01 - 2014
DSS610F / DSS610RFE / DSS610Z
18V 6-1/2” CIRCULAR SAW
3
5
7
4
18
17
19
20
21
22
26
28
27
24
25
16
15
12
10
11
14
13
23
32
9
6
31
2
29
30
1
33
34
52
53
41
54
55
42
46
45
47
48
49
50
51
43
44
40
63
64
65
77
78
79
81
80
38
39
62
76
72
73
71
35
36
37
56
61
60
66
67
70
68
85
69
57
58
59
82
Item No Type Ref Part No Description QtyUnit
E
T
A
V
K
X
R
0
X
R
1 265995-6 TAPPING SCREW 4X18 6 PC.
2 141470-5 HANDLE COVER COMPLETE 1
3 650631-1 SWITCH 1
4 231469-9 COMPRESSION SPRING 4 1
5 419322-1 LOCK OFF LEVER 1
6 620088-0 POWER SUPPLY CIRCUIT 1
7 231469-9 COMPRESSION SPRING 4 1
9 644808-8 TERMINAL 1
10 419176-6 SWITCH LEVER 1
11 265995-6 TAPPING SCREW 4X18 2
12 419281-9 REAR COVER 1
13 643941-3 BRUSH HOLDER CAP 2
14 195022-4 CARBON BRUSH CB-441, 2PCS/SET, W/ORIGIN 1
15 911263-2 PAN HEAD SCREW M5X40 3
16 643895-4 BRUSH HOLDER 1
17 643896-2 BRUSH HOLDER 1
18 815E89-3 NAME PLATE F/DSS610 1
19 142460-1 v MOTOR HOUSING COMPLET
19
INC.
802U29-6 v CAUTION LABEL 1 PC.
20 638107-8 YOKE UNI
21 419285-1 BAFFLE PLATE 1
22 266292-3 TAPPING SCREW 4X65 2
23 210023-2 BALL BEARING 627DDW 1
24 519173-3
24
INC.
RMATURE ASS'Y 18
Item No. 23,25,26
25 241869-5 FAN 55 1
26 211061-7 BALL BEARING 6000LLB 1
27 346059-6 SHAFT LOC
28 233092-6 COMPRESSION SPRING 5 1
29 911118-1 PAN HEAD SCREW M4X12 2
30 419284-3 BLOWER NOZZLE 1
31 188045-9 BLADE CASE SET 1
31
31
INC.
INC.
213434-0 O RING 26 1 PC.
Item No. 32
32 819217-2 MAKITA LOGO PLATE 1
33 262049-0 RUBBER RING 6 1
34 251368-9 + COUNTERSUNK SCREW M6 1
35 210028-2 BALL BEARING 606ZZ 1
36 961052-5 RETAINING RING S-12 1
37 227156-6 SPUR GEAR 52 1
38 257173-2 RING 12 1
39 213512-6 O RING 39 1
40 265034-2 + COUNTERSUNK HEAD SCREW M5X16 2
41 318009-1 BEARING BO
42 211131-2 BALL BEARING 6001DDW 1
43 324626-7 SPINDLE 1
44 285845-9 BEARING RETAINER 19-29 1
45 345469-4 THICKNESS RING 1
46 231821-1 TENSION SPRING 3 1
47 419280-1 SAFETY COVE
48 961152-1 RETAINING RING (EXT) S-34 1
49 224151-7 INNER FLANGE 40 1
50 224275-9 OUTER FLANGE 40 1
51 266133-3 HEX. SOCKET HEAD BOLT M6X2
52 631694-6 LED CIRCUIT 1
53 419341-7 CONNECTOR BO
54 419282-7 LIGHT COVE
PC.
PC.
PC.
PC.
PC.
PC.
PC.
PC.
PC.
PC.
PC.
SET
PC.
PC.
PC.
PC.
1 PC.
1 PC.
PC.
PC.
PC.
1 PC.
PC.
PC.
1 PC.
PC.
PC.
PC.
PC.
PC.
PC.
PC.
PC.
PC.
PC.
PC.
PC.
PC.
1 PC.
PC.
PC.
PC.
PC.
PC.
1 PC.
PC.
PC.
PC.
1 PC.
PC.
1 PC.
1 PC.
2 MODEL DSS610F, DSS610RFE, DSS610Z
(updated: 1/15/2014)
Item No Type Ref Part No Description QtyUnit
A
R
R
A
A
A
Y
A
A
A
A
A
A
A
A06A
A
A
55 266026-4 TAPPING SCREW BIND CT 4X12 2 PC.
56 961014-3 STOP RING E-8 1
57 272229-0 LEVER 40 1
58 252158-3 HEX.NUT M6 1
59 941151-9 FLAT WASHER 6 1
60 345658-1 DEPTH GUIDE 1
61 252103-8 HEX. LOCK NUT M5-8 1
62 345657-3
NGULAR GUIDE 1 PC.
63 317986-4 STOPPE
64 213062-1 O RING 9 1
65 265084-7 + TRUSS HEAD SCREW M5 1
66 266194-3 FLAT HEAD SCREW M6X90 1
67 256480-0 SHOULDER PIN 6-7 1
68 256480-0 SHOULDER PIN 6-7 1
69 266264-8 H.S.SET SCREW(FLAT POINT)M5X6 1
70 251919-8 CAP SQUARE NECK BOLT M6X20 1
71 231007-7 COMPRESSION SPRING 6 1
72 251896-4 SCREW M5X20 1
73 941151-9 FLAT WASHER 6 1
76 252133-9 HEX. NUT M6 1
77 961014-3 STOP RING E-8 1
78 272251-7 LEVER 30 1
79 266264-8 H.S.SET SCREW(FLAT POINT)M5X6 1
80 266229-0 H.S.SET SCREW(CUP POINT)M5X8 1
81 154831-0 BASE COMPLETE 1
81
INC.
816850-1 SCALE PLATE 1 PC.
82 266229-0 H.S.SET SCREW(CUP POINT)M5X8 1
85 253186-1 FLAT WASHER 7 1
D01
D02
654509-0 CONNECTOR 2-SD 2 PC.
654208-4 RECEPTACLE 2
100 620258-1 CONTROLLE
101 911118-1 PAN HEAD SCREW M4X12(F/Dust Nozzle) 1
PC.
PC.
PC.
PC.
PC.
PC.
1 PC.
PC.
PC.
PC.
PC.
PC.
PC.
PC.
PC.
PC.
PC.
PC.
PC.
PC.
PC.
PC.
PC.
PC.
PC.
PC.
1 PC.
PC.
ACCESSORIES - See Catalogue or visit www.makita.ca for more accessories information -
01 164095-8 GUIDE RULE 1 PC.
02 --------- BATTERY CHARGER
03 --------- 18V LI-ION BATTER
04 783203-8 HEX. WRENCH 5 1 PC.
05
05
05
05
05
05
1
1 INC.
1 INC.
2
2 INC.
2 INC.
824757-7 PLASTIC CARRYING CASE 1 PC.
163455-1 LATCH 2 PC.
419360-3 HANDLE 1 PC.
141353-9 PLASTIC CARRYING CASE 1 PC.
163455-1 LATCH 2 PC.
419360-3 HANDLE 1 PC.
-85092 6-1/2" C.T.SAW BLADE 24T (5/8") 1 PC.
07 P-80012 DUST NOZZLE 1 PC.
08 --------- LI-ION BATTERY ACCESSORIES
3 MODEL DSS610F, DSS610RFE, DSS610Z
(updated: 1/15/2014)
