Maytag MYS20PN, MYS30PN, MYS40PN, MYS55PN, MYS65PN Brochure

FOR ON-PREMISES LAUNDRY

FOR ON-PREMISES LAUNDRY

DEPENDABLE BY DESIGN

The Maytag® Multi-Load Washer is built to provide the
performance and durability your business needs.

PERFORMANCE

Experience optimal wash performance with

a consistent spin-out system for all your

tough loads.

DURABILITY

With a robust construction and

commercial-grade components – the

Maytag® Multi-Load Washer is designed to

continually handle heavy loads of laundry.

EASE OF USE

Engineered to deliver an optimal user

experience – our intuitively designed

software allows owners and operators to

navigate and manage system controls, and

program cycle settings – with simplicity,

efficiency, and confidence.

SERVICEABILITY

All of our washers are designed with

maintenance in mind: Almost all service

procedures can be performed from the

front and top of the machine, via quick

access panels.

BUILT FOR BUSINESS

The Maytag® Multi-Load Washer can be configured to meet your exact needs. Constructed
in both soft- and rigid-mounts, and available through multiple financing options – it is the
solution you need to power your laundry operations.

®

/™ ©2018 Maytag. All rights reserved.

ON-PREMISES LAUNDRY

RELIABILITY IN EVERY CYCLE

Ruggedly constructed and equipped with intuitive, flexible controls, our washer doesn’t
just perform, it performs efficiently, over and over again.

SPLIT-LID DISPENSER

with an easy-to-flush design and four
compartments: Pre-Wash and Main

10 CHEMICAL

INJECTION PORTS

to customize the best
formula based on
specific washing needs

Wash (powder or liquid); and Bleach
and Fabric Softener (liquid only)

FLEXIBLE
CONTROLS

with an intuitive
screen flow that
has been user-tested
for navigation and
comprehension

CONSISTENT SPIN-OUT
PERFORMANCE

with G-forces of 200 for
rigid-mounts and 400 for
soft-mounts – to achieve max
extraction and help prevent
unbalanced loads

SECURE
DOOR LOCK

with no moving
parts, and an
ergonomic,
solid-steel
door handle

DRIVE SYSTEM
AND WASH UNIT

complete with a 304
stainless-steel drum and
tub, commercial-grade
bearings, a Variable
Frequency Drive, and
commercial-grade motor

ROBUST CONSTRUCTION

to handle tough loads and
extraction forces

THOUGHTFULLY DESIGNED

for easy access and
serviceability using minimal
screws and key locks

®

/™ ©2018 Maytag. All rights reserved.

ON-PREMISES LAUNDRY

EXPERIENCE COMPLETE CONTROL

Equipped with customizable settings designed to increase efficiency – our
machines are built to help keep your operation running at full speed.

PROGRAMMABILITY

Ensure every load is washed the way you want – every time – and optimize your laundry workflow with system configurations that
reinforce timeliness and efficiency.

CYCLE SETTINGS

With the ability to program up to 99 cycles, each with up to 99 phases, you have the flexibility to customize wash cycles, from
formulas to spin time, all to fit your process needs.

MULTILINGUAL LANGUAGE OPTIONS

Users are able to choose from multiple language options to ensure they
can conveniently navigate each machine.

DETERGENT AND SOLUTIONS SETTINGS

Determine which detergents and solutions are used during every cycle – and
program them to release on time, and in correct amounts, with our split-lid,
four-compartment dispenser.

®

/™ ©2018 Maytag. All rights reserved.

CONNECTED FOR EFFICIENCY

Maytag Connect 360°™ Technology* keeps you up to date with the performance of
every machine – to help ensure your operation is running efficiently at all times.

MAYTAG CONNECT 360°™ TECHNOLOGY

With a WiFi-enabled system, Maytag Connect

360o™ Technology* gives facility managers the

ability to know how their washers are performing,

in real-time. Our intuitively designed software

provides diagnostic reports, maintenance

notifications, and software updates – to help keep

each machine working at full capacity.

POWERFUL ONLINE TOOLS

Receive select diagnostics and alerts

for preventative maintenance, and make

program changes remotely – via WiFi – or

onsite with our USB port.

