User’s Guide
256MB MP3/WMA
Digital Audio Player
MMP8564
Before operating this product,
please read these instructions completely.
COPYRIGHT:
• Distributing copies of MP3, WMA with DRM or WAV tracks without permission is a
violation of international copyright laws.
SAFETY:
• Vibration experienced during walking or exercising will not affect the player. However,
dropping the player or dropping a heavy object on the player may result in damage or
sound distortion.
• Avoid spilling any liquid onto or into the player.
• Do not leave the player in a location near heat sources; in a location subject to direct
sunlight, excessive dust, sand, moisture, rain or mechanical shock; on an unlevel
surface; or in a car with the windows closed during periods of excessive heat.
ROAD SAFETY:
• Do not use headphones while driving, cycling or operating any motorized vehicle. It
may create a traffic hazard and it is illegal in some areas. It can be potentially
dangerous to play your headset at a high volume while walking, especially at pedestrian
crossings. You should exercise extreme caution or discontinue use in potentially
hazardous situations.
FCC WARNING:
• This equipment may generate or use radio frequency energy. Changes or
modifications to this equipment may cause harmful interference unless the
modifications are expressly approved in the instruction manual. The user could lose
the authority to operate this equipment if an unauthorized change or modification is
made.
PRECAUTIONS
1
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
2
FCC DECLARATION
This device complies with Part 15 of the FCC rules. Operation is subject to the
following two conditions: 1) This device may not cause interference, and 2) This
device must accept any interference received, including interference that may cause
undesired operation.
Warning: Changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Shield cable must be used with this unit to ensure
compliance with class B FCC limits.
Dear Customer:
Selecting fine audio equipment such as the unit you’ve just purchased is only the start
of your musical enjoyment. Now it’s time to consider how you can maximize the fun
and excitement your equipment offers. This manufacturer and the Electronic Industries
Association’s Consumer Electronics Group want you to get the most out of your
equipment by playing it at a safe level. One that lets the sound come through loud and
clear without annoying blaring or distortion and, most importantly, without affecting
your sensitive hearing.
Sound can be deceiving. Over time your hearing “comfort level” adapts to higher
volumes of sound. So what sounds “normal” can actually be loud and harmful to your
hearing. Guard against this by setting your equipment at a safe level BEFORE your
hearing adapts.
To establish a safe level:
• Start your volume control at a low setting.
• Slowly increase the sound until you can hear it comfortably and clearly, and without
distortion.
Once you have established a comfortable sound level:
• Set the dial and leave it there.
Taking a minute to do this now will help to prevent hearing damage or loss in the future.
After all, we want you listening for a lifetime.
We Want You Listening For A Lifetime
Used wisely, your new sound equipment will provide a lifetime of fun and enjoyment.
Since hearing damage from loud noise is often undetectable until it is too late, this
manufacturer and the Electronic Industries Association’s Consumer Electronics Group
recommend you avoid prolonged exposure to excessive noise. This list of sound levels
is included for your protection.
3
Decibel
Level Example
30 Quiet library, soft whispers
40 Living room, refrigerator, bedroom away from traffic
50 Light traffic, normal conversation, quiet office
60 Air conditioner at 20 feet, sewing machine
70 Vacuum cleaner, hair dryer, noisy restaurant
80 Average city traffic, garbage disposals, alarm clock at two feet
THE FOLLOWING NOISES CAN BE DANGEROUS UNDER CONSTANT EXPOSURE:
90 Subway, motorcycle, truck traffic, lawn mower
100 Garbage truck, chain saw, pneumatic drill
120 Rock band concert in front of speakers, thunderclap
140 Gunshot blast, jet engine
180 Rocket launching pad
Information courtesy of the Deafness Research Foundation.
4
A
S
S
O
C
I
A
T
I
O
N
EST. 1924
E
L
E
C
T
R
O
N
I
C
I
N
D
U
S
T
R
I
E
S
EIA
We
LISTENING
For A Lifetime
Want You
LOCATION OF CONTROLS
5
1. Headphone Jack
2. Battery Compartment
(Under Cover)
3. MENU/Lock Button
(Side of Unit)
4. Power On/Off/Stop Button
(Side of Unit)
5. Navigation Control*: (clockwise)
Navigation
π
Navigation ®/Skip/Search n
Navigation †
Navigation √/Skip/Search o
6. USB Jack & SD/MMC Memory
Card Slot (Under Cover)
7. Display
8. Volume + Button
9. Volume - Button
10. Play/Pause
®p Button*
*Pressing the Navigation control also
acts as an Enter/Select/Play/Pause
®p
button.
6
BATTERY INSTALLATION
When the bars in the battery indicator (in the display) become low (see Figure 1),
replace the battery as follows.
