Model SR4000 User Guide

AV Surround Receiver

SR4000U DFU cover

Page 5

00.8.6, 0:51 PM

Adobe PageMaker 6.5J/PPC

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,

DO NOT REMOVE COVER (OR BACK)

NO USER-SERVICEABLE PARTS INSIDE

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL

The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of suffi-cient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

WARNING

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,

DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE

BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.

ATTENTION: POUR ÉVITER LES CHOCS ÉLECTRIQUES,

INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE DANS LA

BORNE CORRESPONDANTE DE LA PRISE ET POUSSER

JUSQU’AU FOND.

NOTE TO CATV SYSTEM INSTALLER:

This reminder is provided to call the CATV (Cable-TV) system installer’s attention to Article 820-40 of the NEC, that provides guidelines for proper grounding and, in particular, specified that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as practical.

NOTE:

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by tuning the equipment off and on, the user is encouraged to try to

correct the interference by one or more of the following measures:

-Reorient or relocate the receiving antenna.

-Increase the separation between the equipment and receiver.

-Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

-Consult the dealer or an experienced radio/TV technician for help.

NOTE:

Changes or modifications may cause this unit to fail to comply with Part 15 of the FCC Rules and may void the user’s authority to operate the equipment.

SR4000U DFU cover

Page 6

00.8.6, 0:51 PM

Adobe PageMaker 6.5J/PPC

IMPORTANT SAFETY

INSTRUCTIONS

READ BEFORE OPERATING EQUIPMENT

This product was designed and manufactured to meet strict quality and safety standards. There are, however, some installation and operation precautions which you should be particularly aware of.

1.Read Instructions - All the safety and operating instructions should be read before the appliance is operated.

2.Retain Instructions-The safety and operating instructions should be retained for future reference.

3.Heed Warnings-All warnings on the appliance and in the operating instructions should be adhered to.

4.Follow Instructions-All operating and use instructions should be followed.

5.Cleaning-Unplug this video product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.

6.Attachments-Do not use attachments not recommended by the video product manufacturer as they may cause hazards.

7.Water and Moisture-Do not use this video product near water-for example, near a bath tub, wash bowl, kitchen sink, or laundry tub, in a wet basement, or near a swimming pool, and the like.

8.Accessories-Do not place this video product on an unstable cart, stand, tripod, bracket, or table. The video product may fall, causing serious injury to a child or adult, and serious damage to the appliance. Use only with a cart, stand, tripod, bracket, or table recommended by the manufacturer, or sold with the video product. Any mounting of the appliance should follow the manufacturer’s instructions, and should use a mounting accessory recommended by the manufacturer.

9.Ventilation-Slots and openings in the cabinet are provided for ventilation and to ensure reliable operation of the video product and to protect it from overheating, and these openings must not be blocked or covered. The openings should never be blocked by placing the video product on a bed, sofa, rug, or other similar surface. This video product should never be placed near or over a radiator or heat register. This video product should not be placed in a built-in installation such as a bookcase or rack unless proper ventilation is provided or the manufacturer’s instructions have been adhered to.

10.Power Sources-This video product should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply to your home, consult your appliance dealer or local power company. For video products intended to operate from battery power, or other sources, refer to the operating instructions.

11.Grounding or Polarization-This video product is equipped with a polarized alternating-current line plug (a plug having one blade wider than the other). This plug will fit into the power outlet only one way. This is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug should still fail to fit, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug.

AC POLARIZED PLUG

12.Power-Cord Protection-Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords at plugs, convenience receptacles, and the point where they exit from the appliance.

13.Protective Attachment Plug - The appliance is equipped with an attachment plug having overload protection. This is a safety feature. See Instruction Manual for replacement or resetting of protective device. If replacement of the plug is required, be sure the service technician has used a replacement plug specified by the manufacturer that has the same overload protection as the original plug.

14.Outdoor Antenna Grounding-If an outside antenna or cable system is connected to the video product, be sure the antenna or cable system is grounded so as to provide some protection against voltage surges and built up static charges. Section 810 of the National Electrical Code, ANSI/NFPA No. 70-1984, provides information with respect to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antennadischarge unit, connection to grounding electrodes, and requirements for the grounding electrode. See Figure 1.

15.Lightning-For added protection for this video product receiver during a lightning storm, or when it is left un-attended and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the video product due to lightning and power-line surges.

16.Power Lines-An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.

17.Overloading-Do not overload wall outlets and extension cords as this can result in a risk of fire or electric shock.

18.Object and Liquid Entry-Never push objects of any kind into this video product through openings as they may touch dangerous voltage points or short-out parts that could result in a fire or electric shock. Never spill liquid of any kind on the video product.

i

SR4000U DFU cover

Page 1

00.8.6, 0:51 PM

Adobe PageMaker 6.5J/PPC

19.Servicing-Do not attempt to service this video product yourself as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.

20.Damage Requiring Service-Unplug this video product from the wall outlet and refer servicing to qualified service personnel under the following conditions:

a.When the power-supply cord or plug is damaged.

b.If liquid has been spilled, or objects have fallen into the video product.

c.If the video product has been exposed to rain or water.

d.If the video product does not operate normally by following the operating instructions. Adjust only those controls that are covered by the operating instructions as an improper adjustment of other controls may result in damage and will often require extensive work by a qualified technician to restore the video product to its normal operation.

e.If the video product has been dropped or the cabinet has been damaged.

f.When the video product exhibits a distinct change in performance-this indicates a need for service.

21.Replacement Parts-When replacement parts are required, be sure the service technician has used replacement parts specified by the manufacturer or have the same characteristics as the original part. Unauthorized substitutions may result in fire, electric shock or other hazards.

22.Safety Check-Upon completion of any service or repairs to this video product, ask the service technician to perform safety checks to determine that the video product is in proper operating condition.

23.Carts and Stands-The appliance should be used only with a cart or stand that is recommended by the manufacturer.

24.An appliance and cart combination should be moved with care.

Quick stops, excessive force, and uneven surfaces may cause the appliance and cart combination to overturn.

FIGURE 1

EXAMPLE OF ANTENNA GROUNDING ACCORDING TO

NATIONAL ELECTRICAL CODE INSTRUCTIONS

CONTAINED IN ARTICLE 810 - “RADIO AND TELEVISION EQUIPMENT”

ANTENNA

LEAD IN

WIRE

GROUND

CLAMP

ANTENNA

DISCHARGE UNIT

(NEC SECTION 810-20)

ELECTRIC

SERVICE

GROUNDING CONDUCTORS

EQUIPMENT

(NEC SECTION 810-21)

GROUND CLAMPS

POWER SERVICE GROUNDING ELECTRODE SYSTEM

(NEC ART 250, PART H)

NEC - NATIONAL ELECTRICAL CODE

This Class B digital apparatus meets all requirements of the Canadian Interference - Cansing Equipment Regulations.

Cet appareil numérique de la Classe B respecte toutes les exigences du Règlement sur le matériel brouilleur du Canada.

ii

SR4000U DFU cover

Page 2

00.8.6, 0:51 PM

Adobe PageMaker 6.5J/PPC

ENGLISH ......................................................

1

FRANÇAIS ..................................................

19

iii

SR4000U DFU cover

Page 3

00.8.6, 0:51 PM

Adobe PageMaker 6.5J/PPC

SR4000U(Eng) DFU 00.8.6 0:40 PM 1

General information



Scope of supply ...............................................................................

1

Maintenance ....................................................................................

1

Setup ...............................................................................................

1

Environmental information...............................................................

1

Trademark acknowledgment ...........................................................

1

Controls...............................................................................................

2

Remote control



Remote control usage .....................................................................

3

Remote control buttons ...................................................................

4

Programming the universal remote control .....................................

5

Connectors..........................................................................................

6

Connections



Audio connections ...........................................................................

7

Digital Audio connections ................................................................

7

Video connections ...........................................................................

8

Mains ...............................................................................................

9

Speaker connections .......................................................................

9

Antenna connections .......................................................................

9

System setup



Positioning of the speakers ...........................................................

10

Speaker setup and testing.............................................................

10

Power handling..............................................................................

10

Headphones ..................................................................................

10

Display...............................................................................................

11

Menus



Receiver menu...............................................................................

12

Source selection



INPUT SELECTOR........................................................................

13

6 CH input selection ......................................................................

13

Reassigning a source selection.....................................................

13

Using one source selection for two or more appliances ...............

13

Playback, recording



Playing a source ............................................................................

14

Adjusting the sound .......................................................................

14

Recording from a source ...............................................................

14

Recording from the digital output ..................................................

14

Surround sound



About surround sound ...................................................................

15

Switching surround sound .............................................................

15

Surround sound settings................................................................

15

Tuner



Tuning to radio stations .................................................................

16

Switching FM sensitivity ................................................................

16

Storing radio stations.....................................................................

16

Tuning to stored radio stations ......................................................

17

Resorting stored radio station........................................................

17

Naming radio stations....................................................................

17

Clearing station names..................................................................

17

Technical data



Receiver.........................................................................................

18

Troubleshooting



Warning .........................................................................................

19

Troubleshooting .............................................................................

19

GENERAL INFORMATION

Scope of supply

This receiver is supplied including:

a remote control

2 batteries for the remote control, size AA

a loop antenna

a wire antenna

this instruction booklet

Maintenance

Clean the receiver with a soft, slightly dampened, lint-free

cloth. Do not use any cleaning agents as they may have a

corrosive effect.

Do not expose the receiver to humidity, rain, sand or excessive heat (caused by heating equipment or direct sunlight).

Setup

If you have stacked the components of your system, the receiver must be on top. Place the receiver on a flat, hard, stabile surface. Do not cover any vents and leave 50 cm above and 10 cm left and right of the receiver free for ventilation.

For good reception the loop antenna should not be placed on top of, or beneath VCRs, CD recorders, DVD players, TVs and other radiation sources.

Environmental information

All redundant packing material has been omitted. We have done our utmost to make the packaging easily separable into three mono materials: cardboard (box), polystyrene foam (buffer) and polyethylene (bags, protective foam sheet).

Your set consists of materials which can be recycled if disassembled by a specialized company. Please observe the local regulations regarding the disposal of packing materials, exhausted batteries and old equipment.

Trademark acknowledgment

Manufactured under license from Dolby Laboratories. “DOLBY”, “DOLBY DIGITAL”, “PRO LOGIC” and the double- D symbol 2are trademarks of Dolby Laboratories. Confidential unpublished works. © 1992–1997 Dolby Laboratories. All rights reserved.

