INSTRUCTION MANUAL
MANUEL D'INSTRUCTION
MANUAL DE INSTRUCCIONES

Cordless Rotary Hammer
Perforateur Sans Fil
Martillo Rotativo Inalámbrico

BHR162

IMPORTANT: Read Before Using.
IMPORTANT: Lire avant usage.
IMPORTANTE: Leer antes de usar.

007369

1

ENGLISH (Original instructions)

SPECIFICATIONS

Model BHR162

Capacities

No load speed (RPM) 0 - 1,500/min.

Blows per minute 0 - 5,000

Overall length 296 mm (11-11/16")

Net weight 2.4 kg ( 5.3 lbs)

Rated voltage D.C. 14.4V

Standard battery cartridges BL1430

• Due to our continuing programme of research and development, the specifications herein are subject to change without notice.

• Specifications and battery cartridge may differ from country to country.

• Weight, with battery cartridge, according to EPTA-Procedure 01/2003

General Power Tool Safety
Warnings

WARNING Read all safety warnings and all

instructions. Failure to follow the warnings and

instructions may result in electric shock, fire and/or
serious injury.

Save all warnings and
instructions for future reference.

The term "power tool" in the warnings refers to your
mains-operated (corded) power tool or battery-operated
(cordless) power tool.

Work area safety

1. Keep work area clean and well lit. Cluttered or

dark areas invite accidents.

2. Do not operate power tools in explosive

atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools

create sparks which may ignite the dust or fumes.

3. Keep children and bystanders away while
operating a power tool. Distractions can cause
you to lose control.

Electrical Safety

4. Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power
tools. Unmodified plugs and matching outlets will

reduce risk of electric shock.

5. Avoid body contact with earthed or grounded

surfaces such as pipes, radiators, ranges and
refrigerators. There is an increased risk of

electric shock if your body is earthed or grounded.

6. Do not expose power tools to rain or wet
conditions. Water entering a power tool will

Concrete 16 mm (5/8")

Steel 13 mm (1/2")

Wood 24 mm (5/16")

GEA006-2

increase the risk of electric shock.

7. Do not abuse the cord. Never use the cord for

carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or
moving parts. Damaged or entangled cords

increase the risk of electric shock.

8. When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of
a cord suitable for outdoor use reduces the risk of
electric shock.

9. If operating a power tool in a damp location is

unavoidable, use a ground fault circuit
interrupter (GFCI) protected supply. Use of an

GFCI reduces the risk of electric shock.

Personal Safety

10. Stay alert, watch what you are doing and use
common sense when operating a power tool.
Do not use a power tool while you are tired or
under the influence of drugs, alcohol or
medication. A moment of inattention while

operating power tools may result in serious
personal injury.

11. Use personal protective equipment. Always
wear eye protection. Protective equipment such
as dust mask, non-skid safety shoes, hard hat, or
hearing protection used for appropriate conditions
will reduce personal injuries.

12. Prevent unintentional starting. Ensure the

switch is in the off-position before connecting
to power source and/or battery pack, picking
up or carrying the tool. Carrying power tools with

your finger on the switch or energising power tools
that have the switch on invites accidents.

13. Remove any adjusting key or wrench before
turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may

2

result in personal injury.

14. Do not overreach. Keep proper footing and
balance at all times. This enables better control
of the power tool in unexpected situations.

15. Dress properly. Do not wear loose clothing or

jewellery. Keep your hair, clothing, and gloves
away from moving parts. Loose clothes,

jewellery or long hair can be caught in moving
parts.

16. If devices are provided for the connection of

dust extraction and collection facilities,
ensure these are connected and properly used.

Use of dust collection can reduce dust-related
hazards.

Power tool use and care

17. Do not force the power tool. Use the correct
power tool for your application. The correct

power tool will do the job better and safer at the
rate for which it was designed.

18. Do not use the power tool if the switch does
not turn it on and off. Any power tool that cannot
be controlled with the switch is dangerous and
must be repaired.

19. Disconnect the plug from the power source

and/or the battery pack from the power tool
before making any adjustments, changing
accessories, or storing power tools. Such

preventive safety measures reduce the risk of
starting the power tool accidentally.

20. Store idle power tools out of the reach of

children and do not allow persons unfamiliar
with the power tool or these instructions to
operate the power tool. Power tools are

dangerous in the hands of untrained users.

21. Maintain power tools. Check for misalignment

or binding of moving parts, breakage of parts
and any other condition that may affect the
power tool’s operation. If damaged, have the
power tool repaired before use. Many accidents

are caused by poorly maintained power tools.

22. Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges
are less likely to bind and are easier to control.

23. Use the power tool, accessories and tool bits

etc. in accordance with these instructions,
taking into account the working conditions
and the work to be performed. Use of the power

tool for operations different from those intended
could result in a hazardous situation.

Battery tool use and care

24. Recharge only with the charger specified by
the manufacturer. A charger that is suitable for

one type of battery pack may create a risk of fire
when used with another battery pack.

25. Use power tools only with specifically
designated battery packs. Use of any other
battery packs may create a risk of injury and fire.

26. When battery pack is not in use, keep it away

from other metal objects, like paper clips,
coins, keys, nails, screws or other small metal
objects, that can make a connection from one
terminal to another. Shorting the battery

terminals together may cause burns or a fire.

27. Under abusive conditions, liquid may be

ejected from the battery; avoid contact. If
contact accidentally occurs, flush with water.
If liquid contacts eyes, additionally seek
medical help. Liquid ejected from the battery may

cause irritation or burns.

Service

28. Have your power tool serviced by a qualified
repair person using only identical replacement
parts. This will ensure that the safety of the power

tool is maintained.

29. Follow instruction for lubricating and

changing accessories.

30. Keep handles dry, clean and free from oil and
grease.

GEB046-2

CORDLESS ROTARY HAMMER
SAFETY WARNINGS

1. Wear ear protectors. Exposure to noise can
cause hearing loss.

2. Use auxiliary handle(s), if supplied with the
tool. Loss of control can cause personal injury.

3. Hold power tool by insulated gripping

surfaces, when performing an operation
where the cutting accessory may contact
hidden wiring. Cutting accessory contacting a

"live" wire may make exposed metal parts of the
power tool "live" and could give the operator an
electric shock.

4. Wear a hard hat (safety helmet), safety glasses

and/or face shield. Ordinary eye or sun
glasses are NOT safety glasses. It is also
highly recommended that you wear a dust
mask and thickly padded gloves.

5. Be sure the bit is secured in place before
operation.

6. Under normal operation, the tool is designed
to produce vibration. The screws can come
loose easily, causing a breakdown or accident.
Check tightness of screws carefully before
operation.

7. In cold weather or when the tool has not been
used for a long time, let the tool warm up for a
while by operating it under no load. This will
loosen up the lubrication. Without proper

3

warm-up, hammering operation is difficult.

8. Always be sure you have a firm footing.
Be sure no one is below when using the tool in
high locations.

9. Hold the tool firmly with both hands.

10. Keep hands away from moving parts.

11. Do not leave the tool running. Operate the tool

only when hand-held.

12. Do not point the tool at any one in the area
when operating. The bit could fly out and
injure someone seriously.

13. Do not touch the bit or parts close to the bit
immediately after operation; they may be
extremely hot and could burn your skin.

14. Some material contains chemicals which may
be toxic. Take caution to prevent dust
inhalation and skin contact. Follow material
supplier safety data.

SAVE THESE INSTRUCTIONS.

WARNING:

DO NOT let comfort or familiarity with product
(gained from repeated use) replace strict adherence
to safety rules for the subject product. MISUSE or
failure to follow the safety rules stated in this
instruction manual may cause serious personal
injury.

USD302-1

Symbols

The followings show the symbols used for tool.

･ volts

･ direct current

･ no load speed

･ revolutions or reciprocation per minute

･ number of blow

ENC007-7

IMPORTANT SAFETY
INSTRUCTIONS

FOR BATTERY CARTRIDGE

1. Before using battery cartridge, read all
instructions and cautionary markings on (1)
battery charger, (2) battery, and (3) product
using battery.

2. Do not disassemble battery cartridge.

3. If operating time has become excessively

shorter, stop operating immediately. It may
result in a risk of overheating, possible burns
and even an explosion.

4. If electrolyte gets into your eyes, rinse them
out with clear water and seek medical
attention right away. It may result in loss of
your eyesight.

5. Do not short the battery cartridge:

(1) Do not touch the terminals with any

conductive material.

(2) Avoid storing battery cartridge in a

container with other metal objects such as
nails, coins, etc.

(3) Do not expose battery cartridge to water

or rain.
A battery short can cause a large current flow,
overheating, possible burns and even a
breakdown.

6. Do not store the tool and battery cartridge in
locations where the temperature may reach or
exceed 50 ﾟ C (122 ﾟ F).

7. Do not incinerate the battery cartridge even if
it is severely damaged or is completely worn
out. The battery cartridge can explode in a fire.

