Maplesoft MAPLE Advanced Programming Guide

Maple
Advanced Programming
Guide
M. B. Monagan K. O. Geddes K. M. Heal
G. Labahn S. M. Vorkoetter J. McCarron
P. DeMarco
Maplesoft, a division of Waterloo Maple Inc. 1996-2010.
ii
Maplesoft, Maple, and Maplet are all trademarks of Waterloo Maple Inc.
© Maplesoft, a division of Waterloo Maple Inc. 1996-2010. All rights reserved.
Information in this document is subject to change without notice and does not represent a commitment on the part of the vendor. The software described in this document is furnished under a license agreement and may be used or copied only in accordance with the agreement. It is against the law to copy the software on any medium except as specifically allowed in the agreement.
Windows is a registered trademark of Microsoft Corporation. Java and all Java based marks are trademarks or registered trademarks of Sun Microsystems, Inc. in the United States and other countries. Maplesoft is independent of Sun Microsystems, Inc. All other trademarks are the property of their respective owners.
This document was produced using a special version of Maple that reads and updates LaTeX files.
Printed in Canada
ISBN 978-1-897310-96-0
Contents
Preface 1
Audience . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Worksheet Graphical Interface . . . . . . . . . . . . . . . . . . 2
Manual Set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Customer Feedback . . . . . . . . . . . . . . . . . . . . . . . . . 3
1 Procedures, Variables, and Extending Maple 5
Prerequisite Knowledge . . . . . . . . . . . . . . . . . . . 5
In This Chapter . . . . . . . . . . . . . . . . . . . . . . . 5
1.1 Nested Procedures . . . . . . . . . . . . . . . . . . . . . . 5
Scoping Rules . . . . . . . . . . . . . . . . . . . . . . . . . 6
Local Versus Global Variables . . . . . . . . . . . . . . . . 6
The Quick-Sort Algorithm . . . . . . . . . . . . . . . . . . 8
Example . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Creating a Uniform Random Number Generator . . . . . 11
1.2 Procedures That Return Procedures . . . . . . . . . . . . 14
Conveying Values . . . . . . . . . . . . . . . . . . . . . . . 14
Creating a Newton Iteration . . . . . . . . . . . . . . . . . 14
Example 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Example 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
A Shift Operator . . . . . . . . . . . . . . . . . . . . . . . 17
1.3 Local Variables and Invoking Procedures . . . . . . . . . . 19
Example 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Example 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Procedure as a Returned Object . . . . . . . . . . . . . . 22
Example 3 . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Example 4 . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Exercises . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
1.4 Interactive Input . . . . . . . . . . . . . . . . . . . . . . . 27
iii
iv Contents
Reading Strings from the Terminal . . . . . . . . . . . . . 27
Example 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Reading Expressions from the Terminal . . . . . . . . . . 28
Example 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Converting Strings to Expressions . . . . . . . . . . . . . 30
1.5 Extending Maple . . . . . . . . . . . . . . . . . . . . . . . 31
Defining New Types . . . . . . . . . . . . . . . . . . . . . 31
Exercises . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Neutral Operators . . . . . . . . . . . . . . . . . . . . . . 33
Example 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Exercise . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Extending Commands . . . . . . . . . . . . . . . . . . . . 39
1.6 Conclusion . . . . . . . . . . . . . . . . . . . . . . . . . . 42
2 Programming with Modules 43
Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Examples . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Module Versus Procedure . . . . . . . . . . . . . . . . . . 45
Accessing Module Exports . . . . . . . . . . . . . . . . . . 46
In This Chapter . . . . . . . . . . . . . . . . . . . . . . . 46
2.1 Syntax and Semantics . . . . . . . . . . . . . . . . . . . . 47
The Module Definition . . . . . . . . . . . . . . . . . . . . 47
The Module Body . . . . . . . . . . . . . . . . . . . . . . 48
Module Parameters . . . . . . . . . . . . . . . . . . . . . . 48
Named Modules . . . . . . . . . . . . . . . . . . . . . . . 48
Declarations . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Exported Local Variables . . . . . . . . . . . . . . . . . . 52
Module Options . . . . . . . . . . . . . . . . . . . . . . . . 57
Implicit Scoping Rules . . . . . . . . . . . . . . . . . . . . 58
Lexical Scoping Rules . . . . . . . . . . . . . . . . . . . . 58
Modules and Types . . . . . . . . . . . . . . . . . . . . . . 60
Example: A Symbolic Differentiator . . . . . . . . . . . . 61
2.2 Records . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
2.3 Packages . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
What Is a Package . . . . . . . . . . . . . . . . . . . . . . 78
Writing Maple Packages by Using Modules . . . . . . . . 80
The LinkedList Package . . . . . . . . . . . . . . . . . . 80
Code Coverage Profiling Package . . . . . . . . . . . . . . 87
The Shapes Package . . . . . . . . . . . . . . . . . . . . . 95
2.4 The use Statement . . . . . . . . . . . . . . . . . . . . . . 103
Operator Rebinding . . . . . . . . . . . . . . . . . . . . . 106
Contents v
2.5 Modeling Objects . . . . . . . . . . . . . . . . . . . . . . . 108
Priority Queues . . . . . . . . . . . . . . . . . . . . . . . . 111
An Object-oriented Shapes Package . . . . . . . . . . . . 115
2.6 Interfaces and Implementations . . . . . . . . . . . . . . . 117
Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . 118
Generic Graph Algorithms . . . . . . . . . . . . . . . . . . 124
Quotient Fields . . . . . . . . . . . . . . . . . . . . . . . . 129
A Generic Group Implementation . . . . . . . . . . . . . . 138
2.7 Extended Example: A Search Engine . . . . . . . . . . . . 159
Introduction to Searching . . . . . . . . . . . . . . . . . . 159
Inverted Term Occurrence Indexing . . . . . . . . . . . . . 161
The Vector Space Model . . . . . . . . . . . . . . . . . . . 164
Term Weighting . . . . . . . . . . . . . . . . . . . . . . . . 167
Building a Search Engine Package . . . . . . . . . . . . . 168
Latent Semantic Analysis . . . . . . . . . . . . . . . . . . 172
The Search Engine Package . . . . . . . . . . . . . . . . . 173
Using the Package . . . . . . . . . . . . . . . . . . . . . . 180
2.8 Conclusion . . . . . . . . . . . . . . . . . . . . . . . . . . 184
3 Input and Output 185
In This Chapter . . . . . . . . . . . . . . . . . . . . . . . 185
3.1 A Tutorial Example . . . . . . . . . . . . . . . . . . . . . 186
3.2 File Types and Modes . . . . . . . . . . . . . . . . . . . . 190
Buffered Files versus Unbuffered Files . . . . . . . . . . . 190
Text Files versus Binary Files . . . . . . . . . . . . . . . . 190
Read Mode versus Write Mode . . . . . . . . . . . . . . . 191
The default and terminal Files . . . . . . . . . . . . . . 191
3.3 File Descriptors versus File Names . . . . . . . . . . . . . 192
3.4 File Manipulation Commands . . . . . . . . . . . . . . . . 193
Opening and Closing Files . . . . . . . . . . . . . . . . . . 193
Position Determination and Adjustment . . . . . . . . . . 194
Detecting the End of a File . . . . . . . . . . . . . . . . . 195
Determining File Status . . . . . . . . . . . . . . . . . . . 195
Removing Files . . . . . . . . . . . . . . . . . . . . . . . . 196
3.5 Input Commands . . . . . . . . . . . . . . . . . . . . . . . 197
Reading Text Lines from a File . . . . . . . . . . . . . . . 197
Reading Arbitrary Bytes from a File . . . . . . . . . . . . 197
Formatted Input . . . . . . . . . . . . . . . . . . . . . . . 198
Reading Maple Statements . . . . . . . . . . . . . . . . . 204
Reading Tabular Data . . . . . . . . . . . . . . . . . . . . 204
3.6 Output Commands . . . . . . . . . . . . . . . . . . . . . . 206
vi Contents
Configuring Output Parameters Using the interface Com-
mand . . . . . . . . . . . . . . . . . . . . . . . . . 206
One-Dimensional Expression Output . . . . . . . . . . . . 206
Two-Dimensional Expression Output . . . . . . . . . . . . 207
Writing Maple Strings to a File . . . . . . . . . . . . . . . 210
Writing Bytes to a File . . . . . . . . . . . . . . . . . . . . 211
Formatted Output . . . . . . . . . . . . . . . . . . . . . . 211
Writing Tabular Data . . . . . . . . . . . . . . . . . . . . 215
Flushing a Buffered File . . . . . . . . . . . . . . . . . . . 217
Redirecting the default Output Stream . . . . . . . . . . 217
3.7 Conversion Commands . . . . . . . . . . . . . . . . . . . . 218
Conversion between Strings and Lists of Integers . . . . . 218
Parsing Maple Expressions and Statements . . . . . . . . 219
Formatted Conversion to and from Strings . . . . . . . . . 220
3.8 Notes to C Programmers . . . . . . . . . . . . . . . . . . . 221
3.9 Conclusion . . . . . . . . . . . . . . . . . . . . . . . . . . 222
4 Numerical Programming in Maple 223
Floating-Point Calculations . . . . . . . . . . . . . . . . . 223
In This Chapter . . . . . . . . . . . . . . . . . . . . . . . 223
Why Use Numerical Computations . . . . . . . . . . . . . 223
4.1 The Basics of evalf . . . . . . . . . . . . . . . . . . . . . 224
4.2 Hardware Floating-Point Numbers . . . . . . . . . . . . . 227
Newton’s Method . . . . . . . . . . . . . . . . . . . . . . . 230
Computing with Arrays of Numbers . . . . . . . . . . . . 232
4.3 Floating-Point Models in Maple . . . . . . . . . . . . . . . 235
Software Floats . . . . . . . . . . . . . . . . . . . . . . . . 235
Roundoff Error . . . . . . . . . . . . . . . . . . . . . . . . 236
4.4 Extending the evalf Command . . . . . . . . . . . . . . . 238
Defining New Constants . . . . . . . . . . . . . . . . . . . 238
Defining New Functions . . . . . . . . . . . . . . . . . . . 240
4.5 Using the Matlab Package . . . . . . . . . . . . . . . . . . 243
4.6 Conclusion . . . . . . . . . . . . . . . . . . . . . . . . . . 244
5 Programming with Maple Graphics 245
Maple Plots . . . . . . . . . . . . . . . . . . . . . . . . . . 245
Creating Plotting Procedures . . . . . . . . . . . . . . . . 245
In This Chapter . . . . . . . . . . . . . . . . . . . . . . . 245
5.1 Basic Plotting Procedures . . . . . . . . . . . . . . . . . . 246
Altering a Plot . . . . . . . . . . . . . . . . . . . . . . . . 248
5.2 Programming with Plotting Library Procedures . . . . . . 249
Contents vii
Plotting a Loop . . . . . . . . . . . . . . . . . . . . . . . . 249
Exercise . . . . . . . . . . . . . . . . . . . . . . . . . . . . 251
A Ribbon Plot Procedure . . . . . . . . . . . . . . . . . . 251
5.3 Maple Plot Data Structures . . . . . . . . . . . . . . . . . 254
The PLOT Data Structure . . . . . . . . . . . . . . . . . . 256
Arguments Inside a PLOT Structure . . . . . . . . . . . . . 257
A Sum Plot . . . . . . . . . . . . . . . . . . . . . . . . . . 259
The PLOT3D Data Structure . . . . . . . . . . . . . . . . . 262
Objects Inside a PLOT3D Data Structure . . . . . . . . . . 264
5.4 Programming with Plot Data Structures . . . . . . . . . . 266
Writing Graphic Primitives . . . . . . . . . . . . . . . . . 266
Plotting Gears . . . . . . . . . . . . . . . . . . . . . . . . 268
Polygon Meshes . . . . . . . . . . . . . . . . . . . . . . . . 272
5.5 Programming with the plottools Package . . . . . . . . 273
A Pie Chart . . . . . . . . . . . . . . . . . . . . . . . . . . 275
A Dropshadow Procedure . . . . . . . . . . . . . . . . . . 276
Creating a Tiling . . . . . . . . . . . . . . . . . . . . . . . 278
A Smith Chart . . . . . . . . . . . . . . . . . . . . . . . . 280
Exercise . . . . . . . . . . . . . . . . . . . . . . . . . . . . 281
Modifying Polygon Meshes . . . . . . . . . . . . . . . . . 281
5.6 Vector Field Plots . . . . . . . . . . . . . . . . . . . . . . 286
Drawing a Vector . . . . . . . . . . . . . . . . . . . . . . . 286
Generating a Vector Plot Field . . . . . . . . . . . . . . . 288
5.7 Generating Grids of Points . . . . . . . . . . . . . . . . . 296
5.8 Animation . . . . . . . . . . . . . . . . . . . . . . . . . . . 301
Animation in Static Form . . . . . . . . . . . . . . . . . . 302
Graphical Object as Input . . . . . . . . . . . . . . . . . . 302
Methods for Creating Animations . . . . . . . . . . . . . . 303
Two and Three Dimensions . . . . . . . . . . . . . . . . . 305
Demonstrating Physical Objects in Motion . . . . . . . . 306
5.9 Programming with Color . . . . . . . . . . . . . . . . . . . 308
Generating Color Tables . . . . . . . . . . . . . . . . . . . 309
Using Animation . . . . . . . . . . . . . . . . . . . . . . . 310
Adding Color Information to Plots . . . . . . . . . . . . . 312
Creating A Chess Board Plot . . . . . . . . . . . . . . . . 315
5.10 Conclusion . . . . . . . . . . . . . . . . . . . . . . . . . . 316
6 Advanced Connectivity 319
In This Chapter . . . . . . . . . . . . . . . . . . . . . . . 319
Code Generation . . . . . . . . . . . . . . . . . . . . . . . 319
External Calling: Using Compiled Code in Maple . . . . . 319
viii Contents
OpenMaple: Using Maple in Compiled Code . . . . . . . . 319
6.1 Code Generation . . . . . . . . . . . . . . . . . . . . . . . 319
The CodeGeneration Package . . . . . . . . . . . . . . . . 319
Calling CodeGeneration Functions . . . . . . . . . . . . . 320
Translation Process . . . . . . . . . . . . . . . . . . . . . . 321
Extending the CodeGeneration Translation Facilities . . . 324
Defining a Custom Translator . . . . . . . . . . . . . . . . 325
6.2 External Calling: Using Compiled Code in Maple . . . . . 329
Method 1: Calling External Functions . . . . . . . . . . . 331
External Definition . . . . . . . . . . . . . . . . . . . . . . 333
Type Specification . . . . . . . . . . . . . . . . . . . . . . 334
Scalar Data Formats . . . . . . . . . . . . . . . . . . . . . 335
Structured Data Formats . . . . . . . . . . . . . . . . . . 335
Specifying Argument Passing Conventions . . . . . . . . . 337
Method 2: Generating Wrappers . . . . . . . . . . . . . . 337
Additional Types and Options . . . . . . . . . . . . . . . 338
Structured Data Formats . . . . . . . . . . . . . . . . . . 338
Enumerated Types . . . . . . . . . . . . . . . . . . . . . . 338
Procedure Call Formats . . . . . . . . . . . . . . . . . . . 339
Call by Reference . . . . . . . . . . . . . . . . . . . . . . . 339
Array Options . . . . . . . . . . . . . . . . . . . . . . . . 339
Non-passed Arguments . . . . . . . . . . . . . . . . . . . . 340
Argument Checking and Efficiency Considerations . . . . 341
Conversions . . . . . . . . . . . . . . . . . . . . . . . . . . 341
Compiler Options . . . . . . . . . . . . . . . . . . . . . . . 343
Evaluation Rules . . . . . . . . . . . . . . . . . . . . . . . 347
Method 3: Customizing Wrappers . . . . . . . . . . . . . . 349
External Function Entry Point . . . . . . . . . . . . . . . 349
Inspecting Automatically Generated Wrappers . . . . . . 351
External API . . . . . . . . . . . . . . . . . . . . . . . . . 355
System Integrity . . . . . . . . . . . . . . . . . . . . . . . 373
6.3 OpenMaple: Using Maple in Compiled Code . . . . . . . . 373
Interface Overview . . . . . . . . . . . . . . . . . . . . . . 374
Call-back Functions . . . . . . . . . . . . . . . . . . . . . 379
Maple Online Help Database . . . . . . . . . . . . . . . . 385
Technical Issues . . . . . . . . . . . . . . . . . . . . . . . . 388
File Structure . . . . . . . . . . . . . . . . . . . . . . . . . 388
Building the Sample Program . . . . . . . . . . . . . . . . 389
6.4 Conclusion . . . . . . . . . . . . . . . . . . . . . . . . . . 391
A Internal Representation and Manipulation 395
Contents ix
A.1 Internal Organization . . . . . . . . . . . . . . . . . . . . 395
Components . . . . . . . . . . . . . . . . . . . . . . . . . . 396
Internal Functions . . . . . . . . . . . . . . . . . . . . . . 396
Flow of Control . . . . . . . . . . . . . . . . . . . . . . . . 397