1. Remove the top cover by pressing the
Open button, then lifting the top cover
up to remove it as shown in Figure 2.
2. Insert one (1) “AAA” battery (positive
side facing the bottom of the unit and negative side facing the top) as shown
in Figure 3, making sure to close the battery latch (press down the battery
latch and slide the latch until it locks in place). An alkaline battery is
recommended
for the longest
playing time.
3. Put the top
cover back on
until it snaps in
place.
BATTERY PRECAUTIONS
Follow these precautions when using a battery in this device:
1. Use only the size and type of battery specified.
2. Be sure to follow the correct polarity when installing the battery as indicated. Reversed
batteries may cause damage to the device.
3. If the device is not to be used for a long period of time, remove the battery to prevent damage
or injury from possible battery leakage.
4. Do not try to recharge batteries not intended to be recharged; they can overheat and rupture.
(Follow battery manufacturer’s directions.)
Figure 3
Figure 1
Figure 2
NOTE: Each time after you have replaced the battery, when you turn on the unit again, it
will search the music files to update the index. It will take approx. several seconds to update
the index; this updating time depends on the number of music files in the SD/MMC card and
in the internal memory.
FULL 50% EMPTY
+
-
7
USING THE ARM STRAP
Insert the arm strap into the slot on
the rear of the unit and pull through.
1
Pull the arm strap and insert it into
the buckle.
2
Insert the arm strap into the slot on
the rear of the unit and pull through.
3
TO INSTALL THE "DIGITAL AUDIO PLAYER" CD SOFTWARE
For Windows ME, Windows2000 or Windows XP:
Windows will automatically detect the audio player without installing the CD software
when the USB cable is connected.
For Macintosh OSX:
Macintosh OSX will automatically detect the audio player without installing the CD
software. Do not install the software when using a Macintosh.
For Windows98SE:
The USB mass storage function will not be activated without driver installation. To
activate the USB mass storage function, please use the installation CD-Rom to install
the driver.
For Windows 98SE, if you are connecting your player to your computer for the first
time, please follow these instructions:
Procedure to Install Player Driver
1. Insert the Installation CD-Rom
into the CD Drive, then the
installation screen will appear. If
the installation screen doesn't
automatically appear, doubleclick my computer then doubleclick on the CD drive, then the
installation screen will appear.
Click on the Windows 98
firmware icon. Then click on the
MMP8564 icon.
INSTALL “DIGITAL AUDIO PLAYER” SOFTWARE
8
2. At the Welcome screen, click NEXT.
3. Read the License Agreement. If you accept
the terms of the license agreement, select
and dot the circle at the left of "I accept the
terms of the license agreement". Then click
NEXT.
4. At the Setup screen, click NEXT. It is
recommended to leave the destination folder
as it is.
WINDOWS 98 DRIVER INSTALLATION
9
5. At the Program Folder screen, click NEXT. It
is recommended to leave the program folder
as it is.
6. Click "Install" to start the installation.
7. When finished, the InstallShield Wizard
Complete screen will appear. Click FINISH to
exit the Install program and complete the
Windows 98 Driver installation.
WINDOWS 98 DRIVER INSTALLATION (CONTINUED)
10
WINDOWS MEDIA PLAYER 10 INSTALLATION
11
Windows Media Player 10 is for use with
Windows XP only. For Windows ME and
Windows 2000, please install Windows Media
Player 9. For Windows 98SE, please visit
www.Microsoft.com to download the
corresponding Windows Media Player for your
computer.
Once you have installed Windows Media Player
10, you can transfer MP3 files, WMA files, WMA
files with DRM 9 or DRM 10 to your player using
the “Sync” function.
1. Insert the Installation CD-Rom into the CD
Drive, then the installation screen will appear.
If the installation screen doesn’t automatically
appear, double-click “My Computer” then
double-click on the CD drive, then the
installation screen will appear. Click on the
Windows Media Player 10 Setup icon.
2. Installation will begin.
3. Read the License Agreement, then click I
ACCEPT.
4. Installation will continue.
5. At the Welcome screen, click NEXT.
6. Select the desired privacy options.
WINDOWS MEDIA PLAYER 10 INSTALLATION (CONT.)
12
7. Click on Privacy Statement to view the
Statement, if desired. When finished, click
Next.
8. Read the instructions and tick the check
boxes as desired. Then click on More
Options and tick the check boxes as desired.
9. Click “Finish” to finish the installation of the
Windows Media Player 10.
WINDOWS MEDIA PLAYER 10 INSTALLATION (CONT.)
13
DOWNLOADING AND TRANSFERRING FILES
14
TRANSFERRING FILES
You can download digital music files from the Internet or use encoding software to
convert music that you have on an audio CD into MP3 or WMA format. Once these
files are stored on your computer you can easily copy them
to your player.
