Medion X 7810 user Manual

Notes on This Manual

Keep these instructions with your computer at all times. The proper set up, use and care
can help extend the life of your computer. In the event that you transfer ownership of this
computer, please provide these instructions to the new owner.

This manual is divided into sections to help you find the information you require. Along
with the Table of Contents, an Index has been provided to help you locate information.
In addition, many application programs include extensive help functions. As a general
rule, you can access help functions by pressing F1 on the keyboard. These help functions
are available to you when you use the Microsoft Windows
application programs.

This interactive manual is designed to provide additional information about your
Notebook as well as useful links accessible via the World Wide Web.

Windows Vista
your Notebook. You can find this information in the Welcome Center after booting up
your Notebook. We have listed further useful sources of information starting on page 67.

®

offers you additional aids to learn about the new version of Windows and

®

operating system or the various

Document Your Notebook

It is important to document the details of your Notebook purchase in the event you need
warranty service. The serial number can be found on the back of the Notebook:

Serial Number ......................................

Date of Purchase ......................................

Place of Purchase ......................................

Audience

These instructions are intended for both the novice and advanced user. Regardless of the
possible professional utilization, this Notebook is designed for day-to-day household use.
The functions and applications for use with this Notebook have been designed with the
entire family in mind.

Quality

Medion has selected the components in this computer for their high level of functionality,
ease of use, safety and reliability. Through balanced hardware and software design we are
able to provide you with an innovative personal computer useful for applications relating
to both work and leisure. We are pleased to welcome you as our newest customer. Thank

you for choosing our products.

Copying this manual

This document contains legally protected information. All rights reserved. Copying in
mechanical, electronic and any other form without the written approval of the
manufacturer is prohibited.

Copyright © 2008

All rights reserved.
This manual is protected by Copyright.

Trademarks:

MS-DOS
Pentium

Other trademarks are the property of their respective owners.

Medion
not limited to, the implied warranties of merchantability and fitness for a particular purpose.

Medion
connection with the furnishing, performance, or use of this material.

Medion

furnished by Medion

This document contains proprietary information that is protected by copyright. All rights are reserved.
No part of this document may be photocopied, reproduced, or translated to another language
without the prior written consent of Medion

The information in this document is subject to change without notice.

®

and Windows® are registered trademarks of Microsoft®.

®

is a registered trademark of Intel®.

®

makes no warranty of any kind with regard to this material, including, but

®

shall not be liable for errors contained herein or for incidental or consequential damages in

®

assumes no responsibility for the use or reliability of its software on equipment that is not

®

.

®

.

ii

Table of Contents

Safety and Maintenance ........................................................................ 1

Safety Instructions .......................................................................................... 3

Data Security .............................................................................................. 4

Set-Up Location .......................................................................................... 4

Ambient Temperature................................................................................. 5

Working in Comfort.................................................................................... 6

Connecting................................................................................................. 7

Power supply ........................................................................................ 7

Cabling ................................................................................................. 8

Information about the regulatory compliance according to R&TTE............. 9

Modem....................................................................................................... 9

Touch Pad .................................................................................................. 9

Battery Operation ..................................................................................... 10

Views & Handling ................................................................................ 11

Included with Your Notebook....................................................................... 13

Views............................................................................................................ 14

Open Notebook........................................................................................ 14

Front side ................................................................................................. 15

Left Side.................................................................................................... 15

Right Side ................................................................................................. 16

Back side................................................................................................... 17

Device Indicators ...................................................................................... 18

Hotkeys .................................................................................................... 19

Getting Started ............................................................................................. 20

How to start:............................................................................................. 20

Step 1 ................................................................................................. 20

Step 2 ................................................................................................. 21

Step 3 ................................................................................................. 21

Short description of the Windows® Desktop......................................... 22

Main Components................................................................................ 25

Power Supply ............................................................................................... 27

On/Off Button .......................................................................................... 27

Power Adapter.......................................................................................... 27

Battery Operation ..................................................................................... 28

Inserting the Battery............................................................................ 28

Removing the Battery.......................................................................... 28

Charging the Battery ........................................................................... 29

Discharging the battery....................................................................... 29

Battery Performance............................................................................ 30

iii

Power Management ................................................................................. 31

Sleep Mode ( Ö ) ................................................................... 31

Hibernate Mode ( Ö ).................................................................. 31

Display ......................................................................................................... 32

Opening and Closing the Display ............................................................. 32

Screen Resolution ..................................................................................... 32

Personalization Appearance and Sound.................................................... 33

Connecting an External Monitor ............................................................... 34

Duplicating the Desktop ..................................................................... 35

Extending the Desktop ........................................................................ 35

Connecting a TV ....................................................................................... 36

Data Entry..................................................................................................... 37

The Keyboard ........................................................................................... 37

Notebook-Specific Key Combinations.................................................. 37

Touch Pad ................................................................................................ 39

The Hard drive .............................................................................................. 40

Important Directories................................................................................ 41

The Optical Drive.......................................................................................... 42

Loading a Disc .......................................................................................... 42

Emergency Ejection of a Blocked Disc.................................................. 43

Playing Back and Retrieving Data from Discs............................................. 44

Regional Playback Information for DVD .................................................... 44

Subjects Concerning the CD/DVD-Rewriter .............................................. 45

Recordable/Rewriteable Discs.............................................................. 45

The Sound Card............................................................................................ 46

External Audio Ports.................................................................................. 47

Modem (optional) ........................................................................................ 48

Modem Port ............................................................................................. 48

The Network................................................................................................. 49

What is a network? ................................................................................... 49

Ethernet-Network................................................................................ 49

Wireless LAN ....................................................................................... 50

Troubleshooting within the Network .................................................. 51

Bluetooth (optional) ..................................................................................... 52

The Multimedia Card Reader......................................................................... 53

Inserting Memory Cards ........................................................................... 53

Removing Memory Cards ......................................................................... 53

Express Card ................................................................................................. 54

Installing Express Card.............................................................................. 54

Removing Express Card ............................................................................ 54

Webcam (optional)....................................................................................... 55

Actual example using Windows Messenger .............................................. 55

The T.V. function (optional).......................................................................... 56

Connecting............................................................................................... 56

iv

The Remote Control (optional) ..................................................................... 57

Inserting Batteries................................................................................ 57

Installing the remote control receiver............................................................... 57

Button layout ...................................................................................... 58

Changing the transmission/reception channels................................... 60

Watch TV............................................................................................. 60

Universal Serial Bus (USB) Port ...................................................................... 61

Serial Interface .......................................................................................... 61

IEEE 1394 (FireWire)...................................................................................... 62

Application Options for IEEE 1394 ............................................................ 62

Technical Specifications ............................................................................ 62

Securing the Notebook ................................................................................. 63

Fingerprint Sensor (optional).................................................................... 63

Benefits of this technology .................................................................. 63

Configuration of the software: ............................................................ 63

Additional functions ............................................................................ 64

Fast user switching.............................................................................. 64

File Encryption .................................................................................... 65

File Decryption.................................................................................... 65

Startup Password...................................................................................... 66

Using a safety lock .................................................................................... 66

Software ....................................................................................................... 67

Getting to Know Windows Vista®.............................................................. 67

Windows Vista® – Quickstartguide ....................................................... 67

Windows Vista® – Help and Support .................................................... 67

Windows Vista® – Welcome Center ...................................................... 68

Windows Vista® – User Account Control............................................... 69

Software Installation ................................................................................. 70

Uninstall Software ............................................................................... 71

Windows Activation.................................................................................. 72

Product activation on your Notebook.................................................. 72

The BIOS Set-up-Program ......................................................................... 73

Running the BIOS Set-up..................................................................... 73

First Aid ...............................................................................................75

FAQ – Frequently Asked Questions ............................................................... 77

Data and System Security ............................................................................. 78

Data Security ............................................................................................ 78

Maintenance Programs............................................................................. 78

Password Reset Disk.................................................................................. 78

Windows® Update ..................................................................................... 79

Windows Update Information for Data Security .................................. 80

System Restore ............................................................................................. 81

Correction ................................................................................................ 81

System Restore powered by Symantec ..................................................... 82

Limits of the Recovery ......................................................................... 82

v

Performing the State of Delivery.......................................................... 82

Troubleshooting ........................................................................................... 83

Localize the Cause .................................................................................... 83

Check Cables and Connections ........................................................... 83

Errors And Possible Causes .................................................................. 84

Additional Support ................................................................................... 85

Driver Support.......................................................................................... 85

Maintenance................................................................................................. 86

Care of the TFT Display ............................................................................. 86

Transporting the Notebook ...................................................................... 87

Recycling and Disposal ............................................................................. 88

Batteries and Proper Treatment ........................................................... 89

Upgrades and Repairs............................................................................... 90

Notes for Service Engineers ................................................................. 90

Appendix ............................................................................................. 91

Standards ..................................................................................................... 93

Electromagnetic Compatibility.................................................................. 93

ISO 13406-2 Class II.................................................................................. 93

FCC Compliance Statement...................................................................... 95

Conditions of Warranty for the United Kingdom ........................................... 96

Index .......................................................................................................... 102

vi

Safety

Chapter 1

Safety and Maintenance

Subject Page

Safety Instructions .............................................................3

Data Security ......................................................................4

Set-up Location ..................................................................4

Ambient Temperature .......................................................5

Working in Comfort ...........................................................6

Connecting.........................................................................7

Information about the regulatory compliance

according to R&TTE............................................................9

Modem...............................................................................9

Touch Pad ..........................................................................9

Battery Operation .............................................................10

Handling Components Aid Appendix

2

Safety Instructions

Safety Instructions

Please follow the instructions in this section for the safe operation of your notebook:

• Do not allow small children to play unattended with electrical equipment. Children
are incapable of judging potential risks properly.

• Keep the packing materials, such as foil away from children. The danger of
suffocation could arise in the case of misuse.

• Do not open the case of the notebook, the battery or the power adaptor. When the
case is open there is a danger of severe electric shock.

• CD-ROM-/CDRW-/DVD-drives are Laser Class 1 devices. These lasers must remain in
their sealed casing. DO NOT remove the drive covers, as exposure to the lasers may
be harmful.

• Do not insert objects through the slots and openings of the notebook. This may
lead to electric shock, electrical short-circuit or fire that will damage your notebook.

• Slots and openings in the notebook serve to ventilate it. Do not cover up these
openings, because the notebook could overheat.

• The notebook is not intended to be operated in a heavy industry company.
Operation under extreme environmental conditions can result in damage to your
notebook.

• Do not operate the notebook during a thunderstorm, in order to avoid damage
through lightning strike.

• Never place objects on top of the notebook that would exert any pressure on the
display. There is a danger that even slight pressure may break the TFT display.

• There is a risk of injury if the TFT display breaks. Use protective gloves to pack up
the broken pieces and contact customer service to arrange for proper disposal. It is
important to thoroughly wash your hands after handling a broken TFT display.
There is a chance that chemicals may have been released.

