Make Noise FXDf User Manual

Limited WARRANTY:
Make Noise warrants this product to be free of defects in materials or construction for a period of one year
from the date of purchase (proof of purchase/invoice required).

Malfunction resulting from wrong power supply voltages, backwards power cable connection, abuse of the
product or any other causes determined by Make Noise to be the fault of the user are not covered by this
warranty, and normal service rates will apply.

During the warranty period, any defective products will be repaired or replaced, at the option of Make Noise,
on a return-to-Make Noise basis with the customer paying the transit cost to Make Noise. Please contact
Make Noise for Return To Manufacturer Authorization.

Make Noise implies and accepts no responsibility for harm to person or apparatus caused through operation
of this product.

Please contact [e-mail] with any questions, needs & comments, otherwise...

go MAKE NOISE!

http://www.makenoisemusic.com

Special Thanks to RxMx and Op-Amps

INSTAllaTIon

The Make Noise FXDf is an electronic signal processor requiring 27mA of +12VDC and
27mA of -12VDC regulated power and a properly formatted distribution receptacle to
operate. It is designed to be used within the euro format modular synthesizer system.

Go to http://www.doepfer.de/a100_man/a100t_e.htm for the details of this format.

To install, find 4 HP of space in your euro-rack synthesizer system, confirm proper
installation of included power cable on backside of module (see picture below), plug
the 16 pin end power cable into the euro-rack style power distribution board,
minding the polarity so that the RED stripe on the cable is oriented to the NEGATIVE
12 volt supply line. On the Make Noise power bus board, the negative 12 volt supply is
indicated by the white stripe.

Please refer to your case manufacturer specifications for location of the negative supply

s’