SERVICE NOTIFICATIONS

Receive alerts for service and maintenance

issues – to help identify where the problem exists,

so technicians can come prepared to repair the

washer in timely fashion.

OVER-THE-AIR UPDATES

automatically through the WiFi-enabled

board or with USB port– keeping every

machine constantly updated with the latest

24/7 ACCESS TO INSIGHTS

Conveniently access every machine’s

diagnostic reports – to better understand,

prevent, and solve performance issues, for

*WiFi required. Features subject to change. Details and privacy info at connect360.maytag.com.

Software upgrades can be made

technology from Maytag.

operational efficiency.

®

/™ ©2018 Maytag. All rights reserved.

ON-PREMISES LAUNDRY

SOFT-MOUNT SPECIFICATIONS

FRONT ELEVATION BACK ELEVATION TOP ELEVATIONSIDE ELEVATION

DIAGRAM KEY

DIAGRAM KEY

Control Console

1

Loading Door

2

Electric Connection

3

Hot Water

4

Cold Water

5

Third Water

6

Drain

Steam Connection

8

Soap Dispenser

9

4
5
6

R2 J2 O2

K2 L2

I1

P1

R1

Q1

J1

L1

K1

10

01

8

N2

M2

12

Q2

N1

7

M1

Automatic Liquid

107

OM3

13

11

03

P2

I2

R3

Fuses

13

Soap Manifold

Toe Panel

Electric Disconnect

11

USB

12

14

Stop Switch

15

A B C D E F G H I1 I2 J1 J2 K1 K2 L1 L2 M1 M2 0M3 N1 N2 O1 O2 P1 P2 Q1 Q2 R1 R2 R3

MM 1112 711 720

20S

INCH 43 3/428

MM 1222 794 872 935 1409 110 3 348 420 588 1159 225 1112 10 1 113 7 14 6 10 41 229 90 70 N/A N/A 70 936 502 1146 416 113 3 4 41 115 9 1133

30S

INCH

48 1/831 1/434 3/836 3/455 1/243 3/813 3/416 1/223 1/845 5/88 7/843 3/44 44 3/45 3/441 9 3 1/22 3/

MM 1410 970 901 954 1477 129 0 475 546 657 1347 30 0 12 28 175 13 24 175 1228 270 111 70 63 698 70 109 4 572 133 4 486 1321 511 13 47 132 1

40S

INCH 55 1/238 1/435 1/237 1/258 1/850 3/418 3/421 1/225 7/853 11 3/448 3/86 7/852 1/86 7/848 3/810 5/84 3/82 3/42 1/227 1/22 3/443 1/822 1/252 1/219 1/852 20 1/853 52

MM 1410 970 103 6 1100 16 24 12 90 475 546 657 13 47 300 122 8 17 5 13 24 175 122 8 270 111 70 63 698 70 10 94 572 13 34 486 132 1 5 11 13 47 132 1

55S

INCH 55 1/238 1/440 3/443 1/464 50 3/418 3/421 1/225 7/853 11 3/448 3/86 7/852 1/86 7/848 3/810 5/84 3/82 3/42 1/227 1/22 3/4 43 1/822 1/252 1/219 1/852 20 1/853 52

MM 1410 970 1110 1173 1697 1290 475 546 6 57 1347 300 1228 175 13 24 175 122 8 270 111 70 63 698 70 10 94 572 13 34 486 132 1 5 11 13 47 132 1

65S

INCH 55 1/238 1/443 3/446 1/866 3/450 3/418 3/421 1/225 7/853 11 3/448 3/86 7/852 1/86 7/848 3/810 5/84 3/82 3/42 1/227 1/22 3/4 43 1/822 1/252 1/219 1/852 20 1/853 52

781 1170 993 353 423 502 1048 225 1003 101 1028 146 930 229 90 70 N/A N/A 70 826 419 1035 330 1023 355 1048 1023

28 3/830 3/446 39 1/813 7/816 5/819 3/441 1/48 7/839 1/24 40 1/25 3/436 5/89 3 1/22 3/4N/A N/A 2 3/432 1/216 1/240 3/413 40 1/414 41 1/440 1/

N/A

4

N/A 2 3/436 7/819 3/445 1/816 3/844 5/817 3/845 5/844 5/

Three-Year Limited Warranty on Parts. For the first three ( 3) years from the date of purchase, when this commercial appliance is installed,
maintained, and operated according to the instructions attached to or furnished with the product. Maytag® Commercial Laundry brand of
Whirlpool Corporation (hereafter “Maytag”) will pay for factory-specified parts or original equipment manufacturer parts to correct defects in
materials or workmanship.

