OWNER’S MANUAL

technology. Heat radiates from every square inch of

The top section is mounted on a swivel and is easily

is also heated and designed to receive

with unit).

MODEL CZ3 FRIED FOOD DUMP STATION

Toll Free #: 800-722-3474 Customer Service

Model CZ3

MANUFACTURER'S INTRODUCTION

The Model CZ3 fried food dump station is designed to be dropped into a cutout in a counter. The CZ3A comes with its own castered stand and may be moved or rolled into other locations. The stations feature Marshall's own ThermoGlo heating

the upper flat plate heating surface. This provides for uniform holding temperature and improved moisture retention in the food. The ThermoGlo™ heating system replaces heat lamps and lamp sockets with a robust unbreakable design that blocks grease vapors from entering the wiring compartment. It is very easy to keep clean.

moved to provide easy access to the pans when dumping food. The top section then self centers over the food with a light touch of the handle. The lower section (1) full-size, 4” deep steam table pan or (2) halfsize, 4” deep steam table pans (pans not furnished

Supplier Name: MARSHALL AIR SYSTEMS, INC. Address: 419 Peachtree Drive South Charlotte, NC 28217 Model #: ______________________ Serial #’: ______________________ ______________________ ______________________ Date Received: ______________________ Date Installed: ______________________ Telephone #: 704-525-6230

Fax #: 704-525-6229 Service Referral #: 800-722-3474 Local Service: ______________________ Local Service #: ______________________

GENERAL SPECIFICATIONS

Model: CZ3 Fried Food Dump Station Height: 23.500” Width: 15.500" Depth: 28.500”

Model: CZ3A Fried Food Dump Station W/Stand Height: 56.563” Width: 18.000” Depth: 32.500”

Electrical: 120 VAC, 60Hz, 9.1 amps Power Cord: 8.0 ft 3 wire ground type UL rated Weight: 40 lbs. CZ3 80 lbs. CZ3A Approvals: ETL and NSF

OWNER’S MANUAL

MODEL CZ3 FRIED FOOD DUMP STATION

TABLE OF CONTENTS

INSTALLATION ...............................................................................................................1

DAILY CHECKLIST AND CLEANING GUIDE .................................................................1

MONTHLY MAINTENANCE ............................................................................................1

TROUBLESHOOTING CHART .......................................................................................2

REPLACEMENT PARTS LIST ........................................................................................2

THERMOGLO & HEATED HOLDING CABINET LIMITED WARRANTY.....................3

THERMOGLO & HEATED HOLDING CABINET WARRANTY RETURN

PROCEDURES................................................................................................................4

ILLUSTRATIONS

CZ3, CZ3A REPLACEMENT PARTS .............................................................. FIGURE 1

CZ3 COUNTER TOP INSTALLATION ............................................................. FIGURE 2

CZ3A DUMP STATION..................................................................................... FIGURE 3

WIRING SCHEMATIC (CZ3, CZ3A 120V)...................................................DWG 142500

OWNER’S MANUAL

MODEL CZ3 FRIED FOOD DUMP STATION

INSTALLATION

PRE-INSTALLATION

The Dump Station is packaged to minimize the risk of shipping damage. Immediately upon receipt, make certain to inspect the unit for damage. FILE ALL CLAIMS WITH THE FREIGHT CARRIER.

FINAL INSTALLATION

1. Unpack unit and remove all protective paper or plastic covering from metal parts.

2. Place dump station on stable base.

3. Plug unit into a 120 VAC receptacle.

CAUTION: HEAT GUARD MUST BE INSTALLED ON UNIT DURING OPERATION. HEAT GUARD IS REMOVABLE FOR CLEANING ONLY AND SHOULD BE PUT BACK IN PLACE IMMEDIATELY AFTER CLEANING.

DAILY CHECKLIST AND CLEANING GUIDE

TO USE THE HEAT STATION

1. Turn on the power switch.

2. A red indicator light located above the switch will illuminate, indicating power is going to the heater.

3. The unit is ready to use after a 30-minute preheat period.

NOTE: IT IS NORMAL TO SEE SMOKE COMING FROM HEATER AFTER INITIAL STARTUP. THIS IS CAUSED BY THE INSULATION CURING.