For Windows XP, if you already installed Windows Media
Player 10, you can transfer music files (MP3, WMA, WMA
files with DRM 9 or DRM 10) to the player through the
"Sync" function of Windows Media Player 10. Connect your
computer to the USB port on your
computer using the USB cable.
“Removable Disk” will appear in
your "My Computer" folder which
indicates the player is connected.
Also, the player will display the
above figure. Then, follow the
procedure on page 17 to transfer music files to the player.
For Windows ME, Windows 2000, Windows 98 or Windows XP (without
Windows Media Player 10)
, transfer music files as follows:
1. Connect your player to the USB port on your computer using the USB cable as
shown above.
2. A "Removable Disk" window will automatically pop-up on your computer
screen.
3. To add more files and songs to your player, simply drag and drop MP3 or WMA
files from anywhere on your computer into the "Removable Disk" window.
IMPORTANT: A WMA file with DRM 9 or DRM 10 will not play back if you directly
drag and drop it into the "Removable Disk" window. You must use Windows Media
Player 10 to transfer copy-protected files as described on page 17.
TRANSFERRING AUDIO FILES TO YOUR DIGITAL AUDIO PLAYER USING A
MACINTOSH COMPUTER
Make sure to use a Macintosh computer with an operating system of 10.0 or layer to
transfer audio files.
1. Turn on your computer.
2. Turn on your digital audio player.
3. Connect the smaller end of the cable to the USB jack on the player and the larger
end of the cable to the USB port on your Macintosh.
4. Your computer will automatically recognize your player and mount a hard disk icon
onto your desktop.
5. Locate the folder where your audio files are stored on your computer’s hard drive.
Simply drag and drop the audio files onto the mounted hard disk drive icon of your
digital audio player located on your desktop.
6. After you have finished your transfer, put away the digital audio player hard disk
icon(s) by dragging it to the Trash icon or Control-click its icon and choose Eject from
the File menu or select Eject from the File drop-down menu located at the top of your
screen. You can also use the keyboard shortcuts by selecting the digital audio player
hard disk icon and pressing the Command-E keys.
7. Your player is ready to play the files you transferred.
DOWNLOADING AND TRANSFERRING FILES (CONT.)
15
For Windows XP, you can also utilize the previously
installed Windows Media Player 10 software to
convert music on an audio CD into MP3 or WMA
format as follows:
1. Open the Windows Media Player 10 Browser,
then click on the “Rip” icon on the top tool bar.
Insert a Music CD into the CD-Rom drive of your
computer.
NOTE: For Windows 98SE, Windows ME and
Windows 2000, please use the Windows Media
Player 9 to convert music on an audio CD into MP3 or
WMA format.
2. Click on the “Tools” menu option at the top menu bar,
then click on “Options”; the Option setting menu will
appear. Click on Rip Music and set the Rip Music to the
desired location on your computer. Then, set the desired
format for the newly ripped music (MP3 format or
Windows Media Audio format). Adjust the audio quality as
desired. When finished, click “OK” to confirm the settings.
3. Click on the “Rip Music” icon to start ripping the music to
your computer.
4. When the music tracks are ripped; connect the player to
your computer. Open the “Removable Disk” window and
open the ripped music location window.
5. To add the transferred/ripped music files/songs to your player simply drag and drop the MP3
and/or WMA files into the “Removable Disk” window.
6. When the files are finished loading into the player, follow the “Safely Remove
Hardware” procedure as shown on page 18.
DOWNLOADING AND TRANSFERRING FILES (CONT.)
16
DOWNLOADING AND TRANSFERRING FILES (CONT.)
17
TRANSFERRING MP3/WMA FILES AND WMA
FILES WITH DRM 9 OR DRM 10 USING THE
WINDOWS MEDIA PLAYER 10 (FOR WINDOWS
XP ONLY)
To transfer MP3 files/WMA files/WMA files with DRM
9 or 10 to the player, follow the procedure described
below using the previously installed Windows Media
Player 10. Before beginning the procedure please
turn the unit on and connect the unit to the computer
as previously described.
1. Open the “Windows Media Player Browser 10”
and click on “Sync”.
2. Click on the “Sync List” pull-down menu to
locate the music files you wish to download.
Then make sure to tick the box next to the files.
3. Select the Portable Device (“Removable Disk”)
that you want to copy to from the right side
drop-down menu. Click “Start Sync” to start
transferring music files to the player.
4. After finished transferring all the desired files to
your unit, follow the “Safely Remove Hardware”
procedure on the next page.
NOTES:
• For WMA files with DRM 10, you can only use
Windows Media Player 10 to transfer files to
your player.