A.2 Internal Representations of Data Types . . . . . . . . . . 398
Logical AND . . . . . . . . . . . . . . . . . . . . . . . . . 399
Assignment Statement . . . . . . . . . . . . . . . . . . . . 399
Binary Object . . . . . . . . . . . . . . . . . . . . . . . . . 399
Break Statement . . . . . . . . . . . . . . . . . . . . . . . 399
Name Concatenation . . . . . . . . . . . . . . . . . . . . . 400
Complex Value . . . . . . . . . . . . . . . . . . . . . . . . 400
Communications Control Structure . . . . . . . . . . . . . 400
Type Specification or Test . . . . . . . . . . . . . . . . . . 401
Debug . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 401
Equation or Test for Equality . . . . . . . . . . . . . . . . 401
Error Statement . . . . . . . . . . . . . . . . . . . . . . . 401
Expression Sequence . . . . . . . . . . . . . . . . . . . . . 402
Floating-Point Number . . . . . . . . . . . . . . . . . . . . 402
For/While Loop Statement . . . . . . . . . . . . . . . . . 402
Foreign Data . . . . . . . . . . . . . . . . . . . . . . . . . 403
Function Call . . . . . . . . . . . . . . . . . . . . . . . . . 404
Garbage . . . . . . . . . . . . . . . . . . . . . . . . . . . . 404
Hardware Float . . . . . . . . . . . . . . . . . . . . . . . . 404
If Statement . . . . . . . . . . . . . . . . . . . . . . . . . . 405
Logical IMPLIES . . . . . . . . . . . . . . . . . . . . . . . 405
Not Equal or Test for Inequality . . . . . . . . . . . . . . 405
Negative Integer . . . . . . . . . . . . . . . . . . . . . . . 405
Positive Integer . . . . . . . . . . . . . . . . . . . . . . . . 406
Less Than or Equal . . . . . . . . . . . . . . . . . . . . . . 406
Less Than . . . . . . . . . . . . . . . . . . . . . . . . . . . 407
Lexically Scoped Variable within an Expression . . . . . . 407
List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 407
Local Variable within an Expression . . . . . . . . . . . . 408
Member . . . . . . . . . . . . . . . . . . . . . . . . . . . . 408
Module Definition . . . . . . . . . . . . . . . . . . . . . . 408
Module Instance . . . . . . . . . . . . . . . . . . . . . . . 410
Identifier . . . . . . . . . . . . . . . . . . . . . . . . . . . . 410
Next Statement . . . . . . . . . . . . . . . . . . . . . . . . 411
Logical NOT . . . . . . . . . . . . . . . . . . . . . . . . . 411
Logical OR . . . . . . . . . . . . . . . . . . . . . . . . . . 411
Procedure Parameter within an Expression . . . . . . . . 411
x Contents
Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 412
Procedure Definition . . . . . . . . . . . . . . . . . . . . . 412
Product, Quotient, Power . . . . . . . . . . . . . . . . . . 414
Range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 414
Rational . . . . . . . . . . . . . . . . . . . . . . . . . . . . 414
Read Statement . . . . . . . . . . . . . . . . . . . . . . . . 415
Return Statement . . . . . . . . . . . . . . . . . . . . . . 415
Rectangular Table . . . . . . . . . . . . . . . . . . . . . . 415
Save Statement . . . . . . . . . . . . . . . . . . . . . . . . 417
Series . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 417
Set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 417
Statement Sequence . . . . . . . . . . . . . . . . . . . . . 417
Stop Maple . . . . . . . . . . . . . . . . . . . . . . . . . . 418
String . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 418
Sum, Difference . . . . . . . . . . . . . . . . . . . . . . . . 418
Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 419
Table Reference . . . . . . . . . . . . . . . . . . . . . . . . 419
Try Statement . . . . . . . . . . . . . . . . . . . . . . . . 419
Unevaluated Expression . . . . . . . . . . . . . . . . . . . 420
Use Statement . . . . . . . . . . . . . . . . . . . . . . . . 420
Logical XOR . . . . . . . . . . . . . . . . . . . . . . . . . 421
Polynomials with Integer Coefficients modulo n . . . . . . 421
A.3 The Use of Hashing in Maple . . . . . . . . . . . . . . . . 422
Basic Hash Tables . . . . . . . . . . . . . . . . . . . . . . 422
Dynamic Hash Tables . . . . . . . . . . . . . . . . . . . . 423
The Simplification Table . . . . . . . . . . . . . . . . . . . 423
The Name Table . . . . . . . . . . . . . . . . . . . . . . . 424
Remember Tables . . . . . . . . . . . . . . . . . . . . . . . 425
Maple Language Arrays and Tables . . . . . . . . . . . . . 426
Maple Language Rectangular Tables . . . . . . . . . . . . 426
A.4 Portability . . . . . . . . . . . . . . . . . . . . . . . . . . . 427
Index 429
Preface
This manual describes advanced MapleTMprogramming concepts, includ­ing:
Variable scope, procedures, modules, and packages
Advanced input and output
Numerical programming
Programming with Maple plots
Connectivity: translating Maple code to other programming lan-
guages, calling external libraries from Maple, and calling Maple code from external libraries
Internal representation and manipulation
Audience
This manual provides information for experienced Maple programmers. You should be familiar with the following.
Maple Online Help Introduction
Example worksheets
How to use Maple interactively
The
Introductory Programming Guide
1
2 Preface
Worksheet Graphical Interface
You can access the power of the Maple computation engine through a vari­ety of user interfaces: the standard worksheet, the command-line1version,
r
the classic worksheet (not available on Macintosh
), and custom-built
MapletTMapplications. The full Maple system is available through all of these interfaces. In this manual, any references to the graphical Maple interface refer to the standard worksheet interface. For more information on the various interface options, refer to the ?versions help page.
Manual Set
There are three other manuals available for Maple users, the
Maple Get-
ting Started Guide, the Maple User Manual, and the Maple Introduc­tory Programming Guide.
2
The Maple Getting Started Guide provides extensive information for new users on using Maple, and the resources available in the soft­ware and on the Maplesoft Web site (http://www.maplesoft.com).
The
Maple User Manual provides an overview of the Maple software including Document and Worksheet modes, performing computations, creating plots and animations, creating and using Maplets, creating mathematical documents, expressions, basic programming informa­tion, and basic input and output information.
The Maple Introductory Programming Guide introduces the basic Maple programming concepts, such as expressions, data structures, looping and decision mechanisms, procedures, input and output, de­bugging, and the Maplet User Interface Customization System.
The Maple software also has an online help system. The Maple help sys­tem allows you to search in many ways and is always available. There are also examples that you can copy, paste, and execute immediately.
1
The command-line version provides optimum performance. However, the worksheet interface is easier to use and renders typeset, editable math output and higher quality plots.
2
The Student Edition does not include the Maple Introductory Programming Guide and the Maple Advanced Programming Guide. These programming guides can be pur- chased from school and specialty bookstores or directly from Maplesoft.
Conventions 3
Conventions
This manual uses the following typographical conventions.
courier font - Maple command, package name, and option name
bold roman font - dialog, menu, and text field
italics - new or important concept, option name in a list, and manual
titles
Note - additional information relevant to the section
Important - information that must be read and followed
Customer Feedback
Maplesoft welcomes your feedback. For suggestions and comments related to this and other manuals, email doc@maplesoft.com
.
4 Preface
1 Procedures, Variables,
and Extending Maple
Prerequisite Knowledge
Before reading this chapter, you must have an understanding of Maple evaluation rules for variables and parameters as described in chapter 6 of
Introductory Programming Guide.
the
In This Chapter
Nested Procedures You can define a Maple procedure within another
Maple procedure.
Procedures That Return Procedures You can create procedures that return procedures by using Maple evaluation rules.
Local Variables Local variables can exist after the procedure which cre­ated them has exited. This feature allows a procedure to return a proce­dure. The new procedure requires a unique place to store information.
Interactive Input You can write interactive procedures, querying the user for missing information or creating an interactive tutorial or a test.
Extending Maple The Maple software includes useful mechanisms for extending Maple functionality, which reduce the need to write special­purpose procedures. Several Maple commands can be extended.
1.1 Nested Procedures
You can define a Maple procedure inside another Maple procedure. Some Maple commands are very useful inside a procedure. In the worksheet
5
6 Chapter 1: Procedures, Variables, and Extending Maple
environment, the map command is used to apply an operation to the elements of a structure. For example, you can divide each element of a list by a number, such as 8.
>
lst := [8, 4, 2, 16]:
>
map( x->x/8, lst);
1
1
,
[1,
, 2]
2
4
Consider a variation on the map command, which appears in the fol-
lowing procedure.
Example This new procedure divides each element of a list by the first element of that list.
>
nest := proc(x::list)
>
local v;
>
v := x[1];
>
map( y -> y/v, x );
>
end proc:
>
nest(lst);
1
1
,
[1,
, 2]
2
4
The procedure nest contains a second procedure, map, which in this case is the Maple command map. Maple applies its lexical scoping rules, which declare the v within the call to map as the same v as in the outer procedure, nest.
Scoping Rules
This section explains Maple scoping rules. You will learn how Maple de­termines which variables are local to a procedure and which are global. You must have a basic understanding of Maple evaluation rules for pa­rameters, and for local and global variables. For more information, refer to chapter 6 of the
Introductory Programming Guide.
Local Versus Global Variables
In general, when writing a procedure, you should explicitly declare which variables are global and which are local. Declaring the scope of the vari­ables makes your procedure easier to read and debug. However, sometimes declaring the variables is not the best method. In the previous nest pro­cedure, the variable in the map command is defined by the surrounding
1.1 Nested Procedures 7
procedure. What happens if you define this variable, v, as local to the invocation of the procedure within map?
>
nest2 := proc(x::list)
>
local v;
>
v := x[1];
>
map( proc(y) local v; y/v; end, x );
>
end proc:
>
nest2(lst);
4
2
8
,
[
v
16
,
,
v
]
v
v
The nest2 procedure produces different results. When the variables are declared in the inner procedure, the proper values from the enclosing procedure are not used. Either a variable is local to a procedure and certain procedures that are completely within it, or it is global to the entire Maple session.
Rule Maple determines whether a variable is local or global, from the inside procedure to the outside procedure. The name of the variable is searched for among:
1. Parameters of the inner procedure
2. Local declarations and global declarations of the inner procedure
3. Parameters of the outside procedure
4. Local and global declarations of the outside procedure
5. Implicitly declared local variables of any surrounding procedure(s)
If found, that specifies the binding of the variable.
If, using the above rule, Maple cannot determine whether a variable is global or local, the following default decisions are made.
If a variable appears on the
left side of an explicit assignment or as the controlling variable of a for loop, Maple regards the variable as local.
Otherwise, Maple regards the variable as global to the whole session. In particular, Maple assumes by default that the variables you pass as arguments to other procedures, which may set their values, are global.
8 Chapter 1: Procedures, Variables, and Extending Maple
The Quick-Sort Algorithm
Sorting a few numbers is quick using any method, but sorting large amounts of data can be very time consuming; thus, finding efficient meth­ods is important.
The following quick-sort algorithm is a classic algorithm. The key to
understanding this algorithm is to understand the operation of partition­ing. This involves choosing any one number from the array that you are about to sort. Then, you reposition the numbers in the array that are less than the number that you chose to one end of the array and reposition numbers that are greater to the other end. Lastly, you insert the chosen number between these two groups.
At the end of the partitioning, you have not yet entirely sorted the
array, because the numbers less than or greater than the one you chose may still be in their original order. This procedure divides the array into two smaller arrays which are easier to sort than the original larger one. The partitioning operation has thus made the work of sorting much eas­ier. You can bring the array one step closer in the sorting process by partitioning each of the two smaller arrays. This operation produces four smaller arrays. You sort the entire array by repeatedly partitioning the smaller arrays.
Example
The partition procedure uses an array to store the list because you can change the elements of an array directly. Thus, you can sort the array in place and not waste any space generating extra copies.
The quicksort procedure is easier to understand if you look at the
procedure partition in isolation first. This procedure accepts an array of numbers and two integers. The two integers are element numbers of the array, indicating the portion of the array to partition. While you could possibly choose any of the numbers in the array to partition around, this procedure chooses the last element of the section of the array for that purpose, namely A[n]. The intentional omission of global and local statements shows which variables Maple recognizes as local and which are global by default. It is recommended, however, that you not make this omission in your procedures.
>
partition := proc(A::array(1, numeric),
> > > > > >
i := m; j := n; x := A[j]; while i<j do
if A[i]>x then
m::posint, n::posint)
1.1 Nested Procedures 9
> > > > > > > > > >
Warning, ‘i‘ is implicitly declared local to procedure ‘partition‘ Warning, ‘j‘ is implicitly declared local to procedure ‘partition‘ Warning, ‘x‘ is implicitly declared local to procedure ‘partition‘
end do; A[j] := x; eval(A);
end proc:
A[j] := A[i]; j := j-1; A[i] := A[j];
else
i := i+1;
end if;
Maple declares i, j, and x local because the partition procedure con-
tains explicit assignments to those variables. The partition procedure also assigns explicitly to A, but A is a parameter, not a local variable. Because you do not assign to the name eval, Maple makes it the global name which refers to the eval command.
After partitioning the array a in the following, all the elements less
than 3 precede 3 but they are in no particular order; similarly, the elements larger than 3 come after 3.
>
a := array( [2,4,1,5,3] );
a := [2, 4, 1, 5, 3]
>
partition( a, 1, 5);
[2, 1, 3, 5, 4]
The partition procedure modifies its first argument, changing a.
>
eval(a);
[2, 1, 3, 5, 4]
The final step in assembling the quicksort procedure is to insert
the partition procedure within an outer procedure. The outer proce­dure first defines the partition subprocedure, then partitions the array. In general, avoid inserting one procedure in another. However, you will
10 Chapter 1: Procedures, Variables, and Extending Maple
encounter situations in following sections of this chapter in which it is nec­essary to nest procedures. Since the next step is to partition each of the two subarrays by calling quicksort recursively, partition must return the location of the element which divides the partition.
Example This example illustrates the role of nested procedures. The outer procedure, quicksort, contains the inner procedure, partition.
