Maquet Compressor Mini User manual

Compressor Mini 115V 60Hz - Overview

Siemens AG Picture for Page: 2
Medical Solutions 16.10.2002

Compressor Mini 115V 60Hz 06481779

2

1

4

5

10

6

6A

83 7

11

9

12

Siemens AG Picture for Page: 2
Medical Solutions 16.10.2002

Compressor Mini 115V/60HZ 06481779

ID Part-No. Type Description Wgt. KG TC

1 06545482 EH81E Cover complete 3,060 3

2 06545433 EH81E Fuse 8 AT 250V 5X20, 10 each 0,240 1

3 06545466 EH81E Drainage bottle with hose 0,400 3

4 06545359 EH81E Compressor with motor, 115V/60Hz 8,760 1

5 06545458 EH81E Shock absorber, 4 each 0,080 2

6 06545417 EH81E Circuit board 0,300 1

6A 06545425 EH81E Fuse 0.800AT 250V 5X20, 10 each 0,080 1

7 06545375 EH81E Thermoelectric cooler 1,400 1

8 06545409 EH81E Fan 12V 0,480 1

9 06545474 EH81E Drainage valve 0,400 1

10 06595479 EH81E Motor relay 0,300 1

11 06545490 EH81E Stand by valve 0,600 1

12 06545383 EH81E Radial fan 115V/60Hz 1,360 1

(01295380) SPC99 Compressor Mini Service tools 0,000
