Page 1
Model
MFC100
Food Chopper
MATSUI
Page 2
Mains supply: 230V ~50Hz
Power consumption: 120W
Because we continually strive to improve our products we may
change specifications and designs without prior notice.
Disconnect from the mains before cleaning the food chopper.
Make sure no water enters the inside of the appliance!
Never immerse the chopper or base in water and keep the
electrical contacts dry!
Clean the food chopper exterior with a soft damp cloth or sponge.
Do not use abrasive cleaners or scouring pads which may
damage the finish of the food chopper.
Rinse the bowl under running water.
Only use water and dishwashing liquid to clean the chopper.
Never put any parts in the dishwasher.
Specifications
Cleaning
Safety First
Always remove the mains plug from the socket when you have finished
using the food chopper, before you clean the food chopper, before you
put on or remove the container or if any faults occur.
Wait until the blades have stopped rotating before you remove the lid or
bowl. Never use this chopper without a lid.
Do not put your hands or any utensils such as forks or spoons into the
bowl while the blades are rotating.
Do not immerse in water.
Children should never be allowed to use this food chopper.
Never leave the appliance plugged in when there are young children
around.
Keep the mains lead away from heat source.
Do not use the chopper if the mains lead or the housing are visibly
damaged.
Repairs must only be carried out by qualified electricians.
This food chopper has been designed for domestic quantities only
and is not suitable for commercial use.
This appliance complies with the appropriate EMC safety directives.
Always place the food chopper on a firm and level
surface.
For the sake of the
Environment
Do not simply throw the packaging away. Cardboard packaging can be taken
to your local waste paper collection point. Deposit plastic bags made of
polyethylene (PE) at PE collection points. Please ask you local authority for
the address of your nearest recycling depot.
Do not operate the chopper with a damaged cord
or plug or if the chopper malfunctions or has
been dropped or damaged in any way.
If the power cord becomes damaged, it must be
replaced by your service agent or qualified
person to prevent a hazard. Please contact the
store where you bought your chopper
Food Chopper
MFC100
-2-
Always use extreme care when handling the chopping blades.
Always hold them by the stem of the chopping blade.
MATSUI
Page 3
Using your Food Chopper
Getting to know Your Chopper
Fig. 1
A
Description of the Appliance
A Lid
B Lid Locking Tabs
C Chopping Blade
D LO Pulse
Caution: Never use the chopper without a lid.
Assembling the food chopper
Remove all packing materials before using.
Before using, wash Lid, Blade and Bowl in warm soapy water;
rinse and dry thoroughly.
Place the Base on a dry, stable surface.
Place the Bowl, without Lid and Chopping Blade, on the Base
and turn clockwise to lock into position (fig.2)..
Slide the Chopping Blade down over the shaft, rotating if
necessary to drop into place (fig. 3).
Place the Lid on the Bowl, then turn clockwise into Lid locking
slot (fig. 4).
Note: For your protection, this unit has a safety lock lid. The unit
will not operate unless the Lid and unit dot align. Do not
attempt to operate the unit without locking the Lid in place.
Operating the food chopper
fig. 2 fig. 3
fig. 4
Cut food into approximately 1/2 inch pieces and place up to 2
cups of dry food in the Bowl at a time
.
Place the lid on the Bowl and turn to lock into place.
Plug the cord into an outlet. Press and hold the HI or LO Pulse
button for 5-10 seconds and then release; the motor will stop.
Repeat for a finer consistency.
Hold the unit with one hand placed on top of the lid, to keep the
unit steady.
When finished chopping, allow Chopping Blade to stop rotating
before removing contents.
Remove the Lid and grasp the stem of the Chopping Blade.
Carefully remove it from the Bowl. Remove the Bowl from the
Base and empty the processed food.
Note: Do not use Bowl for storing food..
Important: Do not exceed the maximum
capacity!
Important: Most food requires only 3-10 seconds. Do not
operate longer than 1 minutes.
Troubleshooting
the power is switched on.
the fuse in the plug.
the lid is fitted correctly.
Important: Only add small amounts of liquid into
the chopper, large quantities may leak from the
container.
B
C
H
I
LO
D
E
G
H
F
E HI Pulse
F Bowl
G Drive Shaft
H Base Bowl Tabs
-3-
Important: Blades are sharp, handle with care.
If the food chopper doesn't work please check:
Page 4
Recipes
FOOD
SETTING
QTY TIME
Nuts, coarse chop
LO
1 loosely packed cup
10 seconds
Fresh herbs, coarse chop
LO
1 1/3 cup
30 seconds
Nuts, fine chop
Hard cheeses
Garlic Cloves
Chocolate
Onion
Sun-dried tomatoes in oil
HI
HI
HI
HI
HI
HI
1 1/3 cup
4-6 oz.
1 cup cloves, peeled
1 cup, 1 / 2 inch pieces
1 cup, coarsely chopped
1 cup
15 seconds
30 seconds
20 seconds
30 seconds
30 seconds
20 seconds
1/3 cup fresh cilantro 1 tablespoon fresh lemon juice
1/3 cup fresh oregano 1 /4 teaspoon salt
1 garlic clove, peeled 1/8 teaspoon pepper
1/ 4 cup green onion, sliced 2 teaspoons olive oil
2 (6-ounce) salmon fillets
Combine the first 8 ingredients (excluding olive oil) and salmon fillites in food chopper
bowl and process until well mixed and finely chopped. Brush salmon fillets on both sides
with the herb mixture. Grill salmon over medium-hot coals for 10 minutes or until fish
flakes easily when tested with a fork.
GRILLED HERB CRUSTED SALMON
1 (8-ounce) packaged cream cheese, 1 tablespoon capers
softened. 1 2 cup roasted red pepper,
2 green onions, chopped fresh roasted or jarred
Pat pepper dry. Place all ingredients in food chopper bowl and process until well
combined. Serve with all assortment of crackers.
Make about 1 1 4 cups spread.
ROASTED RED PEPPER SPREAD
-4-
100ml = 0.4 cup = 3.5 oz 200ml = 0.8 cup = 7 oz
250ml = 1 cup = 8.8 oz 400ml = 1.6 cup = 14 oz
500ml = 2 cup = 17.6oz
This symbol on the product or in the instructions means that your electrical and electronic
equipment should be disposed at the end of its life separately from your household waste.
There are separate collection systems for recycling in the EU.
For more information, please contact the local authority or your retailer where you
purchased the product.
