Medion SAM 2000 user Manual

NOTES ON THIS MANUAL

Keep these instructions with your computer at all times. The
proper set up, use and care can help extend the life of your com­puter. In the event that you transfer ownership of this computer,
please provide these instructions to the new owner.

This manual is divided into sections to help you find the informa­tion you require. Along with the Table of Contents, an Index
has been provided to help you locate information.

In addition, many application programs include extensive help
functions. As a general rule, you can access help functions by
pressing F1 on the keyboard. These help functions are available to
you when you use the Microsoft Windows
the various application programs.

We strongly recommend that you read the Online Manual for your
Notebook, which can be found in the Start Menu.

 Important: Additional information about your

notebook can be found in the online help in the
Start Menu of your notebook. Click on:

Information about your notebook

This interactive manual is designed to provide additional informa­tion about your Notebook as well as useful links accessible via the
World Wide Web.

xp

Windows

invites you to a tour (notes on the task bar) to famil­iarize yourself with the operating system. We listed further useful
sources of information starting on page 54.

®

operating system or

AUDIENCE

These instructions are intended for both the novice and advanced
user. Regardless of the possible professional utilization, this Note­book is designed for day-to-day household use. The functions and
applications for use with this Notebook have been designed with
the entire family in mind.

DOCUMENT YOUR NOTEBOOK

It is important to document the details of your Notebook purchase
in the event you need warranty service. The serial number can be
found on the back of the Notebook:

Serial Number ......................................

Date of Purchase ......................................

Place of Purchase ......................................

QUALITY

We have selected the components in this computer for their high
level of functionality, ease of use, safety and reliability.

Through balanced hardware and software design we are able to
provide you with an innovative personal computer useful for ap­plications relating to both work and leisure.

We are pleased to welcome you as our newest customer.

Copyright© 2005. All rights reserved.
The appliance is supposed to be used in Great Britain.

®

Microsoft
U.S. and other countries. Pentium
of actual companies and products mentioned herein may be the trademarks of their respective
owners.

This product incorporates copyright protection technology that is protected by method claims
of certain U.S. patents and other intellectual property rights owned by Macrovision Corporation
and other rights owners. Use of this copyright protection technology must be authorised by
Macrovision Corporation, and is intended for home and other limited viewing uses only unless
otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is pro­hibited.

Information in this document is subject to change without notice.

, MS-DOS®, and Windows are registered trademarks of Microsoft Corporation in the

®

is a registered trademark of Intel Corporation. The names

ii

Table of Contents:

Notes on This Manual.................................................... i

SAFETY AND MAINTENANCE ........................................................ 1

Safety Instructions ......................................................... 3

Data Security.............................................................. 3

Operational Safety....................................................... 4

General Safety Information........................................... 4

Important Additional Safety instructions ......................... 5

CD-ROM/CD-RW/DVD/DVD-RW Drive safety.................... 6

TFT Display Safety....................................................... 6

Set-Up Location .......................................................... 7

Ambient Temperature .................................................. 7

Power Adapter ............................................................ 8

Cabling ...................................................................... 9

Modem ...................................................................... 9

Information about the regualtory compliance of

wireless Lan................................................................ 9

Touch Pad .................................................................. 9

Battery Operation...................................................... 10

VIEWS OF THE NOTEBOOK ........................................................ 11

Views ......................................................................... 13

Open Notebook ......................................................... 13

Front View................................................................ 13

Left Side .................................................................. 14

Right Side ................................................................ 14

Indicators................................................................. 15

Hotkeys ................................................................... 16

HANDLING ................................................................................ 17

Getting Started ............................................................ 19

The Windows® XP Desktop.......................................... 21

Power Supply............................................................... 23

On/Off Button ........................................................... 23

Power Adapter .......................................................... 24

Battery Operation...................................................... 25

Inserting the Battery....................................................... 25

Removing the battery...................................................... 25

Charging the Battery....................................................... 26

Battery Power ................................................................ 26

iii

Power Management ................................................... 28

Standby Mode................................................................ 28

Suspend (hibernate) Mode............................................... 28

Display ....................................................................... 29

Opening and Closing the Display.................................. 29

Screen Resolution...................................................... 29

Connecting an External Monitor ................................... 30

Data Entry .................................................................. 32

The Keyboard ........................................................... 32

Notebook-Specific Key Combinations................................. 32

Touch Pad ................................................................ 33

MAIN COMPONENTS .................................................................. 35

The Hard drive............................................................. 37

Important Directories................................................. 38

The Optical Drive.......................................................... 39

CD-RW/DVD-ROM Combo Drive................................... 39

Handling Discs ............................................................... 39

Loading a Disc ............................................................... 40

Removing a Disc............................................................. 41

Emergency Ejection of a Blocked Disc................................ 41

Playing Music CDs........................................................... 41

Playing DVD Movies ........................................................ 41

Writing CDs ................................................................... 42

The Sound Card ........................................................... 44

External Audio Ports .................................................. 44

Modem ....................................................................... 45

Modem Port .............................................................. 45

The Network................................................................ 46

What is a network?.................................................... 46

Fast Ethernet-Network .................................................... 46

Wireless LAN.................................................................. 49

Multimedia Card Reader ................................................ 50

Inserting Memory Cards ............................................. 50

Removing Memory Cards............................................ 50

The PC Card Slot .......................................................... 51

32-bit CardBus Port ................................................... 51

Use of PC Cards ........................................................ 51

Installing a PC Card ........................................................ 52

Removing a PC Card ....................................................... 52

iv

Connection Options ...................................................... 53

Universal Serial Bus (USB) Port ................................... 53

IEEE 1394 (FireWire®)................................................ 53

Software ..................................................................... 54

Getting to Know Windows XP ...................................... 54

Windows® XP Manual ...................................................... 54

Windows® XP Tour.......................................................... 54

Microsoft® Interactive Training ......................................... 54

Windows® XP Help and Support........................................ 54

Software Help ........................................................... 55

Device Drivers .......................................................... 55

Information about Your PC.......................................... 55

Digital Signatures ...................................................... 56

Windows Activation......................................................... 56

The BIOS Set-up-Program .......................................... 57

Running the BIOS Set-up................................................. 57

Navigating the BIOS Utility .............................................. 57

FIRST AID ................................................................................. 59

FAQ – Frequently Asked Questions.................................. 61

Data and System Security ............................................. 63

Data Security............................................................ 63

Maintenance Programs ............................................... 63

Password Reset Disk ....................................................... 63

Windows® Update...................................................... 64

Windows Update Information for Data Security ................... 65

System Recovery ......................................................... 66

Restoring Microsoft Windows XP .................................. 66

System Restore powered by Symantec ......................... 67

Limits of Restore Factory Settings (Restore option 3)................ 68

Performing the Restore.................................................... 68

Troubleshooting ........................................................... 70

Localize the Cause..................................................... 70

Check Cables and Connections ......................................... 70

The Power On Self Test (POST)......................................... 70

Errors And Possible Causes .............................................. 71

Additional Support..................................................... 72

Driver Support .......................................................... 72

v

Maintenance ................................................................ 73

Maintenance Instructions............................................ 73

Cleaning and Care ..................................................... 73

Care of the TFT Display .............................................. 73

Transporting the Notebook.......................................... 74

Recycling and Disposal ............................................... 74

Batteries and Proper Treatment................................... 75

Securing your Notebook ............................................. 76

Setting a User Password .................................................. 76

Using a safety lock ......................................................... 76

Upgrades and Repairs ................................................ 76

Notes for Service Engineers ............................................. 77

APPENDIX ................................................................................. 79

Standards ................................................................... 81

Electromagnetic Compatibility ..................................... 81

Electrical Safety ........................................................ 82

Ergonomics .............................................................. 82

Supplementary Information ........................................ 82

ISO 13406-2 Class II ................................................. 82

FCC Compliance Statement......................................... 84

Warranty .................................................................... 85

Liability limitations.......................................................... 86

Copying this manual ....................................................... 86

Index ......................................................................... 87

vi

CChhaapptteerr 11

Safety and Maintenance

Subject Page

Data Security....................................................3

Set-up Location.................................................7

Ambient Temperature ......................................7

Power Adapter ..................................................8

Modem ............................................................9

Touch Pad ........................................................9

Battery Operation............................................ 10

2

S

AAFFEETTYY AANNDD

S

M

AAIINNTTEENNAANNCCE

M

E

S

AAFFEETTYY

S

Please follow the instructions in this section for the safe operation
of your Notebook:

• DO NOT insert objects through the slots and open-

• DO NOT cover the slots and openings of the Note-

I

NNSSTTRRUUCCTTIIOONNS

I

• DO NOT open the case of the Notebook, the battery

or the power adaptor. When the case is open there
is a danger of severe electric shock.

ings of the Notebook. This may lead to electric
shock, electrical short-circuit or fire that will dam­age your Notebook.

• DO NOT allow small children to play unattended
with electrical equipment.

book. These openings are for ventilation purposes.
Covering these vents may lead to overheating.

S

• This Notebook is NOT designed for use within
industrial environments.

DATA SECURITY

The supplier does not assume liability for data loss or
damage to data storage units, and no claims can be
accepted for damages resulting from the loss of data
or consequential losses.

S

AAFFEETTYY

S

I

NNSSTTRRUUCCTTIIOONNS

I

S

3

OPERATIONAL SAFETY

It is important to follow all of the safety instructions in this man­ual to ensure the safety of you and your Notebook.

GENERAL SAFETY INFORMATION

If you find that:

• the power cord/power adapter is worn or damaged.

• liquid is spilled on the unit.

• the Notebook fails to work properly.

• the Notebook is dropped or the housing is damaged.

You should:

• shut-down your Notebook immediately.

• remove the power cord from the socket.

• contact Customer Service.

• do not restart unless you have contacted Customer Service.

How important is the information you will be storing on your
Notebook? You need to guard against the loss of your data by
making backup copies. You can backup your data onto CD, floppy
disk, or other media such as Zip drives. It depends upon how
much data you have. In this way, if something happens to the
hard drive in your Notebook, you have another copy of your data.

4

S

AAFFEETTYY AANNDD

S

M

AAIINNTTEENNAANNCCE

M

E

IMPORTANT ADDITIONAL SAFETY INSTRUCTIONS

When using any electronic equipment, basic safety precautions
should always be taken. Following the guidelines below can re­duce the risk of fire, electric shock and personal injury:

• Do not use this product near water (e.g., near a bathtub,
lavatory or kitchens sink, in a wet basement or near a
swimming pool).

• Avoid using a telephone/modem (other than a cordless
type) during an electrical storm. There is a remote risk of
electric shock from lightning.

• Do not use the telephone/modem to report a gas leak in
the vicinity of the leak.

Lithium batteries cannot handle intense pressure,
high temperatures or fire. Danger of explosion if
replaced incorrectly. Replace batteries with a com­patible type as recommended by the manufac­turer. Lithium batteries are hazardous waste and
require proper disposal. Contact our Service
Center for additional information on battery dis­posal.

S

S

AAFFEETTYY

I

NNSSTTRRUUCCTTIIOONNS

I

S

5

CD-ROM/CD-RW/DVD/DVD-RW DRIVE SAFETY

• CD-ROM-/CDRW-/DVD-drives are Laser Class 1
devices. These lasers must remain in their sealed
casing.

• Danger — Invisible laser radiation when open.
Avoid direct exposure to beam. This product is certi­fied by the manufacturer to comply with DHHS rules
21CFR, Chapter 1, Subchapter J, applicable at date
of manufacturer. Refer to optical drive labels for ad­ditional details.

• DO NOT remove the drive covers, as exposure to
the lasers may be harmful.

