Mag Layers MSCDRI-5D28 User Manual

SCOPE

：

This specification applies to the Pb Free high current type SMD inductors for

(1) SHAPES AND DIMENSIONS

(2) ELECTRICAL SPECIFICATIONS

(3) CHARACTERISTICS

MSCDRI-5D28-SERIES

PRODUCT INDENTIFICATION MSCDRI - 5D28 - 100 M

① ② ③ ④

① Product Code ② Dimensions Code ③ Inductance Code ④ Tolerance Code

A: 5.70±0.3 mm B: 5.70±0.3 mm C: 3.00 Max. mm D: 5.50 Typ. mm E: 5.50 Typ. mm F: 2.00 Typ. mm

SEE TABLE 1

TEST INSTRUMENTS L : HP 4284A PRECISION LCR METER (or equivalent) RDC : CHROMA MODEL 16502 MILLIOHMMETER (or equivalent)

(3)-1 Ambient temperature ……......... ＋60℃ Max.

(3)-2 Operate temperature range ...... －40℃～＋125℃

(Including self temp. rise)

(3)-3 Storage temperature range ...... －40℃～＋125℃

MAG.LAYERS

MSCDRI-5D28-SERIES Page 1/8

TABLE 1

MAGLAYERS

PT/NO. MSCDRI-5D28-1R0□ MSCDRI-5D28-1R2□ MSCDRI-5D28-2R2□ MSCDRI-5D28-2R5□ MSCDRI-5D28-2R7□ MSCDRI-5D28-3R0□ MSCDRI-5D28-3R3□ MSCDRI-5D28-3R9□ MSCDRI-5D28-4R2□ MSCDRI-5D28-4R7□ MSCDRI-5D28-5R3□ MSCDRI-5D28-6R2□ MSCDRI-5D28-6R6□ MSCDRI-5D28-8R2□

MSCDRI-5D28-100□ MSCDRI-5D28-120□ MSCDRI-5D28-150□ MSCDRI-5D28-180□ MSCDRI-5D28-220□ MSCDRI-5D28-270□ MSCDRI-5D28-330□ MSCDRI-5D28-390□ MSCDRI-5D28-470□ MSCDRI-5D28-560□ MSCDRI-5D28-680□ MSCDRI-5D28-820□ MSCDRI-5D28-101□ MSCDRI-5D28-151□ MSCDRI-5D28-181□

Inductance Percent Test Resistance Rated DC Current

L(μH) Tolerance Frequency RDC(Ω)Max.

1.0 N 100kHz/0.25V 12m 1R0

1.2 N 100kHz/0.25V 13m 1R2

2.2 N 100kHz/0.25V 18m 2R2

2.5 N 100kHz/0.25V 18m 2R5

2.7 N 100kHz/0.25V 18m 2R7

3.0 N 100kHz/0.25V 24m 3R0

3.3 M,N 100kHz/0.25V 24m 3R3

3.9 N 100kHz/0.25V 31m 3R9

4.2 N 100kHz/0.25V 31m 4R2

4.7 M,N 100kHz/0.25V 35m 4R7

5.3 N 100kHz/0.25V 38m 5R3

6.2 N 100kHz/0.25V 45m 6R2

6.6 M,N 100kHz/0.25V 45m 6R6

8.2 M,N 100kHz/0.25V 53m 8R2 10 M,N 100kHz/0.25V 65m 100 12 M,N 100kHz/0.25V 76m 120 15 M,N 100kHz/0.25V 0.103 150 18 M,N 100kHz/0.25V 0.110 180 22 M,N 100kHz/0.25V 0.122 220 27 M,N 100kHz/0.25V 0.175 270 33 M,N 100kHz/0.25V 0.189 330 39 M,N 100kHz/0.25V 0.212 390 47 M,N 100kHz/0.25V 0.250 470 56 M,N 100kHz/0.25V 0.305 560 68 M,N 100kHz/0.25V 0.355 680 82 M,N 100kHz/0.25V 0.463 820

100 M,N 100kHz/0.25V 0.520 101 150 M,N 100kHz/0.25V 1.050 151 180 M,N 100kHz/0.25V 1.550 181

IDC(A)

3.70

3.50

2.80

2.60

2.40

2.20

2.00

1.90

1.80

1.60

1.30

1.20

1.10

1.00

0.90

0.85

0.75

0.70

0.62

0.58

0.52

0.46

0.42

0.35

0.32

Marking

※ □ specify the inductance tolerance,M(±20%),N(±30%) ※ IDC : Based on inductance change (△L/Lo： ≦ drop 35%) @ambient temp. 25℃ and

Based on temperature rise (△T： 40℃ TYP.)

MAG.LAYERS

MSCDRI-5D28-SERIES Page-2/8

(4) RELIABILITY TEST METHOD

MECHANICAL

TEST ITEM SPECIFICATION TEST DETAILS

Substrate bending

△L/Lo≦±5%

There shall be direction is made approximately 3mm.(keep time 30 seconds) no mechanical PCB dimension shall the page 7/9 damage or elec- F(Pressurization) trical damege.

The sample shall be soldered onto the printed circuit board in figure 1 and a load applied unitil the figure in the arrow

PRESSURE ROD

figure-1

Vibration

Solderability

△L/Lo≦ ±5%

There shall be and a frequency of from 10 to 55Hz/1 minute repeated should no mechanical be applied to the 3 directions (X,Y,Z) for 2 hours each. damage. (A total of 6 hours)

New solder Flux (rosin, isopropyl alcohol{JIS-K-1522}) shall be coated More than 90% over the whole of the sample before hard, the sample shall

The sample shall be soldered onto the printed circuit board and when a vibration having an amplitude of 1.52mm

then be preheated for about 2 minutes in a temperature of 130～150℃ and after it has been immersed to a depth 0.5mm below for 3±0.2 seconds fully in molten solder M705 with a temperature of 245±5℃. More than 90% of the electrode sections shall be couered with new solder smoothly when the sample is taken out of the solder bath.

MAG.LAYERS

MSCDRI-5D28-SERIES

Page-3/8
