Memorex MMP8560 User Manual

MMP8560

User’s Guide

Personal FM Stereo

MP3/WMA/WAV Player

Before operating this product,

please read these instructions completely.

PRECAUTIONS

COPYRIGHT:

• Distributing copies of MP3, WMA with DRM or WAV tracks without
permission is a violation of international copyright laws.

SAFETY:

• Vibration experienced during walking or exercising will not affect the player.
However, dropping the player or dropping a heavy object on the player may result
in damage or sound distortion.

• Avoid spilling any liquid onto or into the player.

• Do not leave the player in a location near heat sources; in a location subject to direct
sunlight, excessive dust, sand, moisture, rain or mechanical shock; on an unlevel
surface; or in a car with the windows closed during periods of excessive heat.

ROAD SAFETY:

• Do not use headphones while driving, cycling or operating any motorized vehicle. It
may create a traffic hazard and it is illegal in some areas. It can be potentially
dangerous to play your headset at a high volume while walking, especially at
pedestrian crossings. You should exercise extreme caution or discontinue use in
potentially hazardous situations.

FCC WARNING:

• This equipment may generate or use radio frequency energy. Changes or
modifications to this equipment may cause harmful interference unless the
modifications are expressly approved in the instruction manual. The user could
lose the authority to operate this equipment if an unauthorized change or
modification is made.

1

FCC DECLARATION

This device complies with Part 15 of the FCC rules. Operation is subject to the
following two conditions: 1) This device may not cause interference, and 2) This
device must accept any interference received, including interference that may cause
undesired operation.

Warning: Changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.

NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Shield cable must be used with this unit to ensure
compliance with class B FCC limits.

2

Dear Customer:

Selecting fine audio equipment such as the unit you’ve just purchased is only the start
of your musical enjoyment. Now it’s time to consider how you can maximize the fun
and excitement your equipment offers. This manufacturer and the Electronic Industries
Association’s Consumer Electronics Group want you to get the most out of your
equipment by playing it at a safe level. One that lets the sound come through loud and
clear without annoying blaring or distortion and, most importantly, without affecting
your sensitive hearing.
Sound can be deceiving. Over time your hearing “comfort level” adapts to higher
volumes of sound. So what sounds “normal” can actually be loud and harmful to your
hearing. Guard against this by setting your equipment at a safe level BEFORE your
hearing adapts.

To establish a safe level:

• Start your volume control at a low setting.

• Slowly increase the sound until you can hear it comfortably and clearly, and without
distortion.

Once you have established a comfortable sound level:

• Set the dial and leave it there.

Taking a minute to do this now will help to prevent hearing damage or loss in the future.
After all, we want you listening for a lifetime.

We Want You Listening For A Lifetime

Used wisely, your new sound equipment will provide a lifetime of fun and enjoyment.
Since hearing damage from loud noise is often undetectable until it is too late, this
manufacturer and the Electronic Industries Association’s Consumer Electronics Group
recommend you avoid prolonged exposure to excessive noise. This list of sound levels
is included for your protection.

3

Decibel

A

S

S

O

C

I

A

T

I

O

N

EST. 1924

E

L

E

C

T

R

O

N

I

C

I

N

D

U

S

T

R

I

E

S

EIA

We

LISTENING

For A Lifetime

Want You

Level Example

30 Quiet library, soft whispers
40 Living room, refrigerator, bedroom away from traffic
50 Light traffic, normal conversation, quiet office
60 Air conditioner at 20 feet, sewing machine
70 Vacuum cleaner, hair dryer, noisy restaurant
80 Average city traffic, garbage disposals, alarm clock at two feet

THE FOLLOWING NOISES CAN BE DANGEROUS UNDER CONSTANT EXPOSURE:

90 Subway, motorcycle, truck traffic, lawn mower
100 Garbage truck, chain saw, pneumatic drill
120 Rock band concert in front of speakers, thunderclap
140 Gunshot blast, jet engine
180 Rocket launching pad

Information courtesy of the Deafness Research Foundation.