ENGLISH

1

SR4000U(Eng) DFU 00.8.6 0:40 PM 2



















ENGLISH

CONTROLS



















q

w

er

t







y

u





























AV SURROUND RECEIVER SR4000

























3D SURROUND

HALL









INPUT SELECTOR

VOLUME



























STANDBY













PHONO DVD











































TUNER











POWER ON/OFF



































CD























CDR/























TAPE























TV























VCR

























SAT











SURROUND

SURR.MODE

BAND

SENS.

PREV

NEXT

FRONT AV



i





PHONES



















VIDEO

L AUDIO R



































BASS

TREBLE







ON/OFF

3D SURROUND

NAME/FREQUENCY

DISPLAY

MENU

ENTER/OK

LOUDNESS



















TUNER PRESET/























MENU NAVIGATOR















@3@2

@0!8!6!4!3 !1!0 o











@1

!9 !7!5



!2





qPOWER ON/OFF..............

Switches the receiver on and



off.

w..........................................

Sensor for the infrared remote



control.

e3D SURROUND ...............

Control light for virtual 3D



surround.

rHALL ................................

Control light for HALL.

t..........................................

Display

yINPUT SELECTOR ..........

Selects the different audio and



video connectors.

uVOLUME ..........................

Increases and decreases the



volume level.

iFRONT AV .......................

Selects the FRONT AV input.

oTREBLE ...........................

Adjusts the treble when used in



combination with VOLUME.

!0BASS................................

Adjusts the bass when used in



combination with VOLUME.

!1LOUDNESS......................

Switches LOUDNESS on and



off.

!2NEXT ...........................

TUNER : searches radio



stations.



MENU : switches to the next



menu level.

!3ENTER / OK .....................

Confirms selected menu values.

!4TUNER PRESET / MENU NAVIGATOR



TUNER : switches to the next



and previous stored radio



station.



MENU : moves upwards and



downwards.

!5PREV. ...........................

TUNER: searches radio stations.



MENU: switches to the previous



menu level.

!6MENU ...............................

Switches the menu on and off.

!7SENS. ...............................

Switches between low and high



tuner sensitivity

!8DISPLAY ..........................

Switches the brightness of the



display.

!9BAND ...............................

Switches the wavebands of the



tuner.

@0NAME/FREQUENCY........

Switches between name and



frequency of the display.

@1SURR. MODE ...................

Switches through the different



surround effects.

@23D SURROUND ...............

Switches virtual 3D surround on



and off.

@3SURROUND ON/OFF .............

Switches the surround sound on



and off.

2

SR4000U(Eng) DFU 00.8.6 0:40 PM 3

Remote control usage

Open the battery

compartment of the remote control and insert 2 alkaline batteries, type

AA (R06, UM-3).

Remove batteries if they are flat or if the remote control is not going to be used for a long time.

Batteries contain chemical substances, so they should be disposed of properly.

The buttons on the remote control work the same way as the corresponding ones on the receiver.

Important!

You have to press a source button for longer than 2 seconds to switch the sound source on the receiver. Pressing a source button for less than 2 seconds will only switch the remote control to use the commands for the selected product.

The remote control remains tuned to the selected source until another source button on the remote control is pressed.

This enables you to operate additional sources (i. e. winding a tape) without changing the source on the receiver.

This button is invalid.

REMOTE CONTROL

ENGLISH

MUTE

PHONO TUNER CD CDR/TAPE

TV VCR SAT DVD

1 2 3

4 5 6

7 8 9

CABLE BOX

0

MENU

OK

VOL TV VOL

+







+









-

NEWS T/A

-







CHANNEL/TRACK

LOUDNESS

SOUND

DVD REC

CANCEL

FR.D.

INDEX

AUDIO







T-C

DISC



NIGHT

3D SURR.

SURR.ON/OFF

SUB WOOFER



REAR

SURR.MODE

++

TEST TONE

CHANNEL

SYSTEM REMOTE CONTROLLER

RC4000SR

3

SR4000U(Eng) DFU 00.8.6 0:40 PM 4

ENGLISH

REMOTE CONTROL

Remote control buttons



MUTE

Mutes the sound of the receiver.







.....................................

Switches the receiver to





standby.

PHONO, TUNER, CD,



CDR/TAPE, TV,



VCR,SAT, DVD .....................

Switches the remote control to





the commands of the different





products. Selects the sources if





pressed longer than 2 seconds.





SAT only works with digital





satellite receivers.

1–0.........................................

Keys in numbers for tracks,





stations or frequencies.





Numbers consisting of two





figures must be keyed in within





2 seconds.

CABLE BOX ..........................

(USA only) Switches the remote





control to the cable box codes.

MENU ....................................

Switches the menu on and off.

OK..........................................

Confirms menu options.

Arrow buttons ........................

TUNER: Moves in the menus.





Right/left arrows are tuning





up/down.





CD,CDR: Left/right arrows are





searching backwards / forwards,





up/down arrows are selecting





the next/previous track.

+ VOL ...................................

Increases the receiver volume.

– VOL ....................................

Decreases the receiver volume.

i NEWS T/A.............................

TUNER: Without function.





TV: Switches teletext on and off.





SAT: Switches the information text





on and off.



+ TV VOL ..........................

Increases the TV volume.





CD, CDR, VCR, DVD: Starts





playback.



– TV VOL ..........................

Decreases the TV volume.





CD, CDR, VCR, DVD: Stops





playback.



CHANNEL/TRACK ........

Selects the previous preset





tuner station.





VCR: Rewinds the tape.





CD, CDR, DVD: Selects the





previous track.





TV: Selects the previous channel.



CHANNEL/TRACK ........

Selects the next preset tuner





station.





VCR: Fast forwards the tape.





CD, CDR, DVD: Selects the





next track.





TV: Selects the next channel

LOUDNESS ...........................

Switches LOUDNESS on and





off.

SOUND..................................

Scrolls through the different





smart sounds.

REC, DVD AUDIO .................

CDR, VCR: Starts recording.



DVD: Switches audio tracks.

CANCEL, DVD ..................

CD, CDR, SAT, VCR: Clears a



program, cancels selections.



DVD: Switches the view angle.

FR.D., DVD ....................

TUNER: Switches to



FREQUENCY DIRECT.



CD, CDR, VCR, DVD: Pauses



playback.

INDEX, DVD T-C ...................

VCR: Switches the index search



on and off.



SAT: Switches the themes on



and off.



DVD: Switches between title



and chapter.

DISC .....................................

CD-, CDR-, DVD-Changers:



Switches to the next disc.

NIGHT....................................

Switches NIGHT MODE on and



off.

3D SURR...............................

Switches virtual 3D surround on



and off.

SURR. ON/OFF.....................

Switches SURROUND SOUND on



and off.

+/-SUBWOOFER...........

Increases/decreases the



subwoofer volume.

+/-REAR ........................

Increases/decreases the volume



of the rear speakers. While test



tone is on, the volume of the



speakers you are hearing can



be increased/decreased with



these buttons.

SURR. MODE........................

Scrolls through the different



surround modes.

TEST TONE ..........................

Switches the test tone on and



off. While test tone is on, the



volume of the speakers you are



hearing can be



increased/decreased with



+/-REAR.

4

SR4000U(Eng) DFU 00.8.6 0:40 PM 5

Programming the universal remote control

You can identify the universal remote control by the inscription Multibrand / Universal.

The universal remote control must be programmed to use the codes for your appliances of different brands. This is done by keying in a 4-digit code or by scanning the codes until the correct one is found. We recommend to using the 4-digit code. This method is faster and more reliable. The code scanning method should be used only if you cannot find the code for one of your appliances. The codes are listed at the end of this book.

Important!

Use the remote control buttons for programming, not the buttons of the receiver or other appliances.

Programming with the 4-digit code

1Keep the source button for the appliance which should be controlled and pressed for 3 seconds.

2Key in the 4-digit code for the appliance (codetable at the end of the booklet).

Notes: – If more than 4 digits are entered, the remote control will recognize only the ones keyed in first.

If you do not key in a code within 30 seconds the remote control will switch off the programming function without changing the code.

To program a new appliance, simply overwrite the old code by entering a new one.

Scanning the codetable

1Switch on the appliance which should be controlled.

2Keep the source button for the appliance which should be controlled and pressed for 3 seconds.

3Press and release again.

The remote control sends the codes for channel up or standby (depending on the selected source) for one brand after the other.

4As soon as the appliance reacts – switches to the next channel or to standby – press to confirm the code.

The identified code will be used.

If the set does not react within 2 minutes, the code for this appliance is not stored in the remote control. The code of the remote control will remain unchanged.

Note: When taking out the batteries of the remote control for more than 1 minute the codes must be reprogrammed.

REMOTE CONTROL

Once you have found and tested the codes for your various appliances, you may want to write them down here.

PHONO........................................

CD................................................

CDR/TAPE...................................

TV ................................................

VCR .............................................

SAT..............................................

DVD .............................................

CABLE BOX ................................

Resetting the remote control

1Keep one of the source buttons and pressed for 3 seconds.

2Key in the 3-digit code 981.

The remote control is now reset to all its original Marantz codes.

ENGLISH

5

SR4000U(Eng) DFU 00.8.6

0:40 PM

6



















ENGLISH

CONNECTORS



























!8!9@9@2@3@5@7 r



e

#1#0





!7



@0@1@4@6 @8







































































AV SURROUND RECEIVER SR4000





PHONO































GND























STANDBY











AM LOOP

















FRONT























CENTER

R

L

SPEAKERS

POWER ON/OFF











ANTENNA

















DIGITAL AUDIO





FM 300Ω





REMOTE





EACH SPEAKER























CONT.













IN/OUT





















AC OUTLET











6 CHANNEL /DVD



VIDEO



SUB WOOFER





120W/1A MAX.SWITCHED











INPUT

DVD

MON



VCR

SAT



PRE - OUT





120V 60HZ































COAX 1

















SURROUND SPEAKERS









IN

CENTER

SUB - IN

OUT

IN

OUT

IN















WOOFER





AUDIO



CENTER

EACH SPEAKER





































COAX 2

SURR.

FRONT PHONO

TV



VCR

SAT

CD

CDR / TAPE PRE - OUT









PHONES





IN



L

















VIDEO

L AUDIO R





































COAX































OUT



































R IN

IN

IN

OUT

IN

IN

IN OUT













!6



!4!2!0i y







w

q



















!5



!3!1o u



t









Connectors







Connectors name



Connect to:





6.3 mm headphone socket

q PHONES

A headphone with a 6.3 mm plug.

at the front











Audio and video inputs

w FRONT AV

Audio and video out sockets of appliances such as video cameras

at the front



and game consoles.







