Mannhart HX Frymate, HX15S Specifications

701 S Ridge Avenue, Troy, OH 45374

1-888-4HOBART • www.hobartcorp.com

Item # _____________________________________

Quantity ___________________________________

C.S.I. Section 11400

HX SERIES
FRYMATE

™

STANDARD FEATURES

■ Free standing or “Add On” in the field to the left
or right of a freestanding fryer or battery of fryers

■ Stainless steel front, top, sides and door

■ Stainless steel sloped drain top with removable

grease collector

■ Set of four 6" adjustable casters (two locking,
two non-locking) on HX15, HX21, HX21S and
HX21MS

■ Set of four 6" adjustable legs for HX15S only

ACCESSORIES

❏ Tank cover (works as solid work surface)

❏ Heat lamp

MODELS

❏ HX15 – Field installed to: 1HG35, 1HG45,

2HG45F, 2HG65F, 4HG45F

❏ HX15S – Field installed to: 1HF50, 2HF50F,

3HF50F, 4HF50F

❏ HX21 – Field installed to: 1HG65, 2HG65F,

3HG65F

❏ HX21S – Field installed to: 1HG85, 2HG85F,

3HG85F, 1HF85, 2HF85F, 3HF85F

❏ HX21MS (with Mobile Filter Storage) –

Field installed to: All fryers, please note – width
and depth may not match fryer

Specifications, Details and Dimensions on Reverse Side.

Shown with Heat Lamp accessory

Frymate™ HX15

F-40185 – HX Series Frymate™ Page 1 of 2

Frymate™ HX21MS with Mobile Filter Storage

Shown with Heat Lamp accessory

HX SERIES FRYMATE

™

Printed On Recycled Paper

HX SERIES
FRYMATE

DETAILS AND DIMENSIONS

SPECIFICATIONS

These “Add On” accessory frymates can be securely attached
to any gas or electric free-standing fryer or KleenScreen
System fryer battery. “Add-On” a Frymate to the left or right side
of a fryer, or both sides. Easy access storage area behind door.

HX21MS has the same features as the HX21S with additional

20.75" x 23.63" stationary shelf plus the added convenience for
a place to store the mobile filter 85HMF.

™

®

Filter

701 S Ridge Avenue, Troy, OH 45374

1-888-4HOBART • www.hobartcorp.com

IMPORTANT

1. An adequate ventilation system is required for Commercial
Cooking Equipment. Information may be obtained by writing
to the National Fire Protection Association, Batterymarch
Park, Quincy, MA 02269. When writing refer to NFPA No. 96.

2. This appliance is manufactured for commercial installation
only and is not intended for home use.

SERVICE CONNECTIONS:

E1 8' 120 volt power cord supplied on optional heat lamp.

120/60/1 electrical connection, 481⁄4" from floor.

MODEL WIDTH DEPTH

OVERALL

HEIGHT

WORKING

HEIGHT

CASTERS LEGS

HX15 15.50" 30.125" 46.25" 36.25" Yes No 122 lbs.
HX15S 15.50" 34.375" 46.25" 36.25" No Yes 130 lbs.
HX21 21.00" 30.125" 46.25" 36.25" Yes No 165 lbs.
HX21S 21.00" 34.375" 46.25" 36.25" Yes No 173 lbs.
HX21MS 21.00" 34.375" 46.25" 36.25" Yes No 185 lbs.

As continued product improvement is a policy of Hobart, specifications are subject to change without notice.

Page 2 of 2 F-40185 – HX Series Frymate

F-40185 (12/07) LITHO IN U.S.A. (H-01)

APPROX.
SHIP. WT.

™