• To avoid damage to the TFT Display, never open it more than 120º. Do not forcibly
open it.

• In order to avoid damage to the display, do not touch it with your fingers or sharp
objects.

• Never lift the notebook by the TFT Display; doing so could break the hinges.

Switch off your Notebook immediately or do not switch it on at all and contact
customer service …

• … if the power cord or the connectors attached to it are burnt or damaged. Replace
the defective power cord with an original power cord. Under no circumstances may
a defective power cord be repaired.

• ... if the housing of the Notebook is damaged or fluids have leaked into it. Have the
Notebook checked by customer service first, because the Notebook may not be
safely operated otherwise and there may be a life-threatening risk of electrocution!

Safety

Handling Components Aid Appendix

Safety Instructions

3

Data Security

Attention!

Every time you update your data make back-up copies on an external
storage medium. The supplier does not assume liability for data loss or
damage to data storage units, and no claims can be accepted for damages
resulting from the loss of data or consequential losses.

Set-Up Location

• Keep your notebook and all connected peripherals away from moisture, dust, heat
and direct sunlight. Failure to do so can lead to Notebook malfunction or damage.

• It is highly recommended you do not use the notebook outdoors.

• Operate the notebook and all peripherals on a stable, balanced and vibration-free

surface.

• Do not leave the base of your notebook on your lap or any part of your body for a
long period of time. The notebook can become very warm while it is turned on or
charging and can cause discomfort or injury from heat exposure.

• The device will emit heat during operation; the keyboard and the hand
compartment can warm up through this. This warming is normal and harmless.

• In the first hours of operation, new devices may emit a typical, unavoidable but
completely harmless smell, which will decline increasingly in the course of time. We
recommend you to ventilate the room regularly, in order to counteract the
formation of the smell. During the development of this product, we have made
sure that the applicable limits are clearly fallen below.

• Your notebook is not suitable for use at video workstation devices in the sense of §2
of the video workstation regulation.

4

Safety Instructions

Ambient Temperature

• The notebook is most reliably operated at an ambient temperature between
+41° (5° C) and +104° F (40° C) and at a relative humidity between 20% and 70%
(without condensation).

• When powered off, the notebook can be stored at temperatures between
32° and 140° F (0° and 60° C).

• Unplug the cable during thunderstorms and make especially sure to remove the
antenna cables, if present. We recommend the use of a surge protector for
additional safety, in order to protect your notebook from being damaged by power
peaks or lightning strikes through the power network.

• Wait until the notebook has reached ambient (room) temperature before turning it
on or connecting it to the power adapter. Drastic variations in temperature and
humidity can create condensation within the Notebook and may cause it to short­circuit.

• For transporting the notebook keep the original packing.

Safety

Handling Components Aid Appendix

Safety Instructions

5

Working in Comfort

Sitting in one position for long periods can be uncomfortable. To minimize the potential
for physical discomfort or injury, it’s important that you maintain proper posture.

• Back – While sitting at your work surface, make sure your back is supported by the
chair’s backrest in erect position or angled slightly backwards.

• Arms – Your arms should be relaxed and loose, elbows close to your sides, with
forearms and hands approximately parallel to the floor.

• Wrists – Your wrists should be as straight as possible while using the keyboard,
mouse or trackball. They should not be bent sideways, or more than 10 degrees up
or down.

• Legs – Your thighs should be horizontal or angled slightly downward. Your lower
legs should be near a right angle to your thighs. Your feet should rest flat on the
floor. If necessary, use a footrest, but double check that you have your seat height
adjusted correctly before getting a footrest.

• Head – Your head should be upright or tilted slightly forward. Avoid working with
your head or trunk twisted.

• Overall – Change your position frequently and take regular breaks to avoid fatigue.

6

Safety Instructions

Connecting

Pay attention to the following information, in order to connect your notebook correctly:

Power supply

• Do not open the power adapter housing. When the housing is open there is a
danger of severe electric shock. It contains no user-serviceable parts.

• The electric outlet must be in the vicinity of the notebook and within reach of the
power adapter cables.

• To disconnect your notebook from the power source, or set the notebook to
battery operation, remove the power cord from the notebook’s power socket.

• Only use the notebook with a power adaptor operating at
AC 110-240V~/50-60 Hz. For details on power consumption, please refer to the
rating plate on the rear of your notebook. If you are unsure of the type of power
supply available at the point of use, ask your local power company.

• Use only the supplied power cord and power adapter.

• If using an extension cord, make certain that it meets your local safety

requirements. If in doubt, consult an electrician.

• To provide additional protection against electric shock, power surges, lightning
strikes, or other electrical damage to your notebook, we recommend the use of a
surge protector.

• Firstly remove the plug, and then the connector of the notebook, from the power
source, if you want to detach the network adapter from the mains power supply. A
reverse sequence could damage the network adapter or the notebook. Always hold
the connector firmly when removing it. Never pull on the power cord.

Safety

Handling Components Aid Appendix

Safety Instructions

7

Cabling

• Arrange cables so no one can walk on or trip over them.

• Do not place objects on any of the cables.

• To avoid damage to your Notebook, connect your peripherals (e.g., keyboard,

mouse and monitor) whilst your notebook is powered off. Some devices can be
connected whilst your notebook is in use. These devices usually have a USB
connector. Please follow the appropriate instructions for each device.

• Keep the notebook at least one meter (approximately three feet) away from high
frequency and magnetic interference sources (e.g., televisions, loudspeaker
cabinets, mobile telephones, etc.) in order to avoid malfunctions and/or loss of
data.

• Please note that only shielded cables shorter than
3 metres (9.84 ft) should be used for the LPT, COM, USB, IEEE 1394, audio, video
and network interfaces with this notebook. Please use only doubly screened cables
in the case of printer cables.

• Do not replace the cables supplied. Only use the cable supplied with the notebook,
since that cable will have been tested extensively in our laboratory.

• Also only use the connection cables supplied with the devices to connect your
peripherals.

• Make sure that all connecting cables are connected with the respective peripheral
devices, in order to avoid perturbing radiation. Remove any cables not needed.

• The connection of devices is limited to equipment that complies with EN60950
“Safety of information technology equipment” or EN60065 “Audio, video and
similar electronic apparatus. Safety requirements”.

8

Safety Instructions

Information about the regulatory compliance according
to R&TTE

The following remote equipment has been supplied with this notebook:

• Wireless LAN (optional)

• Bluetooth (optional)

• Remote control receiver (optional)

• Remote control (optional)

Due to the capacity of the built-in wireless LAN solution (> 100 mW) the device may only
be used within buildings in France.
Currently none of the other EU-countries have any restrictions. For use in other countries
please obtain information about the applicable regulations locally.

The company declares herewith that these devices are in agreement with the fundamental
requirements and the other relevant terms of the 1999/5/EG Guideline. Complete
declarations of conformity are available under www.medion.com/conformity

The modem (optional) meets the requirements of TBR21 (01/1998) and
EG201120/V1.1.1/01/98 regarding connection with an analogue telephone network.

.

Safety

Handling Components Aid Appendix

Modem

• If your system has a modem, please make sure you connect it to an analogue
telephone line only. Connecting to a digital PBX, a digital line designed for
broadband services or ISDN, a shared service line or a payphone will damage the
modem or the devices to which it is connected.

Touch Pad

• Light pressure with the tip of your finger is all that is required to operate the touch
pad. Because the touch pad is electrostatic sensitive, objects cannot be used in
place of your fingers. Using a pen or other object can damage the touch pad or
cause the notebook to malfunction.

Safety Instructions

9

Battery Operation

To extend the life and power of your battery and guarantee secure operation, the
instructions below should be followed:

• Never expose the battery to direct sunlight or heat for long periods.

• Do not dispose of the battery by fire.

• Disregarding these instructions will lead to damage and under some circumstances

may even cause the battery to explode.

• Do not open the battery housing; it contains no user-serviceable parts.

• Keep the battery away from electrically conductive materials, chemical substances

and cleaning agents.

• Only use the originally supplied power adapter to charge the battery.

• Ensure (through the display or the signalling sound of the notebook) that the

battery is completely discharged before recharging it.

• Replace the battery only with the same type or an equivalent type recommended
by the manufacturer.

• Charge the battery only until the battery charging light goes out. Also, refer to the
instructions under “Charging the Battery” on page 29 for instructions on checking
the battery level.

• Only change the battery when the unit is switched off.

• Batteries are classified as special waste and should always be disposed of properly.

Contact Customer Service for more details.

10

Safety Instructions

Safety

Chapter 2

Views & Handling

Subject Page

Included with your notebook ............................................ 13

Open notebook .................................................................. 14

Front side ........................................................................... 15

Left side .............................................................................. 15

Right side............................................................................ 16

Back side............................................................................. 17

Power and status indicators ................................................ 18

Hotkeys .............................................................................. 19

Getting started ................................................................... 20

Handling

Components Aid Appendix

12

Included with Your Notebook

Included with Your Notebook

Please check that the contents are complete and notify us within 14 days of purchase if
any of the following components are missing:

• Notebook

• Battery

• Power adapter with connection cable

(Model: FSP120-AAC)

• Application-/Support-Disc

• OEM version of operating system

• Documentation

Safety

Handling

Components Aid Appendix

Included with Your Notebook

13

Views

Open Notebook

2

3

4

5

6

1 - Webcam (optional)................................................................ (Ö p. 55)

2 - TFT display .............................................................................(Ö p. 32)

3 - Hotkeys .................................................................................(Ö p. 19)

4 - Keyboard ...............................................................................(Ö p. 37)

5 - Touchpad ..............................................................................(Ö p. 39)

6 - Touchpad buttons .................................................................(Ö p. 39)

7 - Fingerprint Sensor (optional)..................................................(Ö p. 63)

8 - Device indicators ...................................................................(Ö p. 18)

9 - Microphone............................................................................(Ö p. 47)

10 - Palm rest

11 - Power ON/OFF ......................................................................(Ö p. 27)

1

11

7

8

(Diagram the same)

10

9

14

Views

Front side

12 12 13 14 15 16 8

8 - Device indicators ...................................................................(Ö p. 18)

12 - Display Catch .........................................................................(Ö p. 32)

13 - Line In ....................................................................................(Ö p. 47)

14 - Audio Out / Headphones ........................................................(Ö S. 47)

15 - Microphone ..........................................................................(Ö p. 47)

16 - Digital Audio Out (S/P-DIF).................................................... (Ö p. 47)

(Diagram the same)

Left Side

17 18 19

(Diagram the same)

17 - Stereo speaker

18 - Kensington

19 - Optical Drive ........................................................................(Ö p. 42)

®

lock ....................................................................(Ö p. 66)

Safety

Handling

Components Aid Appendix

Views

15

Right Side

20 21 22

17 - Stereo speaker

20 - Express Card/54 ....................................................................(Ö p. 54)

21 - Multimedia card reader .........................................................(Ö p. 52)

22 - USB port ...............................................................................(Ö p. 61)

23 - IEEE 1394 (Fire Wire) ...............................................................(Ö p. 62)

24 - Modem port (RJ-11) (optional) .............................................(Ö p. 48)

25 - LAN port (RJ-45) ....................................................................(Ö p. 49)

26 - Antenna connector (optional).................................................(Ö p. 56)

23 24 25 26 17

(Diagram the same)

16

Views

Back side

22 - USB port ...............................................................................(Ö p. 61)

27 - TV out port (S-Video).............................................................(Ö p. 36)

28 - External monitor port DVI ......................................................(Ö p. 33)

29 - Power socket ........................................................................(Ö p. 27)

30 - Serial port ..............................................................................(Ö p. 61)

27 28 22 29 30

(Diagram the same)

Safety

Handling

Components Aid Appendix

Views

17

Device Indicators

LED's indicate the power and operating system states of the Notebook. The meaning of
each LED is:

Num Lock

This LED lights when NUM-Lock has been activated (NumLk).