4

LOCATION OF CONTROLS

133 4 11 121095 87

1

6

2

1. Navigation Control
(Navigation Up/Down, Menu,
CD Skip/Search n/o, Radio
Tuning Up/Down)

2. LOCK Switch (rear of unit)

3. VOLUME - Button

4. VOLUME + Button

5. Battery Compartment
(Under Peel)

6. Display

7. Peel

8. Play/Pause
Button

9. Power/Stop (Exit) Button

10. EQ/ (Play Mode) Button

11. Strap Hole

12. USB Port (Side of Unit)

13. Headphone Jack
(Side of Unit)

5

®p (Enter)

BATTERY INSTALLATION

When the bars in the battery indicator (in the display) become
low, replace the battery as follows.

1

2

Batt.
Low
Batt.
Full

Hold the unit as shown at the figure.

3

Insert one (1) “AAA” battery as shown. An

battery is recommended for the longest

alkaline

time.

playing

these precautions when using a battery in this device:

Follow

1. Use only the size and type of battery specified.

2. Be sure to follow the correct polarity when installing the battery as indicated. Reversed batteries
may cause damage to the device.

3. If the device is not to be used for a long period of time, remove the battery to prevent damage or
injury from possible battery leakage.

4. Do not try to recharge batteries not intended to be recharged; they can overheat and rupture.
(Follow battery manufacturer’s directions.)

BATTERY PRECAUTIONS

Then pull out the Peel from the top edge.

NOTES:

•

Refer to the next page (Step 3 through
Step 6) for how to replace the Peel.

• Before removing the Peel, make sure

the headphones are removed from the
Headphone jack.

6

REMOVING & REPLACING THE PEEL

a

a

b

Remove the Peel and replace the Peel with one of the included Peels as follows:

1 2

To remove the Peel, hold the unit as shown
at the figure.

Then pull out the Peel from the top edge.

3 4

To replace the Peel, pull out the USB cover
slightly.

5

Make sure the USB cover is inserted through
the USB hole in the peel (a), then press the
middle area of the peel unit it locks in place.

NOTE: Before removing the Peel, make sure the headphones are removed from the Headphone jack.

Make sure the tabs at the Peel are aligned
to the corresponding slots on the main unit.

6

Press on the left and right side of the
peel until it is securely on the unit (a).

Replace the USB cover (b).

7

USING THE NECKLACE STRAP

1

Remove the necklace strap cord by
pressing and releasing it.

3

Loop the cord around the locking
piece and pull until tightened.

2

Insert the cord through the strap hole.

4

Attach the necklace strap to the locking
piece until a click is heard.

8

INSTALL “DIGITAL AUDIO PLAYER” SOFTWARE

TO INSTALL THE "DIGITAL AUDIO PLAYER" CD SOFTWARE

For Windows ME, Windows2000 or Windows XP:

Windows will automatically detect the audio player without installing the CD software
when the USB cable is connected.

For Macintosh OSX:

Macintosh OSX will automatically detect the audio player without installing the CD
software. Do not install the software when using a Macintosh.

For Windows98SE:

The USB mass storage function will not be activated without driver installation. To
activate the USB mass storage function, please use the installation CD-Rom to install
the driver.
For Windows 98SE, if you are connecting your player to your computer for the first
time, please follow these instructions:

Procedure to Install Player Driver

1. Insert the Installation CD-Rom
into the CD Drive; the auto-run
program will display the Main
Menu window. Click “Software
Drivers”.

NOTE: If the Main Menu window
does not appear, double click
“Memorex Startup CD” application
file on the Installation CD to open
the Main Menu window.

9

WINDOWS 98 DRIVER INSTALLATION

2. Click “MMP8560” to run the

Windows 98SE driver.

3. Follow the on-screen

instructions to install the
software.