FRONT SPEAKERS

e R, L

Right and left front speaker.









r CENTER

Center speaker.







SURROUND SPEAKERS

t R, L

Right and left surround speaker.







AUDIO IN/OUT

u CDR/TAPE OUT

Input of a CD recorder or a tape deck.









i CDR/TAPE IN

Output of a CD recorder or a tape deck.









o CD IN

Output of a CD player.









!0SAT IN

Output of a satellite system.









!1VCR OUT

Input of a video recorder.









!2VCR IN

Output of a video recorder.









!3TV IN

Output of a TV.









!4PHONO IN

Output of a turntable with MM coil.









!9PHONO GND

Ground cable of a turntable.







DIGITAL AUDIO IN/OUT

!5COAX OUT

Coaxial input of digital appliances such as CD recorders or MD





recorders.









!6COAX 2 IN

Coaxial output of digital appliances.









!7COAX 1 IN

Coaxial output of digital appliances.









!8OPTICAL IN

Optical output of digital appliances such as DVD players, CD players,





CD recorders or MD players.





6-channel input

@96 CHANNEL/DVD INPUT 6-channel output of appliances such as DVD or Laserdisc players.







VIDEO IN/OUT

@0DVD IN

Output of a DVD player.









@1MON OUT

Input of a monitor (e. g. the TV).









@3VCR IN

Output of a video recorder.









@4VCR OUT

Input of a video recorder (for recording).









@6SAT IN

Output of a satellite system..







Antenna connectors

@2AM LOOP

Frame antenna supplied.









@5FM 300 Ω

Wire antenna supplied or exterior antenna.







Preamplified outputs

y CENTER PRE-OUT

Input of a amplifier of center sperker.

@7SUBWOOFER PRE-OUT Input of a powered subwoofer.

Remote control bus

@8REMOTE CONT.

Connect to a component equipped with MARANTZ remote control jack

Mains outlets

#0AC OUTLET

Supplies same voltage as mains. Up to 100 W total permitted load.







Mains lead

#1

After all other connections have been made, connect the





mains lead to the wall socket.

6

SR4000U(Eng) DFU 00.8.6 0:41 PM 7

CONNECTIONS

Audio connections

MONITOR / TV

DVD PLAYER

(6 Channel Output)

PHONO

GND

DIGITAL AUDIO

IN/OUT

COAX 1

IN

COAX 2

IN

COAX

OUT



There are analogue and digital connectors available on some



appliances. If possible use the digital connection; usually this



will result in better sound quality. See “Reassigning a source



selection” on how to use the digital connectors of the



receiver.

TURN TABLE

Because of a different kind of output signal, the use of Dolby

Digital Laserdisc requires an optional AC-3 RF demodulator.







AM LOOP

















FRONT















CENTER

R

L

SPEAKERS





ANTENNA















FM 300Ω





REMOTE





EACH SPEAKER





































CONT.



























AC OUTLET









VIDEO



SUB WOOFER





120W/1A MAX.SWITCHED





DVD

MON



VCR

SAT



PRE - OUT





120V 60HZ















CENTER

SUB -

IN

OUT

IN

OUT

IN





SURROUND SPEAKERS



WOOFER





AUDIO



CENTER

EACH SPEAKER





















SURR.

FRONT

PHONO

TV



VCR

SAT

CD

CDR / TAPE PRE - OUT







L

CD RECORDER

IN

OUT

VCR

AUDIO OUT

AUDIO IN

CD PLAYER

SAT RECEIVER

Digital Audio connections

DVD PLAYER



























(6 Channel Output)



























PHONO



























GND































AM LOOP





















FRONT



















CENTER

R

L

SPEAKERS



ANTENNA













DIGITAL AUDIO

FM 300Ω







REMOTE







EACH SPEAKER

















CONT.







IN/OUT

























AC OUTLET



6 CHANNEL/DVD





VIDEO





SUB WOOFER









120W/1A MAX.SWITCHED



INPUT

DVD

MON

VCR



SAT

PRE - OUT









120V 60HZ

















COAX 1





















SURROUND SPEAKERS

IN

CENTER SUB -

IN

OUT

IN

OUT

IN











WOOFER







AUDIO







CENTER

EACH SPEAKER

























COAX 2

SURR. FRONT

PHONO

TV

VCR



SAT

CD

CDR /TAPE

PRE - OUT







IN



L

















































COAX



























OUT































R IN

IN

IN

OUT

IN

IN

IN

OUT









CD PLAYER

CD RECORDER

































7













ENGLISH

SR4000U(Eng) DFU 00.8.6 0:41 PM 8

ENGLISH

CONNECTIONS

Video connections

DVD PLAYER











MONITOR / TV

























PHONO





























GND



































AM LOOP





















FRONT





















CENTER

R

L

SPEAKERS





ANTENNA













DIGITAL AUDIO



FM 300Ω







REMOTE







EACH SPEAKER



















CONT.







IN/OUT



























AC OUTLET



6 CHANNEL / DVD





VIDEO





SUB WOOFER









120W/1A MAX.SWITCHED



INPUT



DVD

MON

VCR



SAT



PRE - OUT









120V 60HZ





















COAX 1























SURROUND SPEAKERS

IN

CENTER

SUB -

IN

OUT

IN

OUT

IN













WOOFER







AUDIO







CENTER

EACH SPEAKER



























COAX 2

SURR.

FRONT

PHONO

TV

VCR



SAT

CD

CDR / TAPE

PRE - OUT







IN





L



















































COAX





























OUT



































R IN

IN

IN

OUT

IN

IN

IN

OUT









VCR





























VIDEO OUT





























VIDEO IN

























































SAT RECEIVER

8

SR4000U(Eng) DFU 00.8.6 0:41 PM 9

CONNECTIONS

Mains

The type plate is located on the rear of the receiver.

1Check whether the mains voltage as shown on the type plate corresponds to your local mains voltage. If it does not, consult your dealer or service organization.

2Connect the mains cable to the wall socket.

To disconnect the set from the mains completely, remove the mains plug from the wall socket.

Antenna connections

AM antenna

The loop antenna supplied is for indoor use only. Position the antenna as far away as possible from the receiver, the TV, the cables, a DVD player, a VCR and other radiation sources.

1Fit the plug of the frame antenna to AM LOOP as shown below.

2Turn the antenna for optimum reception.

Speaker connections

Some of the speaker connections on the receiver are screw connectors and some are click-fit connectors. Use them as shown below.



7

mm









1



2

3

8 mm

1

2

3

1Always connect the coloured (or marked) wire to the red terminal and the black (or unmarked) wire to the black terminal.

2Connect:

Left front speaker to L

Right front speaker to R

Center speaker to CENTER

Left surround speaker to SURROUND L

Right surround speaker to SURROUND R

ANTENNA

AM LO

OP



FM antenna

The wire antenna supplied can only be used to receive nearby stations. For better reception we recommend using a cable antenna system or an outdoor antenna.

1Open the FM 300 Ω click-fits by pushing the lever down as shown below.

2Insert each wire of the antenna into one hole.

3Close the click-fits using the lever.

4Move the antenna in different positions for optimum reception.

8 mm

1

2

3

The unit complies with the FCC-Rules, Part 15. Operation is subject to the following two conditions:

1.This device may not cause harmful interference, and

2.This device must accept any interference received, including interference that may cause undesired

operation.

ENGLISH

9

SR4000U(Eng) DFU 00.8.6 0:41 PM 10

ENGLISH

SYSTEM SETUP

SUBWOOFER

FRONT

LEFT

SURROUND

(REAR)

LEFT

CENTER

FRONT

RIGHT

SURROUND

(REAR)

RIGHT

Positioning of the speakers

General hints for positioning

Avoid positioning the speakers in a corner or on the floor as this will boost the bass tones too much. Placing the speakers behind curtains, furniture, etc. will reduce the treble response. The listener should always be able to ”see” the speakers.

Each room has different acoustic characteristics and the positioning possibilities are often limited. You can find the best position for your speakers by referring to the picture above.

As a minimum we recommend 5 speakers (2 front, a center, 2 surround) for good surround sound. It is possible to reproduce some kind of surround sound with fewer speakers. This is done by redirecting the signals which are foreseen for the missing speakers to the existing ones. See “Menus” on how to set up the receiver correctly for the number and size of the speakers used.

Positioning the front speakers

The front speakers should be placed right and left in front of the listening position like usual stereo speakers.

Positioning the center speaker

The center speaker should be placed in the center between the two front speakers, e. g. underneath or on top of the TV. The best height for the center speaker is the height of the listener’s ears (while seated).

Positioning the surround speakers

The surround speakers should face each other and be in line with, or slightly behind the listener.

Positioning the subwoofer

A subwoofer can be used to enhance the bass performance of your system dramatically. The subwoofer can be positioned anywhere in the room, because it is not possible to locate the source of deep tones. Nevertheless, you should not place the subwoofer in the middle of a room, since the bass could be severely weakened. Do not place any object on the subwoofer.

Speaker setup and testing

The relative volume of the speakers must be adjusted for optimal surround sound. You should be at your usual listening position when adjusting the speaker volume. See “Receiver menus” on how to set up the receiver for the used speakers.

1Press POWER ON / OFF to switch on the receiver.

2Press TEST TONE on the remote control.

A test tone coming from the different speakers, except the subwoofer, is heard.

3Press +/-REAR on the remote control to increase/decrease the volume of the actual speaker. The best result is achieved when all speakers have equal volume in the listening position.

4Press TEST TONE on the remote control.

The test tone stops.

Note: If you are not completely satisfied with the volume settings, we recommend making minor adjustments to them during surround sound playback.

Power handling

If the receiver is used at very high power, it can produce distortions which may seriously damage your speakers.

If distortions occur, reduce the volume and the tone controls to a level where the sound is acceptable again.

To avoid overheating of the set a safety circuit has been built in. Therefore your set may disconnect under extreme conditions. If this happens, switch the set off and let it cool down before reusing it.

Headphones

Connecting headphones to PHONES will switch off the speakers. The receiver switches to and surround sound will be reduced to a stereo signal which is reproducible by standard headphones.

Disconnecting the headphones switches on the speakers again. If you wish to enjoy surround sound again, switch the receiver back to surround sound.

10

SR4000U(Eng) DFU 00.8.6 0:41 PM 11

Display

The display of the receiver is divided into 3 sections, which are to be used for the following:

Speaker diagram

A rectangle with a letter in it shows that a speaker has been selected in the setup menu. However, the subwoofer indicator will only light when a subwoofer signal is available. If only a letter is shown, this speaker is not used and its sound is reproduced by the other speakers.

