Make Noise STO User Manual

STO

Limited WARRANTY:
Make Noise warrants this product to be free of defects in materials or construction for a period of one year
from the date ofSXUFKDVHSURRIRISXUFKDVHLQYRLFHUHTXLUHG.

Malfunction resulting from wrong power supply voltages, backwards power cable connection, abuse of the
product or any other causes determined by Make Noise to be the fault of the user are not covered by this
warranty, and normal service rates will apply.

During the warranty period, any defective products will be repaired or replaced, at the option of Make Noise,
on a return-to-Make Noise basis, with the customer paying the transit cost to Make Noise.
Please contact Make Noise for Return To Manufacturer Authorization.

Make Noise implies and accepts no responsibility for harm to person or apparatus caused through operation
of this product.

Please contact [e-mail] with any questions, needs & comments, otherwise...
go MAKE NOISE.

http://www.makenoisemusic.com

THANK YOU
Beta Analyst: Walker Farrell, Joe Moresi

Test Subjects: Rob Lowe, Joseph Raglani

Installation:

The Make Noise STO is an electronic signal generator requiring 30mA of +12V and 30ma of

-12V regulated power and properly formatted distribution receptacle to operate. It is designed
to be used within the euro format modular synthesizer system.

Go to http://www.doepfer.de/a100_man/a100t_e.htm for the details of this format.

To install, find 8HP of space in your euro-rack synthesizer system, confirm proper installation
of included power cable on backside of module (see picture below), plug the 16pin end
power cable into the euro-rack style power distribution board, minding the polarity so that the
RED stripe on the cable is oriented to the NEGATIVE 12 volt supply line. This is USUALLY at
the bottom.

Please refer to your case manufacturers’ specifications for location of the negative supply.

Proper installation of included power cable on module.
Please note the RED BAND.