8. Be careful not to drop or strike battery.

9. Do not use a damaged battery.

SAVE THESE INSTRUCTIONS.

Tips for maintaining maximum battery life

1. Charge the battery cartridge before
completely discharged.
Always stop tool operation and charge the
battery cartridge when you notice less tool
power.

2. Never recharge a fully charged battery
cartridge.
Overcharging shortens the battery service life.

3. Charge the battery cartridge with room
temperature at 10 ﾟ C - 40 ﾟ C (50 ﾟ F - 104 ﾟ F).
Let a hot battery cartridge cool down before
charging it.

4. Charge the battery cartridge once in every six
months if you do not use it for a long period of
time.

4

FUNCTIONAL DESCRIPTION

CAUTION:

• Always be sure that the tool is switched off and the

battery cartridge is removed before adjusting or
checking function on the tool.

Installing or removing battery cartridge

1. Red indicator

1

2

012151

Always switch off the tool before installing or

•

removing of the battery cartridge.

• To remove the battery cartridge, slide it from the

tool while sliding the button on the front of the
cartridge.

• To install the battery cartridge, align the tongue on

the battery cartridge with the groove in the housing
and slip it into place. Always insert it all the way
until it locks in place with a little click. If you can see
the red indicator on the upper side of the button, it is
not locked completely. Install it fully until the red
indicator cannot be seen. If not, it may accidentally
fall out of the tool, causing injury to you or someone
around you.

• Do not use force when installing the battery

cartridge. If the cartridge does not slide in easily, it
is not being inserted correctly.

Battery protection system (Lithium-ion
battery with star marking)

1

2. Button

3. Battery cartridge

3

1. Star marking

• Overloaded:

The tool is operated in a manner that causes
it to draw an abnormally high current.
In this situation, release the trigger switch on
the tool and stop the application that caused
the tool to become overloaded. Then pull the
trigger switch again to restart.
If the tool does not start, the battery is
overheated. In this situation, let the battery
cool before pulling the trigger switch again.

• Low battery voltage:

The remaining battery capacity is too low and
the tool will not operate. In this situation,
remove and recharge the battery.

Switch action

1. Switch trigger

2. Lamp

1
2

007375

CAUTION:

• Before inserting the battery cartridge into the tool,

always check to see that the switch trigger actuates
properly and returns to the "OFF" position when

released.
To start the tool, simply pull the switch trigger. Tool speed
is increased by increasing pressure on the switch trigger.
Release the switch trigger to stop.

Electric brake

This tool is equipped with an electric brake. If the tool
consistently fails to quickly stop after switch trigger
release, have tool serviced at a Makita service center.

Lighting up the lamp

1. Switch trigger

2. Lamp

012128

Lithium-ion batteries with a star marking are equipped
with a protection system. This system automatically cuts
off power to the tool to extend battery life.
The tool will automatically stop during operation if the tool
and/or battery are placed under one of the following
conditions:

1
2

007375

CAUTION:

• Do not look in the light or see the source of light

directly.
Pull the switch trigger to light up the lamp. The lamp
keeps on lighting while the switch trigger is being pulled.

5

The light automatically goes out 10 - 15 seconds after the
switch trigger is released.

NOTE:

• Use a dry cloth to wipe the dirt off the lens of lamp.

Be careful not to scratch the lens of lamp, or it may
lower the illumination.

• Do not use thinner or gasoline to clean the lamp.

Such solvents may damage it.

Reversing switch action

1. Reversing switch
lever

AB

1

007376

This tool has a reversing switch to change the direction of
rotation. Depress the reversing switch lever from the A
side for clockwise rotation or from the B side for
counterclockwise rotation.
When the reversing switch lever is in the neutral position,
the switch trigger cannot be pulled.

CAUTION:

• Always check the direction of rotation before

operation.

• Use the reversing switch only after the tool comes

to a complete stop. Changing the direction of
rotation before the tool stops may damage the tool.

• When not operating the tool, always set the

reversing switch lever to the neutral position.

Selecting the action mode

Rotation with hammering

1

2

3

007378

For drilling in concrete, masonry, etc., depress the lock
button and rotate the action mode changing knob to the

symbol. Use a tungsten-carbide tipped bit.

1. Lock button

2. Rotation with
hammering

3. Action mode
changing knob

Rotation only

1. Rotation only

1

007377

For drilling in wood, metal or plastic materials, depress
the lock button and rotate the action mode changing
knob to the

symbol. Use a twist drill bit or wood bit.