• For WMA files with DRM 10, the files will not be
played if you transfer the files into the SD/MMC
card’s memory. You must transfer the WMA files
with DRM 10 to the player’s internal memory for
playback.
• For Windows ME and Windows 2000, please
use Windows Media Player 9 to transfer WMA
files with DRM 9 to the player. For Windows
98SE, please visit
www.Microsoft.com to
download the corresponding Windows Media
Player to transfer music files to the player.
18
SAFELY REMOVE HARDWARE
SAFELY REMOVING YOUR PLAYER FROM THE COMPUTER
NOTE:
To avoid damage to your player or data loss, always follow the procedure listed below
before disconnecting your player from the USB port on your computer.
Using your mouse, double click the "Safely Remove
Hardware" icon on the task bar.
From the "Safely Remove Hardware" window, select "USB
Mass Storage Device" and click the "Stop" button. The
"Stop a Hardware Device" window will pop-up as shown:
Click "OK". When the "Safe to Remove Hardware" window is displayed, you may remove the
player from the USB cable or remove the USB cable from the computer.
NOTES:
• If the “Safely Remove Hardware” icon is not displayed on the task bar, please double click
on My Computer. Right click on “Removable Disk” and left click on “Eject”. Then it is safe to
remove the player from the computer.
• The “Safely Remove Hardware” procedure is not necessary for Win98 and Win98SE users.
19
DOWNLOADING AND TRANSFERRING FILES (CONTINUED)
EXTERNAL MEMORY CARD
TO AVOID DAMAGE, make sure the unit is off before inserting or
removing the card.
1. Remove the top cover by pressing the Open button, then lifting
the top cover up to remove it as shown in Figure 1.
2. Insert a SD/MMC memory card (not included) up to 1GB, label
side facing the rear of the player, as shown in Figure 2.
3. Connect the USB cable as described previously.
4. Drag MP3 and WMA files into the SD/MMC memory card's
"Removable Disk" window.
NOTE: A WMA file with DRM will not playback if you directly drag
and drop it into the “Removable Disk” window. See page 17 for
downloading WMA files with DRM from the computer to your
player.
5. To remove the SD/MMC memory card,
turn the unit off, then
push the edge of the card and the card will spring out. Carefully
remove the card, as shown in Figure 3.
6. Replace the top cover until it snaps in place.
NOTE:
• If the external card is inserted, removed or replaced, the unit
will search the music files to update the index when the unit is
turned on again.
• If the external card is inserted, the memory card
indicator will appear at the top side of the display while
in the Music Player mode.
• While the player is on, if the SD/MMC card is removed or
inserted, “Unload the Card?” or “Load the card?” will appear in
the display. Press the Navigation control to select YES to
reload or load the SD/MMC card to update the player.
Otherwise, the SD/MMC card’s music files will not be played.
Figure 1
Figure 2
Figure 3
label
side
20
OPERATION
Turn the unit on by pressing the Power On/Off/
Stop button; the Memorex start screen will
appear in the display temporarily. Then the
Music Player menu will appear and the
MP3/WMA track’s information will appear in
the display. To turn the unit off, press and hold
the Power On/Off/Stop button; “Hold Down To
Power Off” will appear in the display. The unit
will turn off after it counts up from one to three.
Do not release the Power On/Off/Stop button
until the unit turns off.
1
TURNING THE POWER ON/OFF
LOCK SWITCH
With the unit on, press and hold the MENU/Lock
button until LOCKED appears in the display; no
buttons will function. This is useful when you do
not want the track changed by accidentally
pressing a button. Press and hold the
MENU/Lock button until UNLOCKED appears in
the display to cancel the Lock function.
1
NOTE: After you have transferred music files to the player, when you turn on the player, the
“Memorex” start screen will appear in the display temporarily followed by “Internal Updating
Music Library” and “Create New Music Playlist” (if a SD/MMC card is inserted, “Ext card
checking changes in music content” will appear in the display temporarily). It will take several
seconds to several minutes to update the player’s library or the music files depending on the
number of songs that you transferred to the player. When done, the Music Player menu will
appear in the display.
21
OPERATION (CONTINUED)
Turn the unit on by pressing the Power
On/Off/Stop button; the Memorex start
screen will appear in the display temporarily.
Then the Music Player menu will appear and
the MP3/WMA’s track information will appear
in the display.
1
TO LISTEN TO THE FM RADIO
Press the Menu/Lock button 1; the Main menu will
appear. Push the Navigation control towards
▲ or ▼ 2
to select FM Tuner, then press the Navigation control 2;
the FM Tuner will appear.
