Lynx EPM-4 User Manual

Reference Manual
DOC. REV. 3/16/2009
EPM-4 (Lynx)
AMD ÉlanSC520 processor module with 10/100 Ethernet, and PC/104-Plus interface.
EPM-4
AMD ÉlanSC520 processor module with 10/100 Ethernet, and PC/104-Plus interface
MEPM4
Product Release Notes
This page includes recent changes or improvements that have been made to this product. These changes may affect its operation or physical installation in your application. Please read the following information.
Rev 5 Release
EPM-4h model release – RoHS extended temperature version.
Rev 4 Release
PC/104 (ISA) connector keyed to better comply with standard. PC/104 connector soldered instead of press-fit.
Physically smaller fuse at F1 with same protection value.
3.0V battery.
Rev 3 Release
EPM-4g model release – Initial RoHS version.
Rev 2 Release
Initial public release.
Support Page
The EPM-4 Support Page, at http://www.VersaLogic.com/private/lynxsupport.asp contains additional information and resources for this product including:
Reference Manual (PDF format)
Operating system information and software drivers
Data sheets and manufacturers’ links for chips used in this product
BIOS information and upgrades
Utility routines and benchmark software
Note: This is a private page for EPM-4 users only. It cannot be reached through our web site. You must enter this address dire
ctly to find the support page.