>
quicksort := proc(A::array(1, numeric),
> >
local partition, p;
> >
partition := proc(m,n)
> > > > > > > > > > > > > > > > > > > > > > > >
end proc:
i := m; j := n; x := A[j]; while i<j do
if A[i]>x then
A[j] := A[i]; j := j-1; A[i] := A[j];
else
i := i+1;
end if; end do; A[j] := x; p := j;
end proc:
if m<n then # if m>=n there is nothing to do
p:=partition(m, n); quicksort(A, m, p-1); quicksort(A, p+1, n);
end if;
eval(A);
m::integer, n::integer)
Warning, ‘i‘ is implicitly declared local to procedure ‘partition‘ Warning, ‘j‘ is implicitly declared local to procedure ‘partition‘ Warning, ‘x‘ is implicitly declared local to procedure ‘partition‘
>
a := array( [2,4,1,5,3] );
a := [2, 4, 1, 5, 3]
1.1 Nested Procedures 11
>
quicksort( a, 1, 5);
[1, 2, 3, 4, 5]
>
eval(a);
[1, 2, 3, 4, 5]
Maple determines that the A and p variables in the partition sub­procedure are defined by the parameter and local variable (respectively) from the outer quicksort procedure and everything works as planned. The variable A can be passed as a parameter to the partition subproce­dure (as in the stand-alone partition procedure). However, A does not need to be passed because, by using Maple scoping rules, it is available to the inner procedure.
Creating a Uniform Random Number Generator
If you want to use Maple to simulate physical experiments, you likely need a random number generator. The uniform distribution is particu­larly simple: any real number in a given range is equally likely. Thus, a uniform random number generator is a procedure that returns a ran­dom floating-p oint number within a certain range. This section develops the procedure, uniform, which creates uniform random number genera­tors.
The rand command generates a procedure which returns random
. For example, rand(4..7) generates a procedure that returns ran-
tegers
dom integers between 4 and 7, inclusive.
>
f := rand(4..7):
>
seq( f(), i=1..20 );
in-
4, 6, 6, 5, 4, 7, 5, 5, 6, 7, 7, 5, 4, 6, 7, 4, 7, 4, 5, 6
The uniform procedure is similar to rand but returns floating-point numbers rather than integers. You can use rand to generate random floating-point numbers between 4 and 7 by multiplying and dividing by 10^Digits.
>
f := rand( 4*10^Digits..7*10^Digits ) / 10^Digits:
>
f();
12 Chapter 1: Procedures, Variables, and Extending Maple
9482484381 2000000000
The procedure f returns fractions rather than floating-point numbers so you must compose it with evalf; that is, use evalf(f()). Alterna­tively, you can perform this operation by using the Maple composition operator, @.
>
(evalf @ f)();
5.709873593
The following uniform procedure uses evalf to evaluate the constants in the range specification, r, to floating-point numbers, the map command to multiply both endpoints of the range by 10^Digits, and round to round the results to integers.
>
uniform := proc( r::constant..constant )
>
local intrange, f;
>
intrange := map( x -> round(x*10^Digits), evalf(r) );
>
f := rand( intrange );
>
(evalf @ eval(f)) / 10^Digits;
>
end proc:
You can now generate random floating-point numbers between 4 and 7.
>
U := uniform(4..7):
>
seq( U(), i=1..20 );
4.906178722, 4.342783855, 5.845560096, 5.720041409,
4.477799871, 6.851756647, 4.806779819,
5.504811662, 6.060694649, 6.238504456,
6.440125341, 5.459747079, 5.177099028,
5.921894219, 6.758265656, 5.792661441,
4.988664160, 4.994950840, 4.374705325,
5.782030884
The uniform procedure has a serious flaw: uniform uses the current value of Digits to construct intrange; thus, U depends on the value of Digits when uniform creates it. On the other hand, the evalf command within U uses the value of Digits that is current when you invoke U. These two values are not always identical.
1.1 Nested Procedures 13
>
U := uniform( cos(2)..sin(1) ):
>
Digits := 15:
>
seq( U(), i=1..8 );
0.440299060400000, 0.366354657300000,
0.0671154810000000, 0.224056281100000,
0.131130435700000, 0.496918815000000,
0.464843910000000, 0.458498021000000
The proper design choice here is that U should depend only on the value of Digits when you invoke U. The following version of uniform accomplishes this by placing the entire computation inside the procedure that uniform returns.
>
uniform := proc( r::constant..constant )
> >
proc()
> > > > > > >
end proc:
local intrange, f; intrange := map( x -> round(x*10^Digits),
evalf(r) ); f := rand( intrange ); evalf( f()/10^Digits );
end proc;
The r within the inner proc is not declared as local or global, so it
becomes the same r as the parameter to the outer proc.
The procedure that uniform generates is now independent of the value
of Digits at the time you invoke uniform.
>
U := uniform( cos(2)..sin(1) ):
>
Digits := 15:
>
seq( U(), i=1..8 );
0.0785475551312100, 0.129118535641837,
0.153402552054527, 0.469410168730666,
0.0284411444410350, −0.136140726546643,
0.156491822876214, 0.0848249080831220
Note: The interface variable displayprecision controls the number of decimal places to be displayed. The default value is 1, representing full precision as determined by the Digits environment variable. This sim­plifies display without introducing round-off error. For more information, refer to ?interface.
14 Chapter 1: Procedures, Variables, and Extending Maple
Summary This section introduced:
Rules Maple uses to distinguish global and local variables
Principal implications of these rules
Tools available for writing nested procedures
1.2 Procedures That Return Procedures
Some of the standard Maple commands return procedures. For example, rand returns a procedure which in turn produces randomly chosen inte­gers from a specified range. The dsolve function with the type=numeric option returns a procedure which supplies a numeric estimate of the so­lution to a differential equation.
You can write procedures that return procedures. This section dis­cusses how values are passed from the outer procedure to the inner pro­cedure.
Conveying Values
The following example demonstrates how locating the roots of a function by using Newton’s method can be implemented in a procedure.
Creating a Newton Iteration
Use Newton’s method to find the roots of a function.
1. Choose a point on the x-axis that you think might be close to a root.
2. Find the slope of the curve at the point you chose.
3. Draw the tangent to the curve at that point and observe where the tangent intersects the x-axis. For most functions, this second point is closer to the real root than your initial guess. To find the root, use the new point as a new guess and keep drawing tangents and finding new points.
1.2 Pro cedures That Return Procedures 15
2
1.5
1
0.5
–0.5
0
–1
1 2 3 4
x1x0
5
x
7
6
8
To find a numerical solution to the equation f (x) = 0, guess an ap-
proximate solution, x0, and then generate a sequence of approximations using:
1. Newton’s method
2. The following formulation of the previous process
x
k+1
= xk−
f (xk)
f0(xk)
You can implement this algorithm on a computer in a number of ways.
Example 1
The following procedure takes a function and creates a new procedure, which takes an initial guess and, for that particular function, generates the next guess. The new procedure does not work for other functions. To find the roots of a new function, use MakeIteration to generate a new guess-generating procedure. The unapply command turns an expression into a procedure.
>
MakeIteration := proc( expr::algebraic, x::name )
>
local iteration;
>
iteration := x - expr/diff(expr, x);
>
unapply(iteration, x);
>
end proc:
The procedure returned by the MakeIteration procedure maps the
name x to the expression assigned to the iteration. Test the procedure on the expression x 2
>
expr := x - 2*sqrt(x);
x.
16 Chapter 1: Procedures, Variables, and Extending Maple
expr := x 2√x
>
Newton := MakeIteration( expr, x);
Newton := x x
x 2√x
1
1
x
Newton returns the solution, x = 4 after a few iterations.
>
x0 := 2.0;
x0 := 2.0
>
to 4 do x0 := Newton(x0); end do;
x0 := 4.828427124
x0 := 4.032533198
x0 := 4.000065353
x0 := 4.000000000
Example 2
The MakeIteration procedure requires its first argument to be an al­gebraic expression. You can also write a version of MakeIteration that works on functions. Since the following MakeIteration procedure recog­nizes the parameter f as a procedure, you must use the eval command to evaluate it fully.
>
MakeIteration := proc( f::procedure )
>
(x->x) - eval(f) / D(eval(f));
>
end proc:
>
g := x -> x - cos(x);
g := x x cos(x)
>
SirIsaac := MakeIteration( g );
SirIsaac := (x x)
x x cos(x)
x 1 + sin(x)
1.2 Pro cedures That Return Procedures 17
Note that SirIsaac is independent of the name g. Thus, you can
change g without breaking SirIsaac. You can find a go od approximate solution to x cos(x) = 0 in a few iterations.
>
x0 := 1.0;
x0 := 1.0
>
to 4 do x0 := SirIsaac(x0) end do;
x0 := 0.7503638679
x0 := 0.7391128909
x0 := 0.7390851334
x0 := 0.7390851332
A Shift Operator
Consider the problem of writing a procedure that takes a function, f , as input and returns a function, g, such that g(x) = f (x + 1). You can write such a procedure in the following manner.
>
shift := (f::procedure) -> ( x->f(x+1) ):
Try performing a shift on sin(x).
>
shift(sin);
x → sin(x + 1)
Maple lexical scoping rules declare the f within the inner procedure
to be the same f as the parameter within the outer procedure. Therefore, the shift command works as written.
The previous example of shift works with univariate functions but
it does not work with functions of two or more variables.
>
h := (x,y) -> x*y;
h := (x, y) x y
>
hh := shift(h);
18 Chapter 1: Procedures, Variables, and Extending Maple
hh := x h(x + 1)
>
hh(x,y);
Error, (in h) h uses a 2nd argument, y, which is missing
Multivariate Functions To modify shift to work with multivariate functions, rewrite it to accept the additional parameters.
In a procedure, args is the sequence of actual parameters, and
args[2..-1] is the sequence of actual parameters except the first one. For more information on the selection operation ([ ]), refer to chapter 4 of the
Introductory Programming Guide. It follows that the procedure x->f(x+1,args[2..-1]) passes all its arguments except the first directly to f .
>
shift := (f::procedure) -> ( x->f(x+1, args[2..-1]) ):
>
hh := shift(h);
>
hh(x,y);
hh := x h(x + 1, args
2..1
)
(x + 1) y
The function hh depends on h; if you change h, you implicitly change
hh;
>
h := (x,y,z) -> y*z^2/x;
2
y z
x
2
>
hh(x,y,z);
h := (x, y, z)
y z
x + 1
1.3 Lo cal Variables and Invoking Procedures 19
1.3 Local Variables and Invoking Procedures
Local variables are local to a procedure and to an invocation of that procedure. Calling a procedure creates and uses new local variables each time. If you invoke the same procedure twice, the local variables it uses the second time are distinct from those it used the first time.
Local variables do not necessarily disappear when the procedure exits. You can write procedures which return a local variable, either explicitly or implicitly, to the interactive session, where it can exist indefinitely. These variables are called escaped local variables. This concept can be confusing, particularly since they can have the same name as global variables, or local variables which another procedure or a different call to the same procedure created. You can create many distinct variables with the same name.
Example 1
The following procedure creates a new local variable, a, and then returns this new variable.
>
make_a := proc()
> > >
end proc;
local a; a;
make_a := proc() local a; a end proc
By using local variables, you can produce displays that Maple would otherwise simplify. For example, in Maple, a set contains
unique elements. The following demonstrates that each variable a that make_a returns is unique.
>
test := { a, a, a };
test := {a}
>
test := test union { make_a() };
test := {a, a}
>
test := test union { ’make_a’()$5 };
test := {a, a, a, a, a, a, a}
20 Chapter 1: Procedures, Variables, and Extending Maple
This demonstrates that Maple identities consist of more than names.
Important: Independent of the number of variables you create with the same name, when you type a name in an interactive session, Maple interprets that name to be a global variable . You can easily find the global a in the previous set test.
>
seq( evalb(i=a), i=test);
true, false , false, false , false, false , false
Example 2
You can display expressions that Maple would ordinarily simplify au­tomatically. For example, Maple automatically simplifies the expression a + a to 2a. It is difficult to display the equation a + a = 2a. To display such an equation, use the procedure make_a from Example 1.
>
a + make_a() = 2*a;
a + a = 2 a
When you type a name in an interactive session, the Maple program interprets it as the global variable. While this prevents you from using the assignment
statement to directly assign a value to an escaped local variable, it does not prevent you from using the assign command. You must write a Maple expression which extracts the variable. For example, in the previous equation, you can extract the local variable a by removing the global a from the left side of the equation.
>
eqn := %;
eqn := a + a = 2 a
>
another_a := remove( x->evalb(x=a), lhs(eqn) );
another_a := a
You can then assign the global name a to this extracted variable and
verify the equation.
1.3 Lo cal Variables and Invoking Procedures 21
>
assign(another_a = a);
>
eqn;
2 a = 2 a
>
evalb(%);
true
Assume Facility For complicated expressions, you must use the assume command to extract the desired variable. You may have encountered this situation before without realizing it, when you were using the assume facility to remove an assumption. The assume facility attaches various definitions to the variable you specify, with one result being that the name subsequently appears as a local name with an appended tilde. No relationship exists between the is displayed as b~, and the
>
assume(b>0);
>
x := b + 1;
local variable b with an assumption, which
global variable name containing a tilde b~.
b~ + 1
x :=
>
subs( ‘b~‘=c, x);
b~ + 1
When you clear the definition of the named variable, the association between the name and the local name with the tilde is lost, but expressions created with the local name still contain it.
>
b := evaln(b);
b := b
>
x;
b~ + 1
To reuse the expression, you must either perform a substitution before removing the assumption or perform some manipulations of the expres­sions similar to those used for the equation eqn.
22 Chapter 1: Procedures, Variables, and Extending Maple
Procedure as a Returned Object
An important use for returning local objects arises when the returned object is a procedure. When you write a procedure, which returns a pro­cedure, you will often find it useful to have the procedure create a variable that holds information pertinent only to the returned procedure. This al­lows different procedures (or different invocations of the same procedure) to pass information among themselves. The following examples illustrate how different procedures pass information.
Example 3
Creating the Cartesian Product of a Sequence of Sets When you pass
a sequence of sets to the procedure, it constructs a new procedure. The new procedure returns the next term in the Cartesian product each time you invoke it. Local variables from the outer procedure are used to keep track of which term to return next.
Cartesian product of a sequence of sets is the set of all lists
The in which the ith entry is an element of the ith set. Thus, the Cartesian product of {α, β, γ } and {x, y} is
{α, β, γ } × {x, y} = {[α, x], [β, x], [γ , x], [α, y], [β, y ], [γ, y]}.
The number of elements in the Cartesian product of a sequence of sets grows very rapidly as the number of sets or size of the sets increases. It therefore requires a large amount of memory to store all the elements of the Cartesian product.
Solution You must write a procedure that returns a new element of the Cartesian product each time you call it. By calling such a procedure re­peatedly, you can process every element in the Cartesian product without storing all its elements at once.
The following procedure returns the next element of the Cartesian product of the list of sets s. It uses an array, c, of counters to determine the next element. For example, c[1]=3 and c[2]=1 correspond to the third element of the first set and the first element of the second set.
>
s := [ {alpha, beta, gamma}, {x, y} ];
s := [{γ, α, β }, {y, x}]
>
c := array( 1..2, [3, 1] );
c := [3, 1]
1.3 Lo cal Variables and Invoking Procedures 23
>
[ seq( s[j][c[j]], j=1..2 ) ];
[β, y]
Before you call the element procedure you must initialize all the coun­ters to 1, except the first one, which must be 0.
>
c := array( [0, 1] );
c := [0, 1]
In following procedure element, nops(s) is the number of sets and nops(s[i]) is the number of elements in the ith set. When you have seen all the elements, the procedure re-initializes the array of counters and returns FAIL. Therefore, you can repeatedly trace the Cartesian product by calling element.
