MB QUART QS216 User Manual

QS216
Thank you for choosing an MB Quart Q series component set for your car audio sound system. With proper installation, you are on the path to experiencing your music in a way you only imagined possible. Here at MB Quart, we call this “Sound In Every Detail.”
The Q series has been designed for those unique individuals who settle for nothing but the best! Utilizing MB Quarts’ proprietary acoustic technologies and over 30 years of experience developing and manufacturing speaker systems, the Q series makes the emotions of music so perceptible that the passion of the musician is in perfect harmony with the listener’s feelings.
QS216
Side View Of QM216
180mm / 7.09”
24mm / .95”
72.8mm / 2.87”
7mm / .28”
16mm / .63”
Top View Of QXO216
142mm / 5.59”
Side View Of QTW216
61mm / 2.4”
10.5mm / .413”
40mm / 1.575”
54mm / 2.126”
23mm / .91”
Side View Of QXO216
41.4mm / 1.63”
99.06mm / 3.9”
175.3mm / 6.9”
99.06mm / 3.9”
QS216
QXO216 Crossover:
- Bi-Amplifiable: Tweeters can be powered separate from Midrange by removing jumpers and providing power from independent channels.
- Tweeter Attenuation: Adjusts audible output of tweeter. Selectable settings of +1dB, 0 dB, -2dB and -4dB.
- Midrange Attenuation: Adjusts audible output of midrange. Selectable settings of 0dB, -3dB and -5dB.
C
B
D
A
N
T
R
O
O
C
-
B
C
A
Q
L
BALANCED
TEMPERATURE
TECHNOLOGY
TWEETER
0
B
d
1
+
A
B
d
0
A
MID RANGE
-
2
B
d
d
B
-
4
d
C
B
B
D
B
d
3
-
-
5
d
B
B
C
Removable Top
Jumpers:
x 2 per crossover
QS216 SPECIFICATIONS
Woofers: 6.5” Nomex PMI Composite material designed
to be both light in weight and rigid. This combination allows for a flat linear response and incredible low frequency reproduction with high sensitivty. Tweeters: 40mm Teteron Silk Composite material that allows for flawless reproduction of frequencies found in silk tweeters and improved durability from the Teteron blend.
Crossover
Networks: The High Definition Crossovers offer
advanced “Q Control” for the tweeter and midrange with variable points of attenuation. Featuring MB Quarts’ Balanced Temperature Control Technology, your music will never suffer through lengthy periods of high power listening.
Continuous Power Handling: 80 watts Maxx Music Power: 170 watts Frequency Response: 35Hz - 32,000Hz Efficiency Q 1W/1M: 89 dB Nominal Impedance: 4 Ohms
WF + IN + TW WF - IN - TW
Input From Amp
- WF + - TW +
WF: Output to Midrange TW: Output to Tweeter
Included Components and Parts:
- Two QM216 6.5” (160mm) Woofers
- Two QTW216 1.575” (40mm) Tweeters
- Two QXO216 Crossover Networks
- Two Flush Mount Tweeter Fixtures
- Two Angle Mount Tweeter Fixtures
- Two Mesh Tweeter Grills
- Two Mesh Woofer Grills
- Two ABS Grill Trays
- Bag A:
- 8 pcs M4x32 Black Screws For Speakers
- 8 pcs Clips For Speakers
- 4 pcs M4x12 Black Screws For Crossover
- Bag B:
- 8 pcs Clips For Tweeters
- Bag C:
- 6 pcs Nickel Plated Screws For Tweeters
- 2 pcs Nickel Plated Flat Washers For Tweeters
- 2 pcs Nickel Plated Spring Washers For Tweeters
QS216
We strongly recommend that you have your new Q series speakers installed by your authorized MB Quart dealer. The installation professionals employed by your dealer have the necessary tools and experience to disassemble your vehicle, install your new speakers and reassemble everything properly. If you prefer to perform your own installation, it is very important that you read the entire manual first.
GETTING STARTED:
- Turn off the audio system.
- Check clearance on both sides of mounting surface to ensure that there are no obstructions (windows, tracks, wiring etc).