......

virtual 3D surround

SURROUND ................

surround sound is reproduced

DIGITAL SURROUND ....

digital surround sound is reproduced

L, R ..........................

front left and right speaker

C ..............................

center speaker

SL, SR.......................

surround speakers

SW............................

subwoofer

Menu indication

These signs show you if the menu is on or off and indicate in which direction you may move.

MENU

.......................Menu is on.



............................

You may move backwards to the



previous menu topic using



PREV. (“left” key on the remote control).

............................

You may move up in an option list



using MENU NAVIGATOR (“up” key on



the remote control).



............................

You may move down in an option list



using MENU NAVIGATOR (“down” key



on the remote control).

............................

You may move forward to the next menu



topic using NEXT

(“right” key on the



remote control).



OK............................

You may confirm the displayed value.



0





MENU

OK

VOL TV VOL

+ +

- -

DISPLAY

Status lights

Signs showing you various settings and information about the status of the receiver.

PRESET .....................

Tuner is tuned to a preset radio station.

SENS HI.....................

Tuner is switched to high sensitivity.

SENS LO....................

Tuner is switched to low sensitivity.

STEREO.....................

An FM station is being received in stereo.

SMART SOUND ...........

One of the preset sound settings of the



receiver is being used.

HALL.........................

HALL effect is on.

ANA ..........................

Analogue input is being used for the



playing source.

NIGHT .......................

NIGHT MODE is on.

COAX 1 .....................

Coaxial digital input COAX 1 is being



used for the playing source.

COAX 2 ....................

Coaxial digital input COAX 2 is being



used for the playing source.

DOWNMIX..................

Incoming multi channel signals are being



reduced to fewer output signals



(depending on the number of speakers).

OPT ..........................

Optical digital input OPTICAL IN is being



used for the playing source.

LOUDNESS .................

LOUDNESS is switched on.

Information area

This area is used for feedback of the receiver, tuner frequencies, menu options, values and scrolling text messages.

ENGLISH

11

SR4000U(Eng) DFU 00.8.6 1:13 PM 12

ENGLISH

MENUS

Receiver menu

The receiver is equipped with a menu system. The menu is used for the setup of the receiver. The different menu options are related to each other in a logical way. Let’s assume you have no center speaker connected, and therefore switched

to

. If you try to use



, a message will be

scrolled that this is not possible

(

).

The menu always works the same way. Arrows in the display show you the possible moving directions.

1 Press MENU.



MENU, and

is displayed.

You can exit the menu at any time by pressing MENU.

2Turn MENU NAVIGATOR until the desired option (or a value) is displayed.

3Press NEXT to choose the displayed option (or ENTER / OK to confirm a value).

You can leave any option (values remain unchanged) by pressing PREV.

Menu structure

Switches sound effects.

virtual 3D surround: 0…100 %

Adjusts the relative volume balance between the connected speakers.

Test tone: on/off

Volume front left speaker: –50…+50

Volume front right speaker: –50…+50

Volume center speaker: –50…+50

Volume rear left speaker: –50…+50

Volume rear right speaker: –50…+50

Volume subwoofer: –50…+50

Selects the used speakers.

Subwoofer present: yes/no

Center speaker present: yes/no

Rear speakers present: yes/no

Chooses the speaker sizes of the used speakers, for

optimal sound reproduction.



indicates a speaker

which can reproduce frequencies lower than 50 Hz. If



is set to

,

can

only be set to

. If



is set to

,

can only be set to

and consequently a subwoofer must be connected.

Subwoofer present: yes/no

Left and right front speakers: small/large

Center speaker: small/large

Rear speakers: small/large

Distance between the usual listening position and the speakers. This defines the delay time for the surround sound.

Distance to front speakers: 1…10 m (3…30 ft)

Distance to center speaker: 1…10 m (3…30 ft)

Distance to rear speakers: 1…10 m (3…30 ft)

Assigns the audio input connectors to the different source selections chosen with INPUT SELECTOR (see “SOURCE SELECTION” for details).

Digital coaxial input 1, COAX 1 IN

Digital coaxial input 2, COAX 2 IN

Digital optical input, OPTICAL IN

Analogue audio input SAT IN

Analogue audio input VCR IN

Analogue audio input TV IN

Analogue audio input CDR IN

Analogue audio input CD IN

Analogue audio input 6 CHANNEL IN

Setup for preset radio stations (see TUNER for details).

Stores radio stations automatically

Stores radio stations manually

Allows to assign names to stored radio stations

Resorts stored radio stations

12

SR4000U(Eng) DFU 00.8.6 0:41 PM 13

INPUT SELECTOR

When selecting a source by turning INPUT SELECTOR, the audio and video inputs with the corresponding name are

activated. The incoming signal is reproduced by all audio and

– if the source includes a video signal – video outputs of the receiver.

Source selected

.........Connectors used

DVD .............................

COAX 1 digital audio input and



DVD IN video input

PHONO........................

PHONO IN audio input

TUNER ........................

The tuner part of the receiver is used,



all inputs are switched off.

CD................................

CD IN audio input

CDR/TAPE...................

CDR/TAPE IN audio input

TV ................................

TV IN audio input and



no video input

VCR .............................

VCR IN audio input and



VCR IN video input

SAT..............................

SAT IN audio input and



SAT IN video input

6 CH input selection

The 6 channel input connectors can be assigned to any of the available sources (excluding TUNER and PHONO). The assignment can be done via the option in the menu.

See below for more details.

Reassigning a source selection

If a source is selected with INPUT SELECTOR the standard audio input is used. To change this, the source selection must be reassigned to another audio input.

Example: Reassigning

from the analogue CD IN audio



input to the digital COAX 2 IN audio input.

1

Choose



from the menu and press



NEXT 3.





2

Turn INPUT SELECTOR to select the source which should



be reassigned (e. g.

).





→ The name of the source is displayed and the light of the



source flashes.





3

Turn MENU NAVIGATOR to select the input connectors



which should be used (e. g.

).

4Press ENTER / OK to confirm your selection. → is displayed briefly.

5This source selection is now using the chosen audio input (e. g. uses the COAX 2 IN input connectors, COAX 2 lights when switching to CD).

SOURCE SELECTION

Using one source selection for two or more appliances

You may assign more than one source to a source selection. This can be useful when products are connected one after the other in a chain.

Example: A VCR is connected to the TV but only the TV is connected to the receiver. Both INPUT SELECTOR settings, TV as well as VCR, have to use the TV input connectors.

1

Choose



from the menu and press



NEXT 3.





2

Turn INPUT SELECTOR to select the source which should



be reassigned (e. g.

).





→ The name of the source is displayed and the light of the



source flashes.





3

Turn MENU NAVIGATOR to select the input connectors



which should be used (e. g.

).

4Press ENTER / OK to confirm your selection. → is displayed briefly.

5This source selection is now using the chosen audio input (e. g.

uses the TV IN input connectors,

is

displayed briefly when switching to VCR).



ENGLISH

13

SR4000U(Eng) DFU 00.8.6 0:41 PM 14

ENGLISH

PLAYBACK, RECORDING

Playing a source

1Press POWER ON / OFF to switch on the receiver.

2Turn INPUT SELECTOR to select a source. → The name of the source is displayed.

You can select the FRONT AV input by pressing FRONT AV.

3 Start playback of the source as usual.

Adjusting the sound

Turn VOLUME to adjust the volume.





displayed.

and the volume level between and

is









1

Press BASS or TREBLE.





or

and the actual value are displayed





briefly. Then







is scrolled.





2

Turn VOLUME to adjust the bass or treble.





or

and the actual value are



displayed.

Note : If VOLUME is not turned within 5 seconds or if any other control is used, the bass or treble adjustment is switched off.

• Press SOUND on the remote control to scroll through the

built-in smart sounds:

,

,

,

and

. (



is the

userdefined bass and treble setting.)





SMART SOUND is displayed and the name of the chosen sound profile is scrolled once if smart sound is on.

Press LOUDNESS to switch loudness either on or off. → LOUDNESS is displayed if loudness is on.

Recording from a source

If you wish to record from a source you must select it with INPUT SELECTOR. The incoming signal is reproduced by all audio and – if the source includes a video signal – video outputs of the receiver. The sound settings do not affect the recording.

1Turn INPUT SELECTOR (or press FRONT AV) to select

the source you want to record from.

→ The name of the source is displayed.

2Prepare the desired recording appliance. It must be connected to one of the outputs of the receiver.

3Start recording on the recording appliance.

4Start the playback of the source as usual.

Notes: – The audio and video signal of VCR IN is not reproduced by VCR OUT. The same applies to the audio signal of CDR/TAPE IN to CDR/TAPE OUT.

We recommend not to use the digital output COAX OUT of the receiver to record from an analogue source. Use the analogue output

CDR/TAPE instead.

Recording from the digital output

It is possible to connect a digital recorder to the digital output of the receiver. In this way, all signals coming from the digital inputs can be recorded directly on the connected audio recorder. The receiver will also convert all signals coming from the analogue inputs to the digital output.

The receiver can be used to record digitally a multichannel surround sound audio signal (Dolby Digital) from, for example, DVD to CD-R. The receiver will convert the digital multichannel signal into a stereo signal without loss of relevant sound information.

Notes: – Do not use the 3D SURROUND feature while making digital recordings as this will distort the digital audio signal.

When recording a Dolby Digital signal, each track must be recorded individually.

14

is scrolled.

SR4000U(Eng) DFU 00.8.6 0:41 PM 15

About surround sound

Surround sound gives you a complete new listening sensation. You will have the feeling of being in the middle of the action, because sound is coming from everywhere around you. Look out for TV broadcasts, audio and video tapes and discs with the 3or 1marks which are encoded for multichannel surround sound. You should prefer Dolby Digital to get the best out of your receiver.

Notice that DVDs do not always carry full multichannel surround. To be sure that a disc is multichannel encoded consult your dealer.

Most ordinary stereo tapes and discs can be replayed using surround sound settings with good results. If the reproduction is distorted in surround mode, switch to normal stereo mode.

The availabilty of the various surround sound modes described depends on the number of speakers used and the incoming sound information.

Switching surround sound

With surround sound on, you can switch through the different surround modes. Note that the possibilities are related to speaker setup defined in the receivers menu.

If a digital surround signal is detected, the receiver will scroll either .

1Press SURROUND ON/OFF to switch on the surround sound.

The surround mode in use is scrolled.

2Press SURR. MODE repeatedly to listen to the different surround modes (if available).

The chosen mode and the speakers used are displayed. If the incoming multichannel signals are reduced to fewer output signals, DOWNMIX is displayed.