>
element := proc(s::list(set), c::array(1, nonnegint))
>
local i, j;
>
for i to nops(s) do
> > > > > > > > >
end proc:
c[i] := c[i] + 1; if c[i] <= nops( s[i] ) then
return [ seq(s[j][c[j]], j=1..nops(s)) ] ; end if; c[i] := 1;
end do; c[1] := 0; FAIL;
>
element(s, c); element(s, c); element(s, c);
[γ, y]
[α, y]
[β, y]
>
element(s, c); element(s, c); element(s, c);
[γ, x]
[α, x]
[β, x]
24 Chapter 1: Procedures, Variables, and Extending Maple
>
element(s, c);
FAIL
>
element(s, c);
[γ, y]
Example 4
Instead of writing a new procedure for each Cartesian product you study, you can write a procedure, CartesianProduct, that returns such a pro­cedure. CartesianProduct creates a list, s, of its arguments, which must be sets, and then initializes the array, c, of counters and defines the sub­procedure element. Finally, the element subprocedure is invoked inside a proc structure.
>
CartesianProduct := proc()
>
local s, c, element;
>
s := [args];
>
if not type(s, list(set)) then
> > > > > > > > > > > > > > > > > > > > > >
end proc:
error "expected a sequence of sets, but received",
args ; end if; c := array( [0, 1$(nops(s)-1)] );
element := proc(s::list(set), c::array(1, nonnegint))
local i, j; for i to nops(s) do
c[i] := c[i] + 1; if c[i] <= nops( s[i] ) then
return [ seq(s[j][c[j]], j=1..nops(s)) ] ; end if; c[i] := 1;
end do; c[1] := 0; FAIL;
end proc;
proc()
element(s, c);
end proc;
Again, you can find all six elements of {α, β , γ} × {x, y}.
>
f := CartesianProduct( {alpha, beta, gamma}, {x,y} );
1.3 Lo cal Variables and Invoking Procedures 25
f := proc()
>
to 7 do f() end do;
element(s, c) end proc
[γ, y]
[α, y]
[β, y]
[γ, x]
[α, x]
[β, x]
FAIL
You can use CartesianProduct to study several products simultane-
ously.
>
g := CartesianProduct( {x, y}, {N, Z, R},
>
g := proc()
{56, 23, 68, 92} );
element(s, c) end proc
The following are the first few elements of {x, y} × {N , Z, R} ×
{56, 23, 68, 92}.
>
to 5 do g() end do;
[y, N , 23]
[x, N, 23]
[y, Z, 23]
[x, Z, 23]
[y, R, 23]
The variables s in f and g are local variables to CartesianProduct,
so they are not shared by different
invocations of CartesianProduct. Similarly, the variable c in f and g is not shared. You can see that the two arrays of counters are different by invoking f and g a few more times.
26 Chapter 1: Procedures, Variables, and Extending Maple
>
to 5 do f(), g() end do;
[γ, y], [x, R, 23]
[α, y], [y, N , 56]
[β, y], [x, N, 56]
[γ, x], [y, Z, 56]
[α, x], [x, Z, 56]
The element procedure in g is also local to CartesianProduct. There­fore, you can change the value of the global variable element without breaking g.
>
element := 45;
element := 45
>
g();
[y, R, 56]
Summary The previous examples demonstrate that local variables can escape the bounds of the procedures which create them, and that escaped variables allow you to write procedures which create specialized proce­dures.
Exercises
1. The procedure that CartesianProduct generates does not work if one of the sets is empty.
>
f := CartesianProduct( {}, {x,y} );
f := proc()
>
f();
Error, (in element) invalid subscript selector
element(s, c) end proc
1.4 Interactive Input 27
Improve the type-checking in CartesianProduct so that it generates an informative error message in each such case.
partition of a positive integer, n, is a list of positive integers whose
2. A sum is n. The same integer can appear several times in the partition but the order of the integers in the partition is irrelevant. Thus, the following are all the partitions of 5:
[1, 1, 1, 1, 1], [1, 1, 1, 2], [1, 1, 3], [1, 2, 2], [1, 4], [2, 3], [5].
Write a procedure that generates a procedure that returns a new partition of n each time you call it.
1.4 Interactive Input
Normally you pass input to Maple procedures as parameters. Sometimes, however, you need a procedure to request input directly from the user. For example, you can write a procedure that tests students on some topic by generating random problems and verifying the students’ answers. The input can be the value of a parameter, or the answer to a question such as whether a parameter is positive. The two commands in Maple for reading input from the terminal are the readline command and the readstat command.
Reading Strings from the Terminal
The readline command reads one line of text from a file or the keyboard. Use the readline command as follows.
readline( filename )
If filename is the special name terminal, then readline reads a line
of text from the keyboard. The readline command returns the text as a string.
>
s := readline( terminal );
Maplesoft
s := “Maplesoft”
28 Chapter 1: Procedures, Variables, and Extending Maple
Example 1
The following application prompts the user for an answer to a question.
>
DetermineSign := proc(a::algebraic) local s;
> > > >
>
printf("Is the sign of %a positive? Answer yes or no: ",a); s := readline(terminal); evalb( s="yes" or s = "y" );
end proc:
DetermineSign(u-1);
Is the sign of u-1 positive? Answer yes or no: y
true
Information: For more details on the readline command, see Read­ing Text Lines from a File on page 197.
Reading Expressions from the Terminal
You can write procedures that interpret user input as a Maple expression rather than a string. The readstat command reads one expression from the keyboard.
readstat( prompt )
The prompt is an optional string.
>
readstat("Enter degree: ");
Enter degree: n-1;
n − 1
The user input for a readstat command must have a terminating semi­colon or colon, or an error is raised.
Advantages Unlike the readline command, which only reads one line, the readstat allows you to break a large expression across multiple lines. Another advantage of using the readstat command is that if there is an error in the input, the readstat command automatically repeats the prompt for user input.
1.4 Interactive Input 29
>
readstat("Enter a number: ");
Enter a number: 5^^8; syntax error, ‘^‘ unexpected: 5^^8;
^
Enter a number: 5^8;
390625
Example 2
The following is an application of the readstat command that imple­ments an interface to the limit command. The procedure, given the function f (x), assumes x is the variable if only one variable is present. Otherwise, the user is asked for the variable and the limit point.
>
GetLimitInput := proc(f::algebraic)
>
local x, a, K;
>
# choose all variables in f
>
K := select(type, indets(f), name);
> >
if nops(K) = 1 then
> > > > > > > > > > >
end proc:
x := K[1];
else x := readstat("Input limit variable: "); while not type(x, name) do
printf("A variable is required: received %a\n", x); x := readstat("Please re-input limit variable: ");
end do;
end if;
a := readstat("Input limit point: ");
x = a;
The expression sin(x)/x depends only on one variable, so GetLimitInput
does not prompt for a limit variable.
>
GetLimitInput( sin(x)/x );
Input limit point: 0;
x = 0
30 Chapter 1: Procedures, Variables, and Extending Maple
In the following output, the user first tries to use the number 1 as the limit variable. Because 1 is not a name, GetLimitInput requests another limit variable.
>
GetLimitInput( exp(u*x) );
Input limit variable: 1; A variable is required: received 1
Please re-input limit variable: x;
Input limit point: infinity;
x =
Information: You can specify a number of options to readstat. For more information, see Reading Maple Statements on page 204.
Converting Strings to Expressions
For greater control of how and when Maple evaluates user input to a pro­cedure, use the readline command instead of readstat. The readline command reads the input as a string, and the parse command converts the string to an expression. The string must represent a complete expres­sion.
>
s := "a*x^2 + 1";
s := “a*x^2 + 1”
>
y := parse( s );
y := a x2+ 1
When you parse the string s you get an expression. In this case, you get a sum.
>
type(s, string), type(y, ‘+‘);
true, true
1.5 Extending Maple 31
The parse command does not evaluate the expression it returns. You must use eval to evaluate the expression explicitly. In the following out­put, the variable a is not evaluted to its value, 2, until you explicitly use the eval command.
>
a := 2;
a := 2
>
z := parse( s );
z := a x2+ 1
>
eval(z);
2 x2+ 1
Information: For more details about the parse command, see Parsing Maple Expressions and Statements on page 219.
Summary The techniques in this section are very simple, but you can use them to create useful applications such as Maple tutorials, procedures that test students, or interactive lessons.
1.5 Extending Maple
Although it may be useful to write custom procedures to perform new tasks, sometimes extending the abilities of Maple commands is most ben­eficial. This section familiarizes you with:
Defining custom types and operators
Modifying how Maple displays expressions
Extending commands such as simplify and expand.
Defining New Types
If you are using a complicated structured type, it is recommended that you assign the structured type to a variable of the form ‘type/
name ‘.
32 Chapter 1: Procedures, Variables, and Extending Maple
Writing the structure once reduces the risk of errors. When you have defined the variable ‘type/
>
‘type/Variables‘ := {name, list(name), set(name)}:
>
type( x, Variables );
name , you can use name as a type.
true
>
type( { x[1], x[2] }, Variables );
true
If the structured type mechanism is not powerful enough, you can define a new type by assigning a procedure to a variable of the form
‘type/ Maple invokes the procedure ‘type/
name . When you test whether an expression is of type name,
name on the expression if such a
procedure exists. The procedure should return true or false. The fol­lowing ‘type/permutation‘ procedure determines if p is a permutation of the first n positive integers. That is, p should contain exactly one copy of each integer from 1 through n.
>
‘type/permutation‘ := proc(p)
>
local i;
>
type(p,list) and { op(p) } = { seq(i, i=1..nops(p)) };
>
end proc:
>
type( [1,5,2,3], permutation );
false
>
type( [1,4,2,3], permutation );
true
The type-testing procedure can accept more than one parameter. When you test if an expression,
expr, has type name (parameters), then
Maple invokes
‘type/name ‘( expr, parameters )
if such a procedure exists. The following ‘type/LINEAR‘ procedure de­termines if f is a polynomial in V of degree 1.
1.5 Extending Maple 33
>
‘type/LINEAR‘ := proc(f, V::name)
>
type( f, polynom(anything, V) ) and degree(f, V) = 1;
>
end proc:
>
type( a*x+b, LINEAR(x) );
true
>
type( x^2, LINEAR(x) );
false
>
type( a, LINEAR(x) );
false
Exercises
1. Modify the ‘type/LINEAR‘ procedure so that you can use it to test if an expression is linear in a set of variables. For example, x + ay + 1 is linear in both x and y, but xy + a + 1 is not.
2. Define the type POLYNOM( a polynomial in
X where X is a name, a list of names, or a set of
X ) which tests if an algebraic expression is
names.
Neutral Operators
The Maple software recognizes many operators, for example +, *, ^, and, not, and union. These operators have special meaning to Maple. The
operators can represent:
Algebraic operations, such as addition or multiplication
Logical operations
Operations performed on sets
Maple also has a special class of operators, the
on which it does not impose any meaning. Instead, Maple allows to define the meaning of any neutral operator. The name of a neutral operator begins with the ampersand character (&).
>
7 &^ 8 &^ 9;
neutral operators ,
you
34 Chapter 1: Procedures, Variables, and Extending Maple
(7 &^ 8) &^ 9
>
evalb( 7 &^ 8 = 8 &^ 7 );
false
>
evalb( (7&^8)&^9 = 7&^(8&^9) );
false
Internally, Maple represents neutral operators as procedure calls.
Thus, 7&^8 is a convenient way of writing &^(7,8).
>
&^(7, 8);
7 &^ 8
Maple uses the infix notation, in which the operator is placed between
the operands, only if the neutral operator has exactly two arguments.
>
&^(4), &^(5, 6), &^(7, 8, 9);
&^(4), 5 &^ 6, &^(7, 8, 9)
Information: For more information on naming conventions for neutral operators, refer to chapter 3 of the
Introductory Programming Guide.
Example 1
You can define the actions of a neutral operator by assigning a proce­dure to its name. The following example implements the Hamiltonians by assigning a neutral operator to a procedure that multiplies two Hamilto­nians.
Mathematical Premise The complex numbers in the same way the complex numbers extend the real numbers. Each Hamiltonian has the form a + bi + cj + dk where a, b, c, and d are real numbers. The special symbols i, j, and k satisfy the following multiplication rules: i2= 1, j2= 1, k2= 1, ij = k, ji = k, ik = j, ki = j , j k = i, and kj = i.
Hamiltonians or Quaternions extend the
1.5 Extending Maple 35
The following ‘&^‘ procedure uses I, J , and K as the three special
symbols. However, I is implemented as the
complex imaginary unit in Maple. Therefore, you should assign another letter to represent the imag­inary unit by using the interface function. For more information, refer to ?interface.
>
interface(imaginaryunit=j);
j
You can multiply many types of expressions by using ‘&^‘, making it convenient to define a new type, Hamiltonian, by assigning a structured type to the name ‘type/Hamiltonian‘.
>
‘type/Hamiltonian‘ := { ‘+‘, ‘*‘, name, realcons,
>
specfunc(anything, ‘&^‘) };
type/Hamiltonian :=
{∗, +,
realcons, name, specfunc(anything, &^)}
The ‘&^‘ procedure multiplies the two Hamiltonians, x and y. If either x or y is a real number or variable, then their product is the usual product denoted by * in Maple. If x or y is a sum, ‘&^‘ maps the product onto the sum; that is, ‘&^‘ applies the distributive laws: x(u + v ) = xu + xv and (u + v)x = ux + vx. If x or y is a product, ‘&^‘ extracts any real factors. You must take special care to avoid infinite recursion when x or y is a product that does not contain real factors. If none of the multiplication rules apply, ‘&^‘ returns the product unevaluated.
>
‘&^‘ := proc( x::Hamiltonian, y::Hamiltonian )
>
local Real, unReal, isReal;
>
isReal := z -> evalb( is(z, real) = true );
> >
if isReal(x) or isReal(y) then
> > > > > > > > > > > > >
x * y;
elif type(x, ‘+‘) then
# x is a sum, u+v, so x&^y = u&^y + v&^y. map(‘&^‘, x, y);
elif type(y, ‘+‘) then
# y is a sum, u+v, so x&^y = x&^u + x&^v. map2(‘&^‘, x, y);
elif type(x, ‘*‘) then
# Pick out the real factors of x. Real, unReal := selectremove(isReal, x);
36 Chapter 1: Procedures, Variables, and Extending Maple
> > > > > > > > > > > > > > > > > > > > > > > > > >
end proc:
# Now x&^y = Real * (unReal&^y) if Real=1 then
if type(y, ‘*‘) then
Real, unReal := selectremove(isReal, x); Real * ’‘&^‘’(x, unReal);
else
’‘&^‘’(x, y);
end if;
else
Real * ‘&^‘(unReal, y);
end if;
elif type(y, ‘*‘) then
# Similar to the x-case but easier since # x cannot be a product here. Real, unReal := selectremove(isReal, y); if Real=1 then
’‘&^‘’(x, y);
else
Real * ‘&^‘(x, unReal);
end if;
else
’‘&^‘’(x,y);
end if;
You can place all the special multiplication rules for the symbols I, J , and K in the remember table of ‘&^‘.
Information: For more information on remember tables, refer to chap­ter 6 of the
> > > >
Introductory Programming Guide.
‘&^‘(I,I) := -1: ‘&^‘(J,J) := -1: ‘&^‘(K,K) := -1: ‘&^‘(I,J) := K: ‘&^‘(J,I) := -K: ‘&^‘(I,K) := -J: ‘&^‘(K,I) := J: ‘&^‘(J,K) := I: ‘&^‘(K,J) := -I:
Since ‘&^‘ is a neutral operator, you can write products of Hamilto­nians using &^ as the multiplication symbol.
>
(1 + 2*I + 3*J + 4*K) &^ (5 + 3*I - 7*J);
20 + 41 I + 20 J 3 K
>
(5 + 3*I - 7*J) &^ (1 + 2*I + 3*J + 4*K);
20 15 I 4 J + 43 K
1.5 Extending Maple 37
>
56 &^ I;
56 I
In the following example, a is an unknown Hamiltonian until you enter the assumption that a is an unknown real number.
>
a &^ J;
a &^ J
>
assume(a, real);
>
a &^ J;
a~ J
Exercise
1. The inverse of a general Hamiltonian, a +bi + cj + dk, is (a bi cj dk)/(a2+ b2+ c2+ d2). You can demonstrate this fact by assuming that a, b, c, and d are real and define a general Hamiltonian, h.