10

WINDOWS 98 DRIVER INSTALLATION (CONTINUED)

4. Install the software under
the directory as prompted.

Warning: DO NOT change the
installation path. Otherwise, the
driver may not run properly.

11

WINDOWS 98 DRIVER INSTALLATION (CONTINUED)

5. After successfully installing the driver software, click "Finish" to finish the
installation and exit the Setup menu.

6. When the installation has completed, the new program, “Memorex Audio Player”,
will be added to the PROGRAM menu on your computer.

12

DOWNLOADING AND TRANSFERRING FILES

TRANSFERRING FILES

You can download digital music files from the Internet or use encoding software to convert
music that you have on an audio CD into MP3 or WMA format. Once these files are stored on
your computer you can easily copy them to your player.

Connect the computer to your player using the supplied USB cable.

Press the Power/Stop button to turn the unit on.

A "Removable Disk" window will automatically pop up on your
computer screen.
To add more files and songs to your player simply drag and drop
MP3, WMA or WAV files from anywhere on your computer into the
"Removable Disk" window.

IMPORTANT: A WMA file with DRM will not play back if you directly drag and drop it into the
“Removable Disk” window. You must use MMJB or Windows Media Player to transfer copy
protected files.

When you are finished, see the Safely Remove Hardware procedure on the next page before
disconnecting the player.

13

SAFELY REMOVE HARDWARE

SAFELY REMOVING YOUR PLAYER FROM THE COMPUTER
NOTE: To avoid damage to your player or data loss, always follow the procedure listed

below before disconnecting the USB cable from your computer or disconnecting the
player from the USB cable.

Using your mouse, double click the "Safely Remove
Hardware" icon on the task bar.

From the "Safely Remove Hardware" window, select
"USB Mass Storage Device" and click the "Stop"
button. The "Stop a Hardware Device" window will pop up as shown below.
Click "OK". When the "Safe to Remove Hardware" window is displayed, you may
remove the player from
the USB cable or remove
the USB cable from the
computer.

NOTE:

• If the “Safely Remove
Hardware” icon is not
displayed on the task
bar, please double
click on My Computer.
Right click on
“Removable Disk” and
left click on “Eject”.
Then it will be safe to remove the player from the computer.

• The “Safely Remove Hardware” procedure is not necessary for Win98 and
Win98SE users.

14

INSTALLING MUSICMATCH JUKEBOX

NOTE: WMA DRM protected files will not play if you use the ‘drag and drop’ procedure.

You must follow the procedure below to play WMA DRM files on your MMP8560.

1. Install the MMJB Software as described above.

2. Turn the unit ON, then connect the USB cable to the unit and the USB port of the
computer. “Transfer Mode” will be displayed on the LCD when it is properly
connected.

15

INSTALLING MUSICMATCH JUKEBOX (CONTINUED)

16

OPERATION

TURNING THE POWER ON/OFF

LOCK SWITCH

1

Turn the unit on by pressing the Power/Stop
button; the Memorex start screen will appear in
the display temporarily. Then the Music Player
menu will appear in the display. To turn the unit
off, press and hold the Power/Stop button;
“Hold Down To Power Off” will appear in the
display. The unit will turn off after it counts up
from one to three. Do not release the
Power/Stop button until the unit turns off.

EQ–MUSIC PLAYER ONLY

1

While in the Music Player menu, press and hold the EQ/
button until the EQ setting is highlighted in the display.
Within two seconds, repeatedly press the EQ/ button to

select the desired EQ setting (Normal, Rock, UBass (Ultra
Bass), Jazz, Classical or Pop). Wait two seconds without
pressing a button to confirm the setting. The selected EQ
setting will appear at the bottom left of the display when
playing tracks/files.

1

Slide the LOCK switch to the Lock position; the
lock indicator will appear in the display and no
buttons will function. This is useful when you do
not want the station/track changed by
accidentally pressing a button. Slide the LOCK
switch to the Unlock position to cancel the Lock

NOTE: If you attempt to turn the power

function.
on while the LOCK switch is in the Lock position,
the unit will show “LOCKED” and the lock
indicator and then turn off.