• DO NOT look directly into the laser, even when
wearing eye protection.

TFT DISPLAY SAFETY

• To avoid damage to the TFT Display, never open it
a full 120º. Do not forcibly open it.

• In order to avoid damage to the display, do not
touch it with your fingers or sharp objects.

• Never lift the Notebook by the TFT Display; doing
so could break the hinges.

6

• There is a risk of injury if the TFT display breaks.
Use protective gloves to pack up the broken
pieces and contact customer service to arrange for
proper disposal.

• It is important to thoroughly wash your hands after
handling a broken TFT display. There is a chance
that chemicals may have been released.

S

AAFFEETTYY AANNDD

S

M

AAIINNTTEENNAANNCCE

M

E

• Never place objects on top of the Note-
book that would exert any pressure on
the display. There is a danger that even
slight pressure may break the TFT dis­play.

SET-UP LOCATION

• Keep your Notebook and all connected peripherals away from
moisture, dust, heat and direct sunlight. Failure to do so can
lead to Notebook malfunction or damage.

• It is highly recommended you do not use the Notebook out-
doors.

• Operate the Notebook and all peripherals on a stable, balanced
and vibration-free surface.

• Do not leave the base of your Notebook on your lap or any
part of your body for a long period of time while the Notebook
is turned ON or is charging. The Notebook can become very
warm while it is turned on or charging and can cause discom­fort or injury from heat exposure.

AMBIENT TEMPERATURE

• The Notebook is most reliably operated at an ambient tem-
perature between +41° and +104° F and at a relative humid­ity between 30% and 70% (without condensation).

• When powered off, the Notebook can be stored at tempera-
tures between 32° and 140° F.

S

S

AAFFEETTYY

I

NNSSTTRRUUCCTTIIOONNS

I

S

7

POWER ADAPTER

• Do not open the power adapter housing. When the housing is
open there is a danger of severe electric shock. It contains no
user-serviceable parts.

• The electric outlet must be in the vicinity of the Notebook and
within reach of the power adapter cables. DO NOT stretch the
power cables tightly to reach an electric outlet.

• To disconnect your Notebook from the power source, or set the
Notebook to battery operation, remove the power cord from
the Notebook’s power socket.

• Only use the Notebook with a power adaptor (

FSP065-AAC) op-

erating at AC 115V~/60 Hz. In European countries use the
Notebook at AC 220-240V~/50 Hz.
For details on power consumption, please refer to the rating
plate on the rear of your Notebook. If you are unsure of the
type of power supply available at the point of use, ask your lo­cal power company.

• Use only the supplied power cord and power adapter.

• If using an extension cord, make certain that it meets your lo-

cal safety requirements. If in doubt, consult an electrician.

• To provide additional protection against electric shock, power
surges, lightning strikes, or other electrical damage to your
Notebook, we recommend the use of a surge protector.

8

S

AAFFEETTYY AANNDD

S

M

AAIINNTTEENNAANNCCE

M

E

CABLING

• Arrange cables so no one can walk on or trip over them.

• DO NOT place objects on any of the cables.

Caution – To reduce the risk of fire, use only No.
26 AWG or larger telecommunication cords (applies
to American Standards).

MODEM

• If your system has a modem, please make sure you connect it

to an analogue telephone line only. Connecting to a digital
PBX, a digital line designed for broadband services or ISDN, a
shared service line or a payphone will damage the modem or
the devices to which it is connected.

INFORMATION ABOUT THE REGUALTORY

COMPLIANCE OF WIRELESS

The following low power radio equipment, which has separately
been tested and approved according R&TTE guideline
(1999/5/EC), is bundled with this PC:

-Wireless Lan
These radio devices are marked individually with the CE mark.

LAN

TOUCH PAD

Light pressure with the tip of your finger is all that is required to
operate the touch pad. Because the touch pad is electrostatic sen­sitive, objects cannot be used in place of your fingers. Using a pen
or other object can damage the touch pad or cause the Notebook
to malfunction.

S

S

AAFFEETTYY

I

NNSSTTRRUUCCTTIIOONNS

I

S

9

BATTERY OPERATION

To extend the life and power of your battery and guarantee se­cure operation, the instructions below should be followed:

• Never expose the battery to direct sunlight or

heat for long periods.

• Do not dispose of the battery by fire as they may
explode. Check with local codes for possible special
disposal instructions.

• Do not open the battery housing; it contains no
user-serviceable parts.

• Disregarding these instructions will lead to damage
and under some circumstances may even cause the
battery to explode.

• Keep the battery away from electrically conductive materials,
chemical substances and cleaning agents.

• Only use the originally supplied power adapter to charge the
battery.

• Fully discharge the battery before recharging it.

• Replace the battery only with the same type or an equivalent

type recommended by the manufacturer.

• Charge the battery only until the battery charging light goes
out. Also, refer to the instructions under “Charging the
Battery” on page 26 for instructions on checking the battery
level.

• Only change the battery when the unit is switched off.

• Batteries are classified as special waste and should always

be disposed of properly. Contact Customer Service for more
details.

• Keep batteries away from children at all times.

• Use only the batteries and power adapter/cord indicated in this

manual.

10

S

AAFFEETTYY AANNDD

S

M

AAIINNTTEENNAANNCCE

M

E

CChhaapptteerr 22

Views of the Notebook

Subject Page

Open Notebook ...............................................13

Front view ...................................................... 13

Left Side ........................................................ 13

Right Side ...................................................... 14

Power and Status Indicators .............................15

Hotkeys ......................................................... 16

12

V

IIEEWWSS OOFF TTHHEE

V

N

OOTTEEBBOOOOK

N

K

V

V

S

IIEEWWS

OPEN NOTEBOOK

5

6

1 - TFT display (Ö p. 29)

2 - Hotkeys (Ö p. 16)

3 - Power ON/OFF (Ö p. 23)

4 - Keyboard (Ö p. 32)

5 - Touch pad (Ö p. 33)

6 - Status LED Indicators (Ö p. 15)

2

1

3

4

FRONT VIEW

7 8 9 10

7 - IEEE 1394 (FireWire®) (Ö p. 53)

8 - Microphone In (Ö p. 44)

9 - Audio Out (Ö p. 44)

10 - Display catch (Ö p. 29)

V

S

IIEEWWS

V

13

12 13 14 15 16 15 15 17 18 19 20

LEFT SIDE

11

11 - Optical Drive (Ö p. 39)

12 - Disc eject button (Ö p. 41)

13 - Disc emergency eject

14 - PC card slot PCMCIA, type II (Ö p. 51)

15 - USB port (Ö p. 53)

16 - Multimedia card reader (Ö p. 50)

RIGHT SIDE

15 - USB port (Ö p. 53)

17 - Modem port (RJ-11) (Ö p. 45)

18 - LAN port (RJ-45) (Ö p. 46)

19 - External monitor (VGA) (Ö p. 30)

20 - Power socket (Ö p. 23)

14

V

IIEEWWSS OOFF TTHHEE

V

N

OOTTEEBBOOOOK

N

K

INDICATORS

LED's indicate the power and operating system states of the
Notebook. The meaning of each LED is:

NUM LOCK
This LED lights when NUM-Lock has been activated. It
sets the keyboard so that numbers are assigned to
certain characters, simplifying numerical data input.

CAPITAL LOCK
This LED lights when CAPS-Lock has been activated.

This sets the keyboard to capital letters.

SCROLL LOCK



This LED indicates that the Scroll Lock key on the key­board is activated. The Scroll Lock key has different
functions depending on the software you are using.

ACCESS LED
This LED lights when the Notebook is accessing the

hard disk.

POWER LED
This LED lights when operation (battery / power).

BATTERY LED
This LED lights when the battery is charging. When the
battery is charged the light goes out.

WIRELESS LAN
Display for wireless data exchange. If the display

lights
steadily the wireless LAN function is enabled (optional
feature).

V

S

IIEEWWS

V

15

HOTKEYS

Launches the E-Mail Program.

WWW

Launches the Internet Browser.

To enable or disable the wireless LAN.

This button opens the search function in the
explorer.

16

V

IIEEWWSS OOFF TTHHEE

V

N

OOTTEEBBOOOOK

N

K

CChhaapptteerr 33

Handling

Subject Page

Getting started................................................19

On/Off Button .................................................23

Power Adapter ................................................ 24

Battery Operation............................................ 25

Power Management ......................................... 28

Open and Closing the Display............................ 29

Screen Resolution............................................ 29

Connecting an External Monitor .........................30

Keyboard ....................................................... 32

Touchpad .......................................................33

18

H

AANNDDLLIINNG

H

G

G

EETTTTIINNGG

G

Before you get started using your notebook, first take a few mo­ments to read the important section on Safety.

This Notebook comes with software fully pre-installed. You do
not have to install any of the CDs supplied. However, with many
programs (e.g., telephone CDs or encyclopaedias) it is necessary
to insert the corresponding CD to access the data that is stored on
it. The software will prompt you to do this when necessary.

S

TTAARRTTEED

S

D

Step 1

Before starting the Notebook please insert the battery. For further
information read the section titled “Power Supply” starting on
page 23. Open the display

using the On/Off switch

If the battery level is insufficient, connect the power
adapter.

Note: Make sure there is no bootable CD (e.g., the
Recovery CD) in the CD-ROM drive. Such disks will
prevent the operating system from loading off the
hard drive.

(Ö p. 29) and switch on the Notebook

(Ö p. 13).

Your operating system is finished loading when a welcome screen
is shown on your display.

Step 2

The greeting procedure will guide you through a series of dialogue
boxes. The information in each dialogue box will explain the steps
that need to be taken.

Should you have any questions just click on

G

EETTTTIINNGG

G

S

TTAARRTTEED

S

D

.

19

Enter Personal Details

In one of the initial start-up dialog boxes a request will appear on
the screen for you to enter your personal details. Please enter the
requested information in the white input fields. You can select the
fields by clicking on them with the mouse. When you press Enter,
or click on the Continue button you progress to the next window.

License Agreement

The greeting procedure also displays the license agreement.
Please read this carefully. It contains important legal information
on the use of your software. In order to see the full text, use the
mouse and the scroll bar on the right side of the screen to move
downwards until you have reached the end of the document. You
accept the agreement by clicking on the “I accept the agree-
ment” option field. Only by doing so will you be entitled to use
the product under lawful terms and conditions and be entitled to
open the sealed Windows

Step 3

After the login procedure the Windows
screen. This can be adjusted so that the screen of your computer
looks different.

®

manual.

®

desktop appears on your

20

H

AANNDDLLIINNG

H

G

THE WINDOWS

After the login procedure the Windows® XP desktop appears on
your screen. (Your desktop might not look exactly like the one
shown here.)

®

XP DESKTOP

t

u

v

n o p q r s

1. Start Button

Clicking the Start button brings up a menu where you can ac­cess help, software programs, files, and settings. For more in­formation, click Windows

2. Program Bar

The most commonly used software programs are listed here.

®

XP Tour on the Start menu.

G

EETTTTIINNGG

G

S

TTAARRTTEED

S

D

21

3. All Programs

All of the software programs installed on your Notebook are
ordinarily listed here. Click All Programs to reveal an exten­sive menu.

4. Information about your PC

Click this button to receive important information about your
Notebook as well as valuable hints and additional assistance.

5. Turn Off Computer

®

Click this button to shut down Windows

XP and the Note-

book.

6. Task Bar

Here you receive information and status reports about Win-

®

dows

XP and which programs are running.

7. Desktop Icons

Desktop icons link to their respective programs. To start a
program, double-click its desktop icon.

