45W Single Output Switching Power Supply
EPS-45-3.3 -C =Blank,-C ; Blank=PCB only, -C=Enclosed type
SPECIFICATION
MODEL EPS-45-3.3
DC VO LTAG E
RATED CURRENT
CURRENT RANGE
RATED POWER
PEAK LOAD(10sec.) Note.6
OUTPUT
INPUT
PROTECTION
ENVIRONMENT
SAFETY &
EMC
(Note 4)
OTHERS
NOTE
RIPPLE & NOISE (max.)
VOLTAGE ADJ. RANGE
VOLTAGE TOLERANCE Note.3
LINE REGULATION
LOAD REGULATION
SETUP, RISE TIME
HOLD UP TIME (Typ.)
VOLTAGE RANGE
FREQUENCY RANGE
EFFICIENCY (Typ.)
AC CURRENT (Typ.)
INRUSH CURRENT (Typ.)
LEAKAGE CURRENT
OVER LOAD
OVER VOLTAGE
WORKING TEMP.
WORKING HUMIDITY
STORAGE TEMP., HUMIDITY
TEMP. COEFFICIENT
VIBRATION
SAFETY STANDARDS
WITHSTAND VOLTAGE
ISOLATION RESISTANCE
EMC EMISSION
EMC IMMUNITY
MTBF
DIMENSION
PACKING
1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25 of ambient temperature.℃
2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.
3. Tolerance : includes set up tolerance, line regulation and load regulation.
4. The power supply is considered a component which will be installed into a final equipment. The final equipment must be re-confirmed that it still meets
EMC directives.
5. Derating may be needed under low input voltage. Please check the static characteristics for more details.
6. 33% Duty cycle maximum within every 30 seconds. Average output power should not exceed the rated power.
3.3V
8A
0 ~ 9A
26.4W
29.7W
Note.2
80mVp-p
3.1 ~ 3.6V
±3.0%
±0.5%
±2.0%
1000ms, 50ms/230VAC 2000ms, 50ms/115VAC at full load
50ms/230VAC 16ms/115VAC at full load
Note.5
90 ~ 264VAC 127 ~ 370VDC
47 ~ 63Hz
80%
1.8A/115VAC 1 A/230VAC
COLD START 60A/230VAC
<2mA/240VAC
115 ~ 160% rated output power
Protection type : Hiccup mode, recovers automatically after fault condition is removed
3.7 ~ 4.45V 5.6 ~ 6.75V 8.63 ~ 10.1V
Protection type : Shut down o/p voltage, re-power on to recover
-30 ~ +70 (Refer to output load derating curve)℃
20 ~ 90% RH non-condensing
-40 ~ +85 , 10 ~ 95% RH℃
±℃ ℃0.03%/ (0 ~ 50 )
10 ~ 500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes
UL60950-1, TUV EN60950-1 approved
I/P-O/P:3KVAC I/P-FG:2KVAC O/P-FG:0.5KVAC
I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25 / 70% RH℃
Compliance to EN55022 (CISPR22) Class B, EN61000-3-2,-3
Compliance to EN61000-4-2,3,4,5,6,8,11, EN55024, heavy industry level, criteria A
652.3Khrs min. MIL-HDBK-217F (25 )℃
PCB:101.6*50.8*29mm (L*W*H) ; with optional CASE:103.4*62*37mm (L*W*H)
PCB: 0.14Kg; 96pcs/ 14.5Kg/0.89CUFT ; with optional CASE: 0.3Kg; 45pcs/ 14.5Kg/0.67CUFT
EPS-45-5 EPS-45-7.5 EPS-45-15
5V 7.5V 15V
8A 5.4A 3A
0 ~ 9A 0 ~ 6A 0 ~ 3.3A
40W 40.5W 45W
45W 42W 49.5W
80mVp-p 100mVp-p 150mVp-p
4.75 ~ 5.5V 7.13 ~ 8.25V 13.5 ~ 16.5V
±2.0% ±2.0%
±0.5% ±0.5%
±1.0% ±1.0%
82% 84% 88% 89% 90%
EPS-45 series
■ Features :
Universal AC input / Full range
Optional L-Bracket and cover
High efficiency up to 90%
Protections: Short circuit / Overload / Over voltage
Cooling by free air convection
4 2" compact size×
LED indicator for power on
No load power consumption<0.3W
3 years warranty
EPS-45-12
12V
3.75A
0 ~ 4.2A
45W
50.4W
120mVp-p
10.8 ~ 13.5V
±2.0%
±0.5%
±1.0%
87%
13.8 ~ 16.2V
±2.0%
±0.5%
±1.0%
17.25 ~ 20.25V 27.6 ~ 32.4V
EPS-45-24
24V
1.9A
0 ~ 2.1A
45.6W
50.4W
240mVp-p
21.6 ~ 27V
±1.0%
±0.5%
±1.0%
EPS-45-36
36V
1.25A
0 ~ 1.4A
45W
50.4W
280mVp-p
32.4 ~ 39.6V
±1.0%
±0.5%
±1.0%
89%
39.7 ~ 46.8V
EPS-45-48
48V
1A
0 ~ 1.1A
48W
52.8W
300mVp-p
43.2 ~ 52.8V
±1.0%
±0.5%
±1.0%
53.3 ~ 64.8V
File Name:EPS-45-SPEC 2015-07-17
Page 2
45W Single Output Switching Power Supply
EPS-45 series
Mechanical Specification
3.175
FS1
3
2
1
44.45
50.8
CN1
M1
29
3 max.
HS1
101.6
95.25
HS2
LED
M2
CN2
3.175
SVR1
1
2
3
4
4- 3.2ψ
Mylar film
Unit:mm
Optional cover:
No.998A -T
1.HS1,HS2 cannot be shorted.
2.HS1 must have safety isolation distance with system case.
AC Input Connector (CN1) : JST B3P-VH or equivalent
Pin N o.
1
2
3
Assignment
AC/N
No Pin
AC/L
Mating Housing
JST V HR JST SVH-21T-P1.1
or equivalent or equivalent
Terminal
DC Output Connector (CN2) : JST B4P-VH or equivalent
Pin N o.
Assignment
1,2
3,4
+V
-V
: Grounding Required; M1 and M2 are
Safety ground and should all be grounded.
Mating Housing
JST VHR
or equivalent
Terminal
JST SVH-21T-P1.1
or equivalent
Block Diagram
I/P
FG
EMI FILTER
&
RECTIFIER
PFC
CIRCUIT
O.L.P.
POWER
SWITCHING
CONTROL
Optional L-Bracket:
No.998A -D
55
103.4
RECTIFIERS
&
FILTER
DETECTION
CIRCUIT
O.V.P.
18
4.2
14.5
2-M3 L=3
12.7
24.2
2-M3 L=3
95
78
2-M3 L=4
2- 3.5
37
30.85
62
+V
-V
File Name:EPS-45-SPEC 2015-07-17
Page 3
45W Single Output Switching Power Supply
EPS-45 series
Output Derating
100
80
60
50
40
LOAD (%)
20
-30 0 2010 30 40
AMBIENT TEMPERATURE ( )℃
Enclosed type
PCB only
6050 70
(HORIZONTAL)
Static Characteristics
100
90
80
70
60
50
LOAD (%)
40
90 10095 120115 160140 200180 240220 264
INPUT VOLTAGE (V) 60Hz
File Name:EPS-45-SPEC 2015-07-17