CAUTION:

• Do not rotate the action mode changing knob when

the tool is running. The tool will be damaged.

• To avoid rapid wear on the mode change

mechanism, be sure that the action mode changing
knob is always positively located in one of the three
action mode positions.

Torque limiter

The torque limiter will actuate when a certain torque level
is reached. The motor will disengage from the output
shaft. When this happens, the bit will stop turning.

CAUTION:

• As soon as the torque limiter actuates, switch off

the tool immediately. This will help prevent
premature wear of the tool.

• Hole saws cannot be used with this tool. They tend

to pinch or catch easily in the hole. This will cause
the torque limiter to actuate too frequently.

ASSEMBLY

CAUTION:

• Always be sure that the tool is switched off and the

battery cartridge is removed before carrying out
any work on the tool.

Side grip (auxiliary handle)

6

1. Grip base

2. Side grip

3. Loosen

4. Tighten

5. Teeth

6. Protrusion

2

007370

1

5

3

4

6

CAUTION:

• Always use the side grip to ensure operating safety.

Install the side grip so that the teeth on the grip fit in
between the protrusions on the tool barrel. Then tighten
the grip by turning clockwise at the desired position. It
may be swung 360° so as to be secured at any position.

Bit grease

Coat the bit shank head beforehand with a small amount
of bit grease (about 0.5 -1 g; 0.02 - 0.04 oz.). This chuck
lubrication assures smooth action and longer service life.

Installing or removing the bit

Clean the bit shank and apply bit grease before installing
the bit.

1. Bit shank

1

2

001296

Insert the bit into the tool. Turn the bit and push it in until it
engages.

1

2

007372

If the bit cannot be pushed in, remove the bit. Pull the
chuck cover down a couple of times. Then insert the bit
again. Turn the bit and push it in until it engages.
After installing, always make sure that the bit is securely
held in place by trying to pull it out.
To remove the bit, pull the chuck cover down all the way
and pull the bit out.

1

2. Bit grease

1. Bit

2. Chuck cover

1. Bit

2. Chuck cover

Depth gauge

1. Depth gauge

1

007374

The depth gauge is convenient for drilling holes of
uniform depth. Loosen the side grip and insert the depth
gauge into the hole in the side grip. Adjust the depth
gauge to the desired depth and tighten the side grip.

NOTE:

• The depth gauge cannot be used at the position

where the depth gauge strikes against the gear
housing.

Dust cup

1. Dust cup

1

001300

Use the dust cup to prevent dust from falling over the tool
and on yourself when performing overhead drilling
operations. Attach the dust cup to the bit as shown in the
figure. The size of bits which the dust cup can be
attached to is as follows.

Dust cup 5 6 mm (1/4") - 14.5 mm (9/16")
Dust cup 9 12 mm (15/32") - 16 mm (5/8")

006386

Bit diameter

OPERATION

Hammer drilling operation

007373

2

007379

7

Set the action mode changing knob to the

symbol.
Position the bit at the desired location for the hole, then
pull the switch trigger.
Do not force the tool. Light pressure gives best results.
Keep the tool in position and prevent it from slipping
away from the hole.
Do not apply more pressure when the hole becomes
clogged with chips or particles. Instead, run the tool at an
idle, then remove the bit partially from the hole. By
repeating this several times, the hole will be cleaned out
and normal drilling may be resumed.

CAUTION:

• There is a tremendous and sudden twisting force

exerted on the tool/bit at the time of hole
break-through, when the hole becomes clogged
with chips and particles, or when striking reinforcing
rods embedded in the concrete. Always use the
side grip (auxiliary handle) and firmly hold the tool
by both side grip and switch handle during
operations. Failure to do so may result in the loss of
control of the tool and potentially severe injury.

NOTE:

Eccentricity in the bit rotation may occur while operating
the tool with no load. The tool automatically centers itself
during operation. This does not affect the drilling
precision.

Blow-out bulb (optional accessory)

1. Blow-out bulb

1

1. Sleeve

1

2. Ring

2

007048

Use the optional drill chuck assembly. When installing it,
refer to "Installing or removing the bit" described on the
previous page.
Set the action mode changing knob so that the pointer
points to the

symbol.

CAUTION:

• Never use "rotation with hammering" when the drill

chuck assembly is installed on the tool. The drill
chuck assembly may be damaged. Also, the drill
chuck will come off when reversing the tool.

• Pressing excessively on the tool will not speed up

the drilling. In fact, this excessive pressure will only
serve to damage the tip of your bit, decrease the
tool performance and shorten the service life of the
tool.