CLEANING CHECKLIST

1. Turn off the unit and allow it to cool for 30 minutes.

2. Pans, lids and wire grates should be removed, washed in the dish machine, rinsed and sanitized.

3. Clean unit and base with a damp cloth and cleaner degreaser. DO NOT IMMERSE UNIT IN WATER! DO NOT USE CAUSTIC CLEANING SOLUTIONS!

4. Allow sufficient drying time before attempting to use.

MONTHLY MAINTENANCE

Follow the daily cleaning checklist; there are no periodic adjustments. There are no userreplacement items at this time.

OWNER’S MANUAL

MODEL CZ3 FRIED FOOD DUMP STATION

TROUBLESHOOTING CHART

** DISASSEMBLING HEATER VOIDS WARRANTY **

Identify problem in the left column and look for probable cause and solution in right hand column. Probable causes listed in the order they are most likely to happen. This sequence should be used to isolate the problem.

PROBLEM PROBABLE CAUSE SOLUTION

1. No Heat/No Indicator Light Unplugged Plug in

Circuit breaker is tripped Reset breaker; call electrician if

tripped twice

Cord/plug defective Replace cord/plug

Defective power switch Replace switch

Defective heating unit Call Marshall Customer Service

Assembly 800-722-3474

2. Heat/No Indicator Light Defective Indicator Light Replace Indicator Light

3. No Heat/Indicator Light Defective heating unit assembly Call Marshall Customer Service 800-722-3474

REPLACEMENT PARTS LIST

ITEM PART NO. DESCRIPTION FIGURE

1 142782 Spacer, Alum. .250” OD x .166” ID x .375” LG 1 2 502968 Screw, #8-32 x .625” (M) TRS PH SS 1 3 142632 Heater Assembly, Top 1, Schematic 4 503148 Boot, Switch Long 1, Schematic 5 500130 Switch, Toggle SPST 1, Schematic 6 143301 Guard, Switch 1 7 143324 Light, Indicator Red, S/N 4627 and After 1, Schematic 500086 Light, Indicator Red, S/N 4626 and Before 1, Schematic 8 502080 Connector, Strain Relief For 14/3 SJTO 1, Schematic 9 143892 Cord, Set 14/3 SJTO 9 Ft. 1, Schematic 10 502492 Element, 300W 220V (89W @ 120V) 1 11 142622 Heat Guard Assembly 1 12 501629 Caster, Without Brake (Grey) 3 13 501630 Caster, With Brake (Grey) 3

OWNER’S MANUAL

MODEL CZ3 FRIED FOOD DUMP STATION

THERMOGLO AND HEATED HOLDING CABINET LIMITED WARRANTY

MARSHALL AIR SYSTEMS, INC., ("Marshall") warrants to the first purchaser ("Purchaser") all new equipment of its manufacture to be free of defects in material and factory workmanship for a period of one year from date of shipment provided that (i) the equipment is installed in the Continental United States, Canada or Hawaii and operated according to the Owner's Manual while located at the original address of installation, (ii) the warranty registration card has been completed and returned to the factory within fifteen (15) days after installation. Marshall's obligation under this warranty is limited to the repair or replacement at its option of any defective part. It is understood that Marshall's obligation with respect to equipment located outside the Continental United States, Canada or Hawaii is limited to replacement parts only.

Because Marshall does not and cannot control Purchaser's installation, use, and maintenance of equipment manufactured by Marshall, this warranty DOES NOT COVER:

1. Any equipment calibration.

2. Switches.

3. Plugs and cords.

4. Blown fuses or bulbs.

5. Any component disassembled in the field or that has broken seals.

6. Any replacement parts used on the equipment which are not purchased from Marshall.

7. Accessory components not installed and/or manufactured by Marshall.

8. Water or grease accumulation, which will cause electrical failures.

9. Labor, except that provided at Marshall’s factory.

10. Damage due to improper or lack of cleaning, abuse and/or service.

SHIPPING DAMAGE must be reported to the carrier and is not covered under this warranty. Marshall will not be liable for damage as a result of improper installation, misuse, abuse, alteration of original design, incorrect voltage, unauthorized service, breakage of fragile items, or any other damage caused by an act out of Marshall's control.