>
assume(a, real); assume(b, real);
>
assume(c, real); assume(d, real);
>
h := a + b*I + c*J + d*K;
a~ + b~ I + c~ J + d ~ K
h :=
By the formula above, the following should be the inverse of h.
>
hinv := (a-b*I-c*J-d*K) / (a^2+b^2+c^2+d^2);
hinv :=
a~ b~ I c~ J d ~ K
a~2+ b ~2+ c ~2+ d ~
2
Check that h &^ hinv and hinv &^ h simplify to 1.
>
h &^ hinv;
38 Chapter 1: Procedures, Variables, and Extending Maple
a~ (a~ b~ I c ~ J d ~ K )
%1
b~ (I a~ + b~ c~ K + d ~ J )
>
simplify(%);
+
c~ (J a~ + b~ K + c ~ d ~ I )
+
d ~ (K a~ b~ J + c~ I + d ~)
+
%1 :=
a~2+ b ~2+ c ~2+ d ~
%1
%1
%1
2
1
>
hinv &^ h;
a~ (a~ b~ I c ~ J d ~ K )
%1
a~ b~ I + b~2+ b ~ c ~ K b~ d ~ J
>
simplify(%);
+
a~ c ~ J b~ c ~ K + c ~2+ c ~ d ~ I
+
a~ d ~ K + b~ d ~ J c~ d ~ I + d ~
+
%1 :=
a~2+ b ~2+ c ~2+ d ~
%1
%1
2
%1
2
1
Write a procedure, ‘&/‘, that computes the inverse of a Hamiltonian. It is recommended that you implement the following rules.
&/( &/x ) = x, &/(x&^y) = (&/y) &^ (&/x),
x &^ (&/x) = 1 = (&/x) &^ x.
1.5 Extending Maple 39
Extending Commands
If you introduce custom data structures, there are no manipulation rules for them. In most cases, you write special-purpose procedures that manip­ulate new data structures. However, sometimes extending the capabilities of one or more of the Maple built-in commands is easier than develop­ing new data structures and special-purpose procedures. You can extend several Maple commands, among them expand, simplify, diff, series, and evalf.
Extending the Diff Command You can represent a polynomial anun+
n1
a
u
n1
POLYNOM( u, a_0, a_1, ..., a_n )
You can then extend the diff command so that you can differentiate polynomials represented in that way. If you write a procedure with a name of the form ‘diff/ calls to with respect to
+ · · · + a1u + a0by using the data structure
F ‘ then diff invokes it on any unevaluated
F. Specifically, if you use diff to differentiate F(arguments )
x, then diff invokes ‘diff/F as follows.
‘diff/F ‘( arguments, x )
The following procedure differentiates a polynomial in u with constant coefficients with respect to x.
>
‘diff/POLYNOM‘ := proc(u)
>
local i, s, x;
>
x := args[-1];
>
s := seq( i*args[i+2], i=1..nargs-3 );
>
’POLYNOM’(u, s) * diff(u, x);
>
end proc:
>
diff( POLYNOM(x, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1), x );
POLYNOM(x, 1, 2, 3, 4, 5, 6, 7, 8, 9)
>
diff( POLYNOM(x*y, 34, 12, 876, 11, 76), x );
POLYNOM(x y, 12, 1752, 33, 304) y
40 Chapter 1: Procedures, Variables, and Extending Maple
Extending the simplify Command The implementation of the Hamil­tonians in this section 1.5 does not include the associative rule for multipli­cation of Hamiltonians, that is (xy )z = x(yz). Sometimes, using associa­tivity simplifies a result. Recall that I here is
not the complex imaginary unit, but rather, one of the special symbols I , J , and K that are part of the definition of the Hamiltonians.
>
x &^ I &^ J;
(x &^ I) &^ J
>
x &^ ( I &^ J );
x &^ K
You can extend the simplify command so that it applies the as­sociative law to unevaluated products of Hamiltonians. If you write a procedure with a name of the form ‘simplify/ vokes it on any unevaluated function calls to
F ‘, then simplify in-
F. Thus, you must write a procedure ‘simplify/&^‘ that applies the associative law to Hamiltoni­ans.
The following procedure uses the typematch command to determine if its argument is of the form (a&^b)&^c and, if so, it selects the a, b, and c.
>
s := x &^ y &^ z;
s := (x &^ y) &^ z
>
typematch( s, ’‘&^‘’( ’‘&^‘’( a::anything, b::anything ),
>
c::anything ) );
true
>
a, b, c;
x, y, z
1.5 Extending Maple 41
The userinfo Command You can give the user details about procedure simplifications using the userinfo command. The ‘simplify/&^‘ pro­cedure prints an informative message if you set infolevel[simplify] or infolevel[all] to greater than or equal to least 2.
>
‘simplify/&^‘ := proc( x )
>
local a, b, c;
>
if typematch( x,
> > > > > > > >
end proc:
else
end if;
’‘&^‘’( ’‘&^‘’( a::anything, b::anything ),
c::anything ) ) then userinfo(2, simplify, "applying the associative law"); a &^ ( b &^ c );
x;
Applying the associative law simplifies some products of Hamiltoni-
ans.
>
x &^ I &^ J &^ K;
((x &^ I) &^ J ) &^ K
>
simplify(%);
x
If you set infolevel[simplify] to a sufficiently large value, Maple prints information on the methods used by simplify while attempting to simplify the expression.
>
infolevel[simplify] := 5;
>
w &^ x &^ y &^ z;
infolevel
simplify
:= 5
((w &^ x) &^ y) &^ z
>
simplify(%);
simplify/&^: "applying the associative law" simplify/&^: "applying the associative law"
42 Chapter 1: Procedures, Variables, and Extending Maple
w &^ ((x &^ y) &^ z)
Information: For details on how to extend these commands, refer to
?expand, ?series, and ?evalf. For information on extending the evalf command, see also 4.4 Extending the evalf Command.
1.6 Conclusion
Procedures which return procedures and local variables are fundamental to advanced programming. Interactive input and extending Maple are also important topics in advanced programming.
2 Programming with
Modules
Procedures allow you to associate a sequence of commands with a single command. Similarly, modules allow you to associate related procedures and data.
Modules
This chapter describes Maple modules. Modules are a type of Maple ex­pression (like numbers, equations, and procedures), that enable you to write generic algorithms, create packages, or use Pascal-style records in programs.
The use of modules satifies four important software engineering concepts.
Encapsulation
Packages
Object Mo deling
Generic Programming
Encapsulation guarantees that an abstraction is used only according to its specified interface. You can write significant software systems that are transportable and reusable and that offer clean, well-defined user inter­faces. This makes code easier to maintain and understand—important properties for large software systems.
Packages are a vehicle for bundling Maple procedures related to a prob­lem domain. Much of the functionality of the standard Maple library resides in packages.
43
44 Chapter 2: Programming with Modules
Objects are easily represented using modules. In software engineering or object-oriented programming, an object is defined as something that has both state and behavior. You compute with objects by sending them messages, to which they respond by performing services.
Generic Programs accept objects that possess specific properties or be­haviors. The underlying representation of the object is transparent to generic programs.
Examples
For better understanding, it is helpful to examine a small module.
Example 1: Simple Module When Maple evaluates the right side of the assignment to TempGenerator, it creates a
definition
> > > > > > > > > > >
that begins with module()... and ends with end module.
TempGenerator := module()
description "generator for temporary symbols"; export gentemp; local count;
count := 0; gentemp := proc()
count := 1 + count; ‘tools/gensym‘( T || count )
end proc;
end module;
module using the module
TempGenerator := module()
local count; export gentemp; description “generator for temporary symbols”;
end module
Example Summary The module definition resembles a procedure defi­nition. The main differences are the use of the keyword module instead of proc (and the corresponding terminator) and the export declaration following the description string.
Example 2: Procedure In the following example, the previous module is written using only procedures.
>
TempGeneratorProc := proc()
>
description "generator for temporary symbols";
>
local count, gentemp;
>
count := 0;
45
> > > > > >
end proc:
gentemp := proc()
count := 1 + count;
‘tools/gensym‘( T || count ) end proc; eval( gentemp, 1 )
You can assign the procedure returned by TempGeneratorProc, and
then use it to generate temporary symbols.
>
f := TempGeneratorProc();
f := proc()
count := 1 + count ; ‘tools/gensym‘(T ||count )
end proc
>
f();
T1
>
f();
T2
Module Versus Procedure
The module TempGenerator and the procedure TempGeneratorProc are similar.
In the procedure version, the local variable gentemp is assigned a pro­cedure that references another local variable count; the value of gentemp is returned by the procedure to its caller. The module version of the generator behaves similarly. Its structure differs: its gentemp variable is declared as an
In both versions of the generator, the variables count and gentemp are local variables. The significant difference here is that, in the module version, one of those local variables is is available outside the scope of the structure in which it was created. Special syntax is used access exported local variables. For example, to call the exported variable gentemp of the module, enter
>
TempGenerator:-gentemp();
export, not a local, and there is no explicit return.
exported. This means that it
T1
46 Chapter 2: Programming with Modules
using the member selection operator :-. A module definition returns a data structure (a module) that contains all of its exported local variables.
Accessing Module Exports
The use statement allows you to access module exp orts.
>
use TempGenerator in
> > > >
Within the body of a use statement, the exported local variables of the module that appears after the use keyword can be accessed directly, without using the member selection operator :-.
gentemp(); gentemp(); gentemp();
end use;
T2
T3
T4
In This Chapter
This chapter provides many example modules. Some examples are very simple, designed to illustrate a specific point. Others are more substantial. Many of the nontrivial examples are available as Maple source code in the samples directory of the Maple installation. You can load them into the private Maple library and experiment with them. You can modify, extend, and improve these code samples, and use them in custom programs.
The following topics are covered in this chapter.
Syntax and Semantics
Using Modules as Records or Structures
Using Modules To Write Maple Packages
The use Statement
Modeling Ob jects
Interfaces and Implementations
2.1 Syntax and Semantics 47
2.1 Syntax and Semantics
The syntax of module definitions is very similar to that of procedures, given in chapter 6 of the example of a simple module definition.
>
module()
>
export e1;
>
local a, b;
> >
a := 2;
>
b := 3;
>
e1 := x -> a^x/b^x;
>
end module:
Evaluating this expression results in a module with one export, e1, and two local variables, a and b.
A template for a module definition looks like:
module()
local export global options
L ;
E ; G ;
O ;
description
B
end module
Introductory Programming Guide. Here is an
D ;
The simplest valid module definition is
>
module() end;
module() end module
This module definition does
not have: exported variables, locals, ref­erences, global variables, or a body of statements. The module to which this evaluates is not very useful.
The Module Definition
Every module definition begins with the keyword module, followed by an empty pair of parentheses. Following that is an optional declaration section and the module body. The keyword combination end module (or just end) terminates a module definition.
48 Chapter 2: Programming with Modules
The Module Body
The body of a module definition consists of the following.
Zero or more Maple statements. The bo dy is executed when the mod­ule definition is evaluated, producing a module.
A number of assignment statements that give values to the exported names of the module.
The body of a module definition can also contain:
Assignments to local variables, and performance of arbitrary compu­tations.
A return statement, but cannot contain a break or next statement outside a loop. Executing a return statement terminates the execu­tion of the body of the module definition.
Module Parameters
Module definitions begin with the Maple keyword module, followed by an (empty) pair of parentheses. This is similar to the parentheses that follow the proc keyword in a procedure definition. Unlike procedures, however, module definitions do not have explicit parameters because modules are not called (or invoked) with arguments.
Implicit Parameters Every module definition has an called thismodule. Within the body of a module definition, this special name evaluates to the module in which it occurs. This allows you to refer to a module within its own definition (before the result of evaluating it has been assigned to a name).
All procedure definitions can reference the implicit parameters proc-
name, args, and nargs. Module definitions cannot reference these im- plicit parameters. Additionally, the difference between thismodule and procname is that procname evaluates to a evaluates to the module expression itself. This is because the invocation phase of evaluating a module definition is part of its normal evaluation, and it occurs immediately. Procedures, on the other hand, are not invoked until called with arguments. Normally, at least one name for a procedure is known by the time it is called; this is not the case for modules.
name, while thismodule
implicit parameter
Named Modules
An optional symbol may appear after the module keyword in a mod­ule definition. Modules created with this variant on the syntax are called
2.1 Syntax and Semantics 49
named modules . Semantically, named modules are nearly identical to normal modules, but the exported members of named modules are printed differently, allowing the module from which it was exported to be identi­fied visually.
>
NormalModule := module() export e; end;
NormalModule := module() export e; end module
>
NormalModule:-e;
e
Here, the symbol (the name of the module) after the module keyword
is NamedModule.
>
module NamedModule() export e; end module;
module
>
NamedModule:-e;
NamedModule () export e; end module
NamedModule : e
When the definition of a named module is evaluated, the name (which
appears immediately after the module keyword) is assigned the module as its value, and the name is protected. Therefore, a named module can, ordinarily, be created only once. For example, an attempt to execute the same named module definition yields an error.
>
module NamedModule() export e; end module;
Error, (in NamedModule) attempting to assign to ‘NamedModule‘ which is protected
Executing the normal module definition again creates a
new in­stance of the module, but does not result in an error. (It simply reassigns the variable NormalModule to the new module instance.)
>
NormalModule := module() export e; end;
NormalModule := module() export e; end module
50 Chapter 2: Programming with Modules
Important Do not assign a named module to another variable.
>
SomeName := eval( NamedModule );
SomeName :=
module NamedModule () export e; end module
>
SomeName:-e;
NamedModule : e
Exports of named modules are printed using the
distinguished name that was given to the module when it was created, regardless of whether it has been assigned to another name.
Whether a module has a name also affects the reporting of errors that occur during its evaluation. When the second attempt to evaluate the named module definition above failed, the error message reported the location of the error by name. By contrast, when an error occurs during the evaluation of a normal module definition, the name unknown is used instead.
>
NormalModule := module() export e; error "oops"; end;
Error, (in unknown) oops
This differs from procedure error reporting. Maple cannot report the name of a normal module (that is, the name of the variable to which the module is assigned), because the evaluation of the right side of an assignment occurs
before the assignment to the name takes place. So the error occurs before any association between a variable and the module has occurred.
Declarations
The declarations section of the module must appear immediately after the parentheses. All statements in the declarations section are optional, but at most one of each kind may appear. Most module declarations are the same as those for procedures.
Description Strings Provide a brief description outlining the purpose and function of any module you write. It is valuable to other users who read your code. Include an overview after the description keyword, just as you would in a procedure definition.
2.1 Syntax and Semantics 51
>
Hello := module()
> > > > > >
description "my first module"; export say; say := proc()
print( "HELLO WORLD" )
end proc;
end module:
When the module is printed, its description string is displayed.
>
eval( Hello );
module() export
say;
description “my first module”;
end module
The export declaration is explained later in this chapter.
Global Variables Global variables referenced within a module definition should be declared with the global declaration. Following the keyword global is a sequence of one or more symbols. These symbols are bound to their global instances. In certain cases you must declare a name as a global variable to prevent implicit scoping rules from making it local.
>
Hello := module()
> > > > > > >
export say; global message; say := proc()
message := "HELLO WORLD!"
end proc; end module: message;
>
Hello:-say();
>
message;
message
“HELLO WORLD!”
“HELLO WORLD!”
52 Chapter 2: Programming with Modules
Local Variables You can refer to variables that are local to the module definition by using the local declaration. Its format is the same as for procedures. Here is a variant on the previous Hello module which uses a local variable.
>
Hello := module()
> > > > > > >
local loc;
export say;
loc := "HELLO WORLD!";
say := proc()
print( loc )
end proc; end module:
Local variables are not visible outside the definition of the module in which they occur. They are private to the module, and are exactly analogous to local variables of procedures.