8. Logged in User

This tells you which user is logged in to your Notebook.

9. Control Panel

You can use the icons in Control Panel to change the appear­ance and functionality of Windows
options for configuring your Notebook.

22

H

AANNDDLLIINNG

H

®

XP. These icons represent

G

P

OOWWEERR

P

S

UUPPPPLLY

S

Y

ON/OFF BUTTON

The On/Off button (3) is used to power up/down the Notebook. Press­ing the button briefly will turn off your computer using the operating sys­tem.

This is the same as clicking Start then Turn Off Computer. If the but­ton is held down for longer than 4 seconds, it will force the notebook to
power down without going through the operating system shut down
process. This may be useful if your computer has crashed or stalled.

WARNING! Do not switch off your Notebook while the
hard disk or the optical drive is running and the corre-

sponding media activity LEDs are lit. Otherwise data
may be lost. To protect the hard disk you should always
wait for 20 seconds after powering down the Notebook be­fore powering it up again.

P

P

OOWWEERR

S

S

UUPPPPLLY

Y

23

POWER ADAPTER

Your Notebook is supplied with a universal AC power adapter,
which automatically adjusts to the available power source. The
following levels are supported: AC 100-240V~/ 50-60 Hz.
Please follow the power supply safety instructions found on
page 8.

The power adapter is connected via a power cord to an AC outlet.
The DC power lead from the power adapter is connected to the
right side of the Notebook (20).

The adapter provides the Notebook with power and also charges
the battery. The power supply indicators of the Notebook
(Ö p. 15) provide details on the operating state. The battery is
also being charged when you are working on your Notebook with
the power adapter.

The power adapter is still live if the Notebook is not connected
with it. You should therefore unplug the power adapter from the
outlet if it is not connected to the Notebook.

24

WARNING! Use only the power adapter and power
cord supplied with your Notebook.

H

AANNDDLLIINNG

H

G

BATTERY OPERATION

In order to extend the life and power of your battery, and to guar­antee reliable operation, it is essential that the safety instructions
on page 10 are followed.

INSERTING THE BATTERY

Slide the battery, contacts first, into the battery compartment.

REMOVING THE BATTERY

Slide the battery locks to remove the battery.

WARNING! Do not remove the battery while the

Notebook is running on battery power. You increase
the possibility of losing data.

P

P

OOWWEERR

S

S

UUPPPPLLY

Y

25

CHARGING THE BATTERY

The battery is charged via the power adapter. If the power
adapter is connected, it charges the battery automatically,
whether the Notebook is turned on or not.

When the Notebook is switched off, full charging takes a few
hours. If the Notebook is switched on, the charging process takes
a significantly shorter time. However, it is recommended that
from time to time you discharge the battery completely and re­charge it afterwards with the Notebook switched off. You can dis­charge the battery without losing data, if you turn your notebook
on without using any application and no power adapter. As soon
as the battery is empty your notebook will enter the hibernate
mode. We recommend doing this procedure every time you think
the battery power is losing efficiency.

BATTERY POWER

A fully charged Li-Ion battery will provide power for some hours of
operation. However, the battery life will vary according to how the
power saving functions are set, the way you work, the size of the
main memory and the display type.

When working in Windows an audible warning alert will sound as
soon as the battery level drops below a set minimum value. When
this happens, the processing power is reduced in order to save
power.

NOTE: Battery warning signals and "Low­Battery" mode will be heard immediately when
the power pack is first connected.

NOTE: For full battery performance please
charge and discharge the new battery two to
three times consecutively!

26

H

AANNDDLLIINNG

H

G

CHECKING THE BATTERY LEVEL

In order to check the current level of the battery, move the cursor
over the power symbol in the taskbar.

When in battery mode, a battery symbol is displayed and when
the power adapter is in use a power connector is displayed. If the
battery is being charged the power connector has a lightning
symbol superimposed over it. Further information on power set­tings can be obtained by double clicking on the symbol.

NOTE: If you ignore the warning signal when the battery
level is low, your Notebook goes into suspend mode. (De­pending on the BIOS/OS setting this will be Save-to-Disk or
Save-to-RAM).

WARNING! If the battery is empty, your data will not be
retained for long in Standby/Save-to-RAM mode.

WARNING! Never remove the battery while the Notebook is
switched on or if the Notebook has not yet gone into sus­pend mode, as this may lead to loss of data.

P

P

OOWWEERR

S

S

UUPPPPLLY

Y

27

POWER MANAGEMENT

Your Notebook offers automatic and modifiable power saving
functions that you can use to maximize battery life and reduce
overall operating costs. The power saving modes are known as
standby mode and suspend (hibernate) mode.

STANDBY MODE

When in standby mode, the contents of the RAM of your Notebook
are preserved while practically all other components of your Note­book are shut down, reducing your power consumption to a mini­mum. By pressing any key on the keypad, you can bring your
Notebook back to the fully operational state. You will restart at
precisely the line in which you were working prior to the interrup­tion. The computer takes less time to go into and come out of
standby mode, but uses more power than suspend (hibernate)
mode.

SUSPEND (HIBERNATE) MODE

The hibernate mode is an alternative to a complete shutdown of
the Notebook. In this mode all data from RAM (system and
graphic data) are copied to the hard disk as a file. As soon as the
data has been safely saved, the Notebook powers down. When
the Notebook is switched on again, this file is written back to RAM
by the BIOS. In a few moments the Notebook is in the exact state
as when it was last used. If while working on a document the
Notebook is closed (assuming the correct ACPI setting), the Note­book saves the data in RAM for you automatically. You will restart
at precisely the line in which you were working prior to the inter­ruption. The computer uses no power while it is in suspend (hi­bernate) mode, but it takes a little longer for the computer to go
into and come out of hibernation compared to standby.

28

H

AANNDDLLIINNG

H

G

D

IISSPPLLAAY

D

Unlike a normal monitor, the TFT display does not produce either
radiation or flicker.

Y

OPENING AND CLOSING THE DISPLAY

Display catches (10) keep the display closed when the Notebook
is not in use.

To open, use your thumbs to push the bar then lift the display
with your thumbs and index finger and position it as desired.

The opening and closing of the display can be assigned various
functions via the Power management feature. For example, the
Notebook can be programmed to power down when the display is
closed.

WARNING! The display should not be opened fully
to 120°. Do not try to forcibly open it.

SCREEN RESOLUTION

The integral screen has a native resolution of 1280 x 800 pixels.
Using a higher resolution can lead to distortion of the display,
especially with text. Using a lower resolution may cause the
display to use only a portion of the screen area.

D

D

IISSPPLLAAY

Y

29

CONNECTING AN EXTERNAL MONITOR

The Notebook has a VGA port for connecting an external monitor

(19) . To connect and configure an external monitor:

1. Shut down your notebook.

2. Connect the video signal cable of the external monitor to
the VGA port of the Notebook

3. Connect the external monitor to the electrical socket,
power it up and start your notebook.

There are two options for setting up an external monitor:

1. Clone your Desktop

Press <Fn> + <F2> to activate the external monitor.
The notebook display will be switched off. Adjust the dis­play settings following the external monitor specification.
Press <Fn> + <F2> once more and both displays are
switched on.
Press <Fn> + <F2> again to deactivate the external
monitor. The notebook display will be switched on.

2. Extend your Desktop

This option does not support the key combination <Fn>
+ <F2>.

(19) .

30

Right click anywhere on your desktop and select “Proper-
ties” to start the "Display Properties" program.

• Select the "Settings" tab and left click on the second

display n.

• Check the option “extend my Windows desktop

onto this monitor” o and press “ok”.

• To deactivate the extension uncheck the option “ex-

tend my Windows desktop onto this monitor”.

H

AANNDDLLIINNG

H

G

n

o

You can change the resolution and colour depth for either display
in this screen. However, you may have to decrease the depth of
colour if you increase the resolution since the video memory has a
limited capacity.

D

D

IISSPPLLAAY

Y

31

D

D

AATTAA

E

E

Y

NNTTRRY

THE KEYBOARD

By dual assignment of certain keys you have the same range of
functions available to you as with a normal Windows keyboard.
Some functions are input using the Fn key, which is normal on
notebook computers.

NOTEBOOK-SPECIFIC KEY COMBINATIONS

Toggles the display screen between LCD,

+

+

external display and simultaneous display.

Enhances screen brightness.

32

+

+

+

+

+

Reduces screen brightness.

Decreases the volume.

Increases the volume

Switches the loudspeakers on / off.

Power saving functions. This key combina­tion is set to power down by default. To
adjust this key to your own needs go to dis­play properties in power saving.

H

AANNDDLLIINNG

H

G

TOUCH PAD

The touch pad’s primary function is to move the cursor around or
select items displayed on the screen with the use of your fingertip
instead of a mouse. It is positioned in front of the keyboard
The pointer follows the direction which is specified by moving your
finger or thumb over the touch pad.

DO NOT use a ball-point pen or other object on the touch pad, as
this could damage or cause a malfunction of your touch pad.

Below the touch pad are the left and right mouse buttons which
can be used as on a normal mouse. You can also perform a direct
click or double click using the touch pad by tapping the surface
briefly once or twice.

In the Windows Control Panel you will find a number of useful
settings that will make using the touch pad easier. If the Control
Panel is in category view, click Printers and Other Hardware
and then Mouse. In classic view, double-click Mouse.

(5).

D

Y

E

NNTTRRY

E

AATTAA

D

33

34

H

AANNDDLLIINNG

H

G

CChhaapptteerr 44

Main Components

Subject Page

Hard Drive .....................................................37

Optical Drive................................................... 39

Sound Card .................................................... 44

Modem ..........................................................45

Network......................................................... 46

Multimedia Card Reader ................................... 50

PC Card Slot ...................................................51

Connection Options.......................................... 53

Software ........................................................54

36

M

M

AAIINN

C

C

OOMMPPOONNEENNTTS

S

T

T

The hard drive is the main storage medium combining large stor­age capacity and rapid data access.

The Windows operating system cannot use the full capacity of the
hard drive, which means that there will be a difference between
the capacity that the BIOS displays and what the operating sys­tem displays.

The hard drive contains the operating system of the computer,
other application programs and backup files. These programs and
files are pre-installed on your Notebook, so you may note that
some of the space on your hard drive is already taken.

Whenever the computer is accessing the hard disk, the corre-

sponding LED illuminates

If you are looking for a file on the hard drive and you know the
name, go to Search on the Start menu to find the file. Following is
some general information on where you might find some common
files.

Usually your hard drive is divided into several partitions, as shown
below. The partitions of your hard drive may vary from what is
shown here.

H

HHEE

AARRDD DDRRIIVVE

H

WARNING! Never switch off the computer
while the busy indicator is lit since this may
result in loss of data.

Local Disk C: Windows XP

BOOT D: Drivers for internal PC components

Recover E: Restore software

E

(Ö p. 15).

Software programs
Your documents

Installation files for software that came with
your PC

T

H

HHEE

AARRDD DDRRIIVVE

T

H

E

37

IMPORTANT DIRECTORIES

The most important directories preinstalled on your Notebook are
shown below. These directories may vary from what is shown
here.

Caution: Don't delete files unless you know what they are. Win­dows XP might require these files for your computer to operate
correctly. Also, do not alter or resize the partitions – this will
make it difficult to restore your Notebook to the factory settings.

C:\ This is the main hard disk drive partition for your Notebook.

It is where your program files, settings, and documents are
stored, as well as files necessary for running Windows XP.

C:\Program Files Includes files belonging to software pro-

grams.

C:\Windows The main directory for Windows XP.

C:\Documents and Settings Includes the settings and docu-

ments for all users.

