Magic Chef MCSCWD27W5 User Manual

24” Combo Washer and Dryer 24” Front Load Washer

User’s Manual

Model MCSCWD27W5 / MCSFLW27W

PLEASE READ THIS MANUAL CAREFULLY BEFORE USING YOUR COMBO WASHER AND DRYER AND KEEP IT FOR FUTURE REFERENCE.

PRODUCT REGISTRATION

Thank you for purchasing a Magic Chef® product� The first step to protect your new product is to complete the product registration on our website: www�mcappliance�com/register� The benefits of registering your product include the following:

1� Registering your product will allow us to contact you regarding a safety notification or product update�

2� Registering your product will allow for more efficient warranty service processing when warranty service is required�

3� Registering your product could act as your proof of purchase in the event of insurance loss�

Once again, thank you for purchasing a Magic Chef product�

CONTENTS

PRODUCT REGISTRATION � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 2 IMPORTANT SAFETY INSTRUCTIONS � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 4 SPECIFICATIONS� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 6 INSTALLATION INSTRUCTIONS � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 7 BEFORE USE � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 10 OPERATION INSTRUCTIONS� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 11 WASH CYCLE PARAMETERS� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � �17 CARE AND MAINTENANCE � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 19 TROUBLESHOOTING� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 22 LIMITED WARRANTY � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 24

IMPORTANT SAFETY INSTRUCTIONS

This manual contains Safety Instructions, Installation and Operating Instructions, and Troubleshooting Tips� Please carefully read this manual before using your washing machine for instructions on how to use and maintain the product properly� Be sure to follow the safety instructions to avoid injury or damage to the product�

Keep this manual� When passing on/selling the device to a third party, the manual must be handed over along with the device�

Before calling for service, please make sure unit is installed and being used correctly, and read the troubleshooting section�

WARNING: When using your appliance, follow the precautions listed below� NOTE: Specifications may change at any time without notice�

State of California Proposition 65 Warnings

WARNING: The California Safe Drinking Water and Toxic Enforcement Act requires the Governor of

California to publish a list of substances known to the State of California to cause cancer, birth defects, or other reproductive harm, and requires business to warn of potential exposure to such substances� This product contains a chemical known to the State of California to cause cancer, birth defects, or other reproductive harm� This appliance can cause low-level exposure to some of the substances listed, including benzene, formaldehyde, and carbon monoxide�

1� Read all instructions before using this product� 2� This appliance is for household use only� It is not intended for commercial applications� 3� The appliance is intended for indoor use only� DO NOT use outdoors� 4� DO NOT use this appliance for other than its intended purpose� 5� Use only detergents or softeners recommended for use in this manual and keep them out of the reach of

children�

6� This machine is not intended for use by persons (including children) with reduced physical, sensory or

mental capabilities, or lack of experience and knowledge, unless they are given supervision or instruction

concerning the use of the washer by a person responsible for their safety� 7� This appliance must be properly installed in accordance with the installation instructions before it is to be used� 8� DO NOT unplug your appliance by pulling on its power cord� Always grasp the plug firmly and pull it

straight out from the outlet� 9� Do not operate any appliance that has a damaged cord or plug, if it is damaged or malfunctions in any way,

or if the outlet is not in proper working order� Contact customer service or a service technician� 10� ALWAYS turn off and unplug from outlet before servicing, changing accessories or cleaning the unit� Allow

unit to cool down completely before cleaning, moving or servicing� Turning the unit off does not disconnect

it from the power source� 11� DO NOT put anything flammable or explosive in, on, or near the appliance� DO NOT wash or dry articles

of clothing or any items that have been soaked in flammable or explosive chemicals� To reduce the risk

of fire, clothes, cleaning rags, mop heads and the like which have traces of any flammable substance, such

as cooking oils, petroleum based oils or distillates, waxes, fats, etc�, must not be placed in the washing

machine� These items may contain flammable substances which, even after washing, may smoke or catch

fire� DO NOT dry articles containing foam rubber or similarly textured rubber like materials� 12� ALWAYS wait for the washer tub to completely stop moving before reaching in to add or remove any clothes� 13� The loading door must be closed when the tub is spinning�

