Masterbuilt Manufacturing, Inc.
1 Masterbuilt Court
Columbus, Georgia 31907
Customer Service 1-800-489-1581
ASSEMBLY, CARE & USE MANUAL
WARNING & SAFETY INFORMATION
MODELS 20040311, 20042711 KETTLE CHARCOAL GRILL
THIS PRODUCT IS FOR OUTDOOR USE ONLY
Manual Code:9804100029 101110-JH20
Approximate assembly time: 25 minutes
Tools required for assembly: Adjustable Wrench, Phillips Head Screwdriver.
CARBON MONOXIDE HAZARD
Burning charcoal gives off carbon
monoxide, which has no odor and can
cause death.
DO NOT burn charcoal inside homes,
vehicles, tents, garages or any enclosed
areas.
Use only outdoors where it is well
ventilated.
WARNING
This manual contains important
information necessary for the proper and
safe use of this grill.
Read and follow all warnings and
instructions before using grill and
during use.
Keep this manual for future reference.
Failure to follow these warnings and instructions properly could result in fire or explosion, which could cause
property damage, personal injury, or death.
GENERAL WARNING AND SAFETY INFORMATION
• Keep a fire extinguisher accessible at all times while operating grill.
LIMITED WARRANTY INFORMATION
Masterbuilt warrants its products to be free from defects in material and workmanship under proper assembly,
normal use and recommended care for 90 days from the date of original retail purchase.
• Never leave grill unattended while in use.
• Never use inside an enclosed area such as a patio, garage, building or tent.
• Never use inside a vehicle, not even a recreational vehicle such as a motor home, camper or
truck bed.
• Never operate this grill under any overhead construction such as roof coverings, carports,
awnings or overhangs.
• Maintain a minimum distance of 10 feet from all structures.
• Keep area clear of all combustible materials such as wood, dry plants, grass, brush, paper or
canvas.
• Never operate this grill within 25 feet of flammable liquids.
• Never operate this grill within 10 feet of a gas cylinder.
• Never use this grill as a heater (READ CARBON MONOXIDE HAZARD).
• Use this grill only on a stable, level surface to prevent tipping.
• Use on non-combustible surfaces such as dirt, concrete, brick or rock.
• Keep children and pets away from grill at all times. Do not allow children to use grill.
• Only use charcoal lighting fluid. Never use gasoline, alcohol or other highly volatile fluids to
ignite charcoal. These fluids can explode causing injury or death.
• Grill is HOT while in use and will remain HOT for a period of time afterwards. Do not touch any
part of the grill without wearing protective gloves.
• Never move grill when in use. Allow grill to cool completely before moving or storing.
• Never leave HOT coals or ashes unattended.
Masterbuilt warranty does not cover paint finish as it may burn off during normal use.
Masterbuilt warranty does not cover rust of the unit.
Masterbuilt requires reasonable proof of purchase for warranty claims and suggests that you keep your receipt. Upon
the expiration of such warranty, all such liability shall terminate.
Within the stated warranty period, Masterbuilt, at its discretion, shall repair or replace defective components free of
charge with owner being responsible for shipping. Should Masterbuilt require return of component(s) in question for
inspection Masterbuilt will be responsible for shipping charges to return requested item.
This warranty excludes property damage sustained due to misuse, abuse, accident, damage arising out of
transportation, or damage incurred by commercial use of this product.
This expressed warranty is the sole warranty given by Masterbuilt and is in lieu of all other warranties, expressed or
implied including implied warranty, merchantability, or fitness for a particular purpose.
Neither Masterbuilt nor the retail establishment selling this product, has authority to make any warranties or to promise
remedies in addition to or inconsistent with those stated above.
Masterbuilt’s maximum liability, in any event, shall not exceed the purchase price of the product paid by the original
consumer/ purchaser. Some states do not allow the exclusion or limitation of incidental or consequential damages. In
such a case, the above limitations or exclusions may not be applicable.
