Make Noise modDemix User Manual
modDemix
Limited WARRANTY:
Make Noise warrants this product to be free of defects in materials or construction for a period of one year
from the date of purchase (proof of purchase/invoice required).
Malfunction resulting from wrong power supply voltages, backwards power cable connection, abuse of the
product or any other causes determined by Make Noise to be the fault of the user are not covered by this
warranty, and normal service rates will apply.
During the warranty period, any defective products will be repaired or replaced, at the option of Make Noise,
on a return-to-Make Noise basis, with the customer paying the transit cost to Make Noise. Please contact
Make Noise for Return To Manufacturer Authorization.
Make Noise implies and accepts no responsibility for harm to person or apparatus caused through operation
of this product.
Please contact technical@makenoisemusic.com with any questions, needs & comments, otherwise...
go MAKE NOISE.
http://www.makenoisemusic.com
Thanx to Surachai for his help in beta testing, and to the electronic music pioneers who reclaimed radio
communications tech for musical purposes.
Installation:
The Make Noise modDemix is an analog electronic signal processor requiring 28mA of
+/-12V regulated power and properly formatted distribution receptacle to operate. It is
designed for use within the euro format modular synthesizer system.
Visit http://www.doepfer.de/a100_man/a100t_e.htm for the details of this format.
To install, find 6HP of space in your euro-rack synthesizer system, plug the 16pin power
cable into the euro-rack style power distribution board, minding the polarity so that the RED
stripe on the cable is oriented to the NEGATIVE12 volt supply line. This is USUALLY at the
bottom.
Please refer to your case manufacturers’ specifications for location of the negative supply.
