Makita DFT023FMZ User Manual

02 - 2017

DFT023FMZ

14.4V BL Screwdriver (0.5-2Nm)

11

5

6

7

4

3

1

2

28

20

43

21

29

22

30

44

31

23

32

45

A03

33

34

25

26

35

37

36

38

8

9

15

39

40

41

16

17

14

12

57

46

47

3

42

27

50

19

51

18

10

52

53

55

54

2 MODEL DFT023FMZ (Updated:24/02/2017)

Item

Type

Part No Description Qty Unit

1 345647-6 PLATE L 1 PC.

2 853A21-5 NAME PLATE F/DFT023F 1 PC.

3 183F88-2 HOUSING SET 1 SET

3 INC. 263005-3 RUBBER PIN 6 2 PC.

3 INC. 931002-4 HEX NUT M3 7 PC.

4 233025-1 COMPRESSION SPRING 2 1 PC.

5 2 458136-3 SWITCH LEVER 1 PC.

6 632K18-5 SWITCH UNIT 1 PC.

7 620521-2 LED CIRCUIT 1 PC.

8 457469-3 F/R CHANGE LEVER 1 PC.

9 651082-1 SWITCH C3JW-1B-S 1 PC.

10 620617-9 CONTROLLER 1 PC.

11 457526-7 CHANGE PLATE 1 PC.

12 457484-7 LENS 1 PC.

14 620622-6 LED CIRCUIT 1 PC.

15 620621-8 BUZZER CIRCUIT 1 PC.

16 620623-4 USB CIRCUIT 1 PC.

17 144709-5 USB COVER COMPLETE 1 PC.

18 643850-6

TERMINAL

1 PC.

19

853A24-9 SERIAL NO. LABEL F/DFT023F 1

PC.

20 233930-2 RING SPRING 9 1 PC.

21 267070-4 FLAT WASHER 10 1 PC.

22 232374-3 COMPRESSION SPRING 10A 1 PC.

23 161607-8 BIT SLEEVE 1 PC.

24 457530-6 LOCK NUT M28, BLACK 1 PC.

25 213836-0 O RING 22 1 PC.

26 216015-9 STEEL BALL 2.4 2 PC.

27 123937-5 CLUTCH ASSEMBLY 2M 1 PC.

27 INC. Item No. 28-41

28 961026-6 RETAINING RING S-10 1 PC.

29 210076-1 BALL BEARING 6800LLB 1 PC.

30 232375-1 COMPRESSION SPRING 10B 1 PC.

31 267047-9 FLAT WASHER 10 1 PC.

32 326953-8 LOCK NUT M12 1 PC.

33 144421-7 ADJUST RING COMPLETE 1 PC.

34 253391-0 FLAT WASHER 18 1 PC.

35 326944-9 SPINDLE M 1 PC.

36 232372-7 COMPRESSION SPRING 18A 1 PC.

37 216024-8 STEEL BALL 4 3 PC.

38 223185-7 CAM A 1 PC.

39 216024-8 STEEL BALL 4 3 PC.

40 223186-5 CAM B 1 PC.

41 216001-0 STEEL BALL 3.5 8 PC.

42 123969-2 GEAR ASSEMBLY A 1 PC.

42 INC. Item No. 43-47,50,51

43 144423-3 CARRIER COMPLETE A 1 PC.

44 211375-4 BALL BEARING 6805LLB 1 PC.

45 457529-1 GEAR CASE 1 PC.

46 221546-5 INTERNAL GEAR 47 1 PC.

47 227051-0 SPUR GEAR 19 3 PC.

50 267774-8 LOCK WASHER 1 PC.

51 418003-4 MOTOR BRACKET 1 PC.

52 266490-9 TAPPING SCREW PT M2X6 3 PC.