California residents only: Not withstanding this limitation of warranty, the following specific restrictions apply; if
service, repair, or replacement of the product is not commercially practical, the retailer selling the product or
Masterbuilt will refund the purchase price paid for the product, less the amount directly attributable to use by the
original buyer prior to the discovery of the nonconformity. Owner may take the product to the retail establishment
selling this product in order to obtain performance under warranty.
This expressed warranty gives you specific legal rights, and you may also have other rights which vary from state to
state.
• Do not store grill with HOT ashes or charcoal inside grill. Store only when fire is completely out
and all surfaces are cold.
• Dispose of cold ashes by placing them in aluminum foil, soaking with water and discarding in a
non-combustible container.
• Accessory attachments not supplied by Masterbuilt Manufacturing, Inc. are not recommended.
• Never use this product for anything other than its intended purpose. This grill is not for
commercial use.
• Always use this grill in accordance with all applicable local, state and federal fire codes.
WARNING
Combustion by-product produced when using this product contains
chemicals known to the State of California to cause birth defects,
other reproductive harm, or cancer.
The materials used in this product may contain lead a chemical known to the State of
California to cause birth defects and other reproductive harm.
1
Go Online www.masterbuilt.com
or complete and return to
Attn: Warranty Registration
Masterbuilt Mfg. Inc.
1 Masterbuilt Court - Columbus, GA 31907
Name:
Address:
City, State/Province, Postal Code:
Phone Number: E-Mail Address:
Model Number: Serial Number:
Purchase Date: Place of Purchase:
14
RECIPES
PARTS LIST
BBQ BURGERS
¼ cup catsup
2 tbsp steak sauce
1 tbsp water
1 tsp sugar
1 tsp vinegar
1 clove garlic, minced
1 lb lean ground beef
¼ tsp salt
¼ tsp black pepper
4 hamburger buns, split and toasted
For sauce, in small saucepan combine catsup, steak sauce,
water, sugar, vinegar, garlic, and if desired, hot pepper
sauce. Bring to boiling, and reduce heat. In a medium bowl
combine ground beef, salt, and pepper. Shape meat mixture
into four ¾ inch thick patties.
Grill patties on the rack of an uncovered grill directly over
medium coals for 14-18 minutes or until meat reaches
160° F degrees internally. Turn patties once during cooking
and brush once or twice with sauce during the last five
minutes. Serve burgers on buns.
TANGY PEANUT-SAUCED RIBS
4 lbs meaty pork spareribs or pork loin back ribs
¼ cup hot water
¼ cup peanut butter
2 tbsp lime juice
2 tbsp sliced green onion
½ tsp grated fresh ginger or ¼ tsp ground ginger
¼ tsp ground red pepper
Trim fat from ribs. Cut ribs into 4-6 serving size pieces.
Place ribs bone side down. Cover and grill for 1 to 1 ¾
hours or until tender. Meanwhile, for sauce, in a small
saucepan gradually stir hot water into peanut butter
(mixture will stiffen at first). Stir in lime juice, green onion,
ginger, and red pepper. Cook and stir over low heat until
heated through. Spoon sauce over ribs.
14
13
10
17
15
1
2
12
16
11
6
9
7
18
5
Optional: few dashes bottled hot pepper sauce, American
cheese slices, lettuce leaves, tomato slices, onion slices,
and pickle slices.
HERB-MUSTARD CHICKEN QUARTERS
2 tbsp creamy Dijon-style mustard blend
1 tbsp snipped fresh parsley
1 tbsp snipped fresh oregano or 1 tsp dried oregano crushed
1 tbsp water
1/8 tsp ground red pepper
3 to 3 ½ lb whole broiler-fryer chicken, cut into quarters
For sauce, in a small bowl combine mustard, parsley, oregano, water and red pepper. Cover and chill until ready to use.
Optional to remove skin.
Place chicken bone side down. Cover and grill for 50-60
minutes or until chicken is no longer pink. (170° F degrees
for breast and 180° F degrees for dark meat). Brush the
pieces with sauce occasionally during the last 10 minutes of
grilling.