NOTE: When you select the Radio mode for the first
time, the unit will automatically scan and set the available
stations into Presets 1 through 20. Then Preset 1 will
appear with the corresponding frequency tuned in.
2
1
2
Select a station by pushing the Navigation
control towards
√/m or ®/l. When a
station is broadcasting in stereo,
“STEREO” will appear in the display,
otherwise “MONO” will appear in the
display.
3
AUTOMATIC TUNING: You can also push and
hold the Navigation control towards
√/m or ®/l
until " " appears and then release; the unit will
automatically search for the next strong station.
Press the VOLUME +/- buttons
2 to increase or
decrease the volume.
ANTENNA
FM
–The headphones act as an antenna for FM.
Extend the headphone wire for best FM
reception.
1
2
4
22
OPERATION (CONTINUED)
While in FM Playback mode, and with a
desired station selected, press the
Menu/Lock button 1; the FM Menu will
appear. Push the Navigation control
towards ▲ or ▼ 2 to select Add to Preset,
then press the Navigation control
2.
2
1
1
TO ADD PRESETS
Select a desired Preset by pushing the Navigation
control towards
▲ or ▼ 1, then press the Navigation
control
1. Select Yes (confirm adding the station to the
Preset) or No (cancel adding the station to the Preset)
by pushing the Navigation control towards
√/m or
®/l 1, then press the Navigation control 1. To exit
the FM menu, press the Menu/Lock button 2.
1
2
2
While in FM Playback mode, press the
Menu/Lock button
1; the FM Menu will
appear. Push the Navigation control towards
▲ or ▼ 2 to select Load Preset, then press
the Navigation control
2.
2
1
1
TO LOAD PRESETS
Select a desired Preset by pushing the Navigation control
towards
▲ or ▼, then press the Navigation control.
NOTE: You can also push the Navigation control towards
▲ (for Preset Up) or ▼ (for Preset Down) to select the
desired preset station while in the FM playback mode
(with the radio frequency in the display).
2
AUTO SCAN:
While in FM Playback mode, press the Menu/Lock button; the FM menu will appear. Push the
Navigation control towards ▲ or ▼ to select Auto Scan then press the Navigation control. The unit will
automatically scan and set the available stations into Presets 1 through 20. Then Preset 1 will appear
with the corresponding frequency tuned in.
NOTE: During Auto Scan, " " will appear in the display.
23
OPERATION (CONTINUED)
While in FM Playback mode, press the
Menu/Lock button 1; the FM Menu will
appear. Push the Navigation control
towards ▲ or ▼ 2 to select Delete One,
then press the Navigation control
2.
2
1
1
TO DELETE ONE PRESET
Push the Navigation control towards ▲ or ▼ to
select the Preset station which you want to delete
and press the Navigation control. Select YES
(delete the Preset) or NO (cancel deleting the
Preset) by pushing the Navigation control towards
√/m or ®/l, then press the Navigation control.
2
While in FM Playback mode, press the
Menu/Lock button
1; the FM Menu will
appear. Push the Navigation control towards
▲ or ▼ 2 to select Delete All, then press the
Navigation control
2.
2
1
1
TO DELETE ALL PRESETS
Press the Navigation control again and then
push the Navigation control towards
√/m or
®/l to select YES (delete all presets) or NO
(cancel deleting all presets) and press the
Navigation control.
2
24
OPERATION (CONTINUED)
1
TO LISTEN TO MP3s/WMAs/WAVs
If the unit is in the FM mode, press the MENU/Lock
button
❶; the FM menu will appear in the display. Push
the Navigation control towards
▲ or ▼ 2 to select Exit,
then press the Navigation control
2 to select it. The
Main menu will appear in the display. Select “Play Now”
by pushing the Navigation control towards
▲ or ▼ 2,
then press the Navigation control
2; the Music Player
menu will appear.
2
1
2
To turn the unit off, press and hold the Power
On/Off/Stop button; “Hold Down To Power Off” will
appear in the display. The unit will turn off after it
counts up from one to three. Do not release the Power
On/Off/Stop button until the unit turns of
f.
NOTE:
• See pages 8-17 for information on uploading MP3,
WMA and WAV files to this unit.
4
Turn the unit on by pressing the Power
On/Off/Stop button; the Memorex start
screen will appear in the display
temporarily. Then the Music Player menu
will appear and the MP3/WMA’s track
information will appear in the display.
1
2
3
3
Press the Play/Pause ®p button
1
1
to start
playback; the MP3 information will appear/scroll
across the display. Press the VOLUME +/-
buttons
2 to increase or decrease the volume. To
stop playback, press the Power On/Off/Stop
button
3; the Stop indicator will appear.