17

OPERATION (CONTINUED)

TO LISTEN TO THE FM RADIO

1

Turn the unit on by pressing the Power/Stop
button; the Memorex start screen will appear
in the display temporarily. Then the Music
Player menu and the MP3/WMA’s track
information will appear in the display.

3

Repeatedly push and release the
Navigation control to the left (Tuning Down)
or right (Tuning Up) to tune a station. For
rapid search tuning, push and hold the
Navigation control to the left or right for one
second, then release; the unit will
automatically search and stop on the next
strongest station.

2

Press the Navigation control 1; the Main Menu will
appear. Within six seconds, push the Navigation
control

1 to the left or right until the FM Tuner is
highlighted, then press the PLAY/PAUSE
button 2 to select it.

4

When a station is broadcasting in stereo,
“STEREO” will appear in the display. Press the

EQ/ button to listen in mono, “STEREO” will
disappear from the display. Press the EQ/

button again to return to stereo. If the station is
not strong enough or it is not broadcasting in
stereo, “Stereo” will not appear.

18

®p

OPERATION (CONTINUED)

5

Press the VOLUME + 1/- 2 buttons to
adjust the volume.

6

To turn the unit off, press and hold the
Power/Stop button; “Hold Down To Power Off”
will appear in the display. The unit will turn off
after it counts up from one to three. Do not
release the Power/Stop button until the unit turns
off.

ANTENNA

–The headphones act as an antenna for FM.

FM

Extend the headphone wire for best FM
reception.

19

OPERATION (CONTINUED)

TO MANUALLY SET A STATION INTO MEMORY

1

Turn the unit on by pressing the
Power/Stop button; select the FM Tuner
mode and tune a station as described on
pages 18 and 19.

3

When the desired memory number appears,
press the PLAY/PAUSE
store the preset; “STORE” will disappear
from the display and the station will be set
into memory.
To cancel and not store the Station, press
the Power/Stop button
disappear from the display.

®p button 1 to

2; “Store” will

2

Press the PLAY/PAUSE ®p button 1;
“STORE” will appear in the display. Push the
Navigation control
to select a preset number (“Channel 01” to
“Channel 10”).

20

2 towards the left or right

OPERATION (CONTINUED)

TO AUTOMATICALLY SET STATIONS INTO MEMORY

1

While in the FM radio mode, make sure the
PRESET indicator is not in the display. If it
is, press the Power/Stop button to clear it.

TO RECEIVE MEMORY PRESETS

1

Press the Power/Stop button ❶; “PRESET” will
appear in the display. Push the Navigation

2 towards the left or right to select a

control
preset channel. Press the Power/Stop button
❶ to exit the preset mode; the “PRESET”
indicator will disappear from the display.

2

Press and hold the PLAY/PAUSE ®p button
until “AUTO SCAN” appears in the display. The
unit will automatically store the ten next strong
stations into memory. New FM Stations will
overwrite previous presets.
NOTE: If less than ten stations have been
scanned into the memory, the memory will keep
at a frequency with 87.5MHz.

21

OPERATION (CONTINUED)

TO LISTEN TO MP3s/WMAs/WAVs

1

Turn the unit on by pressing the Power/Stop button
❶; the Memorex start screen will appear in the
display temporarily.Then the Music Player menu will
appear and the MP3/WMA’s track information will
appear in the display. Press the PLAY/PAUSE
button 2to start playback; the playback MP3/WMA
file’s information will appear/scroll across the display.

3

Set the Equalizer as shown on page 17. Press the
VOLUME +
stop playback, press the Power/Stop button
Stop indicator will appear.

NOTE (AUTO RESUME): Each time you exit the Music Player mode or turn the unit off, when the unit is turned
back on or you enter the Music Player mode again, this unit will resume at the beginning of the last track which
was playing before turning the power off or changing mode. To cancel resume, press the Power/Stop button
once while in Music Player Stop mode; the unit will return to showing the first file's information. When in the
Random or Random Repeat mode (see page 26), the unit will not show the first file's information when you
press the Power/Stop button. In the Playlist or Playlist Repeat mode, it will return to show the first selected
file's information.