CAJUN HALIBUT
Relish
1 can (7 oz) Green Giant Niblets whole kernel corn,
drained
1 medium tomato, chopped
2 medium green onions, chopped (2 tbsp)
1 tablespoon cider vinegar
2 tsps honey
¾ tsp dried oregano leaves
¼ tsp ground red pepper (cayenne)
¼ tsp salt
Fish
4 halibut steaks (about 6 oz each)
2 tbsp Worcestershire sauce
½ tsp coarse ground pepper
¼ tsp dried oregano leaves
In small bowl, mix all relish ingredients; set aside. Brush
halibut with Worcestershire sauce; sprinkle with pepper
and oregano. Cover and grill fish over medium heat 10-15
minutes, turning once or twice, until fish flakes easily with
fork. Serve fish with relish.
3
4
ITEM NO.
1 1 Kettle Lid 10 1 Lid Handle
2 1 Kettle Base 11 2 Wheels
3 2 Short Legs 12 1 Lid Hook
4 2 Long Legs 13 1 Air Damper
5 1 Ash Can 14 1 Logo Plate (pre-assembled)
6 1 Ash Can Handle 15 1 Cooking Grate
7 1 Ash Can Spacer Ring w/Air Dampers 16 1 Charcoal Grate
8 1 Storage Shelf 17 2 Hub Caps
9 1 Base Handle 18 1 Lighting Grate
QUANTITY DESCRIPTION ITEM NO. QUANTITY DESCRIPTION
DO NOT RETURN TO RETAILER
STOP!
For Assembly Assistance, Missing or Damaged Parts
Call: MASTERBUILT Customer Service at 1-800-489-1581 or
EMAIL us at Customerservice@masterbuilt.com.
8
13
2
HARDWARE LIST APPROXIMATE GRILLING TIMES
BEEF SIZE GRILLING TIME INTERNAL TEMP
Steaks
3
/4” (2cm) thick 3 to 4 min. /side med rare 145°F (62°C)
4 to 5 min. /side med 160°F (71°C)
(A)
1/4-20x1/2"
Phillips Head Screw
qty-8
(F)
1/4”
Aluminum Flat Washer
qty-8
(D)
1/4-20
Serrated Flange Nut
qty-14
(B)
3/16-24x3/8"
Phillips Head Screw
qty-4
(G)
5/16”
Aluminum Flat Washer
qty-8
(E)
5/16”
Nylon Hex Lock Nut
qty-2
(C)
3/16”
Hex Lock Nut
qty-4
(H)
Heat Insulation Washer
qty-6
Kabobs 1” (2.5cm) cubes 3 to 4 min. /side 145°-160°F (62-71°C)
Hamburger patties
1
/2” (12mm) thick 3 to 4 min. /side med 160°F (71°C))
Roast, rolled rump 4-6 lbs. (1.8-2.7kg) 18 to 22 min /lb. 145°-160°F (62-71°C)
Sirloin tip 3 1/2--4 lbs. (1.5-1.8kg) 20 to 25 min. /lb. 145°-160°F (62-71°C)
Ribs, back cut in 1-rib portions 10 min. /side med 160°F (71°C)
half, 2-3 lbs. (0.9-1.3kg) 10 to 12 min. /side med rare 145°F (62°C)
Tenderloin whole, 4-6 lbs. (1.8-2.7kg) 12 to 15 min. /side med 160°F (71°C)
PORK SIZE GRILLING TIME INTERNAL TEMP
Chops, bone-in
3
/4” (2cm) thick 3 to 4 min. /side med 160°F (71°C)
Chops, bone-out 1 1/2” (4cm) thick 7 to 8 min. /side med 160°F (71°C)
Tenderloin
1
/2-1 1/2 lbs. (0.2-0.6kg) 15 to 25 min. total med 160°F (71°C)
Ribs (indirect heat) 2-4 lbs. (0.9-1.8kg) 1 1/2 to 2 hrs. med 160°F (71°C)
VENISON SIZE
GRILLING TIME
INTERNAL TEMP
Roast, saddle or leg 6-7 lbs. (2.7-3.1kg) 25 to 30 min. /lb. 145°-160°F (62-71°C)
Steaks
3
/4” (2cm) thick 6 to 7 min. /side med 160°F (71°C)
(I)
Heat Insulation Washer
qty-4
3
(J)
1/4”
Lock Washer
qty-2
(K)
1/4”
Crown Nut
qty-2
CHICKEN SIZE GRILLING TIME INTERNAL TEMP
Broiler fryer (indirect
3-4 lbs. (1.3-1.8kg) 60 to 75 min. in thigh 180°F (82°C)
heat)
Cornish hens 18-24 oz. (510-680g) 45 to 55 min. in thigh 180°F (82°C)