The effect of corrosion, fire, and normal wear on the equipment or component parts is not covered by this warranty. This warranty does not cover cooking performance, smoke capture or holding temperatures which is a function of food types, textures, temperatures, equipment line ups and other variables chosen by the Purchaser and over which Marshall has no control. This warranty does not apply to damage caused by accident or to damage caused by the negligence of Purchaser or the employees of Purchaser or to damage caused by lightning generated electrical current or any other Act of God whatsoever. This warranty does not apply to any equipment bearing a serial number which has been tampered with or altered. Marshall reserves the right to accept or reject any such claim in whole or in part. Marshall will not accept the return of any product without prior written approval from Marshall, and all such approved returns shall be made at Purchaser’s sole expense.

THIS WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING THE IMPLIED WARRANTY OF MERCHANTABILITY AND THE IMPLIED WARRANTY OF FITNESS FOR A PARTICULAR PURPOSE, OR PATENT OR OTHER INTELLECTUAL PROPERTY RIGHT INFRINGEMENT, AND EXCEPT FOR THE EXPRESS WARRANTY CONTAINED HEREIN, THE EQUIPMENT IS SOLD "AS IS." REMEDIES UNDER THIS WARRANTY AND UNDER ANY WARRANTY THAT MAY SURVIVE THE DISCLAIMER OF WARRANTIES ARE LIMITED EXCLUSIVELY TO THOSE REMEDIES DESCRIBED ABOVE. NO OTHER REMEDY IS AVAILABLE UNDER THIS WARRANTY OR ANY OTHER WARRANTY. NEITHER THIS WARRANTY NOR ANY OTHER WARRANTY COVERS, AND MARSHALL WILL NOT BE RESPONSIBLE FOR, ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES, INCLUDING BUT NOT LIMITED TO THE COST OF DISASSEMBLY AND SHIPMENT OF THE EQUIPMENT, PRODUCTION OR PRODUCT LOSSES, INJURY TO OTHER PROPERTY, OR LOST PROFITS RESULTING FROM THE USE OF OR INABILITY TO USE THE PRODUCTS OR FROM THE PRODUCTS BEING INCORPORATED IN OR BECOMING A COMPONENT OF ANY OTHER PRODUCT OR GOODS, OR OTHER LOSSES. WHERE, DUE TO OPERATION OF LAW, CONSEQUENTIAL AND INCIDENTAL DAMAGES CANNOT BE EXCLUDED, THEY ARE EXPRESSLY LIMITED IN AMOUNT TO THE PURCHASE PRICE OF THE EQUIPMENT.

FOR INTERNATIONAL INSTALLATIONS -- PLEASE CONTACT YOUR LOCAL MARSHALL AIR SYSTEMS RECOGNIZED DISTRIBUTOR.

OWNER’S MANUAL

MODEL CZ3 FRIED FOOD DUMP STATION

THERMOGLO AND HEATED HOLDING CABINET WARRANTY

RETURN PROCEDURES:

I. RETURN GOODS AUTHORIZATION FOR PARTS

For prompt warranty parts replacement and RGA processing, please call Marshall's Customer Service Department at 800-722-3474 or 704-525-6230 for assistance. In all cases, a Return Goods Authorization (RGA) number must be issued by Marshall Air Systems, Inc. Unauthorized returns will not be processed.

Option #1: Purchaser to return part(s) prepaid to Factory, Marshall to repair or replace at

own expense if defective, and ship part(s) back to Purchaser prepaid.

Option #2: Marshall to furnish replacement part(s) freight prepaid with or without

requesting return of the defective part(s).

Option #3: Purchaser may obtain replacement part(s) from recognized service agency.

II. NON-WARRANTY RETURNS:

All items returned for customer cancellations are subject to a 20% restocking fee. In the event of an error by Marshall Air Systems, Inc., a Returned Goods Authorization will be issued for full credit. Custom fabricated parts are not returnable.

FOR INTERNATIONAL INSTALLATIONS -- PLEASE CONTACT YOUR LOCAL MARSHALL AIR SYSTEMS RECOGNIZED DISTRIBUTOR.