3Press 3D SURROUND to switch virtual 3D surround either on or off.

A light indicates if virtual 3D surround is on.

4Press SURROUND ON/OFF to switch off the surround sound.

SURROUND SOUND

Surround sound settings

The sound reproduction is enhanced and a slight echo is added. This gives the impression of being in a large room. Can only be used in stereo mode.

The surround mode enables normal surround sound reproduction with 4 or 5 speakers. Depending on the source material, Dolby Surround Pro Logic, Dolby Digital is reproduced.



,

In addition to

, the surround mode used –

depending on the source material – will be displayed. In case of digital surround, the sound format AC-3 (for Dolby Digital) will be displayed, followed by the sound channels, available on the source (e. g. DVD).

Example:

Dolby Digital, 3 front channels,



2 surround channels and a



subwoofer channel.



Dolby Digital, 3 front channels, 1



(mono) surround channel without



subwoofer signal.

The surround sound is muted. 3 Stereo lets you listen to surround sound without using the surround speakers.

The sound of the rear channel is simulated by the front speakers. Surround sound is simulated through the front left, right and center speakers. The position of the listener influences the surround effect. The area where the effect is best is shown in grey.

FRONT

CENTER

FRONT







LEFT



RIGHT

All sound is reproduced and played through the front left and right speakers. This enables standard stereo reproduction.

NIGHT MODE (only on the remote control)

The loud parts of the sound are lowered and the soft passages are raised. You can enjoy surround sound without disturbing sleeping children or neighbours. Night mode only works with Dolby Digital, and only if supported by the source material.

ENGLISH

15

SR4000U(Eng) DFU 00.8.6 0:41 PM 16

ENGLISH

TUNER

Tuning to radio stations

You can search for radio stations by scanning the frequency band. You can also key in the frequency of a known radio station. If an FM station is being broadcast and received in stereo, STEREO is shown.

Searching for radio stations

1Turn INPUT SELECTOR to select the tuner.

is displayed.

2Select a waveband by pressing BAND repeatedly.

The selected waveband is displayed.

3Keep or pressed for approximately 1 second.

is displayed and the tuner tunes to a station with sufficient strength.

4Repeat this procedure until you find the desired station.

To fine tune to a weak transmitter, briefly press or as often as necessary for optimum reception.

Tuning to a radio station by frequency (with the remote control only)

1Press TUNER.

is displayed.

2Press TUNER again to select a different waveband.

The selected waveband is displayed.

3Press FR. D..

_ is displayed.

4Use 1–0 to key in the frequency of a radio station.

Note: Only valid numbers within the frequency range of the tuner can be keyed in.

Switching FM sensitivity

You can switch the tuner to a lower search sensitivity, to search for stations with a strong signal only (FM only).

1Turn INPUT SELECTOR to select the tuner.

is displayed.

2Press SENS. on the receiver.

Either SENS HI or SENS LO is displayed for 5 seconds.

Note: While searching for radio stations, the actual sensitivity is displayed. In this case, SENS LO means the tuner is only looking for radio stations with a strong signal.

Storing radio stations

You may store up to 30 radio stations in the memory. The receiver can select and program radio stations by itself or you can choose them yourself.

Automatic programming

1

Choose

from the menu and press NEXT .

2

Choose

and press NEXT .



→ The preset number where programming will start, the



waveband and

are displayed.

3Turn TUNER PRESET to change the preset number where programming should start.

4Use BAND to switch to the desired waveband.

5Press ENTER / OK to start programming.



flashes and all available radio



stations are programmed, this may take a few minutes.



Programming is done when

stops



flashing.





Manual programming





1

Choose

from the menu and press NEXT .

2

Choose



and press NEXT .

A preset number, the waveband and the frequency are displayed.

3Turn TUNER PRESET to change to the preset number where the radio station should be stored.

4Tune to the desired radio station (see “Searching for radio stations”).

5Press ENTER / OK to confirm your selection.

is displayed briefly. The radio station is programmed at the chosen preset number.

6Select and store all desired radio stations this way.

16

SR4000U(Eng) DFU 00.8.6 0:42 PM 17

TUNER

Tuning to stored radio stations

1Turn INPUT SELECTOR to TUNER to select the tuner.

is displayed.

2Turn TUNER PRESET to select a preset radio station.

PRESET, the preset number and station are displayed.

Resorting stored radio stations

After programming radio stations, you might want to change their sequence. allows you to exchange the positions of presets.

1

Choose

from the menu and press NEXT .

2

Choose

and press NEXT .



PRESET, a preset number and station are displayed.

3Turn TUNER PRESET to select a preset station.

4Press ENTER / OK to confirm the selection.

→ The selected preset number

and a second

preset number are displayed.



5Turn TUNER PRESET to select the other preset station.

6Press ENTER / OK to confirm the exchange.

is displayed briefly and these two preset numbers are swapped.

Naming radio stations

It is possible to assign a name to any of the preset radio stations.

1

Choose

from the menu and press NEXT .

2

Choose

and press NEXT .



→ A preset radio station is displayed.

3Turn TUNER PRESET to select the preset to be renamed.

4Press ENTER / OK to confirm your selection.

The existing name or ________ is displayed.

5Turn TUNER PRESET to select a letter and NEXT or PREV. to move to the next or previous position.

6After you have entered the entire name, press ENTER / OK to confirm.

is displayed and the name is stored.

Clearing station names

1 Use the menu option

, choose

.

→ A preset radio station is displayed.



2Turn MENU NAVIGATOR to select the name to be cleared.

3Press ENTER / OK to confirm your selection.

4Press PREV. while the first letter is flashing. → is flashing to the left of the station name.

5Press ENTER / OK to clear the station name.

Or, if you have changed your mind,

press PREV. to leave the station name as it is.

ENGLISH

17

SR4000U(Eng) DFU 00.8.6 0:42 PM 18

ENGLISH

TECHNICAL DATA

Receiver

Subject to modification without notice.





General







Power consumption ....................................................



≈ 195 W

Standby power consumption...........................................





< 2 W

Dimensions, w × h × d...........................



440 × 138 × 394 mm

Weight.............................................................................





9.4 kg

Amplifier part (0.7 % THD, 6 / 8 Ω , 1 kHz)



Output power, stereo mode..............................



2 × 100 / 80 W

Output power, surround mode



2 × 100 / 80 W

Front...........................................................



Center ...............................................................



100 / 80 W

Surround ......................................................



2 × 50 / 40 W

Bass ...............................................................



±9 dB at 100 Hz

Treble .............................................................



±9 dB at 10 kHz

Loudness+6 dB at 100 Hz (-30 dB); +3 dB at 10 kHz (-30 dB)

Total harmonic distortion........................



0.05 % at 1 kHz, 1 W

Frequency response...............................



20–30,000 Hz, ±1 dB

S/N ratio.......................................................................



82 dB

Stereo separation (1 kHz)............................................



45 dB

Crosstalk (1 kHz) ........................................................



≤ -65 dB

Inputs







Linear inputs ..................................................



250 mV at 47 kΩ

Front AV.........................................................



250 mV at 22 kΩ

Phono.................................................................



5 mV at 47 kΩ

Digital coaxial .............................................



75 Ωacc. IEC 958

Outputs







Power supply AC outlets (switched)...........

totally max. 120 W

Linear outputs ..................................................



250 mV at 1 kΩ

Digital coaxial .............................................



75 Ωacc. IEC 958

Digital optical ..................................................................





toslink

Subwoofer pre-out ...............................................



0.8 V at 1 kΩ

Center pre-out......................................................



0.8 V at 1 kΩ

Headphones....................................

8–600 Ω (3 V e.m.f., 60 Ω )

Speakers ..........................................................................





≥ 6 Ω

Tuner part







Wave range







FM............................................................



87.5–108.0 MHz

AM..............................................................



530–1,700 kHz

Sensitivity







Stereo FM ................................................................





41 dBf

Mono FM..................................................................





17 dBf

Total harmonic distortion







Stereo FM .................................................................





0.8 %

Mono FM ...................................................................





0.9 %

Frequency response................................



63–12,500 Hz ±1 dB

S/N ratio







Stereo FM .................................................................





55 dB

Mono FM...................................................................





60 dB

Channel separation...........................................



27 dB at 1 kHz

18

SR4000U(Eng) DFU 00.8.6 0:42 PM 19

TROUBLESHOOTING

WARNING

If a fault occurs, first check the points listed below before

Under no circumstances should you try to repair

taking the speakers for repair.

anything by yourself, as this will invalidate the

If you are unable to solve a problem by following these hints,

guarantee. Do not open the set as there is a risk of

electric shock.

consult your dealer or service center.





PROBLEM

POSSIBLE CAUSE



SOLUTION



No sound

VOLUME is not correctly adjusted.



Adjust the VOLUME.





Headphones are connected.



Disconnect headphones.





The wrong source is selected.



Turn INPUT SELECTOR to select the correct







source.



No sound on the

One speaker is wrongly connected.



Connect the speaker properly.

left or right side

A speaker cable is damaged.



Replace the cable.











Volume balance in the receiver menu is

Adjust

and



wrongly adjusted.



in the receiver menu.



Poor sound or no sound at

SURROUND mode is not switched on.

Press SURROUND ON/OFF to switch on the

the center or surround





surround sound.



speakers

Surround and/or center speakers are not

Connect the speakers properly.





(properly) connected.









Surround and/or center speakers are



Set speaker present to

.



switched off in the

menu.







A speaker cable is damaged.



Replace the cable.



Poor bass sound

Speakers are not in phase.



Connect the coloured (or marked) wires to the







coloured terminals and the black (or unmarked)







wires to the black terminals.

Bad sound

Badly matching setting for the given type of

Correct the sound settings on the receiver.



music or sound.







Surround sound level is

The level of the surround sound is not



Adjust the level of the surround sound on

too low or too high

properly adjusted.



the receiver.



Center sound level is too

The sound level of the center channel is not

Adjust the level of the center channel

low or too high

properly adjusted.



on the receiver.



Only center speaker is

A mono signal is reproduced.



Choose a different sound source or switch off

heard in Dolby Surround





surround sound.



Pro Logic









Bad radio reception,

Receiver or antenna is positioned near a

Change the position of the interfering unit

automatic programming

radiation source such as a TV, CD player,

or try to switch it off.



does not work properly

CD recorder, DVD player, etc.







ENGLISH

19

SR4000U(code) DFU 00.8.6 1:00 PM 39

CABLE BOX



ABC .............................

0030, 0035, 0038, 0040, 0028, 0034,



0041, 0044

Allegro..........................

0180, 0342

Antronix........................

0049, 0234

Archer ..........................

