SC9000 - Overview
7
Siemens AG Picture for Page: 78 Medical Solutions 22.01.2003
Notes
SC 9000 04316928
ID Part-No. Type Description Wgt. KG TC
(01291355) SPC99 SC 9000 - Spare Parts
7 05207456 E522U Lbl Language SC 7/9000 10.4 DE 0,120 3
Siemens AG Page: 78
SC9000 - ETCO2 01291355
504
505
502
504
504
503
501
500
Siemens AG Picture for Page: 79 Medical Solutions 22.01.2003
SC 9000 - Spare Parts 01291355
ID Part-No. Type Description Comment Wgt. KG NSI
500 REP 04728981 EE56U Exc etCO2 Module SC7/9000 0,800
REP 04319260 E525U Module etCO2 for SC
7/9000XL
501 07268373 E525U
502 07268381 E525U
503 07268415 E525U
504 07268407 E525U Filter & Tubing etCO2 1,000
505 07268399 E525U
Cover Rear etCO2 1,000
Asy Connector etCO2 1,000
Cover Front etCO2 1,000
Asy Pump etCO2 1,000
0,550
Siemens AG Page: 79
SC9000 - Front Panel Subassembly 10.4 01291355
5
3A
5A
8
2
6
3
1
Siemens AG Picture for Page: 79 Medical Solutions 22.01.2003
SC 9000 - Spare Parts 01291355
ID Part-No. Type Description Comment Wgt. KG NSI
Front panel sub assembly
10.4"
1 REP 04725110 E522U Panel Front Asy SC 9000 f. 10.4" 2,340
2 04726738 E522U Panel Front Board A121-10.4 A121 0,600
3 04311622 E533U Optical Encoder Switch
SC5/6/7/9
3A 04316662 E533U Rotary Knob SC 6/7/9000 blue 0,400
5 05190801 E522U Front Bezel SC 9000 10.4 in. without label 1,240
5A 04311374 E533U Rubber Foot SC 5/6/7/9000 0,040
6 04710062 E522U Speaker Asy SC 9000 0,400
8 05584789 E522U Backlight SC 9000 10.4 0,420
0,400
Siemens AG Page: 79
SC9000 - Front Panel Subassembly 9.5 01291355
17A
19A
21
19
18
20
16
17
15
Siemens AG Picture for Page: 79 Medical Solutions 22.01.2003
SC 9000 - Spare Parts 01291355
ID Part-No. Type Description Comment Wgt. KG NSI
Front panel sub assembly
9.5"
15 REP 04725110 E522U Panel Front Asy SC 9000 f. 10.4" 2,340
16 03376964 E522U Front Panel Board A120-9.5 A121 0,130
17 04311622 E533U Optical Encoder Switch
SC5/6/7/9
17A 04316662 E533U Rotary Knob SC 6/7/9000 blue 0,400
18 03379844 E522U Backlight SC 9000 9.5in TFTTV LCD f. 9.5" 1,000
19 05190827 E522U Front Bezel SC 9000 9.5 in. without label 1,360
19A 04311374 E533U Rubber Foot SC 5/6/7/9000 0,040
20 04710062 E522U Speaker Asy SC 9000 0,400
21 05190843 E522U Lbl Kit SC 9000 9.5 in 0,400
0,400
Siemens AG Page: 79
SC9000 - Rear Housing Subassembly 01291355
35
26
31
28
30
990
27
34
34
990
32
27
25
Siemens AG Picture for Page: 79 Medical Solutions 22.01.2003
SC 9000 - Spare Parts 01291355
ID Part-No. Type Description Comment Wgt. KG NSI
Rear housing sub assembly
25 REP 05194332 E522U Board Processor SC 9000
A103
26 REP 03376972 E522U Board Pwr Conversion SC
9000
27 04710054 E522U Fan Asy SC 9000 0,400
28 REP 05189720 E522U Board Front End SC 9000 0,906
30 03376865 E522U Button Ram Card SC
5/6/7/9000
31 05193946 E522U Panel Left w/Lbl SC 9000 with Generic label 0,400
32 03376980 E522U Panel Right w/Lbl SC 9000 0,400
34 03377038 E522U Battery Cover SC 9000 0,400
35 05740381 E522U Chassis Rear SC 9000 must provide S/N, P/N H/W Rev 1,090 X
990 Accesories or
Consumables==> please see
A103 1,350
A130 0,333
0,040
Product Catalogue
Siemens AG Page: 79
SC9000 - Options, Accessories, Cables 01291355
990
83
990
990
990
990
260A
990
Siemens AG Picture for Page: 79 Medical Solutions 22.01.2003
SC 9000 - Spare Parts 01291355
ID Part-No. Type Description Comment Wgt. KG NSI
Option, Connection cables, accessories
83 05194464 E530U Spacer Replacement KIT f. Monitor + Auxilary Docking Stations 0,050
260A 02876113 E2513 Connec NP Hose 0,400
990 Accesories or
Consumables==> please see
Product Catalogue
Siemens AG Page: 79
SC9000 - NBP Module 01291355
534
531
533
532
530
Siemens AG Picture for Page: 79 Medical Solutions 22.01.2003
SC 9000 - Spare Parts 01291355
ID Part-No. Type Description Comment Wgt. KG NSI
NIBP
530 REP 04728965 EE56U Exc NBP Module SC 7/9000 0,740
531 04315771 E522U Rear Cover NIBP Module 1,000
