MAKE THE MOST OF YOUR

CARE & USE/INSTALLATION

WARNINGS

WARNING

• Never use dented, rusty or damaged propane cylinders. Never store additional or empty propane cylinders in the grill cabinet or in the vicinity of this or any other appliance. Do not store propane cylinders indoors or on their sides.

• Children should never be left alone or unattended in an area where a grill is located. Place your grill well away from areas where children play. Do not store items that may interest children in or around the grill, in the cart, or in the masonry enclosure.

• Never move the grill when hot. When in use, portions of the grill are hot enough to cause severe burns.

• Always maintain the required clearances from combustibles as detailed. The grill is designed for outdoor use only. Never use in a garage, building, shed, breezeway, or other enclosed area. Do not use this grill under any unprotected overhead combustible construction.

• Gas grills are not designed or certiﬁed for and are not to be installed in or on recreational vehicles, portable trailers, boats or any other moving installation.

• Always have an ABC Fire Extinguisher accessible — never attempt to extinguish a grease ﬁre with water or other liquids.

• Storing your grill: Store your grill in a well-ventilated area. If stored indoors, detach and leave L.P. cylinder outdoors in a well-ventilated area away from heat and away from where children may tamper with it.

• Keep any electrical supply cord and the fuel supply hose away from any heated surfaces. Electrical cords should be placed away from walkways to avoid tripping hazard.

• Do not repair or replace any part of the grill unless speciﬁcally recommended in this manual. Other service should be performed by a qualiﬁed technician.

• If the grill is installed by a professional installer or technician, be sure that he/she shows you where your gas supply shut-off is located. All gas lines must have a shut-off that is readily and easily accessible. If you smell gas, check for gas leaks immediately. Check only with a soap and water solution. (See INDEX: “Leak Testing” for further details.) Never check for gas leaks with an open ﬂame.

• Inspect the L.P. gas supply hose prior to each use of the grill. If there is evidence of excessive abrasion or wear, or the hose is cut, it must be replaced before using the grill.

• Never remove the grounding prong from the plug or use this product with an ungrounded, 2-prong adapter.

THIS MANUAL MUST REMAIN WITH THE PRODUCT OWNER FOR FUTURE REFERENCE.

This product complies with ANSI standard Z21.58/CSA

1.6 latest edition and has been tested and approved by Intertek.

To obtain replacement parts or service contact:

Lynx Professional Grills 7300 Flores Street Downey, CA 90242

888-289-5969

CARE & USE/INSTALLATION

WARNINGS

WARNING

READ THIS MANUAL CAREFULLY and completely before using your grill to reduce the risk of:

1. Fire

2. Burn hazard, personal injury or property damage

3. Ruined steaks or other unpleasant cooking experiences

4. Unapproved installation or servicing.

THIS PRODUCT IS DESIGNED FOR OUTDOOR USE ONLY. Improper installation, adjustment, alteration, service or maintenance can cause property damage, injury or death.

Read this manual thoroughly before installation, use, or servicing of this product.

DANGER

IF YOU SMELL GAS:

1. Shut off all gas supply lines to the grill.

2. Extinguish any open ﬂames.

3. Carefully open the lid. Remember, it may be extremely hot!

4. If odor continues, keep everyone away from the grill and immediately call your gas supplier or your ﬁre department.

S’IL Y A UNE ODEUR DE GAZ:

1. Coupez l’admission de gaz de l’appariel.

2. Éteindre toute ﬂamme nue.

3. Ouvrir le couvercle.

4. Si l’odeur persiste, éloignez-vous de

DANGER

l’appareil et appelez immédiatement le fournisseur de gaz ou le service d’incendie.

WARNING

1. Always maintain the required clearances from combustible construction as detailed. The grill is designed for outdoor use only. Never use in a garage, building, shed, breezeway or other enclosed area. This grill shall not be used under any unprotected overhead combustible construction.

2. Gas grills are not design certiﬁed for and are not to be installed in or on recreational vehicles, portable trailers, boats or any other moving installation.

3. Keep any electrical supply cord and the fuel supply hose away from any heated surfaces. Electrical cords should be placed away from walkways to avoid creating a tripping hazard.

4. Do not repair or replace any part of the grill unless speciﬁcally recommended in this manual. Other service should be performed by a qualiﬁed technician.

5. All gas lines must have a shut-off that is readily and easily accessible. Be sure the owner knows where the shut-off is located. If you smell gas, check for gas leaks immediately. Check only with a soap and water solution. Never check for gas leaks with an open ﬂame. (See INDEX: “Leak Testing” for further details.)

WARNING

1. The outdoor cooking gas appliance and its individual shutoff valve must be disconnected from the gas supply piping system during any pressure testing of that system at test pressures in excess of 0.5 psi (3.5 kPa).

WARNING

1. DO NOT store or use gasoline or other ﬂammable vapors and liquids in the vicinity of this or any other appliance.

2. An LP cylinder not connected for use shall not be stored in the vicinity of this or any other appliance.

1. Ne pas entreposer ni utiliser de l’essence ni

2. Une bouteille de propane qui n’est pas rac-

AVERTISSMENT

d’autres vapeurs ou liquides inﬂammables dans le voisinage de l’appareil, ni de tout autre appareil.

cordée en vue de son utilisation, ne doit pas être entreposée dans le voisinage de cet appareil ou de tout autre appareil.

WARNING! CALIFORNIA PROPOSITION 65

1. The burning of gas cooking fuel generates some by-products which are on the list of substances which are known by the State of California to cause cancer or reproductive harm.

2. California law requires businesses to warn customers of potential exposure to such substances. To minimize exposure to the substances, always operate this unit according to the use and care instructions found in this manual. Be certain to provide adequate ventilation when cooking.

2. The outdoor cooking gas appliance must be isolated from the gas supply piping system by closing its individual manual shutoff valve during any pressure testing of the gas supply piping system at test pressures equal to or less than 1/2 psi (3.5 kPa).

STATE OF MASSACHUSETTS

1. Massachusetts requires all gas be installed using a plumber or gas ﬁtter carrying the appropriate Massachusetts license.

2. All permanently-installed natural gas or propane installations require a “T” handle type manual gas valve be installed in the gas supply line to this appliance.

3. This does not apply to portable propane installations using a 20 pound cylinder.

4 5

CARE & USE/INSTALLATION

TABLE OF CONTENTS

LYNX GRILL MODELS

USE & CARE GUIDELINES

USE & CARE GUIDELINES 7

Lynx Grill Models 7

HOW TO LIGHT YOUR GRILL 7

HOW TO LIGHT YOUR ROTISSERIE BURNER 7

BEFORE YOU START 8

If Shipment Arrives Damaged 8 Important Notes 8

Clearance to Combustibles 9

SPECIFICATIONS & INSTALLATION 10

UNPACKING & ASSEMBLY 12

GAS CONNECTIONS 14

Natural Gas 14 LP Gas 15 Gas Conversion Kits 16

ELECTRICAL CONNECTIONS 18

FINAL CHECKS 19

Leak Testing 19

CHECKLIST BEFORE EACH USE 21

A MESSAGE TO OUR CUSTOMERS 21

IMPORTANT SAFETY PRECAUTIONS 22

GRILLING IN WINDY CONDITIONS 23

USING YOUR LYNX GRILL 24

Pre-Grill Checklist 24 Lighting your Grill 25 Basic Grilling 27 Using the Trident ™ Burner 28 Using the Rotisserie Burner 29 Using the Smoker Box 30

CLEANING YOUR LYNX GRILL (Required Maintenance) 31

TROUBLESHOOTING YOUR LYNX GRILL 33

Potential Problems 34 Contacting Lynx Customer Care 37 The Lynx Story 37

LYNX LIMITED WARRANTY 38

LYNX COMMON AREA LIMITED WARRANTY 39

WIRING SCHEMATICS 40-42

L27 & L30 Rotisserie Grill 40 L36 & L42 Rotisserie Grill 41 L54 Rotisserie Grill 42

LYNX PROFESSIONAL GRILLS EXPLODED PARTS VIEW 43

LYNX PROFESSIONAL GRILLS PARTS LIST 44

MODEL-SPECIFIC BTU OUTPUTS & MAX. RUNS FOR APPLIANCES 45

INSULATED JACKET INSTALLATION 46

INDEX 47

This use & care manual covers the Lynx grill models listed below. Some features and options will vary based upon the model that you purchased.

BUILT-IN FREESTANDING

L27R-3 L27TR L27TRF

L30R-3 L30TR L30TRF

L36R-3 L36TR L36TRF

L42R-3 L42TR L42TRF

L54TR L54TRF

HOW TO LIGHT YOUR GRILL

1. Before each use, refer to the checklist on page 21.

2. Make sure all burner control knobs are in the “OFF” position.

3. Push and hold the control knob in for 5 – 7 seconds, allowing the igniter to heat up.

4. Turn the knob to the “LITE” position.

5. After ignition set the knob to the desired setting.

HOW TO LIGHT YOUR ROTISSERIE BURNER

Note: The rotisserie burner features a thermocouple sensor with a safety valve that automatically shuts off the ﬂow of gas if the burner goes out for any reason.

1. Before each use, complete the checklist below.

2. Make sure all burner control knobs are in the “OFF” position.

3. Push and hold the control knob for 5 – 7 seconds.

4. Turn the knob to the “LITE” position and continue to hold the knob in for an additional 30 – 60 seconds to allow the thermocouple to heat up and keep the safety valve open.

6 7

CARE & USE/INSTALLATION

BEFORE YOU START

IMPORTANT NOTES

WHERE’S THE WIND?

When selecting a suitable location, consider important factors such as exposure to the wind and foot-trafﬁc patterns.

If you have a freestanding grill, position it so the prevailing wind blows into the front control panel (at your back when grilling), supporting the proper front-to-rear airﬂow.

Built-in grills located in areas with prevailing winds should be protected by a wind barrier.

Winds hitting the back of the grill directly may cause

problems, as well as

wind blowing along

the hood gap.

HOW LONG IS YOUR RUN?

Keep all gas supply lines as short as possible because gas lines lose pressure over distance and with each elbow and tee that is added. This drop in pressure affects grill performance. (See INDEX: “Gas Supply Line Runs” for further details.)

ARE YOU “ON-THE-LEVEL”?

Proper leveling during installation is critical. A grill that is out of level will cause erratic burner combustion and inefﬁcient, uneven heating. A carpenter’s spirit level should be used to level the grill both front-to-back and side-to-side.

If the ﬂoor is uneven or has a decided slope, re-leveling may be required each time you move a freestanding unit.

BEFORE YOU START ...continued

BUILT-IN INSTALLATIONS

A minimum of 6” of clearance is needed on the left side of the grill above the counter top for the rotisserie motor and

WARNING

• Never install this product into a combustible enclosure without an insulated jacket. Doing so could result in ﬁre, property damage and personal injury.

• Never locate the grill under a roof or overhang, in a building, garage, shed or other such enclosed area.

• Never locate the grill under unprotected combustible construction.

• Installation must conform with local codes or, in the absence of local codes, with either the National Fuel Gas Code, ANSI Z223.1/NFPA 54, Natural Gas and propane Installation Code, CSA B149.1, or Propane Storage and Handling Code, B149.2, in Canada.

IF SHIPMENT ARRIVES DAMAGED

VISIBLE LOSS OR DAMAGE

CONCEALED LOSS OR DAMAGE

The Lynx Built-In Grill is designed for easy installation into masonry enclosures.

NOTE: Lynx built-in grills are intended either for installation in a built-in enclosure constructed of non-combustible materials or for an installation in a built in enclosure constructed of combustible material when installed with a Lynx insulating jacket (LIJ).

For non-combustible applications, the grill drops into the opening shown in the cutout detail drawing (See INDEX: “Gas Requirements”) and hangs from its counter-top trim. A deck is not required to support it from the bottom.

When using the insulated jacket in a combustible enclosure, the jacket must be supported from the bottom by a ledge on each side or a full deck beneath the jacket.

spit rod.

If the grill is to be placed into a combustible enclosure, an approved insulated jacket is necessary and is available only from your Lynx dealer. Lynx insulated jackets have been designed and tested speciﬁcally for your Grill.

REAR HOOD CLEARANCE

A 3 inch clearance is required behind the grill to allow the front hood to open.

The grill exhausts combustion products and cooking greases to the back. Never locate the grill where this exhaust will be difﬁcult to clean.

Overhead Construction

(See INDEX: “Gas Requirements”) Pay special attention to

Be certain any visible damage to the carton is noted on freight bill or express receipt and signed by the person making delivery.

FILE CLAIM FOR DAMAGES IMMEDIATELY, regardless of extent of damage.

Be sure wind doesn’t blow into the hood gap.

8 9

CARE & USE/INSTALLATION

If damage is unnoticed until the grill is unpacked, notify the transportation company or carrier immediately and ﬁle a “concealed damage” claim with them. This should be done within (5) days of the date delivery is made to you. Be sure to hold on to the container for inspection. We cannot assume responsibility for damage or loss incurred in transit. (See INDEX: “Obtaining Service from Lynx” for further details.)

the provisions shown for gas line hook-up.

The enclosure should have ventilation holes to prevent gas build-up in the event of a leak. The deck ledges and counter should be ﬂat and level. (refer to ANSI Z21.58 Standard for Outdoor Cooking Gas Appliances, Section 1.7 Enclosures For Self Contained LP-Gas Supply Systems)

This grill requires that a 120 volt, 60 hertz, 15 amp GFI certiﬁed outlet be installed by a qualiﬁed electrician.

Never locate the transformer or grill gas line behind the grill inside the insulated jacket.