0049, 0180, 0234, 0824

Belcor...........................

0083

Bell & Howell ...............

0041

Cable Star....................

0083

Cabletenna ..................

0049

Cableview ....................

0049

Century ........................

0180

Citizen..........................

0180, 0342

Colour Voice ................

0052, 0058

Comtronics...................

0067

Contec .........................

0046

Digi...............................

0664

Eastern ........................

0029

Emerson ......................

0824

Everquest.....................

0042, 0067

Focus ...........................

0427

France Telecom...........

0923

GC Electronics.............

0083, 0234

Garrard ........................

0180

Gemini .........................

0269, 0042

General Instrument ......

0303, 0503, 0038, 0837

GoldStar.......................

0067, 0171

Goodmind ....................

0824

Hamlin..........................

0047, 0036, 0286, 0061

Hitachi..........................

0038

Hytex............................

0034

Jasco ...........................

0042, 0180, 0342

Jerrold..........................

0030, 0039, 0303, 0038, 0041, 0042,



0051, 0503, 0837

Linsay ..........................

0467

Magnavox ....................

0054, 0041

Memorex......................

0027

Movie Time ..................

0090, 0183

NAP .............................

0034

NSC .............................

0183, 0090

Novaplex......................

0645

Oak ..............................

0046, 0034

Optimus .......................

0048

Panasonic ....................

0048, 0134, 0027

Panther ........................

0664

Paragon .......................

0027

Philips ..........................

0052, 0058, 0269, 0317, 0054, 0180

Pioneer ........................

0171, 0050, 0560

Popular Mechanics ......

0427

Proscan........................

0048

Pulsar...........................

0027

Quasar .........................

0027

RCA .............................

0048

Radio Shack ................

0824, 0042, 0342, 0910

Realistic .......................

0234

Recoton .......................

0427

Regal ...........................

0286, 0047

Regency.......................

0029

Rembrandt ...................

0038

Runco ..........................

0027

SL Marx .......................

0067

Samsung......................

0067, 0171

Scientific Atlanta ..........

0035, 0044, 0504

Seam ...........................

0537

Signal...........................

0042, 0067

Signature .....................

0038

Sprucer ........................

0048

Starcom .......................

0030, 0042

Stargate .......................

0067, 0042, 0824

Starquest .....................

0042

Sylvania .......................

0028

TFC..............................

0337

TV86 ............................

0090

Tandy...........................

0285

TeleCaption .................

0248

Teleview.......................

0067

Texscan .......................

0028

Timeless ......................

0445

Tocom..........................

0039, 0040

Toshiba ........................

0027

Tusa.............................

0042

Unika............................

0234, 0180, 0049

United Artists ...............

0034

Universal......................

0234, 0049, 0083, 0218, 0180

Viewstar .......................

0285, 0054, 0090

Westminster.................

0132

Zenith...........................

0027, 0552, 0081, 0035, 0042, 0234

Zentek..........................

0427

CD



ADC .............................

0045

Adcom..........................

0261, 0182

Aiwa .............................

0151, 0039, 0184

Akai..............................

0183

Anthem ........................

0924

Audio Alchemy.............

0221

Audio-Technica............

0197

BSR .............................

0272, 0221

Burmester ....................

0447

California Audio Lab ....

0056

Carrera.........................

0221

Carver ..........................

0184, 0206, 0464

Craig ............................

0642

Crown ..........................

0149

Curtis Mathes...............

0056

DAK .............................

0272

DBX .............................

0281

DKK .............................

0027

Denon ..........................

0030, 0061, 0900

Emerson ......................

0182, 0191, 0332, 0496

Fisher...........................

0115, 0206, 0201, 0369

GE................................

0036

Garrard ........................

0307, 0272, 0420, 0447, 0452

Genexxa ......................

0059, 0191, 0332

GoldStar.......................

0444

Harman/Kardon ...........

0200, 0184, 0453

Hitachi..........................

0059, 0182

JVC ..............................

0099, 0682, 0685

Kenwood......................

0055, 0217, 0708, 0853, 0064

Kodak...........................

0314

Krell..............................

0184

Kyocera........................

0045

LXI ...............................

0332

Linn ..............................

0184

Luxman ........................

0120

MCS.............................

0056, 0070

39

SR4000U(code) DFU 00.8.6 1:00 PM 40

MGA.............................

0110

MTC .............................

0447

Magnavox ....................

0184, 0553, 0332

Marantz........................

0184, 0056, 0207, 0462

McIntosh ......................

0314

Mission.........................

0184

Mitsubishi.....................

0110

NAD .............................

0046

NEC .............................

0261, 0070

NSM.............................

0184

Nakamichi ....................

0174

Nikko............................

0197, 0191, 0201

Onkyo ..........................

0128, 0895

Optimus .......................

0447, 0495, 0059, 0453, 0206, 0223,



0464, 0202, 0332, 0064, 0114, 0172,



0221, 0307, 0369, 0027

Panasonic ....................

0056, 0394, 0330, 0779

Parasound ...................

0447, 0221

Philips ..........................

0184, 0314

Pioneer ........................

0059, 0495, 0271, 0332

Proscan........................

0080

Proton ..........................

0184

QED .............................

0184

Quasar .........................

0056

RCA .............................

0080, 0332, 0036, 0182, 0206, 0791

Realistic .......................

0182, 0202, 0191, 0206, 0207, 0447

Rotel ............................

0184, 0447, 0924

SAE..............................

0184

STS..............................

0045

Sansui..........................

0229, 0184, 0332

Sanyo...........................

0114, 0206

Scott.............................

0191, 0182, 0332

Sears ...........................

0332

Sharp ...........................

0064, 0207, 0888

Sherwood.....................

0141, 0207, 0223, 0453

Shure ...........................

0070

Sony.............................

0027, 0212, 0631, 0517, 0632

Soundesign..................

0172, 0452

Sylvania .......................

0184

Tascam ........................

0447

Teac.............................

0420, 0447, 0201, 0207

Technics ......................

0056, 0330, 0234

Toshiba ........................

0046

Vector Research ..........

0221, 0444

Victor............................

0099

Wards ..........................

0080, 0184

Yamaha .......................

0214, 0063, 0197

Yorx .............................

0488

Zenith...........................

0642

TAPE



Aiwa .............................

0224, 0227, 0056

Akai..............................

0310

Carver ..........................

0056

Denon ..........................

0103

Fisher...........................

0101

Garrard ........................

0335, 0466

Harman/Kardon ...........

0209, 0056

JVC ..............................

0271, 0300

Kenwood......................

0098, 0097, 0260

Magnavox ....................

0056

Marantz........................

0056, 0036

Mitsubishi.....................

0310

NAD .............................

0171

Onkyo ..........................

0162, 0163, 0309

Optimus .......................

0247, 0054, 0364, 0466

Panasonic ....................

0256

Philips ..........................

0056

Pioneer ........................

0054, 0247, 0126

Proscan........................

0053

RCA .............................

0053

Revox...........................

0217

Sansui..........................

0036, 0056

Sharp ...........................

0258

Sherwood.....................

0364

Sony.............................

0270, 0197, 0318

Teac.............................

0335, 0316

Technics ......................

0256

Victor............................

0300

Wards ..........................

0054

Yamaha .......................

0121, 0124

DVD



Harman/Kardon ...........

0609

JVC ..............................

0585

Kenwood......................

0561

Magnavox ....................

0530

Mitsubishi.....................

0548

Onkyo ..........................

0530

Optimus .......................

0552

Panasonic ....................

0517

Philips ..........................

0566, 0530

Pioneer ........................

0552, 0598

Proscan........................

0549

RCA .............................

0549

Samsung......................

0600

Sony.............................

0560

Technics ......................

0517

Thomson......................

0578

Toshiba ........................

0530

Yamaha .......................

0572, 0517

Zenith...........................

0618, 0530

TV



A-Mark .........................

0030

AOC .............................

0079, 0030, 0212, 0046, 0057

Abex.............................

0059

Admiral.........................

0120

Adventura ....................

0073

Aiko..............................

0119

Akai..............................

0057

Alaron ..........................

0206

Allegro..........................

0747, 0801

Ambassador.................

0204

Ampro ..........................

0778

Anam ...........................

0207

Anam National .............

0082

Archer ..........................

0030

Audiovox ......................

0119, 0030, 0207, 0478, 0650

Aumark ........................

0087

Baysonic ......................

0207

Belcor...........................

0046

Bell & Howell ...............

0043, 0181

Bradford .......................

0207

Brockwood ...................

0046

Broksonic .....................

0030, 0263, 0490

CCE .............................

0064, 0244

40

SR4000U(code) DFU 00.8.6 1:00 PM 41

CXC .............................

0207

Candle .........................

0213, 0073, 0057, 0083

Capehart ......................

0079

Carnivale......................

0057

Carver ..........................

0081

Celebrity.......................

0027

Cineral .........................

0478, 0119

Citizen..........................

0213, 0073, 0083, 0057, 0066, 0087,



0119, 0307

Clairtone ......................

0212

Concerto ......................

0083

Contec .........................

0184, 0207, 0212

Craig ............................

0207

Crosley.........................

0081

Crown ..........................

0066, 0207

Curtis Mathes...............

0087, 0057, 0181, 0043, 0066, 0074,



0078, 0081, 0083, 0120, 0172, 0193,



0478, 0493

Daewoo........................

0119, 0650, 0046, 0651, 0478, 0066

Daytron ........................

0046, 0066

Denon ..........................

0172

Dumont ........................

0044, 0046

Dwin.............................

0747, 0801

Dynatech......................

0244

Electroband..................

0027, 0212

Electrohome.................

0408

Emerson ......................

0263, 0207, 0205, 0206, 0490, 0204,



0309, 0307, 0651, 0066, 0212, 0650,



0046, 0065, 0181

Envision .......................

0057

Fisher...........................

0181, 0186

Fujitsu ..........................

0206

Funai............................

0207, 0198, 0206

Futuretech....................

0207

GE................................

0048, 0054, 0074, 0082, 0078, 0205,



0162, 0309, 0478, 0120

Gibralter .......................

0044, 0046, 0057

Go Video......................

0087

GoldStar.......................

0028, 0205, 0057, 0046, 0059, 0066,



0083

Gradiente .....................

0083, 0080

Grundig ........................

0064, 0222

Grunpy .........................

0206, 0207

Hallmark.......................

0205

Harley Davidson ..........

0206

Harman/Kardon ...........

0081

Harvard ........................

0207

Hitachi..........................

0172, 0178, 0065, 0083, 0059

Infinity ..........................

0081

Inteq.............................

