Page 1
HUSQVARNA OUTDOOR PRODUCTS ITALIA SPA
V210000001
PNC ML Model Brand
953878046 00 M 40–450 CDP McCulloch
953878182
Number of Pages 1 of 3
Factory: IIQ - Valmadrera Product Group: OP 93
Publication Number: MIPL2008 V210000001 Petrol Portable
Publication Date: 20/05/08 Sub Group 1071
Page 2
HUSQVARNA OUTDOOR PRODUCTS ITALIA SPA
MIPL2008 V210000001 Page 2 of 3
Page 3
HUSQVARNA OUTDOOR PRODUCTS ITALIA SPA
MIPL2008 V210000001 Page 3 of 3
Item PN Description Qty
1 531 20 60–27 lever 2
2 531 20 74–09 pin 2
3 531 20 64–38 cable B&S 1
4 531 21 30–23 upper handle 1
5 531 20 55–81 clamp 2
6 531 20 70–89 screw 2
7 531 20 70–90 washer 2
8 531 20 49–23 knob 2
9 531 20 51–69 cable hook 1
10 531 20 71–65 nut 1
11 531 20 49–61 washer 2
12 531 20 84–91 nut 1
13 531 20 89–50 plug 2
16 531 20 57–68 screw 3
17 531 20 79–81 washer 6
18 531 20 73–69 ring 1
19 531 20 49–04 washer 3
20 531 20 79–82 nut 5
21 531 20 49–07 key 1
22 531 20 63–90 deflector Yellow 1
23 531 20 66–90 washer 2
24 531 20 64–16 tie rod 1
25 531 20 63–99 spring 1
26 531 20 63–90 plug Yellow 4
27 531 20 79–77 screw 4
28 531 20 64–05 housing Yellow 4
29 531 20 64–00 wheel 2
30 531 20 79–89 washer 2
31 531 20 64–15 plate 2
33 531 20 64–19 plate 2
34 531 20 78–48 bearing blade 1
36 531 21 16–53 blade 1
37 531 20 72–37 washer 1
38 531 20 66–49 screw 1
39 531 20 64–01 wheel 2
40 531 21 30–21 clutch cable 1
42 531 20 64–45 spacer 3
43 531 20 64–02 flange 2
44 531 20 87–72 seeger 4
45 531 20 87–78 ball-bearing 2
46 531 20 78–47 washer 2
47 531 20 50–45 pinion 1
48 531 20 88–59 washer 2
49 531 20 71–22 washer 2
50 531 20 50–46 pinion 1
Item PN Description Qty
51 531 20 64–08 housing 1
52 501 38 19–01 belt Z27 1
53 531 20 64–27 spring 1
54 531 21 31–87 gear-box 1
55 531 20 51–08 key 2
56 531 20 76–97 spacer tube 1
59 531 20 63–95 grass catcher 2
62 531 20 79–37 screw 2
63 531 21 07–04 handle lower 2
64 531 21 31–83 deck Yellow 1
65 531 20 74–08 cotter pin 2