CLEARANCE TO COMBUSTIBLE MATERIALS

Minimum clearance from the sides and back of the grill to adjacent combustible construction below the counter top surface is 12” from the sides and 6 1/4” from the back of the hood.

Dégagement minimal entre les parois latérales et l’arrière de l’appariel et la construction combustible au-dessous du panneau supérieur de l’appareil (30 cm à partir des parois latérales et 15.9 cm à partir de

l’arrière de la hotte).

Minimum clearance from sides and back of grill to adjacent combustible construction extending above the counter top surface is 12” from the sides and 6 1/4” from the back.

Dégagement horizontal minimal entre les parois latérales et l’arrière de l’appariel et la construction verticale combustible au-dessus de l’appareil (30 cm à partir des parois latérales et 15.9 cm à partir de

l’arrière).

Do not use this appliance under unprotected overhead combustible surfaces.

N’utilisez pas cet appareil sous des surfaces inﬂammables non protégées.

Combustible overhead construction requires a vent hood

Non-combustible overhead construction a vent hood is highly recommended

Vent Hood

3” overhang on left and right side of grill

R e

6 1/4” Clearance from the

grill back to above

counter combustibles

36” Minimum

6’ Minimum to

non-combustible

l l

3” Minimum hood clearance

6 1/4” Minimum clearance to combustibles

12” clearance to combustibles from

surface level right/left/below

OVERHEAD PROTECTION AND EXHAUST REMOVAL

If installed under any combustible contruction the cooking area over the grill must be covered with an exhaust hood. The hood must provide 3-6 inches of overhang on all exposed sides. The exhaust hood shall provide no less than 1,200 CFM for proper exhaust ventilation. The hood must be approved for outdoor installation and provided with a dedicated GFCI protected branch circuit.

CARE & USE/INSTALLATION

The guides, measurements and dimensions detailed below are designed to assist you with planning your outdoor kitchen.

SPECIFICATIONS & INSTALLATION

LM24REF/LM24BF/LM24DWR

SPECIFICATIONS & INSTALLATION

L15ICE/LMWINE/LM15REF

1/2

” min. for doors/drawers

* Cocktail Pro should have an open bottom for plumbing and drain access.

1/2” NPT gas connection

CLEARANCE

1/2

”

34”

15”

25”

ICE MACHINE

3”

** 1” square hole must be located at rear of grill cutout. 120V GFI outlet must be located within 6’ of the 1” hole.

2”Ø or 2” square holes for manifold connection

(rear or bottom access)

12” min.

Grill**

Cocktail Pro*

Warming Drawer/ Convenience Center

Utility Drawer

Side Burner

Drop In Cooler (LDC18)

Access Doors

1/4

”

1/2

”

1/4

” min.

2”

3” min.

Trash Center

3/8

”

min.

1/2

”

1/4

”

1/4

”

1/4

”

1/4

”

Trash Chute (L18TS)

13 ''

Single Storage Drawer

3”

min.

Towel Dispenser (LTWL)

min.

max.

OUTDOOR REFRIGERATORS

NOTE: Due to continuing product innovation, speciﬁcations are subject to change without notice. IMPORTANT: Please reference the Care & Use / Installation manual for details on gas plumbing requirements, electrical speciﬁcations and the

proper installation of your Lynx outdoor kitchen equipment. This manual can be downloaded from the Lynx website at www.lynxgrills.com

GRILLS

MODEL A B C

L27 26.00 10.88 22.00 L30 29.00 10.88 24.50 L36 35.00 10.13 22.00 L42 41.00 10.88 24.50 L54 53.00 10.88 24.50

WITH INSULATED JACKET INSTALLED

MODEL A B C

LIJ27 33.00 11.63 24.00 LIJ30 36.00 11.63 26.50 LIJ36 42.00 11.63 24.00 LIJ42 48.00 11.63 26.50 LIJ54 60.00 11.63 26.50

OUTDOOR ICE AND REFRIGERATION

MODEL A B C D

LM15REFL/R 15.00 34.00-35.00 26.00 33.75-34.75 LM24REFL/R 24.00 34.00-35.00 26.00 33.75-34.75 LM24REFCL/CR 24.00 34.00-35.00 26.00 33.75-34.75 LM24BFL/R 24.00 34.00-35.00 26.00 33.75-34.75 LM24DWR 24.25 34.00-35.00 26.00 33.75-34.75 LMWINE 15.00 34.00-35.00 26.00 33.75-34.75 LM15ICE 15.00 34.00-35.00 24.00 33.75-34.75

COMPLEMENTARY PRODUCTS

ACCESS DOORS

MODEL

LDR18L/R-4 13.38 19.00 LDR24L/R-4 19.25 19.00 LDR30T-4 25.13 19.00 LDR36T-4 31.50 19.00 LDR42T-4 37.50 19.00

SIDE BURNERS

MODEL

LSB1-3 12.13 10.63 12.50 LSB2-2 12.13 10.63 24.50 LSB2PC-1 24.25 10.63 24.50 LPB 19.00 10.63 22.00

UTILITY DRAWERS

MODEL A B C

LDW16-4 12.25 19.00 24.50 LDW19-4 15.25 19.00 24.50 LMD-4 21.75 5.63 23.38 LTWL 14.63 7.25 7.00

WARMING DRAWERS

MODEL A B C

L30WD-1 28.50 10.00 20.50 L42CC-1 40.25 19.38 24.75

COCKTAIL PRO/SINK

MODEL A B C

LCS30 29.00 10.50 22.00 LSK18 17.00 10.50 22.00 LSK24 23.00 10.50 22.00 LSK30 29.00 10.50 22.00

10 11

CARE & USE/INSTALLATION

A B

A B C

STORAGE SYSTEMS

MODEL A B C

LSA30-4 25.44 19.00 24.50 LSA36-4 31.44 19.00 24.50 LSA42-4 37.44 19.00 24.50 LPA36-4 31.50 19.00 25.00

TRASH CENTERS

MODEL A B C

L20TR-4 16.13 24.00 24.50 LTA30-4 25.44 19.00 24.50

PIZZA OVEN

MODEL A B C

LPZA 29.00 4.00 24.50

SMOKER

MODEL A B C

LSMK 29.00 4.00 24.50

Only required if island counter top overhangs the face of the island

COUNTER TOP NOTCH DETAIL

5”

4.5”

LCS30

UNCONVENTIONAL ISLAND INSTALLS

If building an island that does not conform to the standard properties listed in the following pages, please contact Lynx Grills at 888-259-5969 to verify all safety requirements regarding installation have been met.

3”

CARE & USE/INSTALLATION

The grill arrives nearly ready to use and requires only minor

UNPACKING & ASSEMBLY

UNPACKING & ASSEMBLY ...continued

assembly.

By carefully following the uncrating and unpacking steps, you will improve the customer’s ﬁrst Lynx experience.

Shipping weight on smaller units is app. 300 pounds and larger units may weigh over 500 pounds.

WARNING: EXCESSIVE WEIGHT HAZARD!

imperfections in the surface, or wood slatted decks be cautious and move slowly or use a carpet dolly. Failure to do so may damage the structure of the cart which will not be covered under warranty.

INTERIOR PACKING

Lynx uses sturdy tie-down cables and straps to ensure your grill arrives at your home in the same condition that it left our factory. BE SURE YOU HAVE REMOVED ALL TIE DOWNS BEFORE USING YOUR GRILL.

Oriﬁce all the way

into the venturi

Use two or more people to move or install this unit. Failure to follow this instruction can result in back or other personal injuries.

CRATE & CARTON

• IMPORTANT! Do not remove staples around the top of the carton. These staples hold a wooden pallet in place inside the carton that protects the unit from damage. Removing these staples may cause the pallet to fall on the top of grill.

How to Remove the Carton

• Cut the main strap holding the grill to the pallet.

• Remove the staples at the bottom of the carton.

• Lift off the carton.

• With assistance, remove the grill from the pallet and place into desired location.

The wheels sit down in the gaps of the shipping crate so

Grill will not slide directly off pallet.

• Remove the white accessory box and wood packing, the grill racks, and remove any loose items from the ﬁrebox.

Heat Shield Removed, Oriﬁce/Venturi Position

Inside View, Oriﬁce all the way into venturi

Tie Down

Burner sitting ﬂat

Remove Pink Foam

• Carefully cut the able ties securing the warming rack and

that the grill can sit safely and solidly on the crate during shipping. The grill cannot be slid directly off of the pallet.

One way to safely move the grill off of the pallet is by lifting one end of the grill high enough to place a ramp under the wheel and then lift the other end while rolling the grill off of the pallet.

When pushing, lifting, or pulling a freestanding Lynx Grill across gravel, grass, pavers, brick, stone,

12 13

CARE & USE/INSTALLATION

rotisserie spit.

• Cut the strapping that secures the briquette trays and carefully lift them out, front ﬁrst.

Make sure you remember to remove the strapping on the burners.

• On Trident ™ burner models, cut and remove ties from the burner partition on the left side of the Trident ™ burner.

• Ensure that all burners are properly seated on the burner valve oriﬁce and sitting level with the legs in the frame slots and no side-to-side movement.

Move the rear caps towards the back and pull the front caps forward

CARE & USE/INSTALLATION

NEVER CONNECT A GAS LINE DIRECTLY TO THE GRILL. A PRESSURE REGULATOR MUST BE INSTALLED ON ALL GAS EQUIPMENT. ALL LOCAL CODES REQUIRE IT AND LYNX SUPPLIES THE CORRECT REGULATOR WITH YOUR GRILL. REMOVING OR FAILING TO INSTALL THE PRESSURE REGULATOR CAN RESULT IN FIRE AND SERIOUS PERSONAL INJURY AND WILL VOID THE WARRANTY.

GAS CONNECTIONS

Keep last two threads clean

For freestanding units using natural gas, Lynx recommends using a mobile ﬂex gas line.

This is available at your local hardware store or from your dealer.

LP GAS

Grills set up for LP gas come equipped with an LP hose/ regulator assembly for connection to a standard 20 lb. LP cylinder. (Type 1). All ﬁttings necessary to attach the assem- bly to the grill are included.

Permanently plumbed LP connections, such as those in line with a bulk cylinder, require a 4/11 regulator. (Lynx P/N 30781)

When using the 4/11 regulator you must ensure that it is set for the proper fuel type. This is done by removing the regulator cap and gasket and looking at the bottom of the plunger to see what fuel type is visible. This is the regulator fuel setting. NAT is for natural gas and LP is for propane gas. The LP setting can be further identiﬁed by the large diameter disk on the bottom of the plunger. To change from one gas to the other simply push the plunger to the side to snap it out of the cap, turn the plunger so it reads the desired gas type on the bottom, and push the plunger until it snaps back into place in the cap then replace the cap into the regulator.

Never connect an unregulated gas line to the grill.

LP Cylinder Requirements

The LP cylinder must be constructed and marked in accordance with the speciﬁcations for LP gas cylinders of the U.S. Department of Transportation (DOT) and designed for use with a Type 1 system only.

Cylinders of free standing grills must be secured using the provided cylinder retention system to avoid accidental movement.

When exchanging your cylinder for a reﬁll, exchange only for a Type 1 20lb cylinder with an over-ﬁll protection device.

Never use a cylinder with a damaged valve.

A dented or rusty LP cylinder may be hazardous and should be avoided. If in doubt, have it checked by your LP supplier.

Always check for leaks after every LP cylinder change. (See INDEX: “Leak Test” for further details.)

Always shut off the LP-gas supply at the cylinder when the grill is not in use.

Cylinders must be stored outdoors in a well-ventilated area out of the reach of children. If your grill is stored indoors, the LP cylinder must be stored outside.

LP Connections

Make sure the LP cylinder valve is fully closed. It is possible for the valve to be open without releasing gas but, as soon as you start connecting the regulator, gas will leak from the connection.

GAS CONNECTIONS ...continued

The grill is factory set to use either propane (LP) or natural gas (NAT). It is critical that the gas you use matches that which the grill was set up for. You can verify that by checking the rating plate.

The Rating plate lists serial numbers, model numbers and gas type. This one is underneath the drip tray.

The rating plate is located in one or more of the following places:

• Attached to the underside of the drip tray

• On the heat shield behind the front panel

Ensure that the gas supplied meets with the minimum pressure requirements. Do not operate the grill on any gas other than that for which the grill has been set.

Fuel WC Max Inlet WC Min Under

Nat Gas 10 in 4 in LP 14 in 11 in

Water Column Requirements

Both the regulator and the manifold oriﬁces have been tuned for the type of gas speciﬁed on the rating plate.

Converting to a different type of gas requires a conversion kit, available from Lynx or from your dealer and must be installed by a qualiﬁed technician or certiﬁed plumber.

All installation and all installation parts must conform to local codes with the National Electrical Code, ANSI Z223.1/ NFPA 70 latest edition and the National Fuel Gas Code, ANSI Z223.1/NFPA 54 in the U.S. and CGA-B149.1/.2 in Canada.

14 15

CARE & USE/INSTALLATION

WARNING

Full Load

Canadian installations must conform to CGA-B149.1/.2 natural gas/propane installation code. (Canada)

NATURAL GAS

Lynx recommends that only qualiﬁed professionals perform the required plumbing on this product.

To ensure satisfactory performance, the gas supply line must be sized to accommodate the total BTU requirements of all the gas-ﬁred equipment that will be connected to that line.

In no case should an inlet pipe less than 3/4” inside diameter or 1” outside diameter ever be used to connect this product.