Capital Lock

This LED lights when CAPS-Lock has been activated. This sets the
keyboard to capital letters.

Scroll Lock

This LED indicates that the Scroll Lock key on the keyboard is activated.
The Scroll Lock key has different functions depending on the software
you are using.

Power indicator

Below you will see the different meanings of the LED in various
situation:

Green

Blinking
green

Orange

The notebook is in full operation.

The system is turned off or the notebook is
in Sleep mode.

The power adapter is connected and the
notebook is turned off.

18

Battery LED

Below you will see the different meanings of the LED in various
situation:

Orange

Blinking
orange

Green

The power adapter is connected and the
battery is being charged.

Almost completely discharged.

The battery is charged.

Views

Hotkeys

Access indicator

This LED lights or flashes when the notebook is accessing the hard
disk.

Wireless LAN

Display for wireless data exchange. If the display lights steadily the
wireless LAN function is enabled (optional feature).

Does not
light up

Lights up
green

Lights up
orange

Lights up
yellow

The Bluetooth and WLAN functions are
deactivated.

The WLAN function is activated.

The Bluetooth function is activated.

The Bluetooth and WLAN functions are
activated.

Safety

Handling

Button Function

Launches the E-Mail Program.

Launches the Internet Browser.

Turnst the Mediaplayer on / off.
Button that can be adjusted by the user to enable the preferred

program to start quickly.

Views

Components Aid Appendix

19

Getting Started

Before you get started using your notebook, first take a few moments to read the
important section on Safety. This notebook comes with software fully pre-installed.
You do not have to install any of the discs supplied.

How to start:

Step 1

• Insert the battery before bringing the notebook into operation by sliding the battery
pack into the compartment. Lock the battery under all circumstances, in order to
avoid it falling out unintentionally.

• Connect the supplied power adapter to the notebook at the notebook power
socket (29). Connect the power adapter via a power cable to a free AC power
outlet.

• Push the left lock to the symbol „unlock“.Open the display by pushing the right lock
to the right with your thumb and then opening the display to the required position
with your thumb and index fingers. Do not forcibly open it.

• Please ensure that the battery is inserted and the power adapter connected when
operating the Notebook for the first time. If you fail to do this, Windows Vista® will
not be able to calculate the performance index correctly.

• Switch the notebook on by operating the On/Off Switch (11). The notebook starts
and now goes through a number of phases.

Note

Make sure there is no bootable disc (e.g., the Recovery disc) in the optical
drive. Such discs will prevent the operating system from loading off the hard
drive.

The operating system is loaded from the hard disk. During the initial set-up, the loading
process takes slightly longer than normal to register the operating system and the
individual components completely. Your operating system is finished loading when a
welcome screen is shown on your display.

20

Getting Started

Step 2

Follow the instructions on the screen. Dialogue boxes will explain any steps that need to
be taken.

The greeting procedure will guide you through a series of dialogue boxes. The information
in each dialogue box will explain the steps that need to be taken.

Safety

Should you have any questions just click on

• License Agreement
The greeting procedure also displays the license agreement. Please read this
carefully. It contains important legal information on the use of your software. In
order to see the full text, use the mouse and the scroll bar on the right side of the
screen to move downwards until you have reached the end of the document. You
accept the agreement by clicking on the “I accept the agreement” option field.
Only by doing so will you be entitled to use the product under lawful terms and
conditions.

.

Step 3

After the login procedure the Windows® desktop appears on your screen.
You will find a brief overview on the following pages.
After the login procedure the Windows® desktop appears on your screen. This can be

adjusted so that the screen of your computer looks different.
However, basic operation is guaranteed.

Handling

Components Aid Appendix

Getting Started

21

Short description of the Windows® Desktop

After the login procedure the Windows® Vista® desktop appears on your screen. (Your
desktop might not look exactly like the one shown here.)

s

t

u

v

n o p q r

1. Start Button

Clicking the Start button brings up a menu where you can access help, software
programs, files, and settings.

2. All Programs

All of the software programs installed on your notebook are ordinarily listed here. Click All
Programs to reveal an extensive menu.

3. Program Bar

The most commonly used software programs are listed here.

4. Turn Off Computer

Click on this interface with the left mouse button and select the Shut Down option, in
order to switch the Notebook off.

5. Task Bar

Here you receive information and status reports about Windows® Vista® and which
programs are running.

22

Getting Started

6. Desktop Icons

Desktop icons link to their respective programs. To start a program, double-click its
desktop icon.

7. Logged in User

This tells you which user is logged in to your notebook.

8. Control Panel

You can use the icons in Control Panel to change the appearance and functionality of
Windows

9. Windows

®

Vista®. These icons represent options for configuring your notebook.

®

Vista® Help

Here you can find information on using your notebook, networking, backup, and many
other tasks.

Safety

Handling

Components Aid Appendix

Getting Started

23

24

Getting Started

Safety Handling

Chapter 3

Main Components

Subject Page

Power Supply .................................................................... 27

Display .............................................................................. 32

Data entry .......................................................................... 37

Hard Drive .......................................................................... 40

Optical Drive ...................................................................... 42

Sound Card ........................................................................ 46

Modem (optional) .............................................................. 48

Network ............................................................................. 49

WLAN............................................................................ 50

Bluetooth (optional) ........................................................... 52

The Multimedia Card Reader .............................................. 53

Express Card/54 ................................................................. 54

Webcam (optional)............................................................. 55

TheT.V. Function (optional) ................................................ 56

Universal Serial Bus (USB) Port ............................................ 61

The serial port..................................................................... 61

IEEE 1394 (Fire Wire) (optional) .......................................... 62

Securing the Notebook ...................................................... 63

Software ............................................................................. 67

Components

Aid Appendix

26

Power Supply

Power Supply

On/Off Button

Power on or off your notebook by pressing the on/off button (11) briefly.
The operational indicator will inform you about the operational status of the notebook.

The notebook will always be switched off, if the main switch is pressed for more than
4 seconds.

Warning!

Do not switch off your notebook while the hard disk or the optical drive is
running and the corresponding media activity LEDs are lit. Otherwise
data may be lost. To protect the hard disk you should always wait for
20 seconds after powering down the notebook before powering it up again.

Power Adapter

Your notebook is supplied with a universal AC power adapter, which automatically adjusts
to the available power source. The following levels are supported: AC 100-240V~/ 50-
60 Hz. Please follow the power supply safety instructions found on page 5.

The power adapter is connected via a power cord to an AC outlet. The DC power lead
from the power adapter is connected to the back side of the notebook (29).

Safety Handling

Components

Power Supply

Aid Appendix

27

The adapter provides the notebook with power and also charges the battery. The power
supply indicators of the notebook provide details on the operating state. The battery is also
being charged when you are working on your notebook with the power adapter. The
power adapter is still live if the notebook is not connected with it. You should therefore
unplug the power adapter from the outlet if it is not connected to the notebook.

Warning!

Use only the power adapter and power cord supplied with your notebook.

Battery Operation

Note

Please charge and discharge the new battery completely two to three times
in succession, so that it will achieve its full performance!

Batteries store electrical energy in their cells and then deliver it when needed.
The useful life and performance of your battery depend on careful handling.
The battery should be completely discharged before a charging process and completely

charged again, in order to optimize its useful life and its performance.
You must also pay attention to the Safety Notes from page 8.

Inserting the Battery

Slide the battery into the battery compartment.

Removing the Battery

Push the Safety Lock to the ‘Unlock’ position, in order to remove the battery pack.

Warning!

Do not remove the battery while the notebook is running on battery power.
You increase the possibility of losing data.

Warning!

Pay attention that the contacts to the battery and the notebook are not dirty
or damaged when storing the battery and using the notebook. This could
lead to malfunctions.

28

Power Supply

Charging the Battery

The battery is charged via the power adapter. If the power adapter is connected, it charges
the battery automatically, whether the notebook is turned on or not. When the notebook
is switched off, full charging takes a few hours. If the notebook is switched on, the
charging process takes a significantly longer time.

Note

The charging process will be interrupted if the temperature or the voltage of
the battery is too high.

Discharging the battery

Operate the notebook by means of the battery until it switches off independently because
of the low battery charge.

Note

Think about saving your open files in good time, to avoid a possible loss of
data.

Safety Handling

Components

Power Supply

Aid Appendix

29

Battery Performance

The particular operating duration will vary according to the setting of the energy saving
functions. You can adjust these to your requirements under Energy Options in System
Control. Apart from this, your notebook will require a higher power demand when
carrying out certain tasks, such as playing back a DVD.

Checking the Battery Level

In order to check the current level of the
battery, move the cursor over the
power symbol in the taskbar.

The symbol of a battery is displayed
during battery operation.

You will receive additional information
about settings if you double click on
this symbol.

Note

If you ignore the warning signal when the battery level is low, your
notebook goes into hibernate mode.

Warning!

Never remove the battery while the notebook is switched on or if the
notebook has not yet gone into hibernate mode, as this may lead to loss of
data.

30

Power Supply

Power Management

Your notebook offers automatic and modifiable power saving functions that you can use
to maximize battery life and reduce overall operating costs. The power saving modes are
known as sleep mode and hibernate mode.

Sleep Mode ( Ö )

When in sleep mode, the contents of the RAM of your notebook are preserved while
practically all other components of your notebook are shut down, reducing your power
consumption to a minimum. By pressing any key on the keypad, you can bring your
notebook back to the fully operational state. You will restart at precisely the line in which
you were working prior to the interruption. The computer takes less time to go into and
come out of sleep mode, but uses more power than hibernate mode.

Hibernate Mode ( Ö )

The hibernate mode is an alternative to a complete shutdown of the notebook. In this
mode all data from RAM (system and graphic data) are copied to the hard disk as a file. As
soon as the data has been safely saved, the notebook powers down. When the notebook is
switched on again, this file is written back to RAM by the BIOS. In a few moments the
notebook is in the exact state as when it was last used. If while working on a document the
notebook is closed (assuming the correct ACPI setting), the notebook saves the data in
RAM for you automatically. You will restart at precisely the line in which you were working
prior to the interruption. The computer uses no power while it is in hibernate mode, but it
takes a little longer for the computer to go into and come out of hibernation compared to
sleep.