1/- 2 buttons to adjust the volume. To

3; the

2

If the unit is in a mode other than the Music

Player menu, press the Navigation control ; the

Main menu will appear in the display. Within six
seconds, push the Navigation control towards the

®p

left or right until Play Now/Now Playing is high­lighted, then press the PLAY/PAUSE button

2

to select it. Playback will start automatically.

4

To turn the unit off, press and hold the Power/Stop button;
“Hold Down To Power Off” will appear in the display. The
unit will turn off after it counts up from one to three. Do
not release the Power/Stop button until the unit turns off.

NOTE:

• See pages 9 through 16 for information on uploading
MP3, WMA and WAV files to this unit.

❶

❶

®p

22

OPERATION (CONTINUED)

TO PAUSE PLAYBACK

1

During playback, if you wish to pause the
file momentarily, press the PLAY/PAUSE
®p button; playback will pause, the Pause
indicator will appear and the timer will stop
counting.

2

Press the PLAY/PAUSE ®p button again to
resume playback; the sound will return, the
Play indicator will appear and the timer will
start counting again.

TO SELECT/BROWSE THROUGH THE FILES

1

Press the Navigation control 1; the Main
Menu will appear. Push the Navigation
control
Browse then press the PLAY/PAUSE
button 2 to select it; the Root folder
contents will appear.

1 towards the left or right to

®p

2

Repeatedly push the Navigation control 1
towards the left or right to select a file/folder. If
a folder is selected, press the PLAY/PAUSE
®p button 2 to open the folder, then push the
Navigation control
to select a file. When the desired file is
selected press the PLAY/PAUSE
2 to start playing the selected file.
NOTE: To return to the Root folder, press the
Power/Stop button.

23

1 towards the left or right

®p button

OPERATION (CONTINUED)

FORWARD/REVERSE SKIP

1

During playback, push the Navigation
control to the right to advance the player to
the beginning of the next file. Push the
Navigation control to the right repeatedly to
advance the player to higher-numbered
files.

HIGH-SPEED MUSIC SEARCH

1

2

During playback, push the Navigation
control to the left to move the player back to
the beginning of the currently playing file.
Push the Navigation control to the left
repeatedly to move the player back to
lower-numbered files.

During playback, push and hold the
Navigation control towards the right or the
left to move the player forward or backward
within a file to locate a specific musical
passage. The player will move forward or
backward at high speed as long as the
control is held. When you release the
control, normal playback will resume.

24

TO REPEAT A FILE

OPERATION (CONTINUED)

1

To repeat a single file, press the EQ/ button
1 once while playing a file; the Repeat One

indicator will appear in the display. Push
the Navigation control
to select the specific track that you wish to
repeat.

TO REPEAT ALL FILES

2 towards the left or right

1

To repeat all files, press the EQ/ button twice
while playing a file; the Repeat All indicator

will appear in the display.

2

The specific track you selected will be
repeated continuously. To cancel Repeat
playback, press

until the play mode indicators disappear from the
display.

the EQ/ button repeatedly

2

All tracks on the player will be repeated
continuously. To cancel Repeat playback,

the EQ/ button repeatedly until the play

press

mode indicators disappear from the display.

25

OPERATION (CONTINUED)

TO RANDOMLY PLAY ALL FILES

1

To randomly play all the files and then stop,
press the EQ/ button three times while in the
Stop mode; the Random indicator will

appear in the display.

2

Press the PLAY/PAUSE ®p button 1 to start
playback; the unit will play all the tracks in random
order. When all the tracks have been played, the
unit will stop. To cancel Random playback, press

the EQ/ button 2 repeatedly until the play mode

indicators disappear from the display.