NOTE (AUTO RESUME): Each time you exit the Music Player mode or turn the unit off,
when the unit is turned back on or you enter the Music Player mode again, this unit will
resume at the beginning of the last track which was playing before turning the power off or
changing mode.
OPERATION (CONTINUED)
25
During playback, if you wish to pause the file
momentarily, press the Play/Pause
®p button;
playback will pause, the Pause indicator will
appear and the timer will stop counting.
1
Press the Play/Pause ®p button again to resume
playback; the sound will return, the Play indicator
will appear and the timer will start counting again.
2
TO PAUSE PLAYBACK
Press the MENU/Lock button 1; the Main menu
will appear. Scroll to Browse by pushing the
Navigation control towards
▲ or ▼ 2 then press
the Navigation control
2. Select the desired
Browse option (Artist, Album, Genre or All Songs)
by pushing the Navigation control towards
▲ or
▼ 2 then press the Navigation control 2.
2
1
1
For the Browse option, see more details below:
Artist: All Artists will be shown in the display. Select the
desired Artist by pushing the Navigation control towards
▲ or ▼ then press the Navigation control. All the Artist’s
albums will appear; select the desired album by pushing
the Navigation control towards
▲ or ▼ then press the
Navigation control. Then, select the desired song by
pushing the Navigation control towards
▲ or ▼ then
press the Navigation control to start playback.
Album/Genre: All the albums/genres will appear. Select
the desired album/genre by pushing the Navigation
control towards
▲ or ▼ then press the Navigation
control.
Then, select the desired song by pushing the
Navigation control towards
▲ or ▼ then press the
Navigation control to start playback.
All Songs: The song’s name will appear in the display.
Select the desired song by pushing the Navigation
control towards
▲ or ▼ then press the Navigation
control to start playback.
2
TO SELECT/BROWSE THROUGH THE FILES
OPERATION (CONTINUED)
26
During playback, push the Navigation control
towards ®/l to advance the player to the
beginning of the next file. Push the
Navigation control towards ®/l repeatedly
to advance the player to higher-numbered
files.
1
FORWARD/REVERSE SKIP
During playback, push the Navigation control
towards √/m to move the player back to the
beginning of the currently playing file. Push
the Navigation control towards √/m
repeatedly to move the player back to lowernumbered files.
2
During playback, push and hold the
Navigation control towards √/m or ®/l to
move the player forward or backward within
a file to locate a specific musical passage.
The player will move forward or backward at
high speed as long as the button is held.
When you release the button, normal
playback will resume.
1
HIGH-SPEED MUSIC SEARCH
OPERATION (CONTINUED)
27
Press the MENU/Lock button 1; the Main
menu will appear. Scroll to Settings by
pushing the Navigation control towards ▲ or
▼ 2, then press the Navigation control 2.
2
1
1
Scroll to Equalizer by pushing the
Navigation control towards ▲ or ▼, then
press the Navigation control.
2
Select a desired EQ setting (Normal, XBass, Rock, Classical, Jazz or Pop) by
pushing the Navigation control towards ▲ or
▼ 2, then press the Navigation control 2.
3
Push the Navigation control towards √/m
twice to exit the menus.
NOTE: You can also press the MENU/Lock
button twice to exit and return to the Music
Player menu.
4
SETTING THE EQUALIZER
28
OPERATION (CONTINUED)
Press the MENU/Lock button 1; the Main
menu will appear. Scroll to Settings by
pushing the Navigation control towards ▲ or
▼ 2, then press the Navigation control 2.
2
1
1
Scroll to Play Mode by pushing the
Navigation control towards
▲ or ▼, then
press the Navigation control.
2
Select the desired Play mode by pushing the
Navigation control towards
▲ or ▼ 2, then
press the Navigation control
2.
Normal: Normal playback
Repeat One: Repeats the current track
Repeat All: Repeats all of the files
Shuffle: Randomly plays the files once
and then stops
Shuffle Repeat: Randomly plays all the files
repeatedly
3
Push the Navigation control towards √/m
twice to exit the menus. The selected Play
mode symbol will appear at the top of the
display.
NOTE: You can also press the MENU/Lock
button twice to exit and return to the Music
Player menu.
4
SETTING THE PLAY MODE
29
OPERATION (CONTINUED)
Press the MENU/Lock button 1; the Main
menu will appear. Scroll to Settings by
pushing the Navigation control towards ▲ or
▼ 2, then press the Navigation control 2.
2
1
1
Scroll to Contrast by pushing the Navigation
control towards
▲ or ▼, then press the
Navigation control.
2
Push the Navigation control towards √/m
or ®/l to decrease/increase the contrast,
then press the Navigation control.
3
Push the Navigation control towards √/m
twice to exit the menus.
NOTE: You can also press the MENU/Lock
button twice to exit and return to the Music
Player menu.