Safety Handling

Components

Power Supply

Aid Appendix

31

Display

Unlike a normal monitor, the TFT display does not produce either radiation or flicker.

Opening and Closing the Display

The display is locked by means of a special construction of the display hinge, so that an
additional lock is not necessary.

1. Open the display by pushing the right lock to the right with your thumb and then
opening the display to the required position with your thumb and index fingers.

Warning!

To avoid damage to the TFT Display, never open it more than 120º. Do not
forcibly open it.

The opening and closing of the display can be assigned various functions via the Power
management feature.

Screen Resolution

The integral screen has a native resolution of 1440 x 900 pixels. If you change to a
presentation with different characteristics in the Windows “Personalization” Help
Program, the display will not appear on the whole area of the screen, among other effects.
Using a higher resolution can lead to distortion of the display, especially with text. Using a
lower resolution may cause the display to use only a portion of the screen area. You will
adjust the presentation to the mode supported with the Windows “Personalization”
Help Program.

32

Display

Personalization Appearance and Sound

This program offers you the possibility of adjusting the presentation on your display. This
includes the background colour, the screensaver, Active Desktop (web), additional display
settings and your graphics card, for example. The program can be started as follows:

• Right mouse click on the Windows interface (Desktop) and left mouse click on

Personalization

or

• Through Start Ö Control Panel Ö Personalization appearance and sound,
by means of a double click with the left mouse button.

Safety Handling

Components

You will have the possibility of changing the DPI setting, for example, in order to optimise
the display presentation. Click on Adjust front size (DPI) to do this.

Display

Aid Appendix

33

Connecting an External Monitor

The notebook has a DVI port (28) for connecting an external monitor.

1. Shut down your notebook.

2. Connect the video signal cable of the external monitor to the DVI port of the
notebook (28). Please use an appropriate adapter (optional), in order to be able to
attach an analog monitor.

3. Connect the external monitor to the electrical socket and power it up.

4. Start your notebook.

The external screen will be determined after the operating system has been loaded. The
following Window will appear and various possible presentations will be offered to you:

34

Display

Duplicating the Desktop

This mode duplicates the display of the Notebook on the external monitor.

You will switch between the following combinations with the help of the Fn + F7 key
combination:

• Only Notebook (1 x Fn + F7)

• Only external monitor (2 x Fn + F7)

• Notebook + external monitor (3 x Fn + F7)

Note

When using this modus the same screen resolution has to be set with both
devices.

Extending the Desktop

An empty Desktop will be displayed on the second [external] monitor in this mode.
Windows from the first screen cane shifted to the second one and vice versa.

This option does not support the key combination Fn + F7.
The screen resolution and the colour quality of the individual display devices can be set

under “Control Panel Ö Personalize Ö Display Settings”.

Safety Handling

Components

Display

Aid Appendix

35

Connecting a TV

The Notebook has a port (27) for connecting a TV. To connect and configure the
Notebook for a TV:

This option is supported by the Fn + F7 shortcut.

1. Shut down your notebook.

2. Connect the signal cable of the TV device to the S-video connection (27) of the
Notebook.

3. Connect the TV device to the network and switch it on.

4. Switch on your notebook and boot it properly.

You will be able to switch between the displays with the Fn + F7 shortcut. Proceed as in
the case of an external monitor here.

Note

If the option Extend the desktop onto this monitor in the program
Personalization Ö Display Properties is activated, then it must be

deactivated first in order to change the display to the TV set.

36

Display

Data Entry

The Keyboard

By dual assignment of certain keys you have the same range of functions available to you
as with a normal Windows keyboard. Some functions are input using the Fn key, which is
normal on notebook computers.

Notebook-Specific Key Combinations

Combination Description

Fn +

Fn + F1

Fn + F2 Background lighting

Fn + F3 Mute

Fn + F4 Sleep

Fn + F5 Decreases the volume.

Fn + F6 Increases the volume.

Fn + F7 Display

Playback / Pause button (in Audio/Video programs)

Activates / deactivates the Touchpad functions.

Switches the backlight off to save power. Pressing any key switches
the backlight on again.

Switches the loudspeakers on / off.

Power saving functions. This key combination is set to Hibernate
by default. To adjust this key to your own needs go to
Personalization Ö Screensaver in Power Options.

Toggles the display screen between internal monitor, external
monitor and simultaneous display.
Switch between the LCD display and the TV device in the case that
a TV device is attached. Display of both at the same time is not
supported.

Safety Handling

Components

Aid Appendix

Data Entry

37

Combination Description

Fn + F8 Reduces screen brightness.

Fn + F9 Enhances screen brightness.

Fn + F10

Fn + F11

Fn + F12

Webcam
Enables or disables the optional webcam.

WLAN
Enables or disables the WLAN function.

Bluetooth
Enables or disables the Bluetooth function.

38

Data Entry

Touch Pad

The touchpad is positioned in front of the keyboard.
The mouse pointer (cursor) follows the direction pre-determined on the touchpad by the

movement of your finger in the normal mode.

Caution!

Do not use a ball-point pen or other object on the touch pad, as this could

damage or cause a malfunction of your touch pad.

Below the touch pad are the left and right mouse buttons which can be used as on a
normal mouse.

You can also perform a direct click or double click using the touch pad by tapping the
surface briefly once or twice.

In the Windows
using the touch pad easier.

®

Control Panel you will find a number of useful settings that will make

Safety Handling

Components

Data Entry

Aid Appendix

39

The Hard drive

The hard drive is the main storage medium combining large storage capacity and rapid
data access.

The Windows operating system cannot use the full capacity of the hard drive, which
means that there will be a difference between the capacity that the BIOS displays and what
the operating system displays.

The hard drive contains the operating system of the computer, other application programs
and backup files. These programs and files are pre-installed on your notebook, so you may
note that some of the space on your hard drive is already taken.

Whenever the computer is accessing the hard disk, the corresponding LED illuminates.

Warning!

Never switch off the computer while the busy indicator is lit since this may
result in loss of data.

If you are looking for a file on the hard drive and you know the name, go to Search on the
Start menu to find the file. Following is some general information on where you might find
some common files.

Usually your hard drive is divided into several partitions, as shown below. The partitions of
your hard drive may vary from what is shown here.

BOOT C: Windows

Software programs
Your documents

RECOVER D: Drivers for internal Notebook components

Installation files for software that came with your
Notebook

Restore software

40

The Hard drive

Important Directories

The most important directories preinstalled on your notebook are shown below. These
directories may vary from what is shown here.

Warning!

Do not delete or modify these directories or their contents since data could
be lost or the functionality of the system could be at risk.

Also pay attention to this:

You will no longer be able to carry out the recreation of the supply status by
means of the Support Disc (Ö p. 82), if you have converted the Recovery
Partition into a NTFS file system.

C:\ This is the main hard disk drive partition for your notebook. It is where your

program files, settings, and documents are stored, as well as files necessary for
running Windows.

C:\Program Files

Includes files belonging to software programs.

C:\Windows

The main directory for Windows.

D:\Driver

Drivers for internal notebook components.

D:\Tools

Includes installation files for software that came with your notebook.

D:\Recover

Includes the files needed to perform a system restore.

Safety Handling

Components

Aid Appendix

The Hard drive

41

The Optical Drive

Loading a Disc

Unlike optical drives of desktop PCs optical drives of notebooks retain discs with the help
of a locking mechanism.

When inserting the disc you should take care to push the disc right onto the locking
mechanism so that it can lock in
position.

Note

Do not place protective foils or other stickers on your discs. To avoid
damage to your drive, do not use deformed of damaged discs.

Warning!

Do not use scratched or dirty discs, discs with pieces broken off or discs of
poor quality. Because of the high speeds in the drive the discs might break
and damage your data as well as your drive. Examine the discs before you
enter them. If damage or dirt is visible, you should not use them. Damage
caused by faulty media is excluded from warranty and their repair must be
charged.

Warning!

The disc can be damaged when the drive drawer is pushed in, if it has not
been positioned on the support correctly.

1. Press the eject button at the optical drive to open the tray.

2. Pull the tray out completely with care.Remove the disc from its case, without
touching the unprinted side if possible.

3. Place the disc on the tray so that it lays flat with the label facing upward and gently
push the tray in to close it. The disc will now lie flat on the tray and will engage
onto the disc holder audibly.

4. Test that the disc is able to turn freely and then push the tray back into the optical
drive carefully.

42

The Optical Drive

5. The ‘E’ drive letter will have been allocated to your optical drive in the delivery
status. You will have easy access to your files on your disks with Windows Explorer
(Computer). Start the Computer Help Program by means of the Desktop link or
by pressing the Windows key á and the ‘E’ key at the same time. Open Windows
Explorer by means of Start Ö All Programs Ö Accessories. The pre-installed
media reproduction will be used automatically during access to DVD videos (or
audio and video files on normal data CDs).

6. Press the eject button if you want to remove a disc.

Warning!

While the notebook is accessing the optical drive the media activity indicator
is lit. Do not try to remove the disc from the drive while this LED is lit.

Emergency Ejection of a Blocked Disc

If the tray fails to open automatically, then the tray can be opened manually provided
there is an opening for emergency ejection.

Restart your notebook and if the tray is still locked proceed as follows:

1. Shut down Windows and switch off your notebook.

2. Insert a long thin object (like a straightened paper clip) into the emergency ejection
opening until you feel resistance.

3. Press lightly and the tray will open.

4. Remove the disc and restart the notebook.

Safety Handling

Components

The Optical Drive

Aid Appendix

43

Playing Back and Retrieving Data from Discs

Your notebook is able to playback and to retrieve Audio CDs, DVD Movies and Data discs.
After loading the disc your operating system will open a selection window with different

options for playback. Normally there are various programs at your disposal.
If your operating system doesn’t open the selection window you still have the possibility of

the access via the “Explorer” or “Computer”.

Regional Playback Information for DVD

The playback of DVD movies includes the decoding of MPEG2 videos, digital AC3 audio
data and the deciphering of CSS protected contents.

CSS (sometimes called copy guard) is the name of a data protection program incorporated
by the movie industry as an action against illegal copies.

Among the numerous regulations for CSS licensees the most important ones are the
country specific playback restrictions.

In order to facilitate the geographically restricted release of movies, DVD titles are released
for certain regions. Copyright laws require the restriction of each DVD movie to a certain
region (usually the region, in which it is sold).

DVD movie versions can be published in several regions but the CSS regulations require
that each CSS decipherable system may only be used in one region.

Note

The decoding software included with your Notebook may be changed for
regional DVD decoding up to five times, after which the drive will only
play DVD movies for the region setting last entered. Changing the region
code after that will require factory resetting which is not covered by
warranty. If resetting is desired, shipping and resetting costs will be billed to
the user.

44

The Optical Drive

Subjects Concerning the CD/DVD-Rewriter

This Section only relates to devices that have been supplied with a CD-RW, a combination
drive or a DVD-RW drive.