TO RANDOMLY PLAY ALL THE FILES CONTINUOUSLY

1

To randomly play all the files continuously,
press the EQ/ button four times while in the
Stop mode; the Random Repeat indicator

will appear in the display.

2

Press the PLAY/PAUSE ®p button 1 to start
playback; the unit will play all the tracks in random
order continuously. To cancel Random Repeat

playback, press
until the play mode indicators disappear from the
display.

26

the EQ/ button 2 repeatedly

OPERATION (CONTINUED)

PLAYING A PLAYLIST (A playlist must be programmed first, see pg. 28)

1

Press the EQ/ button 1 five times while
playing a file; “P” will appear in the display.
Push the Navigation control
to start playing the first track of the playlist.

REPEATEDLY PLAYING A PLAYLIST (A playlist must be programmed first, see pg. 28)

2 towards the right

1

Press the EQ/ button 1 six times while
playing a file; “P” and the Repeat indicator

will appear in the display. Push the Navigation

2 towards the right to start playing the

control
first track of the playlist.

2

The unit will play the playlist once and then stop.
To cancel Playlist playback, press

button repeatedly until the play mode indicators

disappear from the display.

the EQ/

2

The unit will play the playlist repeatedly. To cancel
Repeat Playlist playback, press

repeatedly until the play mode indicators
disappear from the display.

27

the EQ/ button

OPERATION (CONTINUED)

CREATING A PLAYLIST

1

Press the Navigation control 1; the Main
Menu will appear. Push the Navigation
control
Browse then press the PLAY/PAUSE
button 2 to select it; the Root folder
contents will appear.

1 towards the left or right to

3

When the desired file is selected, press and hold
the PLAY/PAUSE
playlist; a program number will appear at the left
side of the file (i.e. “01” is the first program file of
the playlist, “02” the second file, etc.). Press the
PLAY/PAUSE
program number will disappear.

NOTE:

• You can only program the same file into the playlist once.

®p button to add it to the

®p button again to confirm and the

2

Repeatedly push the Navigation control 1 towards
the left or right to select a file/folder. If a folder is
selected, press the PLAY/PAUSE
open the folder, then push the Navigation control

®p

towards the left or right to select a file.
NOTE: To return to the Root folder, press the
Power/Stop button.

4

Repeat steps 2 and 3 to add more files.
NOTE: To exit the Browse menu and return to the
Main menu, press the Navigation control until the
Main menu appears in the display. See previous
page for how to play the playlist.

28

®p button 2 to

1

OPERATION (CONTINUED)

TO VIEW/CLEAR THE PLAYLIST

1

Press and hold the Navigation control 1 until
the Setting Menu appears in the display. Push
the Navigation control
repeatedly to Playlist and then press the
PLAY/PAUSE
Playlist will appear.

®p button 2 to select it; the

1 towards the right

3

Push the Navigation control 1 towards the
left or right to select CLEAR ITEM or CLEAR
LIST, then press the PLAY/PAUSE
button 2.

®p

2

To clear a file, select the file to delete by
pushing the Navigation control

right until the file is highlighted

EQ/ button
after entering the playlist, press the EQ/ button

2.

2. To clear alll files in the playlist,

1 to the left or

, then press the

4

Push the Navigation control 1 towards the
left or right to select NO or YES, then press
the PLAY/PAUSE
you select YES and confirm, the file/files in
the playlist will then be deleted; if you select

NO and confirm, the file/files will not be deleted.

29

®p button 2 to confirm. If

DELETING A FILE

OPERATION (CONTINUED)

1

Press the Navigation control 1; the Main
Menu will appear. Push the Navigation
control
Browse then press the PLAY/PAUSE
button 2 to select it; the Root folder
contents will appear.

1 towards the left or right to

®p

3

After the file is selected, press the EQ/

button.

2

Repeatedly push the Navigation control 1 towards
the left or right to select a file/folder. If a folder is
selected, press the PLAY/PAUSE
open the folder, then push the Navigation control
towards the left or right to select a file.
NOTE: To return to the Root folder, press the
Power/Stop button.