• There is a tremendous twisting force exerted on the

tool/bit at the time of hole breakthrough. Hold the
tool firmly and exert care when the bit begins to
break through the workpiece.

• A stuck bit can be removed simply by setting the

reversing switch to reverse rotation in order to back
out. However, the tool may back out abruptly if you
do not hold it firmly.

• Always secure small workpieces in a vise or similar

hold-down device.

002449

After drilling the hole, use the blow-out bulb to clean the
dust out of the hole.

Drilling in wood or metal

1

2

007380

1. Chuck adapter

2. Keyless drill
chuck

MAINTENANCE

CAUTION:

• Always be sure that the tool is switched off and the

battery cartridge is removed before attempting to
perform inspection or maintenance.

• Never use gasoline, benzine, thinner, alcohol or the

like. Discoloration, deformation or cracks may
result.

8

Replacing carbon brushes

r

1. Limit mark

1

001145

Remove and check the carbon brushes regularly.
Replace when they wear down to the limit mark. Keep
the carbon brushes clean and free to slip in the holders.
Both carbon brushes should be replaced at the same
time. Use only identical carbon brushes.
Remove holder cap covers by inserting the slotted bit
screwdriver into the recessed part in the tool and lifting it
up.

1

007381

Use a screwdriver to remove the brush holder caps. Take
out the worn carbon brushes, insert the new ones and
secure the brush holder caps.

1

1. Holder cap cove

2. Recessed part

2

1. Brush holder cap

2. Screwdriver

OPTIONAL ACCESSORIES

CAUTION:

• These accessories or attachments are

recommended for use with your Makita tool
specified in this manual. The use of any other
accessories or attachments might present a risk of
injury to persons. Only use accessory or

attachment for its stated purpose.
If you need any assistance for more details regarding
these accessories, ask your local Makita Service Center.

• SDS-Plus Carbide-tipped bits

• Drill chuck assembly

• Drill chuck S13

• Chuck adapter

• Chuck key S13

• Bit grease

• Side grip

• Depth gauge

• Blow-out bulb

• Dust cup

• Dust extractor attachment

• Safety goggles

• Plastic carrying case

• Keyless drill chuck

• Various type of Makita genuine batteries and

chargers

NOTE:

• Some items in the list may be included in the tool

package as standard accessories. They may differ

from country to country.

2

007382

Remount the holder cap covers on the tool.
After replacing brushes, insert the battery cartridge into
the tool and break in brushes by running tool with no load
for about 1 minute. Then check the tool while running and
electric brake operation when releasing the switch trigger.
If electric brake is not working well, ask your local Makita
service center for repair.
To maintain product SAFETY and RELIABILITY, repairs,
any other maintenance or adjustment should be
performed by Makita Authorized or Factory Service
Centers, always using Makita replacement parts.

9

MAKITA LIMITED ONE YEAR WARRANTY

Warranty Policy

Every Makita tool is thoroughly inspected and tested
before leaving the factory. It is warranted to be free of
defects from workmanship and materials for the period
of ONE YEAR from the date of original purchase.
Should any trouble develop during this one year period,
return the COMPLETE tool, freight prepaid, to one of
Makita’s Factory or Authorized Service Centers. If
inspection shows the trouble is caused by defective
workmanship or material, Makita will repair (or at our
option, replace) without charge.

This Warranty does not apply where:

repairs have been made or attempted by others:
repairs are required because of normal wear and
tear:
the tool has been abused, misused or improperly
maintained:
alterations have been made to the tool.

IN NO EVENT SHALL MAKITA BE LIABLE FOR ANY
INDIRECT, INCIDENTAL OR CONSEQUENTIAL
DAMAGES FROM THE SALE OR USE OF THE
PRODUCT. THIS DISCLAIMER APPLIES BOTH
DURING AND AFTER THE TERM OF THIS
WARRANTY.
MAKITA DISCLAIMS LIABILITY FOR ANY IMPLIED
WARRANTIES, INCLUDING IMPLIED WARRANTIES
OF "MERCHANTABILITY" AND "FITNESS FOR A
SPECIFIC PURPOSE," AFTER THE ONE YEAR TERM
OF THIS WARRANTY.
This Warranty gives you specific legal rights, and you
may also have other rights which vary from state to
state. Some states do not allow the exclusion or
limitation of incidental or consequential damages, so
the above limitation or exclusion may not apply to you.
Some states do not allow limitation on how long an
implied warranty lasts, so the above limitation may not
apply to you.

EN0006-1

10