Fourth- and Fifth-Year Limited Warranty on Ce rtain Parts. In the four th year and fif th years from the date of purchase, May tag will pay for the
following washer par ts: the outer shell, drum and shaft assembly, inner welded frame, and bearings and seals. Visit maytagcommerciallaundr y.com for
warranty details.

®

/™ ©2018 Maytag. All rights reserved.

4

8

MODEL MYS20PN MYS30PN MYS40PN MYS55PN MYS65PN

MOTOR

Size – HP 1.0 2.0 3.0 4.0 4.0

CAPACITY

Cylinder Volume – cu. ft. (liters) 2.74 ( 78) 4. 86 (13 8 ) 6. 45 (18 3 ) 8.56 (242) 9.76 (276 )

Cylinder Diameter – in. (mm) 20.9 (530) 24.4 (620) 29.5 (750) 29.5 (750) 29.5 (750)

Cylinder Depth – in. (mm) 13. 9 ( 3 52 ) 17. 9 (454) 16 . 2 ( 411 ) 21.6 (548) 24.4 (621)

Dry Load Capacity – lb. (kg) 20 (9) 30 (14) 40 (18 ) 55 (25) 65 (30)

EXTRACT FORCE

Maximum Extract Force (G-force) 400 400 400 400 350

CONNECTIVITY

USB Programmability Yes Yes Yes Yes Yes

Maytag Connect 360°™ Technology* Ready Yes Yes Yes Yes Yes

DIMENSIONS

Depth – in. (mm) 28.4 (721) 34.3 ( 872) 35.5 (901) 40.8 (1,0 37) 43 .7 (1,110 )

Width – in. (mm ) 28.0 (710 ) 31.3 (795) 38.2 (970) 38.2 (970) 38.2 (970)

Height – in. (mm) 4 3 . 8 ( 1 ,112 ) 48.1 (1,222) 55.5 (1,410) 55.5 (1,410) 55.5 (1,410)

Door Opening – in. (mm ) 12. 9 (32 8 ) 16.1 ( 410 ) 18.1 ( 459 ) 18.1 (4 59) 18 .1 (45 9 )

CRATED DIMENSIONS

Width – in. (mm ) 29.8 (756 ) 33 .1 ( 841) 39.5 (1,0 03) 39.5 (1,003) 39.5 (1,00 3 )

Depth – in. (mm) 33.4 (854) 39.8 (1,010 ) 41.0 (1,042) 46 . 4 (1,178 ) 49. 3 (1, 251)

Height – in. (mm) 50.0 (1,270 ) 54.4 (1,381) 61.4 (1, 56 0 ) 61.4 (1,560 ) 61.4 (1,5 60 )

APPROXIMATE WEIGHT

Uncrated – lb. (kg) 415 (18 8 ) 582 (264) 851 ( 3 86) 894 (406) 944 (428)

Crated – lb. (kg) 446 (202) 616 (279) 889 (403) 933 (423) 984 (446)

LOADING QUANTITY

Full Truck (53' / 48') 60 / 54 38 / 34 32 / 28 32 / 28 32 / 28

40' HC Container 42 28 24 22 21

20' Container 18 14 10 10 9

ELECTRICAL CONNECTION OPTIONS (VOLTS/Hz/PHASE)

W = 120 / 60 / 1 (no electrical heating) Yes Yes No No No

T = 208 – 240 / 50 – 60 / 1 (no electrical heating) Yes Yes Yes Yes Yes

S = 220 – 240 / 50 – 60 / 1 (no electrical heating) Yes Yes Yes Yes Yes

V = 208 – 240 / 50 – 60 / 3 Yes Yes Yes Yes Yes

N = 380 – 415 / 50 – 60 / 3 Yes Yes Yes Yes Yes

R = 440 – 480 / 50 – 60 / 3 Yes Yes Yes Yes Yes

WATER HEATING OPTIONS

Hot/Cold Water Connections Only Yes Yes Yes Yes Yes

Electrical Heating (size of heating elements, kW) Yes ( 8 ) Yes (12 ) Yes (16) Yes (18 ) Yes (18 )