Breast halves, bone-in 6-8 oz. ( 170-226g)
10 to 15 min. /side 170°F (77°C)
each
Breast halves, boneless 4 oz. (113g) each 6 to 8 min. /side 170°F (77°C)
Legs or thighs 4-8 oz. (113-226g) 10 to 15 min. /side 180°F (82°C)
Drumsticks 4 oz. (113g) 8 to 12 min. /side 180°F (82°C)
Wings 2-3 oz. (56-85g) 8 to 12 min. /side 180°F (82°C)
• When outside temperature is cooler than 65°F and/or altitude is above 3,500 feet, additional
cooking time may be required. To insure that meat is completely cooked use a meat
thermometer to test internal temperature.
• Lifting grill lid during cooking process may extend cooking time due to heat loss.
12
FREQUENTLY ASKED QUESTIONS REGARDING CHARCOAL GRILLS
Q. My cooking grate has rust. How do I get rid of it?
Seasoning will prevent rust and food from sticking. Season by applying a thin coating of solid vegetable
shortening over the entire surface. Place cooking grate in grill and allow to heat for 1 to 1-1/2 hours. Grate is
now ready to use. Frequent re-seasoning prevents rusting. If rust occurs, clean with a steel brush. Reapply
vegetable shortening and heat as indicated above.
STOP!
DO NOT RETURN TO RETAILER
For Assembly Assistance, Missing or Damaged Parts
Call: MASTERBUILT Customer Service at 1-800-489-1581 or
EMAIL us at Customerservice@masterbuilt.com.
REPLACEMENT PARTS LIST
Q. When can I put my meat on the grill?
Grill is ready for use when charcoal is ashed over and no visible flames are present.
Q. How long will the briquets stay hot?
If cooking for more than 30 to 40 minutes, additional briquets must be added to the fire. Add 10 or 12 briquets
to the outer edge of the fire immediately after it has been spread. Once these coals become 80% ashed over,
add to the center of the fire as needed to maintain constant cooking temperature. Read all instructions and
warnings on charcoal bag.
Q. Can adjusting the air damper on my grill make a difference?
Dampers on a covered grill are usually left open. This allows oxygen into the grill, increasing the temperature
of the coals. Regulate the grill temperature by adjusting the air dampers. Closing them (either partially or
completely) may help to "cool down" a fire that is too hot.
SAFE STORAGE AND MAINTENANCE
• Inspect hardware and assembled parts on a regular basis to insure grill is in safe working condition.
MODEL# 20040311 MODEL# 20042711
DESCRIPTION
PART NUMBER
9904090025 9904090025 Short Leg Kit
9904090026
9904090027 9904090027 Kettle Lid Kit
9904090028 9904090028 Kettle Base Kit
9904090005 9904090005 Ash Can Handle Kit
990060086 990060086 Storage Shelf
990060087 990060087 Wheel Kit
9904090045 9904090045
9904090046 9904090046 Base Handle Kit
990060095 990060095 Lid Air Damper Kit
990000004 990000004 Revolution Lid Hook Kit
9904100020 9904100022 Logo Plate Kit
990060130 990060130 Ash Can Spacer Ring Kit
9904090026 Long Leg Kit
Lid Handle Kit
• ALWAYS allow grill to cool completely before handling.
