6993.

32

Memcorp, Inc.

Weston, FL

Printed in China

Visit our website at www.memorexelectronics.com
