Martindale Electric NC1 User Manual

NC1 MAGNETIC

FIELD DETECTOR

Instruction
Manual

ALWAYS READ THESE INSTRUCTIONS

BEFORE PROCEEDING

Thank you for buying one of our products. For

safety and full understanding of its benefits

please read this manual before use. Technical

support is available from 01923 441717 and

[e-mail].

CONTENTS

1 Safety Information 1

1.1 Meaning of Symbols and Markings 1

1.2 Precautions 2

2 Introduction 4

2.1 Inspection 4

2.2 Description 4

2.3 Accessories 4

2.4 Battery Installation 4

3 Operation 5

3.1 NC1 Layout 5

3.2 ON/OFF Button 5

3.3 Low Battery Indication 5

3.4 Torch 6

3.5 Proving check 6

3.6 Testing Considerations 6

3.7 Testing for the Presence of a 6
Magnetic Field

4 Maintenance 7

4.1 Battery Replacement 7

4.2 Cleaning 7

4.3 Repair and Service 8

4.4 Storage Conditions 8

5 Warranty 9

Specifications

1 SAFETY INFORMATION

REMEMBER:

SAFETY IS NO ACCIDENT

These instructions contain both information

and warnings that are necessary for the safe

operation and maintenance of this product. It

is recommended that you read the instructions

carefully and ensure that the contents are fully

understood. Failure to understand and to comply

with the warnings and instructions can result in

serious injury, damage or even death.

Particular attention should be paid to the Warnings,

Precautions and Technical Specifications.

Please keep these instructions for future reference.

Updated instructions and product information are

available at: www.martindale-electric.co.uk

1.1 Meaning of Symbols and Markings

Caution - risk of danger & refer to

instructions

Caution - risk of electric shock

Equipment protected by double or

reinforced insulation (Class II)

CAT IV (Measurement Category IV) is applicable

to test and measuring equipment

connected at the source of the building’s

low-voltage MAINS installation.
For further information on measurement
categories visit
www.martindale-electric.co.uk

Equipment complies with relevant EU

Directives

End of life disposal of this equipment

should be in accordance with relevant

EU Directives

1

1.2 Precautions

This product has been designed with your safety
in mind, but please pay attention to the following
warnings and cautions before use.

Warnings
In order to avoid the danger of electrical shock, it
is important that proper safety measures are taken
when working with voltages exceeding 30V AC
rms, 42V AC peak or 60V DC.

Where applicable other safety measures such as
the use of protective gloves, goggles etc. should be
employed.

The magnetic field detector must only be used by
a skilled and competent person who is familiar with
the relevant regulations, the safety risks involved
and the consequent normal safe working practices,
and under the conditions and for the purposes for
which it has been constructed and specified.

Before each use the magnetic field detector should
be examined for damage, cracks, cuts or scratches.
Do not use if damaged in any way.

Make sure the magnetic field detector is dry, clean
and free from dust, grease and moisture while in
use to avoid the danger from electric shock due to
surface leakage.

Do not use if the battery compartment end cap is
not fitted.

Always keep your fingers behind the finger guard.

Do not use the magnetic field detector during rain

or precipitation.

The magnetic field detector will not detect voltage.

2

Cautions

Avoid severe mechanical shock or vibration and
extreme temperature.

To avoid corrosion from leaking batteries, remove
the batteries when the unit is not in use for an
extended period.

3
