Page 1
Page 2
1
N0.
CODE
NAME
MODEL
QTY.
01
GN650TN.86
LOCK
2PCS
02
HGD-72R.01-M05
FRONT PANEL
1PC
03
27F.11
THERMOSTAT
XR60C 115V
1PC
04
S900.01
MAIN SWITCH
DRH-2415-3
1PC
05
HGD-72R.02
SUPPORT OF UNIT BOARD
2PCS
06
HGD-12R.02
FRONT WHEEL
2PCS
07
HGD12R.17
WASHER OF DOWN HINGE
2PCS
08
HGD-72F.01
BODY
1PC
09
HGD-72R.04
UNIT ROOM COVER
1PC
10
HGD-72F.02-M05
LEFT DOOR
1PC
11
HGD-23R.15
GASKET
3PCS
12
U-GNM2100TN.17M05
GLASS DOOR HANDLE
3PCS
13
HGD-23F.02-M05
DOOR/RIGHT
2PCS
14
HGD-12R.04
BACK WHEEL
2PCS
15
HGD-48F.03
CAPACITOR FOR DOOR
3PCS
16
G350.08
K SHAPE CLIP
32PCS
17
HGD-48R.18
SHELF
8PCS
18
G350.06
SHELF SUPPORT
8PCS
19
27R.14
PLUG
LT312/1.5MM 2x3G
1PC
20
HGD-48R.18
LAMP
1PC
21
HGD-72R.05
LAMP COVER
1PC
22
HGD-23R.16
INSIDE LAMP COVER
2PCS
23
HGD-23F.03
LED LIGHT
4PCS
24
HGD-72R.09
SHELF(MIDDLE)
4PCS
SPARE PARTS LIST OF MXM3-72F
Page 3
2
25
D420.08
DOOR UP HINGE
1PAIR
26
HGD-72F.10
FIXED BOARD OF
EVAPORATOR
1PC
27
GN650TN.17
PROBE PADDING
1PC
28
S900.31
SENSOR FIXED CLIP
1PC
29
GN650TN.23
WALL RING
2PCS
30
HGD-23R.12
CIRCLE FAN
2PCS
31
HGD-72F.03
EVAPORATOR
1PC
32
D420.40
WATER PIPER
1PC
33
HGD-72F.04
EVAPORATOR WATER PAN
1PC
34
81F.06
CIRCLE FAN SUPPORT
1PC
35
HGD-72F.08
CIRCLE FAN COVER
1PC
36
27F.05
SUCTION PIPE
Ф9.52
1PC
37
HGD-48F.08
FIXING STRIP
1PC
38
27R.15
CABLE CONNECTOR
1PC
39
HGD-72F.05
EVAPORATE PIPE
Ф8*0.75
1PC
40
S900.40A
WATER BOX
1PC
41
81F.08
COMPRESSOR BEFORE
S/N-4010881
NJ2212GK
1PC
41
81F.08DV
COMPRESSOR AFTER
S/N-4010881
42
GN650BT.10
BASKET GUARD GRILLES
2PCS
43
27R.32
CONDENSER FAN
CA01-01/Ф230
2PCS
44
81F.09
CONDENSER
1PC
45
GN1410TN.14
FILTER DRIER
25g
1PC
46
81F.10
CAPILLARY
Ф1.6*3900
1PC
47
27F.06
DRIER SUPPORT
1PC
48
81F.11
UNIT BOARD
1PC
Page 4
3
49
HGD-12R.15
DOOR HINGE /DOWN
2PCS
50
HGD-12F.08
LED POWER
1PC
51
D420D.14
DRAIN PIPE (B)
1PC
52
D420D.13
DRAIN PIPE (A)
1PC
53
HGD-72F.05
SUPPORT OF
EVAPORATOR(LEFT)
1PC
54
HGD-12R.23
FEET
2PCS
55
HGD-72F.06
SUPPORT OF
EVAPORATOR(LEFT)
1PC
56
HGD-72R.06
SUPPORT OF LAMP COVER
1PC
57
HGD-72R.07
LAMP COVER PROTECTER
1PC
58
HGD-72F.07
UNIT BOARD GUARD GRILLS
1PC
59
27F.03
CONTACTOR
2PCS
60
HGD-72R.08
DOWN HINGE (MIDDLE)
1PC
61
27F.10
DRAIN PIPE HEATER
1PC
62
81F.04
DEFROST HEATING ELEMENT
1PC
63
27F.13
PROTECTOR FOR HEATING
ELEMENT
1PC