D:\ Includes files for restoring hardware components and soft-

ware programs.

D:\Driver Drivers for internal Notebook components.

D:\Tools Includes installation files for software that came with

your Notebook.

E:\ Includes files for restoring the entire Notebook to working

order.

E:\Recover Includes the files needed to perform a system re-

store.

38

M

M

AAIINN

C

C

OOMMPPOONNEENNTTS

S

T

T

HHEE

O

PPTTIICCAALL

O

D

D

E

RRIIVVE

CD-RW/DVD-ROM COMBO DRIVE

Your Notebook has a CD-RW/DVD-ROM combo drive. This drive
can play everything that a DVD-ROM drive can play: DVD movies,
music CDs, and data DVDs and CDs. It can also run software pro­grams from CDs and DVDs. In addition, this drive can write data
and music CDs and copy CDs. It writes to CD-R or CD-RW.

HANDLING DISCS

To maintain the life of CD and DVD discs, observe these guide­lines.

• Avoid radiation by direct sunlight (UVA/UVB).

• Avoid scratches and damage to the disc surface.

• Avoid extreme temperatures.

• Do not attach labels or paper to DVD discs.

• Do not use record-cleaning or anti-static agents to clean

your discs.

We also recommend that you avoid specially shaped discs such as
hearts or polygons, or discs that are not standard size. Do not use
warped or cracked discs as they may cause damage to your drive.

T

O

HHEE

T

O

PPTTIICCAALL

E

D

RRIIVVE

D

39

LOADING A DISC

 Tip: Do not place protective foils or other stickers

on your CD’s. To avoid damage to your drive, do
not use deformed of damaged CD’s. Attention: Do
not use scratched or dirty disks, discs with pieces
broken off or disks of poor quality. Because of the
high speeds in the drive the disks might break and
damage your data as well as your drive. Examine
the disks before you enter them. If damage or dirt
is visible, you should not use them. Damage caused
by faulty media is excluded from warranty and their
repair must be charged.

1. Press the eject button on the front of the drive to open the tray.

2. Place the disc on the tray so that it lays flat with the label fac­ing upward.

3. Gently push the tray in to close it.

Many discs automatically start when they are loaded and launch a
playback software program. In some cases you might need to
start a program (for example, a DVD player program).

40

M

M

AAIINN

C

C

OOMMPPOONNEENNTTS

S

REMOVING A DISC

Press the eject button on the front of the drive to open the tray.

WARNING! While the Notebook is accessing the
CD-ROM drive the media activity indicator is lit. Do
not try to remove the CD from the drive while this
LED is lit.

EMERGENCY EJECTION OF A BLOCKED DISC

If the tray fails to open automatically, then the tray can be
opened manually provided there is an opening for emergency
ejection

(13).

Restart your notebook and if the tray is still locked proceed as
follows:

1. Shut down Windows and switch off your notebook.

2. Insert a long thin object (like a straightened paper clip) into
the emergency ejection opening

(13) until you feel resistance.

3. Press lightly and the tray will open.

4. Remove the disc and restart the notebook.

PLAYING MUSIC CDS

Windows Media Player and MusicMatch Jukebox can be used to
play music CDs. Please refer to the documentation for these pro­grams to decide which program you would like to use.

PLAYING DVD MOVIES

To play DVD movies on your Notebook, you need a DVD playback
software program, such as CyberLink’s award-winning PowerDVD.
To play DVD movies using this software, insert a movie DVD into
the DVD-ROM or DVD-RW drive, then click Start, then All Pro-
grams and select PowerDVD.

In spite of the high storage capability of the DVD, the data must
be extremely compressed in order for a complete feature film to
be stored. This extreme compression combined with exceptional
picture quality is provided by the MPEG2 image coding method on
the DVD. This places high demands on the Notebook’s processor,
so when playing a DVD please close all other applications. To in­crease Notebook performance, you may also wish to purchase a

T

O

HHEE

T

O

PPTTIICCAALL

E

D

RRIIVVE

D

41

plug-in MPEG2 decoder card, which has its own decompression
processor and will thus free the Notebook’s processor.

NOTE: The decoding software included with your Note­book may be changed for regional DVD decoding up to
five times, after which the drive will only play DVD
movies for the region setting last entered.

WRITING CDS

You can use your CD-RW/DVD-ROM combo drive to write ("burn")
data and music CDs.

A data CD is a compact disc (CD) used to store PC data (for ex­ample, files and folders you have on your hard disk).

A music, or audio, CD is a compact disc (CD) used to record music
that you can play on your home or car stereo CD player. Using a
CD-R instead of a CD-RW for music CDs will help ensure a greater
level of compatibility with conventional CD-players.

There are several different options for burning CDs. The first step
for using any of these options is to insert a blank recordable CD
into your combo drive.

Nero Burning ROM can create different types of audio, video, and
data CDs quickly and easily. Click Start, then All Programs, then
Nero, then Nero OEM to access Nero Burning ROM. Follow the
step-by-step instructions given by the software wizard to create a
CD.

Windows XP includes functionality for quickly and easily creating
data CDs:

1. Select the files or folders you would like to write to your CD.
To select more than one file, hold down the CTRL key while
you click the files you want.

2. In the File and Folder Tasks menu on the left (Picture Tasks if
the files are located in My Pictures), click Copy this file, Copy
this folder, or Copy the selected items. If you do not see
the File and Folder Tasks menu, select Tools on the main
menu, then Folder Options. Under Tasks on the General tab,
select Show common tasks in folders.

42

M

M

AAIINN

C

C

OOMMPPOONNEENNTTS

S

3. In the Copy Items dialog box, click the CD-RW, and then click
Copy.

4. Double-click My Computer, then the CD-RW. Windows dis­plays a temporary area where the files are held before they
are copied to the CD. Verify that the files and folders that you
intend to copy to the CD appear under Files Ready to be Writ­ten to the CD.

5. Under CD Writing Tasks, click Write these files to CD. Win­dows displays the CD Writing Wizard. Follow the instructions in
the wizard.

Music jukebox and media player programs (such as Windows Me­dia Player) often offer alternatives for burning audio CDs. Refer to
the help within the program for more information.

You can also purchase third-party CD burning software for writing
files to a CD-R or CD-RW disc.
More information about copying CDs reliably can be found in the
“Technical Reference” section of this manual under “CD Facts.”

WARNING! Unless you own the copyright or the

permission of the owner of the copyright, unapproved
copying of copyrighted CDs or DVDs violates national
and/or international laws and can result in serious
punishment.

T

O

HHEE

T

O

PPTTIICCAALL

E

D

RRIIVVE

D

43

T

T

Your Notebook has an integrated stereo sound card (on-board)
with 16-bit and 3D spatial sound effects (3D). The sound card is
compatible with the industry standard Sound Blaster and Micro-
soft Sound System Version 2.0. This guarantees optimal sup­port for all popular programs and games.

If you wish to alter the base volume, click on the loudspeaker
symbol in the task bar. A double click opens the sound mixer.

By means of the key combinations
sibility to regulate the volume.

By using the keys Fn+F8 you increase the volume and by using
Fn+F7 you decrease it.

HHEE

S

OOUUNNDD

S

C

C

AARRDD

(Ö p. 32) you still have the pos-

EXTERNAL AUDIO PORTS

Microphone in

(8)

Audio out

(9)

Your Notebook has a loudspeaker, so you can always playback
sounds without additional equipment. The connection of a Hi-Fi
system increases the sound quality significantly.

 For recording via an external microphone.

 For sound reproduction via external stereo

equipment such as loudspeakers (active)
or headphones.

44

M

C

AAIINN

M

OOMMPPOONNEENNTTS

C

S

M

M

The modem is fitted with an RJ-11 interface, into which a stan­dard telephone lead can be plugged.

M

OODDEEM

WARNING! Use only with an analogue telephone
line. The modem cannot withstand the voltage levels
of digital telephone systems such PBX or lines such
as ISDN or Broadband services.

MODEM PORT

Insert one end of the RJ11-connection (telephone plug connector)
into the modem/network interface
logue telephone socket that is easily accessible.

NOTE: Do not place the Notebook in Suspend (or
Sleep) mode if you are connected to your Internet
provider, since this will cause the modem connection
to be lost.

(17) and the other into an ana-

M

M

OODDEEM

M

45

T

T

HHEE

N

EETTWWOORRK

N

K

WHAT IS A NETWORK?

A network means connecting your Notebook to one or several
other computers. Users can transfer data between computers and
share resources such as printers, modems and hard disk drives.

Here are some practical examples:

• You can exchange E-mail and manage appointments in an of­fice.

• Users can share a printer in a network and save their data on
a central server.

• Users can share one modem among computers for Internet
access.

• Two or more computers can be connected to play network
games or share data.

FAST ETHERNET-NETWORK

Connect one end to the RJ45 connection (Western plug) at the
network interface of your Notebook
other PC or a hub/switch.

(Ö p. 14) and the other to an-

Your PC has a Fast Ethernet Network connection. You can use this
to connect to a network.

The Windows XP Help and Support Centre offer extensive infor­mation about networking your PC. You can access this information
by clicking on Start, then Help.

46

M

M

AAIINN

C

C

OOMMPPOONNEENNTTS

S

WHAT DO YOU NEED FOR NETWORKING?

Some requirements have to be fulfilled to successfully network
computers:

1. The Notebook must have a network card that supports the
same network technology as the other computers on the net­work. Unless otherwise quoted, your Notebook will support
the current Fast Ethernet (10/100 Mbit) standard.

2. The network cards must be connected. You need a Shielded
Twisted Pair-cable (CAT5) that has an RJ-45-connector.

- If you want to directly connect two PCs you need a Cross-

Link cable.

- If more PCs must be connected you need a supplementary

distributor (Hub or Switch) and a Patch cable.

3. All connected PCs need a network operating system. Win­dows

®

can act as a network operating system.

4. All networked PCs must speak the same “language” to under­stand one another. They use protocols for this purpose. The
setting of protocols, therefore, must be the same for all net­worked PCs.

T

N

HHEE

T

N

EETTWWOORRK

K

47

TROUBLESHOOTING WITHIN THE NETWORK

Why does an error message appear when I click on the
network environment?

The computer name must be unique on the net­work and may not be the same as the task group.

It appears that the network boards are unable to com­municate. What might be the problem?

Maybe one of the used network boards works with a
different speed (e. g. 10 instead 100 Mbit) and
your network computer is unable to recognize this.
If necessary, set the network driver to the compati­ble speed.

If two PCs should be linked you require a cross-

link cable, otherwise use a patch cable.

In addition, check the protocols and the configu-

ration.

The data transmission is incorrect or very slow. What
might be the problem?

Maybe you have the wrong cable (UTP / CAT3 or
lower) or the problem is the proximity of a power
cord or another source of interference.

For further hints on troubleshooting search for “network errors” in
Windows Help and Support.

48

M

M

AAIINN

C

C

OOMMPPOONNEENNTTS

S

WIRELESS LAN

Wireless LAN is an optional feature. This function allows you to
create a wireless network link with an access point or directly with
another wireless-enabled PC.
The Wireless LAN function can be activated or deactivated via the

hotkey

. The relevant display for WLAN (Ö p. 15) will light

up.

 ATTENTION: Make sure the Wireless LAN option is

switched OFF in any environment where it might in­terfere with critical and sensitive devices, e.g., on
aircraft, in hospitals and other medical centres, etc.

CONDITIONS

An access point is a wireless transmitter that communicates with
your notebook and controls access to the network connection
(e.g., a home network or a broadband connection such as DSL).