®p button 2 to

4

Push the Navigation control 1 towards the
left or right to select NO or YES, then press
the PLAY/PAUSE
you select YES and confirm, the file will then

be deleted; if you select NO and confirm, the
file will not be deleted.

30

®p button 2 to confirm. If

1

OPERATION (CONTINUED)

TO SET THE CONTRAST

1

Press and hold the Navigation control 1 until
the Setting menu appears in the display.
Scroll to Contrast by pushing the Navigation

1 towards the left or right, then press

control
the PLAY/PAUSE
Contrast setting will appear.

®p button 2 to select it; the

2

Push the Navigation control towards the left
or right to set the desired contrast. Press
the Navigation control twice or wait a few
seconds to exit the menu.

31

OPERATION (CONTINUED)

TO SET THE BACKLIGHT

1

Press and hold the Navigation control 1 until
the Setting menu appears in the display.
Scroll to Backlight by pushing the Navigation
control

1 towards the left or right and then
press the PLAY/PAUSE
it; the Backlight setting will appear.

®p button 2 to select

TO SET THE PLAY TIMER

1

Press and hold the Navigation control 1 until
the Setting menu appears in the display.
Scroll to Play Timer

control to the left or right

PLAY/PAUSE
Play Timer setting will appear.

by pushing the Navigation

1 then press the

®p button 2 to select it; the

2

Set the desired backlight time (Always Off, 5
seconds, 10 seconds, 15 seconds or Always On)
by pushing the Navigation control to the left or
right. This is the time the backlight will be lit
before turning off when no buttons are pressed.
Select Always Off and the backlight will not light.

Press the Navigation control to set and return to

the settings menu.

2

Scroll by pushing the Navigation control
towards the left or right to select a desired play
timer setting (Elapsed or Remaining). Press

the Navigation control to set and return to the

settings menu.

32

OPERATION (CONTINUED)

TO SET THE POWER SAVINGS

1

1

2

Press and hold the Navigation control until
the Setting menu appears in the display.
Scroll to Power Savings by pushing the
Navigation control towards the left or right

then press the PLAY/PAUSE button to
select it; the Power Savings setting will appear.

1

®p

TO VIEW THE SYSTEM INFO

1

1

Press and hold the Navigation control 1 until the
Settings menu appears in the display. Scroll to
System Info by pushing the Navigation control
towards the left or right then press the
PLAY/PAUSE
Information will appear. Press the Navigation
control
will then reappear.

®p button 2 to select it; the System

1 to exit System Info, the Settings menu

2

Push the Navigation control towards the left or
right to select a desired Power Savings setting
(Disable, 1 minute, 3 minutes, 5 minutes). This is
the time the unit will stay on if it is not playing
and no buttons have been pressed for the set

2

time. Press the Navigation control to set

and return to the settings menu.

1

33

TROUBLESHOOTING GUIDE

If you experience a problem with this unit, check the chart below before calling for service.

SYMPTOM CAUSE SOLUTION

Unit will not Dead battery, or not Replace battery and install
turn on. installed properly. properly.

Lock switch is in the Slide switch to the Unlock posi­Lock position. tion.

No sound. Headphones are not Insert headphones.

inserted.
Volume is set too Raise the volume.
low.
The MP3 or WMA files Download uncorrupted
are corrupted. files.

FM distorted. Station not tuned. Retune station and extend

Download Failure. Damaged USB cable. Replace cable.

The computer is not The USB cable is Make sure USB cable is
recognizing the not securely connected. securely connected.
player.

Driver is not installed Install driver and/or see
or computer is not pages 9 through 14 for
compatible. compatibility.

WMA files with DRM Incorrect downloading See pages 15 through 16 to
cannot playback. methods. download WMA files with DRM.

headphone wire.

34

TROUBLESHOOTING GUIDE (CONTINUED)

SYMPTOM CAUSE SOLUTION

No buttons work.