A local variable in a module (or procedure) is a distinct object from a global variable with the same name. Local variables are normally short­lived variables; the normal lifetime of a local variable is the execution time of the body of code (a module or procedure body) to which it is local. (Local variables may persist once execution of the scope in which they oc­cur has completed, but they are normally inaccessable and will eventually be recycled by the Maple automatic storage management system.)
Exported Local Variables
Procedures and modules both support local variables. Only modules sup-
exported local variables, often referred to simply as exports.
port
Module exports are declared using the export declaration. It begins with the keyword export, after which follows a (nonempty) sequence of symbols. A name is never exported implicitly; exports
The result of evaluating a module definition is a mo dule. You can view a module as a collection of its exports, which are also referred to as members of the module. These are simply names that can (but need not) be assigned values. You can establish initial values for the exports by assigning to them in the body of the module definition.
The word export is short for exported local variable. In most respects, a module export is a local variable (such as those declared via the local declaration.) The crucial difference is that you can access the exported local variables of a module after it has been created.
To access an export of a module, use the :- member selection opera­tor. Its general syntax is:
must be declared.
2.1 Syntax and Semantics 53
modexpr :- membername
Here, modexpr must be an expression that evaluates to a module, and membername must be the name of an export of the module to which modexpr evaluates. Anything else signals an exception. You cannot ac-
cess local variables of an instantiated module by using this syntax.
Local variables of a procedure are created when the procedure is called (or invoked). Normally, the locals persist only during the execution of the statements that form the body of the procedure. Sometimes, however, local variables persist beyond the procedure activation that instantiated them. For example:
>
gen := proc()
> > > > > >
local s, p; s := 2; p := x -> s * x;
p end proc: g := gen();
g := p
>
g( 3 );
6
The local variable s of gen persists after gen has returned. It is cap­tured in the closure of the procedure p, whose name is returned by gen. Thus, both local variables p and s of gen escape, but in different ways. The local name p is accessible because it is the assigned value of the global variable g. However, there is no way to refer to s once gen has returned. No Maple syntax exists for that purpose. The member selection operator :- provides a syntax for referencing certain local variables of modules–those declared as exports.
The most recent Hello example has one export, named say. In this case, say is assigned a procedure. To call it, enter
>
Hello:-say();
“HELLO WORLD!”
The following expression raises an exception, because the name noSuchModule is not assigned a module expression.
54 Chapter 2: Programming with Modules
>
noSuchModule:-e;
Error, ‘noSuchModule‘ does not evaluate to a module
Here, a module expression is assigned to the name m, and the member selection expression m:-e evaluates to the value of the exported variable e of m.
>
m := module() export e; e := 2 end module:
>
m:-e;
2
Since m does not export a variable named noSuchExport, the following expression raises an exception.
>
m:-noSuchExport;
Error, module does not export ‘noSuchExport‘
Important The following module exports an unassigned name. This illustrates the importance of distinguishing module exports from global variables.
>
m := module() export e; end:
References to the exported name e in m evaluate to the name e.
>
m:-e;
e
Note, however, that this is a
local name e, not the global instance of
the name.
>
evalb( e = m:-e );
false
The first e in the previous expression refers to the global e, while the expression m:-e evaluates to the e that is local to the module m. This distinction between a global and export of the same name is useful. For example, you can create a module with an export sin. Assigning a value to the export sin does not affect the protected global name sin.
2.1 Syntax and Semantics 55
The exports Procedure You can determine the names of the exports of a module by using the exports procedure.
>
exports( Hello );
say
>
exports( NormalModule );
e
This returns the global instances of the export names.
>
exports( m );
e
>
evalb( % = e );
true
You can also obtain the local instances of those names by passing the option instance.
>
exports( m, ’instance’ );
e
>
evalb( % = e );
false
>
evalb( %% = m:-e );
true
For this reason, you cannot have the same name declared both as a local and an export.
>
module() export e; local e; end;
Error, export and local ‘e‘ have the same name
56 Chapter 2: Programming with Modules
(The declared exports and locals actually form a partition of the
names that are local to a module.)
The member Procedure You have already seen the built-in procedure member that is used to test for membership in a set or list.
>
member( 4, { 1, 2, 3 } );
false
This procedure can be used for membership tests in modules as well.
>
member( say, Hello );
true
>
member( cry, Hello );
false
The first argument is a (global) name whose membership is to be tested, and the second argument is a module. It returns the value true if the module has an export whose name is the same as the first argument.
The procedure member also has a three argument form that can be used with lists to determine the (first) position at which an item occurs.
>
member( b, [ a, b, c ], ’pos’ );
true
The name pos is now assigned the value 2 because b occurs at the second position of the list [ a, b, c].
>
pos;
2
When used with modules, the third argument is assigned the local
instance
of the name whose membership is being tested, provided that
the return value is true.
>
member( say, Hello, ’which’ );
>
which;
>
eval( which );
2.1 Syntax and Semantics 57
true
say
proc() print(
loc) end proc
If the return value from member is false, then the name remains unassigned (or maintains its previously assigned value).
>
unassign( ’which’ ):
>
member( cry, Hello, ’which’ );
false
>
eval( which );
which
Module Options
As with procedures, a module definition may contain options. The op­tions available for mo dules are different from those for procedures. Only the options trace, and ‘Copyright...‘ are common to procedures and modules. The following four options have a predefined meaning for mo d­ules: load, unload, package, and record.
The load and unload Options The module initialization option is load= pname where pname is the name of a procedure in the declared exports or locals of the module. If this option is present, then the pro­cedure is called when the module is read from the Maple repository in which it is found. The unload = pname option specifies the name of a local or exported procedure of the module that is called when the module is destroyed. A module is destroyed either when it is no longer accessible and is garbage collected, or when Maple exits.
There is a situation that can arise wherein a module is no longer accessible, and hence subject to garbage collection before the unload= procedure is executed, but becomes accessible again during the execution
58 Chapter 2: Programming with Modules
of that procedure. In that case, the module is
not garbage collected. When
it eventually is garbage collected or Maple exits, the unload= procedure
not executed again. The load= and unload= procedures are called
is with no arguments.
The package Option Modules with the option package represent Maple packages. The exports of a module created with the package option are automatically protected.
The record Option The record option is used to identify records. Records are produced by the Record constructor and are represented using modules.
Implicit Scoping Rules
The bindings of names that appear within a module definition are deter­mined when the module definition is simplified. Module definitions are subject to the same implicit scoping rules that procedure definitions are. Under no circumstances is a name ever implicitly determined to be ex­ported by a module; implicitly scoped names can resolve only to locals or globals.
Lexical Scoping Rules
Module definitions, along with procedure definitions, obey standard lex­ical scoping rules. Modules may be nested, in the sense that a module may have any of its exports assigned to a module whose definition occurs within the body of the outer module.
Here is a simple example of a submodule.
>
m := module()
> > > > > > > >
The global name m is assigned a module that exports the name s. Within
the body of m, the export s is assigned a module that exports the name e. As such, s is a illustrates a nontrivial use of submodules.
Modules and procedures can be mutually nested to an arbitrary depth. The rules for the visibility of lo cal variables (including exported locals of
export s; s := module()
export e; e := proc()
print( "HELLO WORLD!" )
end proc;
end module
end module:
submodule of m. The Shapes package, described later,
2.1 Syntax and Semantics 59
modules) and procedure parameters are the same as the rules for nested procedures.
Parameterized Modules Modules do not take explicit parameters. You can write a generic module that could be specialized by providing one or more parameters.
For example, here is a module for arithmetic modulo 6.
>
z6 := module()
> > > > >
export add, mul; add := ( a, b ) -> a + b mod 6;
mul := ( a, b) -> a * b mod 6; end module: z6:-add( 5, 4);
3
>
z6:-mul( 2, 3);
0
You can write a
generic module for arithmetic modulo any positive integer n, and then specialize it for any integer that you need. This is possible as a result of the standard lexical scoping rules. You must write a
constructor procedure for the module that accepts the value of n as
an argument. Here is a generic version of the z6 example.
>
MakeZn := proc( n::posint )
> > > > > >
module()
export add, mul; add := ( a, b ) -> a + b mod n; mul := ( a, b ) -> a * b mod n;
end module
end proc:
To generate a module that does arithmetic modulo 7, call the constructor
MakeZn with the number 7 as its argument.
>
z7 := MakeZn( 7 );
z7 := module() export add , mul ; end module
>
z7:-add( 3, 4 );
0
60 Chapter 2: Programming with Modules
Modules and Types
Two Maple types are associated with modules. First, the name module is a type name. Naturally, an expression is of type module only if it is a module. When used as a type name, the name module must be enclosed in name quotes ().
>
type( module() end, ’‘module‘’ );
true
>
type( LinearAlgebra, ’‘module‘’ );
true
Secondly, a type called moduledefinition identifies expressions that
are module definitions. In the previous example, the module definition
>
module() end:
was evaluated before being passed to type, so the expression that was tested was not the definition, but the module to which it evaluates. You must use unevaluation quotes () to delay the evaluation of a module definition.
>
type( ’module() end’, ’moduledefinition’ );
true
Other important type tests satisfied by modules are the types atomic and last_name_eval.
>
type( module() end, ’atomic’ );
true
The procedure map has no effect on modules; they pass through un­changed.
>
map( print, module() export a, b, c; end );
module() export a, b, c; end module
Modules also follow last name evaluation rules. For more information on last name evaluation rules, refer to ?last_name_eval.
2.1 Syntax and Semantics 61
>
m := module() end:
>
m;
m
>
type( m, ’last_name_eval’ );
true
Although type module is a surface type, it acts also as a structured type. Parameters passed as arguments to the unevaluated name module are taken to be the names of exports. For example, the module
>
m := module() export a, b; end:
has the structured module type ‘module‘( a, b ):
>
type( m, ’‘module‘( a, b )’ );
true
It also has type type ‘module‘( a )
>
type( m, ’‘module‘( a )’ );
true
because any module that exports symbols a and b is a module that exports the symbol a.
Example: A Symbolic Differentiator
This section illustrates the various module concepts through a symbolic differentiator example. Since Maple provides a built-in differentiator diff, the example symbolic differentiator is named differentiate. Its (final) implementation is in the module DiffImpl (later in this chapter), which holds all the local state for the program. Much of the code for the dif­ferentiator is designed to implement either a standard rule (such as the rule that the derivative of a sum is the sum of the derivatives of the sum­mands), or special case rules for mathematical functions such as sin and exp. The example differentiator handles only real valued functions of a single real variable.
62 Chapter 2: Programming with Modules
The following example shows several steps in the development of the module, from a very simple first try to the final, fully functional program. The final form of the differentiator is a good illustration of a very common Maple design pattern. This pattern arises when you have a single top-level routine that dispatches a number of subroutines to handle special cases using special purpose algorithms.
The First Attempt This initial example presents the differentiator as an ordinary procedure, not a module.
>
differentiate := proc( expr, var )
> > > > > > > > > > > > > > > > > > > > > >
local a, b;
if type( expr, ’constant’ ) then
0
elif expr = var then
1
elif type( expr, ’‘+‘’ ) then
map( procname, args )
elif type( expr, ’‘^‘’ ) then
a, b := op( expr ); if a = var and not has( b, var ) then
b * a ^ ( b - 1 )
else
’procname( args )’
end if
elif type( expr, ’‘*‘’ ) then
a, b := op( 1, expr ), subsop( 1 = 1, expr ); procname( a, var ) * b + a * procname( b, var )
else
’procname( args )’
end if
end proc:
Trivial cases are handled first: The derivative of a constant expression is
equal to 0, and the derivative of the variable with respect to which we are differentiating is equal to 1. The additivity of the derivative operator is expressed by mapping the procedure over sums, using the command
>
map( procname, args );
This is commonly used to map a procedure over its first argument, passing along all the remaining arguments. Only the simple case of powers of the differentiation variable is handled so far, provided also that the power is independent of the differentiation variable. The product rule for derivatives is expressed by splitting expressions of type product into two pieces:
the first factor in the product, and
the product of all the remaining factors.
2.1 Syntax and Semantics 63
This is achieved by the double assignment of
>
a, b := op( 1, expr ), subsop( 1 = 1, expr );
so the input expression expr is expressed as expr = a * b. The stan­dard technique of returning unevaluated is used so that computation can proceed symbolically on expressions that the procedure is unable to dif­ferentiate.
This first example is simple, but it is already able to handle polyno­mials with numeric coefficients.
>
differentiate( 2 - x + x^2 + 3*x^9, x );
1 + 2 x + 27 x
8
However, it fails on expressions containing calls to standard mathe­matical functions.
>
differentiate( sin( x ), x );
differentiate(sin(x), x)
It is also unable to deal successfully with symbolic coefficients.
>
differentiate( a*x^2 + b*x + c, x );
differentiate(a, x) x2+ 2 a x + differentiate(b, x) x + b
+ differentiate(c, x)
Adding Missing Functionality To add the missing functionality, add a case for expressions of type function.
>
differentiate := proc( expr, var )
> > > > > > > > > > > > > >
local a, b;
if not has( expr, var ) then
0
elif expr = var then
1
elif type( expr, ’‘+‘’ ) then
map( procname, args )
elif type( expr, ’‘^‘’ ) then
a, b := op( expr ); if not has( b, var ) then
b * a ^ ( b - 1 ) * procname( a, var )
else
’procname( args )’
64 Chapter 2: Programming with Modules
> > > > > > > > > > > > > > > > > > > > > > >
end proc:
end if
elif type( expr, ’‘*‘’ ) then
a, b := op( 1, expr ), subsop( 1 = 1, expr ); procname( a, var ) * b + a * procname( b, var )
elif type( expr, ’function’ ) and nops( expr ) = 1 then
# functions of a single variable; chain rule b := op( 0, expr ); # the name of the function a := op( 1, expr ); # the argument if b = ’sin’ then
cos( a ) * procname( a, var )
elif b = ’cos’ then
-sin( a ) * procname( a, var )
elif b = ’exp’ then
exp( a ) * procname( a, var )
elif b = ’ln’ then
( 1 / a ) * procname( a, var )
else
’procname( args )’
end if
else
’procname( args )’
end if
This uses the chain rule to compute the derivatives of calls to known
functions.
>
differentiate( sin( x ) + cos( exp( x ) ), x );
cos(x) sin(ex) e
>
differentiate( sin( x^2 ) + cos( x^2 ), x );
x
2 cos(x2) x 2 sin(x2) x
>
differentiate( sin( x )^2 + cos( x )^3, x );
2 sin(x) cos(x) 3 cos(x)2sin(x)
At the same time, this has also improved the handling of expressions independent of the variable of differentiation.
>
differentiate( a*x^2 + b*x + c, x );
2 a x + b
2.1 Syntax and Semantics 65
This is effected by using the expression has( expr, var ) instead of the weaker test type( expr, ’constant’ ). The power rule now handles more than just powers of var.
>
differentiate( sin( x )^2, x );
2 sin(x) cos(x)
However, adding new functions to the differentiator is tedious and error prone, and the job of handling the chain rule must be repeated for each function recognized by it.
Introducing a Function Table Many functions (that you need to add) and the rules used for their differentiation can be stored in a table as follows:
>
differentiate := proc( expr, var )
> > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > >
local a, b, functab;
functab := table(); functab[ ’sin’ ] := ’cos’; functab[ ’cos’ ] := x -> -sin( x ); functab[ ’exp’ ] := exp; functab[ ’ln’ ] := x -> 1 / x;
if not has( expr, var ) then
0
elif expr = var then
1
elif type( expr, ’‘+‘’ ) then
map( procname, args )
elif type( expr, ’‘^‘’ ) then
a, b := op( expr ); if a = var and not has( b, var ) then
b * a ^ ( b - 1 ) * procname( a, var )
else
’procname( args )’
end if
elif type( expr, ’‘*‘’ ) then
a, b := op( 1, expr ), subsop( 1 = 1, expr ); procname( a, var ) * b + a * procname( b, var )
elif type( expr, ’function’ ) and nops( expr ) = 1 then
# functions of a single variable; chain rule b := op( 0, expr ); # the name of the function a := op( 1, expr ); # the argument if assigned( functab[ b ] ) then
# This is a ‘‘known’’ function functab[ b ]( a ) * procname( a, var )
else
# This function is not known; return unevaluated ’procname( args )’
66 Chapter 2: Programming with Modules
> > > > >
end proc:
end if
else
’procname( args )’
end if
This not only simplifies the code used for the function case, but also makes it very easy to add new functions.