First of all, you receive information on the so-called blank discs.

Recordable/Rewriteable Discs

Normal Discs are pressed from a digital, glass master and then sealed. In the case of blank
disc, the information is burnt onto the disc with the laser of the Rewriter. Therefore these
discs are more sensitive than normal discs.

Please avoid the following when using recordable/rewriteable discs - especially blanks ­that have never before been used:

• radiation by direct sunlight (UVA/UVB)

• scratches and damage to the disc surface

• extreme temperatures

Safety Handling

Components

The Optical Drive

Aid Appendix

45

The Sound Card

Your notebook has an integrated stereo sound card (on-board) with 16-bit and 3D spatial
sound effects (3D). The sound card is compatible with the industry standard Sound Blaster
and Microsoft Sound System Version 2.0. This guarantees optimal support for all popular
programs and games. If you wish to alter the base volume, click on the loudspeaker
symbol in the task bar.

Click on Mixer, in order to open the volume mixer.

By using the keys Fn + F5 and Fn + F6 you have the possibility to regulate the volume.

46

The Sound Card

External Audio Ports

Your notebook has a loudspeaker, so you can always playback sounds without additional
equipment. The use of the external connections gives you a good opportunity to connect
your notebook to external devices.

Caution!

The use of headphones/earphones with a high volume can lead to lasting
damage to your hearing. Set the volume to the lowest level before
reproducing any sound. Start the sound reproduction and increase the
volume to the level that is comfortable for you. Changing the basic settings
of the equalizer can also cause damage to the hearing of the listener.

It can cause damage to the hearing ability of the
listener if a device is operated through earphones with
an increased volume for a long period.

Line In

(13)

Audio Out

(14)

Microphone In

(15)

Digital

Audio Out

(S/P-DIF, electrical)

(16)

For reception through an external source of sound.

For sound reproduction via external stereo
equipment such as loudspeakers (active) or
headphones.

For recording via an external microphone.

For sound reproduction with an external surround
decoder via an electrical cable (available separately
at a specialist shop).

Safety Handling

Components

Aid Appendix

The Sound Card

47

Modem (optional)

The built-in modem is able to receive data according to the ITU standard for V.90
transmissions with up 56 Kbit/s. Since the power output of modems is restricted due to
the regulations of some telecommunication providers, the possible maximum download
speed can be restricted. The actual speed may be dependent on the online conditions and
other factors.

Data sent from the user to the server are transmitted with 31.2 Kbit/s. Prerequisite for this
high speed reception is an analogue telephone line compatible with the V.90 standard and
a corresponding compatible Internet provider or company-owned host computer.

The modem is fitted with an RJ-11 interface, into which a standard telephone lead can be
plugged.

Warning!

Use only with an analogue telephone line. The modem cannot withstand
the voltage levels of digital telephone systems such PBX or lines such as
ISDN or Broadband services. (see safety instructions on page 9).

Modem Port

1. Insert one end of the RJ11-connection (telephone plug connector) into the
modem/network interface (24) and the other into an analogue telephone socket
that is easily accessible.

Note

Do not place the notebook in Hibernate (or Sleep) mode if you are
connected to your Internet provider, since this will cause the modem
connection to be lost.

48

Modem (optional)

The Network

What is a network?

A network means connecting your notebook to one or several other computers. Users can
transfer data between computers and share resources such as printers, modems and hard
disk drives.

Here are some practical examples:

• You can exchange E-mail and manage appointments in an
office.

• Users can share a printer in a network and save their data on a central server.

• Users can share one modem among computers for Internet access.

• Two or more computers can be connected to play network games or share data.

Ethernet-Network

If your notebook has an Ethernet connection, you can use this to connect to a network.
The following explanation refers to notebooks with a network connector.
Connect one end to the RJ45 connection (Western plug) at the network interface of your

notebook (25) and the other to another PC or a hub/switch.
The Windows Help and Support Centre offer extensive information about networking your

Notebook. You can access this information by clicking on Start, then Help and Support.

Safety Handling

Components

The Network

Aid Appendix

49

Wireless LAN

Wireless LAN is an optional feature. This function allows you to create a wireless network
link with an access point or directly with another wireless-enabled PC.

Using the key combination Fn+F11 you can enable or disable the wireless LAN function.
A corresponding LED will light.

Warning!

Make sure the Wireless LAN option is switched OFF in any environment
where it might interfere with critical and sensitive devices, e.g., on aircraft, in
hospitals and other medical centres, etc.

Conditions

An access point is a wireless transmitter that communicates with your notebook and
controls access to the network connection (e.g., a home network or a broadband
connection such as DSL). Wireless access points are often found in offices, airports,
universities or Internet cafés. They offer access to networks or to the Internet. Access
authorizations are normally needed. A fee may be required to use a public access point.
To set up a wireless network to share Internet access, files, and printers at home, you will
need an access point, a router, and a broadband (DSL or cable) modem. Some access
points can also serve as a router and/or a broadband modem. Check with your retailer or
Internet Service Provider to find the best solution for your needs. A link to another
computer with wireless LAN functionality can also be created without an access point.
This will allow you to share files, but you will need an access point and a router to share an
Internet connection. The wireless network connection works in accordance with the
IEEE 802.11n Standard (compatible with the 802.11a/b/g Standard). If encrypted
transmission is used, this must operate according to the same principle on all devices.
Encryption is a method of protecting the network from unauthorized access. The
transmission speed (max. 300 Mbp/s) can vary according to the distance and loading of
the partner.

50

The Network

Troubleshooting within the Network

Why does an error message appear when I click on the network
environment?

The computer name must be unique on the network and may
not be the same as the task group.

It appears that the network boards are unable to communicate. What
might be the problem?

Maybe one of the used network boards works with a different
speed (e. g. 10 instead 100 Mbit/s) and your network computer
is unable to recognize this. If necessary, set the network driver to
the compatible speed.

If two PCs should be linked you require a cross-link cable,
otherwise use a patch cable.

In addition, check the protocols and the configuration.

The data transmission is incorrect or very slow. What might be the
problem?

Maybe you have the wrong cable (UTP / CAT3 or lower) or the
problem is the proximity of a power cord or another source of
interference.

Safety Handling

Components

The Network

Aid Appendix

51

Bluetooth (optional)

Bluetooth wireless technology is designed to replace cables between devices, such as
printers, keyboards, and mice.

Bluetooth wireless technology operates over a short distance. Bluetooth devices use radio
transmission, which enables computers, mobile phones, printers, keyboards, mice, and
other devices to communicate with each other without cables.

There are several uses for Bluetooth wireless technology, including, but not limited to:

• Creating a wireless connection to the Internet with a mobile phone or a modem
server.

• Transferring files between computers or between a computer and another device.

• Printing to a Bluetooth wireless printer.

• Using a Bluetooth wireless keyboard and mouse.

• Joining a personal area network (PAN).

• Synchronizing a personal digital assistant (PDA) to a computer or another device

using Bluetooth wireless technology.

The data transfer speed for Bluetooth wireless technology can be up to 700 kilobits (Kbp/s)
per second. The data transfer speed can vary depending on the device or environmental
factors. A Bluetooth device can transmit through walls, pockets, and briefcases.

Since Bluetooth is using the same frequency range as WLAN, simultaneous use might
cause interference. If this should happen you can disable one service temporary.

Using the key combination Fn+F12 you can enable or disable Bluetooth function. A
corresponding LED will light.

Warning!

Make sure the Bluetooth option is switched OFF in any environment where it
might interfere with critical and sensitive devices, e.g., on aircraft, in
hospitals and other medical centres, etc.

52

Bluetooth (optional)

The Multimedia Card Reader

Memory cards are media that are being used for a variety of purposes, especially in digital
photography. They are increasingly replacing the floppy disk. The form and capacity of a
memory card can vary according to the manufacturer.

Your notebook supports the following formats:

• MMC (MultiMediaCard)

• SD (Secure Digital)

• Memory Stick / Memory Stick Pro

When inserting memory cards, ensure that the contacts are facing the right way. See table
below. Incorrect insertion of a card can cause damage to the card reader and/or the card.

Card type Contacts

SD (Secure Digital)
MMC (MultiMediaCard)
Memory Stick
Memory Stick Pro

Inserting Memory Cards

Note

Memory cards can only be installed in one direction. Refer to the
instructions on the previous page.

pointing downwards
pointing downwards
pointing downwards
pointing downwards

Safety Handling

Components

Push the memory card into the slot.

Removing Memory Cards

To remove the SD/MMC-cards or memory sticks pull it out and remove it.

The Multimedia Card Reader

Aid Appendix

53

Express Card

Your notebook supports the Express standard.
Both Express/34 and Express/54 cards (the naming refers to the sizes of the cards) are

available on the market. Your notebook supports both card formats.

Installing Express Card

Note

Please always read the instructions that come with your Express card before
installation. Remove the dummy card from the slot before installation.
Replace the card to protect contacts against dirt if the Slot is not used.

Removing Express Card

Please take note of the following before removing the Express card:

• Terminate the program which you used with the card.

• Left-click on the icon Safely Remove Hardware

click on Stop.

In order to remove the card, first push it into the contact to unlock it. Pull the card from
the bay and store it securely.

54

Express Card

in the taskbar, select the card and

Y

Webcam (optional)

Various services like calling online can be used with the built in webcam.

Actual example using Windows Messenger

1. Start Windows Messenger and create a user account if you do not already have
one. This service is free of charge. You only pay the cost of your Internet
connection.

2. Select your contact from the list and click on the camera icon below your display
image.

Display image
contact

Safety Handling

Components

our

display image

Camera symbol

(Fig.: Messenger window Immediate Message)

3. A wizard helps you optimize the settings of your speakers, microphone and
webcam. Follow the instructions on your screen.

4. Click on Finish to transmit your image via the webcam.

5. If your contact also has a webcam, click on the camera icon below the display
image of your contact to receive the live image.

Webcam (optional)

55

Aid Appendix

The T.V. function (optional)

Connecting

An additional 75 Ohm coaxial antenna cable and the optionally additionally supplied
antenna adapter is required to enable TV.

1. Connect one end of the adapter with the antenna connector (26) and connect the
other end to a coaxial antenna cable.

2. Connect the other end of the coaxial antenna cable to an aerial antenna or to cable
TV.

Attention!

It is important that you pull out the antenna cable, when the device is not in
use, especially during thunderstorms. In this way you protect your device
from a potential power surge caused by lightning.

You will also be able to view your channels through DVB-T*, if you connect a
corresponding antenna to the antenna connection for the TV reception to do this.

*

Provided that DVB-T or digital services are offered at the respective location.

56

The T.V. function (optional)

The Remote Control (optional)

This wireless remote control set can only be used to control the Media Center program
on your PC. In order for it to work, the following conditions must be met:

• The PC must be booted up.

• Windows® must be fully loaded.

• The driver software must be installed*.

• Receiver connected to a USB port.

* All these conditions are met in the delivered state.

