Lynx LEH61 User Manual

MAKE THE MOST OF YOUR
Lynx Electric Infrared Heater
LEH39/61 CARE & USE/INSTALLATION
LEH CARE & USE/INSTALLATION
1
|
TABLE OF CONTENTS
LYNX ELECTRIC HEATER MODELS
Installation Instructions 5
This use & care manual covers the Lynx heater models listed below. Some features and options will vary based upon the model that you purchased.
39" 61"
LEH39 LEH61
2
LEH CARE & USE/INSTALLATION
|
CLEARANCE FROM COMBUSTIBLES
SAVE THIS MANUAL FOR FUTURE REFERENCE
WARNINGS- Read all instructions before using heater:
Unit may be a source of possible shock. NEVER attempt to service heater without disconnecting its power source. Source of possible ignition.
CAUTION-High Temperature, risk of fire, keep electrical cords, drapery, furnishings and other combustibles at least 3' (0.9m) from the front of heater and away from sides and rear.
MOUNTING HEIGHT/CLEARANCES
CLEARANCE FROM COMBUSTIBLES:
MIN. 6" (15.2cm)
CLEARANCE
BEHIND HEATER
MIN. 18" (45.7cm) FROM SIDES AND ENDS OF HEATER
MIN. 36" (91.4cm)
IN FRONT OF HEATER
• For Wall-Mounting, do not install heater closer than 18" (45.7cm) from adjacent walls and 6" (15.2cm) from ceiling and do not install less than 6' (1.8m) if the heater is labeled as UL Listed and 8' (2.4m) if the heater is labeled as UL/CUL Listed from floor, while heater is set at a downward angle of 30 to 60 degrees.
• For Ceiling-Mounting, do not install heater closer than 18" (45.7cm) from adjacent walls and 6" (15.2cm) from ceiling and do not install less than 6' (1.8m) if the heater is labeled as UL Listed and 8' (2.4m) if the heater is labeled as UL/CUL Listed from floor, while heater is at a maximum 30 degrees.
• Adjacent Heaters to be installed no less than 3' (0.9m) apart.
• Do NOT operate within 25' (7.6m) of flammable/explosive material.
• Never block heater.
• Heaters greater than 240 Volts are for “Commercial Use Only. Risk of fire. Do not use as a residential or household heater.”
• A means for disconnection of the appliance must be incorporated in accordance with the local wiring codes.
• Do not use if the heating element is damaged or cracked.
“IMPORTANT INSTRUCTIONS” “SAVE THESE INSTRUCTIONS”
LEH CARE & USE/INSTALLATION
3
|
WARNINGS
!
WARNING
• Children should never be left alone or unattended in an area where this appliance is located. Install your heater well away from areas where children play. Do not store items that may interest children in or around the area of your heater.
• Never touch the heater face when hot. When in use, portions of the heater are hot enough to cause severe burns.
• Always maintain the required clearances from combustibles as detailed. The heater is designed for indoor or outdoor use.
• Electric heaters are not to be installed in or on recreational vehicles, portable trailers, boats or any other moving installation.
• Keep any electrical supply cord away from any heated surfaces.
• Do not repair or replace any part of the heater unless specifically recommended in this manual. Other service should be performed by a qualified technician.
• This appliance must be installed by a professional installer or technician.
• Product installation must meet local electric codes or, in the absence of local codes, the latest edition of the National Electrical Code ANSI/NFPA No. 70 or the Canadian Electrical Code CSA C22.1.
• Unit may be a source of possible shock. NEVER attempt to service heater without disconnecting its power source. Source of possible ignition.
• High Temperature, risk of fire, keep electrical cords, drapery, furnishings and other combustibles at least 3' (0.9m) from the front of heater and away from sides and rear.
THIS MANUAL MUST REMAIN WITH THE PRODUCT OWNER FOR FUTURE REFERENCE.
WARNING
READ THIS MANUAL CAREFULLY and completely before using your heater to reduce the risk of:
1. Fire
2. Burn hazard, personal injury or property damage
3. Unapproved installation or servicing.
Improper installation, adjustment, alteration, service or maintenance can cause property damage, injury or death. Read this manual thoroughly before installation, use, or servicing of this product.
WARNING
If not installed, operated and maintained in accordance with the manufacturer’s instructions, this product can expose you to chemicals including nickel, which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
4
LEH CARE & USE/INSTALLATION
|
INSTALLATION INSTRUCTIONS
WIRING INSTRUCTIONS
This heater must be permanently installed and hard wired by a licensed electrician in accordance with local electrical codes. Assembly procedure must be performed with no electrical power to unit.
Step 1: Check UL/CUL/CE label on heater for proper voltage.
Step 2: Follow supplied wiring instructions. (See wiring instructions below)
Step 3: Heater must be mounted with reflector angled down.
Step 4: All electrical connections must be in compliance with the National Electric Code (NEC) and local codes
for outdoor wiring.
Step 5: Use only wiring components UL/CUL/CE listed for outdoor use with IPX4 minimum rating.
WIRING INSTRUCTIONS
The heater is drilled and threaded for standard 1/2" conduit fittings. The installing electrician will need to provide the appropriate rigid metallic, flexible or liquid tight conduit for the installation location.
• Observe local electrical code regulations.
• Remove cover plate from junction box.
• Attach conduit.
• Use only copper wire suitable for 90°C.
• Replace cover plate.
Connect power with flexible conduit or appropriate cord to allow heater to be swiveled.
The Junction Box inlet hole is sized for a standard ½” weather tight conduit fitting and has a locknut located on the inside of the box for fastening.
Green ground
wire screw
Duplex Stack Switch is Included with the heater.
Junction Box on top of the heater has a gasket side access cover.
LEH CARE & USE/INSTALLATION
5
|