Electrical Heating, Optional Alternate Heating Element Size- kW 12 8 N/A N/A N/A

Steam Kit Option N/A N/A Yes Yes Yes

WATER, CHEMICAL DISPENSING, DRAINS

Number of Water Inlets 2 2 2 2 2

Optional Third Water Inlet Yes Yes Yes Yes Yes

Inlet Sizes – in. ( mm) ½ (13 ) ½ (13 ) ½ (13 ) ½ (13 ) ¾ (19 )

Operating Pressure – PSI (bar) 20 – 120 (1-8) 20 – 120 (1-8) 20 – 120 (1-8) 20 – 120 (1-8) 20 – 120 (1-8)

Number of Dispenser Compartments 4 4 4 4 4

External Chemical Connections, Number 10 10 10 10 10

Dump Valve Drain, Size – in. (mm) Yes, 3 (76) Yes, 3 (76) Yes, 3 (76) Yes, 3 (76) Yes, 3 (76)

Second Dump Valve Drain Option No No No Yes Yes

Drain Pump Option Yes Yes Yes No No

SOUND PRESSURE-dbA

*WiFi required. Features subject to change. Details and privacy info at connect360.maytag.com.

See specific instructions for proper installation.
Because of continuous product improvement, Maytag reserves the right to change specifications without notice.

<70 <70 <70 <70 <70

®

/™ ©2018 Maytag. All rights reserved.

ON-PREMISES LAUNDRY

RIGID-MOUNT SPECIFICATIONS

FRONT ELEVATION BACK ELEVATION TOP ELEVATIONSIDE ELEVATION

DIAGRAM KEY

DIAGRAM KEY

Control Console

1

Loading Door

2

Electric Connection

3

Hot Water

4

Cold Water

5

Third Water

6

Drain

Steam Connection

8

Soap Dispenser

9

4
5
6

R2 J2 O2

K2 L2

I1

P1

R1

Q1

J1

L1

K1

10

01

8

N2

M2

12

Q2

N1

7

M1

Automatic Liquid

107

OM3

13

11

03

P2

I2

R3

Fuses

13

Soap Manifold

Toe Panel

Electric Disconnect

11

USB

12

14

Stop Switch

15

A B C D E F G H I1 I2 J1 J2 K1 K2 L1 L2 M1 M2 OM3 N1 N2 O1 O2 P1 P2 Q1 Q2 R1 R2 R3

MM 1112 660 686

20R

INCH 43 1/426 27 30 3/845 5/839 1/814 16 3/417 3/441 1/88 7/839 3/84 40 1/45 3/436 1/26 5/83 3/42 3/4N/A N/A 2 3/832 1/214 1/240 5/811 40 1/812 41 1/240 1/

MM 1222 75 0 724 791 126 4 1108 346 419 543 1156 225 1108 101 113 3 146 1035 2 13 95 70 N/A N/A 70 937 458 114 0 371 113 0 394 115 5 1130

25R

INCH 48 1/829 1/228 1/231 1/849 3/443 5/813 5/816 1/221 3/845 1/28 7/843 5/84 44 5/85 3/440 3/48 3/83 3/42 3/4N/A N/A 2 3/436 7/818 4 4 7/814 5/844 1/215 1/245 1/244 1/

MM 1222 75 0 841 905 1378 1108 346 419 543 1156 225 110 8 101 1133 146 1035 213 95 70 N/A N/A 70 937 458 114 0 371 113 0 394 115 5 1130

30R

INCH 48 1/829 1/233 1/835 5/854 1/443 5/813 5/816 1/221 3/845 1/28 7/843 5/84 44 5/85 3/440 3/48 3/83 3/42 3/4N/A N/A 2 3/436 7/818 4 4 7/814 5/844 1/215 1/245 1/244 1/

