USE AND CARE GUIDE FOR
MODELS MEMB1W, MEMB1B
AND MEMB1CAN
READ AND SAVE THESE INSTRUCTIONS
WARNING: A risk of fire and electrical shock exists in all
electrical appliances and may cause personal injury or death.
Please follow all safety instructions.
2
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should
always be followed to reduce the risk of fire, electric shock and injury
to persons, including the following:
• Read all instructions before using appliance.
• Do not touch hot surfaces. Use handle.
• Do not immerse cord, plug or coffeemaker base in water or other
liquid. See instructions for cleaning.
• This appliance is not for use by children.
• Close supervision is necessary when any appliance is used near
children.
• Unplug from outlet when not in use. Unplug and allow to cool
before attaching or removing parts and before cleaning the
appliance.
• Do not let cord hang over edge of table or counter or touch hot
surfaces.
• Do not place on or near a hot gas or electric burner or in a heated
oven.
• Do not use appliance except as indicated in these instructions.
• Decanter must never be used on a range top. Use only the
designated decanter for your coffeemaker.
• Do not set a hot decanter on a wet or cold surface.
• Do not use a cracked decanter or a decanter having a loose or
weakened handle.
• Do not clean decanter with abrasive cleaners, steel wool pads or
other abrasive material.
• Do not remove lid or covers during brewing cycle, scalding may
occur .
• Allow mill/brew basket to cool before removing it from appliance.
• To disconnect, press stop button, then remove plug from wall
outlet.
• Do not move entire unit when decanter contains hot liquid.
• Do not operate any damaged appliance. Do not operate with a
damaged cord or plug, or after the appliance malfunctions or has
been dropped or damaged in any manner . Return appliance to the
nearest authorized service center for examination, repair,
electrical or mechanical adjustment.
• Use accessory attachments only if recommended by
manufacturer.
• Be certain lids and covers are securely in place before operating
appliance.
• Do not use outdoors or while standing in a damp area.
• WARNING: Do not remove bottom cover. No user serviceable
3
parts inside. Repair must be done by authorized service
personnel only.
• The mill is intended for processing small quantities of coffee beans
only for immediate consumption. This appliance is not intended to
prepare large quantities of ground coffee at one time.
• WARNING: To prevent injury from hot overflow, replace decanter
within 20 seconds, if removed during brewing. Pour slowly when
full.
• Check mill/brew chamber for presence of foreign objects before
using.
• Blades are sharp. Handle carefully.
• Do not attempt to defeat the cover interlock mechanism.
• Avoid contacting moving parts.
• Do not open Mill/Brew assembly lid until blades stop and brewing
is complete.
SAVE THESE INSTRUCTIONS
THIS APPLIANCE IS FOR HOUSEHOLD USE ONLY
CAUTION: A short power supply cord is provided to reduce the risk
of personal injury resulting from becoming entangled in or tripping
over a longer cord. Extension cords are available from local hardware
stores and may be used if care is exercised in their use. If an
extension cord is required, special care and caution is necessary . Also
the cord must be: (1) marked with an electrical rating of 125 V, and at
least 13 A, 1625 W, and (2) the cord must be arranged so that it will
not drape over the countertop or tabletop where it can be pulled on by
children or tripped over accidentally.
POLARIZED PLUG: This appliance has a polarized plug, (one blade
is wider than the other). As a safety feature to reduce the risk of
electrical shock, this plug is intended to fit in a polarized outlet only
one way. If the plug does not fit fully in the outlet, reverse the plug. If
it still does not fit, contact a qualified electrician. Do not attempt to
defeat this safety feature.
ELECTRIC POWER: If the electric circuit is overloaded with other
appliances, your appliance may not operate properly. It should be
operated on a separate electric circuit from other operating
appliances.