CROSSOVER NETWORK INSTALLATION:
- Locate a dry location for mounting of your Q Crossover Networks. DO NOT MOUNT IN
DOORS!
- Remove the cover of the crossover by squeezing either side. This exposes the mounting holes for securing the crossover to a flat surface. Prior to
pre-drilling pilot holes, ensure that you will not be drilling into wiring, gas tanks, fuel lines etc.
- Once the crossover is mounted, snap the protective cover back in place.
WIRING DIAGRAMS FOR STANDARD WIRING
AND BI-AMP WIRING
Standard Wiring Configuration: This wiring
configuration is used when you want to power each crossover with a single amplifier channel. It
is important that you leave the jumper pins in the locations shown in the diagram labeled Standard.
Bi-Amp Wiring Configuration: This wiring
configuration is used when you want to power each crossover with a pair of amplifiers(Bi-Amp) or pair of channels (Bi-Wire). In this mode, the inputs to the woofer’s low-pass filter and the tweeter’s high-pass filter are electrically isolated. This configuration is shown in the diagram labeled
Bi-Amp.
STANDARD
Crossover #1:
1. Connect Amplifier Channel 1 + to Crossover WF + IN.
2. Connect Amplifier Channel 1 - to Crossover WF - IN.
3. Connect Crossover WF + and - output to the corresponding + and - on midrange speaker #1.
4. Connect the Red tweeter wire to the output TW + on the Crossover.
5. Connect the Black tweeter wire to the output TW - on the Crossover.
Crossover #2:
1. Connect Amplifier Channel 2 + to Crossover WF + IN.
2. Connect Amplifier Channel 2 - to Crossover WF - IN.
3. Connect Crossover WF + and - output to the corresponding + and - on midrange speaker #2.
4. Connect the Red tweeter wire to the output TW + on the Crossover.
5. Connect the Black tweeter wire to the output TW - on the Crossover.
Bi-Amp
Crossover #1:
1. Connect Amplifier Channel 1 + to Crossover WF + IN.
2. Connect Amplifier Channel 1 - to Crossover WF - IN.
3. Connect Crossover WF + and - output to the corresponding + and - on midrange speaker #1.
4. Connect Amplifier Channel 3 + to Crossover TW + IN.
5. Connect Amplifier Channel 3 - to Crossover TW - IN.
4. Connect the Red tweeter wire to the output TW + on the Crossover.
5. Connect the Black tweeter wire to the output TW - on the Crossover.
Crossover #2:
1. Connect Amplifier Channel 2 + to Crossover WF + IN.
2. Connect Amplifier Channel 2 - to Crossover WF - IN.
3. Connect Crossover WF + and - output to the corresponding + and - on midrange speaker #2.
4. Connect Amplifier Channel 4 + to Crossover TW + IN.
5. Connect Amplifier Channel 4 - to Crossover TW - IN.
4. Connect the Red tweeter wire to the output TW + on the Crossover.
5. Connect the Black tweeter wire to the output TW - on the Crossover.
QS216
Standard Wiring Diagram
C
-
Q
WF + IN + TW WF - IN - TW
Jumpers
N
T
R
O
O
BALANCED
L
TEMPERATURE TECHNOLOGY
WF + IN + TW WF - IN - TW
- WF + - TW +
B
d
1
+
d
0
MID RANGE
A
B
TWEETER
d
0
B
A
-
2
B
d
B
-
4
d
C
B
D
B
d
3
-
-
5
d
B
B
C
CLIP INDICATOR
CLIP INDICATOR
AMBER-
AMBER-
SOFT CLIP
SOFT CLIP
GREEN-
GREEN-
PRE CLIP
RED-
PRE CLIP
RED-
HARD CLIP
HARD CLIP
LEVEL
LEVEL
9V
0.2V 9V
0.2V
BASS BOOST
BASS BOOST
0dB
12dB
0dB
12dB
BASS FREQUENCY MULTIPLIER FREQUENCY
30Hz
80Hz
X15 X1
HIGH PASS
FILTER SLOPE
6dB 12dB
15Hz
1KHz
CHANNELS 1&2
CHANNELS 3&4
HIGH PASS
LOW PASS
(x1) 20Hz 300Hz
40Hz
4.5KHz
(x15) 300Hz 4.5KHz
CROSSOVER
CROSSOVER
LP-BP LP-BP HP-FULL
DUPE HP-FULL
MONO STEREO
(3&4)
INPUT MODE
PROTECT
POWER
4CH 2CH
Bi-Amp Wiring Diagram
WF + IN + TW WF - IN - TW
N
T
R
O
O
C
-
Q
WF + IN + TW WF - IN - TW
WF + IN + TW WF - IN - TW
BALANCED
L
TEMPERATURE TECHNOLOGY
- WF + - TW +
-
+
- WF + - TW +
d
1
+
TWEETER
d
0
B
B
A
B
d
0
A
MID RANGE
-
2
B
d
B
-
4
d
C
B
D
B
d
3
-
-
5
d
B
B
C
WF + IN + TW WF - IN - TW
- WF + - TW +
WF+/WF-
CLIP INDICATOR
CLIP INDICATOR
AMBER-
AMBER-
SOFT CLIP
SOFT CLIP
GREEN-
GREEN-
PRE CLIP
RED-
PRE CLIP
RED-
HARD CLIP
HARD CLIP
LEVEL
LEVEL
9V
0.2V 9V
0.2V
BASS BOOST
BASS BOOST
0dB
12dB
0dB
12dB
BASS FREQUENCY MULTIPLIER FREQUENCY
30Hz
80Hz
X15 X1
HIGH PASS
FILTER SLOPE
6dB 12dB
15Hz
1KHz
CHANNELS 1&2
CHANNELS 3&4
HIGH PASS
LOW PASS
(x1) 20Hz 300Hz
40Hz
4.5KHz
(x15) 300Hz 4.5KHz
CROSSOVER
CROSSOVER
LP-BP LP-BP HP-FULL DUPE HP-FULL
MONO STEREO (3&4)
INPUT MODE
PROTECT
POWER
4CH 2CH
+TW/-TW
+
-
QS216
Tweeter Mounting Options
Flush Mount Method
Mounting Surface
Mounting Brackets
Mounting Bracket Washers
Mounting Bracket Screws
Top Mounted Method
Cup Mounting Screws
Mounting Surface
Surface Angle Mount Method
Cup Mounting Screws
Mounting Surface
Woofer Mounting Options
Mounting With ABS Gasket And Grill Mounting Without Grill
4X 4X
4X 4X
QS216
Speaker, Tweeter and Crossover Placement Options:
Factory sound systems vary greatly. Some systems have coaxials (tweeter fixed in the center of the midrange) in the door, while others have factory component (tweeter is separate from midrange) systems. If your system has the factory component offering then you will want to locate your factory tweeter mounting location and compare it to the diagram below. Some vehicles already have the tweeter in the ideal location, while others often position the tweeter in the top corner of the door pane which is less than ideal. A good rule of thumb is to try and mount the tweeter within 8 inches of the midrange woofer for optimal imaging and tonal balance. When selecting an optimal mounting location, ensure that you are clear of any obstructions within the door. Cutting or drilling into moving parts or electrical accessory wires can be very dangerous and costly.
Woofers should typically be installed in the factory locations. Simply ensure that the new woofer will not obstruct the window or other moving parts in the door.
The Crossover should NEVER be mounted in the shell of the door. This can damage the crossover through vibration and moisture which is NOT covered under warranty. The Crossover can be mounted in a kick panel, under a seat or in the trunk as long as the area is not located near any moving parts in the vehicle which could cut or pull the wires resulting in a short circuit.
All wiring to and from the crossover should avoid all moving parts in the vehicle which could potentially damage the wiring. Take great care when running wires through the door frame and into the door as wires can easily be cut. A rubber grommet should be used on both holes and wire loom should be wrapped around the exposed wires as shown in the diagram below.
Alternate Tweeter Location
Ideal Tweeter Location
Mid Bass
Crossover
Route speaker wires through rubber grommet between door jam and door as shown. Use wire loom to protect the wires.
QS216
www.mbquart.com
car audio
PART#U510