0044

JBL...............................

0081

JCB ..............................

0027

JVC ..............................

0080

Janeil ...........................

0073

KEC .............................

0207

KTV..............................

0307, 0207, 0212, 0244, 0066, 0057

Kaypani........................

0079

Kenwood......................

0057, 0046

Kloss ............................

0073, 0051

LG ................................

0083

LXI ...............................

0181, 0205, 0074, 0044, 0081, 0183

Loewe ..........................

0539

Logik ............................

0043

Luxman ........................

0083

MEI ..............................

0212

MGA.............................

0177, 0046, 0057, 0205

MTC .............................

0087, 0046, 0057, 0212, 0083

Magnavox ....................

0081, 0214, 0051, 0123, 0047, 0213,



0057, 0413, 0206

Majestic........................

0043

Marantz........................

0081, 0064, 0057

Matsushita ...................

0078, 0277

Megatron......................

0030, 0172, 0205

Memorex......................

0205, 0043, 0083, 0087, 0177, 0181,



0277

Midland ........................

0044, 0059, 0066, 0074, 0078, 0162

Minutz ..........................

0048

Mitsubishi.....................

0177, 0046, 0205, 0120

Motorola.......................

0082, 0120

Multitech ......................

0244, 0207

NAD .............................

0183, 0193, 0205

NEC .............................

0057, 0046, 0083, 0524

NTC .............................

0119

Nikko............................

0205, 0044, 0074, 0057, 0119, 0181,



0183

Noshi............................

0045

Onwa ...........................

0207

Optimus .......................

0277, 0193, 0181

Optonica ......................

0120, 0192

Orion ............................

0263, 0206, 0490

Panasonic ....................

0078, 0277, 0082, 0028, 0074, 0080,



0081, 0087, 0120, 0172, 0177, 0181,



0183, 0192, 0205

Penney.........................

0074, 0057, 0087, 0048, 0054, 0162,



0045, 0205, 0078, 0066, 0046, 0030,



0059, 0083, 0183

Philco ...........................

0047, 0046, 0057, 0081, 0123, 0172,



0490, 0051, 0213, 0214

Philips ..........................

0081, 0044, 0047, 0066, 0064, 0027,



0045, 0046, 0048, 0051, 0054, 0079

Pilot..............................

0046, 0057, 0066

Pioneer ........................

0193, 0065

Portland .......................

0119, 0046, 0066

Prism............................

0078

Proscan........................

0074, 0057

Proton ..........................

0493, 0205, 0030, 0079

Pulsar...........................

0044, 0046

Quasar .........................

0078, 0082, 0277, 0192

RCA .............................

0074, 0045, 0162, 0046, 0065, 0078,



0117, 0120

Radio Shack ................

0192, 0207, 0205, 0057, 0066, 0046,



0181, 0059, 0074, 0083

Realistic .......................

0192, 0207, 0181, 0057, 0066, 0205,



0046, 0059, 0083

Rhapsody.....................

0212

Runco ..........................

0044, 0524, 0057

SSS..............................

0046, 0207

Sampo .........................

0057, 0059, 0066, 0079

Samsung......................

0087, 0059, 0205, 0046, 0057, 0066,



0083, 0064

Samsux........................

0066

Sansei..........................

0478

Sansui..........................

0490

Sanyo...........................

0181, 0186, 0173

Scimitsu .......................

0046

Scotch..........................

0205

Scott.............................

0263, 0205, 0206, 0207, 0046

Sears ...........................

0186, 0181, 0173, 0183, 0081, 0083,



0198, 0205, 0074, 0206

Semivox .......................

0207

41

SR4000U(code) DFU 00.8.6 1:00 PM 42

Semp ...........................

0183

Sharp ...........................

0192, 0120, 0413, 0066, 0184

Shogun ........................

0046

Signature .....................

0043

Simpson.......................

0213, 0214

Sony.............................

0027, 0138, 0107

Soundesign..................

0205, 0207, 0206, 0213

Spectricon....................

0030

Squareview ..................

0198

Starlite..........................

0207

Supre-Macy .................

0073

Supreme ......................

0027

Sylvania .......................

0081, 0047, 0123, 0057, 0408, 0051,



0213, 0214

Symphonic ...................

0198

TMK .............................

0083, 0204, 0205

Tandy...........................

0120

Tatung..........................

0030, 0082

Technics ......................

0078, 0277, 0044, 0074

Technol Ace.................

0206

Techwood ....................

0030, 0078, 0083

Teknika ........................

0213, 0043, 0206, 0046, 0066, 0081,



0207, 0083, 0119, 0177, 0087

Telefunken ...................

0083

Toshiba ........................

0183, 0087, 0181

Tosonic ........................

0212

Totevision ....................

0066

Trical ............................

0184

Universal......................

0054, 0048

Vector Research ..........

0057

Victor............................

0080

Vidikron........................

0081

Vidtech.........................

0046, 0205

Viking ...........................

0073

Wards ..........................

0081, 0192, 0205, 0183, 0043, 0047,



0048, 0123, 0138, 0214, 0054, 0107,



0206, 0046, 0057, 0083, 0162

White Westinghouse....

0651, 0650

Yamaha .......................

0046, 0057

Zenith...........................

0044, 0043, 0119, 0173

Zonda...........................

0030

VCR



Admiral.........................

0075

Adventura ....................

0027

Aiko..............................

0305

Aiwa .............................

0334, 0027, 0064

Akai..............................

0133, 0080, 0088, 0068

American High .............

0062

Asha.............................

0267

Audiovox ......................

0064

Beaumark ....................

0267

Bell & Howell ...............

0131

Blaupunkt.....................

0033

Broksonic .....................

0211, 0148, 0388, 0029, 0236, 0238,



0322, 0506

CCE .............................

0099, 0305

Calix.............................

0064

Canon ..........................

0062

Capehart ......................

0047

Carver ..........................

0108

Cineral .........................

0305

Citizen..........................

0305, 0064

Colt ..............................

0099

Craig ............................

0064, 0074, 0099, 0267, 0298

Curtis Mathes...............

0062, 0068, 0087, 0189

Cybernex .....................

0078, 0267

Daewoo........................

0305, 0588, 0047, 0072

Daytron ........................

0047

Denon ..........................

0069

Dynatech......................

0027

Electrohome.................

0064

Electrophonic ...............

0064

Emerex ........................

0059

Emerson ......................

0211, 0029, 0148, 0236, 0063, 0238,



0305, 0321, 0115, 0235, 0506, 0088,



0239, 0588, 0095, 0322, 0388, 0027,



0064, 0070

Fisher...........................

0074, 0131, 0081, 0093

Fuji ...............................

0060, 0062

Funai............................

0027

GE................................

0062, 0087, 0229, 0075, 0267

Garrard ........................

0027

Go Video......................

0459, 0553

GoldStar.......................

0064, 0065

Gradiente .....................

0035, 0027

HI-Q .............................

0074

Harley Davidson ..........

0027

Harman/Kardon ...........

0108, 0065

Harwood ......................

0095, 0099

Headquarter.................

0073

Hitachi..........................

0069, 0132, 0027, 0068

JVC ..............................

0094, 0035, 0068

Jensen .........................

0068

KEC .............................

0064, 0305

KLH..............................

0099

Kenwood......................

0068, 0094, 0065, 0073

Kodak...........................

0062, 0064

LXI ...............................

0064

Lloyd‘s..........................

0027, 0235

Logik ............................

0099

MEI ..............................

0062

MGA.............................

0070, 0088, 0267

MGN Technology.........

0267

MTC .............................

0027, 0267

Magnasonic .................

0305

Magnavox ....................

0062, 0108, 0027, 0066, 0176

Magnin .........................

0267

Marantz........................

0108, 0065, 0062

Marta............................

0064

Matsushita ...................

0062, 0481, 0189

Memorex......................

0131, 0074, 0027, 0064, 0062, 0075,



0267, 0334, 0073, 0066

Metz .............................

0033, 0064, 0189, 0323

Minolta .........................

0132, 0069

Mitsubishi.....................

0070, 0088, 0094, 0075

Motorola.......................

0062, 0075

Multitech ......................

0027, 0099

NAD .............................

0085

NAP .............................

0060, 0061, 0062, 0064, 0066, 0069,



0093, 0132

NEC .............................

0065, 0067, 0068, 0094, 0131

Nikko............................

0064

Nikon............................

0061, 0280

Noblex..........................

0267

Olympus.......................

0062

Optimus .......................

0085, 0075, 0064, 0459, 0131, 0189,



0481

Optonica ......................

0089

42

SR4000U(code) DFU 00.8.6 1:00 PM 43

Orion ............................

0506, 0322, 0029, 0211

Panasonic ....................

0062, 0104, 0189, 0252, 0481

Penney.........................

0062, 0267, 0064, 0065, 0069, 0067,



0081

Pentax..........................

0069, 0132

Philco ...........................

0062, 0506, 0236

Philips ..........................

0108, 0062, 0089

Pilot..............................

0064

Pioneer ........................

0085, 0094

Portland .......................

0047

Profitronic.....................

0267

Proscan........................

0087, 0229

Protec ..........................

0099

Pulsar...........................

0066, 0078

Quarter.........................

0073

Quartz ..........................

0073

Quasar .........................

0062, 0189, 0104, 0481

RCA .............................

0087, 0176, 0229, 0069, 0132, 0104,



0133, 0062, 0075, 0267

Radio Shack ................

0027

Radix............................

0064

Randex ........................

0064

Realistic .......................

0074, 0027, 0131, 0075, 0064, 0062,



0089, 0073, 0093

Ricoh............................

0061, 0280

Runco ..........................

0066

STS..............................

0069

Samsung......................

0267, 0072, 0080, 0078

Sanky...........................

0066, 0075

Sansui..........................

0506, 0068, 0298, 0027, 0094

Sanyo...........................

0073, 0074, 0131, 0267

Scott.............................

0211, 0148, 0238, 0072, 0237, 0239,



0070

Sears ...........................

0069, 0132, 0081, 0073, 0064, 0074,



0131, 0027, 0062, 0093

Semp ...........................

0072

Sharp ...........................

0075, 0089

Shintom........................

0099

Shogun ........................

0078, 0267

Signature .....................

0062

Singer ..........................

0099

Sony.............................

0060, 0061, 0059, 0280, 0062, 0027

Sunpak.........................

0280

Sylvania .......................

0062, 0108, 0027, 0070

Symphonic ...................

0027

TMK .............................

0063, 0235, 0267

Tatung..........................

0068

Teac.............................

0027, 0068

Technics ......................

0062, 0189, 0066, 0087, 0229

Teknika ........................

