Mannhart INGBIN-1CMPT1, INGBIN-1CMPT2, INGBIN-1CMPT3, INGBIN-1CMPT4, INGBIN-2COMPT Specifications

Project:

29.2”

(74.2 cm)

14.1”

(35.8 cm)

26.4”

(67.1 cm)

22.1”

(56.1 cm)

27.0” OA

(68.6 cm)

STANDARD FEATURES

■ Stainless steel all-welded bin with sliding cover

■ Sanitary cover corner design eliminates the need for costly replacement liners

■ Approximate capacity of 120 lbs. (54kg) of cake flour or 190 lbs (86kg) of

granulated sugar

■ Sturdy 3" non-marking casters (2 fixed and 2 swivel) require no lubrication

■ Moves easily when fully loaded

■ Divided compartments conveniently separate ingredients within one

mobile unit

MODEL CONFIGURATION

Model Description Weight

INGBIN-1CMPT1 1 Compartment bin, packaged 1 to a box

INGBIN-1CMPT2 1 Compartment bin, packaged 2 to a box

INGBIN-1CMPT3 1 Compartment bin, packaged 3 to a box

INGBIN-1CMPT4 1 Compartment bin, packaged 4 to a box

INGBIN-2COMPT 2 Compartment bin, packaged 1 to a box

INGBIN-3COMPT 3 Compartment bin, packaged 1 to a box

Table Length

Maximum Bin
Quantity

4'

(1.2 m)

2 3 4 5 7 9

5'

(1.5 m)

6'

(1.8 m)

(2.4m)

8'

40 lbs/18.1kg

Frt cl 150

80 lbs/36.3kg

Frt cl 100

120 lbs/54.4kg

Frt cl 92.5

160 lbs/23.6kg

Frt cl 85

52 lbs/23.6kg

Frt cl 150

64 lbs/29.0kg

Frt cl 150

10'

(3.0m)

12'

(3.7m)

Item#

C.S.I. Section 11400

INGREDIENT BIN

Approved for

Single Compartment

Note: Table must be 36" (91 cm) wide min. to accommodate ingredient bin below.

BX56020 (01-09) – Printed In USA

19220 State Route 162 East

Orting, WA 98360

www.baxterbakery.com

Factory

[phone]

Area Reserved For Consultant & Contractor Approvals

Manuf acturer r eserves t he right to mak e changes in siz es and speci fications.

Customer Care

[phone]

or

[phone]

Customer Care Fax

[phone]

Page 1 of 1