532 04315789 E522U Front Cover NIBP Module 1,000
533 04329210 E524U Manifold NIBP Mod SC9000 1,500
534 07266997 E524U NIBP Mnfold Filter KIT SC
9000
0,500
Siemens AG Page: 79
SC9000 - Hemo2, Hemo4, HemoMed 01291355
512
514
513
511
518
508
516
Siemens AG Picture for Page: 79 Medical Solutions 22.01.2003
510
SC 9000 - Spare Parts 01291355
ID Part-No. Type Description Comment Wgt. KG NSI
HEMO
508 04319435 E529U HEMO2 POD 0,820
REP 04729005 EE56U Exc HEMO2 POD 1,200
510 REP 04315961 E529U HEMO4 POD 0,820
REP 04728957 EE56U Exc HEMO4 POD 1,200
511 07268100 E529U HEMO POD/Med Front Cover 1,000
512 05740399 E529U Panel Front HEMO2 POD includes PCB 0,266
05740407 E529U Panel Front HEMO4 POD includes PCB 0,266
513 07268134 E529U Panel Front HEMO2 0,300
07268126 E529U Panel Front HEMO4 0,190
07268142 E529U Panel Front HEMOMED 0,300
514 04313347 E529U Cover Rear HEMO POD 0,520
05733212 E529U Cover Rear HEMOMED 0,100
516 04717711 E529U Adap HEMO POD 0,400
518 04717703 E529U Mount Clamp Hemo POD 0,350
Siemens AG Page: 79
SC9000 - Service tools 01291355
362
364
363
Siemens AG Picture for Page: 79 Medical Solutions 22.01.2003
SC 9000 - Spare Parts 01291355
ID Part-No. Type Description Comment Wgt. KG NSI
Service tools
362 02877855 EE54U Asy Calibration NBP 1,840
363 02868532 EE54U Calibration Gas etCO2 2,100
364 02868540 EE54U Regulator Cal Gas etCO2 f. Kalibrier-Gas 0,400
Siemens AG Page: 79
SC9000 - IDS 01291355
Reverse view
544
541
543
542
Siemens AG Picture for Page: 79 Medical Solutions 22.01.2003
SC 9000 - Spare Parts 01291355
ID Part-No. Type Description Comment Wgt. KG NSI
IDS
541 07262814 E546U Kit Plastics IDS 0,500
542 05590836 E546U Asy Flex Circuit IDS 0,300
543 03376550 E530U Connec IDS Pwr 2 Pin 10 Pc 0,080
544 05594895 E546U Top Cover IDS 1,500
Siemens AG Page: 79
SC9000 - MIB Options 01291355
545
548 549 550
546
Siemens AG Picture for Page: 79 Medical Solutions 22.01.2003
SC 9000 - Spare Parts 01291355
ID Part-No. Type Description Comment Wgt. KG NSI
545 05590794 E546U MIB Option 1/2/MGM To IDS 0,338
546 05591297 E530U MIB Option 3/4 for IDS 0,200
548 07258739 E523U HW Rework Kit IDS 0,050
549 07266427 E530U HW Rework Kit IDS Pwr Sup
Lbl
550 05199125 E537U Cbl MIB Conv Download 0,220
0,250
Siemens AG Page: 79
SC9015 Rep 01291355
400 410
Siemens AG Picture for Page: 79 Medical Solutions 22.01.2003
SC 9000 - Spare Parts 01291355
ID Part-No. Type Description Comment Wgt. KG NSI
400 REP 05194498 EE56U Exc SC 9015 15in 22,880
410 05194480 EE56U EXC 15 DISPL 15,000
Siemens AG Page: 79
SC9000 - Overview 04316977
7
Siemens AG Picture for Page: 80 Medical Solutions 22.01.2003
SC 9000 04316977
ID Part-No. Type Description Wgt. KG TC
(01291355) SPC99 SC 9000 - Spare Parts
7 05207449 E522U Lbl Language SC 7/9000 10.4 EN 0,120 3
Siemens AG Page: 80
SC9000 - Overview 04728395
7
Siemens AG Picture for Page: 81 Medical Solutions 22.01.2003
SC 9000 04728395
ID Part-No. Type Description Wgt. KG TC
(01291355) SPC99 SC 9000 - Spare Parts
7 05207449 E522U Lbl Language SC 7/9000 10.4 EN 0,120 3
Siemens AG Page: 81
SC9000 - Overview 04316910
7
Siemens AG Picture for Page: 82 Medical Solutions 22.01.2003
SC 9000 04316910
ID Part-No. Type Description Wgt. KG TC
(01291355) SPC99 SC 9000 - Spare Parts
7 05207472 E522U Lbl Language SC 7/9000 10.4 FR 0,140 3
Siemens AG Page: 82
SC9000 - Overview 04316902
7
Siemens AG Picture for Page: 83 Medical Solutions 22.01.2003
SC 9000 04316902
ID Part-No. Type Description Wgt. KG TC
(01291355) SPC99 SC 9000 - Spare Parts
7 05207464 E522U Lbl Language SC 7/9000 10.4 ES 0,250 3
Siemens AG Page: 83
SC9000 - Overview 04316894
7
Siemens AG Picture for Page: 84 Medical Solutions 22.01.2003
SC 9000 04316894
ID Part-No. Type Description Wgt. KG TC
(01291355) SPC99 SC 9000 - Spare Parts
7 05207480 E522U Lbl Language SC 7/9000 10.4 IT 0,140 1
Siemens AG Page: 84
