Maytag RB184PLDV User Manual
Repair
List
NUMBER
Parts
MODEL NUMBER
RB184PLDV
MANUFACTURING
DG44A
REFRIGERATOR
©2005 Maytag Services
When requesting service or ordering parts, always
provide the following information:
- Product Type - Part Number
- Model Number - Part Description
Section: UNIT COMPARTMENT & SYSTEM
1
Model: RB184PLDV_DG44A
MR93F3
Section:
2
UNIT COMPARTMENT & SYSTEM
No. Part No. Description
1 RA1032-1 COMPRESSOR 1
2 17245-4 GROMMET, COMPRESSOR 4
3 62165-1 CLIP Note: CLIP, COMPRESSOR 4
- 414011-1 SCREW, COMPRESSOR RAIL 8
4 66588-1 RELAY, START 1
5 69105-10 OVERLOAD Note: OVERLOAD 1
6 N 60110-2 COVER, WIRE HARNESS 1
- 400017-1 SCREW Note: SCRE W, COVER 12
7 66589-2 COVER, TERMINAL 1
8 65886-1 CLIP, TERMINAL COVER Note: CLIP, TERMINAL COVER 1
9 RA43871-1 CONDENSER 1
- 60408-2 U-NUT, CONDENSER 2
10 N 66228-1 SHROUD, CONDENSER 1
- 400017-1 SCREW Note: SCRE W, CONDENSER & SHROUD 2
11 N 53351-1 GROMMET, CONDENSER TUBING 2
12 N 66493-1 BAFFLE, AIR DIVIDER 1
13 13900 DRIER 1
- 65275-33 SCREW Note: SCREW, MOTOR 3
14 67560-7 MOTOR, CONDENSER FAN 1
15 60485-1 BLADE, CONDENSER FAN 1
16 N 60486-1 WASHER Note: WASHER, FAN BLADE 1
17 19914-1 SPEEDNUT Note: CLIP, FAN BLADE 1
18 66225-1 BRACKET, FAN MOTOR 3
19 56933-1 GROMMET, BRACKET 3
20 N 65889-1 CAPACITOR, RUN 1
- 400017-1 SCREW Note: SCRE W, RUN CAPACITOR 1
21 52656-2 PLUG, COMPRESSOR 4
- 9986-45 SCREW Note: SCREW, COVER 2
22 66338-2 COVER, UNIT COMPARTMENT 1
- 405007-1 SCREW Note: SCREW, TIMER 2
23 68233-2 TIMER, DEFROST 1
24 52890-2 CORD, POWER 1
25 68236-1 PAN, DRAIN 1
26 60555-1 RAIL, DRAIN PAN (RT) 1
27 60555-2 RAIL, DRAIN PAN (LT) 1
- 400017-1 SCREW Note: SCRE W, RAIL 4
28 N 69822-10 EVAPORATOR 1
29 N 60101-9 TRAY, DRIP Note: TRAY, EVAPORATOR 1
30 60108-1 BRACKET, COIL TO TRAY Note: BRACKET, EVAPORATOR 2
31 26397-9 RIVET Note: RIVET, BRACKET 2
32 60106-35 HEATER, DEFROST 1
33 60109-5 SHIELD, DEFROST HEATER 1
34 N 60263-1 CLIP, DEFROST HEATER 1
35 52085-33 THERMOSTAT, DEFROST 1
36 65013-4 HEAT EXCHANGER 1
37 65398-1 COVER, HEAT EXCHANGER 1
- 66223-1 WIRE TIE Not e: WIRE TIE, HE AT EXCHANGER 2
38 N 60068-1 GROMMET, TUBE ENTRY 1
- N 69290-2 WIRE HARNESS, MAIN 1
- N 60177-2 RETAINER, MAIN WIRE HARNESS 2
39 N 60069-1 RETAINER, ENTRY GROMMET 1
- N 108568-1 MANUAL, USE & CARE Note: OWNE R'S GUIDE 1
Series Qty
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available