14� DO NOT operate this washer unless all enclosure panels are properly installed� 15� DO NOT tamper with or modify the controls�

WARNING: Risk of child entrapment� DO NOT allow children to play on or in the appliance� Close

16�

supervision of children is necessary when the appliance is used around them� 17� The appliance must be plugged into a properly installed and grounded outlet that meets the voltage

requirements listed on the ratings label�

CAUTION: The power cord is equipped with a 3-prong grounding plug to protect against shock hazards�

18�

ALWAYS plug the cord into a properly installed and grounded 3-prong wall receptacle, and DO NOT remove

the grounding prong� 19� Under certain conditions, hydrogen gas may be produced in a household hot water system that has not

been used for two weeks or more� Hydrogen gas is highly explosive� If the hot water system has not been

used for more than two weeks, turn on all hot water faucets and let the water flow for several minutes

prior to using your compact washer� 20� DO NOT modify or repair the unit by yourself� Contact customer service or a qualified service technician if

service is required� 21� To reduce the risk of electric shock or fire, do not use an extension cord or outlet adapters to connect the

unit to an electrical power source� The appliance must be properly grounded using a three-prong electric

receptacle wall outlet� 22� DO NOT install the washing machine in a moist or wet area, or where it can get wet or exposed to outside

weather conditions� DO NOT spray with water when cleaning� 23� DO NOT put children on top of, or allow children or pets to climb in or on, the washer� ALWAYS check

inside before using� 24� Glass door may be very hot during the operation� Keep children and pets away from the washer while in use� 25� Regularly clean the power plug to remove dust and dirt, in order to prevent electrical failure� 26� It is recommended to unplug the unit when it is not in use� 27� ALWAYS be sure to properly and securely connect the power cord to the outlet, and the water hoses to

prevent leakage or electrical shock� 28� DO NOT operate the unit or handle the plug with wet hands� 29� The water temperature to the washing machine should not exceed 131 °F (55 °C)� 30� DO NOT wash raincoats, heavy jackets, or similar, heavy items� 31� DO NOT machine wash fiberglass materials (such as curtains and window coverings that use fiberglass

materials�) Small particles may remain in the washing machine and stick to fabrics in subsequent wash loads

causing skin irritation� 32� When removing from service and discarding, be sure to remove the door from the unit and cut the power cord� 33� DO NOT reach into the wash tub when the agitator is moving�

CAUTION: Content may be HOT when washing and/or drying cycle is completed�

34�

READ AND FOLLOW THIS

SAFETY INFORMATION CAREFULLY

SAVE THESE INSTRUCTIONS

SPECIFICATIONS

42�5” (1080 mm)

Figure 1

23�5” (595 mm)

33�5” (850 mm)

Height 33�5” (850 mm) Width 23�5” (595 mm) Depth 23�5” (595 mm) Depth with Door Opened 42�5” (1080 mm) Weight 160�9 lbs� (73�0 kg) Voltage / Frequency AC 120V~60Hz Rated Current 11�0A Max� Washing Capacity 26�4 lbs� (12�0 kg) Max� Dry Capacity (For MCSCWD27W5 only) 17�6 lbs� (8�0 kg) Drum Size 2�7 cu� ft�

23�5” (595 mm)

INSTALLATION INSTRUCTIONS

1� The washing machine must be properly grounded� In the event of a short circuit, grounding can reduce the

danger of electrical shock� 2� Washing machine should be operated in a circuit separate from other electrical appliances�

INCLUDED PARTS

Before starting installation, make sure all included parts are in the package inside the drum�

INSTALLATION REQUIREMENTS

ELECTRICAL REQUIREMENTS 1� A 120v, 60Hz, AC 15-or 20amp, fused electrical supply

is required� A time-delay fuse or circuit serving only this appliance should be used� 2� This washer is equipped with a power supply cord having a 3 prong grounding plug� 3� To minimize possible shock hazard, the cord must be plugged into a 3 prong outlet, properly grounded in

accordance with local codes and ordinances� If a proper outlet is not available, it is the responsibility of the

customer to have the properly grounded outlet installed by a qualified electrician� 4� If codes permit and a separate ground wire to be used, it is recommended that a qualified electrician

determine the proper ground path� 5� DO NOT ground to a gas pipe� 6� Check with a qualified electrician if you are not sure the washer is properly grounded� 7� DO NOT have a fuse in the neutral or ground circuit� 8� Certain internal parts are intentionally not grounded and may present a risk of electric shock only during

servicing� Service Personnel – Do not contact the following parts while the appliance is energized: Drain

Pump, Door Lock, Drying Heater (Combo), Fan Motor (Combo)�

LOCATION REQUIREMENTS Selecting the proper location for your washer improves performance and minimizes noise and possible washer

“walk�” The washer can be installed under a custom counter or in a basement, laundry room, closet, or recessed area� You will need:

• A water heater set for 120° F (49° C)�

• A grounded electrical outlet located within 6 ft�( 1�8 m) of where the power cord is attached to the back of

the washer�

• Hot and cold water faucets located within 4 ft� (1�2 m) of the hot and cold water fill valves ,and water

pressure of 20 - 100 psi (137�9 - 689�6 kPa)�

• A level floor with a maximum slope of 1” (25 mm) under entire washer� Installing the washer on soft floor

surfaces, such as carpets or surfaces with foam backing�is not recommended�

• A sturdy and solid floor to support the washer with a total weight (water and load) of 200lbs�

• Do not operate your washer in temperatures below 32° F (0° C)� Some water can remain in the washer and can

cause damage in low temperatures�

Water Hoses (2) Cable Tie

Figure 2

Transport

Hole Plugs (4)

• The location must be large enough to allow the washer door to be fully opened� The door opens more than

90°, and is not reversible�

• Additional spacing should be considered for ease of installation and servicing�

• Minimum spacing of 1” (25 mm) on all sides of the washer is recommended to reduce noise transfer�

• Additional clearances might be required for wall, door, and floor moldings�

• Spacing for companion appliance should also be considered�

INSTALLATION

CAUTION: Packing materials may be dangerous to children�

Please dispose them properly and DO NOT let children play with any packing materials�

Before using this washing machine, transport bolts must be removed from the backside of this machine� Please take the following steps to remove the bolts:

1� Loosen all bolts and then remove them� 2� Insert the transport hole plugs into the holes� 3� Keep the transport bolts for future use� Make sure that the small foam triangle is removed with the bottom

foam piece� If not, carefully lay the unit down and remove it� When you unpack your washing machine, check if there is any

damage or missing pieces� If any items missing, please contact customer service�

LEVELING THE WASHER 1� When positioning the washing machine, make sure the

legs are screwed in close to the cabinet� If not, turn them

to their original positions by hand or with a wrench and

tighten the nuts with a wrench� 2� After positioning the washing machine, push on all four

corners at the top of washing machine� If the washing

machine has any wobble, or is not stable when being

pressed, adjust the leg to level the machine� 3� To level the unit, loosen the lock nut with a wrench and

turn the leg by hand until it tightly contacts with the floor�

Press the leg with one hand and tighten the locking nut

close to the cabinet with the other hand� 4� Repeat steps 2 and 3 as needed� 5� Use a bubble level to check front to back, side to side, and

corner to opposite corner to ensure the washing machine

is level� Repeat above steps if needed�

Figure 3

Figure 4

Figure 5

Figure 6

DRAIN SYSTEM

STANDPIPE DRAIN SYSTEM

- WALL OR FLOOR The standpipe drain requires a

minimum diameter standpipe of 2” (5 cm)� The minimum carry-away capacity can be no less than 17 gal� (64 L) per minute� The top of the standpipe must be at least 24” (60 cm) high and no higher than 39” (100 cm) from the bottom of the washer�

LAUNDRY TUB DRAIN SYSTEM

The laundry tub needs a minimum 20 gal� (76 L) capacity� The top of the laundry tub must be at least 60cm above the foor�

2” (5 cm)

Figure 9 Figure 10

min� 24” (61 cm) max� 39” (100 cm)

Figure 7 Figure 8

min� 24” (60 cm) max� 39” (100 cm)

FLOOR DRAIN SYSTEM

The floor drain system requires a siphon break that may be purchased separately� The siphon break must be a minimum of 28” ( 71 cm) from the bottom of the washer� Additional hoses might be needed�

min� 28” (71 cm)

INSTALL INLET PIPE

Connect the end of the water inlet hose with the 90° elbow to the back of the washing machine and turn clockwise to tighten� Note the position of the Hot and Cold water inlets�

Connect the other end of the water inlet hose to the appropriate Hot and Cold water tap� Tighten by turning clockwise, and turn on the water valve to check for leaks� If any leaks are found, verify all connections are tight and washers are present, and repeat the procedure�

Connector to water inlet is a 90° bend�

Hot

Figure 11

Cold

Figure 12

BEFORE USE

CHECK LIST AND PREPARATION BEFORE WASHING

Read all instructions carefully to avoid any damage or issues with the washing machine and to clothes� ALWAYS follow instructions on fabric care labels on clothing articles for proper care�

WARNING: DO NOT leave items to be washed in the washing machine for long periods of time� Items left in the

machine may get moldy and get spots� Clothes may also become discolored if they are not washed according to the stated washing temperature and instructions�

SELECTING DETERGENT

• Low foaming powdered detergent is recommended for use with the washing machine�

• Some detergents may not completely dissolve if there is too much detergent or if the water temperature is

too low�

• Bleach can damage clothes� Use bleach with caution and follow detergent and clothing article care

instructions� Washing method is based on weight of clothes, soil level, local water hardness as well as the recommendations

from the detergent manufacturers�

NOTE: DO NOT place or store laundry products, such as detergent, bleach, or liquid fabric softener, on top of

your washer/dryer combo unit� Wipe up any spills immediately� These products can damage the finish and controls� Keep all laundry products in a safe, dry space out of reach of children�

SEPARATE CLOTHES TO BE WASHED

Classify clothes to be washed into cottons, blended fibers, synthetic fibers, silks, wools, etc� Light and dark clothes should also be separated�

NOTE: New, colored fabrics should be washed separately�

• Accessories: Loose accessories on some clothes may become damaged and/or damage the washing machine�

Clothes that contain buttons or embroideries should be turned inside-out before being washed�

• Fasteners: Zippers must be closed and buttons or hooks must be firmly affixed� Any loose bands or ribbons

should be tied together before being washed�

• Water-proof materials: It is not recommended to wash water-proof fabrics as they may become damaged

and/or cause damage to the washing machine and other items being washed�

REMOVE ALL LOOSE OBJECTS FROM CLOTHES

Check all pockets/compartments of clothes to be washed and remove any loose items such as coins� Loose items may damage the washing machine�

BALANCING THE LOAD

Washing large, heavy garments, such as towels, jeans, jackets etc�, may cause an unbalanced load� It is suggested to add one or two more items to balance the load to allow smooth and complete draining�

OPERATING INSTURCTIONS

CONTROL PANEL (FOR MCSCWD27W5 ONLY)

Press 3 sec. to set My Cycle

Figure 13

e f

h i j d c b

l m n

a� On/Off: Press [On/Off] to turn the unit ON� Press the button again to turn the unit OFF�

NOTE: If the washer is programmed for a wash cycle and is not started within 10 minutes, the cycle will be

cancelled and the unit will automatically turn OFF� b� Start/Pause: Press [Start/Pause] to start a wash cycle� Press [Start/Pause] again to pause the cycle when

the washer is running� Press [Start/Pause] once more to resume� To add a garment after the wash cycle has

started, push this button for 3 seconds before the drum has filled with water� This can only be done in the

beginning of the cycle before the water reached the bottom of the door� Wait for the drum to stop and the

door to unlock, then add item(s)� Close door and press [Start/Pause] to continue washing� c� Wash Cycles

1� My Cycle: Select this option to save a commonly used washing program as a preset�

• To program, select the settings you wish to use, and then press and hold [Spin] for 3 seconds to save� 2� Quick Wash: Select this option to wash small loads of clothing that are not very dirty quickly� 3� Delicates: Select this option for delicate fabrics such as dress shirts, nylons, etc�

• Wash cycle operates at a lower temperature� 4� Wool: Only use this option to wash wool clothing articles labeled “Machine Washable”�

• Proper detergent and water temperature must be selected for wool textiles�

• Lower spin speed and less agitation 5� Baby Wear: For washing infant clothing 6� Sanitary: Uses hot water to allow enzymes in detergent to work more efficiently for hard to clean or

heavily soiled items�

7� Normal/Cotton: Select this option for regularly used cottons and fabrics�

• Extended wash cycle with stronger intensity

• Recommended fabrics: cotton, linens, bed sheets, t-shirts, towels, jeans, etc�

• Dry cycle can be added.

8� Perm Press: Moderate strength wash cycle� Used to reduce wrinkles in clothes from washing� 9� Heavy Duty: Select this option for washing heavy clothing�

• Dry cycle can be added.

10� Bulky/Large: Select this option for bulky/large items�

• Extended wash cycle 11� Sports Wear: Select this option for sportswear�

• Wash cycle cleans heavily soiled clothes� 12� Spin Only: Select this option to spin a load separately from a regular wash cycle�

• Soap water or rinse water must be drained before spinning� 13� Rinse & Spin: Select this option to rinse and spin a load separately from a regular wash cycle�

• This can be helpful in preventing fresh stains from setting in fabrics� 14� Tub Clean: Select this option to clean the wash tub� This program uses high temperatures to sterilize the

tub while removing built up detergent and residues� Add bleach for a better clean� This program should be used at least once a month with regular use� DO NOT add any clothes or wash items for this program�

d� Dry Cycles

NOTE: Maximum drying load size is smaller than wash load size� Be sure to note the drying load size when

using�

• Auto Dry: Select this option to have dry cycle automatically set based on the load� Auto Dry program

has a 12 minute spin cycle and 45 minute cool air cycle� It is recommended to dry in multiple, smaller loads to allow for better for performance�

• Timed Dry: Select this option to set dry cycle time manually� Timed Dry programs include a 12 minute

spin and 25 minute cool period� It is recommended to dry in multiple, smaller loads to allow for better for performance�

Time in Minutes Capacity

58 1�8 lbs� (0�8 kg) 88 2�2 lbs� (1�0 kg)

199 6�6 lbs� (3�0 kg)

NOTE: Important Notes for Dry Cycles

For Wash only, unit can be filled to the Max� Washing Capacity, however, load sizes less than the Max� Wash Capacity can improve performance and efficiency�

For Wash cycles plus Dry cycles or Dry only cycles, unit should not be filled over the Max� Dry Capacity to allow the dry function to work effectively� Load sizes less than the maximum capacity will improve the drying performance of the combo unit�

DO NOT cut off water supply or remove hose attachments during dry cycle� This is a ventless unit that releases moisture during dry cycles� The dryer is equipped with a door-locking safety feature to ensure safe temperatures and avoid burns and other safety hazards� The door will remain LOCKED during dry cycle until the unit reaches a safe temperature� After a safe temperature is reached, the door should open and function normally�

e� Time Save: Press [Time Save] to decrease the washing time�

• See Wash Cycle Parameters Table for programs that can use Time Save�

f� Delay: Press [Delay] to set a delay time for the wash to begin�

• The delay start light will flash to indicate the delay time� You can delay the start time of the cycle from