Safeguards (Continued)
FIGURE 1
FIGURE 2
FIGURE 3
MILL/BREW ASSEMBLY
FIGURE 4
15
14
13
12
11
10
9
3
4
5
6
7
1
3
4
5
6
7
8
2
8
2
1
1
2
3
4
5
6
10
FIGURE 1
1. Reservoir Cover
2. Water Window
3. Pause and Pour
4. Decanter Lid
5. Decanter
6. Cord Storage
7. Warming Plate
8. Coffeemaker Base
9. Control Panel
10. LED Display
11. Lock Buttons
12. Mill and Brew Assembly
13. Mill/Brew Assembly Lock
14. Mill/Brew Assembly Lid
15. View Window
FIGURE 2
1. Mill/Brew Assembly Lid
2. Spreader Tube
3. Measuring Spoon
4. Motor Grinder Pin
5. Pause and Pour
6. Locking Buttons
FIGURE 3
1. Mill/Brew Basket
2. Maximum Fill Level
3. Blades
4. Pause and Pour
5. Lock Buttons
6. Basket Tabs
7. Mill/Brew Basket Lid
8. Mill/Brew Basket Tabs
4
1
0
9
8
7
T
I
M
E
H
R
M
I
N
C
O
A
R
S
E
F
IN
E
S
E
L
E
C
T
G
R
I
N
D
O
N
/
O
F
F
M
I
L
L
6
5
4
3
T
I
M
E
C
O
A
R
S
E
G
R
I
N
D
O
N
/
O
F
F
1
0
9
8
7
6
5
H
R
M
I
N
4
3
F
I
N
E
SE
LEC
T
M
I
L
L
5
Before Using Your Mill & Brew
Coffeemaker
CAUTION: UNPLUG FROM OUTLET
COFFEEMAKER: Clean the decanter and its lid, mill/brew basket
and its lid, and mill/brew assembly. See Care and Cleaning.
Fill the coffeemaker with the maximum amount of water and no
coffee and turn the unit ON. See Brewing. Unplug coffeemaker and
discard the water. Wait 10 minutes to allow heating elements to cool.
Repeat this process one more time.
CAUTION: DO NOT IMMERSE CORD, PLUG OR COFFEEMAKER
BASE IN WATER OR OTHER LIQUID.
CAUTION: BLADES ARE SHARP. DO NOT ATTEMPT TO
DISASSEMBLE MILL & BREW ASSEMBLY.
Setting the Clock
1. Set the clock for actual time of day. Press and hold “HR” button
for 2 seconds. The LED display will flash and unit will enter into
the clock-setting mode. Press “HR” and “MIN”buttons to set
correct time. Small dot in upper left corner of display signifies
A.M. No dot indicates P.M. The clock display will flash
5 times, then stop. The time is now set.
Brewing Instructions
CAUTION: DO NOTFILLMILL/BREW BASKET WITH MORE THAN
8 SPOONS OR 2
1
⁄8 OUNCES OF COFFEE BEANS. ARROW ON
BASKET INDICATES MAXIMUM CAPACITY. DO NOT FILL
MILL/BREW BASKET WITH MORE THAN 8 SPOONS OR 2
3
⁄4
OUNCES OF GROUND COFFEE.
1. Plug into 120V-60 Hz outlet. You do not have to set clock or timer
to brew.
2. Fill decanter with cold water and pour desired number of cups
into water reservoir. Use markings on water window to gauge
level of water required to brew desired number of 5-ounce cups.
The number 10 at the top indicates maximum 10-cup yield.
Replace decanter on warming plate.
3. Open mill/brew assembly lid and grasp mill/brew basket tabs to
remove basket lid. Place 1 measuring spoon roasted whole bean
6
coffee in mill/brew basket per every two cups of coffee desired.
Replace lid. Make sure basket is firmly seated in assembly , lid on
basket is secured and lid to assembly is closed before
attempting to operate unit.
NOTE: You may substitute ground coffee for coffee beans by
turning off the mill. To do so, push the Mill button. The light will
come on. Place ground coffee into mill/brew basket. Use
approximately 1 tablespoon of grounds per cup of coffee.
4. Y ou are now ready to initiate the automatic mill and brew process.
(If you wish to use the delay timer so you can program the
coffeemaker to mill and brew later, please read section entitled
“Programming the Timer” to make coffee later.
Programming the Mill
CAUTION: DO NOT OPEN UNTIL BLADES STOP AND BREWING
IS COMPLETE. CLEAN AND DRYALL PARTS AFTER EACH USE.
If you desire a medium grind, your machine is automatically preset to
“4” or medium grind; refer to step 2 below. If you wish to program a
finer or coarser grind, start with step 1.
1. To set the mill to grind your beans to the desired level of
coarseness, press SELECT button to select different coarseness
levels, 1-7. Seven levels of coarseness are available.