• Calculate the total BTU output of all equipment and refer to “INDEX: Gas Supply Line Runs” for allowable run distances for ¾ inch pipe. Failure to meet these minimum requirements may reduce performance of the grill and any other appliances running on that supply line.

• Always keep supply line runs as short as possible. (See INDEX: “BTU Output” for speciﬁc model outputs)

• A gas shut-off valve must be installed in an easily accessible location by a qualiﬁed plumber.

• Keep threading compound off of the ﬁrst two pipe threads to avoid having any small pieces of compound break loose and clog a burner valve or oriﬁce. Do not use threading compound on any ﬂare ﬁttings.

For built-in installations, it is recommended that any ﬂexible pipe used be kept as short as possible. (See INDEX: “Gas Connections” for typical permanent hook up.)

Do not change the regulator/hose assembly or use any other assembly than the one supplied with your Lynx grill.

Do not attempt to use a 5LP-A equipped regulator/hose assembly with a standard 510 POL cylinder/valve assembly.

Do not store a spare LP-gas cylinder under or near this appliance.

Never ﬁll the cylinder beyond 80 percent full. If the information above is not followed exactly, a

ﬁre causing death or serious injury may occur.

LP cylinder with type 1 valve connection

WARNING

CARE & USE/INSTALLATION

Never run ﬂex hose behind the ﬁrebox, run the hose at an angle, straight down, or out of the back.

GAS CONNECTIONS ...continued

Insert the regulator inlet into the cylinder valve and turn the

LP CONVERSION KIT

NG CONVERSION KIT

GAS CONNECTIONS ...continued

Side Burner Installation

black coupler clockwise until the coupler is hand tight. Do not over-tighten this connection.

To disconnect the coupler, ﬁrst make sure the main cylinder valve is turned off. Grasp the coupler and turn counter clockwise. The inlet will then disengage.

GAS CONVERSION KITS

Gas conversion kits are available from Lynx Grills to allow the grill to operate on either Natural gas or LPG. These kits should be installed by a qualiﬁed technician or certiﬁed plumber.

NG AND BULK PROPANE CART INSTALLATION

• Shut off the gas supply at the main valve.

• Disconnect all plumbing (if already attached) from the grill and the gas supply valve.

• Remove all the ﬁttings from the grill manifold.

Always leak-test the connection after reﬁlling or exchanging LP cylinders. (See INDEX: “Leak Test” for further details.)

GAS LINE PURGING

You should purge the gas line of air before attempting to light the grill.

• Make sure all grill controls are in the “OFF” position.

• Slowly turn on the main gas supply.

• Push in the rotisserie knob and conﬁrm that the igniter is glowing. It is furthest from the fuel source and will completely purge the lines. It will take several seconds for the burner to light.

• Hold the knob ON for about 20 seconds to allow the air in the system to purge and the burner to light

• Wait at least 5 minutes after shutting off the control before attempting to light the burners.

NG AND BULK LP BUILT-IN INSTALLATION

The kits come with complete installation instructions. These instructions should be read completely and fully understood before installing the conversion kit.

• Connect the gas supply to the grill as shown in the diagram on this page for your gas type.

• Turn the gas supply on and leak test all connections. (See INDEX: “Leak Test” for further details.)

Grill Manifold with Brass Elbow

Angle At Least 20˚ From Horizon

Regulator

P/N 13053

To Propane Tank

Inline

Regulator

P/N 30781

1/2” Close Nipple

1/2” FIP Street Elbow

1/2” MIP Fitting

LP BOTTLE CART INSTALLATION

Grill Manifold

Flexible Gas Line to Inlet

• Shut off the gas supply at the main valve.

• Connect the gas supply to the grill as shown in the diagram on this page for your gas type.

• Turn the gas supply on and leak test all connections. (See INDEX: “Leak Test” for further details.)

• Shut off the gas supply at the main valve.

• If connecting to a bulk propane tank, disconnect the brass elbow, hose and regulator from the grill.

• Remove all the ﬁttings from the grill manifold.

• Connect the gas supply to the grill as shown in the diagram on this page.

1/2” MxF Street Elbow

• Turn the gas supply on and leak test all connections. (See INDEX: “Leak Test” for further details.)

Inline Regulator

P/N 30781

Grill Manifold

Angle At Least 20˚ From Horizon

1/2” MIP Fitting

Flexible Gas Line to Inlet

16 17

CARE & USE/INSTALLATION

1/2” MxF Fitting

Flexible Gas Line

Grill Manifold

Angle At Least 20˚ From Horizon

1/2” MIP Fitting

1/2” Close Nipple

1/2” FIP T Fitting

Flexible Gas Line to Side Burner

To Propane Tank

1/2” MxF Fitting

Flexible Gas Line

1/2” MIP Fitting

1/2” Close Nipple

1/2” MIP Fitting

Grill Manifold

Angle At Least 20˚ From Horizon

1/2” FIP T Fitting

CARE & USE/INSTALLATION

To Propane Tank

Inline Regulator

P/N 30781

Flexible Gas Line to Inlet

Flexible Gas Line to Side Burner

ELECTRICAL CONNECTIONS

WARNING: ELECTRICAL GROUNDING

FINAL CHECKS

• Product installation must meet local electric codes or, in the absence of local codes, the latest edition of the National Electrical Code ANSI/NFPA No. 70 or the Canadian Electrical Code CGA 1.6b2005.

• Use only a Ground Fault Interrupter (GFI) protected circuit with this outdoor cooking gas appliance.

• IMPORTANT: When connecting your rotisserie motor, ﬁrst connect the motor to the grill and then plug the grill into the outlet.

• This grill is equipped with a three prong (grounding) electric plug for your protection against shock hazard and must be plugged directly into a properly grounded three prong outlet. Never cut or remove the grounding prong from this plug.

• Use only extension cords with a 3 prong grounding plug, rated for the power of the equipment, and approved for outdoor use with a “W-A” marking.

LEAK TESTING

DANGER!

To prevent ﬁre or explosion hazard, DO NOT smoke or allow any potential source of ignition (sparks, electrical arcing, etc) in the area while performing a leak test. Leak tests should be conducted outdoors only. Never conduct a leak test using ﬁre or ﬂame.

The main ceramic burners and Trident ™ burner on your Lynx grill feature an adjustable low setting.

Fluctuations in gas pressure, gas conversion and even in the quality of the gas itself may affect burner performance at the “LOW” setting. It could be either too high or too low.

To Adjust the Burner to a Low Setting:

• Make sure the grill is cool.

• Remove the racks so you can see the ﬂames while adjusting the burners.

• Light the burner and allow it to preheat on high for 3 minutes.

• Turn the burner to “LOW”.

• To protect against electric shock, do not immerse any part of the power cord, an extension cord or any plugs in water or other liquid.

• Unplug the product from the outlet when not in use and before cleaning. Allow it to cool before putting on or taking off parts.

• Do not let the cord hang over the edge of a table or touch hot surfaces.

• Do not use an outdoor cooking gas appliance for purposes other than intended.

• Do not operate any outdoor cooking gas appliance with a damaged cord, plug, or after the appliance malfunctions or has been damaged in any manner. Contact the manufacturer for repair.

CONNECTION TO AC

Installation requires an outdoor 120VAC 15A GFI (Ground Fault Interrupter) electrical outlet adjacent to the grill.

The GFI outlet features an internal breaker that reduces shock hazard. This type of outlet should be installed by a qualiﬁed electrician either inside the island enclosure for built-in units, or near the location where a free-standing unit will be used.

For built-in grills, the supplied 12VDC should be installed below the grill within the cabinet enclosure. Select a location where the transformer is protected against water, heat and physical damage.

When installing the transformer to the grill be careful to prevent the wiring and transformer from contacting any hot surfaces behind or below the grill. It is recommended that the transformer be located below the grill in a readily accessible location. Be sure to provide adequate access to facilitate service if the transformer or connections should need future maintenance.

If the electrical system fails to operate, a connection may have come loose in shipping or the GFI may have tripped, requiring a reset. See the Troubleshooting section for more details.

Leak Test Procedure:

• Create a soapy solution of 1 part soap and 3 parts water.

• Conﬁrm that all control knobs are in the off position.

• Turn on the fuel supply. For natural gas, turn the valve handle 1/4 turn to align with the gas ﬂow.

• For L.P., turn the cylinder valve knob counter clockwise one full rotation.

• Apply the soap solution generously by paint brush or squirt bottle on all connections and ﬁttings.

• If bubbles appear to “grow” on any of the connections, you have a gas leak. IMMEDIATELY turn off the gas

supply.

Fixing a Gas Leak:

• Shut off the gas supply

• Turn all grill controls to the “ON” position to purge the grill of any gas build-up, then turn the controls back “OFF”.

• Wash off the soapy solution with cold water and dry.

• Tighten the loose joint, or replace the faulty part with manufacturer-recommended replacement parts.

• DO NOT attempt to repair the L.P. cylinder valve if it is damaged. The only way to safely resolve a damaged

cylinder is to REPLACE IT.

• Pull off the control knob.

• While holding the valve shaft with pliers as shown insert a small ﬂat screwdriver into the center shaft and adjust the ﬂame’s low setting. (1/8” blade 3” long shaft)

Clockwise will lower the ﬂame setting, counterclockwise will raise it.

The proper setting is where the ﬂame is stable at its lowest setting. On the Trident™ burner slight ﬂutter will be present in the crossover portion of the front of the burner before the burner itself becomes weak.

The factory setting for propane gas is ½ to ¾ turn from the very bottom of the adjustment. The setting for natural gas is 1-½ to 1-¾ from the bottom. After the low settings are proper, turn all burners to high for visual inspection.

• Repeat the leak test to ensure that no leaks are present.

LOW HEAT BURNER ADJUSTMENT

FOR MAIN CERAMIC AND TRIDENT ™ BURNERS ONLY! DO NOT ADJUST THE ROTISSERIE BURNER.

18 19

CARE & USE/INSTALLATION

FINAL CHECKS ...continued

CHECKLIST BEFORE EACH USE (FOR YOUR SAFETY)

Flames should be blue and stable with slight yellow tips on the ceramic burner. The bright-blue core should be about 3/8 inch high with a total ﬂame height of about 1 1/2 inches.

The ﬂames should burn quietly (no “torch” sounds) and they should not “lift” up from the burner. If your ﬂames do not match those indicated in the photo, ensure that the burner ports are free and clear of dirt, debris, or spider webs. The ceramic tiles should be uniformly red to orange in appearance. There should be no lifting, ﬂuttering or lazy blue ﬂames.

The appearance of the Trident ™ burner should be visually checked. Some food particles will show as yellow ﬂames but should burn off.

IMPORTANT:

Make sure the owner knows where the main gas supply shut off valve is located.

Finally, for safety and for proper use & care, you must leave this manual with the owner. Make sure you advise them to keep it for future reference.

For technical assistance call:

Lynx Customer Care 888-289-5969

• Do you smell gas? If yes, shut off everything and call the gas company or a qualiﬁed plumber to check for leaks, if not please continue.

• Are you prepared to stay with the grill during the entire cooking process? If not, gather what you need before starting the lighting process. If yes, please continue.

• Is your cooking area free and clear of any combustibles, besides your food, that might ignite? If not, clear the area before starting the lighting process, If yes, please continue.

• Do all control knobs turn freely? If not, call for service, if yes, please continue.

A MESSAGE TO OUR CUSTOMERS

You’ve just joined the world of Lynx cooks … a discriminating collection of amateur and professional chefs that take outdoor cooking to a new level.

• If you are using a portable propane cylinder, is it connected and leak tested? If not, check the connection before continuing. If yes, please continue.

• Do you know where your grill’s main gas supply shut off valve is located? If not, locate it before continuing. If yes, please continue.

• Are all burners properly seated in the grill with mounting legs in slots? If not, seat the burners properly before continuing. If yes, please continue.

• Is the wind blowing just lightly and not blowing on the back of the grill? If not, wait until the wind subsides or turn your free standing grill so the wind goes into the front of the grill. If yes, please continue with the lighting process.

ONE LAST THING

Finally, before leaving, check all the burners for proper operation. Make sure the control knobs turn freely and completely through their full range.

Your grill has been designed and built with meticulous attention to detail and it offers some unique and powerful features. You can achieve maximum performance and enjoyment of these features only by carefully reading this manual ... before your ﬁrst cook-out.

This manual includes important safety tips and great hints for better grilling. You’ll want to keep it handy for easy reference.

Also, at Lynx, we enjoy hearing from our customers. We like to hear about your successes but also about any difﬁculties you are having. Please feel free to contact us with any questions or problems, or just to share a new recipe. Please include the model number of your grill in your correspondence.

With the proper use and care this product will provide years of trouble-free service.

Should your Lynx grill change ownership, please make sure that the new owner receives this manual.

Thanks again for your purchase. Enjoy!

20 21

CARE & USE/INSTALLATION

IMPORTANT SAFETY PRECAUTIONS

PLEASE REVIEW THESE IMPORTANT SAFETY PRECAUTIONS BEFORE YOU USE YOUR GRILL.

IMPORTANT!

GRILLING IN WINDY CONDITIONS

1. NEVER LEAVE THE GRILL UNATTENDED WHILE COOKING.

2. Ensure all tie-down straps have been removed from the burners.

3. Always use caution when operating the grill in a windy area. (See INDEX: “Grilling in Windy Conditions” for further details.)

4. Avoid wearing loose-ﬁtting garments or long sleeves while grilling. They could ignite.

5. Never touch the grill racks, hood or immediate surrounding metal surfaces with your bare hands while grilling.

6. Use an insulated glove or mitt when opening and

operating the grill. Always open the grill lid slowly to allow heat and smoke to escape before fully opening.