Inserting Batteries

1. Turn the remote unit round.

2. Open the battery compartment by pulling off the flap of the cover carefully.

3. Place one-button cell batteries (Type: CR2025, 3V) into the battery compartment.
Ensure that the polarity corresponds to the illustration etched on the inside of the
battery compartment (+ must correspond with + and – with –).

4. Replace the cover of the battery compartment.

Attention!

There will be a danger of explosion if the battery is replaced incorrectly.
Only replace it with the same type or an equivalent type of battery.

Safety Handling

Components

Installing the remote control receiver

It does not matter if the notebook is switched on or off when you connect up the remote
control receiver. The necessary driver software is already installed on your computer.

1. Boot up your notebook and wait for Windows

2. Insert the USB plug of the remote control receiver in a free USB slot.

3. Your PC will automatically detect the new device and automatically integrate it
provided that the driver has been installed (delivered state).

*

All these conditions are met in the delivered state.

The Remote Control (optional)

®

to load fully.

Aid Appendix

57

Button layout

Note

The functions described here are standard functions. These Buttons can
differ according to the operating mode (TV, video, photo, etc.).

On / Off

TV records

EPG function (Electronic Program Guide)

Watch TV programs

DVD menu.

Special function buttton red
(e.g.: Selection of the audio track)

Special function buttton green
(e.g.: subtitle selection)

Special function buttton yellow
(e.g.: Camera selection)

Special function buttton blue
(e.g.: Chapter selection)

58

The Remote Control (optional)

Press + to increase the volume.
Press - to increase the volume.

Safety Handling

Press + to select the next channel (TV). You select
the previous channel with -.

You select the required function with
these navigation Buttons. The selection
indicator will move in the appropriate
direction. Press the OK button to
confirm your selection .

Reverts to the point selected previously.

Application-related information function.

Starts Media Center.

Previous title/images/chapter

Next title/images/chapter

Rewind

Starts playback.

Fast forward

Start recording

Ends the playback/recording

Pauses the playback at the selected point.

Components

Direct selection of the TV channels by means of numbers.
Number entry in the case of some functions (video text,
etc.).

Aid Appendix

The Remote Control (optional)

59

Changing the transmission/reception channels

If several computers with remote controls are set up in close proximity of each other
(approx. 10 metres), this can lead to disturbance. This can be remedied by choosing
different channels. Only reset the remote control in case of disturbances. Proceed
as follows:

1. Start the Control Panel.

2. Choose the menu item Wireless Remote Settings.

3. Check the option “Use Wireless Remote Settings with the remote set to
this channel”.

4. Select the new channel (a number between 1 and 16) and confirm your setting
with the Apply button.

5. Press and hold the Clear button on the remote.

6. Now enter the channel already set in the software by means of the numeric key pad
of your remote, without releasing the Clear button.

7. Press the OK button. Do not release the Clear button until then.

8. Press any button on your remote to see the current code.

9. Confirm your settings by using the OK button of the Wireless Remote Settings
window.

Watch TV

We supply you with the optimum software for digital television, digital photography and
digital music with the Windows Media Center

®

Edition.

Attention!

Audio or video recordings need a great deal of memory (between 1 and 2
GB/hour). Safeguard files that you do not need on external media, such as
DVD/CD-Rs or hard drives.

60

The Remote Control (optional)

Universal Serial Bus (USB) Port

USB ports provide an easy way to connect many peripheral devices to your Notebook
(22). You can use any USB device with any USB port. Your notebook will have 4 USB

2.0 connection sockets (USB 1.1 compatible).
Some USB devices require that you reinstall software drivers when you connect the device

to a different USB port than the one originally used. This can be avoided by always using
the device with the same USB port.

Devices connected directly to the USB bus should not draw more than 500 mA. Should the
devices need more power than this, it will be necessary to provide a powered hub. The
data transfer speed is 1.5 Mbit/s or 12 Mbit/s, depending on the device connected.

Note

Some USB devices require that you reinstall software drivers when you
connect the device to a different USB port than the one originally used. This
can be avoided by always using the device with the same USB port.

Serial Interface

The 9-pin serial interface is used as the port for serial devices such as modems, card readers
or mice. The interfaces are addressed as COM1 and are FIFO 16550-compatible.

Safety Handling

Components

Universal Serial Bus (USB) Port

Aid Appendix

61

IEEE 1394 (FireWire)

(optional feature) IEEE 1394 (also known as iLink® or FireWire®) ports provide an easy and
high-performance way of connecting high-speed storage, imaging, and many new types
of audio/video devices easily.

Application Options for IEEE 1394

• Connection of digital devices of the entertainment industry, such as set-top

speakers, digital video and camcorder, ‘Digital Versatile Disk’ (DVD), television etc.

• Multimedia applications and video processing.

• Input and output devices such as printers, scanners, etc.

Technical Specifications

• Depending on the application, the maximum data transfer is about 100, 200 or 400

Mbit/s, corresponding to a data throughput of up to 50 MB per second.

• The device can be plugged in or unplugged during operation (hot plugging).

• The standardised cord (‘Shielded Twisted Pair’ -STP) includes 6 strands. Two lines

are live (8V up to 40V, 1.5 A max.) and can be used as an external power supply.
The four signal lines transfer data or control information. Some devices do not
require a power supply via the cord so that four pole plugs are used.

62

IEEE 1394 (FireWire)

Securing the Notebook

Your new Notebook will make software and hardware solutions to unauthorized access
available to you.

Fingerprint Sensor (optional)

Your new notebook is equipped with a fingerprint sensor.

Benefits of this technology

First of all, it provides extra comfort. You will not have to memorize passwords, because
the software manages those for you. The program remembers and saves all input that is
necessary for authentication purposes. By your fingerprint the program recognizes that
you are authorized to retrieve and transmit the login data.

Attention!

Store your passwords and access data in a safe place. If you cannot identify
yourself by your fingerprint (e.g., when working on someone else's
computer), you can log in with your access data in the usual way.

Configuration of the software:

1. To configure the software, click on the Start button. The Omnipass wizard is
launched and takes you through the configuration process:

Safety Handling

Components

Securing the Notebook

Aid Appendix

63

2. The next window shows the user name you entered during registration. If you have
a password, enter it here. We recommend that you discontinue this process if you
do not have a password yet. Continue only once you have set up a password in
system control under user accounts. The option to restore a user from a backed-up
user profile is not relevant to the first-time setup, but only once the notebook has
been set to delivery state and you want to use the profile originally created.

3. If you have a password, continue with the setup. Follow further instructions on
your screen.

Additional functions

1. Open the Omnipass Control Center Ö Change Your System Settings Ö Enable or
disable pre-boot authentication.

2. Check „Enable System Boot Authentication“ and remove for added security the
option „Enable Single Touch Boot feature“.

3. Click on Next and assign a password. Confirm it and click Next.
After the system reboot, either your fingerprint or the recently created password is
queried before the operating system can be launched.

Fast user switching

1. If you have created two or more user accounts, the respective users can log on
using their fingerprints.

2. Open the Omnipass Control Center Ö Change Your System Settings Ö

Modify Windows Fast User Switching option Ö Enable Windows Fast User
Switching and save all changes.

64

Securing the Notebook

3. To do this, simply move your finger over the sensor. The „ Fast User Switching
Desktop“interface comes up.
With one or even several users already using the notebook, to register a new user,
simply move your finger over the sensor.

Note

Changes to system settings require administrator rights.

File Encryption

You will in addition have the possibility of setting up an additional access block for all files
and directories on your Notebook, for additional protection against external access to your
Notebook. During this, the files are converted into a format that cannot be read by
unauthorized users (encryption). It will only be possible to unblock or decrypt the files
with your main password or with a given security device after the encryption.

The encrypted files will have the ‘opf’ ending.

The encrypted directories will take over the name of the original directory, but will end
with ‘opx’.

Attention

Safety Handling

The sensor and finger should be clean of any foreign material when used.

1. Click on the file or the directory for which you would like to prevent unauthorized
access with the right mouse button, to encrypt a file or a directory.

2. Click on OmniPass – Encrypt File(s) in the Context menu. OmniPass will then
request you to authenticate yourself.

3. Click on OK when the encryption has been concluded.

File Decryption

1. Click on the file or the directory for which you would like to recreate normal access
with the right mouse button, to decrypt a file or a directory.

2. Click on OmniPass – Decrypt File(s) or on Open in the Context menu.

3. Both actions will lead to the circumstance that OmniPass will invite you to
authenticate yourself. The file will remain decrypted until you encrypt them again,
after the decryption. A renewed encryption will not take place automatically.

Securing the Notebook

Components

Aid Appendix

65

Startup Password

You can protect your notebook against unauthorized use with a switching on password.
Then, an invitation to enter the password will appear on the screen when the notebook is
switched on.

The password will be set up in BIOS.

Warning!

Keep your password in a safe place. You will not have any possibility of
deleting your password if you forget it. Contact your Customer Service in
that case.

You can also use the security options of Windows Vista®, in order to protect your data
against unauthorized access. You will find further information in the chapter “Data and
System Security” starting on page 78.

Using a safety lock

You can prevent theft by using a so called Kensington lock, which can be bought at
your local retailer.

The cable wraps around an object and the “T” shaped end inserts into the Kensington lock
port and a key or combination dial is used to secure the lock in place. Please keep your key
at a safety place.

66

Securing the Notebook

Software

There are many kinds of help and information for using your Notebook. This section tells
you where to get help with the Microsoft
programs, and your notebook.

Getting to Know Windows Vista®

Windows Vista® offers different options to understand its operation, we will mention only a
few of those options here:

Windows Vista® – Quickstartguide

This Handbook will give you a brief overview of the operation of your operating system.
The following themes are dealt with in it:

• Initial steps

• The Welcome Center

• Innovations

• Help displays

We recommend this reading matter to beginners and those switching from other versions
of Windows.

Windows Vista® – Help and Support

An answer to almost every question can be found in this program.
This help function fully covers the Windows operating system.
It is helpful for both beginners and professionals. You can print or bookmark the

information, which is categorized into topics. You start like this:

®

Windows® Vista® operating system, software

Safety Handling

Components

Aid Appendix

1. Click on Start

2. Now select Help and Support

Software

67

Windows Vista® – Welcome Center

You will see the Welcome Center at the first display of the Windows Vista® Desktop. This
contains useful links that will make it easier for you to start using Windows.

It is the aim of this feature to enable both beginners and experienced users to make
additional setting for the optimal use of Windows Vista
into operation.

The Welcome Center has been subdivided into many small groups of subjects, so that the
user will have the possibility of adjusting the content optimally to his or her knowledge.
There are some of the links in the following:

• View computer details
(Find information about you computer, the type of your graphics card and the
Windows Vista

®

version here)

• Transfer files and settings
(Transfer data and settings off your old Notebook with this)

• Add new users
(Administrate and open user accounts for each user of the Notebook with this)

• Connect to the Internet
(Configure your internet access with this)

®

• What’s new in Windows Vista
(Learn how Windows Vista

®

is different in comparison to older versions)

• The use of the email program

• …and much more!