Wireless access points are often found in offices, airports, univer­sities or Internet cafés. They offer access to networks or to the
Internet. Access authorizations are normally needed. A fee may
be required to use a public access point.

To set up a wireless network to share Internet access, files, and
printers at home, you will need an access point, a router, and a
broadband (DSL or cable) modem. Some access points can also
serve as a router and/or a broadband modem. Check with your
retailer or Internet Service Provider to find the best solution for
your needs.

A link to another computer with wireless LAN functionality can
also be created without an access point. This will allow you to
share files, but you will need an access point and a router to
share an Internet connection.

The wireless network link works according to standard IEEE

802.11g which is also compatible with the IEEE 802.11b stan­dard. The standard 802.11a is not supported.

If encrypted transmission us used, this must operate according to
the same principle on all devices. Encryption is a method of
protecting the network from unauthorized access.

The transmission speed (max. 54 Mbps) can vary according to the
distance and loading of the partner.

T

N

HHEE

T

N

EETTWWOORRK

K

49

M

UULLTTIIMMEEDDIIAA

M

Memory cards are media that are being used for a variety of pur­poses, especially in digital photography. They are increasingly
replacing the floppy disk. The form and capacity of a memory card
can vary according to the manufacturer.

Your notebook supports the following formats:

• MMC (MultiMediaCard)

• SD (Secure Digital)

• Memory Stick / Memory Stick Pro

When inserting memory cards, ensure that the contacts are facing
the right way. See table below. Incorrect insertion of a card can
cause damage to the card reader and/or the card.

Slot Card type Contacts

Multimedia
Card Reader
(16)

C

C

AARRDD

SD (Secure Digital)
MMC (MultiMediaCard)
Memory Stick
Memory Stick Pro

R

EEAADDEER

R

R

pointing down
pointing down
pointing down
pointing down

INSERTING MEMORY CARDS

 Memory cards can only be installed in one direc-

tion. Refer to the instructions on the previous page.

 Remove the dummy card from the PCMCIA Slot be-

fore installation. Replace the card to protect con­tacts against dirt if the Slot is not used.

Push the memory card into the slot until it clicks into place.

REMOVING MEMORY CARDS

To remove the SD/MMC-cards or memory sticks press the card
further into the slot. Then pull out and remove the card.

50

M

M

AAIINN

C

C

OOMMPPOONNEENNTTS

S

T

HHEE

T

The PC card slot (14) can be used to operate credit card-sized PC
cards. Most PC cards are communications or interface devices
such as ISDN-, Faxmodem-, Network- or SCSI-adapters.

Some PC cards contain memory chips or hard disks for data stor­age. If you use such cards with your Notebook, the system as­signs the card a drive name, so that you may access the re­sources. The PC card drive in your Notebook supports PCMCIA 2.1

- (Type II), and CardBus (Type I) cards. Cards of Type I are 3.3
mm, and Type II 5 mm thick.

C

PPC

C

C

AARRDD

S

S

LLOOTT

32-BIT CARDBUS PORT

CardBus cards have a 32-bit architecture with which high data
transfer speeds of up to 132 MB can be achieved, similar to PCI.
In this way your Notebook can also support data intensive devices
such as 100Mbps Fast Ethernet, Fast SCSI peripherals and video
conferencing devices.

The CardBus port is backward compatible with 16-bit PC cards
with a 5V power supply, though the CardBus only requires a
power-saving 3.3V.

USE OF PC CARDS

In order to run a PC card, special software is needed (drivers,
etc.). The card manufacturer usually supplies this software. Sup­port for the card port is a component of Windows
represents the optimum in operational smoothness. You should
consider this point when choosing between alternative operating
systems.

T

C

C

HHEE

PPC

C

AARRDD

T

S

S

LLOOT

T

®

and at present

51

INSTALLING A PC CARD

Follow the PC card installation instructions that are given for use
under Windows

 Remove the dummy card from the PCMCIA Slot be-

®

and have the necessary driver software ready.

fore installation. Replace the card to protect contacts
against dirt if the slot is not used.

Once you have started Windows®, slip the card carefully into the
slot provided.

When the card is fully inserted two audible signals will be heard,
provided it has been correctly recognized and successfully config­ured.

If only one signal is heard, this signifies a problem with the card
recognition. In this case, follow the instructions that accompany
your new PC card.

REMOVING A PC CARD

To remove your PC card:

1. Press the eject button next to the slot.

52

 Attention! The Eject Button should be pressed in

during transportation, because the danger will arise
that the button will break off otherwise.

M

M

AAIINN

C

C

OOMMPPOONNEENNTTS

S

C

OONNNNEECCTTIIOONN

C

The Notebook has a number of input and output interfaces for
connection of peripheral devices such as a printer, scanner, key­board, and so on. This section presents the individual ports. For
further information, refer to page 13, where the positions of the
respective ports are described.

O

PPTTIIOONNS

O

S

UNIVERSAL SERIAL BUS (USB) PORT

USB ports provide an easy way to connect many peripheral de­vices to your PC (15). You can use any USB device with any USB
port. 1 USB port is located at the left side and 2 USB ports are
located at the right side of the Notebook for your convenience.
Some USB devices require that you reinstall software drivers
when you connect the device to a different USB port than the one
originally used. This can be avoided by always using the device
with the same USB port. Devices connected directly to the USB
bus should not draw more than 500 mA. Should the devices need
more power than this, it will be necessary to provide a powered
hub. The data transfer speed is 1.5 Mbit or 12 Mbit, depending on
the device connected

.

IEEE 1394 (FIREWIRE®)

IEEE 1394 (also known as iLink® or FireWire®) ports (7) provide
an easy and high-performance way of connecting high-speed
storage, imaging, and many new types of audio/video devices
easily.

C

OONNNNEECCTTIIOONN

C

O

PPTTIIOONNS

O

S

53

S

OOFFTTWWAARRE

S

There are many kinds of help and information for using your PC.
This section tells you where to get help with the Microsoft

®

dows

XP operating system, software programs, and your PC.

E

®

Win-

GETTING TO KNOW WINDOWS XP

WINDOWS

This printed manual provides general information about the oper­ating system. We recommend that all beginning users or users of
previous versions of Windows
found with the CDs in the accessory box that came with your PC.

WINDOWS

Windows® XP includes a tour that you can take to familiarize
yourself with the operating system. This tour can usually be found
by clicking on the Start menu. You can also find the tour by se­lecting All Programs, then Accessories.

MICROSOFT

Training is the most powerful way to acquire skills that help you
perform a specific task efficiently. On the Start menu, choose All

Programs, choose Accessories, and then choose Microsoft
Interactive Training.

WINDOWS

®

XP MANUAL

®

read this information. It can be

®

XP TOUR

®

INTERACTIVE TRAINING

®

XP HELP AND SUPPORT

®

An answer to almost every question can be found in this program.
You’ll find it in the Start menu.

54

M

M

AAIINN

C

C

OOMMPPOONNEENNTTS

S

SOFTWARE HELP

Many software programs incorporate extensive help functions. As
a general rule, you can access help functions by pressing F1 on
the keyboard. Many software programs include Help as an option
on the menu at the top of the screen or window. They may also
provide an icon (or icons) with a question mark on them that you
can click to access more information.

The software included with the Notebook was pre-installed at the
factory.

During software installations, important files can be changed or
even deleted. We recommend that you set a Windows
ery point before installing software (p. 64).

For specific installation information, refer to the documentation
that came with the software program. Here is a typical installation
procedure.

1. Load the software program installation disc in the combo drive.

2. Most installer programs start automatically after a few moments.

If the installer program does not start automatically, you can
manually start it by double-clicking My Computer, and then dou­ble-clicking the drive letter where you loaded the software pro­gram installation disc.

®

XP recov-

3.

Follow the instructions given by the program.

DEVICE DRIVERS

If you install external devices, such as printers or digital cameras,
you may also need to install device drivers. The drivers will be
included with your peripheral devices. These are occasionally up­dated by the manufacturer. Check with the manufacturer of your
peripheral device to find out if you have the most recent version
of your device drivers.

INFORMATION ABOUT YOUR PC

Clicking on Start and then on Information about your PC will
bring up more extensive information about your PC, as well as
useful links to software tools and other resources. It also contains
any last minute information about your PC that may not be in­cluded in this manual.

S

OOFFTTWWAARRE

S

E

55

DIGITAL SIGNATURES

When installing software or drivers, you may receive the message “The
software you are installing has not passed Windows Logo testing to verify
its compatibility with Windows XP.” Although the software lacks the digi­tal signature, it may work properly. Click on “Tell me why this testing is
important” to get detailed information. Click on “Continue Anyway” to
continue to install your software.

To set file signature verification options for Windows XP:

1. Click Start, then Control Panel. Double-click System.

2. On the Hardware tab, select Driver Signing.

3. Under File Signature Verification, select one of the following:

Ignore allows all device drivers and software to be installed on this
PC regardless of whether they have a digital signature.

Warn displays a warning message when you attempt to install a
software program or device driver without a digital signature.

Block prevents installation programs from installing device drivers
without a digital signature.

If you are logged on to your PC as an administrator, you can click Apply
setting as system default to apply the selected setting as the default
for all users of your PC.

WARNING! During software installation important files
can be changed or deleted. To avoid problems in using
older files after installation, make sure to safeguard your
hard disk.

WINDOWS ACTIVATION

Microsoft is committed to the protection of intellectual property rights and
the reduction of software piracy. Windows XP contains software-based prod­uct activation technology. Your copy of Windows XP has already been acti­vated for your Notebook. However, product activation is needed if some
components of your Notebook have been replaced or you use non­authorized BIOS. If necessary, you can activate Windows XP as often as
needed. You will probably need to activate Windows XP by telephone even if
Internet Activation is available. This is due to the pre-activated SLP version
that runs with a special Product-ID. However, activation needs your unique
Product ID that can be found on the Certificate of Authenticity sticker on
your Notebook housing. When you call, please inform the agent that you are
running an OEM (SLP) version of the software.

56

M

M

AAIINN

C

C

OOMMPPOONNEENNTTS

S

THE BIOS SET-UP-PROGRAM

In BIOS setup (Basic Configuration) there are a number of config­urable parameter settings available for your Notebook. For exam­ple, you can change the operating mode of the interfaces, security
features or power management.

WARNING! The Notebook is factory pre-set to
guarantee optimum operation. Only modify the pa­rameters if necessary and if you are familiar with
the configuration options.

RUNNING THE BIOS SET-UP

You can only run the BIOS configuration program at system start­up. If the Notebook has already started, power it down and then
up again. Press the F2 function key in order to start the BIOS­SET-UP.

NAVIGATING THE BIOS UTILITY

There are six menu options: System Information, Basic System
Settings, Start up Configuration, Onboard Devices Configuration,
System Security and Load Default Settings.

To enter a menu, highlight the item using the cursor up/down
keys; then press Enter.

While in a menu, follow these instructions:

- Press the cursor up/down keys to move between parameters.

- Press the cursor left/right keys to change the value of a parameter.

- Press Esc while you are in any of the menus to return to the main

menu.

Note: If you are unsure if your parameter settings are
correct, you should load the "Set-up-Defaults".

S

OOFFTTWWAARRE

S

E

57

58

M

M

AAIINN

C

C

OOMMPPOONNEENNTTS

S

CChhaapptteerr 55

First Aid

Subject Page

FAQ............................................................... 61

Data and System Security ................................ 63

System Recovery ............................................66

Troubleshooting .............................................. 70

Maintenance ...................................................73

60

F

D

A

IIRRSSTT

F

IID

A

Q

FFAAQ

–

F

RREEQQUUEENNTTLLYY

–

F

When do I have to activate Windows?