Section: FRESH FOOD COMPARTMENT
3
Model: RB184PLDV_DG44A
MR93F6
Section:
4
FRESH FOOD COMPARTMENT
No. Part No. Description
1 N 69420-2-WW CHANNEL, MULLION DIVIDER (WHT) 1
2 65275-54 SCREW Note: S CRE W, DIVIDE R CHANNEL 4
3 69617-2 HEATER, DIVIDER CHANNEL 1
- 68577-2 INSULATION Note: INSULATION, HEATER 1
4 N 70123-1 INSULATION Note: INSULATION, DIVIDER CHANNEL 1
- 70117-2 WIRE HARNESS, MULLION 1
5 N 69408-1 TOP, F.F. COMPARTMENT Note: TOP, F.F. COMPARTMENT 1
6 N 69623-1 DEFLECTOR, AIR 1
7 68601-7 CONTROL, TEMPERATURE 1
- 406013-1 SCREW Note: SCREW, CONTROL 2
8 N 60571-59 INSERT, TRIM ESCUTCHEON Note: INSERT, CONTROL ESCUTCHEON 1
- 405012-1 SCREW Note: SCREW, CONTROL COVE R 1
9 N 69421-4 COVER, TEMP. CONT. Note: COVER, TEMPE RA T URE CONTROL 1
- 28013-2 RIVET, AIR TUNNEL Note: CLIP, CONTROL COVER 2
10 69417-5 KNOB, CONTROL Note: KNOB, TEMPERATURE CONTROL 1
11 60147-1 BRACKET, CONTROL Note: BRA CKET, TEMPERATURE CONTROL 1
- 26397-9 RIVET Note: RIVET , BRACKET 2
12 69417-6 KNOB, CONTROL Note: KNOB, FREEZER CONTROL 1
13 405016-35 SCREW Note: SCREW , FREEZER KNOB 1
14 420092-900 WASHER, S P RING Note: WASHER, FREEZER KNOB 1
15 N 69811-3 ORIFICE ASSY., DAMPER Note: ORIFICE, DAMPER ASSY. 1
16 67636-1 CRANK, FRZ. CONTROL 1
17 N 67493-1 COVER, CRANK 1
18 N 69418-3 ROD, FRZ. CONTROL 1
19 65275-13 SCREW Note: SCREW. CONTROL ROD 2
- N 420005-1 WASHER, CONTROL ROD Note: WASHER, CONTR0L ROD 2
20 68974-3 RECEPTACLE, BULB 1
21 68123-1 BULB, LIGHT 1
22 60147-2 BRACKET, LIGHT SOCK ET 1
- 26397-9 RIVET Note: RIVET , BRACKET 2
- N 29675-28 GROUND WIRE Note: GROUND WIRE, LIGHT 1
23 66987-1 SWITCH, LIGHT 1
24 N 54531-8 GROMMET Note: GROMMET, DRAIN TUBE 1
25 65039-1 CAP, DRAIN TUBE 1
26 68664-1 LEG, LEVELING 2
27 N 69876-8 KICKPLATE (WHT) Note: K ICKPLATE 1
- 400017-1 SCREW Note: SCRE W, CLIP 2
28 69940-1 CLIP, KICKPLATE 2
29 69812-1 WHEEL 4
30 29835-2 PIN, WHEEL Note: PIN, WHEEL 4
31 60216-1 CLIP Note: CLIP, PIN 4
32 59101-1 TAPPING PLATE, WHEEL 2
33 N 64965-1 PIN, WHEEL Note: P I N, BRACKET 2
34 N 67530-1 BRACKET, WHEEL 2
35 65275-64 SCREW Note: SCRE W, WHEEL ADJUST ME NT 2
36 69037-1 DISC, CRANK COVER 1
37 68989-1 SEAL, TOP TOWER 1
38 69283-1 SWITCH, HEATER 1
39 N 60583-1 BRACKET, SWI TCH 1
- N 402013-1 SCREW Note: SCREW, BRACKET 1
Series Qty
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available
Section: SHELVES & ACCESSORIES
5
Model: RB184PLDV_DG44A
MR93F9