®

after first bringing the Notebook

68

Software

Use the Welcome Center to understand your Notebook better and in order to be able to
use it optimally. It will also serve you as an additional source of information for
recognizing and removing potential problems.

You will call up the Welcome Center as follows, if you closed it after the start:

Safety Handling

1. Click on Start

2. Select Welcome Center in the Program List.

Windows Vista® – User Account Control

The User account control contributes to the prevention of unauthorized changes to the
Notebook.

A window with the message “If you started this action, continue.” will appear as
soon as you carry out an unauthorized change.

• Click on Continue, in order to continue the procedure.

• Click on Cancel, in order to end the procedure.

Components

Software

Aid Appendix

69

Software Installation

Note

If your operating system is configured that the installation procedure
accepts only signed drivers (default) and software an information screen will
appear.

The software included in delivery is already pre-installed in the factory.

It happens that during installation procedure important files can be
changed or even cancelled. To avoid eventual problems in using
older files after installation, make sure to safeguard your hard disk.

Please follow the instruction of the software vendor. We will describe a typical installation.
Once you insert a disc, the installation menu is started automatically.

Note

If the automatic start does not work, it is likely that the so-called Autorun
function has been deactivated. Read the respective chapter in Windows
Help on how to activate this function.

An example for the manual installation without the autorun function:

1. Click on Start

2. Click on  All Programs.

3. Open the Accessories

4. Select the item Run.

5. Now enter the letter of the CD-ROM drive followed by a colon and the program
name setup:

70

program point.

Software

6. Click on “OK”.

7. Follow the instruction given by the program.

Uninstall Software

In order to remove installed software from your Notebook, follow the next steps:

Safety Handling

1. Click on Start

2. Click on

3. Then select the Programs

4. Select the respective program, start the de-installation and follow the instructions
on the screen.

.

Control Panel.

option.

Components

Aid Appendix

Software

71

Windows Activation

Microsoft is committed to the protection of intellectual property rights and the reduction
of software piracy. Therefore Windows Vista

®

contains software-based product activation
technology. Your copy of Windows Vista® has already been activated for your
Notebook.

Product activation is needed if some components of your Notebook have been replaced or
you use a non-authorized BIOS. If necessary you can activate Windows Vista

®

as often as

requested.

®

You will probably need to activate Windows Vista

by telephone even if Internet Activation
is available. This is due to the pre-activated SLP version which runs with a special Product­ID. However, activation needs your unique Product ID which can be found on the
Certificate of Authenticity sticker on your Notebook housing. When you call, please
inform your agent that you are running an OEM-(SLP) version of the software.

Product activation on your Notebook

In few cases it may still be required to activate Windows Vista®. If activation via the
internet is acknowledged with an error message you should perform the following steps.

1. Please select the telephone activation and click until the related screen appears.

2. Now click on Change Product Key. A new window appears. Enter the product
key. This is located on the Certificated of Authenticity (COA), on the
computer’s casing.

3. Acknowledge your entry and follow the instructions on the screen. Notify your
Microsoft consultant, if necessary, that you have purchased an OEM license with
your computer.

72

Software

The BIOS Set-up-Program

In BIOS setup (Basic Configuration) there are a number of configurable parameter settings
available for your notebook. For example, you can change the operating mode of the
interfaces, security features or power management.

Warning!

The notebook is factory pre-set to guarantee optimum operation. Only
modify the parameters if necessary and if you are familiar with the
configuration options.

Running the BIOS Set-up

You can only run the BIOS configuration program at system start-up. If the notebook has
already started, power it down and then up again. Press the F2 function key in order to
start the BIOS-SET-UP.

Safety Handling

Components

Software

Aid Appendix

73

74

Software

Safety Handling Components

Chapter 4

First Aid

Subject Page

FAQ .................................................................................... 77

Data and System Security ................................................... 78

System Recovery................................................................. 81

Troubleshooting................................................................. 83

Maintenance....................................................................... 86

Aid

Appendix

76

Software

FAQ – Frequently Asked Questions

Do I still have to install the enclosed discs?

No. Basically all programs are already preinstalled. The discs are
only intended as backup copies.

What is the Windows activation?

Your operating instructions include a chapter about this subject.

When do I have to activate Windows?

Your software has been preactivated in the factory. An activation
will only be required, if ...

... several components are replaced by others.
... your installed a new motherboard.
... a different BIOS version has been installed.
... you install the software to another computer.

How do I perform a data backup?

Make a backup and a retrospective backup of selected data on
external media (CD-R), in order to become familiar with the
technology.

A backup is unusable if you are not in a position to recreate the
data, the medium (CD-R) is defective or is no longer available.

Safety Handling Components

When is the recovery of the factory setting recommended?

This method should be chosen as the last resort. Read chapter
“System Restore” concerning the possible alternatives.

Why is the boot partition missing when booting from the support/
application disc?

The first partition is formatted with the file system NTFS.
Compared to FAT32 this file system offers more security and a
more efficient access. However, NTFS partitions can only be read
from operating systems supporting this. This is not the case in the
aforementioned disc.

FAQ – Frequently Asked Questions

77

Aid

Appendix

Data and System Security

The programs described below are part of your Windows operating system. You will have
additional information on these programs in the Windows Help file.

Data Security

Back up data regularly on external media such as a CD-R or CD-RW. Windows offers
Backup Status and Configuration.

This program is found in Accessories Ö System Tools within the Start menu. You
should make a backup disk with all your passwords and the operating system’s original
configuration.

Maintenance Programs

You can avoid some hardware and software errors with disk maintenance programs such
as Disk Defragmenter and Disk Cleanup. The program System Information can
also be helpful since it gives you detailed information about your system configuration.
You will find these programs in Accessories Ö System Tools.

Password Reset Disk

To protect individual user accounts from complications resulting from lost passwords,
users should create a password reset disk and keep it in a safe place. If the user should
forget his/her password, the password can be reset with the password reset disk so that
the user has access again to his/her local user account.

Windows Help describes how to create a password reset disk.

78

Data and System Security

Windows® Update

Windows Update is the online updating of Windows. Use Windows Update to download
elements such as security updates, important updates, the newest help files, drivers and
Internet products from the Internet.

The website is regularly augmented by new content, so that you can download the
newest updates and error corrections at any time, to protect the notebook and guarantee
its functioning.

Windows Update will search through the notebook and provide a list of individual updates
specially for the configuration of your notebook.

Each update that Microsoft regards as important for the operation of the operating system,
programs or hardware components will be classified as an “important update” and
automatically selected for installation for you.

Important updates will be provided to remove known problems and to protect the
notebook against known security risks.

Carry out four simple steps, to download the updates needed and to keep your computer
on the current status of technology:

Note

Updates can be done only via the Internet. When downloading updates,
make sure that your notebook is online.

Safety Handling Components

1. Click on Start .

2. Click on  All Programs.

3. Open Windows Update

4. Click on Check for update.

5. Click on Add to select the desired update and to add it to the updates to be
installed, while you are searching through the available updates in each category.
You can also read a complete description of each individual element by clicking on
the Read further Link.

6. Click on Check and install updates, when you have selected all the desired
updates, and then click on Install now.

.

Data and System Security

Aid

Appendix

79

Windows Update Information for Data Security

Windows Update needs certain information about the respective notebook, so that a
suitable list with updates can be provided for you. This information will include the
following:

• Version number of the operating system

• Version number of Internet Explorer

• Version numbers of additional software programs

• Plug & Play identification key of the hardware devices

Windows Update will stand up for the protection of your private data and will not record
your name, address, email address or other forms of personal data. The information
collected will only be used during the time that you are visiting the website. It will also not
be stored.

80

Data and System Security

System Restore

Windows Vista® provides a useful function (System Restore) enabling the storage of the
so-called Recovery points.

The system remembers the current configuration as a snapshot and returns to this, if
necessary. The advantage is that an unsuccessful installation can be cancelled.

Recovery points are created automatically by the system, but they can also be set
manually.

You can determine and configure yourself the maximum memory taken up by this. You
find this program in the program file under Accessories Ö System Tools.

We recommend setting a recovery point before installing a new software or driver. If the
system does not run stable any longer this enables you usually to return to a workable
configuration without deleting newly created documents. In the next paragraph read your
options for a repair of an incorrect installation.

Correction

Windows Vista® includes various functions ensuring that the Notebook as well as the
installed applications and devices work correctly.

These functions assist you in solving the problems which might occur by adding, deleting
or replacing files required for the functionality of the operating system, the applications
and devices. The recovery function or functions you use depend on the type of occurring
problem or error. For detailed information refer to the Windows help.

Safety Handling Components

System Restore

Aid

Appendix

81

System Restore powered by Symantec

If your system is not functioning properly and Windows Vista® System Restore did not
solve the problem, then you should use the Application Support Disc and not the
Windows Vista Recovery Disc to restore your system.

Limits of the Recovery

• Changes made to the original configuration (RAS, Desktop or Internet settings) and
installed Software will be ignored by this Recovery and will not be reloaded.

• Driver Updates or hardware installed by you will be ignored by this Recovery.

Warning!

All data on drive C will be erased. If necessary, backup all required data on
drive D. (You must pay attention to the information of pages 4 and 78).

This recovery will reset your system to its condition at delivery. Printer installations or
other additional software must be reinstalled.

Performing the State of Delivery

1. First, please read the entire System Restore section of the Windows Help file.

2. Insert the Support-Disc and reboot the notebook.

3. Select the option „Boot from CD-ROM “.

4. Follow the instructions on the screen.

The Notebook will restart and will return to the state at delivery.

82

System Restore

Troubleshooting

Localize the Cause

Errors can have simple causes, but sometimes they are caused by faulty equipment. We
would like to give you some tips to help solve common problems. Should these
instructions not lead to success, please feel free to contact us.

Check Cables and Connections

Visibly check all cables and connections. Should all lights be off, check whether all
equipment is supplied with power.

• In battery mode, connect the notebook to the power adapter and ensure that the
battery is charged up.

• If you are operating the notebook with the power adapter, check the electrical
socket, power cord and all switches in the circuit of the electrical socket.

• Switch off the notebook and check all cable connections. Check the connections to
peripherals. Do not exchange cables, even though they may look similar. The
polarity in the cables may be different. When it is confirmed that the notebook has
power and all connections are correct, turn the notebook on again.

Safety Handling Components

Troubleshooting

Aid

Appendix

83

Errors And Possible Causes

The screen is black:

• This error can have different causes:

1. The operational display (On /Off switch) does not shine and the Notebook is in

the swap file status.
Solution:
Operate the On /Off switch.

2. The sleep display is flashing. The Notebook is in the sleep mode.

Solution:
Operate the On /Off switch.

3. The background lighting has been deactivated with the FN+F2 shortcut.

Solution:
Operate any key to switch on the background lighting again.

The notebook switches itself off during operation.