7. The grill hood must be fully opened while lighting the grill. Releasing fuel into a closed grill before lighting will not make it light sooner or more efﬁciently. It will only risk explosion and personal injury or death. Never lean over a hot grill surface or look directly into the grill when attempting to light.

8. Do not heat unopened food containers as pressure build-up will cause the container to explode.

9. Do not use aluminum foil to line grill racks or drip pans. This will alter the airﬂow or trap excessive heat in the control area and can melt control knobs and ignition modules. Such damage is speciﬁcally excluded from your warranty.

12. Never grill without the drip pan in place. Always ensure the drip pan is pushed all the way to the back of the grill. Hot grease can leak downward and produce a ﬁre or explosion.

13. Grease is extremely ﬂammable. Let hot grease cool down before attempting to handle or dispose of it. The drip tray should be cleaned of grease on a regular basis.

14. Do not use the grill unless a leak check has been

performed on all gas connections. (See INDEX: “Leak Test Procedure” for further details.)

15. Never operate the grill while under the inﬂuence of alcohol or drugs.

16. Do not lean on side shelves and never place a load weighing more than 25 pounds on a side shelf.

17. If any burner does not light or goes out during operation, turn off all gas control knobs, open the hood and wait ﬁve (5) minutes before attempting to re-light.

18. Portable L.P. cylinders: Always shut off the main valve on the L.P. cylinder after each use.

19. Spiders and insects like to nest in the burners, venturis, valves and oriﬁces of a grill, disrupting the gas ﬂow. This very dangerous condition can cause a ﬁre behind the control panel, damaging the grill and risking personal injury. If your grill has been unused for a long time, inspect and clean the burners, venturis, valves and oriﬁces. (See INDEX: “Cleaning the Ceramic Burner” for further details.)

Outdoor grills create more heat than interior kitchen ranges. That’s how they sear and grill steaks and other foods.

These high-performance burners require a constant, steady supply of fresh air to mix with the fuel. Your Lynx grill pulls air

Air enters through the front of the grill.

in through the front and vents hot gases out through the rear.

Using your grill in windy conditions may disrupt the frontto-back air ﬂow. If, while grilling with all burners on high and the hood closed, you notice that the temperature gauge fails to rise ... be careful. If wind has kept hot gases from exiting the rear of the grill the control panel and knobs may have become extremely hot.

Please Note: Any damage caused from use in windy conditions, such as melted knobs or igniter wires, or control panel discoloration from heat buildup, is excluded from warranty coverage.

Wind hitting the back of the grill can disrupt proper exhaust.

Your Lynx grill features an exclusive, patent-pending Heat Stabilizer that will deﬂect wind and, in most cases, prevent this situation.

But there are a few things you can do to further prevent

the possibility of improper heat buildup:

• On breezy days, be careful not to leave the front hood down when the burners are on high if the is grill unattended.

• If you suspect the grill is overheating, using an oven mitt, open the front hood. Then adjust the burner control knob to a lower setting.

• Install your grill with a wind break behind it.

• Orient the grill so prevailing winds are not blowing into the rear of the grill.

10. Never use charcoal or any other solid fuel in the grill.

11. Cooking excessively fatty meats and oils will cause ﬂare ups. Internal ﬁres or damage caused by them or by the grill being left unattended while cooking are not

covered under the terms and conditions of our warranty.

22 23

CARE & USE/INSTALLATION

USING YOUR LYNX GRILL

Grilling requires high heat for searing and low, controlled

PRE-GRILL CHECKLIST

LIGHTING YOUR GRILL

PRE-GRILL CHECKLIST ...continued

heat for slow cooking.

Thinner cuts of food are often cooked at a “HI” heat setting with the lid open.

On the other hand, large, thick pieces of meat or poultry are often ﬁrst seared at the high setting and then grilled at a lower setting ... sometimes with the lid closed … achieving the best results in the middle of the food without burning the outside.

Main Ceramic Burner

Trident ™ Burner

Some foods are cooked using direct heat and some using indirect heat.

Your Lynx grill features a variety of professional-level burners and tools for meeting the wide variety of cooking challenges. We will reveal how these features work for you. So please read and enjoy!

Depending on the model you chose, your Lynx grill may be equipped with up to three different burner types. The operation of each type varies, so it is important to understand all three.

Rotisserie Burner

BEFORE EACH USE

Before any use, always make sure that:

• ... you do not smell gas before you light the grill. If you do smell gas, shut everything off and have a qualiﬁed plumber check for leaks.

• … the cooking area is free and clear of any combustibles, besides your food, that might ignite.

• … the control knobs turn freely.

• … if you are using a portable propane cylinder, it is

WARNING

1. Never attempt to light a burner if you smell gas.

securely connected and leak tested. (See INDEX: “Cylinder Requirements” for details.)

• … you know where the main gas supply shut-off is located.

• … the burners are seated properly in the grill. The main burners must sit level and ﬁrmly on the burner mounting support frame. (See INDEX: “Unpacking & Assembly” for further details.)

• … wind is not blowing too strongly or blowing on the back of grill.

This ceramic burner is the standard main burner found under the briquette trays.

BEFORE YOUR FIRST USE

There are a few must-check safety precautions to consider before you use your grill. Please be sure that:

• All packing materials and tie-downs have been removed from the burners. (See INDEX: “Unpacking & Assembly” for further details.)

• You have fuel connected. (See INDEX: “Gas Requirements” for further details.)

• You have electric connected. (See INDEX: “Electric Requirements” for further details.)

• A qualiﬁed plumber has performed a leak test on all the ﬁttings that supply fuel to your grill.

This advanced infrared burner provides highintensity infrared heat for searing foods and sealing in ﬂavor.

This infrared burner spans the back of the cooking surface and provides consistent heat for slow rotisserie cooking.

• IF YOUR GRILL DOES NOT LIGHT IN 4 TO 5 SECONDS you may need to purge the line. (See INDEX: “Purging the Gas Line”

AT EACH NEW SEASON

At the start of each new grilling season you should remove the grilling racks and check the burners, venturis, oriﬁces and valves for obstructions.

Spiders and insects often nest in these areas of the grill and can disrupt air ﬂow, causing damage to the grill and personal injury.

Also, check all hoses and ﬁttings for damage, abrasion, wear and tear.

2. Always keep the lid open when lighting your grill.

3. Releasing fuel into a closed grill before lighting will increase the risk of explosion, property damage, personal injury or death.

4. Keep your face and body as far from the grill as possible when lighting. Any time a burner doesn’t light within 5 seconds, turn off the control, wait 5 minutes for gas to dissipate, and repeat the lighting procedure.

5. YOU NEVER LEAVE THE GRILL UNATTENDED WHILE THE GRILL IS LIT.

ELECTRIC IGNITION

Before proceeding, make sure you have completed the “Before Each Use” checklist.

Follow these steps to light any of the burners on your grill:

First, make sure all burner control knobs are set to OFF.

For the Main Ceramic Burner or Trident ™ Burner:

Push and hold the control knob in for 5-7 seconds, allowing the igniter to heat up. Then rotate the knob to “LITE”. After ignition, set the knob to the desired heat setting.

For the Rotisserie Burner:

The rotisserie burner features a thermocouple sensor with a safety valve that automatically shuts off the ﬂow of gas if the burner goes out. (See INDEX: “Windy Conditions” for tips on how to prevent burner blow out)

To light the rotisserie burner, push and hold the control knob in for 5-7seconds and then turn the knob to the “LITE” position.

After ignition CONTINUE HOLDING THE CONTROL KNOB IN for 30 to 60 seconds. During this time the thermocouple will heat up and the safety valve will remain open.

If you release the control knob before the thermocouple has heated up, the safety valve will shut off the ﬂow of gas to the rotisserie burner and you will have to re-light the burner.

24 25

CARE & USE/INSTALLATION

LIGHTING YOUR GRILL ...continued

PRE-HEATING

BASIC GRILLING

TYPES OF COOKING

COLD WEATHER WARNING: PROPANE

Extremely cold temperatures may cause your Trident ™ burners to light inside the burners instead of outside. Once lit, if you hear a ‘whooshing’ sound, immediately turn the burner knobs off to extinguish the ﬂame and then immediately re-light the burners.

MANUAL LIGHTING

If a burner doesn’t light after several attempts, it can be match lit using the lighting rod stored in the drip tray.

First, make sure you’ve returned all of the control knobs to the OFF position and have allowed 5 minutes for any accumulated gas to dissipate before attempting to match light a burner.

To match-light this burner, use the lighting rod to insert a lit match through the cooking grate into the front slot of the briquette tray for that burner.

Push and turn the corresponding burner control knob to “LITE”. If the burner doesn’t light within 5 seconds turn the knob off and wait 5 minutes before attempting to light it again.

Trident ™ Burner

To match-light this burner, use the lighting rod to insert a lit match through the cooking grate and through the protective screen.

Push and turn the corresponding burner control knob to “LITE”. If the burner doesn’t light within 5 seconds turn the knob off and wait 5 minutes before attempting to light it again.

Pre-heating your grill every time you use it is extremely important. Pre-heating allows the briquettes to properly heat up, providing more even and more consistent cooking results.

Pre-heat your grill by igniting all main burners, including the Trident ™ burner, and setting them to “HI”.

Then close the hood and allow the grill to heat for 10 to 15 minutes, the hood thermometer should reach approximately 450°. Once you’ve reached your desired pre-heat temperature, turn off the burners that you won’t be using to cook your food. Remember, surface temperature can be up to 200° higher.

WARNING!

DO NOT LEAVE THE GRILL UNATTENDED DURING THE PRE-HEAT CYCLE OR AT ANY TIME WHILE THE GRILL IS IN USE.

PRE-HEATING FOR MORE THAN 10 - 15 MINUTES MAY OVERHEAT THE GRILL, CAUSING DAMAGE TO THE GRILL.

The main ceramic burners and the Trident ™ burner in your Lynx grill are capable of creating a range of heat intensities. By varying the heat output, the number of burners used and the position of the hood, you can create either direct or indirect heat or a combination of both and develop a wide variety of succulent recipes. There are two basic types of grilling in an outdoor grill... Direct Heat and Indirect Heat

Direct Heat

Direct heat cooking occurs when foods are placed directly over the heat source. This form of heat is known as “radiant” heat because the heat radiates directly from the source to the food.

Direct heat is a must when you want to sear the outside of your food to seal in ﬂavor. Lynx Trident ™ Burners provide the heat necessary to sear foods and seal in ﬂavor.

Indirect Heat

Indirect heat cooking occurs when the food is not close to the heat source. Heat reaches the food via air movement within the cooking area. This form of heat is known as “convection” heat.

Indirect, or “convection” cooking is achieved by placing the food on one side of the grill and igniting burners on the other side. You leave the burner below the food “OFF”. You should keep the hood closed as much as possible during this type of cooking to maintain even heat around the food. You regulate the heat by adjusting the burner, using the hood thermometer to monitor the temperature.

26 27

CARE & USE/INSTALLATION

Never place food over a Trident ™ burner before it is fully

USING THE TRIDENT ™ BURNER

USING THE ROTISSERIE BURNER

pre-heated because food particles and grease dripping onto a cold Trident ™ burner can clog the tiny ports and damage the burner.

For the same reason you should minimize water spills on the Trident ™ burner and should not use water to control ﬂare-ups. Take special care to minimize dropping any liquids on the Trident ™ burner while cleaning the cooking grids.

Rotisserie cooking provides an even delivery of heat to your foods. It has no equal. The constant rotation not only cooks foods evenly, it also self bastes. As juices rise to the surface of the food, they naturally ﬂow around it as it rotates. And, by moving the burner out from beneath the food, you avoid scorching

ﬂare-ups.

The Spit Rod & Forks

The rotisserie can handle large food items up to 50 lbs. You should prepare any item and ﬁrst mount it on the skewer.

Professional restaurant chefs rely on a different type of heat ... infrared heat ... to create a higher searing temperature than what standard burners can achieve. So Lynx provides the Trident ™ infrared burner.

Infrared burners work by focusing the gas ﬂame through a ceramic element ﬁlled with tiny holes.

These holes focus the ﬂame on the surface of the element, creating an intense heat much higher than that of a standard ceramic burner. It allows you to sear your food more quickly while leaving the inside rare, if desired.

The Trident ™ burner, with its advanced components, requires particular attention to lighting, usage and cleaning guidelines.

Pre-Heating the Trident ™ Burner

Always preheat the entire grill before cooking to achieve consistent, successful results. (See INDEX: “Preheating” for further details.)

If the grill is already hot from cooking you should still pre-heat the Trident ™ burner for 2-3 minutes, or until it glows red.

HOW TO SEAR

Searing locks in ﬂavor and juices while allowing the food’s outer surface to absorb smoke and food-born aromas produced when drippings are vaporized by the burner.

The result is a restaurant-style ﬁnish … crisp, ﬂavorful outside with a tender, juicy inside.

While the ceramic burners in your grill are capable of producing searing heat, the Trident ™ infrared burner is speciﬁcally designed for this purpose.

SAFETY PRECAUTIONS

Lynx grill cooking grids are heavy duty. Dropping them on the Trident ™ Burner will damage the burner. Such damage is not covered by the product warranty and will cause a ﬁre, burns or other personal injury.

TRIDENT™ BURNER CLEANING

It’s easy to keep your Trident ™ Burner operating at peak performance. Just run it on “HI” with the hood open for 5 minutes after each use to burn away any food particles or drippings.

Any ash accumulation on the burner screen can be removed with a light brush (like a paint brush) or vacuum … BUT WAIT UNTIL THE BURNER IS COOL! Never use water.