4
SETTING THE CONTRAST
30
OPERATION (CONTINUED)
Press the MENU/Lock button 1; the Main
menu will appear. Scroll to Settings by
pushing the Navigation control towards ▲ or
▼ 2, then press the Navigation control 2.
2
1
1
Scroll to Backlight by pushing the
Navigation control towards
▲ or ▼, then
press the Navigation control.
2
Push the Navigation control towards ▲ or
▼ to select the desired backlight time (time
the backlight will stay on after a button is
pressed–Off, 3 seconds, 5 seconds, 10
seconds or Always On), then press the
Navigation control.
3
Push the Navigation control towards √/m
twice to exit the menus.
NOTE: You can also press the MENU/Lock
button twice to exit and return to the Music
Player menu.
4
SETTING THE BACKLIGHT
31
OPERATION (CONTINUED)
Press the MENU/Lock button 1; the Main
menu will appear. Scroll to Settings by
pushing the Navigation control towards ▲ or
▼ 2, then press the Navigation control 2.
2
1
1
Scroll to Power Savings by pushing the
Navigation control towards
▲ or ▼, then
press the Navigation control.
2
Push the Navigation control towards ▲ or ▼
to select the desired Power Savings (time the
unit will stay on before turning off due to
inactivity–Disable [ Off ], 1 Minute, 2 Minutes, 5
Minutes or 15 Minutes), then press the
Navigation control.
NOTE: Select Disable to disable this feature
and not have the unit enter the Power Savings
mode.
3
Push the Navigation control towards √/m
twice to exit the menus.
NOTE: You can also press the MENU/Lock
button twice to exit and return to the Music
Player menu.
4
SETTING THE POWER SAVINGS
32
OPERATION (CONTINUED)
Press the MENU/Lock button 1; the Main
menu will appear. Scroll to Settings by
pushing the Navigation control towards ▲ or
▼ 2, then press the Navigation control 2.
2
1
1
Scroll to Language by pushing the Navigation
control towards
▲ or ▼, then press the
Navigation control.
2
Push the Navigation control towards ▲ or ▼
to select the desired Language the text on the
display will be in (English, Traditional Chinese,
Spanish, Italian, French, Dutch or Japanese),
then press the
Navigation control.
3
Push the Navigation control towards √/m
twice to exit the menus.
NOTE: You can also press the MENU/Lock
button twice to exit and return to the Music
Player menu.
4
SETTING THE LANGUAGE
33
OPERATION (CONTINUED)
Press the MENU/Lock button 1; the Main
menu will appear. Scroll to Settings by
pushing the Navigation control towards ▲ or
▼ 2, then press the Navigation control 2.
2
1
1
Scroll to About by pushing the Navigation
control towards ▲ or ▼, then press the
Navigation control.
The unit will then display the
Version, Internal Media (the total internal
memory) and Internal Free Space.
2
Push the Navigation control towards ▼ to
view the External Media and External Free
Space. (This information will only be available if
an external media card is inserted.)
NOTE: If there is no SD/MMC card inserted,
when you push the Navigation control towards
▼, it will return to the Settings menu.
3
Push the Navigation control towards √/m
three times to exit the menus.
NOTE: You can also press the MENU/Lock
button three times to exit and return to the
Music Player menu.
4
TO VIEW THE SYSTEM INFO (ABOUT)
OPERATION (CONTINUED)
34
Press the MENU/Lock button 1; the Main
menu will appear. Scroll to Stopwatch by
pushing the Navigation control towards ▲ or
▼ 2, then press the Navigation control 2.
2
1
1
USING THE STOP WATCH
Press the Navigation control to start the timer;
the timer will then start counting up. Press the
Navigation control to stop the timer; the timer
will then stop counting.
2
Press the Navigation control to reset the timer to
“0:00:00:00” and start the timer again. You can also
select another timer by pushing the Navigation control
towards
▲ or ▼.
To reset the timer, push the Navigation control
towards
®/l for two seconds and then release; the
timer will be reset.
To reset all the timers, push the
Navigation control towards
▲ or ▼ repeatedly to
select “Clear lap times” then press the Navigation
control to reset all the timers.
3
Push the Navigation control towards √/m
twice to exit the Stopwatch and return to the
Music Player menu.
NOTE: You can also press the MENU/Lock
button twice to exit and return to the Music
Player menu.
4
NOTE:
• The MP3/WMA files can still be played back while using the Stopwatch.
TROUBLESHOOTING GUIDE
35
If you experience a problem with this unit, check the chart below before calling for service.
SYMPTOM CAUSE SOLUTION
Unit will not Battery is low/empty. Replace battery.
turn on.
Unit is not turned Press Power On/Off/Stop
on. button to turn the unit on.