• ALWAYS empty ash can after use only when ashes have completely cooled. This will help prolong
ash can life.
• Clean grill, including special surfaces such as cooking grates with mild cleaning agents. Wipe outside of
grill with damp rag. DO NOT use oven cleaner.
• ALWAYS cover and store cold grill in a protected area.
• Indoor storage of grill is permissible only if the charcoal has burned to a complete ash AND is cold.
Remember to remove cold ashes before storing.
• Grill is made of steel and may rust over time. If rusting occurs on outside surfaces, clean area with sand
paper or steel wool, then cover with heat resistant paint, except for stainless steel parts.
• If rusting occurs on the inside surface of grill, clean area with sandpaper or steel wool, then coat with
cooking oil, except for stainless steel parts.
• NEVER USE PAINT ON INSIDE SURFACES OF GRILL.
11
9004100031 9004100031 Charcoal Lighting Grate
909060030 909060030 Ash Can w/o Dampers
909060028 909060028
9004090041 9004090041 Cooking Grate
906060050 906060050 Charcoal Grate
9004090011 9004090011 MB Hub Cap
9804100029 9804100029 Instruction Manual
9904090008 9904090008 Hardware Kit
Air Damper Ring Control Handle
w/Nut
4
ASSEMBLY INSTRUCTIONS
GRILL OPERATION CAUTIONS
Before assembly read instructions
• Avoid bumping or impacting grill.
carefully.
• Keep your hands, hair and face away from burning charcoal.
Tools needed for assembly:
Adjustable Wrench
Phillips Head Screwdriver
B
Assemble grill on a clean, flat surface.
• This grill has an open flame. Be careful of loose hair and clothing during operation. They may catch fire.
• Use protective gloves when handling this grill or working with fire. Use protective gloves or long, sturdy fireplace
tools when adding wood or charcoal.
2
• Do not allow anyone to conduct activities around this grill during or following its use until the unit has cooled. This
STEP 1.
Align ash can spacer ring (7) with holes in kettle
base (2). Insert phillips head screw (B) through
kettle base (2) into ash can spacer ring (7) as
shown. Secure with hex lock nut (C).
grill is HOT during operation and remains HOT for a period of time following its use.
• Fatty foods like hamburgers can have excess grease that can cause flare ups. When cooking fatty foods, use
caution when opening lid and during cooking to avoid being burned.
• Be careful when removing food from grill. All surfaces are HOT and may cause burns. Use protective gloves or
long, sturdy cooking tools.
• Never use glass, plastic or ceramic cookware on this grill.
7
C
• The use of alcohol, prescription or non-prescription drugs may impair the user’s ability to properly assemble or
safely operate this grill.
• Grill lid and base are HOT while in use and during cooling process.
Front of kettle base has
two holes for base handle
D
• Do not remove ash can while ashes and charcoal are HOT.
Assistance may be required for this step.
I
A
Do not tighten screws all the way. Legs
may need to be adjusted when storage
shelf is attached in STEP 3.
G
STEP 2.
Place heat insulation washers (I) on long
• Air dampers are HOT while the grill is in use and during cooling; wear protective gloves when adjusting.
• Never overfill charcoal grate. This can cause serious injury as well as damage the unit.
• Only use charcoal lighting fluid, never use gasoline, alcohol or other highly volatile fluids to ignite the charcoal.
These fluids can explode causing injury or death.
REMINDER: NEVER OPERATE THIS GRILL UNDER ANY OVERHEAD CONSTRUCTION. MAINTAIN A MINIMUM
DISTANCE OF 10 FT (3M) FROM OVERHEAD CONSTRUCTION, WALLS OR RAILS. SEE DIAGRAM BELOW.
legs (4) as shown. Align holes in long legs
with holes in kettle base (2). Insert phillips
head screws (A) through holes on legs.