Your foods will be more evenly cooked, more tender and juicier when slow-roasted on a Lynx’s rotisserie.

The Lynx rotisserie system consists of four main parts, the motor, the skewer, the forks and the infrared burner.

The Motor

Install the motor by sliding it into one of the slots shown here. Use the top slot for small foods or fast cooking and the lower slot for large foods and slower cooking.

Plug the motor power cord into the motor and into the built-in power outlet on the rear left panel. Your grill must be plugged into an AC power supply for the rotisserie to work.

Place a basting pan in the grill to prevent food accumulations on the briquettes and burners. But BE SURE YOU REMOVE IT before using any of the other burners.

The location of the rotisserie burner makes it more susceptible to strong wind conditions (more so than the main grill burners).

For this reason it features a safety valve that automatically closes any time the rotisserie burner is not properly lit … like if it were to extinguish in windy conditions. During windy conditions, it’s best to keep the lid closed and to periodically check the burner.

Rotisserie Motor Mount

Swing the warming rack up and out of the way. It will rest in place.

Then mount the skewer on the grill before lighting the rotisserie infrared burner. Lighting the burner ﬁrst could result in burning your hands while trying to mount the skewer on the grill.

It’s okay to remove the grill racks and even the briquette trays to make room for large foods on the skewer.

To load the skewer, slide one of the forks onto the skewer. Push the skewer through the center of the food, then slide the second fork onto the skewer. Center the food to be cooked on the skewer then push the forks ﬁrmly together. Tighten the thumb screws (use pliers if necessary). You should wrap any loose, dangling pieces of food (like wings) with butcher’s string (never use nylon or plastic string).

With the food secured to the skewer slowly roll the skewer in the palms of your hands to check for balance. It should rotate smoothly. If you ﬁnd it has a heavy side, adjust where the skewer pierces the meat. An unbalanced skewer will cause uneven rotation and uneven cooking. It’s normal for the skewer to ﬂex with large foods.

When the rotisserie is not in use the rotisserie motor should be stored in a cool dry location.

28 29

CARE & USE/INSTALLATION

Slide the pointed end of the skewer into the motor and rest

USING THE ROTISSERIE BURNER ...continued

USING THE SMOKER BOX

CLEANING YOUR LYNX GRILL (Including Required Maintenance)

the other end on the rollers on the other side of the grill.

The notched portion of the skewer must rest on the rollers for proper operation.

Must rest on rollers

The Rotisserie Burner

To light the rotisserie infrared burner, ﬁrst mount the skewered food item on the grill then follow the rotis-

serie lighting procedure. (See INDEX: “Rotisserie Burner, Lighting” for further details.)

Once lit, the rotisserie burner should reach cooking temperatures in about 1 minute. It will glow evenly across its surface in about 5 minutes.

NOTE: The grill thermometer should not be used for rotisserie cooking. It is not designed to read direct infrared heat.

If the burner will not stay lit when you release the control knob, re-light it and hold the control knob in for at least 60 seconds to allow the thermocouple to heat up.

If, after holding the control knob in for at least 60 seconds, the burner still will not stay lit when releasing the control knob, call for service.

(See INDEX: “Obtaining service from Lynx” for further details.)

STAINLESS STEEL

Lynx products are known for their attractive appearance. We achieve this by selecting only the ﬁnest grades of stainless steel and applying exacting workmanship.

In order to maintain this attractive appearance over the life of the grill it is important to take the following steps:

• After each use wipe down the exterior of the grill to remove grease and splatters.

• Be sure to follow the cleaning instructions for keeping the grates and burners clean and ready for use.

• Use a commercially available Stainless Steel cleaner* to clean and polish the exterior surfaces.

Doing these things on a regular basis minimizes the amount of effort required.

Part of the appeal of your Lynx Grill is the ﬁne grain ﬁnish. When removing stubborn stains:

• Do not use metallic abrasives and always rub in the direction of the grain.

surface rust to appear and even create some pitting if left on the product.

Here are a few tips to avoid this:

• Regularly wipe down the exterior surfaces with a damp cloth. (Micro ﬁber cloths such as Ecloth perform very well).

• Allow the surfaces to dry before installing the cover. Do not cover a damp grill.

• In extreme environments apply a rust inhibitor which leaves a microscopic protective layer on the grill. Products that provide a layer of vapor corrosion inhibitors (VpCI™) protect the surface very well.

• For seasonal storage use the product referred to above, ensure the grill is dry and then cover and secure the cover to minimize the amount of damp air getting to the surfaces.

THE LYNX LIMITED LIFE TIME WARRANTY PROVIDES PROTECTION AGAINST RUST THROUGH OF PARTS THAT RENDER THE PRODUCT INOPERATIVE. IT DOES NOT COVER OCCASIONAL SURFACE RUST OR STAINING DUE TO ENVIRONMENTAL CONDITIONS.

Professional chefs far and wide set their restaurant cuisine apart by cooking over wood ﬁres. Imparting a delicate hint of wood smoke enhances food, raising your culinary skills to the next level.

Your new grill comes with the Lynx Smoker Set with handle. This oval shaped Lynx Smoker box can be placed anywhere on the grates directly over any burner. The unique handle and interlock mechanism is designed to allow quick removal or reﬁlling of the Lynx smoker box.

The smoker box is designed with special draft and ﬂow through for maximum smoke. It is constructed of 304 Heavy Gauge Stainless Steel for years of use.

The Lynx Smoker box can be used with smoker pellets or wood chips. Whether using wood chips or pellets, we recommend using approximately 3 oz. of either material. There is no need for presoaking, just ﬁll the smoker box.

Now use the handle to place the smoker box directly on the hot grates. Don’t forget to remove the smoker handle before closing the grill lid.

Smoke occurs at approximately 575 degrees F. at the grilling surface. Set the burner knob to medium/medium low to achieve this temperature. Use the handle to move or reﬁll the smoker box. Control the smoking by adjusting the heat and being careful not to adjust it too high.

For best results keep the lid closed. The best absorption of smoke ﬂavor occurs early in the cooking process. When ﬁnished with smoking, allow the smoker box to cool and dispose of remnants.

CAUTION

Handle the smoker box with care. The cover becomes extremely hot when in use. Use sturdy, properly insulated gloves or dry pot holders.

• Some household cleaning products are not suitable for stainless steel; be sure to read the label before using on your Lynx Grill.

• Always use the mildest cleaning solution ﬁrst, scrubbing in the direction of the grain. Specks of grease may gather in the grain of the stainless steel and bake on to the surface, giving the appearance of rust.

To remove these baked-on foods use a ﬁne to medium grit non-metallic abrasive pad (Scotch Brite is good) in conjunction with a stainless steel cleaner.

• Solutions used for cleaning concrete and masonry can be very corrosive and will ‘attack’ stainless steel. Ensure your Lynx products are well protected before you allow the use of such chemicals near your grill.

SPECIAL NOTE FOR LOCATIONS NEAR POOLS AND COASTAL AREAS:

After your ﬁrst use certain areas of the grill may discolor from the intense heat given off by the burners - this is normal and cannot be cleaned off.

For light and heavy food stains there are many different stainless steel cleaners available.

DRIP TRAY

The drip tray should be cleaned after each use. After the grill is completely cool, remove the drip tray by pulling it out until it stops, then lifting the front edge until the drip tray comes free.

Clean it with hot soapy water or an oven-style cleaning product and re-install. When using an oven-style cleaning product be sure to carefully follow the manufacturer’s instructions. Many of these cleaners are toxic and can damage the stainless steel ﬁnish if not used properly.

Also, check the tray after rain. If you’ve left the grill uncovered, you may need to remove the drip tray drain plug to drain the water from the tray. The drain plug can be removed with a ﬂat-head screwdriver.

The 304 stainless steel material used in the construction of a Lynx Grill is highly rust resistant, however, chlorine in the air from swimming pools or the salt from sea air may cause

30 31

CARE & USE/INSTALLATION

RATED FOR HIGH HEAT

CARE & USE/INSTALLATION

To Remove Ceramic Burners:

CLEANING YOUR LYNX GRILL (Including Required Maintenance)...continued

TROUBLESHOOTING YOUR LYNX GRILL

TRIDENT ™ BURNER

WARNING

DO NOT ALLOW EXCESS GREASE OR LIQUIDS TO ACCUMULATE IN THE DRIP TRAY AS THIS MAY CREATE A FIRE HAZARD.

NEVER USE GRILL WITHOUT DRIP TRAY PROPERLY INSTALLED.

GRILLING RACKS

The easiest way to clean the grill racks is to do so im- mediately after turning off the burners, while they are still hot. Wearing a long BBQ mitt to protect your hand from steam, dip a brass bristle brush in hot water and scrub the grill rack. Dip the brush frequently because the steam helps remove baked-on foods.

CERAMIC BRIQUETTES

The ceramic briquettes normally burn off any accumulated food drippings. But you may occasionally experience larger spills that don’t burn off under normal use.

When this happens, let the grill cool completely. Remove the racks and then the briquette trays by lifting the front edge and pulling them toward you.

Flip the trays over and put them back in place over the burner. Light the burners and set them to “HI” for 5 - 10 minutes to burn the briquettes clean. Any remaining food items can be brushed off using a soft brush.

Be sure the trays have completely cooled before reinstalling them.

Replacement briquette trays can be ordered from Lynx or from your dealer.

MAIN CERAMIC BURNERS

Remove the grill racks and briquette trays.

Rremove the burner caps to prevent accidental breakage

Lift the burner up until the legs exit the frame.

Then pull to the rear of the grill so the burner head comes off the brass oriﬁce at the front.

Angle the burner sideways and lift it out.

To Clean the Ceramic Burner:

To maximize grill performance, clean the exterior of the burner with a nylon brush when cooled. Clear any clogged ports by lifting the ceramic burner caps and cleaning any debris at the port holes.

Shake out any debris through the venturi or or burner cap openings.

Use a ﬂashlight to inspect the burner inlet to ensure it is not blocked. If obstructions can be seen, clean it with a paper clip or a pipe cleaner.

WARNING

PROPER PLACEMENT OF EACH BURNER IS CRITICAL. AFTER CLEANING THEY MUST BE CENTERED ON THE BRASS ORIFICE, RESTING LEVEL WITHOUT ANY ROCKING.

FAILURE TO MEET THESE CONDITIONS MAY CAUSE A VERY DANGEROUS CONDITION THAT CAN CAUSE PERSONAL INJURY AND PROPERTY DAMAGE.

Oriﬁce all the way

into the venturi

It’s easy to keep your Trident ™ burner operating at peak performance. Just run it on “HI” with the hood open for 5 minutes after each use to burn away any food particles or drippings.

Any ash accumulation on the burner screen can be removed with a light brush or vacuum … BUT WAIT UNTIL THE BURNER IS COOL! Never use water or liquid to clean.

Every 3 to 6 months, remove the burner and inspect the venturi (inlet) and oriﬁce to ensure that they’re free of obstructions.

Food debris on the inside of the burner can be gently shaken out. Do not touch the ceramic surface.

When re-installing the Trident ™ burner, be sure to correctly position the burner.

WARNING: REQUIRED MAINTENANCE

1. Failure to perform required maintenance will void your warranty.

2. Clean out port holes on all ceramic burners if necessary with a plastic scouring pad.

3. Scrape the bottom of the ﬁrebox with a plastic putty knife or similar tool and discard the residue.

4. Clean out the burner oriﬁces and ensure they are free of debris.

5. Clean the drip tray.

BEFORE YOU CALL FOR SERVICE

Please check a few things before calling for service:

• Is there fuel supplied to the grill?

• Is the main shut-off valve open?

• Are you using the correct type of fuel? (LP or Natural Gas) (See INDEX: “Gas Requirements” for further details.)

Heat Shield Removed, Oriﬁce/Venturi Position

Inside View, Oriﬁce all the way into venturi

• Is your propane cylinder empty? Have you recently reﬁlled the propane cylinder? If so, is the connection tight?

• Have you opened the valve on the propane cylinder?

• Is the grill plugged in to a live electric circuit?

If you’ve checked the above items, review the trouble-shooting list below before calling for Lynx for service.

Make sure the grill is completely cool before proceeding.

Ensure that the gas supply is off and all control knobs are in the “OFF” position.

32 33

CARE & USE/INSTALLATION

Burner sitting ﬂat

CARE & USE/INSTALLATION

GRILL WON’T LIGHT

POTENTIAL PROBLEMS

POTENTIAL PROBLEMS ...continued

First, conﬁrm that the grill is getting electricity by turning on the lights, then:

Check The Igniters

Your Lynx grill uses an electric ignition system that does not spark. Instead, the igniters should glow constantly when a control knob is pushed in.

• Ensure that all burner controls are set to OFF.

• Remove the cooking grates and briquette trays.

• Watch an igniter as you push in and hold the corresponding control knob. You will need either a small mirror or shiny metal object to see the igniter under its cover. (Be sure you push in the correct control knob and keep

If match lighting doesn’t work, re-check fuel connections for leaks and ensure the supply is of the correct type and is of adequate pressure. (See INDEX: “Leak Test Procedure” for further details.)

If the burner will light with a match, then the igniter may not be functioning correctly. Call for service.

If the burner will not match light, and you know you are getting gas, wait for any gas to dissipate and remove the burner and check it for blockages.

SMELL OF GAS WHILE COOKING

IF YOU SMELL GAS WHILE THE GRILL IS OPERATING, IMMEDIATELY TURN OFF ALL BURNERS AND SHUT OFF THE MAIN FUEL SUPPLY.