Coarseness is determined by length of time milled—the longer
the time, the finer the grind. Setting 1 will mill the beans for
15 seconds. Setting 7 will mill the beans for 40 seconds. For
medium grind, try setting 4 (if you do not select a setting, the unit
will automatically default to setting 4). Make sure mill light is off.
2. Press ON button to initiate the mill/brew process; the red ON
light will come on. Mill will start. After mill stops, unit will
automatically switch to brewing operation. To interrupt milling
or brewing, press OFF button. Red ON light will then turn off.
Do not attempt to lift mill/brew lid until operation has come to
a complete stop.
3. After brewing is complete, remove decanter from warming plate
and serve. Coffeemaker warming plate will cycle on and off to
maintain proper coffee temperature for one hour before it
automatically shuts off and the red ON light turns off.
4. Unplug and allow unit to cool for 10 minutes between cycles.
Allow to cool completely before attempting to clean.
Brewing Instructions (Continued)
7
NOTE: After unit is turned off or automatically shuts off after one
hour, mill coarseness setting will default to level 4 or medium
grind. Coarseness setting will also default to level 4 in the event
of power interruption.
Programming the Timer to
Make Coffee Later
You can program the timer to automatically mill and brew coffee up to
24 hours in advance.
1. Press and hold the TIME button for 2 seconds. The green TIME
light will come on and display will read 12:00. The unit is now in
the timer programming mode.
2. Press “HR” and “MIN” buttons to program start time. Small dot
in upper left corner signifies clock is programmed for A.M. No dot
in upper left corner means clock is programmed for P.M.
3. The timer display and LED light will flash 5 times to indicate that
timer is now set. Press and release the TIME button.
The green TIME light will come on.
NOTE: If unit is operated before programmed time, timer will
need to be reset. To do this, simply depress TIME button. LED
light will come on to indicate timer has been reset.
IMPORTANT: If programming timer to future start time, make
sure water tank has been filled and mill/brew basket contains the
correct amount of beans.
Care and Cleaning
CAUTION: ALWAYS UNPLUG UNIT BEFORE CLEANING AND
ALLOW TO COOL FOR 15 MINUTES BEFORE ATTEMPTING TO
CLEAN. NEVER USE SCOURING AGENTS. NEVER IMMERSE
MACHINE IN LIQUIDS. NEVER CLEAN MACHINE UNDER
RUNNING WATER.
Decalcification of Your Mill & Brew Coffeemaker
For best tasting coffee, and to promote longer use of your Mill & Brew ,
follow the procedure for decalcification every month, or after 30 uses.
If you have hard water, you may notice a slowing of the brewing
process—an indication that you should decalcify more frequently.
Programming the Mill (Continued)
8
1. Press OFF button.
2. Unplug and allow to cool completely before cleaning.
3. Wash and dry all removable parts.
CAUTION: DO NOT IMMERSE CORD, PLUG OR COFFEEMAKER
UNIT IN WATER OR OTHER LIQUID.
CAUTION: BLADES ARE SHARP. HANDLE CAREFULLY.
4. Special cleaning of the coffeemaker is recommended at least
once a month, depending on frequency of use and quality of
water. Mineral deposits can form a coating in the coffeemaker.
This may cause an off flavor in the water and may lengthen
brewing time.
5. Fill the decanter with 1 cup of vinegar and add 3 cups cold water.
Pour into water reservoir.
6. Make sure mill/brew basket and assembly are securely in place
and lid is closed.
7. Place decanter on warming plate.
8. Press ON button.
9. Halfway through brewing, press the OFF button. Carefully
remove the decanter and place on a heat resistant surface. Wait
15 minutes and pour solution back into water reservoir.
10. Press ON button. Allow all solution to empty into decanter. After
dripping stops, press OFF button and discard solution.
11. Allow coffeemaker to cool 10 minutes. Rinse it out by brewing a
decanter full of cold water. Discard water.
12. Wash, rinse and dry decanter and lid.
13. You may also use a commercial cleaner made for automatic
coffeemakers.
14. When coffeemaker has cooled, wipe exterior housing with
a damp cloth.
Any servicing requiring disassembly other than the above
cleaning must be performed by an authorized service center.
Mill & Brew Assembly
Never attempt to disassemble the grinder. If you wish to empty the
mill/brew basket to refill with different beans, pour beans out, then fill
with new beans. There will always be some ground coffee remaining
in the basket.
Care and Cleaning (Continued)
Loading...