1 - 24 hours�

• Set Wash program, Press Delay to set the number of hours to delay wash cycle, then push Start/Pause�

• To cancel the delay time, press Delay button until time shows 0H�

g� Temp�: Press [Temp�] to set your desired washing temperature�

• Press button to set desired wash temp (Hot+, Hot, Warm, Eco, Cold)

h� Spin: Press [Spin] to increase spin speed�

• Washer drum spins at a speed up to 1300 RPM which reduces drying time and saves energy�

• Press the button until desired speed is lit (No Spin, Low, Med, High, Highest)�

• Some fabrics (i�e� delicates) require a slower spin speed�

• High spin speeds are not available on all cycles�

i� Soil: Press [Soil] to increase time for heavier soiled items�

• There are three (3) soil levels options�

• Each bar increases the base wash time by 15 minutes�

j� Dry Level: Press the Dry button continuously to choose the dry level: Extra Dry/Normal Dry/Gentle Dry� k� Child Lock: Press [Delay] and [Temp] at the same time for 3 seconds to Unlock/Lock the control panel�

• On/Off Button will still function�

l� Extra Rinse: Press the [Temp�] and [Spin] button at the same time to add an extra rinse to the selected cycle� m� My Cycle: After a wash cycle is modified, hold down [Spin] to save your settings�

• You can quickly choose this cycle for your next wash by turning the dial to My Cycle�

• Override saved settings by holding the [Spin] button down again after a different cycle and options are

selected�

n� Sound: Press the [Soil] button for 3 seconds to turn the sound on or off�

DISPLAY (FOR MCSCWD27W5 ONLY)

Figure 14

ePress 3 sec. to set My Cycl

d e f g

a� Cycle Indicator: Indicates stage of wash/dry cycle�

•

: Prewash • : Wash • : Rinse • : Spin

: Time Save • : Extra Rinse • : Dry b� Clock: Indicates time left until the end of wash/dry cycle� c� Feature Indicator: Indicates features that are active�

Sound: Indicates that sounds are on� When unlit, unit is muted�

• Door Lock: Machine is locked for duration of cycle�

•

Child Lock: Child lock is on�

• Add a Garment

•

d� Water Temperature: Indicates the selected temperature� e� Spin Speed: Indicates the selected spin speed� f� Soil Level Indicator: Indicates the selected soil level� g� Dry Level: Indicated the selected dry level�

Extra Dry • Normal Dry • Gentle Dry

•

NOTE: Maximum drying load size is smaller than wash load size�

CONTROL PANEL (FOR MCSFLW27W ONLY)

Press 3 sec. to set My Cycle

Figure 15

d e

g h i c b

k l

a� On/Off: Press [On/Off] to turn the unit ON� Press the button again to turn the unit OFF�

NOTE: If the washer is programmed for a wash cycle and is not started within 10 minutes, the cycle will be

cancelled and the unit will automatically turn OFF�

b� Start/Pause: Press [Start/Pause] to start a wash cycle� Press [Start/Pause] again to pause the cycle when

the washer is running� Press [Start/Pause] once more to resume� To add a garment after the wash cycle has started, push this button for 3 seconds before the drum has filled with water� This can only be done in the beginning of the cycle before the water reached the bottom of the door� Wait for the drum to stop and the door to unlock, then add item(s)� Close door and press [Start/Pause] to continue washing�

c� Wash Cycles

1� My Cycle: Select this option to save a commonly used washing program as a preset�

• To program, select the settings you wish to use, and then press and hold [Spin] for 3 seconds to save�

2� Quick Wash: Select this option to wash small loads of clothing that are not very dirty quickly� 3� Delicates: Select this option for delicate fabrics such as dress shirts, nylons, etc�

• Wash cycle operates at a lower temperature�

4� Wool: Only use this option to wash wool clothing articles labeled “Machine Washable”�

• Proper detergent and water temperature must be selected for wool textiles�

• Lower spin speed and less agitation 5� Baby Wear: For washing infant clothing 6� Sanitary: Uses hot water to allow enzymes in detergent to work more efficiently for hard to clean or

heavily soiled items� 7� Cold Wash: Only uses cold water� 8� Tub Clean: Select this option to clean the wash tub� This program uses high temperatures to sterilize the tub

while removing built up detergent and residues� Add bleach for a better clean� This program should be used at least once a month with regular use� DO NOT add any clothes or wash items for this program�

9� Normal/Cotton: Select this option for regularly used cottons and fabrics�

• Extended wash cycle with stronger intensity

• Recommended fabrics: cotton, linens, bed sheets, t-shirts, towels, jeans, etc� 10� Perm Press: Moderate strength wash cycle� Used to reduce wrinkles in clothes from washing� 11� Heavy Duty: Select this option for washing heavy clothing� 12� Bulky/Large: Select this option for bulky/large items�

• Extended wash cycle 13� Sports Wear: Select this option for sportswear�

• Wash cycle cleans heavily soiled clothes� 14� Spin Only: Select this option to spin a load separately from a regular wash cycle�

• Soap water or rinse water must be drained before spinning� 15� Drain Only: Used to drain any water in the unit� 16� Rinse & Spin: Select this option to rinse and spin a load separately from a regular wash cycle�

• This can be helpful in preventing fresh stains from setting in fabrics�

d� Time Save: Press [Time Save] to decrease the washing time�

• See Wash Cycle Parameters Table for programs that can use Time Save�

e� Delay: Press [Delay] to set a delay time for the wash to begin�

• The delay start light will flash to indicate the delay time� You can delay the start time of the cycle from

1 - 24 hours�

• Set Wash program, Press Delay to set the number of hours to delay wash cycle, then push Start/Pause�

• To cancel the delay time, press Delay button until time shows 0H�

f� Temp�: Press [Temp�] to set your desired washing temperature�

• Press button to set desired wash temp (Hot+, Hot, Warm, Eco, Cold)

g� Spin: Press [Spin] to increase spin speed�

• Washer drum spins at a speed up to 1300 RPM which reduces drying time and saves energy�

• Press the button until desired speed is lit (No Spin, Low, Med, High, Highest)�

• Some fabrics (i�e� delicates) require a slower spin speed�

• High spin speeds are not available on all cycles�

h� Soil: Press [Soil] to increase time for heavier soiled items�

• There are three (3) soil levels options�

• Each bar increases the base wash time by 15 minutes�

i� Function: Use to select functions during the wash cycle j� Child Lock: Press [Delay] and [Temp] at the same time for 3 seconds to Unlock/Lock the control panel�

• On/Off Button will still function�

k� My Cycle: After a wash cycle is modified, hold down [Spin] to save your settings�

• You can quickly choose this cycle for your next wash by turning the dial to My Cycle�

• Override saved settings by holding the [Spin] button down again after a different cycle and options are

selected�

l� Sound: Press the [Soil] button for 3sec� to turn the sound on or off�

DISPLAY (FOR MCSFLW27W ONLY)

Press 3 sec. to set My Cycle

Figure 16

d e f g

a� Cycle Indicator: Indicates stage of wash/dry cycle�

•

: Prewash • : Wash • : Rinse • : Spin

: Time Save b� Clock: Indicates time left until the end of wash/dry cycle� c� Feature Indicator: Indicates features that are active�

Sound: Indicates that sounds are on� When unlit, unit is muted�

• Door Lock: Machine is locked for duration of cycle�

•

Child Lock: Child lock is on�

• Add a Garment

•

d� Water Temperature: Indicates the selected temperature� e� Spin Speed: Indicates the selected spin speed� f� Soil Level Indicator: Indicates the selected soil level� g� Additional Functions: Indicates additional functions selected�

Extra Rinse •

•

Easy Iron •

Prewash

+ 36 hidden pages