• Perform a leak test (See INDEX: “Leak Test Procedure” for further details.)

• Check for blockages (See INDEX: “Clean the Ceramic Burner” for further details.)

YELLOW FLAMES

REPLACE any damaged supply lines.

• Check the Regulator

Make sure that the regulator & hose assembly is the one designed for and supplied with your Lynx grill and that it is correctly set up for the type of fuel you are using. (See INDEX: “Regulator Conversion” for further details.)

The hose and regulator provided by Lynx must be used if your grill is set-up for a portable LP Gas Cylinder. Ensure the LP hose is not behind the ﬁrebox.

Check that there is no physical pressure being applied to the regulator attached to the back of the grill. The regulator contains a ﬂexible diaphragm and should not be allowed to touch the grill body or its surroundings.

• Check for Obstructions Ensure that the burners and drip tray are clean and free

from obstructions.

LP (Propane) units:

• Is the cylinder almost empty?

Almost-empty cylinders may not have sufﬁcient pressure to run the burners at high heat.

Natural gas inlet pressure should be at least 5” W.C. and manifold pressure not less than 4” W.C. under full load (with all burners on.)

• Check burners for blockages.

• Check ﬂame characteristics. (See INDEX: “Flame, Correct Size” )

• Clean or adjust air shutter (See INDEX: “Air Shutter Adjustment.”

WIND HITTING GRILL

Wind hitting the grill while in use, especially winds blowing into or across the hood gap from behind, can cause poor performance and in some cases can cause the control panel and knobs to get dangerously hot.

Steady or gusty winds can prevent the normal exhaust of hot gases. Locate your grill away from prevailing winds and avoid grilling in windy conditions (see page 23).

the knob in the “OFF” position).

• Check the remaining igniters. If igniters don’t glow, proceed with troubleshooting or match-light the burner.

Check The Burners

If the igniters are working check to see if gas is reaching the burners by attempting to match light a burner.

BE CAREFUL! IF THE BURNER FAILS TO IGNITE, WAIT 5 MINUTES BEFORE ATTEMPTING TO IGNITE OTHER BURNERS! (See INDEX: “Match Lighting” for further details.)

Gas Collector Hood

Hot

Surface

Igniter

A yellow ﬂame on the main burners indicates a lack of air. But, if the air around the grill is dusty or if heavy grease is present, some orange tips on the burner ﬂame are normal. Inspect for cracks in the burners where air may be entering.

LOW OR INSUFFICIENT HEAT

No part of the grill should ever be lined with aluminum foil. Doing so will interfere with airﬂow and can cause a low heat condition.

Ensure that you’ve preheated the main burners for at least 10 to 15 minutes with the hood closed and the Trident ™ burner for 3 minutes.

If the low heat problem persists:

• Check the gas supply line sizing requirements.

• Check the gas supply line for kinks or damage.

• Have the line pressure checked by a qualiﬁed technician (See INDEX: “Gas Requirements” for further details.)

• Flow Limiting Device

Improper lighting procedures may have activated the LP cylinder’s ﬂow control device, reducing the heat output.

To reset the ﬂow control:

• Shut off all burner controls and close the LP cylinder valve.

• Wait 30 seconds and, very slowly, reopen the cylinder valve.

• Wait a few seconds and relite a burner.

Bulk LP cylinder users:

Bulk LP cylinder lines must be properly regulated.

Ensure that you are using a 4/11 appliance regulator supplied by Lynx and converted to LP gas. Also ensure that you do not have more than one regulator in line.

Natural Gas units:

• Supply Line

Ensure that the supply line is at least 3/4” inside diameter or 1” outside diameter.

• Check line pressure

34 35

CARE & USE/INSTALLATION

POTENTIAL PROBLEMS ...continued

CONTACTING LYNX CUSTOMER CARE

• TGI Fridays

• Applebee’s

• Houston’s

• Red Lobster

• Hard Rock Café

• Wolfgang Puck’s

• Cheesecake Factory

• Red Robin

• Planet Hollywood

• Hilton

• Hyatt

• Four Seasons Marriott Le Meridian

• Sheraton

• Conrad International

• Bellagio

• New York New York

• MGM Grand

• Treasure Island

• Mirage

• Paris

• Venetian

• Excalibur

• Mandalay Bay

• Riviera

• Desert Inn

• Hard Rock Hotel

• Disney World

BURNER GOES OUT

• Location

First determine if the problem is being caused by location. If the grill is subject to high winds, reposition it to provide some protection.

• Check the Flame

Check the gas supply and ﬂame characteristics. (See INDEX: “Flame, Correct Size”)

• Burners Seated

Check to ensure that the burners are correctly positioned in the grill. (See INDEX: “Burner Placement” for further details.)

Correctly-installed burners should be seated ﬁrmly and level with no side-to-side movement.

BURNER GOES OUT ONLY WHEN SET TO “LOW”

The valves on the grill feature an adjustable low setting.

Fluctuations in gas pressure, gas conversion and even in the quality of the gas itself may affect burner performance at the “LOW” setting. It could be either too high or too low. (See INDEX: “Burner Adjustment” for further details.)

If, after holding the control knob in for at least 60 seconds, the burner still will not stay lit when releasing the control knob, call for service.

(See INDEX: “Obtaining service from Lynx” for further details.)

LIGHTS WILL NOT ILLUMINATE

• Check Power

Ensure that the grill is connected to a live AC power source and check for rotisserie motor operation.

• Replace the Bulb

Replacement bulbs are halogen, 12 volt, 10W max, T3 type with a G4 bi-pin, and are readily available at most home improvement stores. The glass cover is held in place by two spring tension tabs. The bulbs are easily removable without the use of tools. Simply grasp the glass lens at the outer corners, near the front tension clips and push the lens back. Then, swing the lens down and pull it loose. You may have to loosen the screw to remove the lens.

Avoid touching the glass of a new bulb. Halogen bulbs are very sensitive to the oils found in human skin. Touching the bulbs may shorten their life.

Before calling Lynx Customer Care, please make sure you have the following information:

• Model number

• Date of purchase

• Proof of purchase by the original owner

• Serial number

The serial number can be located on the rating plate which is located on the underside of the drip tray and on the heat shield behind the front panel.

For warranty service, contact the Lynx Customer Care Department for an authorized service agent near you at:

(888) 289-5969

www.lynxgrills.com

THE LYNX STORY

Your satisfaction is of the utmost importance to us. If a problem cannot be resolved to your satisfaction, please write, fax or email us:

Lynx Professional Grills 7300 Flores Street Downey, CA 90242 Service: (888) 289-5969 Tel: (562) 299-6900 Fax: (562) 299-6978 www.lynxgrills.com email: service@lynxgrills.com

Contact Lynx for replacement parts. Parts are shipped F.O.B. Downey, CA.

ROTISSERIE WON’T LIGHT

Follow the same procedure as described for the grill burners to diagnose problems with the rotisserie burner.

BE CAREFUL! The rotisserie burner ﬂame may be hard to see in bright sunny conditions.

ROTISSERIE LIGHTS BUT GOES OUT AS SOON AS CONTROL IS RELEASED

• Check Thermocouple

The control knob must be held in for 30 to 60 seconds after ignition for the rotisserie burner to stay lit. (See INDEX: “Lighting Rotisserie Burner” for further details.)

If the burner will not stay lit when you release the control knob, re-light it and hold the control knob in for at least 60 seconds to allow the thermocouple to heat up.

36 37

CARE & USE/INSTALLATION

Pull the bulb straight out from the socket without twisting.

Pull on spring tabs to release light cover

Hold the bulb using a paper towel or other cloth and gently press it straight into the socket. The glass cover should be gently snapped back into place.

Lynx began with a vision.

A small group of manufacturing engineers with over a century of collective experience had a dream. They dared to take their extensive commercial manufacturing know-how and create a line of outdoor cooking products that offer commercial elegance and performance to the consumer market.

Lynx has taken the quality, workmanship, service and innovation of the commercial market and incorporated it into the Lynx Professional Grills line of consumer and commercial products. The combination of creative design, superior materials and exceptional craftsmanship elevates Lynx products to a class of their own.

Lynx original commercial products are used every day in restaurants, hotels and theme parks across the USA:

LYNX SATISFIED CUSTOMERS

CARE & USE/INSTALLATION

LYNX LIMITED WARRANTY

LYNX COMMON AREA LIMITED WARRANTY

I. Limited Lifetime Warranty

The stainless steel grill body, ceramic grill burners, cooking grates,Trident ™ burner and rotisserie infrared burner are warranted to be free from defects in material and workmanship when subjected to normal domestic use and maintenance for the lifetime of the original purchaser. This warranty excludes surface corrosion, scratches, and discoloration which may occur during normal use. This warranty is limited to the replacement of the defective parts, with the owner paying a processing fee and all other costs including labor. Failure to perform required maintenance will void this warranty

II. Limited Five-Year Warranty

The following grill parts are warranted to be free from defects in material and workmanship, when subjected to normal domestic use and maintenance, for a period of ﬁve (5) years from the original date of purchase; warming racks, spit rods, briquette trays, manifolds and gas valves. This warranty is limited to the replacement of the defective parts, with the owner paying a processing fee and all other costs including labor.

III. Limited two-Year Warranty

All other grill components are warranted to be free from defects in material and workmanship, when subjected to normal domestic use and maintenance, for a period of two (2) years from the original date of purchase. This warranty is limited to the replacement of the defective parts, with the consumer paying all labor costs.

IV. Limited One-Year Warranty

For a period of one (1) year from the original date of purchase, Lynx will replace or repair parts found to be defective at no cost to the original purchaser. This includes the cost of shipping replacement parts and, where necessary, service labor at prevailing local rates by a Lynx authorized service person. Service will be provided during normal business hours and must be authorized in advance by Lynx.

V. Limitations & Exclusions

1) This Warranty shall apply to products purchased and located in the United States and Canada. Products must be purchased in the country where service is requested.

2) Warranty applies only to the original purchaser and may not be transferred.

3) Warranty is in lieu of all other warranties expressed or implied and all other obligations or liabilities related to the sale or use of Lynx products.

4) Warranty shall not apply and Lynx is not responsible for damage resulting from misuse, abuse, failure to provide reasonable and necessary required maintenance, natural disaster, animals, alteration of or tampering with the appliance, accident, hostile environment, ﬂare-up ﬁres, improper installation or operation, or an installation not in accordance with the instructions contained in this manual, or the local codes.

5) Lynx shall not be liable for incidental, consequential, special or contingent damages resulting from its breach of this written warranty or any implied warranty.

6) Some states do not allow limitations on how long an implied warranty lasts, or the exclusions of or limitations on consequential damages. This warranty gives you speciﬁc legal rights and you may have other rights which vary from state to state.

7) No one has the authority to add to or vary Lynx’s warranty, or to create for Lynx any other obligation or liability in connection with the sale or use of its products.

8) Limited to the replacement of defective parts with the owner paying all other costs including labor.

VI. What is not covered: Lynx shall not be responsible for

and shall not pay for the following

1) Installation or start-up, damages or problems caused by improper installation or use;

2) Service by an unauthorized service provider;

3) Damage or repair due to service by an unauthorized service provider or use of unauthorized parts;

4) Warranty does not apply to products installed in any commercial or non-residential application. Examples of excluded applications include, but are not limited to day care centers, schools, bed and breakfast centers, churches, private clubs, ﬁre stations, club houses, common areas in multi-family dwellings, restaurants, hotels, nursing homes, food service locations and institutional food service locations. *Contact Lynx for Common Area Warranty.

5) To correct normal adjustments or settings, due to improper installation, commissioning or local gas supply properties.

6) Shipping and handling costs, export duties, installation, removal, or re-installation cost (RMA excluded).

7) Display models are sold “as is”. If you have purchased a display model, please be advised that it is sold “as is” and that it is subject to the following warranty exclusions: any exterior or cosmetic damage is nonwarrantable; any missing components will be replaced at consumers expense; major handling damage to manifold, valve and ignition system will be serviced at consumer’s expense; all other warranties will remain in effect.

8) The cost of a service call to diagnose complaint.

9) Modiﬁcation to Lynx product will void related warranties.

Please refer to Accessory Care & Use for respective warranties.

The Lynx Limited Warranty covers residential installations only and is non-transferable to any other party. This warranty applies when the product is installed in common areas where more than a single party has rightful access to its use or in locations considered beyond normal residential use such as B&B’s, and private clubs.

THIS PROVISION EXCLUDES ALL COMMERCIAL APPLICATIONS, INCLUDING, BUT NOT LIMITED TO RESTAURANTS AND INSTITUTIONAL FOOD SERVICE LOCATIONS.

I. Limited Five-Year Warranty

The stainless steel body, the solid ceramic grill bur ners are warranted to be free from defects in material and workmanship when subjected to normal use and maintenance for a ﬁve year period from the original purchase date. This warranty excludes surface corrosion, scratches, and discoloration which may occur during regular use. This warranty is limited to the replacement of the defective parts, with the consumer paying labor.

II. Limited One-Year Warranty

The structural integrity of the interior grill parts, exterior, and drip pans are warranted to be free from defects in material and workmanship, when subjected to normal domestic use and service, for a period of one year from the date of purchase. This warranty is limited to the replacement of the defective parts, with the owner paying all other costs including labor.

III. Limited Parts & Labor Warranty

All other grill components are warranted to be free from defects in material and workmanship for a period of 90 days from the original date of purchase. Lynx will replace or repair parts found to be defective at no cost to the original purchaser. After the 90 day period Lynx will sell parts to the holder of this warranty at Lynx contractor prices for an additional 9 months.