No sound. Headphones are not Insert headphones.
inserted.
Volume is set too Raise the volume using the
low. Volume + button.
The MP3 or WMA files Download uncorrupted
are corrupted. files.
No files are in the Upload files to the unit as
player. described on pages 14-17.
The computer is not The player is Make sure player is
recognizing the not securely connected. securely connected.
player. Win98 Driver isn’t installed Install Win98 driver and/or see
or computer is not pages 8-13 for
compatible. compatibility.
WMA files with DRM Incorrect downloading
See page 17 to download
can’t playback. methods. WMA files with DRM.
36
TROUBLESHOOTING GUIDE (CONTINUED)
SYMPTOM CAUSE SOLUTION
No buttons work.
The Lock feature is Deactivate Lock feature as
activated. described on page 20.
Unit needs to be reset Reset unit and/or
or firmware needs to be update firmware, see
updated. pages 37-38.
Unit acting erratically. Unit needs to be reset Reset unit and/or
or firmware needs to be update firmware, see
updated. pages 37-38.
37
Formatting the Player
WARNING!
Do not format this player unless it stops working and you are
instructed to do so by technical support personnel.
1. Use the USB cable to connect the
player and the computer.
2. Double click on My Computer, then
right click "Removable Disk" and left
click on "Format".
3. At the "Format" window, select "FAT
32" from the file system pull-down
menu, then click "Start" to format the
unit (see figure above).
NOTE: Make sure you have selected
"FAT 32" at the file system pull-down
menu; otherwise, after formatting,
the player will not work properly.
Then, click OK to confirm and the player will start to format. When
finished, click "Close" to close the Format window.
FORMATTING THE PLAYER
236MB
38
WARNING! Do not update the firmware unless you are experiencing problems with
your digital audio device. Incorrect or faulty firmware installation will cause the player
to stop functioning.
1. Download the updated firmware at www.memorexelectronics.com.
2. Unzip the file, then double click setup.exe in the Desktop folder to install the
software to your computer.
3. Connect the player to the computer using the supplied USB cable and the
installation screen will appear. (If the installation screen does not appear, unplug
the USB cable and turn off the unit). Connect to the computer again and press and
hold the Power On/Off/Stop button until the installation screen appears.
4. Follow the on-screen instructions to install the driver.
5. When finished, click START and locate the newly installed software “Stop Sime II”
and select “Firmware Download”.
UPDATING THE FIRMWARE
To reset the unit, open the top cover, remove the battery for a few seconds and then
replace it. This will reset the unit but all the default settings (i.e. Radio Presets, Play
mode, Equalizer, Contrast, Power Savings, etc.) will be saved in the unit.
RESETTING THE UNIT
SPECIFICATIONS
39
Audio Frequency Range 20Hz – 20KHz
Headphones Output 5mW, 32ohm (Max. Vol)
S/N Ratio 85db (MP3)
File Support MP3 MPEG 1/2/2.5 Layer 3
WMA Windows Media Audio (WMA file with
DRM9 or DRM 10)
Bit Rate 32kbps–320kbps (MP3)
32kbps–192kbps (WMA)
FM Tuner FM Frequency Range 87.5MHz–108MHz
Antenna Headphones/Earphones Cord Antenna
General Dimension 2.4 (W) x 2.5 (H) x 0.8 (D) inches
Weight 1.6 ounces (without battery)
USB USB 2.0
LCD Full Graphic with Backlight
Built-in Memory 256MB
Max. Playtime Approx. 18 hours
Supported OS Win ME, 2000, XP and Mac OSX
Win 98SE (Driver is required)
Operating Temperature 23° F to 104° F
Battery 1 x AAA battery
Specifications are subject to change without notice.
40
FOR ADDITIONAL SET-UP OR OPERATING ASSISTANCE,
PLEASE VISIT OUR WEBSITE AT
WWW.MEMOREXELECTRONICS.COM
OR CONTACT CUSTOMER SERVICE AT (954) 660-7100.
PLEASE KEEP ALL PACKAGING MATERIAL FOR AT LEAST 90
DAYS IN CASE YOU NEED TO RETURN THIS PRODUCT TO YOUR
PLACE OF PURCHASE OR TO MEMOREX.
FOR PARTS AND ACCESSORIES, CONTACT FOX INTERNATIONAL
AT 1-800-321-6993.
FOR FIRMWARE UPGRADE, PLEASE VISIT OUR WEBSITE AT
WWW.MEMOREXELECTRONICS.COM
TO CHECK IF THERE IS NEW FIRMWARE AVAILABLE.
Memcorp, Inc.
Weston, FL
Printed in China
Visit our website at www.memorexelectronics.com
Loading...