Drawbacks Unfortunately, this implementation has serious drawbacks.
It is not extensible. The known functions are hardcoded as part of the procedure definition for differentiate. New functions cannot be added without editing this source code.
A second problem relates to performance. A complete implementation would require a table of dozens or hundreds of functions. That large ta­ble would need to be created and initialized each time differentiate is invoked.
Encapsulation and Extensibility One way to fix both problems is to make the table of functions a global variable. However, using global vari­ables can be dangerous, because they pollute the user namespace and are subject to unwanted inspection and tampering.
Solution A better solution is to put the differentiate procedure, along with its table of functions, into a module. The table is then ini­tialized only once–when the module is created–and can be saved to a Maple repository with the rest of the module by using a savelib call. By making the table a local variable of the module, you prevent users from modifying the table or otherwise inspecting it in unwanted ways.
This does not prevent you from making the differentiator user-
extensible, however. You can add an access procedure addFunc that allows users to add rules for differentiating new functions. For example, you can use the call
>
addFunc( ’cos’, x -> -sin(x) );
to add the derivative of the sin function. The export addFunc of the
DiffImpl module is a procedure that requires two arguments. The first
is the name of a function whose derivative is to be made known to the differentiator. The second is a Maple procedure of one argument that expresses the derivative of the function being added.
2.1 Syntax and Semantics 67
With this strategy in mind, you can create a module DiffImpl, with
principal export differentiate. At the same time, you can also make the basic differentiation rules extensible.
Here is the complete source code for the differentiator with these im-
provements.
>
DiffImpl := module()
> > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > >
description "a symbolic differentiator"; local functab, ruletab, diffPower; export differentiate, addFunc, addRule, rule;
addFunc := proc( fname::symbol, impl )
functab[ fname ] := impl
end proc;
addRule := proc( T, impl )
if type( T, ’{ set, list }’ ) then
map( procname, args )
elif type( T, ’And( name, type )’ ) then
ruletab[ T ] := impl
else
error "expecting a type name, but got %1", T
end if
end proc;
rule := proc( T )
if type( T, ’And( name, type )’ ) then
if assigned( ruletab[ T ] ) then
eval( ruletab[ T ], 1 )
else
error "no rule for expressions of type %1", T
end if
else
error "expecting a type symbol, but got %1", T
end if
end proc;
differentiate := proc( expr, var )
local a, b, e; if not has( expr, var ) then
0
elif expr = var then
1
elif type( expr, ’function’ ) and nops( expr ) = 1 then
e := op( 0, expr ); a := op( expr ); if assigned( functab[ e ] ) then
functab[ e ]( a ) * procname( a, var )
else
’procname( args )’
end if
else
b := whattype( expr );
68 Chapter 2: Programming with Modules
> > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > >
end proc;
addRule( ’{list,set,tabular}’,
addRule( ’‘+‘’,
addRule( ’‘*‘’,
(expr,var) ->
diffPower := proc( expr, var )
end proc; addRule( ’‘^‘’, eval( diffPower ) );
addFunc( ’sin’, cos ); addFunc( ’cos’, x -> -sin(x) ); addFunc( ’exp’, exp ); addFunc( ’ln’, x -> 1/x ); # ... etc.
end module: differentiate := DiffImpl:-differentiate:
if assigned( ruletab[ b ] ) then
ruletab[ b ]( expr, var )
else
’procname( args )’
end if
end if
() -> map( differentiate, args ) );
() -> map( differentiate, args ) );
op(1,expr)*differentiate(subsop(1=1,expr),var)
+ differentiate(op(1,expr),var)*subsop(1=1,expr) );
local b, e; Assert( type( expr, ’‘^‘’ ) ); b, e := op( expr ); if has( e, var ) then
expr * ( differentiate( e, var ) * ln( b )
+ e * differentiate( b, var ) / b )
else # simpler formula
e * b^(e - 1) * differentiate( b, var )
end if;
To give the set of rules for nonfunctional expressions similar extensibility,
you can store those rules in a table. The table is indexed by the primary (or basic) type name for the expression type, as given by the Maple procedure whattype.
>
whattype( a + 2 );
>
whattype( a / b );
+
2.1 Syntax and Semantics 69
>
whattype( a^sqrt(2) );
^
>
whattype( [ f( x ), g( x ) ] );
list
A rule is expressed by a procedure of two arguments, expr and var, in
which expr is the expression to be differentiated, and var is the variable of differentiation. For instance, to make the differentiator handle items such as sets and lists by differentiating their individual components, add the rule
>
addRule( ’{ list, set, tabular }’, () -> map( differentiate,
>
args ) );
The first version of the differentiator dealt with sums by mapping
itself over the sum expression. In the new scheme, this is expressed by the statement
>
addRule( ’‘+‘’, () -> map( differentiate, args ) );
in the module body. The advantage of using this scheme is that, not
only can the author of the differentiator extend the system, but so can users of the system. Having instantiated the module DiffImpl, any user can add rules or new functions, simply by issuing appropriate calls to addRule and addFunc.
The differentiator cannot handle the procedure tan.
>
differentiate( tan( x )/exp( x ), x );
tan(x)
x
e
differentiate(tan(x), x)
+
x
e
You must add it to the database of known functions.
>
DiffImpl:-addFunc( ’tan’, x -> 1 + tan(x)^2 );
x 1 + tan(x)
>
differentiate( tan( x )/exp( x ), x );
2
70 Chapter 2: Programming with Modules
tan(x)
1 + tan(x)
+
x
e
2
x
e
Similarly, there is not yet any rule for handling equations and other
relations.
>
differentiate( y( x ) = sin( x^2 ) - cos( x^3 ), x );
differentiate(y(x) = sin(x2) cos(x3), x)
>
DiffImpl:-addRule( ’{ ‘=‘, ‘<‘, ‘<=‘ }’,
>
>
differentiate( y( x ) = sin( x^2 ) - cos( x^3 ), x );
differentiate(y(x), x) = 2 cos(x2) x + 3 sin(x3) x
() -> map( differentiate, args ) );
{() → map(
differentiate, args)}
2
The Extension Mechanism is Module Aware Do not confuse the ex­tension mechanism previously proposed for the differentiator with the extension mechanism used by the built-in Maple command diff. The diff command uses a traditional string concatenation mechanism for adding knowledge of the derivatives of functions, and all its rules are built-in, so they cannot be extended. For instance, to add a new func­tion F to the Maple built-in diff command, you can define a procedure ‘diff/F‘ that computes the derivative of F.
By contrast, the extension mechanism used in the differentiate
example is
module aware. To add knowledge of the derivative of some
top-level function F, you can issue a command, such as
>
DiffImpl:-addFunc( ’F’, x -> sin( x ) + cos( x ) );
x → sin(x) + cos(x)
The derivative of F( x ) is sin( x ) + cos( x ).) Define a module
with some special functions, one of which is also called F.
2.1 Syntax and Semantics 71
>
SpecFuncs := module()
> > >
export F; # etc. # definition of F() and others
end module:
You can now add this new F to the known functions.
>
DiffImpl:-addFunc( SpecFuncs:-F, x -> exp( 2 * x ) );
(2 x)
x e
>
differentiate( F( x ), x );
sin(x) + cos(x)
>
use SpecFuncs in
> >
differentiate( F( x ), x );
end use;
e
(2 x)
With the traditional mechanism, this does not work.
>
‘diff/‘ || F := x -> sin( x ) + cos( x );
diff /F := x sin(x) + cos(x)
>
diff( F( x ), x );
sin(x) + cos(x)
>
use SpecFuncs in
> > >
‘diff/‘ || F := x -> exp( 2 * x ); diff( F( x ), x );
end use;
diff /F := x e
(2 x)
e
(2 x)
The definition for the global F has been lost.
>
diff( F( 2 * x ), x );
(4 x)
e
72 Chapter 2: Programming with Modules
(You can use a different argument to diff to avoid recalling the an-
swer from its remember table.) The traditional mechanism fails because it relies on the
external representation of names, and not upon their bindings, so each attempt to define an extension to diff in fact adds a definition for the derivative of
all functions whose names are spelled "F".
Note: A commented version of the differentiate module is available in the samples/AdvPG directory of the Maple installation. The implemen­tation shown in the text has been somewhat simplified.
2.2 Records
The simplest way to use modules is as Pascal-style records (or structures, as in C and C++). A record is a data structure that has some number of named values. Although the underlying data structure of a Maple record is cur­rently a module, records and modules represent distinct abstractions. A record is simply an aggregate data structure in which the members have fixed names. Modules provide additional facilities such as computation at initialization and access control.
slots or fields. In Maple, these slots can be assigned arbitrary
Instantiating Records To create a record, use the Record constructor. In the simplest form, it takes the slot names as arguments.
>
rec := Record( ’a’, ’b’, ’c’ );
rec :=
module() export a, b, c; option
record ; end module
The name rec is now assigned a record with slots named a, b, and c. These are the slot names for the record rec. You can access and assign these slots by using the expressions rec:-a, rec:-b, and rec:-c.
>
rec:-a := 2;
a := 2
>
rec:-a;
2
2.2 Records 73
If not assigned, the record slot evaluates to the
local instance of the
slot name.
>
rec:-b;
b
>
evalb( % = b );
false
This is useful because the entire record can be passed as an aggregate data structure.
The record constructor accepts initializers for record slots. That is, you can specify an initial value for any slot in a new or in an unassigned record by passing an equation with the slot name on the left side and the initial value on the right.
>
r := Record( ’a’ = 2, ’b’ = sqrt( 3 ) );
r := module() export a, b; option
>
r:-b;
record ; end module
3
In addition, you can attach type assertions to record slots. To intro­duce a type assertion, use a ‘::‘ structure with the slot name specified as the first operand. Type assertions can be used in combination with initializers. An incompatible initializer value triggers an assertion failure when the assertlevel kernel option is set to 2. For more information, refer to ?kernelopts.
>
kernelopts( ’assertlevel’ = 2 ):
>
Record( a::integer = 2.3, b = 2 );
Error, (in assign/internal) assertion failed in assignment, expected integer, got 2.3
>
r := Record( ’a’::integer = 2, ’b’::numeric );
74 Chapter 2: Programming with Modules
r := module() export a:: option
integer, b::numeric;
record ;
end module
>
r:-b := "a string";
Error, assertion failed in assignment, expected numeric, got a string
If the initializer for a record slot is a procedure, you can use the reserved name self to refer to the record you are constructing. This allows records to be self-referential. For example, you can write a complex number constructor as follows.
>
MyComplex := ( r, i ) ->
> > > >
Record( ’re’ = r, ’im’ = i, ’abs’ = (() -> sqrt(
self:-re^2 + self:-im^2 )) ): c := MyComplex( 2, 3 ): c:-re, c:-im, c:-abs();
2, 3,
13
Combined with prototype-based inheritance, described on page 76, this facility makes the Record constructor a powerful tool for object­oriented programming.
Record Types Expressions created with the Record constructor are of type record.
>
type( rec, ’record’ );
true
This is a structured type that works the same way as the ‘module‘ type, but recognizes records specifically.
>
r := Record( a = 2, b = "foo" ):
>
type( r, ’record( a::integer, b::string )’ );
true
2.2 Records 75
Note: In a record type, the slot types are used to test against the values assigned to the slots (if any), and are not related to type assertions on the slot names (if any).
>
r := Record( a::integer = 2, b::{symbol,string} = "foo" ):
>
type( r, ’record( a::numeric, b::string )’ );
true
Using Records to Represent Quaternions Records are useful for im­plementing simple aggregate data structures for which named access to slots is wanted. For example, four real numbers can be combined to form a quaternion, and you can represent this using a record structure, as fol­lows.
>
MakeQuaternion := proc( a, b, c, d )
> > >
Record( ’re’ = a, ’i’ = b, ’j’ = c, ’k’ = d ) end proc: z := MakeQuaternion( 2, 3, 2, sqrt( 5 ) );
z := module() export option
re, i, j, k;
record ;
end module
In this example, z represents the quaternion 2 + 3i +2j +√5k (where
i, j , and k are the nonreal quaternion basis units). The quaternion records
can now be manipulated as single quantities. The following procedure ac­cepts a quaternion record as its sole argument and computes the Euclidean length of the quaternion that the record represents.
>
qnorm := proc( q )
> > > > >
use re = q:-re, i = q:-i, j = q:-j, k = q:-k in
sqrt( re * re + i * i + j * j + k * k )
end use end proc: qnorm( z );
22
A Maple type for quaternions can be introduced as a structured record
type.
76 Chapter 2: Programming with Modules
>
TypeTools:-AddType( ’quaternion’, ’record( re, i, j, k )’ );
>
type( z, ’quaternion’ );
true
Object Inheritance The Record constructor supports a simple form of prototype-based inheritance. An object system based on prototypes does not involve classes; instead, it uses a simpler, more direct form of object­based inheritance. New objects are created from existing objects (called prototypes) by cloning, that is, copying and augmenting the data and behavior of the prototype.
The Record constructor supports prototype-based inheritance by ac­cepting an index argument, which is the prototype for the new object record.
>
p := Record( a = 2, b = 3 ); # create a prototype
p := module() export a, b; option
>
p:-a, p:-b;
record ; end module
2, 3
>
r := Record[p]( c = 4 );
r := module() export a, b, c; option
>
r:-a, r:-b, r:-c;
record ; end module
2, 3, 4
In this example, the record p is the prototype, and the second record r inherits the slots a and b, and their values, from the prototype p. It also augments the slots obtained from p with a new slot c. The prototype p is not changed.
>
r:-a := 9;
a := 9
2.2 Records 77
>
p:-a;
2
Behavior, as well as data, can be copied from a prototype. To copy be­havior, use a constructor procedure for both the prototype and its clones.
>
BaseComplex := proc( r, i )
>
Record( ’re’ = r, ’im’ = i )
>
end proc:
>
NewComplex := proc( r, i )
>
Record[BaseComplex(r,i)]( ’abs’ =
> > > >
(() -> sqrt( self:-re^2 + self:-im^2 )) ) end proc: c := NewComplex( 2, 3 ): c:-re, c:-im, c:-abs();
2, 3,
13
An object created from a prototype can serve as a prototype for an-
other object.
>
NewerComplex := proc( r, i )
>
Record[NewComplex(r,i)]( ’arg’ =
> > > >
(() -> arctan(self:-im,self:-re)) ) end proc: c2 := NewerComplex( 2, 3 ): c2:-re, c2:-im, c2:-abs(), c2:-arg();
2, 3,
13, arctan(
3
)
2
Note: Prototypes are supertypes of their clones.
>
subtype( ’record( re, im, abs )’, ’record( re, im )’ );
true
For example, NewComplex creates objects of a type that is a subtype
of the objects created by BaseComplex.
78 Chapter 2: Programming with Modules
2.3 Packages
Modules are ideal for writing Maple packages. They provide facilities for large software projects that are better than table and procedure based methods.
What Is a Package
package is a collection of procedures and other data, that can be treated
A as a whole. Packages typically gather a number of procedures that enable you to perform computations in some well-defined problem domain. Pack­ages may contain data other than procedures, and may even contain other packages (subpackages).
Packages in the Standard Library A number of packages are shipped with the standard Maple library. For example, the group, numtheory, codegen, and LinearAlgebra packages are all provided with Maple, along with several dozen others. The group package provides procedures that allow you to compute with groups that have a finite representation in terms of permutations, or of generators and defining relations. The LinearAlgebra package has a large number of procedures available for computational linear algebra.