IV. Limitations & Exclusions

1) This Warranty shall apply to products purchased and located in the United States and Canada. Products must be purchased in the country where service is requested.

2) Warranty applies only to the original location of installation and may not be transferred.

3) Warranty is in lieu of all other warranties expressed or

implied and all other obligations or liabilities related to the sale or use of Lynx products.

special or contingent damages resulting from its breach of this written warranty or any implied warranty.

7) No one has the authority to add to or vary Lynx’s warranty, or to create for Lynx any other obligation or liability in connection with the sale or use of its products.

8) Limited to the replacement of defective parts with the owner paying all other costs including labor.

V. What is not covered: Lynx shall not be responsible for and shall not pay for the following:

1) Installation or start-up, damages or problems caused by improper installation or use;

2) Service by an unauthorized service provider;

3) Damage or repair due to service by an unauthorized service provider or use of unauthorized parts;

4) To correct normal adjustments or settings, due to improper installation, commissioning or local gas supply properties;

5) Shipping and handling costs, export duties, installation, removal, or re-installation cost (RMA exluded).

6) Display models are generally sold “as is.” If you have purchased a display model, please be advised that it is sold “as is” and that it is subject to the following warranty exclusions: any exterior or cosmetic damage is non warrantable; any missing components will be replaced at consumer’s expense; major handling damage to manifold, valve and ignition system will be serviced at consumer’s expense; all other warranties will remain in effect.

7) The cost of a service call to diagnose complaint.

Modiﬁcation to Lynx product will void related warranties.

Please refer to Accessory Care & Use for respective warranties.

5) Lynx shall not be liable for incidental, consequential,

38 39

CARE & USE/INSTALLATION

L27 & L30 ROTISSERIE GRILL

WIRING SCHEMATICS

L36 & L42 ROTISSERIE GRILL

40 41

CARE & USE/INSTALLATION

L54 ROTISSERIE GRILL

WIRING SCHEMATICS

ROLLER BEARING KIT

IR FLEX TUBING

IR BURNER VALVE

BURNER VALVE

32 33BEZEL AND SCREW

STAINLESS BURNER KNOB

STAINLESS ROTIS KNOB

STAINLESS BURNER KNOB

FRONT PANEL

BULLNOSE ASS'Y3538

LIGHT SWITCH

DRIP PAN27

INSULATING BUSHING

COMPLETE ELECTRODE KIT

BRIQUETTE TRAY

TRIDENT BURNER

TRANSFORMER

ROTISERIE CORD

HARNESS

POWER

ASS'Y

LIGHT

HOOD

CERAMIC-BURNER4445

QTY 35 PER BOX

(1 BOX PER BURNER)

BRIQUETTES

ROTISERIE JACK +

INTERNAL HARNESS

HOOD HANDLE

IR PANEL ASSY

BURNER ORIFICE, ROTIS ORIFICE (SEALEVEL TO 2000 FT ELEVATION)

SMOKER BOX

IR IGNITER COVER

REGULATOR

FIREBOX ASS'Y

HANGER

BURNER

16 WOODCHIP TRAY

ROLLER BEARING

HOOD STOP

HOOD SPACER

REAR HOOD ASSY

IR ELECTRODE

IR ELBOW

HOOD LIGHT ASS'Y12

22B

LIGHT PANEL9

WARMING SHELF4

5GRATE

EXTENSION SPRING56

(2-POSITION)

MOTOR MOUNTING BRACKET KIT

PROFESSIONAL SERIES

HEAVY DUTY, 3-SPEED MOTOR ASS'Y

END CAP FOR HOOD HANDLE

HOOD THERMOMETER

SPIT ROD 61

SPIT FORK

FRONT HOOD ASSY1

FIREBOX PARTITION

DRIP PAN

(NOT FIELD REPLACABLE)

KIT-ROTISSERIE

23 SCREW

69MATCH HOLDER

49 IR ACCESS COVER

50 SCREW

IR BURNER FRAME14B

IR ROTIS BURNER14A SCREW TO

14C

5328TRANSFORMER

TRANSFORMER

MOUNTING BRACKET

F/S SCREW

NUT

67NUT

30A

36GAS COLLECTOR BOX

HOOD

BUMPER

70B/I SCREW

34 LIGHT SWITCH

80DRAIN PLUG

MODEL SERIES 'R'

22A

22B

STOP

HOOD

LEFT

37 ELBOW

MANIFOLD PIPE COMPLETE ASS'Y43

78 HEAT SHIELD

30 30A

29LED HARNESS ASSY

INSULATION RETAINER 81

INSULATION 82

BULB

ATTACH IR BURNER

THERMOCOUPLE IR IGNITER

BRACKET

30B

LYNX PROFESSIONAL GRILLS EXPLODED PARTS VIEW

42 43

CARE & USE/INSTALLATION

LYNX PROFESSIONAL GRILLS PARTS LIST

PROFESSIONAL SERIES PARTS LIST

MODEL SERIES 'R'

01/24/18

MODEL-SPECIFIC BTU OUTPUTS & MAX. RUNS FOR APPLIANCES

GRILL SIZE

ITEM

2 3 4

6 7

8 9

14 L27

14A

14B

27,36,42,54

22 22A ALL BUMPER FOR HOOD STOP, .750 DIA 22B ALL HOOD STOP, LEFT, ALL PRO

27,30,36,42,54

30 ALL 30A KNOB KIT, STAINLESS (3 BURNER+1 ROTIS)90139 30B 30C

31 ALL

32 ALL

PART NO.

L27 L30 L36 L42

L54 ALL ALL

L27

L30

L36

L42

L54

L27

L30

L36

L42

L54

L54 ALL ALL ALL

ALL

L30

L36

L42

L54

L27

L30

L42

L54

27,30

36,42,54

ALL

L30

L36

L42

L54

L27

30,36,54

L42

L27

30,36,54

L42 ALL SCREW, #8-32 X 5/16 PH. FLAT HD3264414C

L27

L30

L36

L42

L54

27,30,5416

36,42

ALL

L30

ALL NG ALL LP

ALL ALL 32468

L27,L36 L27,L36 30,42,54 30,42,54 L27,L36 L27,L36 30,42,54

TRIDENT TRIDENT

30,36,54 30,36,54

L27" L27" L42" L42"

ALL

L27

L36 90225

L42

L54 ALL

27,30 36,42

L54

ALL

ALL33 ALL

L2735

L30

L36

L42

L54

FRONT HOOD ASSY, 27"

80322

FRONT HOOD ASSY, 30"

80309

FRONT HOOD ASSY, 36"

80310

FRONT HOOD ASSY, 42"

80311

FRONT HOOD ASSY, 54"

80312

MOTOR MOUNTING BRACKET KIT, ALL PRO

90132

MOTOR ASSY, HEAVY DUTY 3 SPEED

80277

WARMING SHELF, PRO 27"

32555

WARMING SHELF, PRO 30"

32109

WARMING SHELF, PRO 36"

32110

WARMING SHELF, PRO 42"

32111

WARMING SHELF, PRO 54"

32112

(2) GRATES- 12" x 18"

17012

(2) GRATES- 13 1/2" X 21"

30018

(2) GRATES- 16 1/2" X 18 1/2"

17020

(2) GRATES- 13 1/2" X 21"

30018

(1) GRATE- 12" X 21" (CENTER)

30019

(2) GRATES- 13 1/2" X 21"

30018

(2) GRATES- 12" X 21"

30019 20018

IR THERMOCOUPLE IR ELECTRODE, HOT SURFACE (SEE ALSO #73)

33052

GAS COLLECTOR BOX, IR ROTIS.

33093

GAS COLLECTOR BOX, IR ROTIS. R/H 54"L54 33102 SCREW, #6-32 X 1/4 PH. PAN HD14018ALL IR BRASS ELBOW, 7/16-20 MALE THREAD

31795

LIGHT PANEL/REAR HOOD LINER, 27" 32551L27 LIGHT PANEL/REAR HOOD LINER, 30"

32156

LIGHT PANEL FOR DUAL LIGHTS, 36"

32441

LIGHT PANEL FOR DUAL LIGHTS, 42"

32442

LIGHT PANEL FOR DUAL LIGHTS, 54"

32159

REAR HOOD ASSY, PRO 27"

80320

REAR HOOD ASSY, PRO 30"

80269

REAR HOOD ASSY, PRO 36"

80270L36 80271

REAR HOOD ASSY, PRO 42"

80272

REAR HOOD ASSY, PRO 54" HOOD SPACER KIT, ALL PRO SERIESALL11 90237

80446

HOOD LIGHT ASS'Y, SINGLE W/10W BULB

80447

HOOD LIGHT ASS'Y, DUAL W/10W BULB

31979

BULB, REPLACEMENT, 10W HALOGEN GLASS REPLACEMENT COVER W/ CLIP32322ALL

80318

IR PANEL ASSY, PRO 27" (INCLUDES BURNER)

80273

IR PANEL ASSY, 30" (INCLUDES BURNER)

80274

IR PANEL ASSY, 36" (INCLUDES BURNER)

80275

IR PANEL ASSY, 42" (INCLUDES BURNER)

80276

IR PANEL ASSY, 54" (INCLUDES BURNER) IR ROTIS. BURNER ONLY (SMALL-16 IN.)

32988

IR ROTIS. BURNER ONLY (MEDIUM-21 IN.)

32989

IR ROTIS. BURNER ONLY (LARGE-28 IN.)

32990

IR BURNER FRAME ONLY (SMALL-16 IN.)

32991

IR BURNER FRAME ONLY (MEDIUM-21 IN.)

32992

IR BURNER FRAME ONLY (LARGE-28 IN.)

32993

10067

BURNER HANGER, PRO 27"

32484

BURNER HANGER, PRO 30"

32245

BURNER HANGER, PRO 36" 32485 32486

BURNER HANGER, PRO 54" 10159

WOODCHIP TRAY (27", 30", 54") 10158

WOODCHIP TRAY (36", 42") 33059

IR IGNITER BRACKET, PRO 33060 IR IGNITER BRACKET, RIGHT, 54" L54 33135

IR IGNITER COVER, PRO 30" 33136

IR IGNITER COVER (27", 36", 42", 54") 30781

REGULATOR 4/11 N/G ONLY 13053

REGULATOR W/30" HOSE DOUBLE STAGE-LP

FIREBOX PARTITION, TRIDENT 30",42',54"30,42,54

33662

FIREBOX PARTITION, TRIDENT 27"/36"27/36

33663 90128

ROLLER BEARING KIT-ROTISSERIE (2 PARTS EA)

HOOD STOP, RIGHT, ALL PRO 32470 33389

SCREW/HOOD STOP-#8-32 X 1" PH TRUSS HD32469ALL

COMPLETE CONVERSION FIELD KIT-LP TO NG

PRENGK

COMPLETE CONVERSION FIELD KIT-NG TO LP

PRELPK

COMPLETE CONVERSION FIELD KIT-LP TO NG

PRONGK

COMPLETE CONVERSION FIELD KIT-NG TO LP

PROLPK

13013

ORIFICE,BURNER, NG (#41 SHORT) 13019

ORIFICE,BURNER, LP (#53 SHORT) 30329

ORIFICE,BURNER, NG (#41 L0NG)

ORIFICE,BURNER, LP (#53 LONG)

3032830,42,54 13015

ORIFICE,BURNER, NG (#44 SHORT) 13020

ORIFICE,BURNER, LP (#54 SHORT) 13016

ORIFICE, IR ROTIS., NG (#50 SHORT) 13021

ORIFICE, IR ROTIS., LP (#57 SHORT) 13016

ORIFICE, IR ROTIS., NG (#50 SHORT) 13021

ORIFICE, IR ROTIS., LP (#57 SHORT) 30470

ORIFICE, IR ROTIS., NG (#48 SHORT) 31342

ORIFICE, IR ROTIS., LP (#56 SHORT) 90129

ROLLER BEARING KIT-DRIP PAN (2 PARTS EA) 34586

SMOKER SET 90223

DRIP PAN COMPLETE, PRO 27"

DRIP PAN COMPLETE, PRO 30"

90224L30

DRIP PAN COMPLETE, PRO 36"

DRIP PAN COMPLETE, PRO 42"

90226

DRIP PAN COMPLETE, PRO 54"

90227

TRANSFORMER MOUNTING BRKT B/I & F/S

33130 80435 LED HARNESS ASSY, 27"/30-IR 80436

LED HARNESS ASSY, 36"/42" 80437 LED HARNESS ASSY, 54"

LED HOLDERALL 32554 90137

KNOB, BURNER, STAINLESS

KNOB KIT, STAINLESS (2 BURNER+1 TRI. +1 ROTIS)90231ALL

KNOB, TRIDENT BURNER90230ALL 90136

KNOB, ROTIS, STAINLESS 10001

BEZEL 31929

BEZEL SCREW, #6-32 X 1/8 PH PAN 33148

LIGHT SWITCH + HARNESS, BLUE LIGHTED 80536

FRONT PANEL, PRO 27"

FRONT PANEL, 30"

80539

FRONT PANEL, PRO 36"

80538

FRONT PANEL, PRO 42"

80540 80541

FRONT PANEL, PRO 54"