MM 1410 889 883 946 1470 1289 467 537 578 13 43 289 124 4 175 1321 175 12 24 283 133 70 45 534 70 10 95 492 13 30 406 1317 429 13 43 1318

40R

INCH 55 1/235 34 3/437 1/457 7/850 3/418 3/821 1/822 3/452 7/811 3/849 6 7/852 6 7/848 3/1611 1/85 1/42 3/41 3/421 2 3/443 1/819 3/852 3/816 5 1 7/816 7/852 7/851 7/

MM 1410 889 10 19 10 83 1607 128 9 467 537 578 134 3 289 1244 175 13 21 175 122 4 283 133 70 45 534 70 109 5 492 133 0 406 1317 42 9 1343 1318

55R

INCH 55 1/235 40 1/842 5/863 1/450 3/418 3/821 1/822 3/452 7/811 3/849 6 7/852 6 7/848 3/1611 1/85 1/42 3/41 3/421 2 3/443 1/819 3/852 3/816 5 1 7/816 7/852 7/851 7/

MM

65R

1410 889 1092 115 6 16 80 128 9 467 5 37 578 133 4 289 1242 17 5 1321 175 1224 283 133 70 45 534 70 10 95 492 133 0 406 1317 429 1343 13 18

INCH 55 1/235 43 45 1/266 1/850 3/418 3/821 1/822 3/452 7/811 3/849 6 7/852 6 7/848 3/1611 1/85 1/42 3/41 3/421 2 3/443 1/819 3/852 3/816 5 1 7/816 7/852 7/851 7/

772 1159 994 356 425 451

Three-Year Limited Warranty on Parts. For the first three ( 3) years from the date of purchase, when this commercial appliance is installed,
maintained, and operated according to the instructions attached to or furnished with the product. Maytag® Commercial Laundry brand of
Whirlpool Corporation (hereafter “Maytag”) will pay for factory-specified parts or original equipment manufacturer parts to correct defects in
materials or workmanship.

Fourth- and Fifth-Year Limited Warranty on Ce rtain Parts. In the four th year and fif th year from the date of purchase, Maytag will pay for the
following washer par ts: the outer shell, drum and shaft assembly, inner welded frame, and bearings and seals. Visit maytagcommerciallaundr y.com
for warranty details.

1045 225 1000 101 1023 146 927 16 8 95 70 N/A N/A 60 826 368 10 32 280 1019 305 1054 1019

8

2

2

8

8

8

®

/™ ©2018 Maytag. All rights reserved.

MODEL MYR20PN MYR25PN MYR30PN MYR40PN MYR55PN MYR65PN

MOTOR

Size – HP 0.5 0.75 1.0 1.5 2.0 2.0

CAPACITY

Cylinder Volume – cu. ft. (liters) 2.74 ( 78) 3.76 (108) 4 .86 (138) 6 .45 (183) 8.56 (242) 9.76 (276 )
Cylinder Diameter – in. (mm) 20.9 (530) 24.4 (620) 24.4 (620 ) 29.5 (750) 29.5 (750) 29.5 (750 )
Cylinder Depth – in. (mm) 13. 9 ( 3 52 ) 13. 9 ( 3 52 ) 17. 9 (454) 16 . 2 ( 411 ) 21.6 (548) 24.4 (621)
Dry Load Capacity – lb. (kg) 20 (9) 2 5 ( 11) 30 (14) 40 (18 ) 55 (25) 65 (30)

EXTRACT FORCE

Maximum Extract Force (G-force) 200 200 200 200 200 200

CONNECTIVITY

USB Programmability Ye s Yes Yes Yes Yes Yes
Maytag Connect 360°™ Technology* Ready Yes Yes Yes Yes Yes Yes

DIMENSIONS

Depth – in. (mm) 27 (686) 28.5 (725) 3 3 .1 ( 84 0 ) 34.8 (883) 40.1 (1, 019) 43 (1092 )
Width – in. (mm ) 26 (660 ) 29.5 (750) 29.5 (750) 35.0 (890) 35.0 (890) 35.0 (890)
Height – in. (mm) 43 . 8 ( 1,112 ) 48.1 (1,222) 48.1 (1,222) 55.5 (1,410) 55.5 (1,410) 55.5 (1,410)
Door Opening – in. (mm ) 12. 9 (32 8 ) 16.1 ( 410 ) 16.1 (410 ) 18.1 (45 9 ) 18 .1 (45 9 ) 18.1 (45 9 )