Your software has been preactivated in the factory.
An activation will only be required, if ...

... several components are replaced by others.

... your installed a new motherboard.

... a different BIOS version has been installed.

... you install the software to another computer.

What is the Windows activation?

Your operating instructions include a chapter about
this subject.

A

SSKKEEDD

A

Q

UUEESSTTIIOONNSS

Q

How do I perform a data backup?

Use the program Backup for this.

It is important that you follow the operating instruc­tions of these programs.

Make a backup and another backup of selected data
to an external medium (CD-R, CD-RW, DVD-R, DVD­RW, SD card, etc.), to familiarize yourself with the
technique.

A backup is unsuitable if you are not able to recover
the data, the medium (floppy disk, CD-R, etc.) is
defective or no longer available.

Q

–

F

FFAAQ

RREEQQUUEENNTTLLYY

–

F

A

A

SSKKEEDD

Q

UUEESSTTIIOONNS

Q

S

61

Do I still have to install the enclosed CDs/DVDs?

No. Basically all programs are already preinstalled.
The disks are only intended as backup copies.

When is the recovery of the factory setting recom­mended?

This method should be chosen as the last resort.
Read chapter “System recovery” on page 66 con­cerning the possible alternatives.

Why is the boot partition missing when booting from
the support/ application CD?

The first partition is formatted with the file system
NTFS. Compared to FAT32 this file system offers
more security and a more efficient access. However,
NTFS partitions can only be read from operating sys­tems supporting this. This is not the case in the
aforementioned CD.

62

F

D

A

IIRRSSTT

F

IID

A

D

AATTAA AANNDD

D

The programs described below are part of your Windows operat­ing system. You will find additional information on these programs
in the Windows Help file.

S

YYSSTTEEMM

S

S

EECCUURRIITTY

S

Y

DATA SECURITY

Back up data regularly on external media such as a CD-R or CD­RW. Windows offers both a Backup program and a Files and
Settings Transfer Wizard.

Both programs are found in Accessories/System Tools within
the Start menu. You should make a backup disk with all your
passwords and the operating system’s original configuration.

MAINTENANCE PROGRAMS

You can avoid some hardware and software errors with disk main­tenance programs such as Disk Defragmenter and Disk
Cleanup. The program System Information can also be helpful
since it gives you detailed information about your system configu­ration. You will find these programs in Accessories/System

Tools.

PASSWORD RESET DISK

To protect individual user accounts from complications resulting
from lost passwords, users should create a password reset disk
and keep it in a safe place. Windows Help describes how to create
a password-reset disk.

D

AATTAA AANNDD

D

S

YYSSTTEEMM

S

S

EECCUURRIITTY

S

Y

63

WINDOWS

®

UPDATE

Windows Update is the online updating of Windows. Use Win-

dows Update to download elements such as security updates, im­portant updates, the newest help files, drivers and Internet prod­ucts from the Internet.

The website is regularly augmented by new content, so that you
can download the newest updates and error corrections at any
time, to protect the Notebook and guarantee its functioning.

Windows Update will search through the Notebook and provide a
list of individual updates specially for the configuration of your
Notebook.

Each update that Microsoft regards as important for the operation
of the operating system, programs or hardware components will
be classified as an “important update” and automatically selected
for installation for you.

Important updates will be provided to remove known problems
and to protect the Notebook against known security risks.

Carry out four simple steps, to download the updates needed and
to keep your computer on the current status of technology:

1. Open Windows Update in the Help and Support Center.

64

2. Click on Search for update.

3. Click on Add to select the desired update and to add
it to the updates to be installed, while you are
searching through the available updates in each
category. You can also read a complete description
of each individual element by clicking on the Read
further Link.

4. Click on Check and install updates, when you
have selected all the desired updates, and then click
on Install now.

F

D

A

IIRRSSTT

F

IID

A

WINDOWS UPDATE INFORMATION FOR DATA SECURITY

Windows Update needs certain information about the respective
Notebook, so that a suitable list with updates can be provided for
you. This information will include the following:

• Version number of the operating system

• Version number of Internet Explorer

• Version numbers of additional software programs

• Plug & Play identification key of the hardware devices

Windows Update will stand up for the protection of your private
data and will not record your name, address, email address or
other forms of personal data. The information collected will only be
used during the time that you are visiting the website. It will also
not be stored.

 The update can only be executed via the Internet. En-

sure that you are on-line with your notebook when
downloading the updates.

D

AATTAA AANNDD

D

S

YYSSTTEEMM

S

S

EECCUURRIITTY

S

Y

65

S

YYSSTTEEMM

S

Before performing a recovery, you should review the
“Troubleshooting” section in this manual to see if you can resolve
the problem. If not, it is possible that a software file required by
Windows XP to operate the computer was damaged or deleted. If
this is the case, there are basically two strategies for recovery.

• Restoring your system using Windows XP System

Restore

This type of recovery is usually very quick and will solve most
typical problems that occur after an unsuccessful installation
of an application, device, or driver has caused instability in the
system.

• Restoring your system using the Application & Support

Disc

There are several options for recovery available using the
Application & Support Disc, including the ability to restore you
entire system to its original factory settings.

R

EECCOOVVEERRY

R

Y

RESTORING MICROSOFT WINDOWS XP

Windows XP System Restore allows you to set "recovery points."
This feature enables you to take a snapshot of the current system
configuration, which you can return to should an application, de­vice, or driver cause instability in the system.

While Windows XP automatically creates recovery points, you can
also set them manually. In addition, you can configure the maxi­mum amount of memory used for this.

To use System Restore to set recovery points or restore your sys­tem, click the Start menu, then choose All Programs, then
choose Accessories, then choose System Tools, then choose
System Restore. Select the task that you would like to perform
and follow the on screen instructions. For detailed information
refer to Windows XP Help and Support.

System Restore includes various functions to help ensure that
your Notebook and installed applications and devices work cor­rectly. These functions assist you in solving the problems which
might occur by adding, deleting or replacing files required for
proper functioning of Windows XP, and your software and devices.

66

F

D

A

IIRRSSTT

F

IID

A

The restore function you use depends on the type of problem or
error.

In general, it is a good idea to set a recovery point before install­ing a new software program or driver. If the system becomes un­stable during or after the installation, you can usually return to a
workable configuration without deleting newly created documents.
If Windows XP System Restore does not solve your problem refer
to the next section, System Restore powered by Symantec.

SYSTEM RESTORE POWERED BY SYMANTEC

If your system is not functioning properly and Windows XP Sys­tem Restore did not solve the problem, then you should use the
Application Support Disc to restore your system. This recovery
mode provides several options.

There are three options for restoring your system:

1. Recovery of start-up files
Use this option to restore the start-up files. This option is
most useful when a virus has corrupted certain files necessary
for your computer to boot. It is executed very quickly.

2. Recovery of system and driver files
This option will copy the original system and driver files to
your hard disk. This feature shouldn’t affect your personal
files and settings. However, we recommend that you first
back up your personal data just to be safe.

S

S

YYSSTTEEMM

R

EECCOOVVEERRY

R

Y

67

3. Restoring the factory settings
This recovery will reset your system to its condition at
delivery. ALL DATA ON YOUR LOCAL DISC (C:) DRIVE WILL
BE ERASED. If possible, back up your personal data to
external media before performing this restore.

LIMITS OF RESTORE FACTORY SETTINGS (RESTORE OPTION 3)

Any changes made to the original factory configuration (for exam­ple, settings for your display, printers, network, or Internet con­nection) will be overwritten by this restoration.

Any software that you installed after purchasing the computer will
be erased and will need to be reinstalled.

Everything on the C:\Local Disk partition will be erased. This
includes all of your documents and settings.

Tampering with the Recover (E:) hard disk drive or its contents
will make it more difficult to restore your Notebook. Do not alter,
resize, or delete the Recover (E:) hard disk drive. Also, do not
alter or delete the files on the Recover (E:) hard disk drive. We
strongly recommend that you do not store any files, folders, or
programs on the Recover (E:) hard disk drive.

PERFORMING THE RESTORE

Each step of the restore replaces an increasing number of files on
your hard drive, and therefore takes longer to finish. We recommend
that you attempt each of the restore options in order, starting with
“Recovery of start-up files.” After finishing each restore option, you
should test your system to see if it has solved your problem. If the
problem persists, then try the next restore option.

To make selections in the restore program, use the up and down ar­row keys to highlight the option you would like to select, and then
press enter to make the selection.

1. Copy your data files to external media (such as a floppy
disk, CD-R, CD-RW, DVD-RW, or flash card) BEFORE you
continue!

68

F

IIRRSSTT

F

D

A

IID

A

2. Insert the “Application & Support” disc and restart (reboot) the
Notebook.

Caution: Do not use the “Product Recovery” CD-ROM (a Win­dows XP CD for restoring Windows XP itself) for restoration
purposes. This disc does not restore the original factory setup
of the Notebook.

3. Select the option “Boot from CD-ROM” from the first screen.

4. Use the arrow keys to read through the license agreement, and
then press the Esc key to proceed.

5. Read the information screen that appears, and then press Enter
to proceed.

6. Select option 1, 2, or 3 to perform a restore (the types of restore
are described earlier in this chapter). Select option 4. Reboot to
cancel the restore process.

7. The next screen shows information about the type of restore that
you have chosen. Select either Abort or Back to return to the
previous screen, or select Finish to execute the restore.

8. When the restore is completed, it automatically restarts the
Notebook. Remove and store the Application & Support disc.

S

S

YYSSTTEEMM

R

EECCOOVVEERRY

R

Y

69

T

RROOUUBBLLEESSHHOOOOTTIINNGG

T

LOCALIZE THE CAUSE

Errors can have simple causes, but sometimes they are caused by
faulty equipment. We would like to give you some tips to help
solve common problems. Should these instructions not lead to
success, please feel free to contact us.

CHECK CABLES AND CONNECTIONS

Visibly check all cables and connections. Should all lights be off,
check whether all equipment is supplied with power.

¾ In battery mode, connect the Notebook to the power adapter

and ensure that the battery is charged up.

¾ If you are operating the Notebook with the power adapter,

check the electrical socket, power cord and all switches in the
circuit of the electrical socket.

¾ Switch off the Notebook and check all cable connections.

Check the connections to peripherals. Do not exchange ca­bles, even though they may look similar. The polarity in the
cables may be different. When it is confirmed that the Note­book has power and all connections are correct, turn the
Notebook on again.

THE POWER ON SELF TEST (POST)

The Power On Self Test (POST) is executed during each boot
process to test the memory, motherboard, display, keyboard and
other components. If the Notebook does not pass the POST but
beeps several times, or if the screen remains blank, call your
Notebook support technician.

70

F

IIRRSSTT

F

D

A

IID

A

ERRORS AND POSSIBLE CAUSES

The screen is black:

• Make sure that the Notebook is not swapping data and the
Fn+F12 key combination has not been operated.

The Notebook switches itself off during operation.

• The accumulator could be empty. Connect the Notebook by
means of the network adapter and charge the accumulator.

The Notebook cannot be switched on.

• Operate the Notebook by means of the accumulator and
check whether it is correctly inserted and charged.

Incorrect time and date display.

• Double click the time display in the task bar and set the cor­rect values afterwards.

No data can be read from the optical drive.

• Check whether the disk is correctly inserted.

• Is the drive displayed in Explorer? If yes, test another disk.

The mouse or the touchpad is not functioning.

• Check the cable connection.

The Fn+F2 key combination does not react.

• The second monitor is not activated under Display Charac­teristics. Select it by removing the tick from Add this moni­tor to Windows Desktop under Settings.

The WLAN connection is not functioning.