DESCRIPTION

36 37

ALL NG

L2738 L30 L36 L42

L54 39 ALL 40

ALL41 42 ALL

L27

L30

L36

L42

L54

L54 44

27,30

ALL

45 46 TRIDENT

30,42,54

27,36

30,42,54

42,54 42,54 27,36 27,36

ALL

48 49

ALL SCREW, 1/4-20 X 3/8 PH TRUSS HD, S/S14012 5150ALL

ALL

L27

L30

L36

L42

L54

30,42,54

27,36

ALL

58 59 ALL

60 ALL

ALL

ALL 61 L27

L30

L36

L42

L54 62

ALL

64 65 LEFT RETAINING BRACKET, WARMING RACKALL 33597 66 ALL 14014 SCREW #8-32 x 3/8 PH TRUSS HEAD S/S 67 ALL 14024 LOCK NUT, #8-32, S/S 68 ALL 31930 BOLT, HEX HEAD, 1/4-20 X 3/8", S/S 69

ALL 70

ALL 71

ALL 31649 SCREW, #8-32 X 5/8 PH. PAN HD, S/S 72

30,42,54 33609 BRIQUETTE DIVIDER 30",42",54"

ALL 75 76 77 ALL WASHER, #10 SPLIT LOCK, S/S32197

L27

L30

L36

L42

L54

ALL 14023 NUT, COMBINATION (FOR HEAT SHIELD)

ALL

L2781 RETAINER, INSULATION34677

L30 RETAINER, INSULATION34676

L36 RETAINER, INSULATION34630

L42 RETAINER, INSULATION34629

L54 RETAINER, INSULATION34675

L2782

L30

L36

L42

L54

ALL83 BURNER CAP (SET OF 4)90265

GAS COLLECTOR BOX, CERAMIC-BURNER36438 ELBOW, STREET, 1/2" 90 DEGREE-NG ONLY

13010 13054 ELBOW, 3/8" FLARE TO 1/2" FIP-LP ONLYALL LP 80514

BULLNOSE ASS'Y, PRO 27"

80516

BULLNOSE ASS'Y, PRO 30"

80515

BULLNOSE ASS'Y, PRO 36"

80517

BULLNOSE ASS'Y, PRO 42"

80518

BULLNOSE ASS'Y, PRO 54"

31772

IR BURNER VALVE W/ MICROSWITCH BURNER SUPPORT, TRIDENT 30,42,543340530,42,54 P/S

3380927,36 P/S BURNER SUPPORT, TRIDENT 27,36

FLEX HOSE, 9 MM X 38" W/ 7/16 FITTINGS

31794

MAIN BURNER VALVE W/ MICROSWITCH

34103

MICROSWITCH REPLACEMENT FOR VALVE32845ALL MANIFOLD ASS'Y W/VALVES, 27" LP

80251

MANIFOLD ASS'Y W/VALVES, 27" NG

80253

MANIFOLD ASS'Y W/VALVES, 27" LP TRIDENT

80429

MANIFOLD ASS'Y W/VALVES, 27" NG TRIDENT

80428

MANIFOLD ASS'Y W/VALVES, 30" LP

80212

MANIFOLD ASS'Y W/VALVES, 30" NG

80214

MANIFOLD ASS'Y W/VALVES, 30" LP TRIDENT

80211

MANIFOLD ASS'Y W/VALVES, 30" NG TRIDENT

80213

MANIFOLD ASS'Y W/VALVES, 36" LP TRIDENT

80227

MANIFOLD ASS'Y W/VALVES, 36" LP

80228

MANIFOLD ASS'Y W/VALVES, 36" NG TRIDENT

80229

MANIFOLD ASS'Y W/VALVES, 36" NG

80230

MANIFOLD ASS'Y W/VALVES, 42" LP TRIDENT

80201

MANIFOLD ASS'Y W/VALVES, 42" LP

80202

MANIFOLD ASS'Y W/VALVES, 42" NG TRIDENT

80203

MANIFOLD ASS'Y W/VALVES, 42" NG

80204

MANIFOLD ASS'Y W/VALVES, 54" LP TRIDENT

80220

MANIFOLD ASS'Y W/VALVES, 54" NG TRIDENT

80221

COMPLETE ELECTRODE KIT, 27"/30" IR90185 COMPLETE ELECTRODE KIT, 36"/42"9018736,42 COMPLETE ELECTRODE KIT, 54" 90188L54 CERAMIC-BURNER

36160 33415

TRIDENT BURNER, 30", 42", 54"

90181

SCREEN REPLACEMENT, TRIDENT 2 BURNER

33478

TRIDENT BURNER, SHORT, 27"/36"27,36

90179

SCREEN REPLACEMENT, TRIDENT 2 BURNER, 27/36 BRIQUETTE TRAY, WIDE, 30", 42", 54"

80645

COMPLETE TRAY W/ BRIQUETTES & CLIPS

90191

BRIQUETTE TRAY, NARROW, 42",54"

80644

COMPLETE TRAY W/ BRIQUETTES & CLIPS

90190

BRIQUETTE TRAY, 27", 36"

80643

COMPLETE TRAY W/ BRIQUETTES & CLIPS

90189

BRIQUETTES, 35 PER BOX

90053

IR ACCESS COVER30417ALL

ROTISERIE JACK + INTERNAL HARNESS

80440

JACK ONLY, DC PANEL MOUNT33129ALL MAIN POWER HARNESS (27, 30, 36, 42, 54)

80533

TRANSFORMER, 5 AMP, ALL PRO

33100

ROTISERIE EXTERNAL CORD

33416

HOOD HANDLE, 27"

32557

HOOD HANDLE, 30"

32522 32523

HOOD HANDLE, 36"

32524

HOOD HANDLE, 42"

32525

HOOD HANDLE, 54"

31874

EXTENSION SPRING, 30", 42", 54"

31780

EXTENSION SPRING, 27", 36"

31738

INSULATING BUSHING, HOOD HANDLE

31736

END CAP FOR HOOD HANDLE

35765

HOOD THERMOMETER, SEALED (BLACK) 33573ALL WASHER FOR HOOD THERMOMETER 14013 PIVOT SCREW, 1/4-20 X 1" HEX DRIVE

PIVOT SCREW NUT, HEX, 1/4-20 S/S14009

PIVOT WASHER, SPLIT LOCK, 1/4 S/S14026 32556

SPIT ROD, PRO 27" 32128

SPIT ROD, PRO 30" 32129

SPIT ROD, PRO 36" 32130

SPIT ROD, PRO 42" 32131

SPIT ROD, PRO 54" 31563

SPIT FORK, HEAVY DUTY, ALL SIZES

FRONT RETAINING BKT., WARMING RACK 33033 32133 REAR RETAINING BRACKET, WARMING RACK

ALTERNATE LIGHTING DEVICE, MATCH HOLDER31031 31013 SCREW, #8 X 1/2 PH TRUSS HD TYPE 'A'

HOOD BUMPER, .500 DIAALL 32477

33751 BRIQUETTE DIVIDER 27",36"27,36

SCREW, #10-24 X 3/4 PH FLAT HD S/S14099

ROTIS. SPACER32939ALL

NUT, ACORN, #10-24, S/S32196ALL

HEAT SHIELD, PRO 27"

33657

HEAT SHIELD, TRIDENT 27"

33652

HEAT SHIELD, PRO 30"

33659

HEAT SHIELD, TRIDENT 30"

33654

HEAT SHIELD, PRO 36"

33658

HEAT SHIELD, TRIDENT 36"

33653

HEAT SHIELD, PRO 42"

33660

HEAT SHIELD, TRIDENT 42"

33655

HEAT SHIELD, TRIDENT 54"

33656

32839

DRAIN PLUG, DRIP PAN

INSULATION (27" X 6")20021

20021

INSULATION (30" X 6")

20021

INSULATION (36" X 6")

20021

INSULATION (42" X 6")

20021

INSULATION (54" X 6")

PART NO.GRILL SIZEITEM DESCRIPTION

ALL

MODEL-SPECIFIC BTU OUTPUTS

MODEL CERAMIC BURNER (Btu) ROTISSERIE (Btu) TRIDENT ™(Btu) TOTAL INPUT L27R 2 @ 25,000 1 @ 14,000 64,000 Btu/Hr L27TR(F) 1 @ 25,000 1 @ 14,000 1 @ 21,000 62,000 Btu/Hr

L30R(F) 2 @ 25,000 1 @ 14,000 64,000 Btu/Hr L30TR(F) 1 @ 25,000 1 @ 14,000 1 @ 21,000 62,000 Btu/Hr

L36R 3 @ 25,000 1 @ 14,000 89,000 Btu/Hr L36TR(F) 2 @ 25,000 1 @ 14,000 1 @ 21,000 87,000 Btu/Hr

L42R 3 @ 25,000 1 @ 16,000 91,000 Btu/Hr L42TR(F) 2 @ 25,000 1 @ 16,000 1 @ 21,000 89,000 Btu/Hr

L54TR(F) 3 @ 25,000 2 @ 14,000 1 @ 21,000 126,000 Btu/Hr

MAXIMUM RUNS FOR ALL

APPLIANCES ON SUPPLY LINE

Run Length

3/4” Pipe (in feet)

10 360,000 20 245,000 30 198,000 40 169,000 50 150,000 60 135,000 70 123,000 80 115,000

Max BTU for all

Appliances on line

44 45

CARE & USE/INSTALLATION

INSULATED JACKET INSTALLATION INSTRUCTIONS

IMPORTANT: Before you build the frame, you must take into consideration the total weight of the liner, grill and any ﬁnishing materials.

4” square holes for gas and electrial connections both left and right sides (rear or bottom access). Make these holes in the frame based on your requirements.

1” Screws can be provided to help straighten out the

sides of the LIJ if necessary. Contact Lynx for details.

INDEX

Refer to the table below for the proper framing dimensions for the insulation jacket. Determine the entry point for both the gas inlet and electricl connections. Make the 4” square holes for gas and electrical connections (rear or bottom access) based on your requrements. Note that the electrical connections are located on the left side and the gas connections are located on the right side.

A Carpenter’s “spirit level” should be used to assure that the framing is level, both front to back and side to side.

Note: Never under any circumstance should you install the transformer, run wiring or run a quick disconnect hose inbetween the grill and the inside of the insulating jacket.

Model A B C D E F LIJ27 LIJ30

LIJ36 LIJ42 LIJ54

33 5 24 4 ½ 3 11 36 5 26 ½ 4 ½ 3 11 42 5 24 4 ½ 3 11 48 5 26 ½ 4 ½ 3 11 60 5 26 ½ 4 ½ 3 11

5/8

LINER INSTALLATION

Posititon the liner into the frame. No part of the combustible enclosure can protrude above the top surface or in front of the face surface of the liner. Shim the liner if necessary.

GRILL INSTALLATION

Use the proper equipment to support the grill. Place the grill into the liner and engage it over the liner lip across the back and sides. The liner is designed to support the grill without additional fasteners.

FINISHING

If desired any gap remainng between the liner and the combustible enclosure may be ﬁlled with a non-combustilble sealant or caulk.

Note: for service the grill must be removable.

Before Each Use ........................................................... 25

Before You Start ............................................................. 8

BTU Outputs, Model Speciﬁc ...................................... 45

Burner Adjustment, Low ............................................... 19

Burner Adjustment, Main ............................................. 19

Burner Appearance ...................................................... 20

Burner Placement ........................................................ 32

Checklist Before Each Use ............................................ 21

Clean the Ceramic Burner ............................................ 32

Cleaning Your Lynx Grill ............................................... 31

Clearance to Combustibles ............................................ 9

Contacting LYNX .......................................................... 37

Cut-out Dim., Built-in Grills .......................................... 10

Damage:

Concealed ...................................................................... 8

Visible ............................................................................. 8

Direct Heat Cooking .................................................... 27

Drip Tray ...................................................................... 31

Electrical Connections ................................................. 18

Exploded Parts View .................................................... 43

Final Checks ................................................................. 19

Flame, Correct Size ...................................................... 20

Gas Connections .......................................................... 14

Gas Line Purging .......................................................... 16

Gas Requirements ........................................................ 14

Gas Supply Line Runs ................................................... 45

Grilling in Windy Conditions ........................................ 23

Important Safety Precautions ....................................... 22

Indirect Heat Cooking ................................................. 27

Insulated Jacket Installation........................................... 46

Lighting Rotisserie Burner ........................................ 7, 25

Low Heat Burner Adjustment ...................................... 19

LP Cylinder Requirements ........................................... 15

LP Gas ......................................................................... 15

Manual Lighting ............................................................ 26

Match Lighting ............................................................. 26

Maximum Runs for all appliances on supply line .......... 45

Obtaining Service From LYNX ...................................... 37

Parts List ....................................................................... 44

Parts View, Exploded ................................................... 43

Pre-Heating Trident ™ Burner ...................................... 28

Pre-Heating the Grill .................................................... 27

Purging the Gas Line .................................................... 16

Regulator Conversion .................................................. 15

Required Maintenance ................................................ 33

Schematic, L27 & L30 ................................................... 40

Schematic, L36 & L42 ................................................... 41

Schematic, L54 ............................................................. 42

Service, Contacting Lynx ............................................. 37

Technical Support ........................................................ 37

Troubleshooting ........................................................... 33

Unpacking & Assembly ................................................. 12

Using Your Grill ............................................................ 24

Warranty:

Warranty, Limited .......................................................... 38

Warranty, Common Area Limited ................................. 39

Windy Conditions, Grilling in ....................................... 23

CARE & USE/INSTALLATION

Leak Test Procedure ..................................................... 19

Lighting, Manual .......................................................... 26

Lighting Your Grill .................................................... 7, 25

CARE & USE/INSTALLATION

PN #35283

The best outdoor kitchen products come from:

Lynx Grills, Inc. 7300 Flores Street Downey, CA 90242

Service: (888)-289-5969 Fax: (562) 299-6978

www.lynxgrills.com

Lynx L27R-3, L27TR, L27TRF, L30R-3, L30TR User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