Unit acting erratically. Unit needs to be reset Reset unit and/or

WMA files with DRM Incorrect downloading See pages 15-16 to
cannot playback. methods. download WMA files with DRM.

The Lock feature is Slide the Lock switch to the

activated. unlock position.
Unit needs to be reset Reset unit and/or
or firmware needs to be update firmware, see
updated. pages 36-37.

or firmware needs to be update firmware, see
updated. pages 36-37.

35

FORMATTING THE PLAYER

WARNING! Do not format this player unless it stops working and you are

instructed to do so by technical support personnel.

Formatting the Player

1. Use the USB cable to connect the player and
the computer.

2. Double click on My Computer, right click the
"Removable Disk" and left click on "Format".

3. At the "Format" window, select "FAT32" from
the file system pull down menu, then click start
to format the unit (see figure to the right).

NOTE: Make sure you have selected the "FAT32"
at the file system pull down menu, otherwise after
formatting, the player will not work properly.

4. Click OK to confirm and the player will start to
format.

5. When finished, click "Close" to close the
Format window

118MB

32

36

UPDATING THE FIRMWARE

WARNING! Do not update the firmware unless you are experiencing problems with

your digital audio device. Incorrect or faulty firmware installation will cause the player
to stop functioning.

1. Download the updated firmware at www.memorexelectronics.com.

2. Unzip the file, then double click setup.exe in the Desktop folder to install the
software to your computer.

3. Connect the player to the computer using the supplied USB cable and the
installation screen will appear. (If the installation screen does not appear, unplug
the USB cable and turn off the unit). Connect to the computer again and press and
hold the Power/Stop button until the installation screen appears.

4. Follow the on-screen instructions to install the driver.

5. When finished, click START and locate the newly installed software “Memorex
Audio Player” and select “Firmware Download”.

RESETTING THE UNIT

If the unit acts erratically, reset the unit by removing the battery for a few seconds and
then reinserting.

37

SPECIFICATIONS

Audio Frequency Range 20Hz – 20KHz

File Support MP3 MPEG 1/2/2.5 Layer 3

FM Tuner FM Frequency Range 87.5MHz–108MHz

General Dimension 83 x 40 x 40 mm

Headphones Output 20mW, 16ohm (Max. Vol)
S/N Ratio 85db (MP3)

WMA Windows Media Audio (WMA file with DRM)
WAV ADPCM encoding
Bit Rate 8kbps – 320kbps
Tag Info ID3 Tag

Antenna Headphones/Earphones Cord

Weight
Battery 1 x AAA battery
LCD Full Graphic with Backlight
Language English
USB USB 2.0
Built-in Memory 128MB
Max. Playtime Approx. 18 hours (128kps, MP3)
Supported OS Win ME, 2000, XP and Mac OSX

Operating Temperature 23° F to 104° F (-5° C to 40° C)

Specifications are subject to change without notice.

Antenna

38g (Without battery)

Win 98SE (Driver is required)

38

FOR FIRMWARE UPGRADE, PLEASE VISIT OUR WEBSITE AT

WWW.MEMOREXELECTRONICS.COM

TO CHECK IF THERE IS NEW FIRMWARE AVAILABLE.

FOR ADDITIONAL SET-UP OR OPERATING ASSISTANCE,
PLEASE VISIT OUR WEBSITE AT

WWW.MEMOREXELECTRONICS.COM

OR CONTACT CUSTOMER SERVICE AT [phone].

PLEASE KEEP ALL PACKAGING MATERIAL FOR AT LEAST 90
DAYS IN CASE YOU NEED TO RETURN THIS PRODUCT TO YOUR
PLACE OF PURCHASE OR TO MEMOREX.

FOR PARTS AND ACCESSORIES, CONTACT FOX INTERNATIONAL
AT 1-800-321-6993.

39

Memcorp, Inc.

Weston, FL

Printed in China

Visit our website at www.memorexelectronics.com