CRATED DIMENSIONS

Width – in. (mm ) 27. 8 (70 5 ) 31.5 (800) 31.5 (800) 37.0 (940) 37.0 (940) 37.0 (940)
Depth – in. (mm) 33.1 ( 841) 34.6 ( 880) 39.0 (991) 40.5 (1,029 ) 46.0 (1,169) 48.9 (1,242)
Height – in. (mm) 50.0 (1,270) 54.4 (1,381) 54.4 (1,381) 61.4 (1,560) 61.4 (1,560) 61.4 (1,560 )

APPROXIMATE WEIGHT

Uncrated – lb. (kg) 33 4 (151) 447 (203 ) 489 (222) 688 ( 312) 731 (332 ) 764 (347)
Crated – lb. (kg) 36 5 (166 ) 480 ( 218 ) 523 (237) 724 (328) 769 (349) 802 (364)

LOADING QUANTITY

Full Truck (53' / 48') 63 / 57 56 / 50 48 / 42 34 / 30 34 / 30 34 / 30

40' HC Container 45 30 30 24 24 21

20' Container 22 14 14 12 12 10

ELECTRICAL CONNECTION OPTIONS (VOLTS/Hz/PHASE)

W = 120 / 60 / 1 (no electrical heating) Yes Yes Yes No No No
T = 208 – 240 / 50 – 60 / 1 (no electrical heating) Yes Yes Yes Yes Yes Yes
S = 220 – 240 / 50 – 60 / 1 (no electrical heating) Yes Yes Yes Yes Yes Yes
V = 208 – 240 / 50 – 60 / 3 Yes Yes Yes Yes Yes Yes
N = 380 – 415 / 50 – 60 / 3 Yes Yes Yes Yes Yes Yes
R = 440 – 480 / 50 – 60 / 3 Yes Yes Yes Yes Yes Yes

WATER HEATING OPTIONS

Hot/Cold Water Connections Only Yes Yes Yes Yes Yes Yes

Electrical Heating (size of heating elements, kW) Yes ( 8 ) Ye s ( 8 ) Yes (12 ) Yes (16 ) Yes (18) Yes ( 18 )

Electrical Heating, Optional Alternate
Heating Element Size- kW

Steam Kit Option N/A N/A N/A Yes Yes Yes

WATER, CHEMICAL DISPENSING, DRAINS

Number of Water Inlets 2 2 2 2 2 2

Optional Third Water Inlet Yes Yes Yes Yes Yes Yes

Inlet Sizes – in. ( mm) ½ (13 ) ½ (13 ) ½ (13 ) ½ (13 ) ½ (13 ) ¾ (19 )

Operating Pressure – PSI (bar) 20 – 120 (1-8) 20 – 120 (1-8) 20 – 120 (1-8) 20 – 120 (1-8) 20 – 120 (1-8) 20 – 120 (1-8)

Number of Dispenser Compartments 4 4 4 4 4 4

External Chemical Connections, Number 10 10 10 10 10 10

Dump Valve Drain, Size – in. (mm) Yes, 3 (76) Yes, 3 (76) Yes, 3 (76) Yes, 3 (76) Yes, 3 (76) Yes, 3 (76)

Second Dump Valve Drain Option No No No No Ye s Ye s

Drain Pump Option Yes Ye s Ye s Yes No No

SOUND PRESSURE-dbA

*WiFi required. Features subject to change. Details and privacy info at connect360.maytag.com.

See specific instructions for proper installation.
Because of continuous product improvement, Maytag reserves the right to change specifications without notice.

12 12 8 N/A N/A N /A

<70 <70 <70 <70 <70 <70

®

/™ ©2018 Maytag. All rights reserved.

ON-PREMISES LAUNDRY

NOTES

®

/™ ©2018 Maytag. All rights reserved.

®

/™ ©2018 Maytag. All rights reserved.

®

/™ © 2018 Maytag. All rights reserved. Printed in the U.S.A. MY180079 07/18