• You must press the relevant hotkey
connection, and the relevant display

to activate the WLAN

will light up.

T

RROOUUBBLLEESSHHOOOOTTIINNG

T

G

71

ADDITIONAL SUPPORT

If the suggestions in the above section have not solved your prob­lem, please contact customer care and we will attempt to help you
solve the problem. Before you call, however, please have the fol­lowing information available:

- How is your computer configured?

- What additional peripherals do you use?

- What messages, if any, appear on your screen?

- What software were you using when the error occurred?

- What steps have you already undertaken to solve the prob-

lem?

- Have you upgraded or removed drivers or hardware?

- Can you manually repeat the problem?

- If you have been given a customer number previously, please

have this available.

DRIVER SUPPORT

This Notebook has been extensively tested in our laboratories with
a large number of compatible devices. It fulfils all required stan­dards and complies with the standard “Designed for Windows”,
which certifies utmost compatibility. However, the software driv­ers for individual components are updated from time to time. This
is a regular process provided by the manufacturer to mend possi­ble compatibility problems that may occur with components (e.g.,
programs or hardware) that were not tested at the time of your
Notebook’s manufacture.

72

F

D

A

IIRRSSTT

F

IID

A

M

AAIINNTTEENNAANNCCEE

M

MAINTENANCE INSTRUCTIONS

This section provides information on the proper maintenance and
care of your Notebook. Following these measures can extend its
lifetime.

CLEANING AND CARE

• Before cleaning, always remove the power adapter plug and all
connecting cables.

• Only use a damp, lint-free cloth to clean the Notebook.

• Warning! There are no user-serviceable or user-

cleanable parts inside the Notebook housing. Never
open the Notebook housing.

• DO NOT use any solvents, corrosive or gaseous
cleaning agents.

• DO NOT use CD-ROM cleaning disks or similar
products that clean the lens of the laser to clean
your CD-ROM/CD-RW/DVD/DVD-RW drive.

CARE OF THE TFT DISPLAY

• Always close the Notebook when not in use. Avoid touching or
scratching the surface of the screen as it is easily damaged.

• Make sure that no water drops are allowed to remain on the
screen. Water can cause permanent discoloration.

• Clean the screen with a dry, soft, lint-free cloth.

• Do not expose the screen to bright sunlight or ultraviolet radia-

tion.

M

AAIINNTTEENNAANNCCE

M

E

73

TRANSPORTING THE NOTEBOOK

Please use the following guidelines when transporting the Note­book:

• Switch off the Notebook. This will prevent damage to the hard
disk. When the Notebook is turned off, the hard disk heads are
moved into a safe area.

• Remove any CDs and floppy disks. This will prevent damage to
the disks or to the drive heads.

• Close the Notebook and ensure that the cover locks shut.

• Always use the Notebook carrying case. This helps to protect the

Notebook from dirt, moisture, jolts and scratches.

• Fully charge your battery and any spare batteries immediately be-
fore a long journey.

• Should you need to ship your Notebook, always use the original
packaging and make certain the shipper knows the contents con­tain fragile electronic equipment.

• Wait until the Notebook has reached ambient (room) temperature
before turning it on or connecting it to the power adapter. Drastic
variations in temperature and humidity can create condensation
within the Notebook and may cause it to short-circuit.

RECYCLING AND DISPOSAL

This notebook and its packaging was produced mostly from mate­rials which can be disposed of in an environmentally friendly man­ner and be professionally recycled.

After its use the computer will be taken back and recycled or use
will be made of its useful material, if it is returned in a condition
corresponding to its intended use.

Parts not usable will be properly disposed of.

 ATTENTION! There is a lithium battery on the

motherboard. No type of battery belongs in the
household waste. All are taken back free of charge by
the manufacturer, dealer or their representatives for a
proper method of utilisation or disposal.

Should you have any questions concerning the disposal please
contact your dealer or our service.

74

F

IIRRSSTT

F

D

A

IID

A

BATTERIES AND PROPER TREATMENT

Batteries may contain combustible materials. By misuse, this may
cause battery leakage, heat, explosion or ignition, bringing
about injury or damage to the device. Please observe strictly the
following matters:

 Attention: There is a lithium battery on the mother-

board. Lithium batteries are hazardous waste and need to

be disposed of properly. If necessary, we will take back your
used CMOS lithium battery.

• KEEP CHILDREN AWAY from batteries.

If by any chance, the batteries are swallowed, consult a doctor
immediately.

• DO NOT CHARGE batteries (except rechargeable batteries).

• DO NOT FORCIBLY DISCHARGE batteries.

• DO NOT SHORT-CIRCUIT batteries.

• DO NOT HEAT or DISPOSE OFF IN FIRE.

• DO NOT DISASSEMBLE or DEFORM batteries.

Your hands and fingers may be injured, or the liquid of the battery may
get into your eyes or adhere to your skin. If this happens, rinse with a
large quantity of water immediately and consult a doctor.

• DO NOT expose batteries to strong impact by dropping or throw-

ing the batteries.

• DO NOT reverse the positive (+) and negative (-) terminals to

avoid short-circuit.

• Do NOT MIX used and new or different types of batteries together.

Your equipment may not operate properly.
In addition, the battery exhausted first may be excessively drained
(over-discharged).

• REMOVE PROMPTLY the used batteries from the device.

• REPLACE ALL BATTERIES with new batteries of the same type at

the same time.

• INSULATE THE TERMINAL parts with tape or the like at the

storage or disposal of the batteries.

• DO NOT throw rundown batteries in the domestic refuses! Re-

spect the environment and throw them in the specific containers
for separate collection. If necessary, turn to your reseller or to
our service assistance. Thank you!

M

AAIINNTTEENNAANNCCE

M

E

75

SECURING YOUR NOTEBOOK

SETTING A USER PASSWORD

You can prevent unauthorized access to your Notebook by setting
a User Password. When starting the Notebook the password will
be requested. The User Password is set in the BIOS.

 Attention: Keep your password in safety place. If

you forget your password you do not have the pos­sibility to cancel it. In this case please call your
service centre.

To protect your data from unauthorized access, you can also use
the security option of Windows
System Security“

(Ö p. 63).

xp

. See also chapter „Data and

USING A SAFETY LOCK

You can prevent theft by using a so called Kensington-lock,
which can be bought at your local retailer.

The cable wraps around an object and the „T“ shaped end inserts
into the Kensington lock port and a key or combination dial is
used to secure the lock in place. Please keep your key at a safety
place.

UPGRADES AND REPAIRS

• Only a qualified Service Engineer should perform upgrades and
repairs to your Notebook.

If you do not have the necessary qualifications, go to an appropri­ate Service Engineer. Please contact the Service Centre if you
are experiencing technical problems with your Notebook.

76

F

D

A

IIRRSSTT

F

IID

A

NOTES FOR SERVICE ENGINEERS

• Before opening the housing, disconnect the Notebook from all power
sources and remove any connecting cables. If the Notebook has not
been disconnected from the power outlet before being opened, there
is a danger of severe electric shock. There is also a risk of damage
to the components.

• Internal components of the Notebook may be damaged by electro­static discharge (ESD). Perform system upgrades and changes in

an ESD-protected work area. If no such work area is available,
wear an antistatic wrist strap or touch a highly conductive metal
object. Your service center can repair damage sustained by inappro­priate handling for a fee.

• Use only original spare parts.

CAUTION:

sure, high temperatures or fire. Keep away from children! Danger of
explosion if replaced incorrectly. Only replace with a compatible type
(CR2032) as recommended by the manufacturer. Lithium-Batteries
are hazardous waste and need to be disposed of properly. If neces­sary, we will take back your used CMOS lithium battery.

Notes on Laser Radiation

Laser devices of Laser Class 1 to Laser Class 3b may be used in the
Notebook. Where the Notebook housing remains closed, the device
meets the requirements of Laser Class 1. By opening the Notebook
housing you will gain access to laser devices of up to Laser Class 3b.

• The CD-ROM/CD-RW/DVD/DVD-RW drive contains no user-
serviceable parts. Only the manufacturer should perform repairs
to the CD-ROM/CD-RW/DVD/DVD-RW drives.

The CMOS lithium batteries cannot tolerate intense pres-

:

When removing and/or opening laser devices, the following guide­lines must be observed:

• DO NOT look into the laser beam, even while wearing optical pro-
tection.

• DO NOT allow yourself to be exposed to the laser beam. Avoid ex-
posure of the eyes or skin to direct or stray
radiation.

M

AAIINNTTEENNAANNCCE

M

E

77

78

F

D

A

IIRRSSTT

F

IID

A

CChhaapptteerr 66

Appendix

Subject Page

Standards ......................................................81

Warranty........................................................ 85

Index ............................................................87

M

AAIINNTTEENNAANNCCE

M

E

79

80

A

A

PPPPEENNDDIIX

X

S

TTAANNDDAARRDDS

S

This Notebook meets the requirements of the following standards:

S

ELECTROMAGNETIC COMPATIBILITY

This Notebook meets the following requirements for standards of
electromagnetic compatibility and electrical safety:

EN 55022

EN 55024

EN 61000-3-2

EN 61000-3-3

• Keep the Notebook at least one meter (approximately three

feet) away from high frequency and magnetic interfer-
ence sources (e.g., televisions, loudspeaker cabinets, mobile
telephones, etc.) in order to avoid malfunctions and/or loss of
data.

• Please note that only shielded cables shorter than

3 meters (9.84 ft) should be used for the LPT, COM, USB,
IEEE 1394, audio, video and network interfaces with this
Notebook.

Information technology equipment - Radio disturbance
characteristics - Limits and methods of measurement.

Information technology equipment - Immunity character­istics - Limits and methods of measurement.

Limits - Limits for harmonic current emissions (equipment
input current up to and including 16 A per phase).

Limits - Limitation of voltage fluctuations and flicker in
low-voltage supply systems for equipment with a rated
current up to 16 A.

• When connecting additional components, please observe the

Guidelines on Electromagnetic Compatibility (EMC).

S

TTAANNDDAARRDDS

S

S

81

ELECTRICAL SAFETY

EN 60950

Safety of information technology equipment.

• The connection of devices is limited to equipment that com-
plies with EN60950 “Safety of information technology
equipment” or EN60065 “Audio, video and similar electronic
apparatus. Safety requirements”

• For U.S. / Canadian purposes: The Notebook should only be

connected to equipment which complies with UL 60950 /
CAN CSA 22.2 No 60950

ERGONOMICS

EN 29241-3

EN ISO 9241-8

Ergonomic requirements for office work with visual
display terminals (VDTs). Visual display requirements.

Ergonomic requirements for office work with visual
display terminals (VDTs). Requirements for displayed
colours.

SUPPLEMENTARY INFORMATION

This product has been tested for operation in UK and complies
with the European Directives on Radio and Telecommunications
Terminal Equipment (R&TTE 1999/5/EC).

ISO 13406-2 CLASS II

Active matrix LCDs (TFT) with a resolution of 1024 x 768 pixel (XGA),
which are in turn composed of three sub-pixels each (red, green,
blue), contain about 2.4 million addressable transistors. Because of
this very high number of transistors and their extremely complex
production process occasionally defective or incorrectly addressed
pixels or sub-pixels may occur.

There have been several attempts in the past to define the accept­able number of defective pixels. But this can be difficult and varies
widely between different manufacturers.

We, therefore, adhere to the clear and strict requirements of ISO
13406-2, class II, for the warranty handling of all TFT display prod-
ucts. These requirements are summarized below.

Within ISO-standard 13406-2 the general requirements regarding
pixel defects are defined. Pixel defects are classified into three failure
types and four failure classes. Each individual pixel is made up of
three sub-pixels in the primary colours (red, green, blue).