• The accumulator could be empty. Connect the notebook by means of the network
adapter and charge the accumulator.

The notebook cannot be switched on.

• Operate the notebook by means of the accumulator and check whether it is
correctly inserted and charged.

Incorrect time and date display.

• Click the time display in the task bar and set the correct values afterwards.

No data can be read from the optical drive.

• Check whether the disc is correctly inserted.

• Is the drive displayed in Explorer? If yes, test another disc.

The WLAN connection is not functioning.

• Using the key combination Fn+F11 you can enable or disable the wireless LAN
function. A corresponding LED will light.

The Bluetooth connection is not functioning.

• Using the key combination Fn+F12 you can enable or disable the Bluetooth
function. A corresponding LED will light.

84

Troubleshooting

Additional Support

If the suggestions in the above section have not solved your problem, please contact
customer care and we will attempt to help you solve the problem. Before you call,
however, please have the following information available:

• How is your computer configured?

• What additional peripherals do you use?

• What messages, if any, appear on your screen?

• What software were you using when the error occurred?

• What steps have you already undertaken to solve the problem?

• Have you upgraded or removed drivers or hardware?

• Can you manually repeat the problem?

• If you have been given a customer number previously, please have this available.

Driver Support

This notebook has been extensively tested in our laboratories with a large number of
compatible devices. It fulfils all required standards and complies with the standard
“Designed for Windows”, which certifies utmost compatibility. However, the software
drivers for individual components are updated from time to time. This is a regular process
provided by the manufacturer to mend possible compatibility problems that may occur
with components (e.g., programs or hardware) that were not tested at the time of your
notebook’s manufacture.

Safety Handling Components

Troubleshooting

Aid

Appendix

85

Maintenance

Warning!

There are no user-serviceable or user-cleanable parts inside the notebook
housing. Never open the notebook housing.

Following these measures can extend the lifetime of your notebook:

• Before cleaning, always remove the power adapter plug and all connecting cables.

• Only use a damp, lint-free cloth to clean the notebook.

• Do not use any solvents, corrosive or gaseous cleaning agents .

• Do not use CD-ROM cleaning discs or similar products that clean the lens of the

laser to clean your optical drive.

• Dust or grease on the touchpad will impair its sensitivity. Remove dust or grease on
the surface of the Touchpad with a strip of sticky tape.

Care of the TFT Display

• Always close the notebook when not in use. Avoid touching or scratching the
surface of the screen as it is easily damaged.

• Make sure that no water drops are allowed to remain on the screen. Water can
cause permanent discoloration.

• Clean the screen with a dry, soft, lint-free cloth.

• Do not expose the screen to bright sunlight or ultraviolet radiation.

• The notebook and its packaging are recyclable.

86

Maintenance

Transporting the Notebook

Please use the following guidelines when transporting the notebook:

• Switch off the notebook. This will prevent damage to the hard disk. When the
notebook is turned off, the hard disk heads are moved into a safe area.

• Wait until the Notebook has reached ambient (room) temperature before
connecting it to the power supply. Drastic variations in temperature and humidity
can create condensation within the Notebook and may cause it to short-circuit.

• Close the notebook and ensure that the cover locks shut.

• Always use the notebook carrying case. This helps to protect the notebook from

dirt, moisture, jolts and scratches.

• Should you need to ship your notebook, always use the original packaging and
make certain the shipper knows the contents contain fragile electronic equipment.

• Fully charge your battery and any spare batteries immediately before a long
journey.

• Enquire about the electricity and communication provision at the location before a
journey.

• Acquire the necessary adapter for electricity or communication (modem, LAN, etc.),
if necessary, before starting your journey.

• Put the battery into the packaging separately when despatching the notebook.

• It is recommended to send the notebook and all magnetic storage media (floppy

disks, external drives) through the x-ray device (the device into which you put your
bags), when you are passing through the baggage check at airports. Avoid the
magnetic detector (the construction, through which you walk) or the magnetic rod
(the manual device of the security personnel), because they could destroy your
data, among other consequences.

Safety Handling Components

Maintenance

Aid

Appendix

87

Recycling and Disposal

Device
At the end of its life, the appliance must not be disposed of in household rubbish. Enquire

about the options for environmentally-friendly disposal

Batteries
Do not dispose of used batteries in the household rubbish! They must be deposited at a

collection point for used batteries.

Packaging
To avoid damage during transport, the Notebook is stored in a packaging. Packaging is

produced mostly from materials which can be disposed of in an environmentally friendly
manner and be professionally recycled.

Should you have any questions concerning the disposal please contact your dealer or our
service.

88

Maintenance

Batteries and Proper Treatment

Batteries may contain combustible materials. By misuse, this may cause battery leakage,
heat, explosion or ignition, bringing about injury or damage to the device. Please

observe strictly the following matters:

Warning!

There is a lithium battery on the motherboard. Lithium batteries are
hazardous waste and need to be disposed of properly. If necessary, we
will take back your used CMOS lithium battery.

• KEEP CHILDREN AWAY from batteries. If by any chance, the batteries are swallowed,
consult a doctor immediately.

• DO NOT CHARGE batteries (except rechargeable batteries).

• DO NOT FORCIBLY DISCHARGE batteries.

• DO NOT SHORT-CIRCUIT batteries.

• DO NOT HEAT or DISPOSE OFF IN FIRE.

• DO NOT DISASSEMBLE or DEFORM batteries. Your hands and fingers may be

injured, or the liquid of the battery may get into your eyes or adhere to your skin. If
this happens, rinse with a large quantity of water immediately and consult a doctor.

• DO NOT expose batteries to strong impact by dropping or throwing the batteries.

• DO NOT reverse the positive (+) and negative (-) terminals to avoid short-circuit.

• Do NOT MIX used and new or different types of batteries together.

Your equipment may not operate properly. In addition, the battery exhausted first
may be excessively drained (over-discharged).

• REMOVE PROMPTLY the used batteries from the device.

• REPLACE ALL BATTERIES with new batteries of the same type at the same time.

• INSULATE THE TERMINAL parts with tape or the like at the storage or disposal of the

batteries.

• DO NOT throw rundown batteries in the domestic refuses! Respect the
environment and throw them in the specific containers for separate collection. If
necessary, turn to your reseller or to our service assistance. Thank you!

Safety Handling Components

Aid

Maintenance

Appendix

89

Upgrades and Repairs

• Only a qualified Service Engineer should perform upgrades and repairs to your
notebook.

• If you do not have the necessary qualifications, go to an appropriate Service
Engineer. Please contact the Service Centre if you are experiencing technical
problems with your notebook.

• Please contact our authorized Service Partners exclusively in the case of a necessary
repair.

Notes for Service Engineers

• Before opening the housing, disconnect the notebook from all power sources and
remove any connecting cables. If the notebook has not been disconnected from the
power outlet before being opened, there is a danger of severe electric shock. There
is also a risk of damage to the components.

• Internal components of the notebook may be damaged by electrostatic discharge
(ESD). Perform system upgrades and changes in an ESD-protected work area. If no
such work area is available, wear an antistatic wrist strap or touch a highly
conductive metal object. Your service centre can repair damage sustained by
inappropriate handling for a fee.

• Use only original spare parts.

Notes on Laser Radiation:

• Laser devices of Laser Class 1 to Laser Class 3b may be used in the notebook. Where
the notebook housing remains closed, the device meets the requirements of Laser
Class 1. By opening the notebook housing you will gain access to laser devices of
up to Laser Class 3b.

• The CD-ROM/CD-RW/DVD/DVD-RW drive contains no user-serviceable parts. Only
the manufacturer should perform repairs to the CD-ROM/CD-RW/DVD/DVD-RW
drives.

When removing and/or opening laser devices, the following guidelines must be observed:

• DO NOT look into the laser beam, even while wearing optical protection.

• DO NOT allow yourself to be exposed to the laser beam. Avoid exposure of the eyes

or skin to direct or stray
radiation.

90

Maintenance

Safety Handling Components Aid

Chapter 5

Appendix

Subject Page

Standards ........................................................................... 93

Conditions of warranty ....................................................... 96

Index ................................................................................ 102

Appendix

92

Maintenance

Standards

Electromagnetic Compatibility

• When connecting additional components, please observe the Guidelines on
Electromagnetic Compatibility (EMC).
Please note that only shielded cables shorter than
3 meters (9.84 ft) should be used for the LPT, COM, USB, IEEE 1394, audio, video
and network interfaces with this notebook.

• Keep the notebook at least one meter (approximately three feet) away from high
frequency and magnetic interference sources (e.g., televisions, loudspeaker
cabinets, mobile telephones, etc.) in order to avoid malfunctions and/or loss of
data.

ISO 13406-2 Class II

Active matrix LCDs (TFT) with a resolution of 1440 x 900 pixel (WXGA), which are in
turn composed of three sub-pixels each (red, green, blue), contain about 3.9 million
addressable transistors. Because of this very high number of transistors and their extremely
complex production process occasionally defective or incorrectly addressed pixels or sub­pixels may occur.

There have been several attempts in the past to define the acceptable number of defective
pixels. But this can be difficult and varies widely between different manufacturers.

We, therefore, adhere to the clear and strict requirements of ISO 13406-2,
class II, for the warranty handling of all TFT display products. These requirements are
summarized below.

Within ISO-standard 13406-2 the general requirements regarding pixel defects are defined.
Pixel defects are classified into three failure types and four failure classes. Each individual
pixel is made up of three sub-pixels in the primary colours (red, green, blue).

Safety Handling Components Aid

Standards

Appendix

93

Pixel structure

Rows

Blue
Green
Red

Types of Pixel Failures:

• Type 1:
A constantly lit pixel (a bright, white spot), even though it is not addressed. A
white pixel is caused when all three sub-pixel are lit.

• Type 2:
A pixel that does not light up (dark, black spot), although it is addressed

• Type 3:
Abnormal or defective red, green or blue sub-pixels.
(E.g. constantly lit with half the brightness, one colour is not shining, blinking or
flickering, but not belonging to Type 1 or 2 Pixel Failures)

In addition: A cluster of type 3 (= 2 or more defective sub-pixels in an array of 5 x 5
pixel). A cluster is an array of 5 x 5 pixel (15 x 5 sub-pixel).

ISO 13406-2, Class II

Resolution Type 1 Type 2 Type 3 Cluster

Type 1,

Cluster
Type 3

Type 2

1024 x 768 2 2 4 0 2

1280 x 854 3 3 6 0 3

1280 x 1024 3 3 7 0 3

1400 x 1050 3 3 8 0 3

Example:

A 17” - SXGA-display consists of 1280 horizontal and 1024 vertical picture dots (pixel),
which amounts to a total of 1,31 million pixels. Based on one million pixels this translates
into a factor of about 1.31.
Class II type failure consequently allows for three defects each of type 1 and type 2 and 7
defects of type 3 and 3 cluster of type 3.

These cases are normally not covered by warranty.
If the number of failures exceeds the figures of any category mentioned above then this
may be covered by the warranty.

94

Standards