0027, 0062, 0064

Thomas........................

0027

Toshiba ........................

0072, 0239, 0237, 0093, 0070

Totevision ....................

0064, 0267

Unitech.........................

0267

Vector ..........................

0072

Vector Research ..........

0065, 0067

Video Concepts ...........

0067, 0088, 0072

Videosonic ...................

0267

Wards ..........................

0062, 0075, 0089, 0027, 0087, 0074,



0072, 0267, 0239, 0069, 0099, 0176,



0108

White Westinghouse....

0305

XR-1000.......................

0099, 0027, 0062

Yamaha .......................

0065, 0068

Zenith...........................

0066, 0060, 0061, 0027, 0506

SAT



AlphaStar .....................

0799

Astro Industries............

0122

BSR .............................

0122

Capetronic ...................

0122

Channel Master ...........

0045, 0239

Chaparral .....................

0080, 0236, 0243

DX Antenna .................

0068

Drake ...........................

0091, 0272, 0045

Echostar.......................

0307, 0802, 0175, 0186, 0296

Expressvu ....................

0802

General Instrument ......

0388, 0896, 0654

Grundig ........................

0200

HTS..............................

0802

Hitachi..........................

0846

Homecable...................

0265

Hughes Network Syst. ..

0776

Hytek............................

0122

IQ .................................

0237

IQ Prism.......................

0237

JVC ..............................

0802

Janeil ...........................

0179

Jerrold..........................

0388, 0654

Legend.........................

0296

Macom .........................

0045

Magnavox ....................

0749, 0751

Memorex......................

0296, 0751

Next Level....................

0896

Panasonic ....................

0179, 0728

Philips ..........................

0227, 0126, 0749, 0751

President......................

0101

Primestar .....................

0654, 0388

Proscan........................

0593

RCA .............................

0593, 0170, 0882

Radio Shack ................

0593

Realistic .......................

0079

STS..............................

0237, 0068

Sony.............................

0666

Star Choice ..................

0896

Star Trak ......................

0207

Toshiba ........................

0109, 0817

Uniden .........................

0265, 0397, 0079, 0101, 0751, 0103,



0749

Zenith...........................

0091, 0883, 0272

43

COUNTRY

COMPANY

ADDRESS

AUSTRALIA

Scan audio Pty. Ltd.

4 Station Street, Thornleigh NSW 2120, Australia

AUSTRIA

Huber & Prohaska GmbH

Taborstraße 95 / Ladestraße 1, Gebäude Hangartner, A-1200 Wien, Austria

BELGIUM

Van der Heyden Audio N.V.

Brusselbaan 278, 9320 Erembodegem, Belgium

BULGARIA

Ariescommerce GmbH

Makedonia Blvd. 16, 1606 Sofia, Bulgaria

CANADA

Lenbrook Industries Limited

633 Granite Court, Pickering, Ontario

CYPRUS

Empire Hifi systems Ltd.

P.O. Box 5604, Nicosia, Cyprus

CZECH REPUBLIC

Audio International

Fugnerova 1, 67801 Blansko, Czech Republic

DENMARK

Hi-Fi Klubben Denmark

Aboulevarden 1, DK-8000 Arhus C., Denmark

DUBAI

V.V.& SONS

P.O. Box 105, Dubai, U.A.E.

ESTONIA

Audio International Baltic

Lo Hu 12, EE0026 Tallin, Estonia

F.Y.R.O.M.

T.P. KODI

ul.Cedomir Kantargiev 21a, Skopje, Former Yugoslavian Republic of Macedonija

FINLAND

Hi-Fi Klubi Finland

Uudenmaankatu 4-6, SF-00120 Helsinki, Finland

FRANCE

Marantz France

A division of Marantz Europe B.V., P.O. Box 301, 92 156 Suresnes Cedex, France

GERMANY

Marantz Deutschland

Hakenbusch 3, 49078 Osnabrück, Germany

GREECE

Adamco S.A.

188, Hippocratous Street, 11471 Athens, Greece

HEADQUARTERS EUROPE:

Marantz Europe B.V.

Building SFF-2, P.O. Box 80002, 5600 JB Eindhoven, The Netherlands

HONG KONG

Marantz Asia Ltd.

Unit 1706, Metroplaza ll, 223 Hing Fong Road, Kwai Fong, N.T., Kowloon, Hong Kong

HUNGARY

Infovox Ltd.

Terez Krt.31, 1067 Budapest, Hungary

ICELAND

Radiobudin HF

Skipholti 19, P.O. Box 424, 121 Reykjavik, Iceland

INDIA

Marantz India

c/o Philips India Ltd., Plot 80, Bhosari Industrial Estate Pune - 411026, India

IRAN

Home Co.

5th floor no 878 Philips Building Enghelab ave, P.O. 11365/7844 Tehran, Iran

IRELAND

Marantz Ireland

Clonskeagh, Dublin 14, Ireland

ISRAEL

Elmor Ltd.

52 Heh Beiyar Street, Kikar Hamedina, Tel Aviv, Israel

ITALY

Marantz Italy

Via Casati 23, 20052 Monza (Milano), Italy, Servizio Consumatori 1678-20026, Numero Verde

JAPAN

Marantz Japan Inc.

35-1 Sagami Ohno 7-Chome, Sagamihara-shi, Kanagawa 228-8505,Japan

KOREA

Mk Enterprises Ltd.

#604 Electro-officetel, 16-58, 3GA Hangang-ro, Yongsan-ku, Seoul 140-013 Korea

KUWAIT

alAlamiah Electronics Intl.

P.O. Box 8196, Salmiah 22052, Kuwait

LATVIA

Ace Ltd.

61, LacPlesa Str., Riga LV 1011, Latvia

LEBANON

AZ Electronics S.A., 1,

P.O. Box 11 2833, Beirut, Lebanon

LITHUANIA

A Accapella Ltd.

Ausros, Vartu G5, Pasazo Skg., 2001 Vilnius, Lithuania

MALAYSIA

Wo Kee Hong Electronics Sdn. Bhd.

102 Jalan SS 21/35, Damansara Utama, 47400 Petaling Jaya, Selangordarul Ehsan, Malaysia

MALTA

Doneo Co Ltd.

78 The Strand, Sliema SLM07, Malta

MAURITIUS

SKR Electronics Ltd.

P.O. Box 685, Bell Village, Port Louis, Mauritius

NETHERLANDS

Marantz Trading

A division of Marantz Europe B.V., Building SFF-2, P.O. Box 80002, 5600 JB Eindhoven, The Netherlands

NEW ZEALAND

Scan audio Pty. Ltd.

4 Station Street, Thornleigh NSW 2120, Australia

NORWAY

Hi-Fi Klubben Norway

Lillegrensen 7, N-0159 Oslo, Norway

OMAN

Mustafa & Jawad Trading CO.

P.O. Box 1918, Ruwi, Oman

POLAND

Marantz Polska

Ul. Marszalkowska 45/49, 00-648 Warszawa, Poland

PORTUGAL

Corel2

Comércio de Electrónica Lda., Av. Luís Bívar, No 85 A, 1050 Lisboa, Portugal

PROFESSIONAL EUROPE

Marantz Professional Products

Kingsbridge House, Padbury Oaks, 575-583 Bath Road, Longford, Middlesex UB7 0EH, U.K.

PROFESSIONAL U.S.A.

Marantz Professional Products

Distributed by: Superscope Technologies Inc., 1000 Corporate Blvd. Ste.D, Aurora, Illino

QATAR

Almana & Partners W.W.L.

P.O. Box 49, Doha, Qatar

REUNION

Vision +

180 Rue du Marechal Leclerc, 97400 Saint Denis, Ile de la Reunion

ROMANIA

Alltrom SRL

Soseaua Bucuresti, Ploiesti 10, Sector 1, Bucharest, Romania

RUSSIA

Trade Company SV

Bld. 2, 7 Montazhnaya Street, 107497 Moscow, Russia

SAUDI ARABIA

Ultimate Fidelity

Sameria Comm. Center, Roadah Dist., P.O. Box 7760, Jeddah 21472, Saudi Arabia

SINGAPORE

Forward Marketing (S) Pte. Ltd.

Wo Kee Hong Centre, 29 Leng Kee Road, Singapore 159099, Singapore

SLOVAKIA

Audio International Slovakia

Nam. SNP 10, 96001 Zvolem, Slovakia

SLOVENIA

Bofex

Smartinska 152, HALA V/3, 61000 Ljubljana, Slovenia

SOUTH AFRICA

Coherent Imports (PTY) Ltd.

P.O. Box 1614, Alberton, 1450, South Africa

SPAIN

Marantz Spain

Martinez Villergas 2, Apartado 2065, Madrid 28027, Spain

SWEDEN

Hi-Fi Klubben A.B.

Tegnersgatan 21, S-412 52 Gotenborg, Sweden

SWITZERLAND

Sound Company AG

Postfach, 8010 Zürich, Switzerland

TAHITI

Covecolor

Av. Prince Hinoi, Cours de l'union sacré, P.O. Box 2334, Papeete, Tahiti

TAIWAN

Pai-Yuing Co. Ltd.

6th No 148 Sung Kiang Road, Taipei 10429, Taiwan R.O.C.

THAILAND

MRZ Standard Co. Ltd.

746-750 Mahachai Road, Wangburapa, Bangkok 10200, Thailand

TURKEY

Penta Elektronic

Sanayi Ve Ticaret Ltd. Sti., Selvi Kokak, No. 4/1, Senlikkoy, 34810 Florya, Istanbul, Turkey

U.K.

Marantz Hifi UK Ltd.

Kingsbridge House, Padbury Oaks, 575-583 Bath Road, Longford, Middlesex UB7 0EH, U.K.

U.S.A.

Marantz America Inc.

440 Medinah Road, Roselle, IL 60172, U.S.A.

YUGOSLAVIA

ITM

Ljutice Bogdana la, Belgrade, Yugoslavia

EXPORT

Marantz Trading

A division of Marantz Europe B.V., Building SFF-2, P.O. Box 80002, 5600 JB Eindhoven, The Netherlands

www.marantz.com











Manufactured under license from Dolby Laboratories. “Dolby”, and “Pro Logic”, are trademarks of Dolby Laboratories. Confidential Unpublished Works. © 1992-1997 Dolby Laboratories, Inc. All rights reserved.

http://www.marantz.co.jp/



is a registered trademark.

Printed in Singapore

99 / 08 MIT 284W851250



3104 215 3618.1



iv

SR4000U DFU cover

Page 4

00.8.6, 0:51 PM

Adobe PageMaker 6.5J/PPC