82

A

A

PPPPEENNDDIIX

X

Pixelstructure

Rows

Blue
Green
Red

Types of Pixel Failures:

Type 1: A constantly lit pixel (a bright, white spot), even though it is

not addressed
A white pixel is caused when all three sub-pixel are lit.

Type 2: A pixel that does not light up (dark, black spot), although it is

addressed

Type 3: Abnormal or defective red, green or blue sub-pixels.

(E.g. constantly lit with half the brightness, one colour is not
shining, blinking or flickering, but not belonging to Type 1 or
2 Pixel Failures)

In addition: A cluster of type 3 (= 2 or more defective sub-pixels in an

array of 5 x 5 pixel). A cluster is an array of 5 x 5 pixel (15 x
5 sub-pixel).

ISO 13406-2, Class II

Resolution Type 1 Type 2 Type 3 Cluster

Type 1,

Type 2

1024 x 768 2 2 4 0 2

1280 x 854 3 3 6 0 3

1280 x 1024 3 3 7 0 3

1400 x 1050 3 3 8 0 3

Cluster

Type 3

Example:

A 17” - SXGA-display consists of 1280 horizontal and 1024 vertical pic­ture dots (pixel), which amounts to a total of 1,31 million pixels. Based
on one million pixels this translates into a factor of about 1.31.
Class II type failure consequently allows for three defects each of type 1
and type 2 and 7 defects of type 3 and 3 cluster of type 3.

These cases are normally not covered by warranty.
If the number of failures exceeds the figures of any category mentioned
above then this may be covered by the warranty.

S

TTAANNDDAARRDDS

S

S

83

FCC COMPLIANCE STATEMENT

This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency en­ergy and, if not installed and used in accordance with the instruc­tions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harmful in­terference to radio or television reception, which can be deter­mined by turning the equipment off and on, the user is encour­aged to try to correct the interference by one or more of the fol­lowing measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and re-

ceiver.

• Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.

• Consult the dealer or an experienced technician for help.

Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to oper­ate the equipment. Shielded interface cables, if any, must be used
in order to comply with the emission limits.

84

A

PPPPEENNDDIIX

A

X

W

AARRRRAANNTTY

W

The receipt serves as proof of first purchase and should be kept in
a safe place. Your legal rights are not limited
ditions. It is required should you need to make use of the guarantee.

We guarantee that this equipment is in perfect working order.
Upon production of the receipt, the remaining period of guarantee
shall pass on from the original parts to the respective replacement
parts. If you hand in this equipment to make use of the guaran­tee, you must remove all programs, data and removable storage
media. Products which are sent without accessories will be re­placed without accessories. The warranty obligation does not ap­ply in the case of the problem being caused by an accident, a ca­tastrophe, vandalism, misuse, incorrect use, ignoring the safety
and maintenance regulations, changes by software, viruses or
another piece of equipment or accessories or by other modifica­tions not approved by ourselves. This limited guarantee declara­tion replaces all other guarantees of express or implied nature.
This includes the guarantee of saleability or the suitability for a
certain purpose but is not limited to this. In some countries the
exclusion of implied guarantees is not permissible upon principle.
In this case the validity of all express and implied guarantees is
limited to the guarantee period. Once this period has expired, all
guarantees become invalid. In some countries limiting the period
of validity for implied guarantees is not permitted, so that the
above limitation does not come into force. If you have any ques­tions with regard to these guarantee conditions, please contact us.

Y

by these warranty con-

W

AARRRRAANNTTY

W

Y

85

LIABILITY LIMITATIONS

The contents of this manual are subject to unannounced changes
caused by technical progress. Manufacturer and sales shall not be
responsible for any damages which have been caused as a result
of omissions or errors in the information provided in this manual.

Under no circumstances shall we be liable for any of the following:

1. Claims made against you by third parties based on loss or damage.

2. Loss or damage to your blanks, recordings or data.

3. Economic follow-on damage (including lost profit or savings) or associ­ated damage even in the case that we have been informed of the pos­sibilities of this type of damage.

In some countries the exclusion or limitation of accompanying or follow­on damage is not legally accepted so that the above limitations do not
come into force.

COPYING THIS MANUAL

This document contains legally protected information. All rights
reserved. Copying in mechanical, electronic and any other form
without the written approval of the manufacturer is prohibited.

86

A

A

PPPPEENNDDIIX

X

I

I

A

All programs........................22

Ambient Temperature ............ 7

Appendix.............................79

Audience............................... i

Audio Out............................44

B

Batteries and Proper

Battery operation

Battery Power ......................26

BIOS Setup-Program ............57

BIOS Utility

Burning CDs ..... See writing CDs

C

Cabling ................................ 9

CardBus..............................51

Care of Displays ...................73

CD-ROM..............................39

CD-RW Drive .......................39

CDs

Charging the Battery.............26

Checking the Battery Level ....27

Cleaning agents ...................73

Cleaning and Care ................73

Clone Desktop .....................30

Connection Options...............53

Connectors

X

NNDDEEX

Treatment ........................75

Battery Power ...................26

Checking the Battery Level .27

Charging ..........................26

Inserting ..........................25

Removing.........................25

Navigating........................57

Running ...........................57

Data................................42

Music...............................42

Audio IN ..........................44

Audio OUT........................44

External Monitor ............... 30

IEEE 1394........................ 53

Microphone IN .................. 44

Modem ............................ 45

PC Card ........................... 51

USB ................................ 53

Control panel....................... 22

Copyright

D

Data and System Security ..... 63

Data Entry .......................... 32

Data Security .................. 3, 63

Deleting Files ...................... 38

Desktop.............................. 21

Digital Signatures ................ 56

Directories .......................... 38

Disc-Drive........................... 39

Discs

Handling.......................... 39

Loading ........................... 40

Removing ........................ 41

Removing Blocked Discs..... 41

Writing ............................ 42

Display............................... 29

Opening and Closing the

Driver Support..................... 72

Drivers ..........................38, 55

DVD movies ........................ 41

DVD-Drive .......................... 39

E

Electrical safety ................... 82

Electromagnetic Compatibility 81

EMC ...................................81

Emergency ejection of a

blocked disc ..................... 41

Enter personal details ........... 20

Ergonomics ......................... 82

Extend Desktop ................... 30

External audio ports ............. 44

©

............................ ii

Display......................... 29

I

X

NNDDEEX

I

87

External Monitor............. 14, 30

Clone Desktop ..................30

Extend Desktop.................30

F

FAQ....................................61

Fast Ethernet-Network ..........46

FCC Compliance Statement....84

Files

Deleting...........................38

Finding ............................37

Finding Files ........................37

First Aid ..............................59

Fn ......................................32

Frequently Asked Questions ...61

G

Getting Started ....................19

H

Handling .............................17

Hard drive...........................37

Hard Drive

Partitions .........................37

Help ...................................54

Help with Software ...............55

Hotkeys ..............................16

I

Icons ..................................22

IEEE 1394 ...........................13

Indicators............................15

Access .............................15

Battery ............................15

Capital Lock......................15

Num Lock.........................15

Power ..............................15

Scroll Lock .......................15

Wireless LAN ....................15

Information about the

regualtory compliance of

wireless Lan ...................... 9

Information about your PC.....22

Inserting the Battery.............25

Installing a PC Card ..............52

Introduction ..........................3

ISO 13406-2 Class II............ 82

K

Kensington-lock................... 76

Keyboard............................ 32

L

Laser radiation .................... 77

Left Side............................. 14

License agreement ...............20

M

Main components................. 35

Main Operation .................... 24

Maintenance........................ 73

Care of the TFT Display...... 73

Cleaning and Care............. 73

Transporting the Notebook . 74

Maintenance Programs.......... 63

Memory Stick ...................... 50

Microphone in...................... 44

MMC .................................. 50

Modem ........................... 9, 45

Mouse ................................ 33

MPEG2 ............................... 41

Multimedia Card Reader ...14, 50

MultiMediaCard.................... 50

N

Network ............................. 46

Fast Ethernet-Network....... 46

Prerequisites .................... 47

Troubleshooting................ 48

What is a Network? ........... 46

Wireless LAN .................... 49

O

On/Off Button...................... 23

Operational safety.................. 4

P

Partitions ............................ 37

Password Reset Disk............. 63

PC Card

88

A

A

PPPPEENNDDIIX

X

Installing..........................52

Removing.........................52

Using...............................51

PC Card Slot ........................51

PCMCIA ..............................51

Peripheral Devices................55

Playing DVD Movies ..............41

Playing Music CDs ................41

POST ..................................70

Power

Turning off your computer ..22

Power Adapter ...................... 8

Power Management ..............28

Power On Self Test ...............70

Power Supply.......................23

Battery Operation..............25

Main Operation .................24

Standby Mode...................28

Suspend Mode ..................28

PowerDVD...........................41

Program bar ........................21

Programs

Installing..........................67

Location...........................38

Q

Quality..................................ii

R

Recover ..............................38

Recovery.............................66

Factory Settings ................67

Windows

recovery points ....................66

Recycling and Disposal ..........74

Removing a PC Card .............52

Removing Memory Cards.......50

Removing the Battery ...........25

Repairs ...............................76

Restoring ............................66

Limits...............................68

Right Side ...........................14

Running the Bios Setup .........57

xp

........................66

S

Safety

Data ............................... 38

Safety and maintenance..........1

Safety Instructions.................3

Additional Safety

Instructions.....................5

Ambient Temperature..........7

Battery Operation ............. 10

Cabling.............................. 9

Data Security .....................3

General Safety Information ..4

Modem .............................. 9

Operational Safety .............. 4

Optical Drive Safety ............6

Power Adapter....................8

Set-Up location................... 7

TFT Display Safety ..............6

Touch Pad.......................... 9

Upgrades and Repairs........ 76

Screen Resolution ................ 29

SD ..................................... 50

Search ............................... 37

Secure Digital...................... 50

Securing your Notebook........ 76

Serial Number ....................... ii

Service Engineers ................77

Setting a User Password ....... 76

Set-Up Location ..................... 7

Software............................. 54

for playing CDs................. 41

Software Help...................... 55

Sound card .........................44

Standards ........................... 81

Electrical safety ................ 82

Electromagnetic

Compatibility................. 81

Ergonomics ...................... 82

FCC Compliance Statement 84

Standby Mode ..................... 28

Start button ........................ 21

Support ..............................72

Suspend to Disk................... 28

I

X

NNDDEEX

I

89

T

Table of Contents ..................vi

Task bar .............................22

Touch Pad ....................... 9, 33

Trademarks ...........................ii

Transport ............................74

Troubleshooting ...................70

Errors and Possible Causes .71

Turn off computer ................22

U

Universal Serial Bus..............53

Upgrades and Repairs ...........76

Use of PC Cards ...................51

Using a Safety Lock ..............76

V

Views

IEEE 1394 ........................13

Left Side ..........................14

Monitor (external) .............14

Multimedia card reader.......14

PC card slot PCMCIA.......... 14

Right Side........................ 14

TFT Display ......................13

W

Warranty ............................ 85

Windows Activation .............. 56

Windows Logo testing........... 56

Windows Media Player .......... 41

Windows

Recovery ......................... 66

Windows

xp

XP

Control Panel.................... 22

Desktop........................... 21

Help and Support.............. 54

Interactive Training........... 54

Manual ............................ 54

Recovery Point ................. 55

Tour................................ 54

Windows

®

Update ................ 64

Wireless LAN ....................... 49

Writing CDs......................... 42

90

A

A

PPPPEENNDDIIX

X