4
2
When all four legs are attached,
two long legs will be in front with
two short legs in rear.
Secure with aluminum flat washers (G) and
serrated flange nuts (D).
Repeat step with short legs on rear side of
kettle base.
Overhead
Construction
10 ft (3m)
Rails
Wall
5
10 ft (3m)
10
HOW TO USE QUICK START IGNITION SYSTEM
ASSEMBLY INSTRUCTIONS
Read all instructions and warnings on charcoal bag and in manual before using.
1. Load three crumpled sheets of newspaper on top of grate inside ash can. Place ash can
in position below grill.
2. Pile charcoal directly above ash can on charcoal grate. Open holes in bottom air damper,
and ignite paper in ash can.
3. Spread charcoal out on grate and cook in as little as 20 minutes.
• NEVER USE GASOLINE TO LIGHT CHARCOAL.
• OVERFILLING CHARCOAL GRATE CAN CAUSE SERIOUS INJURY AND DAMAGE THE
UNIT.
• NEVER ADD ADDITIONAL LIGHTER FLUID ONCE CHARCOAL HAS IGNITED.
• HOT COALS SHOULD NOT BE LEFT UNATTENDED.
• GRILL IS HOT. USE PROTECTIVE GLOVES AND LONG, STURDY COOKING
UTENSILS.
Carefully reposition grill as shown.
Be careful not to chip/scratch porcelain.
11
17
E
STEP 3.
8
F
K
Note: Shelf may require tilting to place in
position. Legs may need to be spread apart
to place shelf in position.
Insert storage shelf (8) into holes in grill legs
as shown. Secure storage shelf to long legs
using aluminum flat washer (F) and crown
nut (K).
Attach one wheel (11), indented side out, to
each short leg. Then secure wheels and
storage shelf to legs using nylon hex lock
nuts (E).
Snap hubcaps (17) in place as shown.
WARNING
To ensure that it is safe to eat, food must be cooked to the minimum internal
temperatures listed in the table below.
USDA* Safe Minimum Internal Temperatures
Fish 145° F
Pork 160° F
Egg Dishes 160° F
Steaks and Roasts of Beef, Veal or Lamb 145° F
Ground Beef, Veal or Lamb 160° F
Whole Poultry (Turkey, Chicken, Duck, etc.) 165° F
Ground or Pieces Poultry (Chicken Breast, etc.) 165° F
* United States Department of Agriculture
Carefully reposition grill as shown.
9
Tighten all hardware on legs and storage
shelf before continuing.
STEP 4.
Place heat insulation washers (H) on base
handle (9) as shown. Insert screws on base
H
F
J
D
2
handle (9) into kettle base (2). Secure with
aluminum flat washers (F) lock washers (J)
and hex nuts (D).
9
6
ASSEMBLY INSTRUCTIONS
ASSEMBLY INSTRUCTIONS
B
13
C
1
STEP 5.
Note: Do not over tighten. Damper should
move freely.
Attach air damper (13) to kettle lid (1) using
phillips head screw (B) and hex lock nut (C).
6
5
H
F
D
STEP 7.
Place heat insulations washers (H) on ash can
handle as shown. Insert handle (6) into ash can
(5) and secure using aluminum flat washers (F)
and hex nuts (D).
12
10
H
1
F
D
STEP 6.
Place heat insulation washers (H) on lid
handle (10) as shown. Insert screws on lid
handle (10) into holes in kettle lid (1). Add lid
hook (12) then aluminum flat washers (F) and
secure with hex nuts (D).
5
18
Insert lighting grate (18) into assembled ash
1
15
16
2
7
can (5) as shown below.
Slide assembled ash can (5) onto guides of
ash can spacer ring (7).
Place charcoal grate (16) inside kettle base (2).
Rest cooking grate (15) on kettle base (2) as
shown.
Place kettle lid (1) onto kettle base (2).
STEP 8.
GRILL IS READY FOR USE
7
8
Loading...