Table-Based Packages Many packages are implemented as tables. The essential idea underlying this implementation scheme is that the name of a package routine is used as the index into a table of procedures. The table itself is the concrete representation of the package.
Use Modules for New Packages Modules are the new implementa­tion vehicle for packages. A module represents a package by its exported names. The exported names can be assigned arbitrary Maple expressions, typically procedures, and these names form the package.
Package Exports Some of the data in a package is normally made acces­sible to the user as an export of the package. For packages implemented as modules, the package exports are the same as the exports of the under­lying module. For packages implemented as tables, the package exports are the names used to index the underlying table.
Accessing the exports of a package is a fundamental operation that is supported by all packages. If P is a Maple package, and e is one among its exports, you can access e by using the fully qualified reference P[ e ]. If P is a module, then you can also use the syntax P:-e. These methods of accessing the exports of a module are normally used when programming with a package.
2.3 Packages 79
Note that :- is a left-associative operator. If S is a submodule of a module P, and the name e is exported by S, then the notation P:-S:-e is parsed as (P:-S):-e, and so it refers to the instance of e local to S. This fact is important to reference members of subpackages. For example,
>
m := Matrix(2,2,[[1-x,2-x],[3-x,4-x]],
>
>
LinearAlgebra:-LA_Main:-Norm( m, 1, conjugate = false );
’datatype’ = ’polynom(integer)’ );
m :=
´
1 x 2 x 3 x 4 x
µ
max(|x 1| + |x 3| , |x 2| + |x 4|)
calls the procedure Norm in the subpackage LA_Main of the LinearAlgebra package. You can use indexed notation for this.
>
LinearAlgebra[LA_Main][Norm](m, 1, conjugate = false );
max(|x 1| + |x 3| , |x 2| + |x 4|)
Using Packages Interactively For interactive use, it is inconvenient to enter fully-qualified references to all the exports of a package. To ease this burden, the Maple procedure with is provided for the interactive management of package namespaces. Using with, you can globally impose the exported names of a package. This allows you to access the package exports, without typing the package prefix, by making the names of the exports visible at the top-level of the Maple session. For example, to use the numtheory package, you can issue the command
>
with( numtheory );
Warning, the protected name order has been redefined and unprotected
80 Chapter 2: Programming with Modules
GIgcd, bigomega, cfrac, cfracpol , cyclotomic, divisors ,
[
factorEQ, factorset , fermat, imagunit, index , integral _basis, invcfrac, invphi , issqrfree, jacobi , kronecker, λ, legendre , mcombine, mersenne , migcdex, minkowski , mipolys, mlog, mobius , mroot, msqrt, nearestp, nthconver, nthdenom, nthnumer , nthpow, order, pdexpand , φ, π, pprimroot , primroot, quadres , rootsunity, safeprime, σ, sq2factor , sum2sqr, τ , thue ]
The effect of this command is to make the names exported by the numtheory package (a list of which is returned by the call to with) avail- able temporarily as top-level Maple commands.
>
cfrac( ( 1 + x )^k, x, 5, ’subdiagonal’, ’simregular’ );
1
1
k x
(k + 1) x 1 6
1 +
(k 1) x
(k + 2) x
1 6
1 + ...
1
1 +
1 2
Writing Maple Packages by Using Modules
This section describes how to write Maple packages by using modules. The following subsections present several examples that illustrate how to do this.
The LinkedList Package
The first example package is a small package called LinkedList. This example illustrates the basic structure of a package implemented by using modules.
Background Linked lists are a basic data structure used in programs for many different purposes. There are many kinds of linked lists, with variations on the basic idea intended to address performance and func­tionality issues. The example package shown in this subsection provides a few operations on the simplest possible form of linked lists.
The links in a linked list are formed from a very simple data structured called a elements. Pairs can be modeled by fixed length records with two slots.
pair. A pair is essentially a container with space for exactly two
2.3 Packages 81
When used to implement linked lists, the first slot holds the data for the list entry, and the second slot stores a pointer to the next pair in the list.
The LinkedList package implements an abstract data definition for the pair data structure, and adds some higher level operations on pairs to effect the list abstraction. A linked list is effectively represented by its first pair.
The pair abstract data structure is very simple. It consists of a con­structor pair, and two accessors called
head and tail that satisfy the
algebraic specification
p = pair(head(p), tail(p))
for each pair p. In addition, there is a distinguished pair nil, satisfying this algebraic relation, that is unequal to any other pair, and satisfies
head(nil) = nil, tail(nil) = nil.
Note that linked lists are quite different from the Maple built-in list structures, which are really immutable arrays. Linked lists are best suited for applications in which you want to incrementally build up the list from its members.
1
Package Implementation The LinkedList package is implemented as a module containing the primitive operations on pairs, and higher level operations that implement the list abstraction.
>
macro( _PAIR = ‘‘ ): # for nice printing
>
LinkedList := module()
> > > > > > > > > > > > > > > >
1
Lisp programmers will recognize the pair, head, and tail operations as the more
traditional operations known as “consÔ, “carÔ and “cdrÔ.
description "routines for simple linked lists"; export
nil, nullp, pair, head, tail, list, length, member, reverse, append, map;
local
setup, cleanup,
82 Chapter 2: Programming with Modules
> > > > > > >
unload = cleanup;
map1, reverse1, _PAIR;
option
package,
load = setup,
> > > >
setup := proc()
global ‘type/Pair‘, ‘type/LinkedList‘; ‘type/Pair‘ := ’{ _PAIR( anything, anything ),
> >
‘type/LinkedList‘ := proc( expr )
> > > > > > > > >
end proc; userinfo( 1, ’LinkedList’,
> > >
NULL
end proc;
> > > >
cleanup := proc()
global ‘type/Pair‘, ‘type/LinkedList‘; userinfo( 1, ’LinkedList’,
> > > > >
‘type/Pair‘ := evaln( ‘type/Pair‘ ); ‘type/LinkedList‘ := evaln( ‘type/LinkedList‘ ); NULL
end proc;
> > > > > > > >
pair := ( a, b )
-> setattribute( ’_PAIR’( a, b ), ’inert’ );
head := ( c::Pair )
-> ‘if‘( c = nil, nil, op( 1, c ) );
tail := ( c::Pair )
-> ‘if‘( c = nil, nil, op( 2, c ) );
nullp := ( pair )
> > > > > >
list := proc()
local a, L; L := nil; for a in args do
> > >
end do
end proc;
> > >
length := proc( lst )
if nullp( lst ) then
identical( nil ) }’;
if expr = nil then
true
elif type( expr, Pair ) then
type( tail( expr ), ’LinkedList’ )
else
false
end if
"new types ‘Pair’ and ‘LinkedList’ defined" );
"cleaning up global types" );
-> evalb( pair = nil );
L := pair( a, L )
2.3 Packages 83
> > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > >
end proc;
member := proc( item, lst )
end proc;
map := proc( p, lst )
end proc;
append := proc( lst1, lst2 )
end proc;
reverse1 := proc( sofar, todo )
end proc;
reverse := lst -> reverse1( nil, lst );
setup();
end module:
0
else
1 + length( tail( lst ) )
end if
if nullp( lst ) then
false
elif item = head( lst ) then
true
else
procname( item, tail( lst ) )
end if
if nullp( lst ) then
nil
else
pair( p( head( lst ) ),
procname( p, tail( lst ) ) )
end if
if nullp( lst1 ) then
lst2
else
pair( head( lst1 ),
procname( tail( lst1 ), lst2 ) )
end if
if nullp( todo ) then
sofar
else
procname( pair( head( todo ), sofar ),
tail( todo ) )
end if
Normally, a package definition like this would be entered into a Maple source file using a text editor, or in a worksheet using the Maple graphical user interface. In either case, the definition would then be followed by a call to the savelib procedure using the name of the module as its sole
84 Chapter 2: Programming with Modules
argument:
>
savelib( ’LinkedList’ );
Evaluating the savelib call saves the module to the first repository found in the global variable libname, or the repository named with the global variable savelibname, if it is defined. (At least one of these must be defined.)
Important Always ensure that the standard Maple library is write­protected to avoid saving expressions in it. If you accidentally save some­thing to the standard Maple library, you may need to restore the original from the media on which you obtained the Maple software.
The package exports are listed as the exports of the module. A few local variables are used to implement the package. The local procedures map1 and reverse1 are part of the package implementation that is not available to users of the package. They are visible only within the module definition. This allows the package author to make improvements to the package without disturbing any code that uses it. If the local procedures reverse1 and map1 were exported (thus, available to users), it would be difficult for the author to replace these routines without breaking existing code that relies upon them.
The package includes two special (local) procedures, setup and cleanup. These are executed, respectively, when the module is first read from a repository, and when the package is either garbage collected or when Maple is about to exit.
Using the Package The package exports can always be accessed by using the long form of their names.
>
LinkedList:-pair( a, b );
(a, b)
For consistency with the older table-based package implementations, an indexed notation can also be used.
>
LinkedList[ ’pair’ ]( a, b );
(a, b)
2.3 Packages 85
This form requires that the index (in this case, the symbol pair) be protected from evaluation, and the notation does not extend to packages with nested subpackages.
To access the package exports interactively, use the with command.
>
with( LinkedList );
Warning, the protected names length, map and member have been redefined and unprotected
append, head , length, list, map, member, nil , nullp, pair,
[ reverse, tail ]
Note that, since some of the package exports shadow global procedures with the same name, the with command issues warnings. These warnings are normal. They remind you that these names now refer to expressions different from the expressions to which they referred previously. Once the exports of the package LinkedList have been bound, you can call them as you would global Maple routines with those names. Note that you can still access the global version of member, for example, by using the syntax :-member.
>
use LinkedList in
>
member( a, %% );
>
:-member( a, [ a, b, c, d ] )
>
end use;
true
true
This is one of the principal advantages of using modules and binding, rather than assignment, to implement packages.
Lists are either built incrementally using the pair export of the pack­age, or by calling the list export.
>
L := nil:
>
for i from 1 to 10 do
> >
L := pair( i, L )
end do;
86 Chapter 2: Programming with Modules
L := (1,
L := (2, (1,
L := (3, (2, (1,
L := (4, (3, (2, (1,
L := (5, (4, (3, (2, (1,
L := (6, (5, (4, (3, (2, (1,
nil )
nil ))
nil )))
nil ))))
nil )))))
nil ))))))
L := (7, (6, (5, (4, (3, (2, (1,
L := (8, (7, (6, (5, (4, (3, (2, (1,
L := (9, (8, (7, (6, (5, (4, (3, (2, (1,
L := (10, (9, (8, (7, (6, (5, (4, (3, (2, (1,
>
length( L );
10
>
member( 3, L );
nil )))))))
nil ))))))))
nil )))))))))
nil ))))))))))
true
>
member( 100, L );
false
>
reverse( L );
(1, (2, (3, (4, (5, (6, (7, (8, (9, (10,
>
map( x -> x^2, L );
(100, (81, (64, (49, (36, (25, (16, (9, (4, (1,
>
member( 100, % );
true
nil ))))))))))
nil ))))))))))
>
L2 := list( a, b, c, d );
L2 := (d, (c, (b, (a, nil ))))
>
map( sin, L2 );
2.3 Packages 87
(sin(d), (sin(c), (sin(b), (sin(a),
>
eval( L2, { a = 1, b = 2, c = 3, d = 4 } );
nil ))))
nil ))))
>
map( evalf[ 10 ], % );
(4., (3., (2., (1.,
(4, (3, (2, (1,
nil ))))
Code Coverage Profiling Package
The following example is a package called coverage. It instruments proce­dures and modules for coverage profiling, that is, turns on statement-level tracing. It serves as an example of a small package, and illustrates ways in which modules can be manipulated.
Design You can write tests that exercise each part of the program to ensure that the program:
Works correctly
2
Continues to work when it, or other programs on which it depends, change over time.
It is important to be able to determine whether each statement in a procedure is executed by some test case. The traceproc option of the Maple command debugopts provides that capability. It takes the name p of a procedure, using the syntax
2
The Maple CodeTools package provides tools for profiling code and testing code
coverage. For more information, refer to ?CodeTools.
88 Chapter 2: Programming with Modules
debugopts( ’traceproc’ = p );
and instruments the procedure assigned to p for coverage profiling. Here is an example.
>
p := proc( x )
> > > > > > >
if x < 0 then
2 * x
else
1 + 2 * x
end if end proc: debugopts( ’traceproc’ = p ):
Once the procedure has been instrumented, each time it is executed, profiling information at the statement level is stored. To view the profiling information, use the procedure showstat.
>
p( 2 );
5
>
showstat( p );
p := proc(x)
|Calls Seconds Words|
PROC | 1 0.000 12|
1 | 1 0.000 12| if x < 0 then 2 | 0 0.000 0| 2*x
else
3 | 1 0.000 0| 1+2*x
end if
end proc
The display shows that only one branch of the if statement that forms the body of p was taken so far. This is because only a non-negative argu­ment has been supplied as an argument to p. To get complete coverage, a negative argument must also be supplied.
>
p( -1 );
2
>
showstat( p );
2.3 Packages 89
p := proc(x)
|Calls Seconds Words|
PROC | 2 0.000 24|
1 | 2 0.000 24| if x < 0 then 2 | 1 0.000 0| 2*x
else
3 | 1 0.000 0| 1+2*x
end if
end proc
The display shows that each statement in the body of p has been reached.
To display the profiling information, use the debugopts command with the traceproctable=procedure_name equation argument.
>
debugopts( traceproctable=p );
2 0 24
2 0 24
 
1 0 0
  
1 0 0
The package illustrated in this section helps extend this functionality to modules, and acts as an interface to the debugopts with the traceproc option.
The coverage package has two exports: profile and covered. Two private procedures, rprofile and traced, are used as subroutines. They are stored in local variables of the underlying module of the package.
The Package Source Here is the source code for the package.
>
coverage := module()
> > > > > > > > > > > > >
description "a package of utilities for "
"code coverage profiling"; option package; export profile, covered; local rprofile, traced, userprocs;
# Instrument a procedure or module # for coverage profiling. Return the # number of procedures instrumented. profile := proc()
local arg; add( rprofile( arg ), arg = [ args ] )
end proc;
90 Chapter 2: Programming with Modules
> > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > >
rprofile := proc( s::name )
local e; if type( s, ’procedure’ ) then
debugopts( ’traceproc’ = s ); 1
elif type( s, ’‘module‘’ ) then
add( procname( e ),
e = select( type,
[ exports( s, ’instance’ ) ], ’{ ‘module‘, procedure }’ ) )
else
error "only procedures and modules can be profiled"
end if
end proc;
# Subroutine to recognize non-builtin procedures userprocs := proc( s)
type( ’s’, procedure) and not( type( ’s’, builtin ) )
end proc;
# Subroutine to recognize profiled procedures traced := proc( s )
debugopts( ’istraceproced’ = ’s’ )
end proc;
# Determine which procedures have # coverage information. covered := proc()
local S; S := [ anames( ) ]; S := select( userprocs, S ); S := select( traced, S ); if nargs > 0 and args[ 1 ] = ’nonzero’ then
S := select( s -> evalb( s[1,1] <> 0 ), S )
elif nargs > 0 then
error "optional argument is the name nonzero" end if; map( parse, map( convert, S, ’string’ ) )
end proc;
end module:
How the Package Works The export profile is an interface to the package’s principal facility: instrumenting procedures and modules for coverage profiling. It returns the number of procedures instrumented, and calls the private subroutine rprofile to do most of the work.
1. The procedure rprofile accepts a name s as an argument. If s is the name of a procedure, rprofile simply calls debugopts to instrument the procedure assigned to that name. Otherwise, if s is the name of a module, rprofile selects any exports of the module that are
